Caddytek CaddyLite 13.5 User manual

Quad-Fold Deluxe Golf Push Cart
Model: CaddyLite 13.5
User’s Manual Ver.1

WARNING:
FOR YOUR OWN SAFETY, PLEASE REVIEW
THESE WARNINGS AND KEEP THIS USER
GUIDE FOR FUTURE REFERENCE.
●Before using this golf cart, please read and
understand the important instructions and
warnings in this user guide.
●AVOID INJURY by always following the folding
and unfolding the cart instructions carefully.
●AVOID INJURY by keeping clear of moving parts
while adjusting, folding or unfolding this cart.
●ALWAYS make sure the cart is fully extended
and locked before use.
●ALWAYS make sure the cart is folded and
locked properly before lifting or transporting.
●ALWAYS use the brake when parking the cart.
●DO NOT run while using this cart.
●DO NOT use accessories other than those
designed specifically for this cart.
●Keep hands and fingers away from moving parts
or sliding sections of the cart!

Unfolding the cart
Step1: Adjust the
upper bracket to
proper position as
in fig.1
Step2: Unlock the
lower red buckle to
release front wheel
fork as in fig. 2
Step 3: Push the front
wheel fork downward
until the support bracket
clicks and then lock the
red buckle as in fig. 3
Fig.1
Fig.2
Fig.3
2

Folding the cart
Step 1: Press the red button
and rotate the front wheel
counterclockwise 180
degrees to outside of the
cart as in fig. 6
Step 2: Release the lower
red buckle, fold the front
wheel folk till it click to
position. Lock the buckle as
in fig. 7 & 8
Fig.6
Fig.7
Fig.8
4

Umbrella Holder
Assembly
To put in use:
Simply attach the umbrella
holder onto the cart as in fig.
a&b
To store:
Attach the umbrella holder to
the storage rack on the handle
as in fig. c & d
Install and Remove the main wheels & se the brake
Press the red button on the wheel holder to remove or install the
rear wheel.
Step on the brake pad to activate and step on again to
deactivate the brake
Fig.a
Fig.b Fig.c
Fig.d
6

WARRANTY
CaddyTek Inc. warrants its products to be free of
defects and workmanship for one year from the
date of purchase. We will either repair or replace
defective products at our option.
Normal wear and fading of products is not
considered a manufacturer's defect. This
warranty does not apply to claim of damage to
items used in connection with CaddyTek Inc.
products. In the case of deterioration due to
normal use we will repair the item for a normal
charge. CaddyTek Inc. is the sole judge of any
claim or warranty.
8
Bag Holder Strap Adj stment
Refer to the Fig.i & Fig.j:
1.Pull the elastic strap out of the strap buckle as in Fig.i.
2.Adjust the strap to desired length.
3.Push the elastic strap back to the strap buckle as in Fig.j.
Fig.i Fig.j

Caddytek Inc.
20153 Paseo Del Prado
Walnut, CA 91789, USA

Package contents:
1.The main frame of the cart with the front wheel
2.Two main wheels
3.Umbrella holder
4.This user’s manual
5.Hangtag on the handle
6.Tools for adjustment
In case any of above item is missing or damaged, please call
909-895-6478
Part Identification:
A: Foam grip
B: Umbrella holder
C. Umbrella holder base
D: Scorecard holder assembly
E: Storage net
F: Handle frame
G: Upper bag holder bracket assembly
H: Adjustable handle mechanism
I: Main frame
J: Connection Rod
K: Leg bracket
L: 2 holes leg frame
M: 3 holes leg frame
N: Lower bag holder bracket assembly
O: Lower frame lock mechanism
P: Supporting cable
Q: Right stabilization bar
R: Right wheel lock mechanism
S: Rear wheel assembly
T: Front wheel fork assembly
U: Front wheel assembly
V: Left wheel lock mechanism
W: Footbrake
X: Left stabilization bar
Y: Umbrella holder rack
1

Step 4: Push the red
button to rotate the front
wheel clockwise 180
degrees to the inner side
of the cart as in fig. 4
Step 5: Release the handle
buckle, adjust handle to
desired position, then tighten
the button as in fig. 5
The cart now is ready for
use.
Fig.4
Fig.5
3

Step 3: Push the upper
bag holder bracket
downward to the folding
position as in fig. 9
Step 4: Release the upper
red button to fold the
handle downward then
tighten it as in Fig.10
Fig.9
Fig.10
5

Adj sting & tightening the handle
If the handle becomes
loose during normal use,
please use the supplied
tool to tighten the handle
as in Fig.h.
Front Wheel Alignment
13
If the cart veers to the right:
Step 1: Face the front wheel of the cart and use the provided
Allen wrench to loose the two side screws as in Fig.e.
Step 2: Then use the Allen wrench to adjust the front bolt
clockwise until the front wheel is centered as in Fig.f. Then
tighten the two side screws as in Fig.g.
.
If the cart veers to the left:
Step1: The same as above.
Step 2: Adjust the front bolt counterclockwise until the front
wheel is centered as in Fig.f. Then tighten the two side
screws as in Fig.g.
Fig.g
Fig.e Fig.f
7
Fig.h

9
