Caddytek incontro sports Operating and maintenance manual

EZ Version 8 Push Buggy
INSTRUCTIONAL MANUAL
www.incontrosports.com.au / 03 5924 6056

Parts Identification:
A: Ergonomic Handle
B: Umbrella Holder
C. Umbrella Holder Base
D: Scorecard holder assembly
E: Umbrella Holder Storage Rack
F: Handle Frame
G: Upper Adjustable Bag Straps
H: Handle Height Adjusting Knob Assembly
I: Main Frame
J: Front Connection Rod
J1: Main Connection Rod
K: Leg Frame Bracket
L: Leg Frame
L1: Leg Frame
M: Leg Frame
N: Lower Adjustable Bag Straps
O: Optional Seat Installation Slot
P: Supporting Cable
Q: Right Stabilization Bar
Q1: Left Stabilization Bar
R: Right Wheel Lock Mechanism
R1: Left Wheel Lock Mechanism
S: Rear Wheel Assembly
T: Front Wheel Fork Assembly
U: Front Wheel Assembly
V: Foot Brake
X: Drink Holder
Y: Handle Mesh Carry Bag
Z: Main frame folding holder
Z1: Sand Bucket Hook
Z2 Elastic Rope of Upper Bracket
1
O
Z
Z2

Assemble the Buggy
Lift the upper bag holder
bracket.
Make sure the handle height
adjusting knob is fully tightened.
Pull the handle and upper bag
bracket as shown in Fig. 2 to
extend the buggy. (Shake the
buggy slightly to release the main
frame from the holding slot.)
Release the wheel locking lever,
insert the wheel axel into the wheel
holder completely and then tighten
the locking lever.
The buggy is fully
extended as shown in
Fig. 6.
Fig. 1
Fig. 2
Fig. 4
Fig. 5
Fig. 6
locking lever
2
As shown in Fig 4, press the
button and rotate the front
wheel 180 degree clockwise
so the front wheel is at centre
of the buggy.
button
Handle Height
Adjusting Knob
button
button
Fig. 3
Press the button on both
sides of the golf bag holder
mechanism to unfold the bag
support wings automatically
as shown in Fig. 3.
Unfolding Motion

Press the button and rotate
the front wheel 180 degree
counterclockwise so the front
wheel is on the right of the
front wheel fork (when you
stand in front of the buggy).
The buggy is fully
folded.
Fig. 7
Fig. 12
Fig.13
3
Folding The Buggy
Folding button
Fold down the upper
bag holder bracket.
Fig. 8
Fig. 9
Fig. O
adjusting
knob
Fig. 10
handle height
button
You can secure the folded buggy with the
lower bag holder elastic rope as shown in
Fig.14/15.
Fig. 11
Fig.14
Fig.15
Make sure the handle height adjusting knob is fully tightened .Slightly lift
up the handle as Fig. 8 then press the folding button and push the handle
downward as shown in Fig. 9. Continue to push down on handle as per
Fig. 10, until the main frame clicks into the holding slot as in Fig.O. Then
Push the golf bag bracket wings inwards to close the wings as shown in
Fig.11.

Umbrella Holder
To install:
Simply attach the umbrella holder onto the buggy as in
fig. 19/20.
Fig. 19
Fig. 21
4
Fig. 20
To store:
Attach the umbrella holder to
the storage rack on the right
leg frame as in Fig. 21.
Applying The Brake
Install The Drink Holder
Press the foot brake to
brake, lift it up to release
as Fig. 22.
Fig. 17
Fig. 16
Fig. 18
Fig. 22
Hole 2
When installing the drink holder as Fig.16, align the smallest part of the slot on the holder with the
fixed blocks. Then pull horizontally to fit the holder on the base as Fig.17 & 18.
Hole 1
Hole 2
Upper Bracket
To Tighten, push both
wings inwards to
clamp the bag as
shown in Fig.23.
To release the bag, press
the button at the back of
upper bracket to loosen the
wings as shown in Fig.24.
button
button
Fig. 23
Fig. 24
Fixed block on base notch
Slot on drink holder

Fig. 26
Fig. 25
Refer to Figs. 25 and 26:
1. Pull the elastic strap out of the strap buckle, as in Fig. 25.
2. Adjust the strap to the desired length.
3. Push the elastic strap back to the strap buckle, as in Fig. 26.
Optional Upper Bag Holder Strap
When playing hilly golf course with steep downhill slopes or if the golf bag is an abnormal
shape or size, this optional upper bag holder strap can help to further secure the golf bag
and prevent the golf bag moving in the bag holder bracket.
Hole
Knot
Fig.1
Fig. 2
Fig.3
1. Put the elastic strap through the hole on the
tip of the bag holder wing as shown in Fig. 1
and Fig.2.
2. Adjust the strap to the desired length, then
tie a knot to fix the length of the strap as
shown in Fig. 3.
3. The length of the elastic strap can also
be adjusted as shown in Fig. 4 and
Fig. 5. Pull the strap out of the buckle,
adjust the strap length and then set the
strap back to the buckle tightly.
Fig.4
Fig.5
Lower Bag Holder Strap Length Adjustment

Front Wheel Alignment
If the buggy veers to the right:
Step 1: Face the front wheel of the buggy and use the provided Allen Key to loosen the two
side screws as in fig. 27.
Step 2: Then use the Allen Key to adjust the front bolt clockwise until the front wheel is
centered as in Fig. 28. Then tighten the two side screws as in fig. 29.
If the cart veers to the left:
Step1: The same as above.
Step 2: Adjust the front bolt counterclockwise until the front wheel is centered as in fig.25.
Then tighten the two side screws as in fig. 26.
Fig. 28
Fig. 27
5
Fig. 29
bolt
screws
screws
