Cake OSA Series User manual

ösa
manual

Hello and Welcome!
We are extremely flattered that you have chosen to ride a CAKE electric motorbike.
It's our obligation to do the best we can to serve you with product information,
service, and spare parts for an effortless experience.
Our ambition is to develop uncompromising high-performance off-road
motorbikes.
CAKE's mission is to inspire people, contributing to speeding up the journey
towards a zero-emission society, combining excitement with responsibility.
To optimize the performance and benefits for a motorbike with an electric
drivetrain, establishing a new category, we needed to start from scratch.
Every little detail, hard and software has been engineered, designed, and chiseled
for perfection while considering the perspectives of sustainability.
This manual should be your tool and guidance for general maintenance, safety
precautions, service matters - stretching from what may be dealt with by yourself
and what needs to be handed over to professional mechanics, tuning, warranty
aspects, handling, and troubleshooting.
Explore with Respect
Stefan Ytterborn Founder & CEO

1. INTRODUCTION AND GETTING STARTED 3
1.1 INTRODUCTION 3
1.2 UNPACKING 3
1.3 GETTING STARTED 3
2. GENERAL INFORMATION 4
2.1 SAFETY ADVICE 4
2.2 START-UP PROCEDURE 4
2.3 HOW TO CHANGE THE PIN 5
2.4 POWER OFF PROCEDURE 5
2.5 STEERING LOCK 5
3. HANDLEBAR CONTROLS 6
3.1 KILL SWITCH 6
3.2 THROTTLE 6
3.3 BRAKES 6
4. OPERATING THE DISPLAY 6
4.1 DISPLAY 6
4.2 RIDE MODE 6
4.2A ÖSA LITE 7
4.2B ÖSA+ 7
4.3 CHANGING RIDE MODE 7
4.4 BRAKE MODE 8
4.5 CHANGING BRAKE MODE 8
4.6 CHANGE BETWEEN MILES PER HOUR AND KILOMETERS PER HOUR 8
4.7 RESET THE TRIP METER 8
4.8 CHANGE BETWEEN ODOMETER AND TRIP METER 8
5. CHARGING AND BATTERY 9
5.1 BATTERY 9
5.2 REMOVAL OF THE BATTERY AND BATTERY LOCK 10
5.3 CHARGING 10
6. OWNERSHIP AND MAINTENANCE 11
6.1 CLEANING 11
6.2 CLAMPS AND ACCESSORIES11
6.2 STORAGE 12
6.3 CRASH 12
6.4 TROUBLESHOOTING 12
6.5 TOOLS 13
7.0 SUPPORT AND CONTACT 14

1. Introduction and getting started
1.1 Introduction
Please read the manual to its entirety to ensure that you understand the functions
and operation of this vehicle before you ride.
To get the most out of your ÖSA electric motorcycle, and to ensure safe operation,
it's critical that you fully understand the features of this bike. This manual includes
important information that every rider needs to fully understand. Please study this
manual cautiously in its entirety before your first ride on your new CAKE, ÖSA. Do
not ride the motorcycle until you've attained enough understanding of its controls
and features.
We are a growing company that wants to get better at everything we do. Make
sure you have the latest manual with up to date information on how to best take
care of your ÖSA and get the most out of your vehicle.
The latest manual can be found at www.ridecake.com/manuals
1.2 Unpacking
You will receive your CAKE ÖSA in a cardboard box. To ensure that the unpacking
process is smooth and that you don’t damage the ÖSA or yourself, make sure to
go to www.ridecake.com/manuals and see the unboxing video tutorial and how to
unpack and assemble the bike.
The video features easy step-by-step guidance and what tools are needed.
1.3 Getting started
Before you are ready to take your first ride on the ÖSA, please follow the steps
below to make sure to not make any damage to the vehicle, property, or injure
yourself or others.
During transportation, the bike might have become damaged. We can't guarantee
the bike’s rideability as it has been strapped down for up to several weeks before
you receive it. During shipping, some components might have become loose or
even damaged.
• Read the manual and understand the information. If anything is unclear, please
get in touch with our service team.
• Charge the battery.
• Make sure that the handlebar is tightened firmly and in a comfortable riding
position.
• Check the suspension.
• Tighten and check that the assembly of the front wheel is correct and safe.

2. General information
2.1 Safety Advice
When riding a CAKE bike for the first time, there are a few things to consider.
The bike has an electric motor with instant torque and a primary drive with no
gears or clutch, which means you have all the power available at all times using
the throttle. It's very sensitive and it's highly recommended to start riding using
Ride Mode 1 in order to get used to riding the ÖSA.
• Learn the handlebar controls and how to operate the bike.
• Check the bike for any damages to make sure it’s in a roadworthy condition.
• Never ride the bike under the influence of alcohol or drugs.
• Always check your local laws and regulations.
• Make sure that you have the correct driving license to operate the motorcycle on
the street.
• Always use the bike with appropriate gear and protection.
2.2 Start-up procedure
Your bike should be fully assembled. Check the chapter “5.3 Charging” to charge
the battery to full.
To start your ÖSA, follow the steps below
1. Battery. Start the battery by pressing the ON/OFF button on the right side of
the battery. The button should be pushed in and you will see white LED
lights indicating the battery’s SOC (state of charge). Charge the battery if
empty or low. The battery is now powered on.
2. Kill switch. On the right side of the handlebar, you will find the kill switch,
flip the switch to activate.
3. Display. Press and hold the power button (white outline) on the display for 1
second. This will start the display and will let you enter your PIN code. The
bike comes with factory settings and the generic PIN code “123”. Each
button has a corresponding digit, with the number being displayed on the
side of the button.

2.3 How to change the PIN
We advise you to change the PIN to personalize your bike and avoid it from
getting stolen.
Once the PIN has been changed, write it down and don’t lose it. If you would lose
or forget your PIN code has to be reset by the Cake service team.
Your PIN can consist of either 3 or 6 digits. The available digits are 1, 2, or 3. A PIN
can for example be “131”, “113”, “132212” or “123321”.
1) In the “ENTER YOUR PIN” screen, hold button 2 and 3 (middle and lower)
simultaneously for 5 seconds
2) Enter the current PIN (factory default = “123”)
3) Enter your new PIN
4) Enter your new PIN again to confirm
5) Your new PIN is now set, please restart the bike to make sure it works.
2.4 Power off procedure
Follow the below procedure to safely power off your ÖSA.
1) Press and hold the power button on the display for 2 seconds to de-activate
the bike. The de-activation procedure can only be initiated when the
motorcycle is not running.
2) Turn off the battery by pushing the ON/OFF button on the right side of the
battery.
The “Power off” procedure can only be initiated when the motorcycle is not
running.
Turn off the battery by pressing the button on the right side of the battery.
2.5 Steering lock
When leaving the bike unattended, always use the steering lock as a safety
precaution.
The steering lock is engaged by using the bike-specific key that was sent along
with the bike. The steering lock is located in front of the bike, on the left side of
the main beam, above where the front fork connects to the main beam. To
activate the lock, pull the handlebar so it angles to the left while twisting the key.
When the key is removed, the handlebar should have some play but still have a
limited range of motion.
Apart from the steering lock, CAKE always recommends all our customers to invest
in a proper and approved chain and lock for motorcycle use to prevent your bike
from being stolen.

3. Handlebar controls
3.1 Kill switch
The kill switch is located on the right side of the handlebar.
The kill switch is used to turn off the power to the controller. There are two
different positions on the kill switch, on and off.
3.2 Throttle
The throttle is located on the right side of the handlebar. It’s a twist throttle that
gradually increases the power of the bike as you twist it.
3.3 Brakes
Please note that, unlike regular petrol motorcycles, both the rear and the front
brake are located on the handlebar and there is no foot brake. The rear brake
lever is located on the left side of the handlebar and the front brake lever is
located on the right side of the handlebar.
Please be cautious when first riding, take your time to learn and get used to how
the bike and braking system behaves before you ride.
4. Operating the display
4.1 Display
The Display on the stem is the bikes control panel. Here, you will be able to see
the speedometer, odometer, trip meter, Ride mode, Brake mode, Service
notifications, Warning signals, Limiters, and Error codes.
4.2 Ride Mode
The ÖSA has three different ride modes made for different types of riding.
Never ride the bike above your comfort level and always ride according to your
riding skills. We always recommend a new CAKE-rider to start on the first ride
mode to get used to the bike and the differences between an electric motor and
an internal combustion engine.
The 3 different ride modes have different attributes in terms of top speed,
acceleration, and torque to suit riders of all riding levels, from beginners to
professionals.
As the ÖSA Lite and ÖSA+ are different vehicles, the power modes vary depending
on the model.

4.2A ÖSA Lite
Ride mode 1
This riding mode is perfect when navigating crowded roads and top speed is not
of importance. It offers you the best range and has a top speed of 30kmh/19mph.
Ride mode 2
This riding mode has a top speed of 45kmh/28mph and is perfect for casual riding
in the city. Best suited for when you don’t want to compromise on range or top
speed.
Ride mode 3
This riding mode also has a top speed of 45kmh/28mph but offers greater
acceleration to make sure that you are the fastest moped at any red light.
4.2B ÖSA+
Ride mode 1
This riding mode has the best range by far. It’s been optimized for city riding with
a limited top speed of 45kmh/28mph while still being quick and fun.
Ride mode 2
This riding mode has a top speed of 70kmh/44 mph. It has a slightly slower
acceleration to conserve more energy. This riding mode is recommended to use
for a better range while still being able to maintain a high top speed.
Ride mode 3
This is the most powerful ride mode and has a top speed of around
90kmh/56mph. While being the most fun, use with caution as this ride mode will
drain the battery more quickly.
4.3 Changing Ride mode
When the bike has been activated, press the middle button to cycle between the
different Ride Modes. To the left of the middle button, the current Ride Mode is
indicated by “RX”, with X being the ride mode 1, 2, or 3. The bike will make a
specific sound depending on the selected riding mode.

4.4 Brake mode
The ÖSA comes with two different brake modes that you can choose from to suit
your riding style.
Brake mode 1
This brake mode has the motor brake turned off. When you release the throttle,
the bike keeps freewheeling making for a pleasant experience for casual cruising.
Brake mode 2
This brake mode has the motor brake activated when you release the throttle. This
will slow you down gradually and can be used for greater control. All the braking
power is regenerated into the battery pack for an increased range.
WARNING: When riding in traffic and utilizing the brake mode, the braking light
will not be activated and notify other road users that you are slowing down. Use
with caution and always use the mechanical brakes as a means to stop your bike
when riding.
4.5 Changing Brake mode
When the bike has been activated, press the lower button to cycle between Brake
Mode 1 and 2. The current brake mode is indicated by “BX”, with the X being
either 1 or 2. The bike will make a specific sound depending on the selected riding
mode.
4.6 Change between Miles per hour and Kilometers per hour
When the bike has been activated, press and hold the lower button on the display
to change between Mph and Kmh.
4.7 Reset the trip meter
When the bike has been activated, press and hold the middle button on the
display, to start a new trip, or to cancel your current trip.
4.8 Change between odometer and trip meter
When the bike has been activated, press the top button on the display to switch
between displaying the odometer and trip meter

5. Charging and Battery
5.1 Battery
Be careful, the battery has a high voltage and a high current. Careless handling of
the battery pack can lead to serious injury or death.
• Always turn the battery off when the battery pack is not installed in the bike or
connected by the power connector.
• Never use running water to clean the battery pack.
• Never drop the battery pack.
• Never open the battery pack.
• Never use the battery pack in other applications than what is specified in this
manual.
• Never use an un-authorized DC/AC converter.
• Never short circuit any of the pins or sockets on the battery connectors.
• Always keep the connector connected to the battery pack when in use.
The ÖSA battery can also be used as a big power bank. You can find USB
connectors and an automotive 12V connector on the side of the battery pack. The
maximum discharge power on the USB connectors is 5V/2A (10W). The maximum
discharge power on the automotive connector is 12V/15A (180W).
If you want to use your battery pack to power appliances with a higher power
rating the separate power converter is required. The power converter is connected
to the battery main power port and allows you to connect regular 110V/230V
appliances to its standard sockets.
When disconnecting the battery pack, always turn the battery pack off with the
pushbutton to make sure there is no voltage on the power pins. A short circuit on
the power pins can damage the battery pack which will require a service repair. It
is therefore advised to always keep the battery pack in the bike with the power
connector attached.
When cleaning the battery pack, NEVER use running water on the battery pack.
Irresponsible use of the battery could potentially end in a fire which can lead to
serious damage or even death to people or property.

5.2 Removal of the battery and battery lock
Before removing the battery, turn the battery OFF. Then disconnect the big
connector by pushing and pressing the yellow latch, before pulling the whole
connector outwards.
The battery is secured by a lock located in the lower, front part of the battery. You
access the lock by looking at the skid plate, that the battery stands on from the
front. You unlock it by using the key that you received when you unpacked the
ÖSA.
When the lock is unlocked, removed the Velcro, and then carefully lift the battery
pack and angle it towards you. Be careful as you might create ugly marks on the
frame if you are not cautious.
Warning: Without the battery locked, anyone can steal the battery without effort.
Always use the lock.
5.3 Charging
When charging the bike, follow these steps.
ALWAYS read the charging manual before charging. Please check the charger
specific manual at www.ridecake.com/manuals to if you have any questions
regarding your charger.
1. Make sure that the battery is connected to the bike.
2. Disconnect the kill switch
3. Start by plugging the charger into the charging connector found on the battery.
Remove the protective plug on the charging connector by pressing the silver latch
on top of the connector while pulling on the plug.
4. Plug the charger into the outlet.
5. When you have charged the bike, first disconnect the charger from the outlet
and then disconnect the charger from the bike. Don’t forget to put in the
protective plug in the connector to avoid any dirt inside. If this step is not
followed, dirt can be accumulated in the connector causing the connector to
break.
• Never charge the bike without supervision.
• Never use the charger in any other application than with the CAKE ÖSA.
• Never use any other charger than the original CAKE ÖSA charger.
• Always follow the battery instructions giving above.

6. Ownership and maintenance
6.1 Cleaning
Always be cautious when cleaning the bike. The bike's electrical components can
be damaged if cleaned improperly which can in turn damage the bike, property,
or people.
• Never clean the bike with the battery connector disconnected. Without the
connector attached, the battery is sensitive to water.
• Always make sure that the bike is standing firmly before washing and don't
forget to turn the bike off.
• Never use a pressure washer or a water hose to clean the bike.
It's recommended to use pressurized air, a bucket of water together with a cloth
and brush.
When cleaning the chain, use a chain cleaner and scrub the chain with a brush.
6.2 Clamps and accessories
The main beam is your workbench, you can modify your accessories and riding
position by sliding seats, baskets and other accessories to suit your needs. There
are two levers on every clamp, one for mounting the clamp onto the beam, and
the other to hold your accessory.
• Always make sure that the clamp is properly tightened and that the lever is
pushed all the way to the bottom to ensure that the clamp works properly. If this
step is not followed properly, it could result in serious injury or even death. CAKE
takes no responsibility for damages or injuries that is a result of incorrectly
clamped items.
• Be careful when operating the clamps. A careless operation can result in
scratches and damages to the frame.
• Never use clamps or accessories in other ways than what has been approved by
CAKE.
• Always follow the instructions and limits of each accessory when using them.
• Make sure that the clamp has full contact with the beam and that there is
nothing in between the clamp and the beam. If this is not followed, this can result
in damages to the bike, injury, or incorrectly clamped accessories.

6.2 Storage
Follow these steps to ensure that your ÖSA is always in good condition and to
extend the life of the bike. We recommend you to ride the bike at least once every
month as some of the bike's components need to be used in order for them to
stay in good condition.
Store the bike indoors away from sunshine to avoid unnecessary aging or
discoloration.
• Make sure to turn the bike off with the battery button as it's otherwise in
standby and will drain the battery to an unhealthy level which will shorten the
lifespan of the battery.
• Never store a bike with an empty battery. The optimal SOC is 30% (1-2 bars on
the dashboard).
If the bike will be stored for a longer period of time, charge the bike to 30% SOC to
maximize the lifespan of the battery.
• Never store your bike in below 10° C, if you are unable to store the bike in
temperature above that, remove the battery and bring it inside.
• If the bike is unused for too long. The oil inside of the forks can start to leak.
6.3 Crash
In the case of a crash, please go through the bike for any visual or structural
damage. If you find any damage affecting the handling of the vehicle, stop riding
to prevent further damage to the vehicle, yourself, or the environment around
you. Get in contact with an authorized motorcycle dealer or our service team if you
have any questions.
6.4 Troubleshooting
If your bike isn't working properly, please read the following use cases to find the
solution.
If you can't find the problem you are experiencing or a solution that works for you,
contact CAKE directly.
I can find small “shavings” from the belt.
This is perfectly normal and happens in the beginning when you use a new belt. If
the belt looks damaged and you feel unsure. Get in contact with our service team
at CAKE.

My bike doesn’t start
Make sure to follow the start-up procedure found at the beginning of the manual.
If the bike still doesn’t start, send an email to our service team describing what
happened and what happened before this issue occurred.
I have forgotten my Pin code and can’t ride my bike.
Get in contact with our service team directly.
I can’t charge my bike.
Follow the charging steps described in the chapter “5.3 Charging”
Make sure that the outlet you are charging from works. After that, check that the
LEDs on the chargers turn on. Also, try to use the battery’s USB connector by
charging your phone to check if the battery works. Send this information to our
service team if nothing above works.
6.5 Tools
To properly maintain and keep your ÖSA in mint condition, we always recommend
you to use quality tools and to handle the bike with care. If you feel unable to do
necessary maintenance, please get in touch with someone who has the proper
experience.

7.0 Support and Contact
If you have problems or questions regarding the bike. Send an email to
[e-mail]
For general questions and information, get in contact with us at
[e-mail]
www.ridecake.com
Cake 0 Emission AB
Hammarby fabriksväg 43
12030 Stockholm
Sweden
This manual is constantly being updated.
Please make sure that you have the latest one on
www.ridecake.com/manuals
CAKE Ösa Manual rev.1
