CAME VER10 User manual

INSTALLATION MANUAL
VER10 - VER12
FA00045-EN
OPERATORS
FOR GARAGE DOORS
E
n
g
lish
E
N

p.
2
2- Manual
FA00045-EN
FA00045-EN v.
2
2- 09/2016 - © Came S.p.A. - The contents of this manual may be changed, at any time, and without notice.
PREMISE
• THIS PRODUCT SHOULD ONLY BE USED FOR THE
PURPOSE FOR WHICH IT WAS EXPLICITLY DESIGNED.
ANY OTHER USE IS DANGEROUS. CAME S.P.A.
IS NOT LIABLE FOR ANY DAMAGE CAUSED BY
IMPROPER, WRONGFUL AND UNREASONABLE USE
• KEEP THESE WARNINGS TOGETHER WITH THE
INSTALLATION AND OPERATION MANUALS THAT COME
WITH THE OPERATOR.
BEFORE INSTALLING
(CHECKING WHAT'STHERE: IF SOMETHING IS MISSING,
DO NOT CONTINUE UNTIL YOU HAVE COMPLIED WITH ALL
SAFETY PROVISIONS)
• CHECK THAT THE AUTOMATED PARTS ARE IN PROPER
MECHANICAL ORDER, THAT THE OPERATOR IS LEVEL AND
ALIGNED, AND THAT IT OPENS AND CLOSES PROPERLY.
MAKE SURE YOU HAVE SUITABLE MECHANICAL STOPS
• IFTHE OPERATOR IS TO BE INSTALLED AT AHEIGHT
OF LESS THAN 2.5 MFROM THE GROUND OR OTHER
ACCESS LEVEL, MAKE SURE YOU HAVE ANY NECESSARY
PROTECTIONS AND/OR WARNINGS IN PLACE • BEFORE
BEGINNING ANY OPERATION IT IS MANDATORY TO
CAREFULLY READ ALL INSTRUCTIONS; IMPROPER
INSTALLATION MAY RESULT IN SERIOUS HARM TO PEOPLE
AND THINGS. • IFANY PEDESTRIAN OPENINGS ARE FITTED
INTO THE OPERATOR, THERE MUST ALSO BE ASYSTEM
TO BLOCK THEIR OPENING WHILE THEY ARE MOVING •
MAKE SURE THAT THE OPENING AUTOMATED DOOR
OR GATE CANNOT ENTRAP PEOPLE AGAINST THE FIXED
PARTS OF THE OPERATOR • DONOT FIT UPSIDE DOWN
OR ONTO ELEMENTS THAT COULD BEND. IFNECESSARY,
ADD SUITABLE REINFORCEMENTS TO THE ANCHORING
POINTS • DONOT INSTALL DOOR OR GATE LEAVES
ON TILTED SURFACES • MAKE SURE ANY SPRINKLER
SYSTEMS CANNOT WET THE OPERATOR FROM THE
GROUND UP • MAKE SURE THE TEMPERATURE RANGE
SHOWN ON THE PRODUCT LITERATURE IS SUITABLE TO
THE CLIMATE WHERE IT WILL BE INSTALLED • FOLLOW
ALL INSTRUCTIONS AS IMPROPER INSTALLATION MAY
RESULT IN SERIOUS BODILY INJURY
INSTALLING
• SUITABLY SECTION OFF AND DEMARCATE THE
ENTIRE INSTALLATION SITE TO PREVENT UNAUTHORIZED
PERSONS FROM ENTERING THE AREA, ESPECIALLY
MINORS AND CHILDREN • BECAREFUL WHEN
HANDLING OPERATORS THAT WEIGH OVER 20 KG. IF
NEED BE, USE PROPER SAFETY HOISTING EQUIPMENT
• ALL OPENING COMMANDS (THAT IS, BUTTONS,
BUTTON SWITCHES, MAGNETIC READERS, AND SO ON)
MUST BE INSTALLED AT LEAST 1.85 MFROM THE
PERIMETER OF THE GATE'SWORKING AREA, OR WHERE
THEY CANNOT BE REACHED FROM OUTSIDE THE GATE.
ALSO, ANY DIRECT COMMANDS (WHETHER BUTTONS,
TOUCH PANELS, AND SO ON) MUST BE INSTALLED AT
LEAST 1.5 MFROM THE GROUND AND MUST NOT
BE REACHABLE BY UNAUTHORIZED PERSONS • ALL
MAINTAINED ACTION COMMANDS, MUST BE FITTED IN
PLACES FROM WHICH THE MOVING GATE LEAVES AND
TRANSIT AND DRIVING AREAS ARE VISIBLE • APPLY, IF
MISSING, APERMANENT SIGN SHOWING THE POSITION
OF THE RELEASE DEVICE • BEFORE DELIVERING TO
THE USERS, MAKE SURE THE SYSTEM IS EN 12453
STANDARD COMPLIANT (REGARDING IMPACT FORCES),
AND ALSO MAKE SURE THE SYSTEM HAS BEEN PROPERLY
ADJUSTED, AND, THAT ANY SAFETY, PROTECTION AND
MANUAL RELEASE DEVICES ARE WORKING PROPERLY
• APPLY WARNING SIGNS WHERE NECESSARY AND
IN AVISIBLE PLACE, (SUCH AS, THE GATE'SPLATE •
ONCE INSTALLED, MAKE SURE THAT THE MOTOR EITHER
PREVENTS OR BLOCKS THE OPENING MOVEMENT WHEN
THE DOOR IS LOADED WITH A20-KGMASS, FITTED
TO THE CENTER OF THE DOOR'SLOWER EDGE • ONCE
INSTALLED, MAKE SURE THAT PARTS OF THE DOOR DO
NOT JUT INTO PUBLIC STREETS OR SIDEWALKS.
SPECIAL USER-INSTRUCTIONS AND RECOMMENDATIONS
• KEEP GARAGE-DOOR OPERATION AREAS CLEAN
AND FREE OF ANY OBSTRUCTIONS. MAKE SURE THAT
THE PHOTOCELLS ARE FREE OF ANY OVERGROWN
VEGETATION AND THAT THE OPERATOR'SAREA OF
OPERATION IS FREE OF ANY OBSTRUCTIONS • DONOT
ALLOW CHILDREN TO PLAY WITH FIXED CONTROLS, OR
TO LOITER IN THE GATE'SMANEUVERING AREA. KEEP
ANY REMOTE CONTROL TRANSMITTERS OR ANY OTHER
WARNING!
Important safety instructions for people:
READ CAREFULLY!

p.
3
3- Manual
FA00045-EN
FA00045-EN v.
2
2- 09/2016- © Came S.p.A. - The contents of this manual may be changed, at any time, and without notice.
Danger of hand crushing
Danger! High
voltage.
No transiting while the
barrier is moving
Danger of foot crushing
COMMAND DEVICE AWAY FROM CHILDREN, TO PREVENT
THE OPERATOR FROM BEING ACCIDENTALLY ACTIVATED.
• THIS APPARATUS IS NOT FOR PEOPLE (INCLUDING
CHILDREN) WITH PHYSICAL, MENTAL AND SENSORY
ISSUES, OR EVEN ONES WITHOUT ANY EXPERIENCE,
UNLESS THEY ARE UNDER CLOSE SUPERVISION OR ONCE
THEY HAVE BEEN PROPERLY INSTRUCTED TO USE THE
APPARATUS SAFELY AND TO THE POTENTIAL HAZARDS
INVOLVED. • FREQUENTLY CHECK THE SYSTEM FOR
ANY MALFUNCTIONS OR SIGNS OF WEAR AND TEAR
OR DAMAGE TO THE MOVING STRUCTURES, TO THE
COMPONENT PARTS, ALL ANCHORING POINTS, INCLUDING
CABLES AND ANY ACCESSIBLE CONNECTIONS. KEEP ANY
HINGES, MOVING JOINTS AND SLIDE RAILS PROPERLY
LUBRICATED • PERFORM FUNCTIONAL CHECKS ON THE
PHOTOCELLS AND SENSITIVE SAFETY EDGES, EVERY
SIX MONTHS. TOCHECK WHETHER THE PHOTOCELLS
ARE WORKING, WAVE AN OBJECT IN FRONT OF THEM
WHILE THE GATE IS CLOSING; IF THE OPERATOR INVERTS
ITS DIRECTION OF TRAVEL OR SUDDENLY STOPS, THE
PHOTOCELLS ARE WORKING PROPERLY. THIS IS THE ONLY
MAINTENANCE OPERATION TO DO WITH THE POWER ON.
CONSTANTLY CLEAN THE PHOTOCELLS' GLASS COVERS
USING ASLIGHTLY WATER-MOISTENED CLOTH; DO NOT
USE SOLVENTS OR OTHER CHEMICAL PRODUCTS THAT
MAY RUIN THE DEVICES • IFREPAIRS OR MODIFICATIONS
ARE REQUIRED TO THE SYSTEM, RELEASE THE OPERATOR
AND DO NOT USE IT UNTIL SAFETY CONDITIONS HAVE
BEEN RESTORED • CUT OFF THE POWER-SUPPLY
BEFORE RELEASING THE OPERATOR FOR MANUAL
OPENINGS AND BEFORE ANY OTHER OPERATION, TO
PREVENT ANY RESULTING HAZARDS. SEE INSTRUCTIONS
• IFTHE POWER SUPPLY CABLE IS DAMAGED, IT MUST
BE REPLACED BY THE MANUFACTURER OR AUTHORIZED
TECHNICAL ASSISTANCE SERVICE, OR IN ANY CASE,
BY SIMILARLY QUALIFIED PERSONS, TO PREVENT ANY
RISK • IT IS FORBIDDEN FOR USERS TO PERFORM ANY
OPERATIONS THAT ARE NOT EXPRESSLY REQUIRED OF
THEM AND WHICH ARE NOT LISTED IN THE MANUALS.
FOR ANY REPAIRS, MODIFICATIONS / ADJUSTMENTS,
AND FOR EXTRA-ORDINARY MAINTENANCE, CALL
TECHNICAL ASSISTANCE • LOG THE JOB AND CHECKS
INTO THE PERIODIC MAINTENANCE LOG.
FURTHER RECOMMENDATIONS FOR ALL
• KEEP CLEAR OF HINGES AND MECHANICAL MOVING
PARTS • DONOT ENTER THE OPERATOR'SAREA OF
OPERATION WHEN IT IS MOVING • DONOT COUNTER
THE OPERATOR'SMOVEMENT AS THIS COULD RESULT
IN DANGEROUS SITUATIONS • ALWAYS PAY SPECIAL
ATTENTION TO ANY DANGEROUS POINTS, WHICH HAVE
TO BE LABELED WITH SPECIFIC PICTOGRAMS AND/
OR BLACK AND YELLOW STRIPES • WHILE USING A
SELECTOR SWITCH OR ACOMMAND IN MAINTAINED
ACTIONS, KEEP CHECKING THAT THERE ARE NO PERSONS
WITHIN THE OPERATING RANGE OF ANY MOVING PARTS,
UNTIL THE COMMAND IS RELEASED • THE OPERATOR
MAY MOVE THE DOOR AT ANY TIME AND WITHOUT
WARNING • ALWAYS CUT OFF THE MAINS POWER
SUPPLY BEFORE PERFORMING ANY MAINTENANCE OR
CLEANING. • OBSERVE THE MOVING DOORS AND KEEP
PEOPLE AWAY UNTIL THE DOOR IS FULLY OPENED OR
CLOSED.

p.
4
4- Manual
FA00045-EN
FA00045-EN v.
2
2- 09/2016 - © Came S.p.A. - The contents of this manual may be changed, at any time, and without notice.
LEGEND
This symbol shows which parts to read carefully.
⚠This symbol shows which parts describe safety issues
☞This symbol shows which parts to tell users about.
UNLESS OTHERWISE STATED, THESE OPERATIONS APPLY TO ALL MODELS.
THE MEASUREMENTS, UNLESS OTHERWISE STATED, ARE IN MILLIMETERS.
DESCRIPTION
Operator, complete with control board with encoder, for sectional and overhead garage-doors.
Intended use
The VER10 - VER12 are designed to power overhead garage doors in residential and apartment block
settings.
Any installation and/or use other than that specified in this manual is forbidden.
Limits to use
Type VER10 VER12
Door's max. surface area (m2)1821
Counter-weighted overhead door's max. weight (m) 2.40 2.40
Maximum height of spring-balanced overhead doors (m) 3.25 3.25
Maximum height of door (m) 3.20 3.20
Technical data
Type VER10 VER12
Protection rating (IP) 30 30
Power supply (V - 50/60 Hz) 230 AC 230 AC
Power supply motor (V) 24 DC 24 DC
Stand-by consumption (W) 5 7.5
Maximum power of the accessories (W) 40 40
Nominal power (W) 130 260
Maneuvering speed (m/min) 6 6
Duty cycle (%) 50 50
Traction force (N) 1,000 1,200
Operating temperature (°C) -20 ÷ +55 -20 ÷ +55
Apparatus class I I
Weight (Kg) 5.7 5.8

212140
400
3020 ÷ 4020
38
①
②
③
④
⑥
⑤
⑦
⑧
⑨
⑪
⑩
⑦
①
②
③
④
⑤
p.
5
5- Manual
FA00045-EN
FA00045-EN v.
2
2- 09/2016- © Came S.p.A. - The contents of this manual may be changed, at any time, and without notice.
Description of parts
1. Cover
2. Gearmotor
3. Transformer
4. Control board
5. Transmission arm for the VER10*
6. Transmission arm for the VER12*
7. Door fastening brace
8. Guide fastening brace
9. Ceiling fastening brace
10. Cable gland
11. Fastening screws
☞(*) Only for sectional doors.
Dimensions
Description of the traction guide
1. Guide
2. Chain or belt
3. Traction assembly with release lever
4. Mechanical stop
5. Support rods

p.
6
6- Manual
FA00045-EN
FA00045-EN v.
2
2- 09/2016 - © Came S.p.A. - The contents of this manual may be changed, at any time, and without notice.
Traction guides
001V0679 Chain guide L = 3.02 m.
Counter-balanced overhead doors up to 2.4 m in height
- Counter-balanced overhead doors up to 2.25 m in height
- Sectional doors* up to 2.20 m in height.
001V0682 Chain guide T = 3.52 m.
- Counter-balanced overhead doors up to 2.75 m in height.
- Sectional* doors up to 2.70 m in height.
001V0683 Chain guide L = 4.02 M OF ONE PIECE.
- Spring-balanced overhead doors up to 3.25 m in height.
- Sectional* doors up to 3.20 m in height.
001V0684 Chain guide L = 3.02 M IN TWO PIECES.
Counter-balanced overhead doors up to 2.4 m in height
- Counter-balanced overhead doors up to 2.25 m in height
- Sectional doors* up to 2.20 m in height.
001V0685 Belt guide T = 3.02 m.
Counter-balanced overhead doors up to 2.4 m in height
- Counter-balanced overhead doors up to 2.25 m in height
- Sectional* doors up to 2.20 m in height.
001
001V0686 Belt guide T = 3.52 m.
- Counter-balanced overhead doors up to 2.75 m in height.
- Sectional* doors up to 2.70 m in height.
001
001V0687 Chain guide L = 3.02 in two pieces.
Counter-balanced overhead doors up to 2.4 m in height
- Counter-balanced overhead doors up to 2.25 m in height
- Sectional doors* up to 2.20 m in height.
001V0688 Belt guide T = 4.02 m.
- Spring-balanced overhead doors up to 3.25 m in height
- Sectional* doors up to 3.20 m in height.
☞(*) For sectional doors, see the paragraph on APPLICATION EXAMPLES
Accessories
001
001V005 Extension for the following types of chain guides: V0679, V0682, V0683, V0684.
001
001V201 Transmission arm for partially retracting overhead garage-doors.
001
001V122 Transmission arm for sectional doors having a top-rail to spring-pole assembly distance compri-
sed between 300 and 600 mm.
001V121 Pull-cord auto-resetting release device to fit onto the door handle.
001V670 Card for operation during power outages and for recharging the batteries.
To 12 V - 1.2 Ah batteries (not supplied).
GENERAL INSTRUCTIONS FOR INSTALLING
⚠Only skilled, qualified staff must install this product.
⚠If the door is fitted with a pedestrian door, you must also fit a safety switch at the entrance, to stop the
operator from working when the pedestrian door is open.

28
48
①
②
③
④
⑨
⑦
⑤
⑥
⑧
⑥
p.
7
7- Manual
FA00045-EN
FA00045-EN v.
2
2- 09/2016- © Came S.p.A. - The contents of this manual may be changed, at any time, and without notice.
Preliminary checks
⚠Before beginning, do the following:
• make sure you have set up a suitable dual pole cut off device along the power supply that is compliant
with the installation rules. It should completely cut off the power supply according to category III surcharge
conditions (that is, with minimum contact openings of 3 mm);
• setup suitable tubes and conduits for the electric cables to pass through, making sure they are protected
from any mechanical damage;
• make sure that any connections inside the container (ones that ensure continuity to the protection
circuit) are fitted with additional insulation with respect to those of other electrical parts inside:
• make sure that the door is properly balanced; when stopped at any in-between point, it should hold its
position.
Cable types and minimum thicknesses
Connection Cable type Cable length
1 < 15 m
Cable length
15 < 30 m
Control panel power supply 230 V AC H05VV-F 3G x 1.5 mm23G x 2.5 mm2
Flashing light FROR CEI
20-22
CEI EN
50267-2-1
2 x 0.5 mm2
Photocell transmitters 2 x 0.5 mm2
Photocell receivers 4 x 0.5 mm2
Command and safety device 2 x 0.5 mm2
Antenna RG58 max 10 m
If cable lengths differ from those specified in the table, establish the cable sections depending on the actual
power draw of the connected devices and according to the provisions of regulation CEI EN 60204-1.
For multiple, sequential loads along the same line, the dimensions on the table need to be recalculated according
to the actual power draw and distances. For connecting products that are not contemplated in this manual, see
the literature accompanying said products.
Standard installation
1. Operator
2. Traction guide
3. Release device
4. Transmission arm
5. Key-switch selector
6. Photocells
7. Control device
8. Sensitive safety-edge
9. Flashing light

M6 x 20
M6
H
H
p.
8
8- Manual
FA00045-EN
FA00045-EN v.
2
2- 09/2016 - © Came S.p.A. - The contents of this manual may be changed, at any time, and without notice.
Applicative examples
Sectional door with single
slide-guide
Sectional door with double
slide-guides
SECTIONAL DOOR
COUNTERBALANCED OVERHEAD DOOR,
PARTIALLY RETRACTING AND PROTRUDING
SPRING-BALANCED OVERHEAD DOOR,
FULLY RETRACTING AND PROTRUDING
INSTALLATION
⚠The following illustrations are just examples, in that the space available for fitting the operator and
accessories varies depending on the overall dimensions. It is up to the installer to find the most suitable
solution.
Assembling the traction guide

==
xx
20÷30
V122
300÷600
20
p.
9
9- Manual
FA00045-EN
FA00045-EN v.
2
2- 09/2016- © Came S.p.A. - The contents of this manual may be changed, at any time, and without notice.
Positioning the traction guide
Sectional doors: above the spring-pole brace assembly. If the distance between the spring-pole and the upper
part of the door is between 300 and 600 mm, use the V122 transmission arm.
For protruding overhead garage-doors, kepp the guide at 20 from the highest opening point.
Fastening the traction guide
The traction guide should be fastened at the center of the door opening, using suitable screws. .
Raise the guide and position it horizontally to measure the distance from the ceiling, and then fasten it. .
☞For partially-retracting protruding overhead garage doors, use the V201 transmission arms.

M6 x 14
M6
p.
10
10 - Manual
FA00045-EN
FA00045-EN v.
2
2- 09/2016 - © Came S.p.A. - The contents of this manual may be changed, at any time, and without notice.
Fit the braces to the guide and to the ceiling ❸.
⚠If necessary, fit additional support rods ❹.
Drill the ceiling where the braces will god and fit them to the ceiling using suitable dowels and screws.
Fitting the transmission arm to the door
Position the transmission arm braceto the door's top rail, perpendicularly to the traction guide and fasten it
using the supplied screws or other suitable screws .

UNI 5739
M6 x 20
UNI 6955 Ø 6.3 x 45
p.
11
11 - Manual
FA00045-EN
FA00045-EN v.
2
2- 09/2016- © Came S.p.A. - The contents of this manual may be changed, at any time, and without notice.
Turn the release lever clock-wise .
Move the traction assembly towards the door and fasten the transmission arm using the supplied bolt
.
Fitting the operator to the guide
Fasten the operator to the traction guide using the supplied screws .
The operator can also be fitted laterally .

CL.SENS.
ZL56
OP.SENS.
MOTOR FUSE
8A-F
2
1
ON
ACC. FUSE 3,15A-F
LINE FUSE
1,6A-F
OPEN
OP / CL
AF
26V 17V 0V MN +E-
ENC/RADIO
0V
230V
0
17
26
A.C.T.
SLOW.SENS
C.BOARD FUSE 315mA-F
L1T
L
L2T
N
p.
12
12 - Manual
FA00045-EN
FA00045-EN v.
2
2- 09/2016 - © Came S.p.A. - The contents of this manual may be changed, at any time, and without notice.
Fit the cable gland into the corresponding hole and fit the electrical cables .
The number of cables depends on the type of system and accessories fitted.
ELECTRICAL CONNECTIONS
FUSE TABLE
Motor (A) 8
Accessories (A) 3.15
Control device (mA) 315
Line fuses (A) 1.6
LIGHTS
LED courtesy lights 24 V E14S (W) 1
Components
1. Line fuse
2. Motor fuse
3. Accessories fuse
4. Control
5. panel/ Gearmotor board fuse
6. Transformer
7. Battery housing
8. Transformer connection terminals
9. Gearmotor connection terminals
10. Encoder connection terminals
11. Accessories connection terminals and
control devices
12. Power supply terminal board
13. Antenna connection terminals
14. Memorization button
15. Limit-switch adjustment buttons
16. Programming LED
17. POWER-ON alerting LED
18. DIP-switch
19. Trimmer
20. Courtesy light
21. AF card connector
22. Hole for cables






-
+
,.
CL.SENS.
ZL56
OP.SENS.
MOTORFUSE 8A-F
2
1
ON
ACC.FUSE 3,15A-F
LINEFUSE 1,6A-F
OPEN
OP/ CL
AF
26V17V 0V MN +E-
ENC/RADIO
0V
230V
0
17
26
A.C.T.
SLOW.SENS
C.BOARDFUSE 315mA-F
L1T
L
L2T
N
10 11



 %   
#
#
0
0
p.
13
13 - Manual
FA00045-EN
FA00045-EN v.
2
2- 09/2016- © Came S.p.A. - The contents of this manual may be changed, at any time, and without notice.
Power supply
230 V AC
50/60 Hz
Terminals for powering up accessories:
- 24 V AC - grid powered (230 V);
- 24 V DC when the emergency batteries are operating;
Overall allowed power: 40 W
Eyelet end-piece for grounding connection.
Command and control devices
Stop button (NC contact). Enables the door to stop and excludes the
automatic closing. To resume movement, use the control device.
OPEN-STOP-CLOSE-STOP sequential function from control
device (NO contact).
PARTIAL OPENING feature from command device (NO contact).
If a device is connected, remove the bridge.

10 11 E 1 2 7 C13P



 % #0
#,3%.3
:,
/03%.3
-/4/2&53%
!&


/.
!##&53%!&
,).%&53%
!&
/0%.
/0#,
!&
6 6 6 -. %
%.#2!$)/
!#4
3,/73%.3
#"/!2$&53%M!&
,4
,
,4
.


/.
ON
OFF
p.
14
14 - Manual
FA00045-EN
FA00045-EN v.
2
2- 09/2016 - © Came S.p.A. - The contents of this manual may be changed, at any time, and without notice.
Safety devices
Reopening while closing function (NC contact). When the door is opening, opening the contact causes the
door to invert its movement until it is completely open.
If a device is connected, remove the bridge
Signaling devices
Flashing light connecting (contact rated for: 24 V AC - 25 W max).
It flashes during the door's opening and closing phases.
Selecting DIP switches
DIP-SWITCH Description of functions
1 ON
It activates the opening and closing limit-switch setting procedure and the delayed-opening
setting procedure.
(1 OFF - deactivated)
2 ON Activate the procedure for partial opening and closing slow-down programming.
(2 OFF - deactivated)
PROGRAMMING

#,3%.3
:,
/03%.3
-/4/2&53%
!&


/.
!##&53%!&
,).%&53%
!&
/0%.
/0#,
!&
66 6 -. %
%.#2!$)/
!#4
3,/73%.3
#"/!2$&53%M!&
,4
,
,4
.


#,3%.3 /03%.3
!#4
3,/73%.3
p.
15
15 - Manual
FA00045-EN
FA00045-EN v.
2
2- 09/2016- © Came S.p.A. - The contents of this manual may be changed, at any time, and without notice.
Adjusting the trimmers
Trimmer Description of functions
Sensitivity during slow-downs
Adjusts the amperometric sensitivity that controls the force exerted by the motor during slow-
downs; if the exerted force is greater than the setting, the system inverts the direction of travel.
Automatic Closing Time
Sets the open door's waiting time. Once this time elapses, a closing maneuver is automatically
performed.
The time can be set between 0 and 120 seconds.
Sets the time to a minimum, and excludes AUTOMATIC CLOSING.
Sensitivity during closing
Adjusts the amperometric sensitivity that controls the force exerted by the motor during closing;
if the exerted force is greater than the setting, the system inverts the direction of travel.
Sensitivity during opening
Adjusts the amperometric sensitivity that controls the force exerted by the motor during opening;
if the exerted force is greater than the setting, the system inverts the direction of travel.

p.
16
16 - Manual
FA00045-EN
FA00045-EN v.
2
2- 09/2016 - © Came S.p.A. - The contents of this manual may be changed, at any time, and without notice.
Fastening the opening mechanical stop
Release the operator and completely open the door.
Encoder operation
Obstruction detection when CLOSING
The door inverts its travel direction and reopens.
After three consecutive inversions, the door stays open and excludes the automatic opening.
To reclose the door, press a control button or use the transmitter.
Obstruction detection when OPENING
The door recloses.

#,3%.3 /03%.3


/.
/0%.
/0#,
!&
.
%
%.#2!$)/
!#4
3,/73%.3
#,3%.3 /03%.3


/.
/0%.
/0#,
!&
%
%.#2!$)/
!#4
3,/73%.3
p.
17
17 - Manual
FA00045-EN
FA00045-EN v.
2
2- 09/2016- © Came S.p.A. - The contents of this manual may be changed, at any time, and without notice.
Position the mechanical stop against the traction assembly and fasten it.
Mechanical stop
Traction assembly
Manually close the door until it latches shut.
Establishing the closing and opening limit switch points
Set DIP-switch 1 to ON, the programming LED will flash .
Press the OP/CL button until the door reaches the closing strike plate .

CL.SENS.
Z
L56A
OP.SENS.
MOTOR FUSE
8A-F
2
1
ON
C
. FUSE 3,15A-F
OPEN
OP / CL
AF
26V 17V 0V MN +E-
ENC/RADIO
A.C.T.
SLOW.SENS
CL.SENS. OP.SENS.
O
R FUSE
F
2
1
ON
A
-F
OPEN
OP / CL
AF
26V 17V 0V MN +E-
ENC/RADIO
A.C.T.
SLOW.SENS
CL.SENS. OP.SENS.
O
R FUSE
F
2
1
ON
A
-F
OPEN
OP / CL
AF
26V 17V 0V MN +E-
ENC/RADIO
A.C.T.
SLOW.SENS
 
CL.SENS. OP.SENS.
E
2
1
ON
OPEN
OP / CL
AF
6
V 17V 0V MN +E-
ENC/RADIO
A.C.T.
SLOW.SENS

CL.SENS. OP.SENS.
R FUSE
2
1
ON
-
F
OPEN
OP / CL
AF
26V 17V 0V MN +E-
ENC/RADIO
A.C.T.
SLOW.SENS

p.
18
18 - Manual
FA00045-EN
FA00045-EN v.
2
2- 09/2016 - © Came S.p.A. - The contents of this manual may be changed, at any time, and without notice.
Press the ENC/RADIO button ❹to memorize the closing point.
Press the OPEN button until the door reaches its completely-open point .
Press the ENC/RADIO button to memorize the opening point .
Reset DIP-switch 1 to OFF .
Use the OP/CL button to command an opening and a closing to check that the programming was properly done.

#,3%.3 /03%.3


/.
/0%.
/0#,
!&
-. %
%.#2!$)/
!#4
3,/73%.3
#,3%.3 /03%.3


/.
/0%.
/0#,
!&
%
%.#2!$)/
!#4
3,/73%.3
CL.SENS.
ZL56A
OP.SENS.
MOTOR FUSE
8A-F
2
1
ON
ACC. FUSE 3,15A-F
N
E FUSE
1
,6A-F
OPEN
OP / CL
AF
26V 17V 0V MN +E-
ENC/RADIO
A.C.T.
SLOW.SENS
#,3%.3 /03%.3 /0%.
/0#,
!&
%.#2!$)/
!#4
/03%.3 /0%.
/0#,
!&
%.#2!$)/
#,3%.3 /03%.3 /0%.
/0#,
!&
%.#2!$)/
!#4
#,3%.3 /03%.3


/.
/0%.
/0#,
!&
-
.%
%.#2!$)/
!#4
3,/73%.3


p.
19
19 - Manual
FA00045-EN
FA00045-EN v.
2
2- 09/2016- © Came S.p.A. - The contents of this manual may be changed, at any time, and without notice.
Programming the partial opening
When the door is fully closed, set DIP-switch 2 to ON, the LED will flash .
Press the OPEN button until the door reaches the wanted opening position .
Press ENC/RADIO to memorize the partial opening .
Reset DIP-switch 2 to OFF .
Programming the slow start with door open (max. 50% of the door travel)
Before programming, deactivate the automatic closing by setting the trimmer to a minimum.
When the door is fully open, press the ENC/RADIO button, the LED will flash rapidly .
Set DIP-switch 1 to ON, the LED turns o .
Release the ENC/RADIO button, the LED flashes slowly .

#,3%.3 /03%.3 /0%.
/0#,
!&
%.#2!$)/
#,3%.3 /03%.3 /0%.
/0#,
!&
%.#2!$)/ #,3%.3 /03%.3


/.
!#4
3,/73%.3
/03%.3 /0%.
/0#,
!&
%.#2!$)/ #,3%.3 /03%.3


/.
/0%.
/0#,
!&
.
%
%.#2!$)/
!#4
3,/73%.3
/03%.3 /0%.
/0#,
!&
%.#2!$)/
p.
20
20 - Manual
FA00045-EN
FA00045-EN v.
2
2- 09/2016 - © Came S.p.A. - The contents of this manual may be changed, at any time, and without notice.
Press the OP/CL button until the door reaches the desired end slow-down point  - Press the ENC/RADIO
button until the LED stays on to signal that memorization is now complete .
Reset DIP-switch 1 to OFF .
Programming the closing slow-down (min. 600 mm from the final closing strike or max. 50% of the door travel)
When the door is fully closed, press the ENC/RADIO button, the LED will flash rapidly .
Set DIP-switch 2 to ON, the LED turns o .
Release the ENC/RADIO button, the LED flashes slowly .
