CAME Entrotec Entroview User manual

came.com/entrotec
entroview
user guide
user guide

entroview user guide
To let the caller gain access, press Unlock.
Replace the handset to complete the call.
Press the Privacy button or Adjust the ringer volume with the slider.
If you do not wish to be disturbed, press Privacy. The button will illuminate and the ringer is silenced. Press the
button again to turn the ringer back on.
Lift the handset to answer an incoming call. The video monitor will display for the length of the call.
When someone calls
While on a call
Silence a call
keep it quiet
Privacy
Unlock
Adjust
Low Med Hi

installation guide
Cat 5e / Cat 6 / CW1308 6 Pair Minimum.
This does not allow for redundant cables. If this is a requirement then the installer must allow for this during
installation.
10 Pair CW1308 recommended for cable runs exceeding 70 metres.
Any unused cores to be tied to system 0v.
* NOTE: If DS is required the internal ringer can be enabled and the BZ connection is not required, freeing up the Orange wire.
cable specification
wiring diagram
Privacy
Unlock
Adjust
ENTROVIEW
PLUS
PRIVAC YDOOR OPEN
DR V T 0V
BZ S2 S1 DS V- V+ CB X EX To Sou nders or Beacons Only
DR
VT
0V
BZ*
S2
S1
DS
V-
V+
Suggested Colour Code
Cat 5 / Cat 6
DR - White/Blue+Blue/White
VT - White/Orange+Orange/Whit
e
0V - White/Green+White/Brown
BZ - White/Grey
S2 - Green/White
S1 - Brown/White
DS - Grey/White
V- - Red/Blue
V+ - Blue/Red
Suggested Colour Code
6 Pair CW1308
White/Blue
Blue
White/Orange
*Orange
White/Green
Green
White/Brown
Brown
CB*
X*
CB
Optional
Door Bell

entroview user guide
Press the Menu button to turn the screen on.
Press Menu to cycle through the on screen display options.
Press + or – to adjust the selected parameter. Once adjusted
the settings will store and the screen will turn off.
Switches 1, 2 & 3 select the privacy function options. Privacy
can be: disabled completely, set to latch on/off or set to time
out after a preset time (see table: 0 = OFF 1 = ON).
Switch 4is for 1 way systems and should be ON for normal
use.
Switch 5is not used.
Switch 6selects video termination and should be ON for
normal use.
video setup
option switches
Menu
+
ENTROVIEW
PRIVACY DOOROPEN
3 Position Call
Tone Volume
Low Med Hi
_
DR VT
0V BZ S2 S1 DS
V- V+ CB X EX
PL12
Option Switches
ON
12 34 56
1 2 3 Time
0 0 0
0 0 1 Disabled
0 1 0 5 mins
0 1 1 30 mins
1 0 0 1 hr
1 0 1 4 hrs
1 1 0 8 hrs
1 1 1 12 hrs

entroview user guide
To adjust the ringtone press and hold Privacy to start the ringer. Press Privacy to select the ringtone options and
press Door Open to store.
ringtones

CAME S.p.A.
Came cancelli automatici S.p.A.
is certied for Quality and Environment
UNI EN ISO 9001
UNI EN ISO 14001
BS OHSAS 18001
© 2022 - EN - EVGUIDE0322
YOU MAY NOT EVEN PARTIALLY REPRODUCE THIS DOCUMENT
CAME RESERVES THE RIGHT TO MAKE ANY CHANGES TO THIS DOCUMENT AT ANY TIME
THE DATA AND INFORMATION SHOWN IN THIS CATALOGUE ARE SUBJECT TO CHANGE WITHOUT OBLIGATION TO GIVE PRIOR NOTICE BY CAME S.P.A, E&OE
CAME ENTROTEC
5 Ashwood Court
Oakbank
Livingston
EH53 0TL
Tel: [phone]
Support: 01506 886235
came.com/kms
