imageRUNNER ADVANCEC5051/C5045/C5035/C5030 Series
Service Manual
September 24, 2009
Revision 0
Product Outline
Function
Periodic Servicing
Parts Replacing and Cleaning
Adjustments
Troubleshooting
Error Code
Service Mode
Installation
Appendix

0-2
0-2
Application
This manual has been issued by Canon Inc. for qualied persons to learn technical theory,
installation, maintenance, and repair of products. This manual covers all localities where the
products are sold. For this reason, there may be information in this manual that does not
apply to your locality.
Corrections
This manual may contain technical inaccuracies or typographical errors due to improvements
or changes in products. When changes occur in applicable products or in the contents of this
manual, Canon will release technical information as the need arises. In the event of major
changes in the contents of this manual over a long or short period, Canon will issue a new
edition of this manual.
The following paragraph does not apply to any countries where such provisions are
inconsistent with local law.
Trademarks
The product names and company names used in this manual are the registered trademarks
of the individual companies.
Copyright
This manual is copyrighted with all rights reserved. Under the copyright laws, this manual may
not be copied, reproduced or translated into another language, in whole or in part, without the
written consent of Canon Inc.
(C) CANON INC. 2009
Caution
Use of this manual should be strictly supervised to avoid disclosure of condential
information.

0-3
0-3
Explanation of Symbols
The following symbols are used throughout this Service Manual.
Symbols Explanation Symbols Explanation
Check. Remove the claw.
Check visually. Insert the claw.
Check the noise. Use the bundled part.
Disconnect the connector. Push the part.
Connect the connector. Plug the power cable.
Remove the cable/wire
from the cable guide or wire
saddle. Turn on the power.
Set the cable/wire to the
cable guide or wire saddle.
Remove the screw.
Tighten the screw.
F-0-1F-0-1 F-0-2F-0-2
F-0-3F-0-3 F-0-4F-0-4
F-0-5F-0-5 F-0-6F-0-6
F-0-7F-0-7 F-0-8F-0-8
F-0-9F-0-9 F-0-10F-0-10
F-0-11F-0-11 F-0-12F-0-12
F-0-13F-0-13
F-0-14F-0-14
F-0-15F-0-15
The following rules apply throughout this Service Manual:
1. Each chapter contains sections explaining the purpose of specic functions and the
relationship between electrical and mechanical systems with reference to the timing of
operation.
In the diagrams, represents the path of mechanical drive; where a signal name
accompanies the symbol, the arrow indicates the direction of the electric
signal.
The expression "turn on the power" means ipping on the power switch, closing the
front door, and closing the delivery unit door, which results in supplying the machine with
power.
2. In the digital circuits, '1' is used to indicate that the voltage level of a given signal is
"High", while '0' is used to indicate "Low". (The voltage value, however, differs from
circuit to circuit.) In addition, the asterisk (*) as in "DRMD*" indicates that the DRMD
signal goes on when '0'.
In practically all cases, the internal mechanisms of a microprocessor cannot be checked
in the eld. Therefore, the operations of the microprocessors used in the machines
are not discussed: they are explained in terms of from sensors to the input of the DC
controller PCB and from the output of the DC controller PCB to the loads.
The descriptions in this Service Manual are subject to change without notice for product
improvement or other purposes, and major changes will be communicated in the form of
Service Information bulletins.
All service persons are expected to have a good understanding of the contents of this Service
Manual and all relevant Service Information bulletins and be able to identify and isolate faults
in the machine.

CDRH Act
Laser Safety
Handling of Laser System
Turn power switch ON
Safety of Toner
Notes When Handling a
Lithium Battery
Notes Before Servicing
■
■
■
■
■
■
■
imageRUNNER ADVANCE
C5051/5045/5035/5030
Series
Safety Precautions

0
00-2
0-2
CDRH Act
The Center for Devices and Radiological Health of the US Food and Drum Administration put
into force regulations concerning laser products on August 2, 1976. These regulations apply
to laser products manufactured on and after August 1, 1976, and the sale of laser products
not certied under the regulations is banned within the Untied States. The label shown here
indicates compliance with the CDRH regulations, and its attachment is required on all laser
products that are soled in the United States.
CANON INC.
MANUFACTURED:
30-2,SHIMOMARUKO,3-CHOME,OHTA-KU,TOKYO,JAPAN
THIS PRODUCT CONHORMS WITH DHHS RADIATION
PERFORMANCE STANDARD 21CFR CHAPTER 1
SUBCHAPTER J.
A different description may be used for a different product.
Laser Safety
Laser beam radiation may pose a danger to the human body. A laser scanner mounted on the
machine is sealed with the protection housing and external cover to prevent the laser beam
from leaking to the outside. The laser beam never leaks out of the scanner as far as users
operate the machine normally.
F-0-16F-0-16
Handling of Laser System
When servicing the area around the laser assembly, be sure to turn off the main power.
The machine's covers that can reect laser light are identied by means of a warning label
(Figure). If you must detach a cover showing the label, be sure to take extra caution during
the work.
F-0-17F-0-17

0
00-3
0-3
Turn power switch ON
The machine is equipped with 2 power switches: main power switch and control panel power
switch.
The machine goes on when the main power switch is turned on (i.e., other than in low power
mode, sleep mode).
Safety of Toner
About Toner
The machine's toner is a non-toxic material made of plastic, iron, and small amounts of dye.
Do not throw toner into re. It may cause explosion.
Toner on Clothing or Skin
If your clothing or skin has come into contact with toner, wipe it off with tissue; then, wash it
off with water.
Do not use warm water, which will cause the toner to jell and fuse permanently with the
bers of the cloth.
Tonner is easy to react with plastic material, avoid contact with plastic.
•
•
•

0
00-4
0-4
Notes When Handling a Lithium Battery
RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN INCORRECT TYPE.
DISPOSE OF USED BATTERIES ACCORDING TO THE INSTRUCTIONS.
The following warnings are given to comply with Safety Principles (EN60950).
Wenn mit dem falschen Typ ausgewechselt, besteht Explosionsgefahr.
Gebrauchte Batterien gemäß der Anleitung beseitigen.
Notes Before Servicing
At servicing, be sure to turn OFF the power source according to the specied steps and
disconnect the power plug.

1
1
Product Overview
Product Lineup
Feature
Specications
Name of Parts
■
■
■
■

1
11-2
1-2
Product Lineup
Host machine
Host machine conguration
Host machine conguration
Printer only
Model type
C5051 C5045 C5035 C5030
Print Speed (BW /
Color) 51 / 51ppm 45 / 45ppm 35 / 35ppm 30 / 30ppm
Positioning High-speed / high-quality Middle-Ofce
model
Target machine :
iRC5180 / 4580 / 3880Series
Cost-prioritized Standard-Ofce model
Target machine :
iRC3380 / 2880Series,
iRC6800Series, iRC3100Series
■
■
F-1-1F-1-1
T-1-1T-1-1
T-1-2T-1-2
imageRUNNER ADVANCE C50 51
A: Product category (90: Production model, 50 : Office model)
B: Print speed (unit is ppm : print per minutes)
A B
F-1-2F-1-2

1
11-3
1-3
Option
Pickup delivery / image reading options
【1】
【2】
【3】
【4】【5】
【6】
【7】
【8】
【9】
【10】
【11】
【12】
【13】
【14】
【15】
【16】
【17】
【18】
【19】
【20】
■
F-1-3F-1-3
No. Brand name Remarks and condition
1 Inner Finisher Additional Tray-A1 -
2 Inner Finisher-A1 Built-in nisher
3 Duplex Color Image Reader Unit-B1 ADF-XD (1 Path Duplex Type DADF) + Reader
4 Reader Heater Kit-G1 For USA,CCI,CLA, this is provided as a service
part.
5 Color Image Reader Unit-B1 ADF-SU (Reverse Duplex Type DADF) + Reader
6 Color Image Reader Unit-B2 Copyboard + Reader
7 Printer Cover-C1 -
8 Copy Tray-J1 -
9 Cassette Heater Unit-32 Deck Heater for Paper Deck Unit-B1.
10 Paper Deck Unit-B1 -
11 Envelope Feeder Attachment-D1 Cassette Attachment for envelope
12 FL Cassette-AG1 -
13 FL Cassette-AH1 -
14 Cassette Heater Unit-37 Cassette Heater for host machine, 2-Cassette
Pedestal-AD1
15 Cassette Feeding Unit-AD1 -
16 Buffer Pass Unit-G1 -
17 Inner 2Way Tray-F1 For host machine delivery additional tray
18 External 2 Hole Puncher-B1 External 2/3 Hole Puncher-B1(USA,CAN,CLA),
External 2/4 Hole Puncher-B1(EUR,FRA,CA),
External 4 Hole Puncher-B1(EUR)
19 Booklet Finisher-C1 Buffer Path Unit G1 is required
20 Staple Finisher-C1 Buffer Path Unit G1 is required
T-1-3T-1-3

1
11-4
1-4
Function expanding option
Voice
Guidance
Unit
Voice
Guidance
PCB
Voice
Operation
Unit
Voice
Operation
PCB
【1】
【2】
【3】
【4】
【5】
【6】
【7】
【8】
【9】
【10】
【11】
【12】
【13】
【14】
【15】
【16】
【17】
【18】
【19】
【20】
【21】
【22】
【23】
【24】
No. Brand name Remarks and condition
1 Voice Operation Kit-C1 Note
2 Voice Guidance Kit-F1 Note
3 Removable HDD Kit-AC1 -
4 2.5inch/80GB HDD-C1 -
2.5inch/250GB HDD-D1 Only when Mirroring Kit is extended
5 Copy Card Reader-C1 Note
Copy Card Reader Attachment-B1 Note
6 Utility Tray-A1 Note
7 Multimedia Reader/Writer-A1 USB device port-B1 is required
8 USB Device Port-B1 -
9 ColorPASS-GX300/PS-GX300 -
10 Key Switch Unit-A2 -
11 HDD Mirroring Kit-D1 -
12 HDD Data Encryption & Mirroring Kit-C1 -
13 Expansion Bus-F1 -
■
F-1-4F-1-4
No. Brand name Remarks and condition
14 Additional Memory Type B (512MB) -
15 Image Data Analyzer Board-A1 Document Scan Lock Kit-A1 is required
16 Super G3 FAX Board-AE1 -
17 Super G3 2nd Line Fax Board-AE1 1-line FAX board is required
18 Super G3 3rd/4th Line Fax Board-AE1 1-line FAX board + additional 2nd line FAX Board
is required
19 imagePASS-B1 -
20 IPSec Board-B2 PCI bus expansion kit-F1 is required
21 Wireless LAN Board-B1-
22 Signal Interface Kit-A1 -
23 Serial Interface Kit-K1 -
24 PCL Printer Kit-AE1 -
Direct Print Kit (for PDF/XPS)-H1 -
Barcode Printing Kit-D1 -
Encrypted Secure Print Software-D1 -
IMPOSE(Ver2.7) Roman Number of license: 1, 3, 7
Universal Send Digital User Signature
Kit-C1 -
Universal Send Advanced Feature Set-D1 -
Universal Send Security Feature Set-D1 -
Remote Operators Software Kit-B1 -
Remote Operators Software Kit-A3 -
HOTFOLDER VER.2 -
HDD Data Erase Kit-A1 -
Remote Fax Kit-A1 -
PS Printer Kit-AE1 -
Secure Watermark-A1 -
Document Scan Lock Kit-A1 -
ACCESS MANAGEMENT SYSTEM Kit-B1 -
Web Access Software-H1 -
Note:
There is a combination restriction when installing No1,2,5 to 6. (Part No5 can be
installed with any of those. Other than No5, only one of them can be installed.)
T-1-4T-1-4

1
11-5
1-5
Feature
Product feature
Product feature
Y M C Bk
Fixing Assembly
・Color on-demand fixing
method is adopted.
ITB
・Primary Transfer Roller
detaching control is
Main Controller
・Next generation controller
Toner Container
・New toner is adopted.
Low running cost
High image quality
High-speed support
Laser Scanner Unit
・Twin Laser Scanner Unit
・ Capable of 1200 dpi
Developing Assembly
・ACR control is adopted.
・Developing Assembly/Drum
・Highly-durable drum is
High-speed support
High-speed support
Low running cost
High image quality
High image quality
High image quality
Unit are separated.
adopted(BK only).
is adopted.
adopted.
■
F-1-5F-1-5
Features at servicing
Improvement on upgrade operation
It is possible to upgrade options through the host machine.
Same as conventional way, use SST (service support tool) to upgrade.
New type connector is adopted
To prevent the communication error due to following factors, new type connector is adopted.
Loose connector / disconnection due to vibration during transportation
Imperfect connection of connector at service operation
■
■
•
•

1
11-6
1-6
Specication
Specication
Host machine installation
method Desktop type
Photosensitive medium Phi 30 OPC
Exposure method Laser exposure
Charging method Roller charging
Developing method Dry type 2-component jumping development
Transfer method Intermediate belt transfer
(Primary transfer: roller transfer, secondary transfer: roller transfer)
Separation method Curvature separation + static eliminator
Pickup method Separation retard
Fixing method On demand xing (Ceramic nitride heater + Phi 30 elastic lm)
Delivery method Facedown (inner delivery)
Drum cleaning method Cleaning blade
Transfer cleaning method Cleaning blade
Toner type Non-magnetic negative toner
Toner supply method Toner container method
Toner level detection function Yes
Leading edge image margin 4.0+1.5/-1.0mm
Left edge image margin 2.5+/-1.5mm
Leading edge blank width 4.0+1.5/-1.0mm
Left edge blank width 2.5+/-1.5mm
Warm-up time At power-ON, 38 sec or less
Image gradation 256 gradation
Print resolution 1200 x 1200dpi
Paper type (cassette) Thin paper (52 to 63g/m2), Recycled paper (64 to 81g/m2), Color
paper, Pre-Punched paper, Bond paper, Plain paper (64 to 105g/
m2), Heavy paper (106 to 209g/m2), Textured paper, Transparency
lm, Tab paper, Envelope
Paper type (multi-purpose tray) Thin paper (52 to 63g/m2), Recycled paper (64 to 81g/m2), Color
paper, Pre-Punched paper, Bond paper, Plain paper (64 to 105g/
m2), Heavy paper (106 to 256g/m2), Textured paper, Tracking
paper, Coater paper,Labels paper, Washi paper,Transparency lm,
Tab
Paper size (upper cassette) B4,A4,A4R,B5,B5R,A5R,LGL,LTRR,LTR,EXEC,Custom size (Min
139.7mm x 182mm to Max 304.8mm x 390mm),K8,K16,K16R
Paper size (lower cassette) A3, B4, A4, A4R, B5, B5R, A5R, 12"×18"(305mm×457mm), 11" x
17", LGL, LTR, LTRR, STMTR, EXEC, Custom size (Min 139.7mm
x 182mm to Max 304.8mm x 457.2mm), K8, K16, K16R, Envelope
(COM10, Monarch, DL, ISO-B5, ISO-C5)
Paper size (multi-purpose tray
pickup) A3, B4, A4, A4R, B5, A5,A5R,12""×18""(305mm×457mm),11""× 17"", LGL, LTR, LTRR, STMT, STMTR, EXEC, K8, K16, K16R,
FLS, 305×457, 320×450(SRA3), Custom size (Min 99mm x
139.7mm to Max 320 mm x 457.2mm),Postcard, Envelope (COM10,
Monarch, DL, ISO-B5, ISO-C5)
Pickup capacity Cassette: 550 sheet (80g/m2), multi-purpose tray pickup: 100 sheet
(80g/m2)
Duplexing method Through path duplexing
Memory capacity Main controller PCB: 1 GB
Main controller PCB2: 1GB/1.5GB (differs depending on destination
and model)
Note:
Option (additional memory 512MB) can be extended to main
controller PCB 2.
HDD capacity 80GB (Option 80GB C1/ 250GB D1)
Operation noise 75dB or less (during printing)
Ozone amount Maximum: 0.01 ppm or less
Power rating AC120V/20A (image RUNNERADVANCE C5051/C5045 Series)
AC120V/15A (image RUNNER ADVANCE C5035/C5030 Series)
AC220-240V/10A
Maximum power consumption image RUNNER ADVANCE C5051/C5045 Series: 1.8kW or less
image RUNNER ADVANCE C5035/C5030 Series: 1.3kW or less
Power consumption during
copy 120V:1.1KW or less 220V-240:1.3KW or less
Power consumption during
standby 120V: 120W or less 220V-240: 150W or less
Dimension (W x D x H) 620mm x735mmx 801mm (printer only)
Grammage Approx. 133kg (printer only)
T-1-5T-1-5

1
11-7
1-7
Weight / Size
Product name Width
(mm) Depth (mm) Height (mm) WeightApprox. (Kg)
iR ADVANCE C5051/C5045 620 735 806 153
iR ADVANCE C5035/C5030 620 735 806 170
Duplex Color Image Reader Unit-B1 618 588 251 38.8
Color Image Reader Unit-B1 620 536 207 23
Color Image Reader Unit-B2 620 564 72 13.7
Cassette Feeding Unit-AD1 620 700 251 27.5
Paper Deck Unit-B1 372 603 473 37
Envelope Feeder Attachment-D1 439 307 81 1.2
Inner Finisher-A1 602 540 234 13.5
Staple Finisher-C1 545 656 1071 47
Booklet Finisher-C1 756 656 1071 76
Buffer Pass Unit-G1 489 493 184 4
External 2 Hole Puncher-B1 107 623 908 7.2
External 2/3 Hole Puncher-B1 756 656 1071 76
Productivity (Print speed)
Size Mode Paper type
Paper
basis
weight(g/
m2)
ImageRUNNER ADVANCE
C5051 C5045
Cassette Multi- purpose
tray Cassette Multi-
purpose
tray
Color, B/W Color, B/W Color, B/W Color, B/W
A4 / LTR
1-sided
Plain paper 52-81 51.0 31.0 45.0 31.0
82-105 51.0 31.0 45.0 31.0
Thick paper 105-163 25.5 15.5 25.5 15.5 164-209 20.0 15.5 20 15.5
210-256 - 10.0 - 10.0
2-sided
Plain paper 52-81 51.0 31.0 45.0 31.0
82-105 51.0 31.0 45.0 31.0
Thick paper 105-163 25.5 15.5 25.5 15.5 164-209 20.0 15.5 20 15.5
210-256 - - - -
T-1-6T-1-6
Size Mode Paper type
Paper
basis
weight(g/
m2)
ImageRUNNER ADVANCE
C5051 C5045
Cassette Multi- purpose
tray Cassette Multi-
purpose
tray
Color, B/W Color, B/W Color, B/W Color, B/W
A3 / LDR
1-sided
Plain paper 52-81 25.5 19.5 25.5 19.5
82-105 25.5 19.5 25.5 19.5
Thick paper 105-163 12.5 9.8 12.5 9.8 164-209 10.0 9.8 10.0 9.8
210-256 - 6.5 - 6.5
2-sided
Plain paper 52-81 25.5 19.5 25.5 19.5
82-105 25.5 19.5 25.5 19.5
Thick paper 105-163 12.5 9.8 12.5 9.8 164-209 10.0 9.8 10.0 9.8
210-256 - - - -
Size Mode Paper type
Paper
basis
weight(g/
m2)
ImageRUNNER ADVANCE
C5035 C5030
Cassette Multi- purpose
tray Cassette Multi-
purpose
tray
Color, B/W Color, B/W Color, B/W Color, B/W
A4 / LTR
1-sided
Plain paper 52-81 35.0 20.0 30.0 20.0
82-105 35.0 20.0 30.0 20.0
Thick paper 105-163 17.0 10.0 17.0 10.0 164-209 17.0 10.0 17.0 10.0
210-256 - 10.0 - 10.0
2-sided
Plain paper 52-81 35.0 20.0 30.0 20.0
82-105 35.0 20.0 30.0 20.0
Thick paper 105-163 17.0 10.0 17.0 10.0 164-209 17.0 10.0 17.0 10.0
210-256 - - - -
A3 / LDR
1-sided
Plain paper 52-81 17.5 13.0 17.5 13.0
82-105 17.5 13.0 17.5 13.0
Thick paper 105-163 8.5 6.5 8.5 6.5 164-209 8.5 6.5 8.5 6.5
210-256 - 6.5 - 6.5
2-sided
Plain paper 52-81 17.5 13.0 17.5 13.0
82-105 17.5 13.0 17.5 13.0
Thick paper 105-163 8.5 6.5 8.5 6.5 164-209 8.5 6.5 8.5 6.5
210-256 - - - -
T-1-7T-1-7
T-1-8T-1-8

1
11-8
1-8
Paper type
Usable paper types are shown on the next page and later.
For irregular-sized paper, refer to the table below.
Type Feeding direction (mm) Width direction (mm)
Irregular size 1-1 182.0 to 209.9 139.7 to 181.9
Irregular size 1-2 210.0 to 279.2 -
Irregular size 1-3 279.3 to 432.0 -
Irregular size 1-4 432.1 to 487.7 -
Irregular size 2-1 182.0 to 209.9 182.0 to 210.0
Irregular size 2-2 210.0 to 279.2 -
Irregular size 2-3 279.3 to 432.0 -
Irregular size 2-4 432.1 to 487.7 -
Irregular size 3-1 182.0 to 209.9 210.1 to 297.0
Irregular size 3-2 210.0 to 279.2 -
Irregular size 3-3 279.3 to 432.0 -
Irregular size 3-4 432.1 to 487.7 -
Irregular size 4-1 182.0 to 209.9 297.1 to 330.2
Irregular size 4-2 210.0 to 279.2 -
Irregular size 4-3 279.3 to 432.0 -
Irregular size 4-4 432.1 to 487.7 -
Irregular size 5 487.8 to 630.0 139.7 to 330.2
T-1-9T-1-9
Pickup
Paper type(g/
m2)Size Multi-
purpose
tray
Cassette
1Cassette 2
Cassette
Feeding
Unit 1
Cassette
Feeding
Unit 2
Paper
Deck
Plain 1 (52 to
81)
Thin, Recycled,
Pre-Punched,
Color
Plain 2 (82 to
105)
Bond
Heavy 1 (106
to 163)
Textured
Heavy 2 (164
to 209)
Labels, Tab
•
•
•
•
A4, LTR Yes Yes Yes Yes Yes Yes
B4, A4R, A5R,
B5, B5R, EXEC,
LGL, LTRR,
STMTR, 16K,
16KR
Yes Yes Yes Yes Yes No
A3, LDR, EXE,
12”No18”, 8K
Yes No Yes Yes Yes No
A5, STMT,
SRA3, OFFICIO,
E-OFFICIO,
B-OFFICIO,
M-OFFICIO,
A-OFFICIO,
A-LTR, A-LTRR,
GLTR-R, GLTR,
GLGL, AFLS,
FLS, Irregular
size 1-1, Irregular
size 1-2, Irregular
size 1-3, Irregular
size 1-4, Irregular
size 2-1, Irregular
size 2-2, Irregular
size 2-3, Irregular
size 2-4, Irregular
size 3-1, Irregular
size 3-2, Irregular
size 3-3, Irregular
size 3-4, Irregular
size 4-1, Irregular
size 4-2, Irregular
size 4-3, Irregular
size 4-4, Irregular
size 5
Yes Yes Yes Yes Yes No
EXEC-R Yes No No No No No
Transparency A4, LTR Yes Yes Yes Yes Yes Yes
■

1
11-9
1-9
Paper type(g/
m2)Size Multi-
purpose
tray
Cassette
1Cassette 2
Cassette
Feeding
Unit 1
Cassette
Feeding
Unit 2
Paper
Deck
Special paper
Tracing, Coated,
Washi
Heavy 3 (210
to 258)
•
•
A4, LTR, B4,
A4R, A5R, B5,
B5R, EXEC,
LGL, LTRR,
STMTR, 16K,
16KR, A3, LDR,
EXE, 12”No18”,
8K, A5, STMT,
SRA3, OFFICIO,
E-OFFICIO,
B-OFFICIO,
M-OFFICIO,
A-OFFICIO,
A-LTR, A-LTRR,
GLTR-R, GLTR,
GLGL, AFLS,
FLS, F4A,
Irregular size 1-1,
Irregular size 1-2,
Irregular size 1-3,
Irregular size 1-4,
Irregular size 2-1,
Irregular size 2-2,
Irregular size 2-3,
Irregular size 2-4,
Irregular size 3-1,
Irregular size 3-2,
Irregular size 3-3,
Irregular size 3-4,
Irregular size 4-1,
Irregular size 4-2,
Irregular size 4-3,
Irregular size 4-4,
Irregular size 5
Yes No No No No No
Postcard A6 irregular Yes No No No No No
Envelope COM10,
Monarch, ISO-C5,
ISO-B5, DL,
Yes No Yes* No No No
* When Envelope Feeder Attachment-D1 is installed T-1-10T-1-10
Name of Parts
External View
1
2
6
7
11
3
11
10
9
8
5
4
12
13
[1] DADF [8] Front Cover
[2] Main Power Switch [9] Front Upper Cover
[3] Stack Bypass Tray [10] Output Tray
[4] Paper Drawer4 [11] Control Panel
[5] Paper Drawer3 [12] Rear Cover
[6] Paper Drawer2 [13] Rear Rower Cover
[7] Paper Drawer1 [14] Breaker
F-1-6F-1-6

1
11-10
1-10
Cross Sectional View
Y M C Bk
[1]
[2]
[3]
[4]
[5]
[6]
[7]
[8]
[9]
[10]
[11]
[14]
[17]
[24]
[18]
[19]
[20]
[21]
[26]
[28]
[29]
[32]
[12]
[15]
[13]
[23]
[25]
[27]
[30]
[31]
[22]
[16]
[37]
[38]
[39]
[40]
[41]
[42]
[43]
[44]
[45]
[33]
[36]
[34]
[35]
F-1-7F-1-7
[1] Reversal roller [16] Fixing separration guide [31] Cassette 2 feeding roller
[2] 2-side delivery / delivery
unit [17] Roller pressure [32] Cassette 2 separation roller
[3] Secondary delivery roller [18] Film unit [33] Casset 2 pick-up roller
[4] Second delivery entrance
apper
[19] ITB unit [34] Casset pick-up unit
[5] Second delivery apper [20] Registration roller [35] Laser scanner unit (BK /
C)
[6] Third delivery roller [21] 2-side delivery lower
roller [36] Laser scanner unit (M / Y)
[7] Second / third delivery
entrance roller [22] Registration roller [37] Developing unit (Bk) + Drum unit (Bk)
[8] 2-side entrance roller [23] Bypass feeding roller [38] Developing unit (C) +
Drum unit (C)
[9] Primary delivery roller [24] Bypass pick-up roller [39] Developing unit (M) +
Drum unit (M)
[10] Primary delivery apper [25] Bypass separration roller [40] Developing unit (Y) +
Drum unit (Y)
[11] Fixing inner delivery roller [26] Vertical path roller 1 [41] ITB cleaning unit
[12] Fixing inner delivery
opposed roller [27] Cassette 1 feeding roller [42] Hopper unit (Y)
[13] Fixing unit [28] Cassette 1 separation
roller [43] Hopper unit (M)
[14] Post-xing roller [29] Casset 1 pick-up roller [44] Hopper unit (C)
[15] 2-side delivery upper
rollerr [30] Vertical path roller 2 [45] Hopper unit (BK)

1
11-11
1-11
Operation
Power Switch
Types of power switch
Environmnet
Heater Switch Control Panel
Power Switch
Main Power Switch
This machine is equipped with the Main Power Switch, Control Panel Power Switch and
Environment Heater Switch.
[1] Main Power Switch
This switch is used to turn OFF / ON the power of host machine.
[2] Control Panel Power Switch
This switch is to shift the machine to power-save mode or to restore it to normal mode.
[3] Environment Heater Switch
Environment Heater Switch is to supply and shut the power to Cassette Heater and
Reader Heater.
■
●
F-1-8F-1-8
How to turn ON / OFF the power and points to note
While progress bar is kept displayed at power-on, HDD access is processing; thus, never
turn OFF the Main Power Switch.
To turn off the power, turn off the Main Power Switch. (Conventional shutdown sequence
operation is not required.)
After power-OFF (after the Main Power Switch is turned OFF), do not reactivate the Main
Power Switch until a screen disappears.
Do not turn OFF the power while download is processing.
●
•
•
•
•

1
11-12
1-12
Description of Control Panel
Control Panel
iR ADVANCE C5051 / 5045 / 5035 / 5030 Series
1 2
3
4
56789
10111213
14
15
[1] Control Panel Power Switch [9] ID (authentication) Key
[2] USB Insertion Slot [10] Touch Panel Display
[3] Settings / Registration Key [11] Screen Brightness Adjustment Dial
[4] Counter Check Key [12] FAX Volume Adjustment Key
[5] Operation Pen [13] Status Check / Stop Key
[6] Main Power Lamp [14] Custom Menu Key
[7] Error Lamp [15] Main Menu Key
[8] Execution / Memory Lamp
■
●
F-1-9F-1-9
Main Menu
iR ADVANCE C5051 / 5045 / 5035 / 5030 Series
Scan and Send
Fax / I-Fax
Inbox
3 421
7 865
9
[1] Copy [6] Secured Print
[2] Scan and Send [7] Scanner
[3] Scan and Store [8] Set / Regi. Short Cut
[4] Access Stored Files [9] Tutorial
[5] Fax / I-Fax Inbox
●
F-1-10F-1-10

1
11-13
1-13
Difference of main menu
iRC 3380 / 2880 Series iR ADVANCE
C5151/5045/5035/5030 Series
Copy Copy
Send Scan and Send
Mail BOX Scan and Store
Access Stored Files
Fax / I-Fax Inbox
Menu Change Key -----
Print Job Secured Print
Scan Scanner
----- Set / Regi. Short Cut
(Help) Tutorial
●
T-1-11T-1-11
Settings / Registration menu
iR ADVANCE C5051 / 5045 / 5035 / 5030 Series
Log in
Settings/Registration
Select an item to set
Preferences
Adjustment/Maintenance
Function Settings
Set Destination
TOP
OK
1/1
Management Settings
1
2
3
4
5
[1] Preferences [4] Set Destination
[2] Adjustment / Maintenance [5] Management Settings
[3] Function Settings
Difference of Settings / Registration menu
iRC 3380 / 2880 Series iR ADVANCE
C5151/5045/5035/5030 Series
Common Settings Preferences
Timer Settings
Adjustment / Cleaning Adjustment / Maintenance
System Settings Set Destination
Report Settings Function Settings
Copy Settings
Communication Settings
Mail Box Settings
Printer Settings
Address Book Settings Management Settings
●
●
F-1-11F-1-11
T-1-12T-1-12
