TurningthePoweronandoff [ForLBP-2260]
Tooperatetheprinter,pressthepowerbuttontoturntheprinteron.Aftertheprinterandoptions
gothroughastatuscheckandcalibration,printingisenabled.
Toturntheprinteroff,checkprinterstatusandthenfollowtheinstructionsbelowtoturnthe
printeroff.Whenyouturnthepoweroff,alldataintheprinter’smemoryislost.Topreventprint
datathatyouneedfrombeingaccidentallyerasedandtopreventdatafrombeingerasedfrom
anothercomputerwhentheprinterisconnectedtoanetwork,alwayscheckthattheジョブand
HDDindicators(whenaharddiskdriveisattached)areoffbeforeyouturntheprinteroff.
TurningthePoweron
Toturnthepoweronfollowtheinstructionsbelow.
1
Pressthepowerbuttononthe
printer.
Thepowerbuttonwillnowbeinapressed-
downstate.
Theoperationpanelindicatorsandthe
displaycomesonandthestatusoftheprinter
andoptionaldevice(s)isself-diagnosed.If
theresultsoftheself-diagnosisarenormal,
theprinterandoptionswillthenbecalibrated.
When calibration is completed, the
オンラインindicator,the印刷可indicator
andtheselectedpaperfeedindicatorcome
onandprintingisenabledwhenthemessage
[00 インサツ カノウ]appearsonthe
display.
ジョブキャンセル
メッセージ/ HDD
00ｲﾝｻﾂｶﾉｳ A4
ﾊｲｼﾄﾚｲ

3
Thefollowinginformationappearsonthedisplay.
Currentlyselected
paperfeedsize
Currentlyselectedoutputtray
Printingenabled,noprinting
databeingprocessed
00ｲﾝｻﾂｶﾉｳA4
ﾊｲｼﾄﾚｲ
Powersaving(Sleepmode)
Theprinterwillgointosleepmodetosavepowerifnooperationsarecarriedoutandno
dataissentfromthecomputerforasettime.
Sleepmodeisautomaticallycanceledifdataissentfromthecomputeroranoperation
panelkeyispressed.
● Theprinterwilltakelonger(amaximumof5minutes)towarmup
(thetimethefixingassmblytemperaturetakestorise)ifithasbeen
insleepmodeforalongtime.
● Thefactorysettingforsleepmodeis60minutes.Youcanusethe
menufunctiontochangethisto15,30,60or180minutes.

4
TurningthePoweroff
Theprocedureforturningthepoweroffdiffersdependingonwhetherornotaharddiskdriveis
installed.Ifaharddiskdriveisinstalled,alwaysturnthepoweroffbyfollowingtheinstructions
givenforprotectingtheharddiskdrive.(→p.5)
● Iftheprinterisconnectedtoanetwork,checkthatothercomputersarenot
printingbeforeyouturnthepoweroff.
● Ifyouturnthepoweroffwhentheジョブindicatorison,anyprintingdata
remainingintheprinter’smemoryaswellasprintingdataspooledonthe
harddiskthatisbeingprocessed(otherthanprintdatathathascompleted
storageprocessing)willbelost.Waituntiltheprintingdatathatyouneed
hasfinishedprintingorgooff-line,pressthe 排出 keytooutputthe
printingdatathenturnthepoweroff.
● Donotturnofftheprinterwhileprinting.
● Donotturnofftheprinterduringtheself-diagnosiscarriedoutimmediately
afterturningthepoweron.
● Ifaharddiskdriveisinstalled,alwayscheckthattheHDDindicator(green)
isnoton.IfthepoweristurnedoffwhiletheHDDindicator(green)ison
(whiletheharddiskdriveisbeingwritteninto),thiswilldamagethehard
diskdriveandmayrenderitinoperable.
● IfamessageappearsonthedisplayindicatingthattheNVRAMisinitializing
orthattheNVRAMisbeingwritteninto,checkthatthemessagehas
disappearedbeforeyouturnthepoweroff.
● Ifamessageappearsonthedisplayindicatingtheflashmemoryisbeing
writtenintoorthattheflashmemoryisbeingerased,checktomakesure
themessagehasdisappearedbeforeyouturnthepoweroff.
■ Ifnoharddiskdriveisinstalled
1
Checkthattheジョブindicatoris
off.
メッセージ/ HDD

5
2
Pressthepowerbuttononthe
printer.
Thepowerbuttonwillpopup.
● Whenthepoweristurnedoff,theinternalcoolingfanontherearpanelof
theprinterwillcontinuetooperateuntiltheinterioroftheprinterhasbeen
fullycooledoff.Ifyouwanttoremovethepowercable,waituntilthecooling
fanhascompletelystopped(approx.30minutes).
■ Ifaharddiskdriveisinstalled
1
Checkthattheジョブindicatorand
theメッセージindicator(orange)/
HDDindicator(green)areoff.
メッセージ/ HDD
2
Pressthe オンライン keytoturn
offtheオンラインindicator.
ジョブキャンセル
00ｲﾝｻﾂｶﾉｳA4
ﾊｲｼﾄﾚｲ
Settingcanbecarriedoutusingtheoperation
panel.

6
3
Pressthe 動作モード key.
ジョブキャンセル
4
Pressthe ＜ or ＞ keyto
select[シャットダウン] andthen
pressthe ∨ key.
ジョブキャンセル
5
Checkthe message and then
pressthe ∨ key.
ジョブキャンセル
Shutdownisrunandthemessage[デンゲ
ンヲ オキリクダサイ]willappeartotell
youwhenyoucanturntheprinteroff.

● Ifthereisajobontheharddiskforwhichoperationshavebeenstopped,
themessage[ジョブガ ノコッテイマス]willappear.Whenshutdownis
run,alljobswillbedeleted.However,jobsthathavebeenstoredforprinting
willbesavedontheharddisk.Ifyouwanttocontinueprinting,pressthe
オンライン keytogoon-line.
● Shutdowncannotbestoppedonceithasbeenstarted.Ifyouwanttoturn
theprinteronagain,followtheinstructionsonthedisplayandturnthepower
backonafteryouhaveturneditoff.
ﾄﾞｳｻﾓｰﾄﾞ
=ｼﾞﾄﾞｳｾﾝﾀｸ
ﾄﾞｳｻﾓｰﾄﾞ
ｼｬｯﾄﾀﾞｳﾝ
ｼｬｯﾄﾀﾞｳﾝ
ｼﾞｯｺｳｼﾏｽｶ?
ｼｬｯﾄﾀﾞｳﾝ
ｼﾞｯｺｳｼﾏｽｶ?
ｼｬｯﾄﾀﾞｳﾝ
ｼﾞｯｺｳﾁｭｳ
ｼｬｯﾄﾀﾞｳﾝｵ
ﾃﾞﾝｹﾞﾝｦ ｵｷﾘｸﾀﾞｻｲ

7
6
Whenthemessage[デンゲンヲ オ
キリクダサイ] appears on the
display,pressthepowerbuttonon
theprinter.
Thepowerbuttonwillpopup.
● Whenthepoweristurnedoff,theinternalcoolingfanontherearpanelof
theprinterwillcontinuetooperateuntiltheinterioroftheprinterhasbeen
fullycooledoff.Ifyouwanttoremovethepowercable,waituntilthecooling
fanhascompletelystopped(approx.30minutes).

8
TurningthePoweronandoff [ForLBP-2160]
Aftertheprinterandoptionsgothroughastatuscheckandcalibration,printingisenabled.
Whenthepoweristurnedoff,alloftheprintingdatainthememoryislost.Alwayscheckthat
theジョブindicatorisoffbeforeturningthepoweroffinordertoavoiddeletingimportant
printingdatabyaccidentordeletingprintingdatafromanothercomputerwhenconnectedtoa
network.
TurningthePoweron
Toturnthepoweronfollowtheinstructionsbelow.
1
Pressthepowerbuttononthe
printer.
Thepowerbuttonwillnowbeinapressed-
downstate.
Theoperationpanelindicatorsandthe
displaycomesonandthestatusoftheprinter
andoptionaldevice(s)isself-diagnosed.
Iftheresultsoftheself-diagnosisarenormal,theprinterandoptionswillthenbecalibrated.
Whencalibrationiscompleted,theオンラインindicator,the印刷可indicatorandtheselected
paperfeedindicatorcomeonandprintingisenabledwhenthemessage[00 インサツ カノ
ウ]appearsonthedisplay.
00ｲﾝｻﾂｶﾉｳ A4
ﾊｲｼﾄﾚｲ
Thefollowinginformationappearsonthedisplay.
Currentlyselected
paperfeedsize
Currentlyselectedoutputtray
Printingenabled,noprinting
databeingprocessed 00ｲﾝｻﾂｶﾉｳA4
ﾊｲｼﾄﾚｲ

9
TurningthePoweroff
Toturnthepowerofffollowtheinstructionsbelow.
● Iftheprinterisconnectedtoanetwork,checkthatothercomputersarenot
printingbeforeyouturnthepoweroff.
● Ifyouturnthepoweroffwhentheジョブindicatorison,anyprintingdata
remainingintheprinter’smemorywillbelost.Gooff-line,pressthe
排出 keytooutputtheprintingdatathenturnthepoweroff.
● Donotturnofftheprinterwhileprinting.
● Donotturnofftheprinterduringtheself-diagnosiscarriedoutimmediately
afterturningthepoweron.
1
Checkthattheジョブindicatoris
off.
2
Pressthepowerbuttononthe
printer.
Thepowerbuttonwillpopup.
● Whenthepoweristurnedoff,theinternalcoolingfanontherearpanelof
theprinterwillcontinuetooperateuntiltheinterioroftheprinterhasbeen
fullycooledoff.Ifyouwanttoremovethepowercable,waituntilthecooling
fanhascompletelystopped(approx.30minutes).

10
Powersaving(Sleepmode)
Theprinterwillgointosleepmodetosavepowerifnooperationsarecarriedoutandno
dataissentfromthecomputerforasettime.
Sleepmodeisautomaticallycanceledifdataissentfromthecomputeroranoperation
panelkeyispressed.
● Theprinterwilltakelonger(amaximumof5minutes)towarmup
(thetimethefixingassemblytemperaturetakestorise)ifithasbeen
insleepmodeforalongtime.
● Thefactorysettingforsleepmodeis60minutes.Youcanusethe
menufunctiontochangethisto5,15,30,60or180minutes.

11
Paper
PaperSources[ForLBP-2260only]
Initsnormalstatetheprinterhasthreepossiblepapersources,twopapercassettesandapaper
tray.Ifyouattachtheoptional2000-sheetpaperdeckand2×500-sheetpaperdeck,youwillbe
abletouseuptofivepapersources.
● Normalstate
Papersource: Papertray
Papercassette1
Papercassette2
No.ofsheets: 1100(max.)(64g/m2)
Papertray

Cassette1
Cassette2
● Whenthe2000-sheetpaper
deck-N1isattached
Papersource: Papertray
Papercassette1
Papercassette2
Paperdeck
No.ofsheets: 3100(max.)(64g/m2)
Papertray

Cassette1
Cassette2
Paperdeck
● Whenthe2×500-sheetpa-
perdeck-C1isattached
Papersource: Papertray
Papercassette1
Papercassette2
Papercassette3
Papercassette4
No.ofsheets: 2100(max.)(64g/m2)
Papertray

Cassette1
Cassette2
Cassette4
Cassette3


12
● Whenthe2×500-sheetpa-
perdeck-C1Lisattached
Papersource: Papertray
Papercassette1
Papercassette2
Papercassette3
Papercassette4
No.ofsheets: 2100(max.)(64g/m2)
Papertray
Cassette1
Cassette2

Cassette4
Cassette3


13
CompatiblePaper[ForLBP-2260only]
Thisprintercanusethefollowingtypesofpaper.◎indicatesthatbothsingle-sideandduplex
printingusinganoptionalduplexunitispossible.○indicatesthatonlysingle-sideprintingis
possible,△indicatesthatprintingsubjecttorestrictionsispossibleand×indicatesthatprinting
cannotbeperformed.
■ Papersizes
Papersource
Papertype Papertray Cassette1 Cassette2 Cassette3 Cassette4 Paperdeck
(option) (option) (option)
Plainpaper
(64-105g/m
2
)
A5 ◎ ◎ *1× ◎ *1××
B5 ◎ ◎ *2× ◎ *2××
A4 ◎◎◎◎◎◎
A4R ◎×××××
B4 ◎◎◎◎◎◎
A3*3◎×◎×◎◎
Letter ◎ ◎◎◎◎◎
LetterR ◎ ×××××
Executive ◎ ×××××
Legal*3◎◎◎◎◎◎
Ledger*3◎×◎×◎◎
Userpaper
width:98.4-304.8mm ○×××××
length:190-469.9mm
Thickpaper
(106-135g/m2)
A5 ○×××××
B5 ○×××××
A4 ○×××××
A4R ○×××××
B4 ○×××××
A3 ○×××××
Letter ○ ×××××
LetterR ○ ×××××
Executive ○ ×××××
Legal ○ ×××××
Ledger ○ ×××××
Userpaper
width:98.4-304.8mm ○×××××
length:190-469.9mm
GlossypaperA4 ○ ×××××
TransparenciesA4 ○ ×××××
LabelsheetA4 ○ ×××××
*1CanbeloadedwhentheoptionalCS-82(A5R)500-sheetcassetteisinstalled.
*2CanbeloadedwhentheoptionalCS-82(B5R)500-sheetcassetteisinstalled.
*3BothsidescanbeprintedifoptionalextraRAMmemoryisinstalled.

14
■ No.ofSheetsStoredinPaperSource
Papersource
Papertype
Papertray Cassette1 Cassette2 Cassette3 Cassette4 Paperdeck
(option) (option) (option)
Plainpaper (64g/m
2
) approx.100 approx.500 approx.500 approx.500 approx.500 approx.2,000
Thickpaper(128g/m2) approx.50 ×××××
Glossypaper approx.50 ×××××
Transparencies approx.50 ×××××
Labelsheet approx.40 ×××××
■ No.ofSheetsOutput
Output
Papertype Outputtray Sub-outputtray Bins1-7
(non-sorterbin) (option)
Plainpaper (64g/m
2
) approx.300 approx.100 120sheetsforeachbin
Thickpaper(128g/m2)△*4approx.50 ×
Glossypaper △*41×
Transparencies △*41×
Labelsheet △*4approx.40 ×
*4 Ifabinina7-binsorterisspecifiedforoutput,printingiscarriedoutandanerrorskipis
performed,thepaperwillbeoutputintotheoutputtray.Youcanalsosetastandardoutput
destination,butbecausethatmayresultincurledorwrinkledpaper,werecommendthatthe
sub-outputtray(non-sorterbin)beused.
● Whenprintingonbothsidesofasheetofpaper,alwaysusetheoptional
duplexunit.Donotmakeamanualduplexprintfromthepapertray.
● IfyouhaveloadedA3-orLedger-sizepaperintoatray,makesurethatthe
paperisatleast75g/m2.
● WhenyouloadA5-orB5-sizepaperintothepapertray,loaditinthe
lengthwisefeeddirection.
● Whenyouloadlabelsheetintothepapertray,insertitinthelengthwisefeed
direction.Ifyouhaveset[トレイ ヨウシ サイズ]inthepaperfeedmenuto
[A4R]oryouhavesetitto[フリー],set[ヨウシノムキ]to[タテオクリ].

15
● Ifapaperdeckisconnected,consecutiveprintingmaybetemporarily
suspended,nomatterwhatthepapersourceis,inordertomonitorthe
statusofthepaperdeck.
● Whentheprinter’suppercassette(cassette1)orthe2 ×500-sheetpaper
deck’suppercassette(cassette3)ischangedtotheoptional500-sheet
cassetteCS-82(B5RorA5R),B5-orA5-sizepapermaybeloaded.
● Theoptional500-sheetuniversalcassetteUC-82maybereplacedbythe
printer’suppercassette(cassette1)orthe2×500-sheetpaperdeck’s
uppercassette(cassette3).
● Theoptional500-sheetuniversalcassetteUC-82Kmaybereplacedbythe
printer’slowercassette(cassette2)orthe2×500-sheetpaperdeck’s
lowercassette(cassette4).

16
CompatiblePaper[ForLBP-2160only]
Inthisprinter,papercanbefedfromthepapercassette,papertrayorthe2000-sheetpaperdeck
(optional).Differenttypesofpapercanbeloadedintoeachpapersource.Makesurethatyou
loadthepaperproperly.
Usethecorrectpaperinordertogetthebestperformancefromyourprinter.Usingimcompatible
papercanleadtoreducedprintingqualityandpaperjamming.
■ Standardstatus
Papersource Papertype Size Weight Max. Papertype/
(g/m
2
) sheetno. mediasetting
Uppercassette Plainpaper A4,B4,Letter,Legal 64-105
approx.500 フツウシ
(64g/m
2
)
Lowercassette Plainpaper
A4,B4,A3,Letter,Legal,
64-105
approx.500 フツウシ
Ledger (64g/m
2
)
Papertray Plainpaper width:98.4-304.8mm 64-105
approx.100 フツウシ
length190-469.9mm (64g/m
2
)
Thickpaper width:98.4-304.8mm 106-135
approx.50 アツガミ
length190-469.9mm (128g/m
2
)
Glossypaper A4(CanonColorLaser − approx.50 コウタク
GlossypaperGF-1A4) フィルム
Transparencies
A4(CanonColorLaser − approx.50 OHP
OHPpaperTR-1A4)
Labelsheet A4(Canondomestic − approx.40 アツガミ
labelsheet:7.8g)
● Werecommendusing75g/m2orheavierpaperwhenloadingA3-andLedger-
sizepaper.
● LoadingA5andB5paperintothepapercassetterequirestheoptional500-
sheetuppercassetteCS-82(B5RorA5R).
● AlwaysloadA5orB5sizepaperorlabelsheetlengthwiseintothepaper
trayandchange[ヨウシノムキ]inthepaperfeedmenuto[タテオクリ].A5-
andB5-sizepaperandlabelsheetcannotprintiffedwidthwise.

17
■ Whenusingoptionalequipment
Papersource Papertype Size Weight Max. Papertype/
(g/m
2
) sheetno. mediasetting
500-sheetuppercassette
Plainpaper B5lengthwise 64-105
approx.500 フツウシ
(CS-82B5R) (64g/m
2
)
500-sheetuppercassette
Plainpaper A5lengthwise 64-105
approx.500 フツウシ
(CS-82A5R) (64g/m
2
)
2000-sheetpaperdeck
Plainpaper
A4,B4,A3,Letter,
64-105
approx.2,000
フツウシ
(PD-82) Legal,Ledger (64g/m
2
)
● Werecommendusing75g/m2orheavierpaperwhenloadingA3andLedger
sizes.
● Toprintonbothsidesofthepaper,usetheoptionalduplexunit.Manually
printingbothsidesfromthepapertraycanleadtoreducedprintingquality.
● Beforeselectingpaper,carefullyreadtheinstructions,“Paper”(→ p.16).
● Iftheoptional2000-sheetpaperdeckisconnected,consecutiveprinting
maybetemporarilysuspended,nomatterwhatthepapersourceis,inorder
tomonitorthestatusofthepaperdeck.
CompatiblePaper[ForLBP-2260/2160]
● Plainpaper
Theprintercanbeloadedwithanystandardformpaperof98.4-304.8mmwidth,190-469.9mm
lengthand64-105g/m2weightincludingA5-,B5-,A4-,B4-,A3-,Executive-,Letter-,Legal-
andLedger-sizepaper.
Standardformpapercanbefedfromeitherthepapercassette,paperdeckorpapertray.Attaching
aduplexunitallowsautomaticduplexprinting.Allothersizesarefedfromthepapertrayand
onlyonesidecanbeprinted.
● Thickpaper
Thisprintercanbeloadedwithanystandardformpaperof98.4-304.8mmwidth,190-469.9mm
lengthand106-135g/m
2
weightincludingA5-,B5-,A4-,B4-,A3-,Executive-,Letter-,Legal-
andLedger-sizepaper.Thickpapercanbefedonlyfromthepaperfeedtrayandprintedononly
oneside.
● Glossypaper
Touseglossypaper,useonlydedicatedCanonGF-1A4ColorLaserGlossypaper(A4size).
● GF-1A4GlossypaperisdesignedespeciallyforusewiththeLBP-2160
andLBP-2260printers.Donotusethispaperinanyothercolorlaserprinter
ormonochromeprinter.Suchusemayresultinprintermalfunctionor
deteriorationinpicturequality.

18
● Transparencies
Tousetransparencies,useonlydedicatedCanonTR-1A4ColorLaserOHPpaper.
● TR-1A4OHPpaperisdesignedespeciallyforusewiththeLBP-2160,
LBP-2040andtheLBP-2260.Donotusethispaperinanyothercolorlaser
printerormonochromeprinter.Suchusemayresultinprintermalfunction
ordeteriorationinpicturequality.
● Transparencies,otherthanthatspecifiedsuchasOHPpaperforusewith
theLBP-2030(CanonT-H1A4andT-H1LTRColorLaserOHPpaper),
OHPforCLC,andOHPformonochromeuse(CanondomesticLBP
transparencies),mustnotbeusedinthisprinter.Suchusemayresultina
malfunctioninthefixingassembly,ordeteriorationofpicturequality.
● Labelsheet
A4-sizelabelsheetcanbeusedinthisprinter.
● Donotusethefollowingtypesoflabelsheet.Ifapapertypethatdoesnot
conformtospecificationsisused,paperjamsthatarehardtoremovemay
occurorprintermalfunctionsmaybecaused.
・ Sheetwithlabelsthatarelikelytopeeloff,orsheetonwhichpartofthe
labelshavebeenused
・ Coatedsheetthatcaneasilypeelofffromthebackingsheet
・ Labelsheetwithsomeadhesivesurfacesexposed
● Whenputtinglabelsheetinthepapertray,eitherplaceitinthelengthwise
(vertical)directionandset[トレイ ヨウシ サイズ]inthepaperfeedmenu
to[A4R]orwhensettingitto[フリー]set[ヨウシノムキ]to[タテオクリ].

19
PrintableAreas
Theareasthatcanbeprintedonthepaperaregivenbelow.
● Plainpaper,thickpaper,transparencies,glossypaperandlabelsheet
Plainpaper,thickpaper,transparencies,glossypaperandlabelsheetcanbeprintedinareas
withaminimummarginof5millimeters.
5mm
5mm
5mm
5mmAreathatcanbeprinted
