Canon imageRUNNER C3222L User manual

Getting Started
Quick Operation P.5
Quick Setup P.2
Please read "Important Safety Instructions" before operating this product. After you finish
reading this guide, store it in a safe place for future reference.
The information in this document is subject to change without notice.
User's Guide / FAQ
https://oip.manual.canon/

Conguring the Method of
Connecting to a Computer
About Application Library
Application Library is an application that
allows you to use useful functions for
routine jobs or other convenient
functions in a one-touch operation
without necessity of making functional
settings every time. You can access each
registered function by simply pressing
the appropriate button displayed in the
Home screen. For the respective
function, see the description displayed in
the Setup Guide.
1.
2. Configure the initial settings, according to the
screen.
• Set the date and time
• Configure the Remote UI Access
• Perform color correction
IMPORTANT
To prevent unauthorized access by third parties,
you need a PIN for login to the remote UI that
has been set on the machine.
Before starting the conguration
• The machine cannot be connected to
both wired and wireless LANs at the
same time.
• If the machine is connected to an
unsecured network, your personal
information might be leaked to a third
party. Please be aware and careful of
this.
• The machine does not come with a
router. Please have one ready, if
necessary.
• Even in an environment without
wireless LAN router, you can use Access
Point Mode to make a wireless
connection to the machine directly
from your mobile device (Direct
Connection).
User's Guide
Specifying the connection method
• To connect via wireless LAN : <Yes>
• To connect via wired LAN or USB : <No>
2
Conguring the Machine
Conguring the Initial Settings
of the Machine
Congure the settings in the following order.
Quick Setup

For details
"Setting Up Using the Setup Guide" in the User's Guide
To connect via wireless LAN
1. Make sure that the computer is connected to a
router properly.
2. Check the network settings on the computer.
3. Take note of the SSID and network key.
• Check the label on the router. User's Guide
• The setting operation is easier if the router is
provided with a WPS mark. User's Guide
4. Set the access point and network key.
1. Select the access point (SSID).
2. Enter a network key, and select <Apply>.
• Wait until message <Connected.> is
displayed.
3. Select <Close>.
• The IP address will be automatically
configured in a few minutes.
5. Install the driver and software.
P.4 "Installing the software"
To connect via wired LAN
The machine does not come with a LAN cable.
Please have one ready, if necessary.
1. Make sure that the computer is connected to a
router properly.
2. Check the network settings on the computer.
3. Connect the LAN cable.
• After connecting the cable, wait a few
minutes (until the IP address is set
automatically).
• If a static IP address has been set on the
computer, set the machine's IP address
manually.
4. Install the driver and software.
P.4 "Installing the software"
Now you are finished with the
configuration of the initial settings.
Now you are finished with the
configuration of the initial settings.
3
Quick Setup

To connect via USB
• The machine does not come with a USB cable.
Please have one ready, if necessary.
• Make sure that the USB cable you
use has the following mark.
• Do not connect the USB cable before installing
the driver. If you did, disconnect the USB cable
from the computer, close the dialog box, and then
perform the following procedure from step 1.
1. Install the driver and software.
P.4 "Installing the software"
Now you are finished with the
configuration of the initial settings.
Installing the software
You can download the latest printer driver from
the Canon website (https://global.canon/en/
support/).
POINT
For details of software installation, see the driver's
manual. The manual can be downloaded from, or
viewed on, the same page of the Canon website
as for the software.
Latest OS support information
See the Canon website (https://global.
canon/en/support/).
For details
"Setting Up Using the Setup Guide" in the User's Guide
4
Conguring the Machine
Quick Setup

5
Quick
Operation

Remember before
You Start Operation
Place your original on the platen glass Place your originals into the feeder
Place the original
with the scan side
face down.
Place to fit
inside the
corner. Place the originals
with the scan side
face up.
Adjust
the slide
guides.
Suitable for scanning book
pages, magazine pages and
newspaper clips.
Suitable for continuously
scanning many pages of
literature, quotation, etc.
6
Place the Original Properly
Start the Operation from the Operation Panel
Machine
Quick Operation
Operation Panel
Display (screen)
([Energy Saver] key)
([Home] key)

Scanning
1. Place the original.
2. Press , and select <Scan>.
3. Select the type of scan, and enter the necessary information.
4. Select <Start>, <B&W Start> or <Color Start>.
Types of scan
■Store in computer
■Store in USB memory device
■Send e-mail/I-Fax
■Send to le server
To scan from a computer
■Use the scanner driver
supplied with the machine For details
"Scanning" in the User's Guide
Copying
1. Place the original.
2. Press , and then select <Copy>.
3. Specify the copy settings, as necessary.
4. Enter the desired number of copies.
5. Select <Start>.
Useful copy functions
■N on 1
■2-Sided or 1-Sided
■Enlarging or reducing
■Copying ID cards
For details
"Copying" in the User's Guide
Printing
1. Open the document to print, and select the print function of the
application.
2. Select the printer driver for the machine, and select [Preferences] or
[Properties].
3. Specify the paper size.
4. Specify the paper source and paper type.
5. Specify the print settings, as necessary.
6. Select [OK].
7. Select [Print] or [OK].
Useful print settings
■2-sided
■N on 1
■Booklet Printing
For details
"Help" on the printer driver
7
Quick Operation

In the following, the operations that are common
to paper drawers 1 and 2 are described by taking
drawer 2 as example.
1
2This operation is only applicable to Paper
Drawer 2.
Slide the light blue knobs to adjust the
positions of the paper guides.
Align the protrusion to the
appropriate paper size marking.
3First fan the paper stack well and then load
it.
Make sure that
this line is not
exceeded.
Paper
The print side face up
4Place the paper drawer back into the
machine.
CAUTION!
Be careful not to get your fingers caught
between the paper drawer and the
machine.
If you have changed the paper type, be
sure to change the paper settings.
5Press , and then select <Paper Settings>.
6Specify the size and type of paper, according
to the screen.
Loading in the Paper Drawer
For details
"Loading Paper" in the User's Guide
8
Loading Paper
Quick Operation

When paper is jammed, a screen, as shown below
appears.
Clear the paper jams, according to the on-screen
instructions.
Check the following.
• Is the power turned ON?
• Is the machine out of sleep mode?
If both the display and are not lit, press the
power switch.
• Is the power cord connected correctly ?
If the problem persists, see the User's Guide.
If a Problem Has Occurred
Replacing Consumables
Toner Cartridge
Canon genuine toner cartridge
• Canon NPG-67 Toner Black
• Canon NPG-67 Toner Cyan
• Canon NPG-67 Toner Magenta
• Canon NPG-67 Toner Yellow
• Canon NPG-67L Toner Cyan
• Canon NPG-67L Toner Magenta
• Canon NPG-67L Toner Yellow
For details
"Troubleshooting" in the User's Guide
9
The Machine Does Not Seem to
Work Paper Jams Have Occurred
Quick Operation

Black Streaks Appear in Images
Clean the document feed scanning areas.
1. Open the feeder, and clean the lower side
document feed scanning area using a cloth
dampened with water. Then, wipe the area
with a soft, dry cloth.
NOTE
Do not use glass cleaner or an alcohol
solution, etc., as they will strip away the stain-
proof coating.
2. Close the feeder.
If black streaks still appear after the
document feed scanning area has
been cleaned
Perform feeder cleaning.
1. Press , and then select <Menu>.
2. Select <Adjustment/Maintenance>
<Maintenance> <Clean Feeder>
<Start> on the screen.
NOTE
It takes approximately 20 seconds to clean
the feeder.
Irregularities Appear in Images/Images
Are Faint
Solution 1
The paper may have absorbed moisture.
Turn the Dehumidication switch on. If the
problem is still not resolved, load paper
that is not damp.
Solution 2
Perform gradation adjustment.
1. Press , and then select <Menu>.
2. Select <Adjustment/Maintenance> <Adjust
Image Quality> <Auto Adjust Gradation>
on the screen.
Follow the instructions on the screen to perform
gradation adjustment.
For more information, see the User's Guide.
For details
"Adjusting Gradation" in the User's Guide
Printing Results Are Not
Satisfactory
If a Problem Has Occurred
10
Quick Operation
