This extraordinary 60"printer incorporates the new 12-color pigment
system with LUCIA™ink plus the new L-COA controller and dual print
head system. Together, these technologies put the power to produce
vivid and breathtaking output right at your fingertips. Designed for
quality, reliability, and simplicity, the iPF9000 is the answer for any
professional looking to create high-quality prints.
The Canon imagePROGRAF iPF9000 takes large-format color produc-
tion to the next level. The 12-color pigment system with LUCIA inks
was designed to expand the spectrum of color for environments
from photography to design. The new L-COA controller intelligently
processes the data and directs the rapid printing process to the two
ultra high-density, high-quality, and high-speed print heads. The
included software suite makes the iPF9000 an innovative, out-of-
the-box printing solution that can be utilized by all types of digital
professionals. The imagePROGRAF iPF9000 printer is the result of
accumulated knowledge from Canon’s photography, imaging, and
printingtechnologies, all of which have been brought together to
provide the next generation of printers.
Large-Format Solutions
INTRODUCING THE 60" imagePROGRAF®iPF9000,
THE LATEST ADDITION TO CANON’S NEXT GENERATION
OF LARGE-FORMAT PRINTERS.
Canon delivers a remarkable 60" printer that fits the needs
of any professional printer looking to create captivating
images from capture to output.

AMAZING COLOR
The imagePROGRAF iPF9000 features a newly developed,
12-color pigment ink system designed to expand the color
reproduction range by providing an extremely wide color gamut
for vivid accurate colors and fine precise details. The expanded
color gamut produces brilliant colors to more accurately match a
broader spectrum of colors. The two levels of gray provide a
perfectly neutral monotone output that surpasses expectations.
Also, the utilization of automatic switching between regular
black and matte black eliminates the wasted ink and time spent
swapping out ink tanks. The combinations of these 12 inks
produce exquisite results.
EXCEPTIONAL SPEED AND PRODUCTIVITY
Engineered for speed and advanced image production, the
iPF9000 model boastsCanon’s new L-COA controller, a dual
print-head system with FINE technology, and a 40GB hard drive.
The L-COA print controller intelligently processes print data and
directs the two high-precision, high-density (30,720 nozzles)
print heads to lay down ink with extraordinary speed and
accuracy. It’s so smart, it’s simple. A single chip optimizes the
printer’s capabilities and accelerates processing while the dual
high-density one-inch print heads—each with 15,360 nozzles—
deliver smooth yet beautiful gradations on every print. The
onboard hard drive allows for print jobs to be saved for future
printing.
All that’s needed in one printer—
brilliant color, exceptional speed, and maximum productivity
NEVER-ENDING COLOR AND SIZE
Dual Print-Head System
LUCIA Pigment Inks
R
G
B
C
PC
M
PM
Y
BK
GY
PGY
MBK
BUNDLED SOFTWARE INCLUDED
Along with the printer's unique ability to print in unprece-
dented quality and speed is the software suite that makes
the iPF9000 an ideal solution for professionals. Stunning
quality prints can be created right out of the box, with soft-
ware that's just as innovative as the printer itself.
■Print Plug-in for Photoshop®–This application was
designed to enable direct printing of 16-bit RGB images
directly from Adobe Photoshop 6/7/CS/CS2.
■Digital PhotoPrint Pro – DPPP simplifies advanced
functions such as red-eye correction, dust removal, skin tone
improvement, and many other features.
■PosterArtist – PosterArtist helps users of all levels to cre-
ate professional-looking posters, banners, and signage with
extreme ease.
■Printer Driver 2006 –The imagePROGRAF printer driver
2006 works with both Windows®and Macintosh®operating
systems, offering exceptional, high-quality prints through
easy usability and accurate color. Features such as Nesting
and imageRUNNER®Scan-To-Print are included.

As an ENERGY STAR®Partner, Canon U.S.A., Inc. has determined that this product meets the ENERGY STAR
guidelines for energy efficiency. ENERGY STAR and the ENERGY STAR mark are registered U.S. marks.
Adobe, Photoshop, and Illustrator are registered trademarks of Adobe Systems Incorporated in the United
States and/or other countries. QuarkXPress is a trademark of Quark, Inc. and all applicable affiliated
companies, Reg. U.S. Pat. And Tm.Off. and in many other countries. Windows is a registered trademark of
Microsoft Corporation in the United States and/or other countries. Macintosh is a registered trademark of
Apple Computer, Inc. CANON, IMAGEPROGRAF, and IMAGERUNNER are registered trademarks and LUCIA is
atrademark of Canon Inc. in the United States and may also be registered trademarks or trademarks in
other countries. IMAGEANYWARE is a trademark of Canon. All referenced product names and other marks
are trademarks of their respective owners.
Specifications subject to change without notice.
Printer output images are simulated.
©2006 Canon U.S.A., Inc. All rights reserved.
1-800-OK-CANON
www.usa.canon.com
Canon U.S.A., Inc.
One Canon Plaza
Lake Success, NY 11042
Main Unit
Print Head (PF-02)
•Technology
-FINE Full-lithography
(Ink-jet Nozzle Engineering)
•Configuration
-6Colors per Print Head
-Dual Print Heads (Total 12 Colors)
-Print Head (L) Y/PC/C/PGY/GY/MBK
-Print Head (R) PM/M/BK/R/G/B
•Replacement
-End-User replaceable
Number of Nozzles
•2,560 Nozzles per Color
•30,720 Nozzles Total
Droplet Size
•4Picoliter
Nozzle Pitch (Head Resolution)
•1200 dpi x 2
Print Head Swath
•1.07"
Print Resolution (Max.)
•2400 x 1200 dpi
Ink Type
•LUCIA Ink (Pigment-Based)
Ink Tank (PFI-701 or PFI-301)
• Colors
- Cyan, Photo Cyan, Magenta, Photo
Magenta, Yellow, Black, Matte Black,
Red, Green, Blue, Gray, Photo Gray
Ink Tank Capacity*
•700ml (PFI-701) or 330ml (PFI-301)
Ink Supply Method
•Tubing System with Sub-Tanks for
Continuous Ink Supply
Nozzle Recovery System
•Non-FiringNozzle Detection and
Compensation
Printer Controller
•L-COA Controller
Printer Memory
•640MB
Print Speed/A0 size**
•Photo Glossy Paper ***
-5minutes
Built-in Hard Disk Capacity
•40GB
Media Feed
•Roll Feed
-One Roll, Front Output
•Cut Sheet
-One Sheet, Front 0utput
Media Width
-8" – 60" (Cut sheet)
-10" – 60" (Roll Feed)
Minimum Media Length
-8" (203mm)
Maximum Print Length
•Manual Feed
-63" (1.6 m)
•Roll
-59' (18 m)
†
Borderless Printing Width
(Roll Media Only)
•10", 14", 16", 24", 36", 42", B2
(20.28"/515mm), A1 (23.38"/594mm),
A0(33.11"/841mm), B0
(40.55"/1030mm)
MediaCutter
•User-Replaceable Durable Rotary Blade
(CT-06)
MediaThickness
•0.07 – 0.8mm (2.8 – 31.4mil)
Media Core Sizes
•2" (3" Core with Optional 3" Core Spool)
MediaOutput
•Automatically Winding Media Take-up
Reel (Standard), Basket (Optional)
Printable Margins
•Manual Feed (Top/Front)
-Leading and Left/Right Edges: 0.20"
(5mm), Trailing Edge: 0.90" (23mm)
•Roll Feed
-All Sides: 0.20" (5mm) or 0" for
Borderless
Maximum Media Roll Outer Diameter
-5.9" (150mm)
Minimum Printable Line Weight
-0.02mm
Line Accuracy
-+0.19%/-0.25%
Bundled Software
•Printing Software
- Printer Driver 2006, Print Plug-in for
Photoshop‡,Printer Driver Extra
Kit▲(Free Layout, imageRUNNER
Linking Function)
•Applications
-PosterArtist 2006▲▲
Digital Photo Print Pro▲▲
•Utilities
-GARO Status Monitor, Media
Configuration Tool, Remote UI
Printer Language
•GARO (Canon Proprietary)
OperatingSystem ■
•Windows
®
98SE/Me/2000/XP/2003
Server,Macintosh
®
OS 9.1/X 10.2/
10.3/10.4
Interface
•Standard
-USB 2.0 High Speed
-10/100Base-T/TX
•Optional
-IEEE1394 (FireWire)
Acoustic Noise
•Operation
-52dB or Less
•Standby
-35dB or Less
•Acoustic Power (Operation and Standby)
-6.7 Bels or Less
Power Supply
•AC 100-240V (50-60Hz)
Power Consumption
•Maximum
-190W or Less
•Standby
-5W or Less
(8W or Less when EB-05 is Installed)
•Power Off (Standby)
-Less than 1W
(Compliant with Executive Order)
Certifications
•UL, FCC Class B, ENERGY STAR
®
Operational Environment
•Temperature
- 59 – 86 F° (15 – 30 C°)
•Relative Humidity
-10 – 80% (No Condensation)
Dimensions with Stand ( W x D x H )
•90.5" x 31.6" x 45.1"
(2299mm x 766mm x 1144mm)
Weight with Stand and Take-up Reel
•Approx. 365 lb. (165kg)
Package Dimensions ( W x D x H )
•97.7" x 41.4" x 48.8"
(2480mm x 1050mm x 1238mm)
PackageWeight (Including Pallet)
•552 lb. (250kg)
User Replaceable Items
•Ink Tank PFI-301/PFI-701
•Print Head (PF-02)
•Maintenance Cartridge(MC-08)
•Durable Rotary Blade (CT-06)
Options
•IEEE1394 Expansion Board (EB-05)
•Media Catch Basket (BU-01)
•2" Core Roll Holder (RH2-63)
•3" Core Roll Holder (RH3-63)
•EFI Colorproof XF for Canon
Media Types
Signage Media
Durable Banner (Polypropylene),
Banner Vinyl (Scrim), Tyvek Banner,
Removable Banner Vinyl, Adhesive
Matte Vinyl, Durable Backlit Film,
Back Print Back Lit Film
Photo Paper
Premium Super-Gloss, Glossy
Photographic Paper, Satin Photographic
Paper, Heavyweight Glossy
Photographic Paper, Heavyweight Satin
Photographic Paper, Premium Bright
Photo Glossy Paper, Premium Bright
Photo Satin Paper, Premium RC
Photogloss, Premium RC Photomatte,
Premium RC Luster
Proofing Paper
Commercial Proofing Paper, Premium
Proofing Paper
Matte Paper
Universal Bond Paper, Matte Coated
Paper, Heavyweight Coated Paper,
Heavyweight Matte Coated Paper,
Premium Matte Paper
Fine Art Paper
Fine Art Photo Rag, Fine Art German
Etching, Fine Art Enhanced Velvet, Fine
Art Watercolor Paper, Fine Art Smooth
Rag, Fine Art Smooth Rag Heavyweight,
Fine Art Smooth Natural Rag, Fine Art
Textured Rag, Fine Art Water Resistant
Canvas, Graphic Matte Canvas, Canvas
Semi-Glossy
