Canon LBP-2460 Instruction Manual

LOCATION
SUBJECT
MODEL : NO. :
DATE:
SERVICE INFORMATION
Issued by Peripheral Products Technical Documentation Dept . , Canon Inc.
RY8-31AM-01Y
RAD-12E-0002
December 20, 1997
Printed in Japan
Imprimé au Japon
Because of the many changes and corrections, the LBP-2460 Parts Catalog has been completely
revised
Please discard the old Parts Catalog.
Revision of the Parts Catalog for LBP-2460

FIG-
URE PAGE REVISION FIG-
URE PAGE REVISION
REVISION PAGE LIST
R : Replacement,
S : Supplement,
D : Destroyed,
Model : LBP-2460
Page 1
A
100
101
102
103
104
141
151
i
ii
iii
iv
v
vi
vii
viii
1
2
1
2
1
2
1
2
1
2
1
2
1
1
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
1R
1R
1R
1R
1R
1R
1R
152
152A
153
250
300
301
310
320
330
1
2
1
2
1
1
2
1
2
3
1
2
3
1
2
3
4
5
6
1
2
1
2
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
1R
1R
1R
1R
1R
1R
1R
1R
1R
Apr.
1997 Dec. 1997 Apr. 1997 Dec. 1997

FIG-
URE PAGE REVISION FIG-
URE PAGE REVISION
REVISION PAGE LIST
R : Replacement,
S : Supplement,
D : Destroyed,
Model : LBP-2460
Page 2
340
341
350
351
810
900
D
D10
D90
F
1
2
3
1
2
1
2
1
2
1
2
3
4
1
i
1
2
3
4
1
i
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
FA
F10
F11
F90
R
RA
R10
R15
R20
1
1
2
1
2
3
4
1
i
1
1
2
3
4
1
2
3
4
1
2
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
1R
1R
1R
1R
1R
1R
1R
1R
Dec.
1997
Apr.
1997
Dec.
1997
Apr.
1997

FIG-
URE PAGE REVISION FIG-
URE PAGE REVISION
REVISION PAGE LIST
R : Replacement,
S : Supplement,
D : Destroyed,
Model : LBP-2460
Page 3
R40
R50
R90
V
V10
V90
W
W10
B
1
2
3
1
2
3
1
i
1
1
i
1
1
2
3
4
5
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
1R
1R
1R
1R
1R
1R
1R
1R
1R
1R
Dec.
1997
Apr.
1997

COPYRIGHT
C
1997 CANON INC. CANON LBP-2460 REV.0 APR. 1997 PRINTED IN JAPAN [IMPRIME AU JAPON]
PARTS
CATALOG
REVISION 1
DEC. 1997 RY8-31AM-010

COPYRIGHT
C
1997 CANON INC. CANON LBP-2460 REV.0 APR. 1997 PRINTED IN JAPAN [IMPRIME AU JAPON]
ii
PREFACE
This Parts Catalog contains listings of parts used in the LBP-2460, the duplex unit,
the envelope feeder, the paper deck, the option controller, and the hard disk.
Diagrams are provided with the listings to aid the service technician in clearly
identifying the item to be orderd.
Whenever ordering parts, consult this Parts Catalog for all of the information per-
taining to each item. Be sure to include in the Parts Request the full item
description, the item part number, and the quantity. The parts catalog may be
revised if there is significant product modification. For minor product
Canon Inc.
Peripheral Products Quality Advancement Div.
Peripheral Products Technical Documentation Dept
5-1, Hakusan 7-chome, Toride-shi, Ibaraki 302, Japan
COPYRIGHT C 1997 CANON INC.
Printed in Japan
Imprime´ au Japon
Use of this manual should be
strictly supervised to avoid dis-
closure of confidential infor-
mation.

COPYRIGHT
C
1997 CANON INC. CANON LBP-2460 REV.0 APR. 1997 PRINTED IN JAPAN [IMPRIME AU JAPON]
iii
NAME REMARKS ORDER No. SERIAL No.
LIST OF ORDER AND SERIAL NUMBERS
LBP-2460 100-120V 50/60Hz 600DPI R76-0094 JHT00001-
220-240V 50Hz 600DPI R76-0098 KJM00001-
CASSETTE R77-0013
R77-0014
DUPLEX UNIT R77-1001 LFA00001-
ENVELOPE FEEDER R77-1008 LDP00001-
PAPER DECK R77-1032 LFK00001-
OPTION CONTROLLER R77-1027
HARD DISK R03-0170

COPYRIGHT
C
1997 CANON INC. CANON LBP-2460 REV.0 APR. 1997 PRINTED IN JAPAN [IMPRIME AU JAPON]
iv

COPYRIGHT
C
1997 CANON INC. CANON LBP-2460 REV.0 APR. 1997 PRINTED IN JAPAN [IMPRIME AU JAPON]
v
CONTENTS
RA.
R10.
R15.
R20.
R40.
R50.
R90.
V10.
V90.
W10.
B.
A.
100.
101.
102.
103.
104.
141.
151.
152.
152A.
153.
250.
300.
301.
310.
320.
330.
340.
341.
350.
351.
810.
900.
D10.
D90.
FA.
F10.
F11.
F90.
—PAPER DECK—
ASSEMBLY LOCATION DIAGRAM
PAPER DECK MAIN BODY
PAPER DECK ASS'Y
PAPER DECK DRIVE ASS'Y
PAPER PICK-UP ASS'Y
FEED ASS'Y
PCB ASS'Y LOCATION DIAGRAM
—OPTION CONTROLLER—
OPTION CONTROLLER ASS'Y
PCB ASS'Y LOCATION DIAGRAM
—HARD DISK—
HARD DISK ASS'Y
NUMERICAL INDEX
ASSEMBLY LOCATION DIAGRAM
EXTERNAL COVERS, PANELS, ETC.
INTERNAL COMPONENTS 1
INTERNAL COMPONENTS 2
INTERNAL COMPONENTS 3
INTERNAL COMPONENTS 4
FACE-UP SOLENOID ASS'Y
HIGH VOLTAGE POWER SUPPLY ASS'Y
VIDEO CONTROLLER ASS'Y (100-120V)
VIDEO CONTROLLER ASS'Y (220-240V)
VIDEO CONTROLLER PCB ASS'Y (100-120V)
PRINTER DRIVE ASS'Y
CASSETTE (LOWER)
CASSETTE (UPPER)
PAPER PICK-UP ASS'Y
REGISTRATION ROLLER ASS'Y
FEEDER ASS'Y
MULTI-PURPOSE TRAY PICK-UP ASS'Y
MULTI-PURPOSE TRAY ASS'Y
DELIVERY ASS'Y
DELIVERY FRAME ASS'Y
FIXING ASS'Y
PCB ASS'Y LOCATION DIAGRAM
—DUPLEX UNIT—
DUPLEX UNIT MAIN BODY
PCB ASS'Y LOCATION DIAGRAM
—ENVELOPE FEEDER—
ASSEMBLY LOCATION DIAGRAM
EXTERNAL COVERS, PANELS, ETC.
INTERNAL COMPONENTS
PCB ASS'Y LOCATION DIAGRAM

COPYRIGHT
C
1997 CANON INC. CANON LBP-2460 REV.0 APR. 1997 PRINTED IN JAPAN [IMPRIME AU JAPON]
vi

COPYRIGHT
C
1997 CANON INC. CANON LBP-2460 REV.0 APR. 1997 PRINTED IN JAPAN [IMPRIME AU JAPON]
vii

COPYRIGHT
C
1997 CANON INC. CANON LBP-2460 REV.0 APR. 1997 PRINTED IN JAPAN [IMPRIME AU JAPON]
Assembly Location Diagrams. These diagrams show
the locations of major assemblies of the machine. Their
names are identified in rectangular boxes. Below each box
is the number of the Figure which shows an exploded view
of the assembly.
Finding a Parts Number. Refer to the Assembly
Location Diagrams and find the Figure Number of the
assembly of interest. Turn to the page(s), locate the part on
the exploded view, and find its Key Number. Refer to the
Parts List on the page facing the exploded view and find
the Key Number, Part Number and quantity required for
your type of machine.
Note : While looking for a Part Number, pay particular
attention to the voltage listed in the SERIAL
NUMBER/REMARKS columm to ensure that the
Part Number selected is for your type of machine.
Immediate shipping or action regarding the part
depends on using its correct Part Number.
Parts List pages. The Parts List pages contain the
following columns and information.
(1) Figure and Key Number column. The first column
shows the Figure Number of the illustration corresponding
to the Parts List, and the Key Number that identifies the part
on the illustration.
(2) Part Number. The second column shows the Part
Number for the part. This Number must be used when
ordering replacement parts or assemblies described in the
description column do not have a Part Number and are not
stocked.
(3) Rank N. Parts marked"N"are service parts, but are
not stock items. They are produced on a special-order basis.
(4) Quantity column. The quantity shown in this
column is the number of parts used in the Figure. However,
the quantity listed for an assembly indicates the number of
that assembly per machine. The letters in this column
indicate that the quantity of a parts is not specified, allowing
the use of the number of parts needed for assembly and that
the quantity cannot be mentioned clearly.
(5) Description column. The Description column lists
the description that should be used when ordering the part.
(6) Serial Number/Remarks. When there are differ-
ences in the specifications of power suppply voltage,
frequency, etc., the differences are described in words or
indicated by one two or three letters in front of the serial
number.
(Example)
Serial number ABC00001
This is the descriptive
indicator.
If a model modified and a part is no longer interchangeable,
the serial number of machines for which the part can be
used is shown in this column. If there is no indication the
part can be used with all models.
Numerical Index. There is a Numerical Index at the
end of this catalog; it lists in numerical order every Part
Number contained in the Parts Lists. The Numerical Index
contains the following columns and information.
(1) Part Number. The first column shows the Part
Number.
(2) Figure and Key Number column. The second
column lists the Figure and Key Number for each
occurrence of the part in the illustrations.
Note : The last three digits (suffix) of the Parts Number
are called the Revision Number. The Revision
Number is changed if the part is modified.
Information regarding such changes will be pro-
vided by Service Information Bulletins. These
Bulletins should be read carefully.
HOW TO USE PARTS LISTS
viii

A-1
COPYRIGHT
C
1997 CANON INC. CANON LBP-2460 REV.0 APR. 1997 PRINTED IN JAPAN [IMPRIME AU JAPON]
FIGURE A
ASSEMBLY LOCATION DIAGRAM(1/2)
DELIVERY ASS'Y
FIXING ASS'Y
FEEDER ASS'Y
REGISTRATION ROLLER ASS'Y
MULTI-PURPOSE TRAY PICK-UP ASS'Y
MULTI-PURPOSE TRAY ASS'Y
PAPER PICK-UP ASS'Y
310
341
320
340
330
350
810

A-2
COPYRIGHT
C
1997 CANON INC. CANON LBP-2460 REV.0 APR. 1997 PRINTED IN JAPAN [IMPRIME AU JAPON]
FIGURE A
ASSEMBLY LOCATION DIAGRAM(2/2)
Å
CASSETTE (LOWER)
300
CASSETTE (UPPER)
301
DELIVERY FRAME ASS'Y
351
FACE-UP SOLENOID ASS'Y
141
VIDEO CONTROLLER ASS'Y
152 153152A
HIGH VOLTAGE POWER SUPPLY ASS'Y
151
PRINTER DRIVE ASS'Y
250

100-1
COPYRIGHT
C
1997 CANON INC. CANON LBP-2460 REV.0 APR. 1997 PRINTED IN JAPAN [IMPRIME AU JAPON]
FIGURE 100
EXTERNAL COVERS, PANELS, ETC.
13
18
5A
15
23
5B
5C
20
24
19
22
23
7K
11 SEE FIGURE 351
7K
7E
16
6C
6E
6A
6B
6D
12 23
7B
7D
23
7F
23
7G
7C
7H 7J
1423
10
9A
21
7A
25 17
501
17B
17A
5
6
34
12
2
9
8
7

100-2
COPYRIGHT
C
1997 CANON INC. CANON LBP-2460 REV.1 DEC. 1997 PRINTED IN JAPAN [IMPRIME AU JAPON]
SERIAL NUMBER / REMARKSDESCRIPTION
T
Y
Q'
R
A
N
K
PART NUMBER
FIGURE
&
KEY NO.
100 - NPN RF EXTERNAL COVERS, PANELS, ETC.
1 RB1-6967-000 1 COVER, DELIVERY
2 RF5-2701-000 2 HINGE, STOPPER
3 RB1-6507-000 1 PLATE, HINGE
4 XA9-0267-000 6 SCREW, TP, M3X6
5 RF5-1748-000 1 UPPER COVER ASS'Y
5A RB1-6936-000 1 PLATE, GROUNDING
5B RB1-6985-000 1 COVER, ELCTRICAL
5C XB4-7400-807 1 SCREW,TAPPING,TRUSS HEAD,M4X8
6 RG5-2412-000 1 OPEN/CLOSE COVER, ASS'Y
6A RB1-6983-000 1 STOPPER, DELIVERY
6B RB1-6984-000 1 TRAY, DELIVERY
6C RB1-6935-000 1 TRAY, DELIVERY, SUB
6D RB1-6938-000 1 COVER, CRG
6E XB4-7400-809 4 SCREW,TAPPING,TRUSS HEAD,M4X8
7 RG5-2413-000 1 COVER ASS'Y
7A RB1-6973-000 1 COVER, RIGHT
7B RB1-6974-000 1 COVER, OPEN/CLOSE, RIGHT
7C RB1-6975-000 1 GUIDE, COVER
7D RB1-6484-000 1 STOPPER, OPEN/CLOSE
7E RB1-6976-000 1 LEVER
7F RB1-6486-000 1 SPRING, COMPRESSION
7G RB1-6487-000 1 PLATE, GUIDE
7H RB1-6488-000 2 ROLLER
7J RS5-2494-000 1 SPRING, TENSION
7K XB4-7400-807 4 SCREW,TAPPING,TRUSS HEAD,M4X8
8 RB1-7079-000 1 COVER, FRONT
9 RF5-1438-000 1 COVER, FRONT, SUB
9A RS5-8677-000 1 LABEL, JAM REMOVAL
10 XZ9-0379-000 1 LATCH
11 RB1-6972-000 1 COVER, LEFT
12 RB1-6977-000 1 COVER, ELECTRICAL
13 RB1-6978-000 1 TRAY, FACE-DOWN
14 RB1-6980-000 1 COVER, SWITCH
15 RB1-6493-000 1 SPRING, COMPRESSION
16 RB1-6981-000 1 COVER, RIGHT, LOWER
17 RF5-1749-000 1 COVER, REAR
17A RB1-6939-000 1 GUIDE, COVER
17B XA9-0437-000 5 NUT, PUSH
18 RB1-6509-000 1 SPRING, TORSION
19 RG5-3683-000 1 PANEL, FRONT
20 RS5-8676-000 1 LABEL, JAM REMOVAL
21 XA9-0605-000 6 SCREW, M4X8
22 RB1-6940-000 1 TRAY, FACE-UP
23 XA9-0872-000 11 SCREW, W/WASHER, M3X8
24 RB1-7000-000 1 PLATE, GUARD
25 XA9-0872-000 1 SCREW, W/WASHER, M3X8
501 XB4-7400-809 3 SCREW,TAPPING,TRUSS HEAD,M4X8

101-1
COPYRIGHT
C
1997 CANON INC. CANON LBP-2460 REV.0 APR. 1997 PRINTED IN JAPAN [IMPRIME AU JAPON]
FIGURE 101
INTERNAL COMPONENTS 1
(MT1)
(J12)
(J218)
1
2
4
4
5
11
11
6
7
7
8
9
10 501
11
3
11
12
13
14 18
19
15
16
16
11
17
16
16
1A
1A
1B
1C
16
SEE FIGURE 330
SEE FIGURE 320
SEE FIGURE 340
SEE FIGURE 250
SEE FIGURE 141
SEE FIGURE 810
SEE FIGURE 350
SEE FIGURE 310
SEE FIGURE 341
11
