Canon PIXMA G6000 Series User manual

Démarrage
Commencez par lire Sécurité et informations
importantes (addendum).
Configuration en ligne
Des instructions détaillées et des vidéos
sont disponibles sur le site Web de Canon.
Configurer un ordinateur
Configurer un smartphone
Getting Started
Read Safety and Important Information
(addendum) first.
Online Setup
Detailed instructions and videos are
available on the Canon website.
Setup a Computer
Setup a Smartphone

Go
Accéder
Installation de l'imprimante..................................................................................................page 1
Connexion à un ordinateur, un smartphone ou une tablette.........................page 4
Instructions vidéo
Manipulation de l'imprimante
Installing the Printer...................................................................................................................page 1
Connecting to a Computer, Smartphone or Tablet...............................................page 4
Holding the Printer
Instructional Videos

1
ENGLISH
Setting Up the Printer Online Setup
1. Box Contents
•
Print heads • Ink bottles
•
Power cord
•
Setup CD-ROM
•
Safety and Important Information
•
Getting Started (this manual)
2. Removing Packing Materials
1 Remove and dispose of any packing materials
and orange tape.
2 Open the scanning unit / cover, remove and
dispose of the orange tape and protective
material inside.
a
b
3. Installing the Print Heads
1 Open the print head locking cover.
2 Take out each print head from the package and
remove the label.
3 Remove the protective tape.
4 Insert the C (color) print head on the left and the
B (black) print head on the right.
5 Close the print head locking cover and press
down until it clicks.
6 Press down both joint buttons completely until
they click.
Check!

2
Setting Up the Printer
4. Pouring Ink
Important
This product requires careful handling of ink. Ink may splatter
when the ink tanks are filled with ink. If ink gets on your clothes or
belongings, it may not come off.
1 Open the ink tank cover and tank cap on the left
of the printer.
2 Hold the ink bottle upright and gently twist the
bottle cap to remove.
Check!
PGBK
3 Align the nozzle of the ink bottle with the inlet.
4 Slowly stand the ink bottle upside down and
push down to pour the ink.
• If the ink does not pour, gently remove the ink bottle
and try again.
b
a
5 Gently remove the ink bottle from the inlet.
• Be careful not to spill the ink.
b
a
6 Replace the tank cap securely, and then close
the ink tank cover.
7 Repeat steps 1 through 6 to pour all ink into the
corresponding ink tanks on the right according
to the label.
Check!
CMY
8 Close the scanning unit / cover.
5. Turning on the Printer
1 Connect the power cord.
Back
Important
At this time, do not connect any other cables.
2 Open the operation panel and press the ON
button.

3
ENGLISH
3 When the following screen appears, use the [
and ]buttons to select a language, and then
press the OK button.
Important
If an error appears on the screen, see "If an error message
(support code) appears on the screen" on page 3 and
follow the instruction.
6. Loading Paper
1 When the following screen appears, use the [
and ]buttons to select Yes , and then press the
OK button.
2 Remove the cassette from the printer.
3 Slide apart the paper guides.
• Slide the right paper guide to the right edge. Align
the front paper guide with the Letter or A4 mark.
4 Load paper.
• Load 2 or more sheets of Letter or A4 sized plain
paper with the print side facing down.
• Place the paper against the front paper guide, and
align the right paper guide to the width of the paper.
ab
5 Replace the cassette.
6 Pull out the paper output tray.
7 Follow the on-screen instructions, and then
press the OK button.
• Check that Ready to connect appears on the
printer's screen.
Check the support code, and then follow the
instruction if the displayed code is written below.
• 1890
The protective materials are not removed.
"2. Removing Packing Materials" on page 1
• 1470
The print heads are not installed correctly.
"3. Installing the Print Heads" on page 1
• 1471
No print heads are installed.
"3. Installing the Print Heads" on page 1
• 1642
There may be insufficient ink.
"4. Pouring Ink" on page 2
For all other cases, refer to the Online Manual.
If an error message (support code) appears on
the screen
Support code

7-b
page 6
7-a
4
Setting Up the Printer
Press the Stop button,
and then select Do not
connect > Yes, in this
order.
Computer Computer and
smartphone
Smartphone
No device
Connecting to a Computer
If you are using multiple computers, perform these steps on each computer. There are
two methods, " Online Setup" and " Using the Setup CD-ROM (Windows Only)
Provided".
1 Access the Canon website from a
computer.
2 Select Set Up.
3 Enter your printer's model name and click
Go.
4 Click Start.
5 Click If you have already prepared your
printer, go to Connect.
Note
The following steps are for Windows (except Windows
10 in S mode) and macOS users. For other operating
systems, continue setup by following the on-screen
instructions instead.
6 Click Download.
• The setup file is downloaded to your
computer.
7 Run the downloaded file.
8 Proceed to step 9 on page 5.
Online Setup
What device are you connecting?
Select a device and follow the instructions in the relevant section.

5
ENGLISH
1 Insert the Setup CD-ROM
into your computer.
2 Follow the instructions for your version of
Windows.
Windows 10/Windows 8.1
aClick on the following message when it
appears on the right-hand side of your
computer screen.
Note
If the message does not appear (or is no longer
visible), click the File Explorer icon in the
taskbar. On the left-hand side of the window, click
This PC. Double click the CD icon that is
displayed on the right-hand side. When the
content of the CD is displayed, double click
Msetup4.exe. Proceed to c.
bClick Run
Msetup4.exe.
cIf the User Account Control dialog box
appears, click Yes .
Windows 7
aClick Run Msetup4.exe.
• When the AutoPlay screen appears, click
Run Msetup4.exe.
Note
If the AutoPlay screen does not appear, in the
Start menu, click Computer. On the right-hand
side of the window, double click the CD icon.
When the content of the CD is displayed, double
click Msetup4.exe.
bIf the User Account Control dialog box
appears, click Continue.
3 Proceed to step 9 below.
Using the Setup CD-ROM (Windows Only) Provided
9 Click Start Setup.
10 Follow the on-screen instructions.
• These operations may take some time.
11 When the following screen appears, click
Exit.
Your printer is now connected to your computer.
To connect to a smartphone as well, see "7-b.
Connecting to a Smartphone" on page 6.

7-b
6
Setting Up the Printer
1 Install the "Canon PRINT Inkjet/SELPHY" app on your smartphone.
• Scan the QR code shown on the right to access the Canon website, and then download
the app.
2 Check the printer's screen and proceed to each step.
If the following screen is displayed,
Ready to connect
For details on how to continue, refer to
"Getting Started"
If the following screen is displayed
Press the COPY button and check the screen that
appears.
• If or is displayed,
• If or is not displayed,
Note
• The printer's screen turns off when the printer is idle for 10 minutes. Press any button (except the ON button) on the operation
panel to turn on the screen.
• If appears, the printer cannot communicate by Wi-Fi connection. For details, refer to "Frequently Asked Questions" at
"https://ij.start.canon".
Connecting to a Smartphone
If you are using multiple smartphones, perform these steps on each smartphone.
Prepare the following before starting.
aEnable the Wi-Fi setting on your smartphone.
bConnect your smartphone to the wireless router (if you have a wireless router).
Refer to your smartphone and wireless router manuals for more details.
3 Open the installed app. 4 Follow the on-screen instructions to add
your printer.
Once you have added your printer, you can
print from the smartphone. To print photos, see
"Loading Photo Paper" on page 8.

7
ENGLISH
3 Tap Settings on your smartphone's home
screen, and tap Canon_ij_XXXX in the
Wi-Fi settings.
Note
If Canon_ij_XXXX does not appear, follow the
procedure in , and then search for Canon_ij_XXXX
again.
4 Open the installed app, and then
follow the on-screen instructions
to add your printer.
• The printer is added with the most
appropriate connection method for
the environment you are using.
3 Open the installed app, and then
follow the on-screen instructions
to add your printer.
• The printer is added with the most
appropriate connection method for
the environment you are using.
Note
If a message saying "No printer has been added.
Perform printer setup?" does not appear after
starting the application, follow the procedure in ,
and then return to smartphone operations.
Procedures vary for iOS and Android. Follow the instructions for your operating system.
3 Press and hold the Wireless connect
button for about 3 seconds. 4 When Follow the instructions on the PC or smartphone, etc. appears on the
printer's screen, proceed to .
Once you have added your printer, you can print from the smartphone. To print photos, see "Loading Photo
Paper" on page 8.

8
Loading Photo Paper
1 Open the rear tray cover and extend the paper
support.
2 Open the feed slot cover and slide the right-
hand side paper guide to the far right.
ab
3 Load several sheets of photo paper with the
print side facing up and slide the side paper
guide against the edge of the paper stack.
a
b
4 Close the feed slot cover.
5 When Save the rear tray paper information
appears on the printer's screen, press the OK
button.
6 Select the paper size and type, and press the OK
button.
Transporting Your Printer
Photo paper can only be loaded in the rear tray.
When relocating the printer, make sure of the following. Refer to the Online Manual for details.
Check that both joint buttons are pressed down
completely to avoid ink leaks.
Check that the position of the ink valve lever is closed.
Pack the printer in a plastic bag in case ink leaks.
• Pack the printer in a sturdy box so that it is placed with its
bottom facing down, using sufficient protective material
to ensure safe transport.
• Do not tilt the printer. Ink may leak.
• Please handle with care and ensure the box remains flat
and NOT turned upside down or on its side, as the printer
may be damaged and ink in the printer may leak.
• When a shipping agent is handling transport of the
printer, have its box marked "THIS SIDE UP" to keep the
printer with its bottom facing down. Mark also with
"FRAGILE" or "HANDLE WITH CARE".
