Canon PIXMA MP470 User manual

Canon
Photo AII-in-One
PI}{MA MP470 series
Quick Start Guide
..... t(
Exit Ptint PictBridge
1JA
,.f_
,;:=
-
F
,
...
\;
<
1111111111111111111111111111111111111111
QT51007VOI

Getting Help from Canon
Help Us Help You Better
Before you contact Canon, please record the following information.
Serial Number (located on the inside of the product): _
Model Number (located above the LCD): _
Setup CD-ROM number (located on the CD-ROM): _
Purchase Date: _
Customer Technical Support Sequence*
1.lnternet -www.canontechsupport.com
For quick and comprehensive self-help in an intuitively guided interactive troubleshooting
environment, the place to start is our helpful tech support web site. In addition, the latest
driver downloads, answers to frequently asked questions, product information, and "where to
buy" instructions are found here.
2. Email Tech Support -www.canontechsupport.com
For individual attention to aspecial issue, try emailing our friendly technical support
representatives, specially trained to communicate quick, easy, and logical solutions to your
inquiries within 24 hours.
3. Toll-Free Live Tech Support -(1-800-828-4040)
This option provides live telephone technical support, free of service charges, Monday-
Saturday (excluding holidays), during your product's 1year limited warranty period.
Telephone Device for the Deaf (TOO) support is available at (1-866-251-3752).
4. Extended Service and Support -www.canonesp.com
Canon CarePAK Extended Service Plan is acost-attractive and easy-to-use extended
service program that provides up to three full years of service and support coverage at avery
attractive price. CarePAK offers toll-free Canon technical support and includes Canon's
superb InstantExchange product replacement program. For further information about
extending your Canon service and support, call (1-800-385-2155), or visit our Web site at
www.canonesp.com. CarePAK must be purchased during your product's warranty period.
For more information and updated program specifics, please visit our web site at
www.canontechsupport.com.
•Support program specifics are subject to change without notice.

Canon
PI){MA MP470 series
Photo AII-in-One
Quick Start Guide

Canon PIXMA MP470 series Photo AII-in-One Quick Start Guide.
Copyright
This manual is copyrighted by Canon U.S.A., Inc. with
all rights reserved. Under the copyright laws,
this manual may not be reproduced
in any form, in whole or in part, without the prior written consent
of Canon U.S.A., Inc.
©2007 Canon U.S.A., Inc.
Disclaimer
Canon U.S.A., Inc. has reviewed this manual thoroughly
in order that it will be an easy-to-use guide
to your Canon PIXMA MP470 series Photo AII-in-One. All statements, technical information and
recommendations
in this manual and in any guides or related documents are believed reliable, but
the accuracy and completeness thereof are not guaranteed or warranted, and they are not intended
to be, nor should they
be understood to be, representation or warranties concerning the products
described.
Depending on your application program, operations may differ. For details, refer to the instruction
manual of your application. The steps described
in this manual are in Windows Vista™ operating
system Ultimate Edition (hereafter referred to
as "Windows Vista") and Mac® OS X v.1 OA.x.
As an ENERGY STAR® Partner, Canon Inc. has determined that this product meets the ENERGY
STAR® guidelines for energy efficiency.
All information regarding non-Canon products was compiled from publicly available information. No
representation is made regarding the accuracy thereof.
About Consumables
Consumables (ink tanks /FINE Cartridges) are available for 5years after production has stopped.
Trademarks
•"MiCrosoft" is aregistered trademark
of Microsoft Corporation.
•"Windows" is atrademark
of Microsoft Corporation, registered in the U.S. and other countries.
•"Windows Vista" is atrademark
of Microsoft Corporation.
•"Macintosh" and "Mac" are trademarks of Apple Inc., registered
in the U.S. and other countries.
•"MEMORY STICK", "Memory Stick PRO", "MEMORY STICK Duo" and "Memory Stick PRO Duo"
are trademarks of Sony Corporation.
•"xD-Picture Card" is atrademark of Fuji Film Co. Ltd.
•"MultiMediaCard"
is atrademark of the MultiMediaCard Association.
•"SD Card", "miniSD Card", and "microSD Card" are trademarks
of SD Association.
•"Bluetooth" is atrademark
of Bluetooth SIG, Inc.,U.S.A. and licensed to Canon Inc.
Canon U.S.A., Inc.
One Canon Plaza
Lake Success, NY 11042

. .. 71
66
.. 67
Table of Contents
Before Using the Machine 2
Operation Panel 2
How to Navigate Menus
on the LCD .4
Turning the Machine On and
Off 8
Handling the Original Document. 9
Loading Printing Paper.. .12
Copying 20
Making Copies. .20
Setting Items.. .
.. 20
Using Useful Copy Functions 22
Printing from a Memory Card 23
Memory Cards Supported by This Machine. 23
Printable Image Data 24
Inserting the Memory
Card. ..24
Removing the Memory Card.. .
.. 25
Printing Photographs (Display photo) 25
Setting Items.. .26
Using Useful Printing Functions 27
Printing by Using the Photo Index Sheet.. 28
Printing from Your Computer 29
Printing with Windows.. .29
Printing with Macintosh
30
Scanning Images 31
Scanning Methods 31
Printing Photographs Directly from
a Compliant Device 32
Printing Photographs Directly from
aCompliant Device
32
About PictBridge Print Settings 34
Routine Maintenance 38
When Printing Becomes Faint or Colors
Are Incorrect.... .
38
Printing the Nozzle Check Pattern 39
Examining the Nozzle Check Pattern .40
Print Head Cleaning .42
Print Head Deep Cleaning 43
Aligning the Print Head 44
Replacing aFINE Cartridge. .
46
Keeping the Best Printing Results. . 51
Cleaning Your Machine 52
Troubleshooting 56
An Error Message Is Displayed on the LCD. 57
LCD Cannot Be Seen At All 58
An Unintended Language
Is Displayed
on the LCD.. .58
Cannot Install the MP Drivers 59
Cannot Connect to Computer Properly.. .
.. 60
Print Results Not Satisfactory
61
The Print Result Not Satisfactory When
Copying. ..65
Printing Does Not Start.. ..65
Paper Does Not Feed Properly
Paper Jams .
Error Message Appears on the Computer
Screen 68
Error Message Appears on aPictBridge
Compliant Device 70
Cannot Print Properly via Bluetooth
Communication... . .
Cannot Print Properly from aPhoto Index
Sheet ..71
Cannot Remove aMemory Card
71
Scanning Problems 72
The Document Cover Comes
Off.. . .. 72
Appendix 73
How to Use the Documentation Provided 73
Reading the On-screen Manuals 74
Specifications. .75
Safety Precautions 78
Legal Limitations on Use of Your Product
and Use
of Images 81
Users in the U.S.A. ... .82
Index 86
1

Before Using the Machine
Operation Panel
(1 )
(14)
(13) -t--='-/
(12)
(11) -t--=-~I
(10)
(9)
(8) (7) (6)
(2)
(3)
(4)
(5)
2
(1) ON/OFF button
Turns the machine on and off. Before turning on the machine, make sure the Document
Cover is closed.
(2) MEMORY CARD button
Switches the machine to the memory card mode.
(3) Settings button
Used to configure the page size, media type, and image correction settings.
(4) OK button
Finalizes your selection for the menu or setting item.
Dismisses the error message and resumes the machine's normal operation after
resolving aprinting error or removing jammed paper.
(5) Stop/Reset button
Cancels aprint job in progress.
(6) Alarm lamp
Lights or flashes orange when an error, such as paper-out or ink-out, occurs.
(7) Power lamp
Lights or flashes green to indicate the power status.
(8) Color button
Starts color copying, photo printing, or scanning.
(9) Black button
Starts black &white copying or scanning.
(10) Back button
Returns the LCD to the previous screen.
Before Using the Machine

(11) and. buttons
Scroll through menu selections, and increases/decreases setting values, such as the
number of copies.
(12) Menu button
Displays menus.
(13) SCAN button
Switches the machine to the scan mode. Used when the machine
is connected to your
computer. For details, refer
to the Scanning Guide on-screen manual.
(14)
COpy button
Switches the machine
to the copy mode.
Before Using the Machine 3

How to Navigate Menus on the LCD
You can make good use of the various functions of the machine with the menu screen and the
settings screen on the LCD.
This section describes how to use the menu screen and the settings screen.
(1 )
(2)
(3)
(4)-+---:::-11
(5)
H-ft--(6)
(7)
(8)
(9)
(1) SCAN button
(2) COpy button
(3) Menu button
(4) A,.,., and. buttons
(5) Back button
(6) LCD (Liquid Crystal Display)
(7) MEMORY CARD button
(8) Settings button
(9) OK button
• Basic Operation on the Menu Screen
You can perform various printing functions and machine maintenance by selecting the menu
items on the menu screen
in each mode.
To display the menu screen on the LCD, press the Menu button.
To select the menu item, use the A, ., 04, and. buttons to specify the item, then press the OK
button.
~ Note
• You can return the LCD to the previous screen by pressing the Back button.
•For details
on each item, see "Menu Screens" on page 5.
4Before Using the Machine

•Menu Screens
~ Note
• You can display the Maintenance screen or Device settings screen in the copy mode, memory
card mode, or scan mode.
Refer to the following list
to confirm the menu items available in the menu screen.
•For details
on maintenance, see "When Printing Becomes Faint or Colors Are Incorrect" on
page 38 or "Cleaning Your Machine" on page 52. For details on the device settings, refer to
"Changing the Machine Settings" in the User's Guide on-screen manual.
~COPYmOde
Copy menu screen
Borderless copy
Image repeat
Frame erase
Sticker
copy
~;j,i !Ha ;rrmnZa] 1 :J'kIirnnVg
~SCANmOde
Maintenance/settings screen will be displayed
by pressing the Menu button.
For details
on the scan mode, see "Scanning
Images"
on page 31.
~. Memory card mode
Card menu screen
Layout print
Sticker print
Print all photos
Photo Index print
DPOF print
Captured info
Photo Index Sheet print
Scan
sheet and print
,cm(,Ht!mm~rmmJ
Maintenance/settings
Maintenance screen
Device settings screen
Extended copy amount
Date display
Read/write attribute
Adjust contrast
Slide
show setting
Quiet mode
*1 For details, refer to the User's Guide on-
screen manual.
*2
Appears only when the optional Bluetooth
unit is attached to the machine.
Before Using the Machine 5

•Basic Operation on the Settings Screen
You can change the print sellings such as page size, media type, bordered or borderless print,
etc. on the settings screen either in the copy mode, in the
memory card mode, or when printing
directly from aPictBridge compliant device.
Eel Note
When printing from acomputer, see "Printing from Your Computer" on page 29.
When printing from awireless communication device, refer to "Printing Photographs from a
Wireless Communication Device"
in the User's Guide on-screen manual.
This section describes the procedure to change the sellings, taking the steps to specify the page
size for the
memory card mode to 4"x6"(101x152) as an example.
1Display the settings screen.
(1) Press the Settings button.
The Memory card settings screen is displayed.
~Memory card settings
l~J>JJlJ
A4
Photo Plus Glossy
Standard
Borderless [J
No date/f iIe no.
i§ii1iitm1iJ -Set
2Select the settings tab.
(1) Use the '4 or •button to select the settings tab.
Example: Select Tab 1here.
mory card settings
(~] 2iJ j
1\4
Photo PillS Glossy
Standard
Borderless [J
No date/f iIe no
i§ii1iitm1iJ =Set
3Select the setting item.
(1) Use the .. or'" button to select the setting item.
Example: Select A4 here.
~Memory card settings
1 ri 1 ~ nlD ............ r-i"'7.-.
(~A4~ 0
t"'now t"'IUS ljlOSSY
Standard
Borderless 0
No date/f iIe no.
i§ii1iitm1iJ = Se t
6Before Using the Machine

4Change the setting.
(1) Use the. or ~ button to change the setting.
Example:
Change to 4"x6"(101x152) here.
~Memory card settings
in I ") nJ 0-=0.-10 c-i-;.oo
(~4"X8"(101X152) 0
r-'IIUlU r-'Illb L:lIUbbY
Standard
Borderless 0
No date/f iIe no.
kiiDillllil-Set
5Complete setting.
(1) Press the Settings button.
The LCD returns to the previous screen.
~ Note
For details on the setting Items
•For the settings in the copy mode, see "Setting Items" on page 20.
•For the settings
in the memory card mode, see "Setting Items" on page 26.
•For the settings when printing directly from aPictBridge compliant device, see "Setting
on the Machine"
in "Printing Photographs Directly from aCompliant Device" on page 32.
Before Using the Machine 7

Turning the Machine On and Off
Turn on the machine before printing.
•Turning on the Machine
Before turning on the machine, confirm the following.
•The FINE Cartridges are installed properly.
If you are using the machine connected to acomputer, confirm also the following.
•The machine is connected to your
computer (or acompatible device).
•The
MP Drivers are installed.
rn Note
If preparatory operations above are not complete, follow your setup sheet to complete them.
1Open the Operation Panel and press
the ON/OFF button to turn on the
machine.
The Power lamp flashes and then
remains lit green.
~ Important
Ifthe Alarm lamp begins to flash orange and
an error message is displayed on the LCD,
see "An Error Message
Is Displayed on the
LCD"
on page 57.
2If you are using the machine
connected to acomputer, turn on your computer.
•Turning off the Machine
1 To turn off the machine, press the
ON/OFF button.
When the Power lamp stops flashing, the
machine is turned off.
~ Important
About the Power Plug
When removing the power plug after turing
off the machine,
be sure to confirm that the
Power lamp
is not lit. Ifthe power plug is
removed from the wall outlet with the Power
lamp still lit or flashing green, the machine
may become unable
to print.
See "Keeping the Best Printing Results"
on
page 51.
8Before Using the Machine

• Screen-saver Mode
The LCD goes out if the machine is not operated for about five minutes'.
, You cannot change the wait time before the LCD goes out.
~ Note
When you want to restore the display, perform aprint operation or press any button except for the
ON/OFF button. When you press the ON/OFF button while the machine is in Screen-saver mode,
the machine turns off.
Handling the Original Document
This section describes how to load the original document on the Platen Glass.
• Original Document Requirements
The original documents you load on the Platen Glass for copying or scanning must meet these
requirements:
Document type
•Paper documents
•Photographs
•Books
Size (W xL) Max. 8.5 x11.7 inches
/216 x297 mm
Thickness Max. 0.6 inches /15 mm
• Loading Original Documents
Load originals to copy or scan on the Platen Glass.
~ Note
Make sure any glue, ink, correction fluid, or the like on the original document is completely dry
before loading it on the Platen Glass.
1Lift the Document Cover.
2Load the original with the side to be
copied Iscanned facing down on the
Platen Glass.
•To make copies or scan
documents
Place the original in landscape
orientation and align the uppercorner of
it with the alignment mark as shown in
the figure on the right.
Platen Glass
Before Using the Machine 9

Efl Note
•The machine cannot scan the shaded area in the figure below.
(A) 0.04 inches / 1 mm
•For details about making copies, see "Copying"
on page 20.
•For details about scanning images. see "Scanning Using the Operation Panel of the
Machine"
in "Scanning Images" on page 31 .
• To scan photographs
Place the photograph at least 0.4 inches /10 mm away from and in square with the edges of
the Platen Glass.
(A)
(A) 0.4 inches /10 mm
(A)
10
Platen Glass
Before Using the Machine

When setting two or more photographs at the same time, place them at least 0.4 inches /10
mm apart from each other.
'-
UD
,hl
D
(A)
(A)
(A) (A)
(A) 0.4 inches /10 mm
~ Important
•Do not place any objects weighing more than 4.4 Ib /2.0 kg on the Platen Glass.
•Do not press or put weight
on the original with pressure exceeding 4.4 Ib /2.0 kg.
Doing so may cause the scanner to malfunction or the Platen Glass to break.
~ Note
•If photographs are placed closer, they may be scanned as asingle image. For details, refer to
the Scanning Guide on-screen manual.
•For details about scanning images, see "Scanning Using the Operation Panel
of the Machine" in
"Scanning Images" on page 31.
3Gently close the Document Cover.
Before Using the Machine
11

Loading Printing Paper
This section describes how to load printing paper in the Rear Tray.
•Using Specialty Media
Canon recommends that you use Canon genuine media to ensure optimal print quality.
•Photo Quality Media
•Glossy Photo Paper
•Matte Photo Paper
•Photo Paper Plus Double Sided
•Photo Paper Plus Glossy
•Photo Paper Plus Semi-gloss
•Photo Paper Pro
•Photo Stickers
~
t .• -
•Media Suited for Business
Documents
•High Resolution Paper
jl
12 Before Using the Machine

•Paper Handling
•Recommended Paper and Requirements
IPlus Glossy 5 __ ~ I ~ =+_IOSSY t~ GIO"W
iPhOto Paper PP- 11 sheet lLeft -Photo Paper .
Plus Double 101 DPlus Double i
Sided'~_ I _L_____ ISided I
Photo. lPS-101 11 sheet L;fi ~- -- Photo Pape;:- I
Stickers 8 -h;:;- ------ -----1----- PIU~~OSSY-1
T-Shirt iTR-301 1sheet IRight -T-Shirt I
Transfers'4 ~ Transfer~ __ I
*1 Paper with aModel Number is Canon specialty media. Refer to the instruction manual
supplied with the paper for detailed information on the printable side and notes on handling
paper. For information on the paper sizes available for each Canon genuine paper, visit our
website. You may not be able to purchase some Canon genuine papers depending on the
country or region of purchase. Paper is not sold in the US by Model Number. Purchase paper
by name.
*2 If the corners or edges of the paper are smudged, try to print with the Paper Thickness Lever
set to the right. It may improve print quality.
Reset the Paper Thickness Lever to the left when you finish printing_
For details on the Paper Thickness Lever, refer to "Inside" in "Main Components" of the User's
Guide on-screen manual.
Media Type Mode(1 Paper Paper Paper Media Type
Support Output Thickness Machine Printer
Load Limit Tray Load Lever*9 Setting Driver
Limit Setting
~'" P'P~ -_~ shee_ts 50 sheets Left Plain paper IPlain Paper i
Envelopes'
4-
~ envelopes 1envelope Right
-r-- !Envelop;- -'
----------- ------f-------'-
------------- --it-------
High I HR- 180 ,h .. " .1'" ,heel,
Left -High
i Resol~tion 1
101
NIIResolution
Paper 4 ~
!Paper
---t-------- --- ----- -----
1----------- ----1------ ----
Super White SW-201 80 sheets 150 sheets Left Plain paper Plain Paper
Paper
.- ---~
IGlossy Photo! GP-401 A4,-cetter-r
Left Glossy Photo
~SSy Photo I
Paper 55" x7" I_Paper Paper I
-'--------- ---
-----
----- - ---I
Glossy Photo GP-501 I127.0 xLeft Glossy Photo !Glossy Photo I
Paper 1177.8mm, Paper
[paper I
"Ever~day and 8" x10" I
Use'" 1203 .2 x
1254.0 mm: -II
;:'~cPhOIO_.'::1\];~ :~:~"
Left Matte Photo IMatte Photo
Paper Paper :
---,------ --I
Photo Paper GP-502 101_6 xLeft Glossy Photo -Glossy Photo
r-~Iossy 152.4 mm, Paper Paper I
---
Photo pape~1
Photo Paper SG-101, Wide and Left Photo Plus
Plus ~5emi- SG-201 Credit card: Glossy Plus Glossy I
gloss 20 sheets I
--------~
Photo Paper PR-101 IILeft Photo Paper Photo Paper !
Pro'
5IPro
'Pro ~
II
------ f------- -------
Photo Pape~
PP-101 Left Photo Plus Photo Paper
~
Before Using the Machine 13

*3 Proper feeding of paper may not be possible at the maximum capacity depending on the type
of paper or environmental conditions (either very high or low temperature and humidity).
In
such cases, reduce the sheets of paper you load at atime to around half (around 0.2 inches 1
5 mm in paper stack height).
*4 Available only when printing from your computer.
*5 When loading paper
in stacks, the print side may be marked as it is fed in or sheets may be
stuck to one another causing them not to be fed properly.
In this case, load one sheet at a
time.
*6 We recommend that you remove the previously printed sheet from the Paper Output Tray
before continuously printing to avoid blurs and discoloration.
*7 This paper cannot be used in Macintosh@
*8 When copying onto sticker paper, be sure to select Sticker copy in Special copy. Refer to
"Copying on Stickers (Sticker copy)"
in "Using Useful Copy Functions" of the User's Guide on-
screen manual.
When printing photos saved
on amemory card to sticker paper, be sure to select Sticker
print in Special photo print. Refer to "Printing on Stickers (Sticker print)" in "Using Useful
Printing Functions" of the User's Guide on-screen manual.
~ Important
• Put unused paper back into the package, and store them avoiding heat, humidity, and direct
sunlight.
•
Do not touch the printed surface nor stack the printed sheets until the ink is fixed.
EEl Note
For adetailed description of printing media types, refer to "Printing Media" in the User's Guide on-
screen manual.
•Media Types You Cannot Use
Do not use the following types of paper. Using such paper will not only produce unsatisfactory
results, but can also cause the machine
to jam or malfunction. Additionally, when printing on A5
or smaller sized paper, do not use paper thinner than apost card, including plain paper or
notepad paper cut to asmall size.
•Folded, curled, or wrinkled paper
•Damp paper
•Paper that
is too thin (weighing less than 17 lb 164 gsm)
•Paper that
is too thick (plain paper, except for Canon genuine paper, weighing more than 28
Ib 1105 gsm)
•Picture postcards
•Postcards affixed with photos or stickers
•Any type of paper with holes
•Paper that is not rectangular
•Paper bound with staples or glue
•Paper with adhesives
•Paper decorated with glitter, etc.
14 Before Using the Machine

•Loading Paper
~ Important
•If you cut plain paper to 4" x6" /101.6 x152.4 mm, 5" x7" /127.0 x177.8 mm, or2.13" x3.39"
/54.0 x86.0 mm (credit card-size) for atrial print, it can cause paper jams.
•
You cannot print on postcards affixed with photos or stickers.
•Always load paper in portrait orientation (A). Loading paper in landscape orientation (B) can
cause the paper to be jammed.
D
(A) D (B)
~ Note
•We recommend using genuine Canon photo media when printing photographs. For details on
the specialty media Canon provides for use with its various printers, see "Using Specialty
Media" on page 12.
When Printing on Plain Paper
• You can use general copy paper or Canon's Super White Paper. When printing on both sides,
we recommend Canon's Super White Paper Double-Sided.
Paper size:
-Standard sizes: A4, B5, A5, Letter, and Legal
-Non-standard sizes: 2.13 x3.39 inches to 8.5 x23 inches
/54.0 x86.0 mm to 215.9 x584.2
mm
Paper weight: 17 to 28 lb
/64 to 105 gsm (non-Canon genuine plain paper)
1Flatten the four corners of the paper before loading it.
~ Note
•Align the edges of paper neatly before loading. Loading paper without aligning the edges may
cause paper jams.
•If paper is curled, hold the opposing curled corners and gently bend them
in the opposite
direction until the paper becomes completely flat. See "Paper is curled." on page 64.
•
To avoid curling, handle paper as follows.
-Put unused paper back into the package and keep them on alevel surface.
-Take out only the necessary number
of sheets from the package, just before printing.
Before Using the Machine 15

2Prepare to load paper.
(1) Open the Paper Support, then pull out the
Paper Support Extension.
(2) Open the Paper
Output Tray.
(3) Open the Output Tray Extension.
(4) Adjust the position
of the Paper Thickness
Lever.
Set it to the right when printing on
envelopes
or T-shirt transfers, and left when
printing on any other type
of paper. See
"Paper Handling" on page 13.
(4)
(3) (2)
(1 )
~ Note
If the corners or edges of the paper are smudged, try to print with the Paper Thickness Lever set to
the right. It may improve print quality.
Reset the Paper Thickness Lever
to the left when you finish printing.
For details
on the Paper Thickness Lever, refer to "Inside" in "Main Components" of the User's
Guide on-screen manual.
3Load the paper.
(1) Load the paper in the Rear Tray
with the print side facing
UP.
(2) Align the paper stack against the
right side
of the Rear Tray.
(3) Pinch the Paper Guide and slide it
against the left side
of the paper
stack.
4Specify the page size and media
type settings according to the
loaded paper. *Do not load higher than the Load Limit
Mark (A).
16
~ Note
•When performing copy direct printing without using acomputer, select the size and type of the
loaded paper
in Page size and Media type by pressing the Settings button in each mode.
For details
on the copy mode settings, see "Setting Items" on page 20.
For details
on the memory card mode settings, see "Setting Items" on page 26.
•When using the machine connected
to acomputer, select the size and type of the loaded paper
in Page Size (or Paper Size) and Media Type in the printer driver.
For details
on printer driver settings, see "Printing with Windows" on page 29 or "Printing with
Macintosh"
on page 30.
Before Using the Machine
