Canvas CTCBF36V User manual

ASSEMBLY INSTRUCTIONS
HAVING TROUBLE?
TOLL-FREE:
1-888-670-6684
IMPORTANT: Please read this manual carefully
before beginning assembly of this product.
Keep this manual for future reference.
BAYFIELD 36” (91.4 CM)
BATHROOM VANITY
PRODUCT NO. 063-6382-4-NAVY

To the trend seekers and design mavens,
CANVAS™ is the furniture and décor brand
that helps you imagine and create a space
you can be proud of.
That’s because
CANVAS™ oers style with
ease with products that are made for real life
and Canadian inspired.
We would love to hear from you and welcome
your thoughtful feedback. Visit our website
at canadiantire.ca to tell us about your
experience, and share your photos with us
using #myCANVASstyle.
Show us how you bring CANVAS™ products
to life. We can’t wait to see!

Parts List 4
Before You Begin Assembly 8
Step-by-step Guide 10
Technical Data 21
Troubleshooting 22
Caring for Your Item 22
Warranty 23
TABLE OF CONTENTS
TOOLS REQUIRED
No. 2 Cross-head Screwdriver
Tip Shown Actual Size
NOTE: Do not over-drill/
be aware of over-drilling
• Pleasereadandunderstandthisentiremanualbeforeattemptingtoassemble,
operate,orinstalltheproduct.
• Anyassemblyormaintenanceoftheproductmustbecarriedoutbyadultsonly.
• Somepartsmaycontainsharpedges.Wearprotectiveglovesifnecessary.
• Topreventdamage,placeallpartsonalevelsurfaceduringassembly.Adda
layer of protective surface if needed.
• Donotallowyourchildrentoclimborjumponfurnitureduetopossible
accident,injuryordeath.Achildclimbingonapieceoffurniturecanmakeit
top-heavy and cause the furniture to tip over.
• Keepchildrenandpetsawayduringassembly.
• Thisunitisintendedforuseonlywithinthemaximumweightindicated.Use
withloadsheavierthanthemaximumweightindicatedmayresultininstability
causingpossibleinjury.
• Failuretofollowthesewarningscouldresultinseriousinjury.
WARNING!TOREDUCETHERISKOFSERIOUSINJURY,
READTHEFOLLOWINGSAFETYINSTRUCTIONSBEFORE
ASSEMBLINGANDUSINGTHEPRODUCT.
2 People
Rubber
Mallet

BAYFIELD 36” (91.4 CM) BATHROOM VANITY
4
PARTS LIST
ITEM DESCRIPTION THUMBNAIL QUANTITY
7 AdjustableShelf 1
9 BackPanel 1
13 Right Door 1
8Bottom Panel 1
10 LowerBackStretcher 1
12 Left Door 1
11 Leg 4
2Vanity Top 1
1 Backsplash 1
3Side Panel Left 1
4Side Panel Right 1
5 UpperBackStretcher 1
6 UpperFrontStretcher 1

BAYFIELD 36” (91.4 CM) BATHROOM VANITY 5
EXPLODED VIEW
1
3
8
13
12
11
2
4
5
6
9
10
7

BAYFIELD 36” (91.4 CM) BATHROOM VANITY
6
HARDWARE LIST
ITEM DESCRIPTION THUMBNAIL QUANTITY
I M3.5x12mmScrew 4
F M4x15mmScrew 24
E M4x32mmScrew 4
A CamLock 6
BCam Bolt 6
G M4x16mmScrew 20
H SlowCloseHinge 4
CWood Dowel 10
D Handle 2
JLeveller 4
KBolt 8

BAYFIELD 36” (91.4 CM) BATHROOM VANITY 7
HARDWARE LIST
ITEM DESCRIPTION THUMBNAIL QUANTITY
SMetal Plate 4
R M4x25mmScrew 16
U M4x50mmScrew 2
TPlastic anchor 2
L LockWasher 8
M FlatWasher 8
P5/32”x25mmBolt 4
NShelf Pin 4
OGlue 1
QBigger Wood Dowel 4

BAYFIELD 36” (91.4 CM) BATHROOM VANITY
8
BEFORE YOU BEGIN ASSEMBLY
MAKE SURE ALL PARTS ARE PRESENT
Compareallpiecestothepartsandhardwarelists,and
makesureyouhavealltoolsrequiredforassembly.
REMOVE PACKAGING MATERIALS
Placepackingmaterialsbackinthebox.Donotdisposeof
packagingmaterialsuntilassemblyiscomplete.
READ EACH STEP CAREFULLY
Makesureyouunderstandeachstep.Ifyouhaveanyquestions,
contact CANVAS™
customer service at 1-888-670-6684 (toll free).
ASSEMBLE IN A CLEARED AREA
Placeallpartsfromtheboxontheoorinfrontofyouonaclean,
dry,levelsurfacetoprotecttheproductasitisbeingbuilt.
?

BAYFIELD 36” (91.4 CM) BATHROOM VANITY 9
BEFORE YOU BEGIN ASSEMBLY
CAM LOCK SYSTEM OPERATION
NOTE:ITISVERYIMPORTANTTOUSEGLUEWITHDOWELS.EXCESSGLUECAN
BEWIPEDOFFWITHDAMPCLOTH.
InsertdowelatleasthalfwaybytappinglightlywitharubbermalletIFNECESSARY.
Takecautionnottostrikemalletatanangle—thiscancausethedoweltosnapor
break.
GLUE
XX
1.Screwcamboltintothepre-drilledsmallholesonpanel.Alignthepanelstobejoined
so that the cam bolt goes into the pre-drilled hole on the edge of the second panel and
protrudesintotheholethatwillhousethecamlock.
2.Insertthecamlockintopre-drilledlargeholeonpanel.Makesurearrowonthecam
lockispointedtowardthecambolt.
3.Oncethecamboltisconnectedinsidecamlock,takeacross-headscrewdriverand
tightenthecamlockbyturningclockwise.
You are now ready to assemble the product.
1 4
3
2

BAYFIELD 36” (91.4 CM) BATHROOM VANITY
10
STEP-BY-STEP GUIDE
4X1BX6 11 X4RX16 SX4 3X1
3
4
B
Install cam bolts BB into side panel left 33 and side panel right 44.
Attach metal plate Sto leg 11,tightenwithM4x25mmscrewsR.
NoteNote:Makesurecambolts BB and screws R are completely seated.
STEP 1
11
R
S

BAYFIELD 36” (91.4 CM) BATHROOM VANITY 11
STEP-BY-STEP GUIDE
4X1 3X110 X1
3
4
5
6
10
C
A
AX6CX6
Attach side panel left 33 and side panel right 44toto upperbackstretcher55,upper
front stretcher 66andlowerbackstretcher1010,,using wood dowels CC,andcamlocks
AA. Tightencamlocks AA..
STEP 2

BAYFIELD 36” (91.4 CM) BATHROOM VANITY
12
STEP-BY-STEP GUIDE
CX4EX4 8X1
Attach bottom panel 8to side panel left 3and side panel right 4usingcamlocksA
and wood dowels C,and tightenwithM4x32mmscrewsE.
STEP 3
8
3
4
C
E

BAYFIELD 36” (91.4 CM) BATHROOM VANITY 13
11
8
J
Q
KL
M
MX8 KX8LX8QX4
STEP-BY-STEP GUIDE
STEP 4
JX4
Insert bigger wood dowel Q to pre-drilled hole on bottom panel 8,attachassembled
leg 11 with metal plate Sto the bottom panel 8,usingatwasherM,lockwasherL
and bolt K,tightenwithcross-head screwdrive.
Assemble leveller Jto bottom of leg 11.

BAYFIELD 36” (91.4 CM) BATHROOM VANITY
14
STEP-BY-STEP GUIDE
9
G
STEP 5
9X1GX20
Attachbackpanel99tothebackofthevanity,usingM4x16mmscrewsGG. Tighten
screws GG..

BAYFIELD 36” (91.4 CM) BATHROOM VANITY 15
STEP-BY-STEP GUIDE
7
STEP 6
I
N
Insert shelf supports Ninto corresponding holes in the sides of the vanity assembly.
Makesureyouplacetheshelfsupportsatthesamelevelsotheshelfisnottilted.
Tiltandrestadjustableshelf7onto shelf supports N.SecureusingM3.5x12mm
screws I.
7X1NX4 IX4

BAYFIELD 36” (91.4 CM) BATHROOM VANITY
16
STEP-BY-STEP GUIDE
FX8PX4 12 X113 X1DX2HX4
STEP 7
12
13
H
D
P
F
Attach slow close hinges HHto left door 1212 and right door 1313 withM4x15mm
screws FF.
Attach handle DD to left door 1212 and right door 1313 with5/32”x25mmboltsPP..

BAYFIELD 36” (91.4 CM) BATHROOM VANITY 17
STEP-BY-STEP GUIDE
STEP 8
FX16
Align the left door 1212 hinges H to the pilot holes in side panel left 33,and align right
door 1313 hinges H to the pilot holes in side panel right 44. AttachwithM4x15mm
screws FF.Openandclosethedoorstomakesuretheyarealignedandshutcorrectly.
Ifnecessaryadjustthescrewsforagoodt.
Three-wayadjustablehingeforperfectlyaligneddoors.
1.Toadjustthedoorforwardorbackward.
2.Toadjustthedoortorightorleft.
3.Toadjustthedoorupordown.
4
3
12
13
F
22
11
33

BAYFIELD 36” (91.4 CM) BATHROOM VANITY
18
STEP-BY-STEP GUIDE
5
TX2UX2
T
U
STEP 9
WALL
Determinewherevanityistobeplacedandmarklocationonthewallforthe
mounting.
Drill a 3/8” hole in the wall. Press the plastic anchor TT into the hole and gently tap
untiltheangeoftheanchorisagainstthewallsurface.
AttachVanitytothewallusingM4x50mmscrewsUU.
Incaseofunevenoors,oorlevellersareprovidedatthebottomofthevanity.If
necessary,adjustoorlevellersbyhandtocorrecttiltingand/orleveldoors.

BAYFIELD 36” (91.4 CM) BATHROOM VANITY 19
2X1
2
Silicone (NOT Provided)
STEP-BY-STEP GUIDE
Apply silicone around the top edge of vanity assembly to secure the vanity top 2.
STEP 10

BAYFIELD 36” (91.4 CM) BATHROOM VANITY
20
Silicone (NOT Provided)
UP
1X1
STEP-BY-STEP GUIDE
Tomountthebacksplash1tothewall,applyathinbeadofsiliconecompound(not
included)totheunpolishedbacksideandbottomofthebacksplash1. Position
backsplash1as shown onto vanity top 2andagainstthewall.Cleananyexcess
silicone compound before allowing to dry.
STEP 11
2
1
