Canvas NELSON 168-0098-0 User manual

ASSEMBLY INSTRUCTIONS
HAVING TROUBLE?
TOLL-FREE:
NELSON
EXTENDING CONSOLE DESK
PRODUCT NO. 168-0098-0

We believe in the power of décor and its
ability to make up the fabric of your home.
That’s why CANVAS
TM
TM
TM
collections draw
inspiration from Canadians and the way
they live.
From on-trend furniture pieces to holiday
décor and all your outdoor living essentials,
CANVAS makes it easy to refresh your space
your unique style and the way you
live every day.
We would love to hear from you and welcome
your thoughtful feedback. Visit our website
at canadiantire.ca to tell us about your
experience, and share your photos with us
using #myCANVASstyle.
Show us how you bring CANVAS products
to life. We can’t wait to see!

TABLE OF CONTENTS
TOOLS REQUIRED
NOTE:
4
8
9
23
24
24
Phillips
and Flat-head Screwdriver
Do not use a power drill.
Be aware of power drilling.

4
PARTS LIST
ITEM DESCRIPTION THUMBNAIL QUANTITY
1
2
3
4
5
6
7
Top Panel
Left Side Panel
Right Side Panel
Desk Top Panel
Desk Back
Connection Rail
Left Leg
8
9
Right Leg
Desk Skirt
10
11
Left Desk
Right Desk
NELSON EXTENDING CONSOLE DESK

PARTS LIST
ITEM DESCRIPTION THUMBNAIL QUANTITY
12
13
14
15
16
17
18
Drawer Front
Left Drawer
Right Drawer
Drawer Back
Drawer Base
Drawer Support Rail
Support Rail
5
NELSON EXTENDING CONSOLE DESK

EXPLODED PARTS
6NELSON EXTENDING CONSOLE DESK
1
6
18
10
14
17
16
12
15
13
11
2
4
5
98
7
3

HARDWARE LIST
ITEM THUMBNAIL QUANTITY
31
26
11
4
5
A
B
C
D
E
7
Cam Bolts
Cam Locks (Big)
Cam Locks (Small)
Wood Dowels 6x30 mm
Adjustable Feet
4
6
2
2
F
G
H
I
Flat Head Screws (Big) 4x40 mm
Casters
Round Head Screws (Small) 4x16 mm
Wall Anchors
2
2
J
K
Round Head Screws (Big) 4x35 mm
Anti-tip Brackets
5
LFlat Head Screws (Small) 4x30 mm
NELSON EXTENDING CONSOLE DESK
31
MCoated Paper Stickers
2
1
Wood Dowels 8x30 mm 2
O
P
Q
N
Barrel Nuts
Hex Key
DESCRIPTION
Warning: Before assembly, please check all accessories in the hardware box,
and ensure all parts are not missing.
Flat Head Hex Screws 6x50 mm 2

BEFORE YOU BEGIN ASSEMBLY
?
MAKE SURE ALL PARTS ARE PRESENT
REMOVE PACKAGING MATERIALS
READ EACH STEP CAREFULLY
ASSEMBLE IN A CLEARED AREA
TM
8NELSON EXTENDING CONSOLE DESK
If
．

STEP-BY-STEP GUIDE
STEP 1
Hx2 Ax6 1x1 Kx2
9
Insert six cam bolts Ainto the underside of the top panel 1. Avoid over tightening. Attach the
anti-tip brackets Kusing two small round head screws H.
Hand tighten all screws.
NELSON EXTENDING CONSOLE DESK
1
A
A
A
A
A
A
A
H
H
K
K
H
K

STEP-BY-STEP GUIDE
STEP 2
10
3x1
2x1 Ax8 Ex4
Insert four cam bolts Ainto the left side panel 2.
Insert two adjustable feet Einto the bottom end of the left side panel 2.
Insert four cam bolts Ainto the right side panel 3.
Insert two adjustable feet Einto the bottom end of the right side panel 3.
NELSON EXTENDING CONSOLE DESK
A
A
A
E
EA
A
A
E
E
A
2
3

STEP-BY-STEP GUIDE
STEP 3
11
2x1 3x1 6x1 18 x1 Bx8 Dx2
Insert four cam locks Binto the connection rail 6.
Insert four cam locks Band two wood dowels D into the support rail 18 as shown.
Attach the connection rail 6to the left side panel 2and the right side panel 3.
Attach the support rail 18 to the left side panel 2and the right side panel 3.
Hand tighten all cam locks B.
NELSON EXTENDING CONSOLE DESK
3
2
B
B
D
B
6
B
18
B
B
D
B
Note: it may be easier to tighten the
cam locks B with a flat-head screwdriver.

12
STEP-BY-STEP GUIDE
STEP 4
1x1 Bx6 Dx5
Insert five wood dowels Dalong the top surfaces of the left side panel 2,
right side panel 3 and connection rail 6.
Insert six cam locks Bjust below the top surfaces of the left side panel 2,
right side panel 3 and connection rail 6.
Attach the top panel 1to the left side panel 2, right side panel 3,
and connection rail 6. Hand tighten all cam locks B.
NELSON EXTENDING CONSOLE DESK
1
B
B
B
D
DD
B
B
B
D
D
B
B

STEP-BY-STEP GUIDE
STEP 5
7x1 8x1 Ax6
Insert three cam bolts Ainto the right leg 8.
Attach one caster Gto the right leg 8using two small round head screws H.
Hand tighten all screws H.
Repeat above step on the left leg 7.
Gx2 Hx4
13
NELSON EXTENDING CONSOLE DESK
A
A
A
A
A
A
G
G
H
H
G
H
H
8
7

NELSON EXTENDING CONSOLE DESK
STEP-BY-STEP GUIDE
STEP 6
10 x1 11 x1 Bx4
Insert two cam locks Binto the right desk 11.
Attach the right desk 11 to the right leg 8.
Hand tighten the cam locks B.
Repeat above steps for the left desk 10 and left leg 7.
14
11
10
B
B
B
B
7
8
B

STEP-BY-STEP GUIDE
STEP 7
5x1 9x1
Insert two cam locks B and two barrel nuts Ointo the desk skirt 9.
Align the desk back 5 and desk skirt 9to the left desk 10 and right desk 11.
Insert two big flat head screws Fthrough the right desk 11 into the desk back 5. Insert
one flat head hex screw Qthrough the right desk 11 into the desk skirt 9.Tighten the
flat head screws F, flat head hex screw Q and cam locks B.
Insert two big flat head screws Fthrough the left desk 10 into the desk back 5. Insert
one flat head hex screw Qthrough the left desk 10 into the desk skirt 9.Tighten the
flat head screws F, flat head hex screw Q and cam locks B.
Bx2 Qx2 Fx4
15
NELSON EXTENDING CONSOLE DESK
Ox2 Px1
B
B
O
O
D
F
F
Q
F
F
5
9
11
O
Q
Q
P
8
7
10

STEP-BY-STEP GUIDE
STEP 8
4x1 Ax6
Insert six cam bolts A into the desk top panel 4.
16 NELSON EXTENDING CONSOLE DESK
A
A
A
A
A
A
A
4

STEP-BY-STEP GUIDE
STEP 9
Insert four wood dowels Dalong the top surfaces of the left desk 10, right desk 11
and desk back 5.
Insert two wood dowels Nalong the top surface of the left leg 7and right leg 8.
Insert six cam locks Bjust below the top surfaces of the left desk 10, right desk 11
and desk back 5.
Attach the desk top panel 4to the left desk 10, right desk 11 and desk back 5.
Hand tighten all cam locks B.
4x1 Bx6 Dx4
17
NELSON EXTENDING CONSOLE DESK
Nx2
B
BB
B
D
D
N
D
D
B
B
4
B
N
11
8
9
7
5
10

18
STEP-BY-STEP GUIDE
STEP 10
12 x1 13 x1 14 x1
Attach the drawer back 15 to right drawer 14 and left drawer 13 using four small flat head
screws L. Hand tighten.
Attach the drawer support rail 17 to drawer back 15 using one small flat head screw L. Hand
tighten.
Insert five cam bolts Ainto drawer front 12.
15 x1 17 x1 Ax5 Lx5
NELSON EXTENDING CONSOLE DESK
A
A
A
12
17
14
L
L
L
A
L
13
15

STEP-BY-STEP GUIDE
STEP 11
12 x1 16 x1 Cx5
Insert the drawer base 16 into the groove around the bases of the right drawer 14,
left drawer 13 and drawer back 15.
Insert four small cam locks C into the right drawer 14 and left drawer 13.
Insert one small cam lock Cinto the drawer support rail 17.
Attach the drawer front 12 to the right drawer 14, left drawer 13 and the
drawer support rail 17.
Hand tighten all cam locks C.
19
NELSON EXTENDING CONSOLE DESK
Note: it may be easier to tighten the
cam locks C with a flat-head screwdriver.
17
17
13
13
14
14
15
15
16
16
12
C
C
C
C

STEP-BY-STEP GUIDE
STEP 12
Kx2 Jx2
1. Move unit to desired position.
2. Mark the wall through the holes in the anti-tip brackets K.
3. Using a 6 mm drill bit, drill a hole at each mark approximately 1 1/2" (4 cm) deep.
4. Insert two wall anchors I into the drilled holes and hammer so that they are flush
with the wall.
5. Attach anti-tip bracket using two big round head screws J. Hand-tighten the
big round head screws J.
20 NELSON EXTENDING CONSOLE DESK
I
J
I
J
WARNING!
Ix2
TOOLS REQUIRED
