Canvas RENFREW 088-2041-2 User manual

RENFREW ARMCHAIR
AND OTTOMAN
PRODUCT NO. 088-2041-2
ASSEMBLY INSTRUCTIONS
Toll free: 1-888-670-6684
IMPORTANT: Please read and understand this manual before any assembly. Before beginning assembly
of product, make sure all parts are present. Compare parts with packaging contents list. If any part is
missing, or if you have any questions, contact the customer service department at 1-888-670-6684.

IMPORTED BY TRILEAF DISTRIBUTION TRIFEUIL TORONTO, CANADA M4S 2B8
Made in China

3
TABLE OF CONTENTSIMPORTANT SAFETY INSTRUCTIONS
Table of Contents 3
Important Safety Instructions 3
Parts List 4
Assembly 5
Cleaning and Maintenance 8
Technical Data 8
Warranty 9
IMPORTANT: Retain for future reference, and read carefully.
Warning! To reduce the risk of serious injury, read the following safety
instructions before assembling and using the armchair.
•This product is intended for domestic outdoor use only.
•The product should be placed on flat, horizontal ground.
•Any assembly or maintenance of the product must be carried out by adults only.
•Arrange necessary manpower when assembling or moving the product.
•Some parts may contain sharp edges. Wear protective gloves if necessary.
•Keep children and pets away while setting up the armchair.
•Check all nuts and bolts periodically for tightness. When required, tighten them again.
•Repairing and replacing parts should be done by a qualified technician.
•If the product will not be used for a long period (e.g. winter time), it should be stored in a clean,
dry environment.
•Do not light any fires below or near the product!
•Retain the original packaging to store the armchair.
Caution! Always keep children under close supervision while they are using or
around this product.
Never leave children unattended.

Right arm-1 Screw with washer M6X20 - 2
Left arm-1 Screw with washer M6X40 - 6
Back panel-1
1
2
3
Hex key - 1
C
Seat panel-1
4
Back cushion -1
5
Seat cushion-1
6
A
B
4PRODUCT NO. 088-2041-2
PARTS LIST
4

Hex key
5
ASSEMBLY PREPARATION
Let us help you!
DO NOT RETURN YOUR PRODUCT TO THE STORE. CALL US FIRST!
1-888-670-6684
If you have questions regarding your product, require warranty
assistance, or have damaged or missing parts, please call our customer
service toll-free helpline. Contact us for assistance;we’re here to help.
Place all parts from the box in a cleared area and position them on the floor in front of you.
Remove all packing materials and place them back into the box. Do not dispose of the packing
materials until assembly is complete. Read each step carefully before beginning any assembly
and make sure you understand each step. If you are missing a part, please call our toll-free
number for assistance 1-888-670-6684.
CAUTION!
•
The maximum weight capacity of the armchair is 250 lb (113.39 kg);
for ottoman 200 lb (90.7 kg)
Do not stand on the product.
•
Keep children away during assembly.
This product contains small parts which can be swallowed by children.
•
Keep fingers away from the places where they can be pinched or trapped.
•
Do not attempt to assemble the table if any parts are missing.
Needed for assembly:
Two people

Step 1
Requires part 1, 4, B, C
Attach the seat panel (4) to the right arm (1) by using M6X40 screws (B)
with washers, aligning the holes. When assembled, tighten the screws with Hex Key (C).
Step 2
Requires parts 3, A, B
Connect the back panel (3) to the seat panel (4) by using the M6X40
screw (B) with washers, then connect back panel(3) to the right arm (1) by M6X20
screw (A), then tighten the screws with Hex Key (C).
4
6PRODUCT NO. 088-2041-2
ASSEMBLY
Note: Do not tighten screws all the way until you have assembled the armchair.
Once assembly is complete, tighten each screw.
4
4
3
1
B
C
B
C
A

Step 3
Requires parts 2,A, B
Attach the left arm (2) to the seat panel by using M6X40 screw (B), then connect to
back panel by using M6x20 screw (A), then tighten the screws with Hex Key (C).
Step 3
Requires parts 5,6
Turn the chair to upright position and put the seat cushion (5) and back
cushion (6) on the seat.
2
6
5
7
ASSEMBLY
4
B
C

8PRODUCT NO. 088-2041-2
MAINTENANCETECHNICAL DATA
•
Clean the product with a slightly damp cloth and a little detergent. Let it dry thoroughly.
•
Do not use bleach, acid, or other abrasive cleaners on the cushions or frame parts.
CAUTION!
•
Check all screws and nuts periodically for tightness, tightening them
again as required.
Dimensions (L x W x H)
Product weight
12 PRODUCT NO. 046-3456-8 | MODEL NO. 088-163
Armchair: 27 15/16 x 29 15/16 x 31 7/8"
(71 x 76 x 81 cm)
Ottoman: 24 x 18 1/8 x 11"
(61 x 46 x 28 cm)
Product weight Armchair: 33 lb (15 kg)
Ottoman: 12 lb (5.5 kg)

13
9
WARRANTY
This CANVAS product carries a one (1) year warranty against defects in
workmanship and materials.
Trileaf Distribution agrees to replace the defective product free of charge
within the stated warranty period, when returned by the original purchaser
with proof of purchase. This product is not guaranteed against wear or
breakage due to misuse and/or abuse.
