Canvas ACAPULCO YD-ACA3B User manual

ASSEMBLY INSTRUCTIONS
HAVING TROUBLE?
TOLL-FREE:
1-888 -670 -6684
IMPORTANT: Please read this manual carefully
before beginning assembly of this product.
Keep this manual for future reference.
ACAPULCO
BLACK 3-PIECE CHAT SET—CHAIR
MODEL NO.
PRODUCT NO. 088-0097-2
YD-ACA3B

We believe in the power of décor and its
ability to make up the fabric of your home.
That’s why collections draw
inspiration from Canadians and the way
they live.
From on-trend furniture pieces to holiday
décor and all your outdoor living essentials,
makes it easy to refresh your space
your unique style and the way you
live every day.
We would love to hear from you and welcome
your thoughtful feedback. Visit our website
at canadiantire.ca to tell us about your
experience, and share your photos with us
using #mycanvasstyle.
Show us how you bring products
to life. We can’t wait to see!
CANVAS™
CANVAS™
CANVAS™

ACAPULCO BLACK 3-PIECE CHAT SET3
Parts List 4
Step-by-step Guide 6
Caring for Your Item 19
Warranty
TABLE OF CONTENTS
Please read and understand this entire manual before attempting to assemble,
operate, or install the product.
Any assembly or maintenance of the product must be carried out by adults only.
Some parts may contain sharp edges. Wear protective gloves if necessary.
To prevent damage, place all parts on a level surface during assembly. Add a
layer of protective surface if needed.
Due to the nature of steel, surface oxidation (rusting) will occur if this protective
coating is scratched. This is a natural process. To minimize this condition, it is
recommended that care be taken when assembling and handling the product in
order to prevent the paint from being scratched.
WARNING! TO REDUCE THE RISK OF SERIOUS INJURY,
READ THE FOLLOWING SAFETY INSTRUCTIONS BEFORE
ASSEMBLING AND USING THE PRODUCT.
19
Maximum weight limit: 250 lb (113.3 kg) per chair.

ACAPULCO BLACK 3-PIECE CHAT SET 4
PARTS LIST
ITEM DESCRIPTION THUMBNAIL QUANTITY
1Chair frame 1
2Chair leg 4

ACAPULCO CHAIR5
EXPLODED PARTS
1
2

STEP-BY-STEP GUIDE
2x 4 1x 1
STEP 1
Place the chair frame
1onto a non-abrasive surface,
such as a carpet.
Screw the chair leg 2up to the chair frame 1 by turning
1
2
ACAPULCO BLACK 3-PIECE CHAT SET 6
clockwise.

STEP 2
Turn over the chair. Now the chair is ready for use.
7ACAPULCO BLACK 3-PIECE CHAT SET

ASSEMBLY INSTRUCTIONS
HAVING TROUBLE?
TOLL-FREE:
1-888-670 -6684
IMPORTANT: Please read this manual carefully
before beginning assembly of this product.
Keep this manual for future reference.
ACAPULCO
BLACK 3-PIECE CHAT SET—TABLE
MODEL NO.
PRODUCT NO. 088-0097-2
YD-ACA3B

We believe in the power of décor and its
ability to make up the fabric of your home.
That’s why collections draw
inspiration from Canadians and the way
they live.
From on-trend furniture pieces to holiday
décor and all your outdoor living essentials,
makes it easy to refresh your space
your unique style and the way you
live every day.
We would love to hear from you and welcome
your thoughtful feedback. Visit our website
at canadiantire.ca to tell us about your
experience, and share your photos with us
using #mycanvasstyle.
Show us how you bring products
to life. We can’t wait to see!
CANVAS™
CANVAS™
CANVAS™

ACAPULCO BLACK 3-PIECE CHAT SET10
Parts List 11
Step-by-step Guide
13
14
Caring for Your Item 19
Warranty 19
TABLE OF CONTENTS
Please read and understand this entire manual before attempting to assemble,
operate, or install the product.
Any assembly or maintenance of the product must be carried out by adults only.
Some parts may contain sharp edges. Wear protective gloves if necessary.
To prevent damage, place all parts on a level surface during assembly. Add a
layer of protective surface if needed.
Due to the nature of steel, surface oxidation (rusting) will occur if this protective
coating is scratched. This is a natural process. To minimize this condition, it is
recommended that care be taken when assembling and handling the product in
order to prevent the paint from being scratched.
WARNING! TO REDUCE THE RISK OF SERIOUS INJURY,
READ THE FOLLOWING SAFETY INSTRUCTIONS BEFORE
ASSEMBLING AND USING THE PRODUCT.
TOOLS REQUIRED
2 people
Hex key
Hardware List
Maximum weight limit: 100 lb (45 kg) per table.

ACAPULCO BLACK 3-PIECE CHAT SET 11
PARTS LIST
ITEM DESCRIPTION THUMBNAIL QUANTITY
2Table leg A 1
3Table leg B 1
14
1Table top 1

ACAPULCO BLACK 3-PIECE CHAT SET12
EXPLODED PARTS
1
2
3

13
HARDWARE LIST
ITEM DESCRIPTION THUMBNAIL QUANTITY
AM6x25 mm combination bolt 1
Hex KeyB1
ACAPULCO BLACK 3-PIECE CHAT SET

ACAPULCO BLACK 3-PIECE CHAT SET14
STEP-BY-STEP GUIDE
2x 1 1x 1
STEP 1
Place the table top 1onto a non-abrasive surface, such as
a carpet.
Place table leg A 2in the upright postion and start to insert.
1
2

STEP 2
Insert table leg A 2into the table top 1.
1
2
2
1
15
ACAPULCO BLACK 3-PIECE CHAT SET

ACAPULCO BLACK 3-PIECE CHAT SET16
STEP-BY-STEP GUIDE
3x 1
STEP 3
Insert the table leg B 3into the table top 1.
1
3

-
Bx 1 Ax 1
STEP 4
Connect table leg A 2and table leg B 3using combination
bolt A. Tighten the bolt by using hex key B.
1
1
2
3
2
3
ACAPULCO BLACK 3-PIECE CHAT SET 17
A

ACAPULCO BLACK 3-PIECE CHAT SET18
STEP-BY-STEP GUIDE
STEP 5
Turn over the table. Now the table is ready for use.

088-0097-2
CARING FOR YOUR ITEM
1 3
4 5
OFF SEASON:
CLEANING:
ACAPULCO BLACK 3-PIECE CHAT SET
2
