Caple WC1791 User manual

67
45°
1 2
45°
34
180°
Limited block B
Limited block A
5
1. Incline the wine cooler with 45 degrees, take out right lower hinge’s screws with screwdriver (Fig.1)
2. Level the wine cooler Hold the door and take out right upper hinge’s screws with screwdriver,
then take out the door, put the door safety, rotate door at 180 degree (Fig.2 & Fig.3 & Fig.4)
3. Remove limited block B as per the arrows in picture, then release all the screws on limited block A,
and take away limited block A.Install the limited block A at the right side with screws,then install limited block B,
then fit the door with screws . (see Fig.5& Fig.6& Fig.7)

www.caple.co.uk
Bristol
BS11 8DW
t: 0117 938 7420
e: [email protected]
www.caple.co.uk
Please keep this instruction manual for future reference
