10 11Instruction manual Wi6161 Please keep this instruction manual for future reference Please keep this instruction manual for future reference Instruction manual Wi6161
CONTROL PANEL
Control panel
•“ ”
Indicator light illuminates to signify the cooling mode is currently in operation.
•“ ”Button
Used to switch the internal light on/off.
•“ ” Button
To switch the appliance on/off (press and hold this buttons for approximately 3 seconds).
•“ ” Button
Used to raise the temperature in 1ºC increments.
•“ ” Button
Used to lower the temperature by in 1ºC increments.
Setting the temperature
•To set the temperature, connect the power cord to a properly grounded outlet. In the event of
a power interruption, the previous temperature setting is automatically erased and it will default
to a preset temperature setting of 12°C
•Set the desired cooling temperature by pressing the buttons adjacent to the “ / "
indicators. Each press of the buttons will scroll through the available temperature settings in
increments of 1°C.
•The temperature setting can be adjusted from 5°C to 18°C
•To view the actual temperature at anytime press and hold the temperature adjustment button
(up or down) for approximately 5 seconds, the actual temperature will temporarily flash in the
LED display for 5 Seconds. After this it will revert back to the set temperature.
Flashing LED = Cabinet temperature
Steady LED = Set temperature
Note
•If the unit is unplugged, power lost or turned off, you must wait 3 to 5 minutes before restarting
the unit. If you attempt to restart before this time delay, the wine cabinet will not start.
•When you use the wine cabinet for the first time or you restart the cabinet after having been shut
off for a long time, there could be a few degrees variance between the temperature you select
and the one indicated on the LED readout. This is normal and it is due to the length of the
activation time. Once the wine cabinet has been running for a few hours everything will be back
to normal.
Control panel
•“ ”
Indicator light illuminates to signify the cooling mode is currently in operation.
•“ ”Button
Used to switch the internal light on/off.
•“ ” Button
To switch the appliance on/off (press and hold this buttons for approximately 3 seconds).
•“ ” Button
Used to raise the temperature in 1ºC increments.
•“ ” Button
Used to lower the temperature by in 1ºC increments.
Setting the temperature
•To set the temperature, connect the power cord to a properly grounded outlet. In the event of
a power interruption, the previous temperature setting is automatically erased and it will default
to a preset temperature setting of 12°C
•Set the desired cooling temperature by pressing the buttons adjacent to the “ / "
indicators. Each press of the buttons will scroll through the available temperature settings in
increments of 1°C.
•The temperature setting can be adjusted from 5°C to 18°C
•To view the actual temperature at anytime press and hold the temperature adjustment button
(up or down) for approximately 5 seconds, the actual temperature will temporarily flash in the
LED display for 5 Seconds. After this it will revert back to the set temperature.
Flashing LED = Cabinet temperature
Steady LED = Set temperature
Note
•If the unit is unplugged, power lost or turned off, you must wait 3 to 5 minutes before restarting
the unit. If you attempt to restart before this time delay, the wine cabinet will not start.
•When you use the wine cabinet for the first time or you restart the cabinet after having been shut
off for a long time, there could be a few degrees variance between the temperature you select
and the one indicated on the LED readout. This is normal and it is due to the length of the
activation time. Once the wine cabinet has been running for a few hours everything will be back
to normal.
Control panel
•“ ”
Indicator light illuminates to signify the cooling mode is currently in operation.
•“ ”Button
Used to switch the internal light on/off.
•“ ” Button
To switch the appliance on/off (press and hold this buttons for approximately 3 seconds).
•“ ” Button
Used to raise the temperature in 1ºC increments.
•“ ” Button
Used to lower the temperature by in 1ºC increments.
Setting the temperature
•To set the temperature, connect the power cord to a properly grounded outlet. In the event of
a power interruption, the previous temperature setting is automatically erased and it will default
to a preset temperature setting of 12°C
•Set the desired cooling temperature by pressing the buttons adjacent to the “ / "
indicators. Each press of the buttons will scroll through the available temperature settings in
increments of 1°C.
•The temperature setting can be adjusted from 5°C to 18°C
•To view the actual temperature at anytime press and hold the temperature adjustment button
(up or down) for approximately 5 seconds, the actual temperature will temporarily flash in the
LED display for 5 Seconds. After this it will revert back to the set temperature.
Flashing LED = Cabinet temperature
Steady LED = Set temperature
Note
•If the unit is unplugged, power lost or turned off, you must wait 3 to 5 minutes before restarting
the unit. If you attempt to restart before this time delay, the wine cabinet will not start.
•When you use the wine cabinet for the first time or you restart the cabinet after having been shut
off for a long time, there could be a few degrees variance between the temperature you select
and the one indicated on the LED readout. This is normal and it is due to the length of the
activation time. Once the wine cabinet has been running for a few hours everything will be back
to normal.
Control panel
•“ ”
Indicator light illuminates to signify the cooling mode is currently in operation.
•“ ”Button
Used to switch the internal light on/off.
•“ ” Button
To switch the appliance on/off (press and hold this buttons for approximately 3 seconds).
•“ ” Button
Used to raise the temperature in 1ºC increments.
•“ ” Button
Used to lower the temperature by in 1ºC increments.
Setting the temperature
•To set the temperature, connect the power cord to a properly grounded outlet. In the event of
a power interruption, the previous temperature setting is automatically erased and it will default
to a preset temperature setting of 12°C
•Set the desired cooling temperature by pressing the buttons adjacent to the “ / "
indicators. Each press of the buttons will scroll through the available temperature settings in
increments of 1°C.
•The temperature setting can be adjusted from 5°C to 18°C
•To view the actual temperature at anytime press and hold the temperature adjustment button
(up or down) for approximately 5 seconds, the actual temperature will temporarily flash in the
LED display for 5 Seconds. After this it will revert back to the set temperature.
Flashing LED = Cabinet temperature
Steady LED = Set temperature
Note
•If the unit is unplugged, power lost or turned off, you must wait 3 to 5 minutes before restarting
the unit. If you attempt to restart before this time delay, the wine cabinet will not start.
•When you use the wine cabinet for the first time or you restart the cabinet after having been shut
off for a long time, there could be a few degrees variance between the temperature you select
and the one indicated on the LED readout. This is normal and it is due to the length of the
activation time. Once the wine cabinet has been running for a few hours everything will be back
to normal.
Control panel
•
Indicator light illuminates to signify the cooling mode is currently in operation.
•“ ”Button
Used to switch the internal light on/off.
•“ ” Button
To switch the appliance on/off (press and hold this buttons for approximately 3 seconds).
•“ ” Button
Used to raise the temperature in 1ºC increments.
•“ ” Button
Used to lower the temperature by in 1ºC increments.
Setting the temperature
•To set the temperature, connect the power cord to a properly grounded outlet. In the event of
a power interruption, the previous temperature setting is automatically erased and it will default
to a preset temperature setting of 12°C
•Set the desired cooling temperature by pressing the buttons adjacent to the “ / "
indicators. Each press of the buttons will scroll through the available temperature settings in
increments of 1°C.
•The temperature setting can be adjusted from 5°C to 18°C
•To view the actual temperature at anytime press and hold the temperature adjustment button
(up or down) for approximately 5 seconds, the actual temperature will temporarily flash in the
LED display for 5 Seconds. After this it will revert back to the set temperature.
Flashing LED = Cabinet temperature
Steady LED = Set temperature
Note
•If the unit is unplugged, power lost or turned off, you must wait 3 to 5 minutes before restarting
the unit. If you attempt to restart before this time delay, the wine cabinet will not start.
•When you use the wine cabinet for the first time or you restart the cabinet after having been shut
off for a long time, there could be a few degrees variance between the temperature you select
and the one indicated on the LED readout. This is normal and it is due to the length of the
activation time. Once the wine cabinet has been running for a few hours everything will be back
to normal.
WI6133 Wine Cabinet manual.indd 11 17/10/2017 12:45
CONTROL PANEL
TOUCH CONTROL KEYS AND SYMBOLS
To switch the appliance on/off. Press and hold this button for approximately
1 second to turn the appliance on. Press and hold this button for approximately 3 seconds
to turn the appliance off.
To turn the lock function on/off. Press and hold this button for approximately 3 seconds to
activate/deactivate. When activated, the symbol will illuminate.
Press this button to raise the temperature in 1ºC increments. Once the temperature reaches
the highest temperature value for the upper or
lower zone, it will revert back to its lowest temperature value.
Upper zone = 5-10ºC
Lower zone = 10-18ºC
Once the required temperature is selected, the LED display will temporarily flash for 5
seconds, then reverts back to the normal display, and the temperature is now set.
NOTE:
Press and hold for 3 seconds, to change the display from ºC to ºF.
This button is used to toggle between the different light functions. When selected, the
relevant symbol will illuminate:
The internal light will switch on when the door is opened, and off when the door
is closed.
The internal light is continuously on. However after 3 minutes the light
will dim.
The internal light will remain on for 10 minutes once the door is closed and then
turn off.
TOUCH CONTROL KEYS AND SYMBOLS
This button is used to toggle between the different operational functions. When selected, the
relevant symbol will illuminate:
Standard mode - Select this function to operate the wine cabinet in standard mode.
ECO mode - An energy saving mode where both the inner light and control panel
lights are off (except the indicator). The LED display is also switched off, until you
change the temperature using the and keys, this will be displayed for 5
seconds and then switch off again. The compressor is also delayed 5 minutes in order
to save energy.
Intelligent mode - In intelligent mode, the wine cabinet will adjust the fan speed
according to the ambient temperature. This will reduce noise levels and save energy.
DEMO mode - When DEMO mode is selected, the compressor and PTC heater will be
disabled, and the fan input voltage reduces to 9V. The HI/LO temperature alarm is
also disabled during DEMO mode.
Note: Press and hold and for 3 seconds, to change the display from ºC to ºF.
To switch the appliance on/off .
Press and hold this button for approximately 1 second to turn the appliance on.
Press and hold this button for approximately 3 seconds to turn the appliance off.
To turn the lock function on/off.
Press and hold this button for approximately 3 seconds to activate/deactivate.
When activated, the symbol will illuminate.
Press this button to raise the temperature in 1ºC increments. The highest temperature is 18ºC.
Once the required temperature is selected, the LED display will temporarily flash for 5 seconds,
then reverts back to the normal display, and the temperature is now set.
Press this button to lower the temperature in 1ºC increments. The lowest temperature is 5ºC.
Once the required temperature is selected, the LED display will temporarily flash for 5 seconds,
it then reverts back to the normal display, and the temperature is now set.
This button is used to toggle between the different light functions. When selected, the relevant
symbol will illuminate:
The internal light will switch on when the door is opened, and off when the door is closed.
The internal light is continuously on. However after 3 minutes the light will dim.
The internal light will remain on for 10 minutes once the door is closed and then turn off.
This symbol indicates the brightness adjuster: Hold the light key for 3 seconds until
flashes. Then use the and keys to adjust the brightness of the internal light.
CONTROL PANEL AND OPERATION
The cooling symbol will illuminate to show when the wine cabinet is currently cooling.
The alarm symbol will illuminate to show the alarm is on. This will activate when either
the door has been left open for a long period of time, or the temperature has fluctuated
too high or low (HI or LO will also show in display to confirm this).
CONTROL PANEL AND OPERATION
TOUCH CONTROL KEYS AND SYMBOLS
This button is used to toggle between the different operational functions. When selected, the
relevant symbol will illuminate:
Standard mode - Select this function to operate the wine cabinet in standard mode.
ECO mode - An energy saving mode where both the inner light and control panel
lights are off (except the indicator). The LED display is also switched off, until you
change the temperature using the and keys, this will be displayed for 5
seconds and then switch off again. The compressor is also delayed 5 minutes in order
to save energy.
Intelligent mode - In intelligent mode, the wine cabinet will adjust the fan speed
according to the ambient temperature. This will reduce noise levels and save energy.
DEMO mode - When DEMO mode is selected, the compressor and PTC heater will be
disabled, and the fan input voltage reduces to 9V. The HI/LO temperature alarm is
also disabled during DEMO mode.
Note: Press and hold the keys for 3 seconds, to change the display from ºC to ºF.
To switch the appliance on/off .
Press and hold this button for approximately 1 second to turn the appliance on.
Press and hold this button for approximately 3 seconds to turn the appliance off.
To turn the lock function on/off.
Press and hold this button for approximately 3 seconds to activate/deactivate.
When activated, the symbol will illuminate.
Press this button to raise the temperature in 1ºC increments. Once the temperature reaches
the highest temperature value for the upper or lower zone, it will revert back to its lowest
temperature value.
Upper zone = 5-10ºC
Lower zone = 10-18ºC
Once the required temperature is selected, the LED display will temporarily flash for 5
seconds, then reverts back to the normal display, and the temperature is now set.
This button is used to toggle between the different light functions. When selected, the relevant
symbol will illuminate:
The internal light will switch on when the door is opened, and off when the door is closed.
The internal light is continuously on. However after 3 minutes the light will dim.
The internal light will remain on for 10 minutes once the door is closed and then turn off.
for 3 seconds until
This symbol indicates the brightness adjuster: Hold the light key
flashes. Then use the right hand side keys to adjust the brightness of the internal light.
The cooling symbol will illuminate to show when the wine cabinet is currently cooling.
The alarm symbol will illuminate to show the alarm is on. This will activate when either
the door has been left open for a long period of time, or the temperature has fluctuated
too high or low (HI or LO will also show in display to confirm this).
CONTROL PANEL AND OPERATION
TOUCH CONTROL KEYS AND SYMBOLS
This button is used to toggle between the different operational functions. When selected, the
relevant symbol will illuminate:
Standard mode - Select this function to operate the wine cabinet in standard mode.
ECO mode - An energy saving mode where both the inner light and control panel
lights are off (except the indicator). The LED display is also switched off, until you
change the temperature using the and keys, this will be displayed for 5
seconds and then switch off again. The compressor is also delayed 5 minutes in order
to save energy.
Intelligent mode - In intelligent mode, the wine cabinet will adjust the fan speed
according to the ambient temperature. This will reduce noise levels and save energy.
DEMO mode - When DEMO mode is selected, the compressor and PTC heater will be
disabled, and the fan input voltage reduces to 9V. The HI/LO temperature alarm is
also disabled during DEMO mode.
Note: Press and hold the keys for 3 seconds, to change the display from ºC to ºF.
To switch the appliance on/off .
Press and hold this button for approximately 1 second to turn the appliance on.
Press and hold this button for approximately 3 seconds to turn the appliance off.
To turn the lock function on/off.
Press and hold this button for approximately 3 seconds to activate/deactivate.
When activated, the symbol will illuminate.
Press this button to raise the temperature in 1ºC increments. Once the temperature reaches
the highest temperature value for the upper or lower zone, it will revert back to its lowest
temperature value.
Upper zone = 5-10ºC
Lower zone = 10-18ºC
Once the required temperature is selected, the LED display will temporarily flash for 5
seconds, then reverts back to the normal display, and the temperature is now set.
This button is used to toggle between the different light functions. When selected, the relevant
symbol will illuminate:
The internal light will switch on when the door is opened, and off when the door is closed.
The internal light is continuously on. However after 3 minutes the light will dim.
The internal light will remain on for 10 minutes once the door is closed and then turn off.
for 3 seconds until
This symbol indicates the brightness adjuster: Hold the light key
flashes. Then use the right hand side keys to adjust the brightness of the internal light.
The cooling symbol will illuminate to show when the wine cabinet is currently cooling.
The alarm symbol will illuminate to show the alarm is on. This will activate when either
the door has been left open for a long period of time, or the temperature has fluctuated
too high or low (HI or LO will also show in display to confirm this).
CONTROL PANEL AND OPERATION
TOUCH CONTROL KEYS AND SYMBOLS
This button is used to toggle between the different operational functions. When selected, the
relevant symbol will illuminate:
Standard mode - Select this function to operate the wine cabinet in standard mode.
ECO mode - An energy saving mode where both the inner light and control panel
lights are off (except the indicator). The LED display is also switched off, until you
change the temperature using the and keys, this will be displayed for 5
seconds and then switch off again. The compressor is also delayed 5 minutes in order
to save energy.
Intelligent mode - In intelligent mode, the wine cabinet will adjust the fan speed
according to the ambient temperature. This will reduce noise levels and save energy.
DEMO mode - When DEMO mode is selected, the compressor and PTC heater will be
disabled, and the fan input voltage reduces to 9V. The HI/LO temperature alarm is
also disabled during DEMO mode.
Note: Press and hold the keys for 3 seconds, to change the display from ºC to ºF.
To switch the appliance on/off .
Press and hold this button for approximately 1 second to turn the appliance on.
Press and hold this button for approximately 3 seconds to turn the appliance off.
To turn the lock function on/off.
Press and hold this button for approximately 3 seconds to activate/deactivate.
When activated, the symbol will illuminate.
Press this button to raise the temperature in 1ºC increments. Once the temperature reaches
the highest temperature value for the upper or lower zone, it will revert back to its lowest
temperature value.
Upper zone = 5-10ºC
Lower zone = 10-18ºC
Once the required temperature is selected, the LED display will temporarily flash for 5
seconds, then reverts back to the normal display, and the temperature is now set.
This button is used to toggle between the different light functions. When selected, the relevant
symbol will illuminate:
The internal light will switch on when the door is opened, and off when the door is closed.
The internal light is continuously on. However after 3 minutes the light will dim.
The internal light will remain on for 10 minutes once the door is closed and then turn off.
for 3 seconds until
This symbol indicates the brightness adjuster: Hold the light key
flashes. Then use the right hand side keys to adjust the brightness of the internal light.
The cooling symbol will illuminate to show when the wine cabinet is currently cooling.
The alarm symbol will illuminate to show the alarm is on. This will activate when either
the door has been left open for a long period of time, or the temperature has fluctuated
too high or low (HI or LO will also show in display to confirm this).
TOUCH CONTROL KEYS AND SYMBOLS
This button is used to toggle between the different operational functions. When selected, the
relevant symbol will illuminate:
Standard mode - Select this function to operate the wine cabinet in standard mode.
ECO mode - An energy saving mode where both the inner light and control panel
lights are off (except the indicator). The LED display is also switched off, until you
change the temperature using the and keys, this will be displayed for 5
seconds and then switch off again. The compressor is also delayed 5 minutes in order
to save energy.
Intelligent mode - In intelligent mode, the wine cabinet will adjust the fan speed
according to the ambient temperature. This will reduce noise levels and save energy.
DEMO mode - When DEMO mode is selected, the compressor and PTC heater will be
disabled, and the fan input voltage reduces to 9V. The HI/LO temperature alarm is
also disabled during DEMO mode.
Note: Press and hold and for 3 seconds, to change the display from ºC to ºF.
To switch the appliance on/off .
Press and hold this button for approximately 1 second to turn the appliance on.
Press and hold this button for approximately 3 seconds to turn the appliance off.
To turn the lock function on/off.
Press and hold this button for approximately 3 seconds to activate/deactivate.
When activated, the symbol will illuminate.
Press this button to raise the temperature in 1ºC increments. The highest temperature is 18ºC.
Once the required temperature is selected, the LED display will temporarily flash for 5 seconds,
then reverts back to the normal display, and the temperature is now set.
Press this button to lower the temperature in 1ºC increments. The lowest temperature is 5ºC.
Once the required temperature is selected, the LED display will temporarily flash for 5 seconds,
it then reverts back to the normal display, and the temperature is now set.
This button is used to toggle between the different light functions. When selected, the relevant
symbol will illuminate:
The internal light will switch on when the door is opened, and off when the door is closed.
The internal light is continuously on. However after 3 minutes the light will dim.
The internal light will remain on for 10 minutes once the door is closed and then turn off.
This symbol indicates the brightness adjuster: Hold the light key for 3 seconds until
flashes. Then use the and keys to adjust the brightness of the internal light.
CONTROL PANEL AND OPERATION
The cooling symbol will illuminate to show when the wine cabinet is currently cooling.
The alarm symbol will illuminate to show the alarm is on. This will activate when either
the door has been left open for a long period of time, or the temperature has fluctuated
too high or low (HI or LO will also show in display to confirm this).
TOUCH CONTROL KEYS AND SYMBOLS
This button is used to toggle between the different operational functions. When selected, the
relevant symbol will illuminate:
Standard mode - Select this function to operate the wine cabinet in standard mode.
ECO mode - An energy saving mode where both the inner light and control panel
lights are off (except the indicator). The LED display is also switched off, until you
change the temperature using the and keys, this will be displayed for 5
seconds and then switch off again. The compressor is also delayed 5 minutes in order
to save energy.
Intelligent mode - In intelligent mode, the wine cabinet will adjust the fan speed
according to the ambient temperature. This will reduce noise levels and save energy.
DEMO mode - When DEMO mode is selected, the compressor and PTC heater will be
disabled, and the fan input voltage reduces to 9V. The HI/LO temperature alarm is
also disabled during DEMO mode.
Note: Press and hold and for 3 seconds, to change the display from ºC to ºF.
To switch the appliance on/off .
Press and hold this button for approximately 1 second to turn the appliance on.
Press and hold this button for approximately 3 seconds to turn the appliance off.
To turn the lock function on/off.
Press and hold this button for approximately 3 seconds to activate/deactivate.
When activated, the symbol will illuminate.
Press this button to raise the temperature in 1ºC increments. The highest temperature is 18ºC.
Once the required temperature is selected, the LED display will temporarily flash for 5 seconds,
then reverts back to the normal display, and the temperature is now set.
Press this button to lower the temperature in 1ºC increments. The lowest temperature is 5ºC.
Once the required temperature is selected, the LED display will temporarily flash for 5 seconds,
it then reverts back to the normal display, and the temperature is now set.
This button is used to toggle between the different light functions. When selected, the relevant
symbol will illuminate:
The internal light will switch on when the door is opened, and off when the door is closed.
The internal light is continuously on. However after 3 minutes the light will dim.
The internal light will remain on for 10 minutes once the door is closed and then turn off.
This symbol indicates the brightness adjuster: Hold the light key for 3 seconds until
flashes. Then use the and keys to adjust the brightness of the internal light.
CONTROL PANEL AND OPERATION
The cooling symbol will illuminate to show when the wine cabinet is currently cooling.
The alarm symbol will illuminate to show the alarm is on. This will activate when either
the door has been left open for a long period of time, or the temperature has fluctuated
too high or low (HI or LO will also show in display to confirm this).
TOUCH CONTROL KEYS AND SYMBOLS
This button is used to toggle between the different operational functions. When selected, the
relevant symbol will illuminate:
Standard mode - Select this function to operate the wine cabinet in standard mode.
ECO mode - An energy saving mode where both the inner light and control panel
lights are off (except the indicator). The LED display is also switched off, until you
change the temperature using the and keys, this will be displayed for 5
seconds and then switch off again. The compressor is also delayed 5 minutes in order
to save energy.
Intelligent mode - In intelligent mode, the wine cabinet will adjust the fan speed
according to the ambient temperature. This will reduce noise levels and save energy.
DEMO mode - When DEMO mode is selected, the compressor and PTC heater will be
disabled, and the fan input voltage reduces to 9V. The HI/LO temperature alarm is
also disabled during DEMO mode.
Note: Press and hold and for 3 seconds, to change the display from ºC to ºF.
To switch the appliance on/off .
Press and hold this button for approximately 1 second to turn the appliance on.
Press and hold this button for approximately 3 seconds to turn the appliance off.
To turn the lock function on/off.
Press and hold this button for approximately 3 seconds to activate/deactivate.
When activated, the symbol will illuminate.
Press this button to raise the temperature in 1ºC increments. The highest temperature is 18ºC.
Once the required temperature is selected, the LED display will temporarily flash for 5 seconds,
then reverts back to the normal display, and the temperature is now set.
Press this button to lower the temperature in 1ºC increments. The lowest temperature is 5ºC.
Once the required temperature is selected, the LED display will temporarily flash for 5 seconds,
it then reverts back to the normal display, and the temperature is now set.
This button is used to toggle between the different light functions. When selected, the relevant
symbol will illuminate:
The internal light will switch on when the door is opened, and off when the door is closed.
The internal light is continuously on. However after 3 minutes the light will dim.
The internal light will remain on for 10 minutes once the door is closed and then turn off.
This symbol indicates the brightness adjuster: Hold the light key for 3 seconds until
flashes. Then use the and keys to adjust the brightness of the internal light.
CONTROL PANEL AND OPERATION
The cooling symbol will illuminate to show when the wine cabinet is currently cooling.
The alarm symbol will illuminate to show the alarm is on. This will activate when either
the door has been left open for a long period of time, or the temperature has fluctuated
too high or low (HI or LO will also show in display to confirm this).
TOUCH CONTROL KEYS AND SYMBOLS
This button is used to toggle between the different operational functions. When selected, the
relevant symbol will illuminate:
Standard mode - Select this function to operate the wine cabinet in standard mode.
ECO mode - An energy saving mode where both the inner light and control panel
lights are off (except the indicator). The LED display is also switched off, until you
change the temperature using the and keys, this will be displayed for 5
seconds and then switch off again. The compressor is also delayed 5 minutes in order
to save energy.
Intelligent mode - In intelligent mode, the wine cabinet will adjust the fan speed
according to the ambient temperature. This will reduce noise levels and save energy.
DEMO mode - When DEMO mode is selected, the compressor and PTC heater will be
disabled, and the fan input voltage reduces to 9V. The HI/LO temperature alarm is
also disabled during DEMO mode.
Note: Press and hold and for 3 seconds, to change the display from ºC to ºF.
To switch the appliance on/off .
Press and hold this button for approximately 1 second to turn the appliance on.
Press and hold this button for approximately 3 seconds to turn the appliance off.
To turn the lock function on/off.
Press and hold this button for approximately 3 seconds to activate/deactivate.
When activated, the symbol will illuminate.
Press this button to raise the temperature in 1ºC increments. The highest temperature is 18ºC.
Once the required temperature is selected, the LED display will temporarily flash for 5 seconds,
then reverts back to the normal display, and the temperature is now set.
Press this button to lower the temperature in 1ºC increments. The lowest temperature is 5ºC.
Once the required temperature is selected, the LED display will temporarily flash for 5 seconds,
it then reverts back to the normal display, and the temperature is now set.
This button is used to toggle between the different light functions. When selected, the relevant
symbol will illuminate:
The internal light will switch on when the door is opened, and off when the door is closed.
The internal light is continuously on. However after 3 minutes the light will dim.
The internal light will remain on for 10 minutes once the door is closed and then turn off.
This symbol indicates the brightness adjuster: Hold the light key for 3 seconds until
flashes. Then use the and keys to adjust the brightness of the internal light.
CONTROL PANEL AND OPERATION
The cooling symbol will illuminate to show when the wine cabinet is currently cooling.
The alarm symbol will illuminate to show the alarm is on. This will activate when either
the door has been left open for a long period of time, or the temperature has fluctuated
too high or low (HI or LO will also show in display to confirm this).
TOUCH CONTROL KEYS AND SYMBOLS
This button is used to toggle between the different operational functions. When selected, the
relevant symbol will illuminate:
Standard mode - Select this function to operate the wine cabinet in standard mode.
ECO mode - An energy saving mode where both the inner light and control panel
lights are off (except the indicator). The LED display is also switched off, until you
change the temperature using the and keys, this will be displayed for 5
seconds and then switch off again. The compressor is also delayed 5 minutes in order
to save energy.
Intelligent mode - In intelligent mode, the wine cabinet will adjust the fan speed
according to the ambient temperature. This will reduce noise levels and save energy.
DEMO mode - When DEMO mode is selected, the compressor and PTC heater will be
disabled, and the fan input voltage reduces to 9V. The HI/LO temperature alarm is
also disabled during DEMO mode.
Note: Press and hold and for 3 seconds, to change the display from ºC to ºF.
To switch the appliance on/off .
Press and hold this button for approximately 1 second to turn the appliance on.
Press and hold this button for approximately 3 seconds to turn the appliance off.
To turn the lock function on/off.
Press and hold this button for approximately 3 seconds to activate/deactivate.
When activated, the symbol will illuminate.
Press this button to raise the temperature in 1ºC increments. The highest temperature is 18ºC.
Once the required temperature is selected, the LED display will temporarily flash for 5 seconds,
then reverts back to the normal display, and the temperature is now set.
Press this button to lower the temperature in 1ºC increments. The lowest temperature is 5ºC.
Once the required temperature is selected, the LED display will temporarily flash for 5 seconds,
it then reverts back to the normal display, and the temperature is now set.
This button is used to toggle between the different light functions. When selected, the relevant
symbol will illuminate:
The internal light will switch on when the door is opened, and off when the door is closed.
The internal light is continuously on. However after 3 minutes the light will dim.
The internal light will remain on for 10 minutes once the door is closed and then turn off.
This symbol indicates the brightness adjuster: Hold the light key for 3 seconds until
flashes. Then use the and keys to adjust the brightness of the internal light.
CONTROL PANEL AND OPERATION
The cooling symbol will illuminate to show when the wine cabinet is currently cooling.
The alarm symbol will illuminate to show the alarm is on. This will activate when either
the door has been left open for a long period of time, or the temperature has fluctuated
too high or low (HI or LO will also show in display to confirm this).
TOUCH CONTROL KEYS AND SYMBOLS
This button is used to toggle between the different operational functions. When selected, the
relevant symbol will illuminate:
Standard mode - Select this function to operate the wine cabinet in standard mode.
ECO mode - An energy saving mode where both the inner light and control panel
lights are off (except the indicator). The LED display is also switched off, until you
change the temperature using the and keys, this will be displayed for 5
seconds and then switch off again. The compressor is also delayed 5 minutes in order
to save energy.
Intelligent mode - In intelligent mode, the wine cabinet will adjust the fan speed
according to the ambient temperature. This will reduce noise levels and save energy.
DEMO mode - When DEMO mode is selected, the compressor and PTC heater will be
disabled, and the fan input voltage reduces to 9V. The HI/LO temperature alarm is
also disabled during DEMO mode.
Note: Press and hold and for 3 seconds, to change the display from ºC to ºF.
To switch the appliance on/off .
Press and hold this button for approximately 1 second to turn the appliance on.
Press and hold this button for approximately 3 seconds to turn the appliance off.
To turn the lock function on/off.
Press and hold this button for approximately 3 seconds to activate/deactivate.
When activated, the symbol will illuminate.
Press this button to raise the temperature in 1ºC increments. The highest temperature is 18ºC.
Once the required temperature is selected, the LED display will temporarily flash for 5 seconds,
then reverts back to the normal display, and the temperature is now set.
Press this button to lower the temperature in 1ºC increments. The lowest temperature is 5ºC.
Once the required temperature is selected, the LED display will temporarily flash for 5 seconds,
it then reverts back to the normal display, and the temperature is now set.
This button is used to toggle between the different light functions. When selected, the relevant
symbol will illuminate:
The internal light will switch on when the door is opened, and off when the door is closed.
The internal light is continuously on. However after 3 minutes the light will dim.
The internal light will remain on for 10 minutes once the door is closed and then turn off.
This symbol indicates the brightness adjuster: Hold the light key for 3 seconds until
flashes. Then use the and keys to adjust the brightness of the internal light.
CONTROL PANEL AND OPERATION
The cooling symbol will illuminate to show when the wine cabinet is currently cooling.
The alarm symbol will illuminate to show the alarm is on. This will activate when either
the door has been left open for a long period of time, or the temperature has fluctuated
too high or low (HI or LO will also show in display to confirm this).
TOUCH CONTROL KEYS AND SYMBOLS
This button is used to toggle between the different operational functions. When selected, the
relevant symbol will illuminate:
Standard mode - Select this function to operate the wine cabinet in standard mode.
ECO mode - An energy saving mode where both the inner light and control panel
lights are off (except the indicator). The LED display is also switched off, until you
change the temperature using the and keys, this will be displayed for 5
seconds and then switch off again. The compressor is also delayed 5 minutes in order
to save energy.
Intelligent mode - In intelligent mode, the wine cabinet will adjust the fan speed
according to the ambient temperature. This will reduce noise levels and save energy.
DEMO mode - When DEMO mode is selected, the compressor and PTC heater will be
disabled, and the fan input voltage reduces to 9V. The HI/LO temperature alarm is
also disabled during DEMO mode.
Note: Press and hold and for 3 seconds, to change the display from ºC to ºF.
To switch the appliance on/off .
Press and hold this button for approximately 1 second to turn the appliance on.
Press and hold this button for approximately 3 seconds to turn the appliance off.
To turn the lock function on/off.
Press and hold this button for approximately 3 seconds to activate/deactivate.
When activated, the symbol will illuminate.
Press this button to raise the temperature in 1ºC increments. The highest temperature is 18ºC.
Once the required temperature is selected, the LED display will temporarily flash for 5 seconds,
then reverts back to the normal display, and the temperature is now set.
Press this button to lower the temperature in 1ºC increments. The lowest temperature is 5ºC.
Once the required temperature is selected, the LED display will temporarily flash for 5 seconds,
it then reverts back to the normal display, and the temperature is now set.
This button is used to toggle between the different light functions. When selected, the relevant
symbol will illuminate:
The internal light will switch on when the door is opened, and off when the door is closed.
The internal light is continuously on. However after 3 minutes the light will dim.
The internal light will remain on for 10 minutes once the door is closed and then turn off.
This symbol indicates the brightness adjuster: Hold the light key for 3 seconds until
flashes. Then use the and keys to adjust the brightness of the internal light.
CONTROL PANEL AND OPERATION
The cooling symbol will illuminate to show when the wine cabinet is currently cooling.
The alarm symbol will illuminate to show the alarm is on. This will activate when either
the door has been left open for a long period of time, or the temperature has fluctuated
too high or low (HI or LO will also show in display to confirm this).
TOUCH CONTROL KEYS AND SYMBOLS
This button is used to toggle between the different operational functions. When selected, the
relevant symbol will illuminate:
Standard mode - Select this function to operate the wine cabinet in standard mode.
ECO mode - An energy saving mode where both the inner light and control panel
lights are off (except the indicator). The LED display is also switched off, until you
change the temperature using the and keys, this will be displayed for 5
seconds and then switch off again. The compressor is also delayed 5 minutes in order
to save energy.
Intelligent mode - In intelligent mode, the wine cabinet will adjust the fan speed
according to the ambient temperature. This will reduce noise levels and save energy.
DEMO mode - When DEMO mode is selected, the compressor and PTC heater will be
disabled, and the fan input voltage reduces to 9V. The HI/LO temperature alarm is
also disabled during DEMO mode.
Note: Press and hold and for 3 seconds, to change the display from ºC to ºF.
To switch the appliance on/off .
Press and hold this button for approximately 1 second to turn the appliance on.
Press and hold this button for approximately 3 seconds to turn the appliance off.
To turn the lock function on/off.
Press and hold this button for approximately 3 seconds to activate/deactivate.
When activated, the symbol will illuminate.
Press this button to raise the temperature in 1ºC increments. The highest temperature is 18ºC.
Once the required temperature is selected, the LED display will temporarily flash for 5 seconds,
then reverts back to the normal display, and the temperature is now set.
Press this button to lower the temperature in 1ºC increments. The lowest temperature is 5ºC.
Once the required temperature is selected, the LED display will temporarily flash for 5 seconds,
it then reverts back to the normal display, and the temperature is now set.
This button is used to toggle between the different light functions. When selected, the relevant
symbol will illuminate:
The internal light will switch on when the door is opened, and off when the door is closed.
The internal light is continuously on. However after 3 minutes the light will dim.
The internal light will remain on for 10 minutes once the door is closed and then turn off.
This symbol indicates the brightness adjuster: Hold the light key for 3 seconds until
flashes. Then use the and keys to adjust the brightness of the internal light.
CONTROL PANEL AND OPERATION
The cooling symbol will illuminate to show when the wine cabinet is currently cooling.
The alarm symbol will illuminate to show the alarm is on. This will activate when either
the door has been left open for a long period of time, or the temperature has fluctuated
too high or low (HI or LO will also show in display to confirm this).
TOUCH CONTROL KEYS AND SYMBOLS
This button is used to toggle between the different operational functions. When selected, the
relevant symbol will illuminate:
Standard mode - Select this function to operate the wine cabinet in standard mode.
ECO mode - An energy saving mode where both the inner light and control panel
lights are off (except the indicator). The LED display is also switched off, until you
change the temperature using the and keys, this will be displayed for 5
seconds and then switch off again. The compressor is also delayed 5 minutes in order
to save energy.
Intelligent mode - In intelligent mode, the wine cabinet will adjust the fan speed
according to the ambient temperature. This will reduce noise levels and save energy.
DEMO mode - When DEMO mode is selected, the compressor and PTC heater will be
disabled, and the fan input voltage reduces to 9V. The HI/LO temperature alarm is
also disabled during DEMO mode.
Note: Press and hold and for 3 seconds, to change the display from ºC to ºF.
To switch the appliance on/off .
Press and hold this button for approximately 1 second to turn the appliance on.
Press and hold this button for approximately 3 seconds to turn the appliance off.
To turn the lock function on/off.
Press and hold this button for approximately 3 seconds to activate/deactivate.
When activated, the symbol will illuminate.
Press this button to raise the temperature in 1ºC increments. The highest temperature is 18ºC.
Once the required temperature is selected, the LED display will temporarily flash for 5 seconds,
then reverts back to the normal display, and the temperature is now set.
Press this button to lower the temperature in 1ºC increments. The lowest temperature is 5ºC.
Once the required temperature is selected, the LED display will temporarily flash for 5 seconds,
it then reverts back to the normal display, and the temperature is now set.
This button is used to toggle between the different light functions. When selected, the relevant
symbol will illuminate:
The internal light will switch on when the door is opened, and off when the door is closed.
The internal light is continuously on. However after 3 minutes the light will dim.
The internal light will remain on for 10 minutes once the door is closed and then turn off.
This symbol indicates the brightness adjuster: Hold the light key for 3 seconds until
flashes. Then use the and keys to adjust the brightness of the internal light.
CONTROL PANEL AND OPERATION
The cooling symbol will illuminate to show when the wine cabinet is currently cooling.
The alarm symbol will illuminate to show the alarm is on. This will activate when either
the door has been left open for a long period of time, or the temperature has fluctuated
too high or low (HI or LO will also show in display to confirm this).
CONTROL PANEL AND OPERATION
TOUCH CONTROL KEYS AND SYMBOLS
This button is used to toggle between the different operational functions. When selected, the
relevant symbol will illuminate:
Standard mode - Select this function to operate the wine cabinet in standard mode.
ECO mode - An energy saving mode where both the inner light and control panel
lights are off (except the indicator). The LED display is also switched off, until you
change the temperature using the and keys, this will be displayed for 5
seconds and then switch off again. The compressor is also delayed 5 minutes in order
to save energy.
Intelligent mode - In intelligent mode, the wine cabinet will adjust the fan speed
according to the ambient temperature. This will reduce noise levels and save energy.
DEMO mode - When DEMO mode is selected, the compressor and PTC heater will be
disabled, and the fan input voltage reduces to 9V. The HI/LO temperature alarm is
also disabled during DEMO mode.
Note: Press and hold the keys for 3 seconds, to change the display from ºC to ºF.
To switch the appliance on/off .
Press and hold this button for approximately 1 second to turn the appliance on.
Press and hold this button for approximately 3 seconds to turn the appliance off.
To turn the lock function on/off.
Press and hold this button for approximately 3 seconds to activate/deactivate.
When activated, the symbol will illuminate.
Press this button to raise the temperature in 1ºC increments. Once the temperature reaches
the highest temperature value for the upper or lower zone, it will revert back to its lowest
temperature value.
Upper zone = 5-10ºC
Lower zone = 10-18ºC
Once the required temperature is selected, the LED display will temporarily flash for 5
seconds, then reverts back to the normal display, and the temperature is now set.
This button is used to toggle between the different light functions. When selected, the relevant
symbol will illuminate:
The internal light will switch on when the door is opened, and off when the door is closed.
The internal light is continuously on. However after 3 minutes the light will dim.
The internal light will remain on for 10 minutes once the door is closed and then turn off.
for 3 seconds until
This symbol indicates the brightness adjuster: Hold the light key
flashes. Then use the right hand side keys to adjust the brightness of the internal light.
The cooling symbol will illuminate to show when the wine cabinet is currently cooling.
The alarm symbol will illuminate to show the alarm is on. This will activate when either
the door has been left open for a long period of time, or the temperature has fluctuated
too high or low (HI or LO will also show in display to confirm this).
CONTROL PANEL AND OPERATION
TOUCH CONTROL KEYS AND SYMBOLS
This button is used to toggle between the different operational functions. When selected, the
relevant symbol will illuminate:
Standard mode - Select this function to operate the wine cabinet in standard mode.
ECO mode - An energy saving mode where both the inner light and control panel
lights are off (except the indicator). The LED display is also switched off, until you
change the temperature using the and keys, this will be displayed for 5
seconds and then switch off again. The compressor is also delayed 5 minutes in order
to save energy.
Intelligent mode - In intelligent mode, the wine cabinet will adjust the fan speed
according to the ambient temperature. This will reduce noise levels and save energy.
DEMO mode - When DEMO mode is selected, the compressor and PTC heater will be
disabled, and the fan input voltage reduces to 9V. The HI/LO temperature alarm is
also disabled during DEMO mode.
Note: Press and hold the keys for 3 seconds, to change the display from ºC to ºF.
To switch the appliance on/off .
Press and hold this button for approximately 1 second to turn the appliance on.
Press and hold this button for approximately 3 seconds to turn the appliance off.
To turn the lock function on/off.
Press and hold this button for approximately 3 seconds to activate/deactivate.
When activated, the symbol will illuminate.
Press this button to raise the temperature in 1ºC increments. Once the temperature reaches
the highest temperature value for the upper or lower zone, it will revert back to its lowest
temperature value.
Upper zone = 5-10ºC
Lower zone = 10-18ºC
Once the required temperature is selected, the LED display will temporarily flash for 5
seconds, then reverts back to the normal display, and the temperature is now set.
This button is used to toggle between the different light functions. When selected, the relevant
symbol will illuminate:
The internal light will switch on when the door is opened, and off when the door is closed.
The internal light is continuously on. However after 3 minutes the light will dim.
The internal light will remain on for 10 minutes once the door is closed and then turn off.
for 3 seconds until
This symbol indicates the brightness adjuster: Hold the light key
flashes. Then use the right hand side keys to adjust the brightness of the internal light.
The cooling symbol will illuminate to show when the wine cabinet is currently cooling.
The alarm symbol will illuminate to show the alarm is on. This will activate when either
the door has been left open for a long period of time, or the temperature has fluctuated
too high or low (HI or LO will also show in display to confirm this).
CONTROL PANEL AND OPERATION
TOUCH CONTROL KEYS AND SYMBOLS
This button is used to toggle between the different operational functions. When selected, the
relevant symbol will illuminate:
Standard mode - Select this function to operate the wine cabinet in standard mode.
ECO mode - An energy saving mode where both the inner light and control panel
lights are off (except the indicator). The LED display is also switched off, until you
change the temperature using the and keys, this will be displayed for 5
seconds and then switch off again. The compressor is also delayed 5 minutes in order
to save energy.
Intelligent mode - In intelligent mode, the wine cabinet will adjust the fan speed
according to the ambient temperature. This will reduce noise levels and save energy.
DEMO mode - When DEMO mode is selected, the compressor and PTC heater will be
disabled, and the fan input voltage reduces to 9V. The HI/LO temperature alarm is
also disabled during DEMO mode.
Note: Press and hold the keys for 3 seconds, to change the display from ºC to ºF.
To switch the appliance on/off .
Press and hold this button for approximately 1 second to turn the appliance on.
Press and hold this button for approximately 3 seconds to turn the appliance off.
To turn the lock function on/off.
Press and hold this button for approximately 3 seconds to activate/deactivate.
When activated, the symbol will illuminate.
Press this button to raise the temperature in 1ºC increments. Once the temperature reaches
the highest temperature value for the upper or lower zone, it will revert back to its lowest
temperature value.
Upper zone = 5-10ºC
Lower zone = 10-18ºC
Once the required temperature is selected, the LED display will temporarily flash for 5
seconds, then reverts back to the normal display, and the temperature is now set.
This button is used to toggle between the different light functions. When selected, the relevant
symbol will illuminate:
The internal light will switch on when the door is opened, and off when the door is closed.
The internal light is continuously on. However after 3 minutes the light will dim.
The internal light will remain on for 10 minutes once the door is closed and then turn off.
for 3 seconds until
This symbol indicates the brightness adjuster: Hold the light key
flashes. Then use the right hand side keys to adjust the brightness of the internal light.
The cooling symbol will illuminate to show when the wine cabinet is currently cooling.
The alarm symbol will illuminate to show the alarm is on. This will activate when either
the door has been left open for a long period of time, or the temperature has fluctuated
too high or low (HI or LO will also show in display to confirm this).
CONTROL PANEL AND OPERATION
TOUCH CONTROL KEYS AND SYMBOLS
This button is used to toggle between the different operational functions. When selected, the
relevant symbol will illuminate:
Standard mode - Select this function to operate the wine cabinet in standard mode.
ECO mode - An energy saving mode where both the inner light and control panel
lights are off (except the indicator). The LED display is also switched off, until you
change the temperature using the and keys, this will be displayed for 5
seconds and then switch off again. The compressor is also delayed 5 minutes in order
to save energy.
Intelligent mode - In intelligent mode, the wine cabinet will adjust the fan speed
according to the ambient temperature. This will reduce noise levels and save energy.
DEMO mode - When DEMO mode is selected, the compressor and PTC heater will be
disabled, and the fan input voltage reduces to 9V. The HI/LO temperature alarm is
also disabled during DEMO mode.
Note: Press and hold the keys for 3 seconds, to change the display from ºC to ºF.
To switch the appliance on/off .
Press and hold this button for approximately 1 second to turn the appliance on.
Press and hold this button for approximately 3 seconds to turn the appliance off.
To turn the lock function on/off.
Press and hold this button for approximately 3 seconds to activate/deactivate.
When activated, the symbol will illuminate.
Press this button to raise the temperature in 1ºC increments. Once the temperature reaches
the highest temperature value for the upper or lower zone, it will revert back to its lowest
temperature value.
Upper zone = 5-10ºC
Lower zone = 10-18ºC
Once the required temperature is selected, the LED display will temporarily flash for 5
seconds, then reverts back to the normal display, and the temperature is now set.
This button is used to toggle between the different light functions. When selected, the relevant
symbol will illuminate:
The internal light will switch on when the door is opened, and off when the door is closed.
The internal light is continuously on. However after 3 minutes the light will dim.
The internal light will remain on for 10 minutes once the door is closed and then turn off.
for 3 seconds until
This symbol indicates the brightness adjuster: Hold the light key
flashes. Then use the right hand side keys to adjust the brightness of the internal light.
The cooling symbol will illuminate to show when the wine cabinet is currently cooling.
The alarm symbol will illuminate to show the alarm is on. This will activate when either
the door has been left open for a long period of time, or the temperature has fluctuated
too high or low (HI or LO will also show in display to confirm this).
This symbol indicates the brightness adjuster: Hold the light key for 3 seconds
until flashes. Then use the keys to adjust the brightness of the internal light.
This button is used to toggle between the different operational functions. When selected,
the relevant symbol will illuminate:
Standard mode - Select this function to operate the wine cabinet in standard mode.
ECO mode - An energy saving mode where both the inner light and control panel
lights are off (except the indicator). The LED display is also switched off, until
you change the temperature using the and keys, this will be displayed for 5
seconds and then switch off again. The compressor is also delayed 5 minutes in order
to save energy.
Intelligent mode - In intelligent mode, the wine cabinet will adjust the fan speed
according to the ambient temperature. This will reduce noise levels and save energy.
DEMO mode - When DEMO mode is selected, the compressor and PTC heater will
be disabled, and the fan input voltage reduces to 9V. The HI/LO temperature alarm is
also disabled during DEMO mode.
The cooling symbol will illuminate to show when the wine cabinet is currently cooling.
The alarm symbol will illuminate to show the alarm is on. This will activate when either
the door has been left open for a long period of time, or the temperature has fluctuated
too high or low (HI or LO will also show in display to confirm this).
TOUCH CONTROL KEYS AND SYMBOLS
This button is used to toggle between the different operational functions. When selected, the
relevant symbol will illuminate:
Standard mode - Select this function to operate the wine cabinet in standard mode.
ECO mode - An energy saving mode where both the inner light and control panel
lights are off (except the indicator). The LED display is also switched off, until you
change the temperature using the and keys, this will be displayed for 5
seconds and then switch off again. The compressor is also delayed 5 minutes in order
to save energy.
Intelligent mode - In intelligent mode, the wine cabinet will adjust the fan speed
according to the ambient temperature. This will reduce noise levels and save energy.
DEMO mode - When DEMO mode is selected, the compressor and PTC heater will be
disabled, and the fan input voltage reduces to 9V. The HI/LO temperature alarm is
also disabled during DEMO mode.
Note: Press and hold and for 3 seconds, to change the display from ºC to ºF.
To switch the appliance on/off .
Press and hold this button for approximately 1 second to turn the appliance on.
Press and hold this button for approximately 3 seconds to turn the appliance off.
To turn the lock function on/off.
Press and hold this button for approximately 3 seconds to activate/deactivate.
When activated, the symbol will illuminate.
Press this button to raise the temperature in 1ºC increments. The highest temperature is 18ºC.
Once the required temperature is selected, the LED display will temporarily flash for 5 seconds,
then reverts back to the normal display, and the temperature is now set.
Press this button to lower the temperature in 1ºC increments. The lowest temperature is 5ºC.
Once the required temperature is selected, the LED display will temporarily flash for 5 seconds,
it then reverts back to the normal display, and the temperature is now set.
This button is used to toggle between the different light functions. When selected, the relevant
symbol will illuminate:
The internal light will switch on when the door is opened, and off when the door is closed.
The internal light is continuously on. However after 3 minutes the light will dim.
The internal light will remain on for 10 minutes once the door is closed and then turn off.
This symbol indicates the brightness adjuster: Hold the light key for 3 seconds until
flashes. Then use the and keys to adjust the brightness of the internal light.
CONTROL PANEL AND OPERATION
The cooling symbol will illuminate to show when the wine cabinet is currently cooling.
The alarm symbol will illuminate to show the alarm is on. This will activate when either
the door has been left open for a long period of time, or the temperature has fluctuated
too high or low (HI or LO will also show in display to confirm this).
TOUCH CONTROL KEYS AND SYMBOLS
This button is used to toggle between the different operational functions. When selected, the
relevant symbol will illuminate:
Standard mode - Select this function to operate the wine cabinet in standard mode.
ECO mode - An energy saving mode where both the inner light and control panel
lights are off (except the indicator). The LED display is also switched off, until you
change the temperature using the and keys, this will be displayed for 5
seconds and then switch off again. The compressor is also delayed 5 minutes in order
to save energy.
Intelligent mode - In intelligent mode, the wine cabinet will adjust the fan speed
according to the ambient temperature. This will reduce noise levels and save energy.
DEMO mode - When DEMO mode is selected, the compressor and PTC heater will be
disabled, and the fan input voltage reduces to 9V. The HI/LO temperature alarm is
also disabled during DEMO mode.
Note: Press and hold and for 3 seconds, to change the display from ºC to ºF.
To switch the appliance on/off .
Press and hold this button for approximately 1 second to turn the appliance on.
Press and hold this button for approximately 3 seconds to turn the appliance off.
To turn the lock function on/off.
Press and hold this button for approximately 3 seconds to activate/deactivate.
When activated, the symbol will illuminate.
Press this button to raise the temperature in 1ºC increments. The highest temperature is 18ºC.
Once the required temperature is selected, the LED display will temporarily flash for 5 seconds,
then reverts back to the normal display, and the temperature is now set.
Press this button to lower the temperature in 1ºC increments. The lowest temperature is 5ºC.
Once the required temperature is selected, the LED display will temporarily flash for 5 seconds,
it then reverts back to the normal display, and the temperature is now set.
This button is used to toggle between the different light functions. When selected, the relevant
symbol will illuminate:
The internal light will switch on when the door is opened, and off when the door is closed.
The internal light is continuously on. However after 3 minutes the light will dim.
The internal light will remain on for 10 minutes once the door is closed and then turn off.
This symbol indicates the brightness adjuster: Hold the light key for 3 seconds until
flashes. Then use the and keys to adjust the brightness of the internal light.
CONTROL PANEL AND OPERATION
The cooling symbol will illuminate to show when the wine cabinet is currently cooling.
The alarm symbol will illuminate to show the alarm is on. This will activate when either
the door has been left open for a long period of time, or the temperature has fluctuated
too high or low (HI or LO will also show in display to confirm this).
TOUCH CONTROL KEYS AND SYMBOLS
This button is used to toggle between the different operational functions. When selected, the
relevant symbol will illuminate:
Standard mode - Select this function to operate the wine cabinet in standard mode.
ECO mode - An energy saving mode where both the inner light and control panel
lights are off (except the indicator). The LED display is also switched off, until you
change the temperature using the and keys, this will be displayed for 5
seconds and then switch off again. The compressor is also delayed 5 minutes in order
to save energy.
Intelligent mode - In intelligent mode, the wine cabinet will adjust the fan speed
according to the ambient temperature. This will reduce noise levels and save energy.
DEMO mode - When DEMO mode is selected, the compressor and PTC heater will be
disabled, and the fan input voltage reduces to 9V. The HI/LO temperature alarm is
also disabled during DEMO mode.
Note: Press and hold and for 3 seconds, to change the display from ºC to ºF.
To switch the appliance on/off .
Press and hold this button for approximately 1 second to turn the appliance on.
Press and hold this button for approximately 3 seconds to turn the appliance off.
To turn the lock function on/off.
Press and hold this button for approximately 3 seconds to activate/deactivate.
When activated, the symbol will illuminate.
Press this button to raise the temperature in 1ºC increments. The highest temperature is 18ºC.
Once the required temperature is selected, the LED display will temporarily flash for 5 seconds,
then reverts back to the normal display, and the temperature is now set.
Press this button to lower the temperature in 1ºC increments. The lowest temperature is 5ºC.
Once the required temperature is selected, the LED display will temporarily flash for 5 seconds,
it then reverts back to the normal display, and the temperature is now set.
This button is used to toggle between the different light functions. When selected, the relevant
symbol will illuminate:
The internal light will switch on when the door is opened, and off when the door is closed.
The internal light is continuously on. However after 3 minutes the light will dim.
The internal light will remain on for 10 minutes once the door is closed and then turn off.
This symbol indicates the brightness adjuster: Hold the light key for 3 seconds until
flashes. Then use the and keys to adjust the brightness of the internal light.
CONTROL PANEL AND OPERATION
The cooling symbol will illuminate to show when the wine cabinet is currently cooling.
The alarm symbol will illuminate to show the alarm is on. This will activate when either
the door has been left open for a long period of time, or the temperature has fluctuated
too high or low (HI or LO will also show in display to confirm this).
TOUCH CONTROL KEYS AND SYMBOLS
This button is used to toggle between the different operational functions. When selected, the
relevant symbol will illuminate:
Standard mode - Select this function to operate the wine cabinet in standard mode.
ECO mode - An energy saving mode where both the inner light and control panel
lights are off (except the indicator). The LED display is also switched off, until you
change the temperature using the and keys, this will be displayed for 5
seconds and then switch off again. The compressor is also delayed 5 minutes in order
to save energy.
Intelligent mode - In intelligent mode, the wine cabinet will adjust the fan speed
according to the ambient temperature. This will reduce noise levels and save energy.
DEMO mode - When DEMO mode is selected, the compressor and PTC heater will be
disabled, and the fan input voltage reduces to 9V. The HI/LO temperature alarm is
also disabled during DEMO mode.
Note: Press and hold and for 3 seconds, to change the display from ºC to ºF.
To switch the appliance on/off .
Press and hold this button for approximately 1 second to turn the appliance on.
Press and hold this button for approximately 3 seconds to turn the appliance off.
To turn the lock function on/off.
Press and hold this button for approximately 3 seconds to activate/deactivate.
When activated, the symbol will illuminate.
Press this button to raise the temperature in 1ºC increments. The highest temperature is 18ºC.
Once the required temperature is selected, the LED display will temporarily flash for 5 seconds,
then reverts back to the normal display, and the temperature is now set.
Press this button to lower the temperature in 1ºC increments. The lowest temperature is 5ºC.
Once the required temperature is selected, the LED display will temporarily flash for 5 seconds,
it then reverts back to the normal display, and the temperature is now set.
This button is used to toggle between the different light functions. When selected, the relevant
symbol will illuminate:
The internal light will switch on when the door is opened, and off when the door is closed.
The internal light is continuously on. However after 3 minutes the light will dim.
The internal light will remain on for 10 minutes once the door is closed and then turn off.
This symbol indicates the brightness adjuster: Hold the light key for 3 seconds until
flashes. Then use the and keys to adjust the brightness of the internal light.
CONTROL PANEL AND OPERATION
The cooling symbol will illuminate to show when the wine cabinet is currently cooling.
The alarm symbol will illuminate to show the alarm is on. This will activate when either
the door has been left open for a long period of time, or the temperature has fluctuated
too high or low (HI or LO will also show in display to confirm this).
TOUCH CONTROL KEYS AND SYMBOLS
This button is used to toggle between the different operational functions. When selected, the
relevant symbol will illuminate:
Standard mode - Select this function to operate the wine cabinet in standard mode.
ECO mode - An energy saving mode where both the inner light and control panel
lights are off (except the indicator). The LED display is also switched off, until you
change the temperature using the and keys, this will be displayed for 5
seconds and then switch off again. The compressor is also delayed 5 minutes in order
to save energy.
Intelligent mode - In intelligent mode, the wine cabinet will adjust the fan speed
according to the ambient temperature. This will reduce noise levels and save energy.
DEMO mode - When DEMO mode is selected, the compressor and PTC heater will be
disabled, and the fan input voltage reduces to 9V. The HI/LO temperature alarm is
also disabled during DEMO mode.
Note: Press and hold and for 3 seconds, to change the display from ºC to ºF.
To switch the appliance on/off .
Press and hold this button for approximately 1 second to turn the appliance on.
Press and hold this button for approximately 3 seconds to turn the appliance off.
To turn the lock function on/off.
Press and hold this button for approximately 3 seconds to activate/deactivate.
When activated, the symbol will illuminate.
Press this button to raise the temperature in 1ºC increments. The highest temperature is 18ºC.
Once the required temperature is selected, the LED display will temporarily flash for 5 seconds,
then reverts back to the normal display, and the temperature is now set.
Press this button to lower the temperature in 1ºC increments. The lowest temperature is 5ºC.
Once the required temperature is selected, the LED display will temporarily flash for 5 seconds,
it then reverts back to the normal display, and the temperature is now set.
This button is used to toggle between the different light functions. When selected, the relevant
symbol will illuminate:
The internal light will switch on when the door is opened, and off when the door is closed.
The internal light is continuously on. However after 3 minutes the light will dim.
The internal light will remain on for 10 minutes once the door is closed and then turn off.
This symbol indicates the brightness adjuster: Hold the light key for 3 seconds until
flashes. Then use the and keys to adjust the brightness of the internal light.
CONTROL PANEL AND OPERATION
The cooling symbol will illuminate to show when the wine cabinet is currently cooling.
The alarm symbol will illuminate to show the alarm is on. This will activate when either
the door has been left open for a long period of time, or the temperature has fluctuated
too high or low (HI or LO will also show in display to confirm this).
TOUCH CONTROL KEYS AND SYMBOLS
This button is used to toggle between the different operational functions. When selected, the
relevant symbol will illuminate:
Standard mode - Select this function to operate the wine cabinet in standard mode.
ECO mode - An energy saving mode where both the inner light and control panel
lights are off (except the indicator). The LED display is also switched off, until you
change the temperature using the and keys, this will be displayed for 5
seconds and then switch off again. The compressor is also delayed 5 minutes in order
to save energy.
Intelligent mode - In intelligent mode, the wine cabinet will adjust the fan speed
according to the ambient temperature. This will reduce noise levels and save energy.
DEMO mode - When DEMO mode is selected, the compressor and PTC heater will be
disabled, and the fan input voltage reduces to 9V. The HI/LO temperature alarm is
also disabled during DEMO mode.
Note: Press and hold and for 3 seconds, to change the display from ºC to ºF.
To switch the appliance on/off .
Press and hold this button for approximately 1 second to turn the appliance on.
Press and hold this button for approximately 3 seconds to turn the appliance off.
To turn the lock function on/off.
Press and hold this button for approximately 3 seconds to activate/deactivate.
When activated, the symbol will illuminate.
Press this button to raise the temperature in 1ºC increments. The highest temperature is 18ºC.
Once the required temperature is selected, the LED display will temporarily flash for 5 seconds,
then reverts back to the normal display, and the temperature is now set.
Press this button to lower the temperature in 1ºC increments. The lowest temperature is 5ºC.
Once the required temperature is selected, the LED display will temporarily flash for 5 seconds,
it then reverts back to the normal display, and the temperature is now set.
This button is used to toggle between the different light functions. When selected, the relevant
symbol will illuminate:
The internal light will switch on when the door is opened, and off when the door is closed.
The internal light is continuously on. However after 3 minutes the light will dim.
The internal light will remain on for 10 minutes once the door is closed and then turn off.
This symbol indicates the brightness adjuster: Hold the light key for 3 seconds until
flashes. Then use the and keys to adjust the brightness of the internal light.
CONTROL PANEL AND OPERATION
The cooling symbol will illuminate to show when the wine cabinet is currently cooling.
The alarm symbol will illuminate to show the alarm is on. This will activate when either
the door has been left open for a long period of time, or the temperature has fluctuated
too high or low (HI or LO will also show in display to confirm this).
TOUCH CONTROL KEYS AND SYMBOLS
This button is used to toggle between the different operational functions. When selected, the
relevant symbol will illuminate:
Standard mode - Select this function to operate the wine cabinet in standard mode.
ECO mode - An energy saving mode where both the inner light and control panel
lights are off (except the indicator). The LED display is also switched off, until you
change the temperature using the and keys, this will be displayed for 5
seconds and then switch off again. The compressor is also delayed 5 minutes in order
to save energy.
Intelligent mode - In intelligent mode, the wine cabinet will adjust the fan speed
according to the ambient temperature. This will reduce noise levels and save energy.
DEMO mode - When DEMO mode is selected, the compressor and PTC heater will be
disabled, and the fan input voltage reduces to 9V. The HI/LO temperature alarm is
also disabled during DEMO mode.
Note: Press and hold and for 3 seconds, to change the display from ºC to ºF.
To switch the appliance on/off .
Press and hold this button for approximately 1 second to turn the appliance on.
Press and hold this button for approximately 3 seconds to turn the appliance off.
To turn the lock function on/off.
Press and hold this button for approximately 3 seconds to activate/deactivate.
When activated, the symbol will illuminate.
Press this button to raise the temperature in 1ºC increments. The highest temperature is 18ºC.
Once the required temperature is selected, the LED display will temporarily flash for 5 seconds,
then reverts back to the normal display, and the temperature is now set.
Press this button to lower the temperature in 1ºC increments. The lowest temperature is 5ºC.
Once the required temperature is selected, the LED display will temporarily flash for 5 seconds,
it then reverts back to the normal display, and the temperature is now set.
This button is used to toggle between the different light functions. When selected, the relevant
symbol will illuminate:
The internal light will switch on when the door is opened, and off when the door is closed.
The internal light is continuously on. However after 3 minutes the light will dim.
The internal light will remain on for 10 minutes once the door is closed and then turn off.
This symbol indicates the brightness adjuster: Hold the light key for 3 seconds until
flashes. Then use the and keys to adjust the brightness of the internal light.
CONTROL PANEL AND OPERATION
The cooling symbol will illuminate to show when the wine cabinet is currently cooling.
The alarm symbol will illuminate to show the alarm is on. This will activate when either
the door has been left open for a long period of time, or the temperature has fluctuated
too high or low (HI or LO will also show in display to confirm this).
TOUCH CONTROL KEYS AND SYMBOLS
This button is used to toggle between the different operational functions. When selected, the
relevant symbol will illuminate:
Standard mode - Select this function to operate the wine cabinet in standard mode.
ECO mode - An energy saving mode where both the inner light and control panel
lights are off (except the indicator). The LED display is also switched off, until you
change the temperature using the and keys, this will be displayed for 5
seconds and then switch off again. The compressor is also delayed 5 minutes in order
to save energy.
Intelligent mode - In intelligent mode, the wine cabinet will adjust the fan speed
according to the ambient temperature. This will reduce noise levels and save energy.
DEMO mode - When DEMO mode is selected, the compressor and PTC heater will be
disabled, and the fan input voltage reduces to 9V. The HI/LO temperature alarm is
also disabled during DEMO mode.
Note: Press and hold and for 3 seconds, to change the display from ºC to ºF.
To switch the appliance on/off .
Press and hold this button for approximately 1 second to turn the appliance on.
Press and hold this button for approximately 3 seconds to turn the appliance off.
To turn the lock function on/off.
Press and hold this button for approximately 3 seconds to activate/deactivate.
When activated, the symbol will illuminate.
Press this button to raise the temperature in 1ºC increments. The highest temperature is 18ºC.
Once the required temperature is selected, the LED display will temporarily flash for 5 seconds,
then reverts back to the normal display, and the temperature is now set.
Press this button to lower the temperature in 1ºC increments. The lowest temperature is 5ºC.
Once the required temperature is selected, the LED display will temporarily flash for 5 seconds,
it then reverts back to the normal display, and the temperature is now set.
This button is used to toggle between the different light functions. When selected, the relevant
symbol will illuminate:
The internal light will switch on when the door is opened, and off when the door is closed.
The internal light is continuously on. However after 3 minutes the light will dim.
The internal light will remain on for 10 minutes once the door is closed and then turn off.
This symbol indicates the brightness adjuster: Hold the light key for 3 seconds until
flashes. Then use the and keys to adjust the brightness of the internal light.
CONTROL PANEL AND OPERATION
The cooling symbol will illuminate to show when the wine cabinet is currently cooling.
The alarm symbol will illuminate to show the alarm is on. This will activate when either
the door has been left open for a long period of time, or the temperature has fluctuated
too high or low (HI or LO will also show in display to confirm this).
CONTROL PANEL AND OPERATION
TOUCH CONTROL KEYS AND SYMBOLS
This button is used to toggle between the different operational functions. When selected, the
relevant symbol will illuminate:
Standard mode - Select this function to operate the wine cabinet in standard mode.
ECO mode - An energy saving mode where both the inner light and control panel
lights are off (except the indicator). The LED display is also switched off, until you
change the temperature using the and keys, this will be displayed for 5
seconds and then switch off again. The compressor is also delayed 5 minutes in order
to save energy.
Intelligent mode - In intelligent mode, the wine cabinet will adjust the fan speed
according to the ambient temperature. This will reduce noise levels and save energy.
DEMO mode - When DEMO mode is selected, the compressor and PTC heater will be
disabled, and the fan input voltage reduces to 9V. The HI/LO temperature alarm is
also disabled during DEMO mode.
Note: Press and hold the keys for 3 seconds, to change the display from ºC to ºF.
To switch the appliance on/off .
Press and hold this button for approximately 1 second to turn the appliance on.
Press and hold this button for approximately 3 seconds to turn the appliance off.
To turn the lock function on/off.
Press and hold this button for approximately 3 seconds to activate/deactivate.
When activated, the symbol will illuminate.
Press this button to raise the temperature in 1ºC increments. Once the temperature reaches
the highest temperature value for the upper or lower zone, it will revert back to its lowest
temperature value.
Upper zone = 5-10ºC
Lower zone = 10-18ºC
Once the required temperature is selected, the LED display will temporarily flash for 5
seconds, then reverts back to the normal display, and the temperature is now set.
This button is used to toggle between the different light functions. When selected, the relevant
symbol will illuminate:
The internal light will switch on when the door is opened, and off when the door is closed.
The internal light is continuously on. However after 3 minutes the light will dim.
The internal light will remain on for 10 minutes once the door is closed and then turn off.
for 3 seconds until
This symbol indicates the brightness adjuster: Hold the light key
flashes. Then use the right hand side keys to adjust the brightness of the internal light.
The cooling symbol will illuminate to show when the wine cabinet is currently cooling.
The alarm symbol will illuminate to show the alarm is on. This will activate when either
the door has been left open for a long period of time, or the temperature has fluctuated
too high or low (HI or LO will also show in display to confirm this).
CONTROL PANEL AND OPERATION
TOUCH CONTROL KEYS AND SYMBOLS
This button is used to toggle between the different operational functions. When selected, the
relevant symbol will illuminate:
Standard mode - Select this function to operate the wine cabinet in standard mode.
ECO mode - An energy saving mode where both the inner light and control panel
lights are off (except the indicator). The LED display is also switched off, until you
change the temperature using the and keys, this will be displayed for 5
seconds and then switch off again. The compressor is also delayed 5 minutes in order
to save energy.
Intelligent mode - In intelligent mode, the wine cabinet will adjust the fan speed
according to the ambient temperature. This will reduce noise levels and save energy.
DEMO mode - When DEMO mode is selected, the compressor and PTC heater will be
disabled, and the fan input voltage reduces to 9V. The HI/LO temperature alarm is
also disabled during DEMO mode.
Note: Press and hold the keys for 3 seconds, to change the display from ºC to ºF.
To switch the appliance on/off .
Press and hold this button for approximately 1 second to turn the appliance on.
Press and hold this button for approximately 3 seconds to turn the appliance off.
To turn the lock function on/off.
Press and hold this button for approximately 3 seconds to activate/deactivate.
When activated, the symbol will illuminate.
Press this button to raise the temperature in 1ºC increments. Once the temperature reaches
the highest temperature value for the upper or lower zone, it will revert back to its lowest
temperature value.
Upper zone = 5-10ºC
Lower zone = 10-18ºC
Once the required temperature is selected, the LED display will temporarily flash for 5
seconds, then reverts back to the normal display, and the temperature is now set.
This button is used to toggle between the different light functions. When selected, the relevant
symbol will illuminate:
The internal light will switch on when the door is opened, and off when the door is closed.
The internal light is continuously on. However after 3 minutes the light will dim.
The internal light will remain on for 10 minutes once the door is closed and then turn off.
for 3 seconds until
This symbol indicates the brightness adjuster: Hold the light key
flashes. Then use the right hand side keys to adjust the brightness of the internal light.
The cooling symbol will illuminate to show when the wine cabinet is currently cooling.
The alarm symbol will illuminate to show the alarm is on. This will activate when either
the door has been left open for a long period of time, or the temperature has fluctuated
too high or low (HI or LO will also show in display to confirm this).
