Caple WC6100 User manual

Built-In Wine Cabinet
Instruction Manual
WC6100,
WC6100GM &
WC6100SS
Contact Caple on 0117 938 7420 for spare parts or www.caple.co.uk

Instruction manual WC6100, WC6100GM, WC6100SS
2Please keep this instruction manual for future reference
CONTENTS
Introduction 3
Warnings 4
Electrical Shock Hazard 5
Environmental Protection 7
Installation 8
Setting the Temperature 11
Shelves 12
Storage Diagram 13
Installation Instructions 14
Care and Maintenance 15
Problems / Troubleshooting 16
Temperatures 17
Caple Contact Details 20

3
Instruction manual WC6100, WC6100GM, WC6100SSPlease keep this instruction manual for future reference
INTRODUCTION
Thank you for buying your new Caple Wine Cabinet.
To ensure that you get the best results from your new purchase, we strongly suggest that you read
this instruction manual thoroughly before use. This manual contains installation advice, usage
instructions and other important facts about your Caple Wine Cabinet. If treated with care your
Caple Wine Cabinet will give you many years of trouble free use.

Instruction manual WC6100, WC6100GM, WC6100SS
4Please keep this instruction manual for future reference
SAFETY WARNINGS:
-To prevent damaging the door, make sure the door is
fully open when pulling shelves out of the
rail compartment.
-This appliance is not intended for use by persons
(including children) with reduced physical, sensory or
mental capabilities, or lack of experience and knowledge,
unless they have been given supervision or instruction
concerning the use of the appliance by a person
responsible for their safety.
-Children should be supervised at all times to ensure they
do not play with the appliance. The appliance must be
positioned so that the plug is accessible. Release the
electric cord and move your cabinet to its final location.
Do not move your cabinet while loaded with wine as you
may distort the body.
-The wine cabinet should be installed in a suitable place
in order to avoid touching the compressor.
-After unpacking, make sure that the appliance is in
perfect order. If you have any doubt, do not use it and
contact your retailer.
-If the supply cord is damaged, it must be replaced by
a Caple service agent or a similarly qualified person in
order to avoid a hazard.
-Keep ventilation openings, in the appliance enclosure or
built in structure, clear of obstruction.
-This appliance is intended to be used exclusively for the
storage of wine. This appliance is not suitable for the
storage of food.

5
Instruction manual WC6100, WC6100GM, WC6100SSPlease keep this instruction manual for future reference
-This product is not designed for commercial use, it is a
household appliance only.
It is not intended to be used in:
• Staff kitchen areas in shops, offices and other working
environments
• Bed and breakfast type environments
• By clients in hotels, motels and any other residential
type environments
IMPORTANT:
Caple cannot be held liable for any non compliance with
these instructions.
ELECTRICAL SHOCK HAZARD
To reduce the risk of fire, electrical shock, or injury when using
your appliance, follow these basic precautions:
-Read all instructions before using the wine cabinet.
-DANGER or WARNING: Risk of child entrapment.
-Before you throw away your old wine cabinet: Take off
the door, leaving the shelves in place so that children
cannot easily climb inside.
-Never allow children to operate, play with, or crawl
inside the appliance.
-Do not use electrical appliances inside the storage
compartment of the appliance, unless they are the type
recommended by the manufacturer.

Instruction manual WC6100, WC6100GM, WC6100SS
6Please keep this instruction manual for future reference
-Never clean appliance parts with flammable fluids. The
fumes can create a fire hazard or explosion.
-Do not store or use gasoline or any other flammable
vapours and liquids in the vicinity of this or any other
appliance. The fumes can create a fire hazard or
explosion.
-The refrigerant of this appliance is R600a, flammable
and explosive articles should not be put in or near the
cabinet, to avoid the risk of fire or explosion.
-This appliance can be used by children aged from 8
years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience
and knowledge if they have been given supervision or
instruction concerning use of the appliance in a safe way
and understand the hazards involved. Children shall not
play with the appliance. Do not allow children to hang,
oull or sit on the door to avoid injuries and damage to
the appliance.
-Cleaning and user maintenance shall not be made by
children without supervision.
When positioning the appliance, ensure the supply cord
is not trapped or damaged.
-To avoid a hazard due to instability of the appliance,
it must be fixed into position in accordance with the
installation instructions. Do not locate multiple portable
socket-outlets or portable power supplies at the rear of
the appliance.
-Do not use plug adapter.
-Do not place wine bottles or other loads onto the
door when the door is open, to avoid any accidents or
damage to the appliance.

7
Instruction manual WC6100, WC6100GM, WC6100SSPlease keep this instruction manual for future reference
ENVIRONMENTAL PROTECTION
Waste electrical products should not be disposed of with household waste. Please recycle where
facilities exist. Check with your Local Authority or retailer for recycling advice. This appliance is
marked according to the European directive on Waste Electrical and Electronic Equipment (WEEE).
By ensuring this product is disposed of correctly, you will help prevent potential negative
consequences for the environment and human health, which could otherwise be caused by
inappropriate waste handling of this product. The symbol on the product indicates that this
product may not be treated as household waste. Instead it shall be handed over to the applicable
collection point for the recycling of electrical and electronic equipment. Disposal must be carried
out in accordance with local environmental regulations for waste disposal.
For more detailed information about treatment, recovery and recycling of this product, please
contact your local council, your household waste disposal service or the retailer where you
purchased the product.
CE DECLARATIONS OF CONFORMITY
This appliance has been manufactured to the strictest standards and complies with all applicable
legislation, Low Voltage Directive (LVD) and Electromagnetic Compatibility (EMC).
TECHNICAL FICHE
This appliance conforms to all current and applicable energy regulations. To view the Technical
Fiche that supports the energy labelling data, please visit the product page on our
website www.caple.co.uk
Symbol ISO 7010 W021
Warning; Risk of fire / flammable materials

Instruction manual WC6100, WC6100GM, WC6100SS
8Please keep this instruction manual for future reference
INSTALLATION WARNINGS
BEFORE USING YOUR WINE CABINET
-Remove the exterior and interior packing.
-IMPORTANT: Before connecting the wine cabinet to the power source, let it stand upright for
at least 12 hours. This will reduce the possibility of a malfunction in the cooling system from
handling during transportation.
-Clean the interior surface with lukewarm water using a soft cloth.
Before installation, turn the unit off and unplug it from the outlet.
-This appliance uses flammable refrigerant. Never damage the cooling pipework
during transportation.
-Locate the wine cooler away from direct sunlight and sources of heat (ovens, hobs, heaters,
radiators, etc.). Never clean appliance parts with flammable fluids. The fumes can create a fire
hazard or explosion. When disposing your appliance, please choose an authorized disposal site.
-Avoid locating the unit in moist areas.
-It is fitted with a power cord having an earth wire terminating in a 13amp plug.
-Ensure the product is correctly ventilated. See ‘Installation instructions’ on page 14.
-Consult a qualified electrician or service engineer if the earthing instructions are not
completely understood.
-Plug the wine cabinet into an exclusive, properly installed-grounded wall outlet. Do not under
any circumstances cut or remove the third (ground) pin from the plug. Any questions concerning
power and/or grounding should be directed toward a certified electrician or Caple service.
WARNING:
INCORRECT EARTHING CAN RESULT IN THE RISK OF ELECTRIC SHOCK

9
Instruction manual WC6100, WC6100GM, WC6100SSPlease keep this instruction manual for future reference
ATTENTION
-Store wine in sealed bottles.
-Do not overload the cabinet.
-Do not open the door unless necessary.
-Do not cover shelves with aluminium foil or any other shelf material which may prevent air
circulation.
-Should the wine cabinet be stored without use for long periods it is suggested, after careful
cleaning, to leave the door ajar to allow air to circulate inside the cabinet in order to avoid
possible formations of condensation, mould or odours.
-Keep ventilation openings, in the appliance enclosure or in the built-in structure, clear of
obstruction.
-Do not damage the refrigerant circuit.
-Do not use electrical appliances inside the storage compartments of the appliance, unless they
are the type recommended by the manufacturer.

Instruction manual WC6100, WC6100GM, WC6100SS
10 Please keep this instruction manual for future reference
OPERATING YOUR WINE CABINET AND SETTING THE
TEMPERATURE CONTROL
Please use the cabinet within a ambient temperature of 16-32 ºC. If the ambient temperature
is higher or lower than this, it will cause a temperature fluctuation in the cabinet, impairing its
performance.
CONTROL PANEL
TOUCH CONTROL KEYS
Used to switch the internal light on/off
To switch the appliance on/off
(press and hold this button for approximately 5 seconds)
Used to raise the temperature in 1ºC increments
Used to lower the temperature in 1ºC increments
INTERNAL LIGHT
Press the light button when the door is shut to turn the internal light on and off. The internal
light will automatically turn on every time the door is opened, and will turn off when the door is
shut.

11
Instruction manual WC6100, WC6100GM, WC6100SSPlease keep this instruction manual for future reference
SETTING THE TEMPERATURE
Set the desired cooling temperature by pressing the /keys. Each press of the key will scroll
through the available temperature settings in increments of 1°C.
The temperature setting can be adjusted from 5°C to 18°C. Once the desired temperature is
selected, the display will continue to flash for 5 seconds. Once it has stopped flashing, this
confirms the new temperature has been set, and the screen will now display the new
set temperature.
NOTE:
It is possible to change the display from Celsius to Fahrenheit. Press and hold /at the same
time to switch to Fahrenheit. Repeat the process to return to Celsius.
DEFROSTING/ CONDENSATION
Your wine cabinet is designed with an “Auto-cycle’ defrost system. When the cooling cycle is
OFF, the refrigerated surface of the wine cabinet (interior rear wall) defrosts automatically. The
defrosted water is channelled into a drain pan which is located at the back of the cabinet next to
the compressor from where it evaporates.

Instruction manual WC6100, WC6100GM, WC6100SS
12 Please keep this instruction manual for future reference
SHELVES
-For easy access to your wine, you must pull the shelves approximately 1/3 out of the cabinet
before inserting or removing bottles. The telescopic rail system is designed to only allow the
shelves to pull out a certain distance, to avoid the possibility of bottles falling.
-To remove the shelves from the telescopic rails, you must pull the shelf out until the holes either
side of the shelf line up with the lugs inside the wine cabinet. Once these are lined up, you can
lift the shelf off the rails, and pull out from the wine cabinet. To reinstall the shelves, you can
reverse this process, but also line up the telescopic rail supports with the holes on the bottom of
the shelf.
CAUTION
Do not store bottles crossways on the interior floor. Otherwise, bottles may fall out when the
appliance door is opened and this may cause injury or material damage.

13
Instruction manual WC6100, WC6100GM, WC6100SSPlease keep this instruction manual for future reference
STORAGE DIAGRAM
6
+
6
+
6
+
6
+
6
= 30
Stores max. 30 Bordeaux style bottles 750ml.
PLEASE NOTE:
If you wish to store other style bottles i.e champagne, the maximum storage capacity will be less
than as shown above. Shelves may also need to be removed to allow more bottles to be stored.

Instruction manual WC6100, WC6100GM, WC6100SS
14 Please keep this instruction manual for future reference
INSTALLATION INSTRUCTIONS
To install the wine cabinet, place the wine cabinet in an opening with dimensions as shown in
Fig.1. The wine cabinet must be placed on a flat stable surface.
DIMENSIONS
600mm
70mm
min 550mm
560mm
70mm
521mm
598mm
585mm
555mm
22mm
595mm
Ventilation
min 200cm² in plinth
Once the wine cabinet is in place, it can then be fixed into position. Using the 6 fixing screws,
locate these into the 6 fixing holes on either side of the wine cabinet and along the top rail, and
screw into the carcass (see Fig.2).
DIMENSIONS
FIG 1
VENTILATION:
-The ventilated cross section must be at least 200cm2 and the wine cabinet shall be ventilated
from the kitchen plinth.
-The back panel of the carcass the appliance is installed into shall be removed.
-Where the decorative grill is used it must be noted that the total area of the grill opening
corresponding to the ventilation cross section shall not be less than 200cm2.
FIG 2

15
Instruction manual WC6100, WC6100GM, WC6100SSPlease keep this instruction manual for future reference
CARE AND MAINTENANCE
CLEANING YOUR WINE CABINET
-Turn off the power, unplug the appliance, and remove all items including shelves and rack.
-Wash the inside surfaces with a warm water and baking soda solution. The solution should be
about 2 tablespoons of baking soda to a quart of water.
-Wash the shelves with a mild detergent solution.
-Wring excess water out of the sponge or cloth when cleaning area of the controls, or any
electrical parts.
-Wash the outside cabinet with warm water and mild liquid detergent. Rinse well and wipe dry
with a clean soft cloth.
POWER FAILURE
-Most power failures are corrected within a few hours and should not affect the temperature of
your appliance if you minimise the number of times the door is opened. If the power is going to
be off for a longer period of time, you need to take the proper steps to protect your contents.
HOLIDAY TIME
-Short vacations: Leave the Wine cabinet operating during vacations of less than three weeks.
-Long vacations: If the appliance will not be used for several months, remove all items and turn
off the appliance. Clean and dry the interior thoroughly. To prevent odour and mould growth,
leave the door open slightly: blocking it open if necessary.
MOVING YOUR WINE CABINET
-Remove all items.
-Securely tape down all loose items (shelves) inside your appliance.
-Tape the door shut.
-Be sure the appliance stays secure in the up right position during transportation. Also protect
outside of appliance with a blanket, or similar item.

Instruction manual WC6100, WC6100GM, WC6100SS
16 Please keep this instruction manual for future reference
PROBLEMS WITH YOUR WINE CABINET
You can solve many common wine cabinet problems easily, saving you the cost of a possible
service call. Try the suggestions below to see if you can solve the problem before calling
Caple Service.
TROUBLESHOOTING GUIDE
If the above table has not solved the problem please contact Caple Service by phone on
0117 938 7420 or by email [e-mail]
PROBLEM POSSIBLE CAUSE
The wine cabinet does not operate Not plugged in.
The appliance is turned off.
The circuit breaker tripped or a blown fuse.
The wine cabinet is not cold enough Check the temperature control setting.
External environment may require a higher setting.
The door is opened too often.
The door is not closed completely.
The door gasket does not seal properly.
The compressor turns on and off
frequently
The room temperature is hotter than normal.
A large amount of contents has been added to the wine cabinet.
The door is opened too often.
The door is not closed completely.
The temperature control is not set correctly.
The door gasket does not seal properly.
The light does not work The circuit breaker tripped or a blown fuse.
The bulb has burned out.
The light button is “OFF”.
Vibrations Check that the appliance is even
The Wine cabinet seems to make
too much noise.
The rattling noise may come from the flow of the refrigerant, which is normal.
As each cycle ends, you may hear gurgling sounds caused by the flow of
refrigerant in your wine cabinet.
Contraction and expansion of the inside walls may cause popping and crackling
noises.
The wine cabinet is not level.
The door will not close properly The wine cabinet is not level.
The gasket is dirty.
The shelves are out of position.

17
Instruction manual WC6100, WC6100GM, WC6100SSPlease keep this instruction manual for future reference
TEMPERATURES
RECOMMENDED STORAGE TEMPERATURES
For storing ALL TYPES OF WINES 12˚C to 14˚C
RECOMMENDED DRINKING TEMPERATURES
Champagne NV, Sparkling 6˚C
Champagne Vintage 10˚C
Dry White Semillon, Sauvignon Blanc 8˚C
Dry White Gewürztraminer, Riesling 10˚C
Dry White Chardonnay 10˚C
Vintage Chardonnay 14˚C
Sweet White Sauternes Monbazillac, Late Harvest ice wine 10˚C
Sweet whites vintage Sauternes 14˚C
Beaujolais 13˚C
Red Pinot Noir 16˚C
Vintage Pinot Noir red 18˚C
Red Cabernet, Merlot, French, Australian, New Zealand,
Chilean, Argentinean, Italian, Spanish, Californian 18˚C
Red Grenache, Syrah 16˚C
TEMPERATURE MEMORY FUNCTION
In the event of a power interruption, the wine cabinet can remember the previous temperature
setting, and when the power is recovered, the cabinet temperature will go back to the same
setting as when the power went off.

Instruction manual WC6100, WC6100GM, WC6100SS
18 Please keep this instruction manual for future reference
NOTES:

19
Instruction manual WC6100, WC6100GM, WC6100SSPlease keep this instruction manual for future reference
NOTES:

Caple Service
Fourth Way
Avonmouth
Bristol
BS11 8DW
T: 0117 938 1900
E: [e-mail]
www.caple.co.uk
