Caple WC6115 Manual

WC6115
Caple 60cm In-column Wine Cabinet
Technical information

New product information sheet
Product name: WC6115
Description: Caple 60cm In-column Wine Cabinet
Product code: WC6115
Features
Width 590mm
Height 885mm
Single temperature zone for red or white wine
No frost compressor cooling system
Fan circulated cool air for even temperature distribution
Quiet operation 40dB(A)
100% CFC/HFC free
Electronic temperature control and LED display
White LED interior lighting with on/off switch
Reversible door
7 wooden shelves
One piece stainless steel door frame and handle
Stainless steel fronted beech shelves
Toughened UV protected glass door
Black cabinet interior
Performance
Temperature range 4C-18C
Ambient temperature 5C-35C
Humidity range >65%RH
Capacity
2.08 Cu ft/124 Litre total net capacity
2.33 Cu ft/153 Litre total gross capacity
Max. 46 wine bottles 750ml (4 bottles per first wooden shelf,
6 bottles for another wooden shelf)

Item Part Code Description Quantity
1DG2-14 Power cord 1
2DG22-476 support bar of Water tank 2
3DG13-447 Water tank 1
DG1-77 Compressor 1
B40-120/B 1
QP2-12/B 1
5DG3-205 PCB board 1
6DG6-7 Transformer 1
7DG11-41 Condense
r
1
8DG26-136 Cabine
t
1
9DG13-268 Decorative nail 3
10 DG13-473 limiting bar (B) 1
11 DG13-472 limiting bar (A) 1
12 DG14-177 Top hinge module 1
13 DG121AEvaporato
r
1
14 DG12-6.1
A
ir-circulating pipe 1
15 DG13-7 Shelf suppor
t
1
16 DG20-1 Wire clamp 2
17 DG8-7-R Senser 1
18 DG7-3.1-BH Fan 1
19 DG22-3004
A
ir duct board 1
20 DG3-207-1-W LED LIGHT 1
21 DG13-471 Electrical box 1
22 DG13-470 lid of Electrical box 1
23 DG20-260 Display panel 1
24 DG15-179 Wooden shelves 6
25 DG15-193 Decorative bar of stainless steel 7
26 DG23-176 Doo
r
1
27 M147-005 gasket 1
28 DG22-3064 handle 1
29 DG13-3005 magnet 2
30 DG15-178 Wooden shelves 1
31 DG13-198 Senser cove
r
1
32 DG8-8 Sense
r
1
33 DG22-3003
A
ir duct board 1
WC6115 - Caple 60cm In-column Wine Cabinet
4

Item Part Code Description Quantity
WC6115 - Caple 60cm In-column Wine Cabinet
34 DG14-176 Lower hinge 1
35 DG22-3004 reed switch 1
36 DG22-3040 lid of reed switch 1
37 DG13-474 Support bar 2
38 DG22-3005 Electrical box cove
r
1
39 DG22-473 strengthening bracket 1

1
/
24
Computer Controlled Wine Cellar
WC6115
Service Manual
Here below we listed various faults while using the wine cellar, and the method of check-up and solve these
default, and find the information of the correspondent page.
Statement: (Fig.4 ) shows the reference figure Fig4
( →6.1.6 ) shows the reference item 6.1.6.
Warning: before attempting any cleaning or maintenance this unit MUST be disconnected from the
electrical supply, to prevent electrical shock
▲Preparation before maintenance
○Tools
1．Pliers 2．Phillips head screwdrivers
3．Process pipe 4．Electrical Multi meter
5．Amp meter (5A) (caliper cable type) 6．Electrical soldering iron
7．Wire strippers 8．Seal pliers
○Equipment
1．Vacuum pump 2．Soldering iron for copper pipes 3.Refrigerant meter
1. Safety rules on operation of repairing. (Rules must be
obeyed).——————————————————————— 2
2. Electrical circuit diagram. ———————————— 4
3. Cooling system diagram. —————————————— 5

2
/
24
4. Name and function on control panel. ———————— 5
5. How to diagnose the fault. （E1、E2、E3、E4） ——— 6
6. Gist on disassembly. ———————————————— 8
7. How to maintain the default. ———————————— 13
1. Safety rules on operation of repairing (Rules must be obeyed).
To avoid the accident during maintain the wine cooler, and make sure the product is safety, rules must
be obeyed list below.
○Below we list the symbols and explain the danger if ignore it.
Danger This symbol means that the instance may have the chance to suffer
death or a serious wound.
Warning This symbol means that the instance may have the chance to suffer
death or a serious wound.’
Notice This symbol means that the instance may have the chance to suffer
a wound.’
○Below symbols’ distinguish and rules should be obeyed.
This symbol means the
instance hope to be noticed
This symbol means the
instance must be done forcibly
This symbol means the
instance forbidden

3
/
24
Danger
·Please make sure to discharge the rest refrigerant in the parts.
·When discharging refrigerant, make sure that it never go to the fire place and drain
to outdoors.
Tell the customers that they never close to the discharge place and the fire is
forbidden.
·Take apart the pipe by cutter.
Never take apart the part by soldering, otherwise it will fire the rest refrigerant in the
systems and cause blast.
·Exhaust the rest refrigerant in the systems before welding.
·After filling the refrigerant the sealing should be done by using smithing welding
nozzle.
Using the welding machine will fire the refrigerant and blast.
·Since the R600a is heavier than the air, please let the R600a on the ground go
especially for the hypogeum.
·The operation on the servicing refrigerant bottle should be done in place without fire
and outdoors.
·Use the refrigerant warner please， as the rest refrigerant will cause the fire.
·Don’t use fire in the place with rest refrigerant.
·Don’t place the default compressor in indoor.

4
/
24
Danger
·During repairing, the power plug should be disconnected.
Before remove, install, replace parts disconnect the power plug.
·Attention don’t get electric shock.
When checking current, voltage or charging never touch the connectors.
When changing the parts, don’t touch the charged parts within three minutes after
disconnect the plug.
The capacitor will discharge for some time.
·Don’t damage the cooling pipe, sine the refrigerant is flammable, the damage will
cause the fire or blast.
·Don’t smoking in the service car.
·Discharge the refrigerant entirely in the place without fire before disusing the
refrigerant bottle.
·Don’t touch the wine cooler when the cooling pipe damaged, don’t fie inside the wine
cooler, keep the windows open to exchange the air.
·Disusing the default compressor should be done outdoor without fire.
·The maximum weight of the refrigerant bottle loaded in the vehicle should be comply
to stated, the bottle should be place upright, the maximum leaning angle is 40°.
·Do use the appointed part, otherwise it have chance to smoke fire or default.
·Please put the default compressor into plastic bag and seal the peristome, then pack
it with strip, as the rest compressor oil may leak in the vehicle and cause fire or blast.
·Check if all the snails, parts, wiring are install in it’s place, if the area around the
service part worsen.

5
/
24
When measuring the grounding resistance make sure that the test range is more than
1MΩ.
Make sure the power cord and plug never be pinched on rear of the wine cooler.
Exchange the power cord when it damaged.
Clean the flake of the plug when it dirty.
Notice
·Attention the hot.
The running or just stop compressor and the pipe sometimes are very hot. And the
heating or just stop heater is very hot. The hot will cause scald.
·Attention the hot parts of the pipe after the welding.
·Attention the refrigerant during charge and discharge it, as it will frostbite the skin
when touch it.
·Attention the burr.
The burr on the metal or plastic part may hurt the hand.
·Attention the fins of the evaporator.
The fins of the evaporator may hurt the hand.
·Drive up the wine cooler when moving it. Pushing it may damage the floor. Cover a
protector board on the easy damage floor.

6
/
24
2. Electrical circuit diagram.
3. Cooling system diagram.

7
/
24
4. Name and function on control panel.
•“ ” Press ‘▲’，the setting temp will raise up in 1.
•
•“ ” Press ‘▼’，the setting temp will lower down in 1.
•
•“”Press one time, the light on, press again, the light off, it is not effect by the door switch. Press it and hold
on for three seconds will enter the time adjustment. Press ‘▲’ adjust the hour, press ’▼’ adjust the minute.
•
•“”Press it one time, the power on, press it and hold on for three seconds, the power off.
•“Power” Power on/off indication light.
zThe default setting temp of this wine cooler is 12, but when restart the wine cooler after power off, it will
back to the former setting temp before power off.
zAccording to customers’ requirement, this wine cooler can be set to that the readout display actual temp
or setting temp.
a. In the readout display actual temp mode, press the ‘▲’ or ‘▼’, the systems enter the temperature
setting mode and the setting temperature twinkling. Five seconds twinkling after stopping adjust

8
/
24
temperature, the readout stop twinkling and the readout show actual temperature, the temperature
setting mode end.
b. In the readout display setting temp mode, press the ‘▲’ or ‘▼’, the systems enter the temperature
setting mode and the setting temperature twinkling. Five seconds twinkling after stopping adjust
temperature, the readout stop twinkling and the readout show setting temperature, the temperature
setting mode end.
5. How to diagnose the fault.
5.1 Fault finding by the self-check mode.
The wine cooler is controlled by computer, in order to maintain the wine cooler easily, there is a self-check
function in the control PCB.
If you suspect that the control system fault, you can star the self-check mode by following below:
1 >．Power on the wine cooler, it will beep one sound, the wine cooler star, within 10 seconds after it star, press
the ‘▲’and‘▼’at the same time and holding, three beep will sound, the systems enter self-check mode.
The power indication light on.
The readout show the actual temp.
The “Run” light on.
The LED light on.
The inner and outer fans running.
No response when touch the controlled button.
2>．If all tally with above description, the parts are normal. If any part fail, check the failed part and the
corresponding wiring and connection, if the wiring and connection is in good condition, replace the part and
check again, if it still failed, the default should be the control PCB, replace it with same model.
3 >．The self-check can be quit only disconnect the power plug.
5.2 Err code

9
/
24
Symbol Representation Checking point Solution
E1 Inner sensor open
circuit.
Check the wiring and connection between PCB and
sensor, if it open circuit.
If the connection and wiring is
normal, replace the sensor
please.
E2 Inner sensor short
circuit.
Check the wiring and connection between PCB and
sensor, if it short circuit.
If the connection and wiring is
normal, replace the sensor
E3 Anti-frost sensor open
circuit.
Check the wiring and connection between PCB and
sensor, if it open circuit.
If the connection and wiring is
normal, replace the sensor
E4 Anti-frost sensor open
circuit.
Check the wiring and connection between PCB and
sensor, if it short circuit.
If the connection and wiring is
normal, replace the sensor
A Check if any refrigerant leakage. Repair the leakage and refill.
B Check it the capillary jam Clean or replace the capillary.
HI Inner temperature too
high C Check it the inner fan run normally Repair the wiring or replace the
fan.
a Check it the inner fan run normally Repair the wiring or replace the
fan.
LO Inner temperature too
low b Check it the PCB normal. Replace the PCB.
High temperature warning—After turning on the wine cooler ten hours, if the inner temperature is over 23ºC, the readout show HI,
after it showing for one hour, the readout twinkling and the buzzer alarm, and twenty minutes later, the buzzer
stop, the compressor stop, the readout keep twinkling. The HI alarm can be stopped by disconnect the power
plug.
Low temperature warning—After turning on the wine cooler two hours, if the inner temperature is lower than 0 ºC and lasting for
15 minutes, the readout show LO, the buzzer alarm, and the compressor stop at the same time, when the inner
temperature is over 2ºC, the LO warning stop.
Remark: some models without the HI and LO warning function.
5.3 Diagnose the default
● There isn’t any display on the display PCB.
●Not cooling (the compressor stop)
Yes
Yes
If the inner light can be turn on Check the power source (power cord,
plug, socket)
If the display have power input Check the PCB circuit
Display PCB failed
No
No

10
/
24
●Not cooling (the compressor running)
6. Gist on disassembly.
Warning: Disconnect the power plug before maintain the wine cooler.
No
Yes
No
是
Yes
No
No
Yes
The
compressor run for more than 30 minutes
？
If the door opened frequently? Don’t open the door frequently
If the hot goods was put into the
cabinet?
If the door gasket airproof?
Cooling system default
?
（
Check if any gas leakage or block
）
It can be loaded with normal temperature
wine bottle
Repair or replace the gasket
No
Yes
No
No
Yes
Yes
Yes
No
If the inner light can be turn on Check the power source (power cord,
plug, socket)
Display error code? Refer to 5.2.
The starter have power input?
The protector have power input?
Check the compressor
The starter failed
The protector failed
Compressor fault

11
/
24
6.1 Gist on disassembling the inner cabinet.
6.1.1. How to remove the shelves.
Push the shelf to the end, and revolve the shelf on either side, make the stopper on the out of the
guiding rail, then pull the shelf out (Fig.1).
6.1.2. How to remove the air-duct board
The process of removing the air-duct board: Remove all shelves → Remove the air-duct board
1>；Remove the shelves, remove the screws fixing the air-duct board, remove the air-duct board, you
can see the inner air-duct board. (Fig.2& Fig.2.1)
Fig.1
Shelves

12
/
24
2>.Remove the screws fixing inner air-duct board, disconnect the connecter of the fan, and remove the
inner air-duct board, we can see the welding points around the evaporator. (Fig.3 )
A: Capillary joint B: Evaporator joint C: Evaporator D: Inner sensor connector
E: Defrost sensor
6.1.3． How to remove the evaporator
Fig.3
Fig.2 Fig.2.1
Screws
Screws
Air-duct
board
Inner
air-duct
board
A
B
C
D
E

13
/
24
The process of removing the evaporator: remove all shelves→ remove the air-duct board →
remove the inner air-duct board→ separate the evaporator from the compressor and dry filter on the
joints.
You can see the evaporator is joint to suction pipe and capillary. （Fig.3 ）Heat the joint E,G （Fig.12 ）
in the compressor room, and disconnect the pipe from compressor by using the plier. Then remove
the evaporator and capillary and suction pipe.
6.1.4. How to remove the inner fan.
The process of remove the inner fan: remove all shelves→ remove the air-duct board → remove
the inner air-duct board→ disconnect the fan connector→ remove the fan
Remove the inner fan fixing screws, remove the inner fan（Fig.4）
6.1.5. How to remove the inner sensor.
The process of remove the inner sensor: Remove the shelves→Remove the air-duct board→
Disconnect the connector→Remove the sensor cover→Remove the sensor
Remove the air-duct board (A), pull off the fixing nails(D), Take off the sensor cover (C), remove the
sensor (B). (Fig.5)
Fig.4
Screws
Inner air-duct
board
