Car Solutions PIP-RGB-HE-STD-V5 User manual

model : PI P-RGB-HE-STD-V5 pr oduct code : PI P-RG-0810-861
model : PI P-RGB-HE-STD-V5 pr oduct code : PI P-RG-0810-861
Video Interface for
Merecedes-Benz W211
User Guide
www.car-solutions.com
[email protected]
www.car-solutions.com

-. POP(Picture On Picture) Function (Only available on navigation mode)
-. Auto detection for NTSC & PA &SECOM signals.
-. Parking Guide ine function added
-. “Sync On Green” supported (Auto detection)
-. Able to change modes via mode switch
-. Able to change modes via using the original buttons
(Soldering point will be different depending on car models)
-. OSD Menu added (Controlled by Remote control)
1.1 Features
2
www.car-solutions.com
[email protected]
www.car-solutions.com

1. Input Spec. (MU TI VIDEO INTERFACE)
-. 3 x AV Input (External video source).
-. 1 x CVBS (REAR CAMERA) Input (Rear camera source)
-. 1 x Analog RGB Input (Car commander original monitor output)
-. 1 x Analog RGB Input (Navigation System output)-OPTION
2. Output Spec.
-. 2 X CVBS OUTPUT (Video Out for installing Headrest monitor)
-. 1 x Audio OUTPUT
-. 1 X CD OUTPUT( CD Operation)
-. 4 X Audio Select Output
3. Power Spec.
- Input Power : 8VDC ~ 24VDC
- Consumption Power : 5WATT, Max
4. Switch Input mode
- NAVI/CVBS1,2 Original MUTE Function : Possible to mute each input by operating Dip S/W
- Possible to switch Input mode with remote control or toggle switch.
- Rear View Camera mode : When to sense rear gear power, be switched to Rear view
camera mode
(Impossible to switch to rear mode with Toggle S/W or the remote control)
1.2 Main Specification
3
www.car-solutions.com
[email protected]
www.car-solutions.com

4
CVBS OUT HEADREST
MONI TOR
MCU
VI DEO
CI RCUI T
VI DEO MUX
POWER
CI RCUI T
AV 1
CVBS
( Rear
Camer a)
Power I nput
( +8VDC~+24VDC)
DI P S W
Remot e Cont r ol Swi t ch f or sour ce t oggl e & REAR SENSE
Navi gat i on I nput
( Anal og RGB) CAR
I nst al l at i on
OEM LCD
DI SPLAY
AV 2
CAR SCREEN I NPUT
( CAR MAI N BOARD)
1. 3 Syst em Di agr am
AUDI O OUT
AV 3
www.car-solutions.com
[email protected]
www.car-solutions.com

1.4 Components
5
GROUND cable (14P) * 1ea
Sub-board * 1ea
FFC cable (30P) * 1ea
MODE cable * 1ea
IR cable (3P) * 1ea
(HIRCAB0001) (HARETC0001)
POWER cable (10P) * 1ea
RGB cable * 1ea AV cable * 1ea REMOTE CONTRO * 1ea
(REMOTE0001)
(HAVCAB0002)
(HNAVIC0002)
(HPOWER0005)
(HGROUN0002)
(FFCAB 0003)
(QCPASS0063)
www.car-solutions.com
[email protected]
www.car-solutions.com

MODE
ED
Power/CAN RGB(IN) AV (IN/OUT)
CD IN/OUTTEST(IR)
DIP S/W
1.4 Exterior
Dimension
Horizontal length 150mm
Vertical length 95mm
Height 21mm
6
www.car-solutions.com
[email protected]
www.car-solutions.com

1.5 Wiring diagram
FI TER
& FUSE BOX
* Power cable
AV3-Sel
AV2-Sel
AV1-Sel
NAVI Sel
CAN( )-N.C
CAN(H)-N.C
SAFE-N.C
REAR-C
ACC
GND
1m
7
www.car-solutions.com
[email protected]
www.car-solutions.com

※ON : DOWN, OFF : UP
※DI S/W Use Example
-. Use Input Mode : AV1, Navigation (RGB), Main
-. Rear Camera : When to be installed on CVBS 4
▷DIP S/W : 1  OFF
▷DIP S/W : 2  OFF
▷DIP S/W : 3  ON
▷DIP S/W : 4  ON
▷DIP S/W : 5  OFF
▷DIP S/W : 6  OFF
▷DIP S/W : 7  ON (enable CVBS4)
▷DIP S/W : 8  OFF
2.1 DI switch
8
※Please make sure to disconnect the power cable of the interface and reconnect
the power cable again to apply the dip switch setting whenever changing DIP switch.
Otherwise, DIP switch setting will not be applied.
www.car-solutions.com
[email protected]
www.car-solutions.com

*FACTORY MODE (Interface setting)
: Operated with pressing ▲ -> ▼ -> ▲ ->MENU buttons of the remote in sequence.
Dimension : 85 * 40 * 8 (mm)
(Example : PIP implementation)
2.2 Remote controller
9
www.car-solutions.com
[email protected]
www.car-solutions.com

- BRIGHTNESS
- CONTRAST
- SATURATION
- HUE
- SHARPNESS
- USER IMAGE : To choose a option
among 4 prepared color shade.
OSD
-ANGUAGE : To change the language
displaying on navigation, DVD, CMMB
OSD menu (select 1 among English or
Chinese)
- TRANS : Transparency control of the OSD
background
- H_POSITION : Horizontal movement of
the OSD window
- V_POSITION : Vertical movement of the
OSD window
UTI
- FACTORY RESET : To reset all the
values about navigation, DVD screen
to factory default.
(NOT available for reset of the
position value of images, only for
functions inside OSD menu)
Analog RGB
Video
Analog RGB
Video
Analog RGB
Video
2.3 OSD (On Screen Display)
10
www.car-solutions.com
[email protected]
www.car-solutions.com

PARK
- PARK ENAB E
- H-POSITION
- V-POSITION
· Factory Mode
- Operated with pressing ▲ -> ▼ -> ▲ ->MENU buttons of the remote in sequence.
2.3 OSD (On Screen Display)
UTI
- BUTTON : Car Model Setting for using Navi button
(Refer to the next page for details)
- FACTORY RESET : Initializing
11
www.car-solutions.com
[email protected]
www.car-solutions.com

※This setting needed with wire soldering, if want to use Navi button for switching AV
sources. (Refer to the next page for further details.)
2.3 OSD (On Screen Display)
12
www.car-solutions.com
[email protected]
www.car-solutions.com

①
②
* Factory Default : DISP AY - DISAB E
① When the car gear is in reverse, Enter to
the Factory mode by ▲ → ▼ → ▲
→MENU button of remote control.
Then, the left image will be displayed on
the screen.
②Set “PARK ENAB E” to “ON” on the park
mode, then the line will be displayed as
shown left.
* If you would like to remove this line, just
select “Off” on the above process.
2.4 arking guide line
13
www.car-solutions.com
[email protected]
www.car-solutions.com

③
④
③Can move the line with H-Position
on the factory mode.
④Can move the line with V-Position
on the factory mode.
2.4 arking guide line
14
www.car-solutions.com
[email protected]
www.car-solutions.com

Ignition key should be taken off before starting installation, interface power connection must be the last step
in installation.
Power cable should be separated when connecting interface.
Should be no any electronic devices or magnetic pole around installation place.
All steps of installation should be done by well-trained specialist.
Dismantling without manufacturer’s permission can not be guaranteed, (No permission to break attached
label on the board.)
Kindly check all parts are in the box, when receiving the product, if anything missing, inform to the supplier or
manufacturer.
According to our sales policy, any problems caused by user’s mistake, careless can not be guaranteed.
It may not work on a camera with 12V
3.1 Cautions on installation
15
www.car-solutions.com
[email protected]
www.car-solutions.com

LED
OWER/CAN RGB(IN)
I RGB Hi-End
TEST
A/V(IN/OUT)
DI S/W MODE LCD IN/OUT
Control Box
•If want to use Navi button, Solder
gray wire of offered LCD cable to
appointed point inside Head Unit.
- Applicable models : Cayenne
05~08 year, W164US, W211, heaton)
MONITOR
Offered
FFC
Original
FFC
3.2 Installation diagram
16
R DATA ( r ed) G DATA ( gr een) B DATA (bl ue)
N. C
SYNC ( whi t e)
GND ( bl ack)
N. C
VIDEO
AUDIO R
AUDIO
REAR C
AV1
AV2
AV3
AV/OUT
YEOW
YEOW
RED
WHITE
AV3-SEL
AV2-SEL
AV1-SEL
NAVI SEL
CAN(L)
CAN(H)
SAFE
REAE-C
GND
ACC
※lease make sure that the installation
should be carefully conducted to avoid
from the damage of a monitor by
ESD(Electrostatic discharge) and
misalignment while connecting the
module of a monitor with cables.
www.car-solutions.com
[email protected]
www.car-solutions.com

◎Solder the gray wire on Ground cable which is
connecting sub board with main board to the Head
Unit as shown above.
*Soldering point: 5th Pin from right
*Original button : NAVI
3.3 Soldering oint
17
www.car-solutions.com
[email protected]
www.car-solutions.com

Q. I can not switch A/V sources.
A. Check IR or Ground cable connection. Check ED lamps in the interface, if it is not on, check power cable.
Q. All I got on the screen is black.
A. Check second ED lamp of the interface is on, if not, check A/V sources connected are working well.
(Second lamp indicates AV sources connected works well.) Check interface connection has been done well.
Q. Displayed image color is not proper. (too dim or not suitable color)
A. Try to select “INITIA ” in OSD menu, if it does not work, inform the manufacturer.)
Q. Rear camera image does NOT appear.
A. Set DIP switch #7 in “ON”
Q. Unwanted A/V mode is displayed. (A/V source switching order : OEM->RGB->AV1->AV2->AV3)
A. Check DIP Switch Setting.
Q. OEM image is not displayed.
A. Check interface’s CD In/Out cable connection. If the status keeps on, inform the manufacturer.
Q. Screen only displays white like left picture.
A. Check CD out cable is connected well, if this status keeps, inform the manufacturer.
4. Troubleshooting
