Caraudio-Systems r.LiNK-Interface User manual

Version 08.05.2018 RL-CCC-PNP
r.LiNK-Interface
RL-CCC-PNP
Interface for activation of
factory rear-view camera input
compatible with BMW vehicles with
Professional CCC navigation systems
and factory PDC behind
Full version with Quadlock plug and play harness.

Version 08.05.2018RL-CCC-PNP
Page1"
Contents
1. Prior to installation
1.1. Delivery contents
1.2. Check compatibility of vehicle and accessories
2. Installation
2.1. Assignment of the female 12pin connector of harness RLC-CX011
2.2. Assignment of the harness PNP-QUAD01
2.3. Connection of the RLC-CX011 and PNP-QUAD01 harness
2.4. Camera video connection
2.5. Coding of rear-view camera
2.5.1. Reversing the coding of rear-view camera
2.6. Picture settings
3. Mode of operation
4. Specification
5. Technical Support
Legal Information
By law, watching moving pictures while driving is prohibited, the driver must not be
distracted. We do not accept any liability for material damage or personal injury resulting,
directly or indirectly, from installation or operation of this product. This product should only
be used while standing or to display fixed menus or rear-view-camera video when the
vehicle is moving, for example the MP3 menu for DVD upgrades.
Changes/updates of the vehicle’s software can cause malfunctions of the interface. We
offer free software-updates for our interfaces for one year after purchase. To receive a free
update, the interface must be sent in at own cost. Labor cost for and other expenses
involved with the software-updates will not be refunded.

Version 08.05.2018RL-CCC-PNP
Page2"
1. Prior to installation
Read the manual prior to installation. Technical knowledge is necessary for installation. The
place of installation must be free of moisture and away from heat sources.
1.1. Delivery contents
1.2. Check compatibility of vehicle and accessories
Take down the SW-version and HW-version of the interface boxes, and store this
manual for support purposes.
Requirements
Vehicle ONLY! BMW X5 (E70), X6 (E71)
Navigation Professional CCC with factory PDC behind
Installed interface xxxLOGiC interface
Limitations
Factory-TV-tuner Optionally available Video switch-box SW-V2X1-MQS is necessary
to connect.
Factory-PDC The picture of the after-market rear-view camera can only be
displayed in full-screen mode. The optical PDC will not be
displayed, the acoustical PDC is still available .
Harness
RLC-CX011
Interface-box
RLC-CX431
HW_____ SW_____
Harness
PNP-QUAD01
Adapter
CAB-TVAS40

Version 08.05.2018RL-CCC-PNP
Page3"
2. Installation
Switch off ignition and disconnect the vehicle’s battery! If according to factory rules
disconnecting the battery has to be avoided, it is usually sufficient to put the vehicle in
sleep-mode. In case the sleep-mode does not show success, disconnect the battery with a
resistor lead.
2.1. Assignment of the female12-pin connector of harness RLC-CX011
Cable colour
Assignment
Pin 1 ● pink
+12V ACC (output) max.1.5A
Pin 2 ● blue
CAN-LOW (input)
Pin 6 ● red
+12V Permanent (input)
Pin 8 ● yellow
CAN-HIGH (input)
Pin 9 ● green
Reverse gear (output) max. 1.5A
Pin 12 ● black
Ground
2.2. Assignment of the harness PNP-QUAD01
Cable colour
Assignment
● blue
CAN-LOW (output)
● yellow
CAN-HIGH (output)
● red
+12V Permanent (output)
● black
Ground
● green
No function
2.3. Connection of the RLC-CX011 and PNP-QUAD01 harness
Connect together the following loose wires of the RLC-CX011 and PNP-QUAD01 harnesses:
yellow with yellow, blue with blue, black with black and red with red.
Connect the loose green wire on the RLC-CX011 harness to the power supply wire of the rear
view camera.

Version 08.05.2018RL-CCC-PNP
Page4"
2.4. Camera video connection
Pin-assignment quadlock connector / CAB-TVAS40
No liability for vehicle wire colors and pin definition! Possible changes by the vehicle
manufacturer. The given information must be verified by the installer.
2.5. Coding of rear-view camera
Press button “menu” while in main menu of the CCC for 5 seconds to code the navigation to
rear-view camera.
2.5.1. Reversing the coding of rear-view camera
The above described coding of rear-view camera can be reversed by pressing the button
“menu” for 5 seconds while in main menu of the CCC.
2.6. Picture settings
For an acceptable display of the rear-view camera video the PDC function (optical) must be
set to OFF and camera function set to ON in the submenu of the CCC.
(Menu: Settings > Vehicle tires > Shunting Help > Image combinations)
3. Mode of operation
After engaging the reverse gear the rear-view camera will be displayed on the monitor
automatically. It remains on display until the vehicle reaches a speed of 20km / h. The rear
view camera can also be switched on or off manually by the PDC button. Even if the video of
the rear-view camera is visible, the acoustic warning signals of the factory parking sensors
are active.
Assignment
Pin number
● Red (Video signal)
Pin 4 (Chamber A)
● Black (Video ground)
Pin 2 (Chamber A)

Version 08.05.2018RL-CCC-PNP
Page5"
4. Specifications
Operation voltage 10.5 – 14.8V
Stand-by power drain <1mA
Operation power drain ~50mA
Power consumption 0.07-40W
Temperature range -30°C till +80°C
Weight 38g
Measurements (box only) W x H x D 71 x 22 x 50 mm
5. Technical Support
Caraudio-Systems Vertriebs GmbH
manufacturer/distribution
In den Fuchslöchern 3
D-67240 Bobenheim-Roxheim
email [e-mail]
