USER MANUAL
PRODUCT CODE WA02010035
Scan me on your
phone camera
to watch our
assembly video.

PRODUCT CODE WA02010035
2
Visually impaired users can view this manual in PDF
format at the following URL:
www.careco.co.uk
INTRODUCTION
The Endeavour 2.0 is the ideal partner for users on the go and users who want to stay active.
A convenient collapsible aluminium frame and a feather-light 6.6kg carry weight make this
rollator the go-to reliable aid for both indoor and outdoor use.
Due to CareCo’s commitment to continuous product improvement, product information and
designs are subject to change without notice. No claims can be made based on the data or
illustrations in this user manual.
READ BEFORE USE:
Before you begin using your rollator, please ensure you, and any persons that may assist
you in its use, take the time to read, understand and follow the instructions given within this
manual carefully. We recommend that you keep this user manual in a safe place for future
reference.
If you have any questions about wheelchair use, maintenance, or safety,
please contact CareCo:
CareCo (UK) Limited, 1 Turing Court, Tel: [phone]
Great Notley, Braintree , CM77 7AT, www.CareCo.co.uk
Thank you for choosing CareCo.

3
SAFETY INSTRUCTIONS
• Only use the rollator for its intended use, incorrect use can lead to
hazardous situations.
• Only use the rollator on even and solid surfaces
• Do not overll the product bag – Maximum load 5KG
• Prolonged exposure to hot or cold temperatures can cause parts of the
rollator to become hot or cold.
• Do not use the rollator as a transportation device
• Replace damaged or signicantly worn parts if and when required.
• Periodically test the brakes to ensure safe use.
• Do not sit on the rollator when on an incline or uneven ground
Need help with assembly?
We’ve put together a step-by-step assembly guide to help
you get your product set up safely and correctly. Just scan
the QR code with your phone camera to play the video.

PRODUCT CODE WA02010035
4
PARTS DESCRIPTION
1. Height Adjustable Handle
2. Backrest
3. Seat
4. Bag
5. Front Wheel
6. Rear Wheel
MAXIMUM WEIGHT CAPACITY: 136 KG
MAXIMUM CARRY BAG LOAD: 5 KG
4
1
2
3
5
6

5
UNPACKING
Remove all outer packaging before placing components on a level surface.
Contact CareCo immediately if any parts are missing from the product box.
ASSEMBLY
Insert the front wheel assembly into the base of the front frame.
Secure using 2x C-Clips provided.

PRODUCT CODE WA02010035
6
Insert the rear wheel assembly into the base of the rear frame.
Secure the assembly to the desired height option by pressing and locating the
button spring clip.
Repeat on the other side.
Place the rollator upright on its wheels
Insert the handle into the top of the frame.
Secure the handle to the desired height option using the provided star knob.
Repeat on the other side.

7
Locate the brake cable into the “S” Clip to secure to the frame.
Repeat on the other side.
Attach the backrest to the frame by pressing and locating the button spring
clips into the bracket.
DISASSEMBLY
Reverse the assembly instructions and use them as a guide to disassemble the rollator.

PRODUCT CODE WA02010035
8
HANDLE HEIGHT ADJUSTMENT
Loosen the star knob by turning it
anticlockwise.
Remove the star knob from the handle
bracket.
Lift or lower handle to the desired height.
Reinsert the star knob into the handle
bracket.
Tighten the star knob by turning it clockwise.
Repeat on the opposite side
To set the correct handle height, stand
upright behind the rollator with arms by
side.
Adjust the height of the hand grips so they
are level with the users’ wrists.
Ensure both handles are level before using the rollator.
APPLYING THE BRAKES
Stopping
Gradually squeeze both brake levers to stop
the rollator.
Release the brake levers to start moving again.

9
Turning
Squeeze the left and right brake levers individually to rotate the rollator.
Release the brake lever to stop rotating.
Locking
Push both brake levers downwards to apply
the brake lock.
An audible “click” will conrm the brakes are
secure.
Unlocking
Pull both brake levers upwards to unlock the
brakes.
Ensure the rollator is stationary when locking the brakes.
Regularly test the brakes to ensure they function correctly.

PRODUCT CODE WA02010035
10
FOLDING
Push both brake levers downwards to apply the brake lock.
Lift the backrest upwards to fold the backrest.
Lift the seat upwards to reveal the support bar.
Pull the support bar upwards to fold the rollator.

11
UNFOLDING
Unfold the backrest.
Push downwards on the seat to open the rollator.
Pull both brake levers upwards to unlock the brakes.

PRODUCT CODE WA02010035
12
BACKREST
Attaching & Removing the backrest
Secure the backrest to the frame by
pressing and locating the button spring
clips into the bracket. Remove the
backrest by pressing the button spring
clips and pulling the backrest upwards.
Ensure the backrest is secure before using the rollator as a seat.
Folding
Raise the backrest to fold.
Unfolding
Lower the backrest to unfold.

13
SEAT
The seat height can be adjusted by raising or lowering the wheel assemblies.
Place the rollator upright on its wheels
Push both brake levers downwards to apply the brake lock.
Remove the C-Clips from the front frame
Adjust the front wheel assembly to the desired height
Secure using the C-Clips
Press and locate the rear wheel assembly spring clip to the desired height - repeat on the
opposite side.
Ensure all wheels touch the oor to conrm they are at the same height.
Pull both brake levers upwards to unlock the brakes.
SITTING
Ensure the rollator is on a at and even surface and the locking brakes are applied.
Do not use the product as a transportation device.
HANDLING & TRANSPORTING
Carry the rollator using the rubber handles and/or areas of the frame that are clear of pinch
points.

PRODUCT CODE WA02010035
14
ACCESSORIES
WALKING STICK / CANE HOLDER
The rollator is equipped with a walking stick/ cane holder out of the box.
Place the walking stick/cane into the lower cup section
Secure the walking stick/ cane to the rollator frame using the velcro included.
BAG
Attaching
Lift the seat upwards to reveal the
support bar.
Loop the eight bag straps over the
frame bar and secure using the snap
on fasteners.
Removing
Lift the seat upwards to reveal the
support bar.
Undo the eight snap on fasteners and
unloop the straps from the frame.

15
CLEANING & HYGIENE
To keep the rollator in optimal condition, it should be cleaned regularly with a damp cloth
and/or mild soap. Do not use abrasive cleaners/materials.
Dry the rollator after cleaning and after use in bad weather conditions.
MAINTENANCE
By performing simple maintenance, the user can extend the life expectancy of the rollator.
• Check fasteners regularly and tighten if necessary
• Check tyre condition regularly
• Check brake functionality
• Check wheels move freely
• Check upholstery for wear
ADJUSTMENTS
BRAKE CABLE ADJUSTMENT
Diculty Level
Tools Required
The user can adjust the brake cable using
simple household tools.
Loosen the lock nut (A) by rotating it
anticlockwise.
Adjust the brake cable tension by rotating
the brake adjuster (B).
Tighten the lock nut (A) by rotating it
clockwise.
LOW Moderate High
8mm Spanner x1
10mm Spanner x1
AB

PRODUCT CODE WA02010035
16
SPECIFICATIONS
Length 62cm
Width 57cm
Height (Adjustable) 78-94cm
Seat Height 48-56cm
Seat Width 38cm
Seat Depth 24cm
Cushion Height 3.5cm
Folded Width 32cm
Folded Length 60.5cm
Folded Height 85cm
Arm to arm distance 45.5cm
Net weight 6.6kg
Gross Weight 7.6kg
Max Carry Bag Load 5kg
Rear wheel size 6 inch
Front wheel size 6 inch
Max user weight 136kg
Frame material AL.
Wheel material PVC
Handle material TPR
Suspension N/A
Bag depth 20cm
Bag width 19cm
Bag length 36cm

17
WARRANTY
If a component requires repair or replacement due to a specic manufacturing or material
defect within its warranty period, it will be repaired or replaced free of charge by CareCo.
• 1-YEAR LIMITED WARRANTY
Consumables are not covered under normal warranty circumstances unless they have clearly
suered excessive wear or damage as a direct result of a manufacturing defect. These items
include grips, tyres, and rubber accessories.
The guarantee for the rollator is not transferable.
Parts that have been previously replaced that require subsequent repair or replacement
due to manufacturing defects will be honoured for the remainder of the rollator’s warranty
period.
Parts that have been purchased by the end user after the original warranty period has
expired have a warranty period of 12 months.
CareCo is not responsible if the rollator requires repair or replacement as a direct result of:
• Changes or modications made to the product that fall outside of the manufacturer’s
specications
• The product not being serviced or maintained according to the manufacturer’s
recommendations contained in this user manual.
• Negligence, Accidental Damage, and Improper use
• Repairs attempted before CareCo have been notied
• The product being purposely damaged or mistreated
In the unlikely event that this product is recalled, CareCo will notify the user.
Please ensure that your contact information is up to date.

PRODUCT CODE WA02010035
18
RECYCLING & DISPOSAL
Disposal or recycling of the rollator should be completed through an approved distributor or
disposal facility. (Local disposal & recycling regulations may apply)
Alternatively, contact CareCo for advice on disposal.
Materials:
Packaging:
Cardboard Box, Low-density polyethylene bag,PE foam
Upholstery:
Foam, nylon fabric,sponge with PVC coating
Plastic:
Hand grip, star knob,brake house, brake lever,wheel caster, front fork,tipper,tube plugs
cane holder
Aluminium:
Mainframes, push handle, detachable leg tube,backrest tube, cross bar
Steel:
Seat tube, bearings,brake pad, brake cable

19
USAGE
This rollator is intended for users who experience diculty in walking and/or have reduced
mobility.
Unauthorized modications and/or installation of unapproved 3rd party components and
accessories are not permitted.
This rollator is suitable for indoor and outdoor use.
EXPECTED LIFETIME
The expected lifetime of this product is 10 years, provided the product is used for its intended
purpose and all maintenance and care instructions are followed.
Proper maintenance, handling with care and repairs (if necessary), will signicantly extend the
product lifetime. Improper use of the product will reduce the expected lifetime.
The expected lifetime is not related to the product warranty.
PRODUCT IDENTIFICATION
The product identication label is located on the cross-frame underneath the seat.
