CareCo BA07036 User manual

BA07036 - Deluxe Toilet Seat Raiser
How to fit:
Removal instructions:
1. Remove product from carton and read all instructions carefully before attempting
to install product.
2. To install the arms, depress push pins and insert into mounting tubes. There
will be an audible click. Ensure the push pin fully protrude through the holes in
the mounting tubes. Make sure the arms are locked in place by pulling them. To
remove arms, reverse steps.
3. Lift toilet lid and seat assembly and place rear wings of toilet seat around rim
of the toilet bowl. (Some toilet bowls may require that seat assembly should be
removed to allow proper t). In addition the front adjustment bracket must clear
the rim in order for the raised toilet seat to t securely.
4. With the raised toilet seat resting correctly on the rim, straighten and centre the
product over the toilet bowl as necessary. Turn adjusting knob clockwise to tighten
product securely in place. Hand tighten product securely in place. Hand tighten
only - use no tools, and be careful not to over-tighten, as threads on adjustment
bracket may strip.
5. Check for secure t routinely before using product. User’s weight should be
centred over toilet seat, not too far forward or too far to one side, as unit may tip.
6. If you have a style of commode where this product will not t properly, or cannot
be tightened securely as noted above, it is recommended that you
discontinue usage.
1. Rotate knob counter clockwise until seat is loose.
2. Lift front of raised toilet seat and pull forward to move.
Product Specifications (BA07036)
Seat Width 46cm
Seat Depth 42cm
Seat Height 18cm
Product Weight 2.4kg
Max User Weight 180kg / 28 stone

Caution:
Warranty:
1. Always be sure that the seat is correctly and securely locked in place before
using.
2. Be sure that the adjustment knob in front of the seat is tight at all times, thus
securing the seat to the toilet bowl.
3. This product is designed for use with the most common type of commodes. It will
not t all commode types; be sure that the unit is correctly installed, ts properly
and is stable before use.
4. On models with arm rests: The arms are for the purpose of providing assistance
when getting on and off the seat. Do not try to use the arms to support full body
weight during transfer, as this may result in failure of the unit.
Your CareCo branded product is under warranty to be free from defects in material
and workmanship for one year from date of purchase. This warranty expresses our
condence in the workmanship and materials used for our products.
In the event of a defect covered by this warranty, CareCo will, at our discretion,
replace the product or supply parts to remedy. This warranty does not cover device
failure due to owner misuse or negligence, or due to normal wear and tear. The
warranty does not extend to non-durable parts, such as rubber accessories, castors,
grips and arm pads, which are subject to normal wear and tear and require periodic
replacement.
If you have any queries please contact CareCo.
CareCo, Hubert Road, Brentwood,
Essex CM14 4JE
www.careco.co.uk
Cleaning instructions:
1. Use a non-abrasive detergent or household cleaner with warm water.
2. Rinse with warm water and wipe dry.
3. Do not use an abrasive cleaner or cloth with this product, as damage may ensue.
