Maxi Walk-Thru Gate
with Pet Door
MODEL NO: 1210
Owner’s Manual
READ ALL INSTRUCTIONS BEFORE ASSEMBLY AND USE
OF GATE. KEEP INSTRUCTIONS FOR FUTURE USE.
Carlson Pet Products, Inc.
3200 Corporate Center Drive, Suite 105
Burnsville, MN 55306-9804,USA
Phone: [phone]
Made in China
www.carlsonpetproducts.com

按排版格式此处为空面！！！

Assembly and Installation Instructions
Read and follow all instructions carefully to ensure that your Pet Gate is properly
installed. Improper installation could result in the Gate becoming unstable or dislodged
from the doorway. Please keep these instructions for your reference.
This is a Pet Gate, but when used with children the small pet door must
remain closed and securely latched.
To prevent serious injury or death, securely install gate or enclosure,
and use according to manufacturer’s instructions.
Intended for young children aged 6 to 24 months.
Check the gate regularly to see if all the hardware and mountings
are tightened.
Never use with child able to climb over or dislodge the gate or enclosure.
Never leave child unattended.
Use only with the locking/latching mechanism securely engaged.
The four wall mounting brackets must be used with this gate. If not used, the gate may
dislodge from the opening and become unstable. This gate can be used in openings
from 34 inches to 39 inches AND 49 inches to 59 inches. This gate will not work with
openings that have a width between 39 inches and 49 inches.
NOTE: If wall mounting your gate to a surface other than drywall or wood, please
contact a professional about installation.
Contact Carlson for questions and replacement parts.
For questions about the use of your pet gate, call our customer care line 952-435-1084.
Carlson Pet Products, Inc.
3200 Corporate Center Drive, Suite 105,
Burnsville, MN 55306-9804,USA.
Made in China

1
Check to make sure you have all of the parts shown:
A. Maxi Gate Main Panel
B. Maxi Gate Extension Panel
C. 4 Maxi Mounting Brackets
D. 4 Maxi Threaded Rods
E. Stabilizing Foot
F. 8 - 1” Screws (requires a Phillips/crosshead screwdriver)
G. 4 Double Ended Screws (requires a Phillips/crosshead screwdriver)
H. Paper Wall Mounting Template
A.
D.
G.
H.
E. F.
B. C.
UP

2
Assembling andInstalling Your Gate:
Step 1.
Determine the width of your doorway or opening.
For openings between 34” and 39”:
Remove and discard the protective end screws located at points X and Yin
Diagram A, then skip to Step 3.
For openings between 49” - 59” :
Proceed to Step 2.
Step 2.
Use the 4 Double Ended Screws to fasten the Extension Panel to the Main Gate Panel so
that the new gate conguration ts within your doorway or opening with 1”-5” of extra
space.
NOTE: You must use 2 sets of Double Ended Screws on top, and 2 sets of Double
Ended Screws on the bottom. See Diagram A
Diagram A

3
Step 3.
Screw in the 4 Threaded Rods into the 4 corners of the assembled gate. The Threaded
Rods do not need to be fully screwed in, nal adjustments will be made before
completing installation.
Step 4.
Use the Paper Wall Mounting Template to help you mark the exact locations to attache
the Maxi Mounting Brackets
To use the Paper Wall Mounting Template, place it against the wall with the bottom
edge of the template touching the oor. You may choose to use a level or measuring
device to ensure exact placement.
Mark the location of the screw
holes of the Mounting Brackets
through the template and onto
the wall. Then, repeat the process
on the opposing side of the
opening or doorway.
Diagram B
Diagram C
Screw Holes

4
Step 5.
Use the 8 included 1” Screws to attach the Maxi Mounting Brackets to the wall at the
locations you marked in Step 4.
NOTE: The Mounting Brackets must be orientated so that the Release Tabs are towards
the top. See Diagram D
Step 6.
Before attaching your gate to the wall, attach the plastic Stabilizing Foot to the bottom
of the gate. To do this, simply insert the Male Connection Area of the Stabilizing Foot
into the Female Connection Area of the gate frame.
Diagram D
Diagram E
Release Tabs
Female Connection Area
Male Connection Area

5
Step 7.
Connect the assembled gate to the wall by inserting the at ends of the Threaded Rods
into the semi-circle slot at the bottom of each Maxi Mounting Brackets. Adjust the
length of the threaded rods appropriately to allow for installation. After proper
insertion, the Threaded Rods will lock in place.
Step 8.
Adjust the Threaded Rods so that an equal amount of spacing is distributed between
the 4 corners.
IMPORTANT: The maximum length of the exposed threaded rods should not exceed 3
inches.
Then, using a wrench, tighten the locking nuts to lock the gate in place.
HINT: Install one side of the gate completely before attempting to install the second
side.
Diagram F
Diagram G

6
Removing the Gate From the Wall:
To release the gate from the wall, simply press down on the Release Tabs on each of the
four Maxi Mounting Brackets while lifting the Threaded Rods upwards and out of their
locked position.
Diagram H
Release Tab
Care And Maintenance
90 Days Limited Warranty:
If, during the rst 90 days after consumer purchase of the item, under
reasonable and non-commercial use and conditions of maintenance, it
fails while owned by the original purchaser because of the quality of
materials or workmanship of nish and assembly, Carlson Pet Products
will replace or repair it at Carlson’s option. PROOF OF PURCHASE
REQUIRED.
Periodically check the gate for signs of damage, wear, or missing
components.
Do not use if any part is missing, worn or damaged.
Check the gate regularly to ensure all the hardware and mountings are
tightened.
Do not use abrasive cleaners or bleach.
Clean by sponging with warm water and a mild detergent.

Replacement Parts Available
In the event of any damage or breakage, the following replacement parts
are available for order by contacting Carlson Pet Products Customer
Service.
Contact Carlson Pet Products for questions and replacement parts.
For questions about the use of your gate, call our customer care line 952-453-1084.
Carlson Pet Products.
3200 Corporate Center Drive, Suite 105
Burnsville, MN 55306-9803, USA
Made in China
1” Wall Mounting Screw
(#10001)
Double Ended Screw
(#10046)
Maxi Mounting Bracket
(#13047)
Maxi Threaded Rods
(#10048)
Stabilizing Foot
(#13049)
