CARTER-HOFFMANN WELLS KFC PACK LINE User manual

CARTER-HOFFMANN
1551 McCormick Ave, Mundelein, IL 60060
telephone: [phone]
www.carter-hoffmann.com
WELLS MANUFACTURING
265 Hobson Street, Smithville, Tennessee 37166
telephone: [phone]
www.wells-mfg.com
IMPORTANT: THIS DOCUMENT CONTAINS PROPRIETARY INFORMATION
DISSEMINATION OF THIS INFORMATION TO ANYONE OTHER THAN
AN AUTHORIZED PERSONELL IS STRICTLY PROHIBITED.
TECHNICAL CONTENT OF THIS
MANUAL IS DESIGNED FOR USE BY A QUALIFIED PROFESSIONAL ONLY.
KFC PACK LINE
ASSEMBLY INSTRUCTIONS
04/18
2M-Z20071 Rev. B

58.5”
(148.6 cm)
76.125”
(193.35 cm)
138.5 ” (351.8 cm)
106.5 ” (270.5 cm)
TABLE OF CONTENTS
SPECIFICATIONS
RECEIVING THE UNIT
RECEIVING THE UNIT 1
SPECIFICATIONS 1
TABLE IDENTIFICATION 2
ASSEMBLY PROCEDURES 3 - 15
ELECTRICAL BOX SPECIFICATIONS 16 - 18
Thank you for purchasing this
Wells Manufacturing appliance.
Proper installation, professional
operation and consistent
maintenance of this appliance
will ensure that it gives you the
very best performance and a
long, economical service life.
This manual contains the
information needed to properly
install this appliance in a
manner which will ensure its
optimum performance.
RECEIVING THE UNIT
First and foremost, each crate should be examined before signing the Bill of Lading to
report any visible damage by the trucker in transit and to account for the proper number
of crates. If there is apparent damage, arrangements should be made to le a claim
against the carrier.
1

Accessories & Hardware
Boxes shipped
with Overshelf
4 Places
1
7
8
2
3
4
5
6
9
View A
View A
Bump Bar
Mounting
Holes
Bump Bar
Mounting
Holes
KFC PACKLINE ASSEMBLY
Item Part Number Description Manufacturer
1 KFCP32 FRY DUMP TABLE CARTER-HOFFMAN
2 SL-TG4821-K KFC GRILL TABLE ASSEMBLY WELLS MANUFACTURING
3 SL-TH5332-K KFC HOT TABLE ASSEMBLY WELLS MANUFACTURING
4 SL-TC5336-K KFC COLD TABLE ASSEMBLY WELLS MANUFACTURING
5 SL-OS8929-K KFC OVER SHELF ASSEMBLY WELLS MANUFACTURING
6 KFCPL18 TOASTER END TABLE CARTER-HOFFMAN
7 KFCHS FRY TABLE OVERSHELF CARTER-HOFFMAN
8 Q3-SL011 ASSEMBLY UPPER ELECT BOX FRY WELLS MANUFACTURING
9 Q3-SL010 ASSEMBLY UPPER ELECT TOAST WELLS MANUFACTURING
TOOLS NEEDED
Electric Screwdriver
Level
Phillips Head Screw Driver
Wrench
TABLE IDENTIFICATION
2

Step 1
existing table
FRY DUMP TABLE
KFCPL32
Mounting Holes
for overshelf
Mounting Hole
for grill table
Mounting Hole
for conduit
3
Locate Fry Dump Table

Step 2
2C-Z19938; WASHER 1/4" FLAT
2X
4X
2X
2C-Z18752; LOCKNUT, ACORN, 1/4"-20, SS
2C-Z20123; 1/4"-20 X 3-1/2" PAN HEAD
ACORN NUT
BOLT
WASHER
KFC GRILL TABLE
SL-TG4821-K
(equipment not shown)
OPTIONAL
Save for later step
FASTENER PACK SL017 INCLUDES:
Secure all hardware nger tight until entire table is together.
4
Install Grill Table

Step 3
Secure all hardware nger tight until entire table is together.
5
2C-Z19938; WASHER 1/4" FLAT
2X
4X
ACORN NUT
SL-TH5332-K
HOT TABLE ASSEMBLY
BOLT
WASHERS
2X
2C-Z18752; LOCKNUT, ACORN, 1/4"-20, SS
FASTENER PACK SL018 INCLUDES:
2C-Z20123; 1/4"-20 X 3-1/2" PAN HEAD
Set each knob to 5 1/2
Install Hot Table

Step 4
NUT
WASHER
SL-TC5336-K
COLD TABLE ASSY
REMOVE STAINLINER BRACKETS
AND SAVE FOR NEXT STEP
(BOTH SIDES)
WASHER
BOLT
FASTENER PACK SL019 INCLUDES:
2C-53-0009; NUT, 1/4-20, S/S HEX LOCK
2C-Z19938; WASHER 1/4" FLAT
2X
4X
2X
2C-Z19939; 1/4"-20 X 4" PAN HEAD
Secure all hardware nger tight until entire table is together.
6
Install Cold Table

Step 5
HOT TABLE COLD TABLE
BOLT
BOLT
STAINLINER BRACKET
Q3-Z19807
STAINLINER BRACKET
NOTE: Stainliner brackets were shipped backwards for shippment
Q3-Z19807
4X
2C-Z19935; 8-32 X 1/2" PHILLIPS TRUSS HEAD
HARDWARE & STAINLINER BRACKETS ARE ALREADY INSTALLED DURING SHIPPMENT
Secure all hardware nger tight until entire table is together.
7
Re-install Stainliner Brackets

Step 6
2C-Z19938; WASHER 1/4" FLAT
5X
5X
2C-Z19942; 1/4"-20 X 2" PAN HEAD
BOLT
INSTALL THIS
BOLT FIRST
WASHER
SL-OS8929-K
OVER SHELF
FASTENER PACK SL020 INCLUDES:
Secure all hardware nger tight until entire table is together.
8
Install Overshelf

Step 7
2C-53-0009; NUT, 1/4-20, S/S HEX LOCK
2C-Z19938; WASHER 1/4" FLAT
2X
4X
2X
2C-Z19940; 1/4"-20 X 2-1/4" PAN HEAD
NUT
WASHER
WASHER
BOLT
KFCPL18
TOASTER END TABLE
FASTENER PACK SL021 INCLUDES:
Secure all hardware nger tight until entire table is together.
9
Install Toaster Table

Step 8
Secure all hardware nger tight until entire table is together.
10
2C-Z19938; WASHER 1/4" FLAT
3X
5X 3X
2X
2C-Z18752; LOCKNUT, ACORN, 1/4"-20, SS
2C-Z19941; 1/4"-20 X 3/8" PAN HEAD
SHORT BOLT
FASTENER PACK SL022 INCLUDES:
LONG
BOLT
KFCHS
FRY TABLE OVERSHELF
ACORN NUT
WASHER
2C-Z19940; 1/4"-20 Thread, 2-1/4" Length
WASHER
Install Fry Table Overshelf

Step 9
Note: Refer to electrical boxes for electrical components.
ELECTRIC BOX
Q3-SL011
BOLT
WASHER
NUT
2C-53-0009; NUT, 1/4-20, S/S HEX LOCK
2C-Z19938; WASHER 1/4" FLAT
2X
2X
2X
2C-Z20034; 1/4"-20 X 1-1/4" PAN HEAD
FASTENER PACK SL023 INCLUDES:
11
Install Electrical Box

Step 10
Note: Refer to electrical boxes for electrical components.
BOLT
Q3-SL010
WASHER
NUT
2C-53-0009; NUT, 1/4-20, S/S HEX LOCK
2C-Z19938; WASHER 1/4" FLAT
2X
2X
2X
2C-Z19942; 1/4"-20 X 2" PAN HEAD
FASTENER PACK SL024 INCLUDES:
12
Install Electrical Box

Step 11
Snub Nose Style
front holes
45° Nose Style
rear holes
Tray Slide is used
when only one
grill is needed.
Top View
of Grill Table
2C-Z3841; CABLE TIE
2X
FASTENER PACK SL025 INCLUDES:
13
Locate Star Grills and Tray Slides

Step 12
BOTTLE BRACKET
Q3-SL016
BOTTLE BRACKET
Q3-SL015
14
Install Bottle Brackets

Step 13
LEVEL
LEVEL
LEVEL
IMPORTANT: Once all tables are together, level
unit & tighten all hardware previously installed.
15
Level and Tighten

16
THIS DRAWING CONTAINS INFORMATION CONFIDENTIAL TO STAR MFG. INT'L. INC. NO REPRODUCTION OR DISCLOSURE OF ITS CONTENTS IS PERMITTED
DRDESCRIPTION OF CHANGEDATELTR
REVISIONS
TOLERANCE UNLESS NOTED:` .015 ANGLES` 1~
PART NO.
TITLE
MODEL NO.
FINISH
DATE:DR.
MATERIAL
STAR MANUFACTURING INTERNATIONAL INC.
265 HOBSON STREET
SMITHVILLE, TENNESSEE 37166 U.S.A.
2M-Z19825
12/1/2014
SL-KFC
KFC PACKLINE ASSY.
mhuegerich
DETAIL A
SCALE .250
RECEPTACLES OF LOWER BOX
FACE TO SIDE AS SHOWN
HOT TABLE
TOASTER TABLE
PG. 2
A3-15-2015
ECO# 14534
REMOVED EXTRA COMPONENTS
FROM AROUND ELEC PANEL ASSY. BKB
A
A
A
THIS DRAWING CONTAINS INFORMATION CONFIDENTIAL TO STAR MFG. INT'L. INC. NO REPRODUCTION OR DISCLOSURE OF ITS CONTENTS IS PERMITTED
DRDESCRIPTION OF CHANGEDATELTR
REVISIONS
TOLERANCE UNLESS NOTED:` .015 ANGLES` 1~
PART NO.
TITLE
MODEL NO.
FINISH
DATE:DR.
MATERIAL
STAR MANUFACTURING INTERNATIONAL INC.
265 HOBSON STREET
SMITHVILLE, TENNESSEE 37166 U.S.A.
2M-Z19825
12/1/2014
SL-KFC
LOWER ELECTRICAL PANEL ASSEMBLY
mhuegerich
SPLIT TOP SANDWICH GRILL - CIRCUIT 3
120 VOLT, 30 AMP, SINGLE PHASE, 2 WIRE
NEMA L5-30R
SPLIT TOP SANDWICH GRILL - CIRCUIT 2
120 VOLT, 30 AMP, SINGLE PHASE, 2 WIRE
NEMA L5-30R
REFRIGERATORS - CIRCUIT 1
120 VOLT, 20 AMP, SINGLE PHASE, 2 WIRE
GFCI DUPLEX RECEPTACLE
PG. 1

17
THIS DRAWING CONTAINS INFORMATION CONFIDENTIAL TO STAR MFG. INT'L. INC. NO REPRODUCTION OR DISCLOSURE OF ITS CONTENTS IS PERMITTED
DRDESCRIPTION OF CHANGEDATELTR
REVISIONS
TOLERANCE UNLESS NOTED:` .015 ANGLES` 1~
PART NO.
TITLE
MODEL NO.
FINISH
DATE:DR.
MATERIAL
STAR MANUFACTURING INTERNATIONAL INC.
265 HOBSON STREET
SMITHVILLE, TENNESSEE 37166 U.S.A.
2M-Z19826
1/17/2015
SL-KFC
KFC PACKLINE ASSY.
mhuegerich
DETAIL C
SCALE .250
RECEPTACLES FACE OUT
AS SHOWN
PG. 2
B3-31-2015
ECO# 14596
PICTORIAL CHANGE TO SHOW
KNOCK-OUTS ON TOP OF BOX MH
B3-31-2015
ECO# 14596
PICTORIAL CHANGE TO SHOW
KNOCK-OUTS ON TOP OF BOX MH
C
THIS DRAWING CONTAINS INFORMATION CONFIDENTIAL TO STAR MFG. INT'L. INC. NO REPRODUCTION OR DISCLOSURE OF ITS CONTENTS IS PERMITTED
DRDESCRIPTION OF CHANGEDATELTR
REVISIONS
TOLERANCE UNLESS NOTED:` .015 ANGLES` 1~
PART NO.
TITLE
MODEL NO.
FINISH
DATE:DR.
MATERIAL
STAR MANUFACTURING INTERNATIONAL INC.
265 HOBSON STREET
SMITHVILLE, TENNESSEE 37166 U.S.A.
2M-Z19826
1/17/2015
SL-KFC
UPPER ELECRICAL BOX/COMM HOLDER
mhuegerich
MONITOR/COMMUNICATION - CIRCUIT 1
120 VOLT, 15AMP, SINGLE PHASE, 2 WIRE
ORANGE GFCI DUPLEX RECEPTACLE - GROUND ISOLATED
FRY DUMP - CIRCUIT 2
208 VOLT, 20 AMP, SINGLE PHASE, 2 WIRE
NEMA 6-20R
SIDES HOLDING CABINET - CIRCUIT 3
120 VOLT, 15 AMP, SINGLE PHASE, 2 WIRE
NEMA L6-15R
MONITOR/COMMUNICATION - CIRCUIT 4
120 VOLT, 20 AMP, SINGLE PHASE, 2 WIRE
ORANGE
GFCI DUPLEX RECEPTACLE - GROUND ISOLATED
PG. 1
A
NOTE:
BEFORE INSTALLING OUTLETS,
REMOVE FRONT PANEL AND INSTALL
ELECTRICAL BOX TO END SHELF
UPRIGHT AS SHOWN ON PG 2
USING THE FASTENERS PROVIDED

18
THIS DRAWING CONTAINS INFORMATION CONFIDENTIAL TO STAR MFG. INT'L. INC. NO REPRODUCTION OR DISCLOSURE OF ITS CONTENTS IS PERMITTED
DRDESCRIPTION OF CHANGEDATELTR
REVISIONS
TOLERANCE UNLESS NOTED:` .015 ANGLES` 1~
PART NO.
TITLE
MODEL NO.
FINISH
DATE:DR.
MATERIAL
STAR MANUFACTURING INTERNATIONAL INC.
265 HOBSON STREET
SMITHVILLE, TENNESSEE 37166 U.S.A.
2M-Z19827
1/17/2015
SL-KFC
KFC PACKLINE ASSY.
mhuegerich
DETAIL A
SCALE .188
RECEPTACLES FACE OUT
AS SHOWN
TOASTER END TABLE
PG. 2
A
A
THIS DRAWING CONTAINS INFORMATION CONFIDENTIAL TO STAR MFG. INT'L. INC. NO REPRODUCTION OR DISCLOSURE OF ITS CONTENTS IS PERMITTED
DRDESCRIPTION OF CHANGEDATELTR
REVISIONS
TOLERANCE UNLESS NOTED:` .015 ANGLES` 1~
PART NO.
TITLE
MODEL NO.
FINISH
DATE:DR.
MATERIAL
STAR MANUFACTURING INTERNATIONAL INC.
265 HOBSON STREET
SMITHVILLE, TENNESSEE 37166 U.S.A.
2M-Z19827
1/17/2015
SL-KFC
UPPER ELECTRICAL BOX - TOASTER
mhuegerich
MONITOR/COMMUNICATION - CIRCUIT 5
120 VOLT, 15 AMP, SINGLE PHASE, 2 WIRE
ORANGE GFCI DUPLEX RECEPTACLE - GROUND ISOLATED
WARMING/HOLDING UNIT - CIRCUIT 4
208 VOLT, 20 AMP, SINGLE PHASE, 2WIRE
NEMA L6-20R
BUN HOLDING CABINET - CIRCUIT 3
208 VOLT, 15 AMP, SINGLE PHASE, 2WIRE
NEMA L6-15R
CONTACT TOASTER - CIRCUIT 2
120 VOLT, 15 AMP, SINGLE PHASE, 2 WIRE
IVORY GFCI DUPLEX RECEPTACLE
MONITOR/COMMUNICATION - CIRCUIT 1
120 VOLT, 15 AMP, SINGLE PHASE, 2 WIRE
ORANGE GFCI DUPLEX RECEPTACLE - GROUND ISOLATED
PG. 1
A
B3-31-2015
ECO# 14596
PICTORIAL CHANGE TO SHOW
KNOCK-OUTS ON TOP OF BOX MH
B3-31-2015
ECO# 14596
PICTORIAL CHANGE TO SHOW
KNOCK-OUTS ON TOP OF BOX MH
