CAS Retail PR-T Series User manual

1
표지

2
CONTENTS
PRECAUTIONS.........................................................3
PREFACE, OVERALLVIEW................................5
DISPLAYAND KEYBOARD.................................6
REMOVE THE SCREW..........................................9
COLUMNINSTALLATION...................................9
OPERATION
Chapter1.BasicOperation ................................10
Chapter2. PLU Saving & Calling-up...............13
Chapter3. User' s Set-up Mode.........................15
Chapter4.Sales transaction...............................17
TECHNICALPARAMETER................................19
ERROR MESSAGE.................................................19

3
PRECAUTIONS

4
PRECAUTIONS

5
PREFACE
Thank you for purchasing your PR-T.
CAS scales are designed and produced under rigid quality control to deliver
outstanding performance, reliability and long life.
This manual will help you with the proper operation and care of your new
PR-T.
Please review the PR-T manual before you use the scale and keep it handy
for future reference.
■ The Pb battery of product may not be fully charged. It is recommended to
charge Pb battery using AC power before initial usage.
CHANGING THE PRINTER ROLL
■ Recommended size for thermal paper;
58mm (Width) / 65 m(Thickness) / 60mm (Maximum Diameter)

6
■ It is recommended to tear off the ticket left to right.

7
OVERALL VIEW

8
■ POLE TYPE INSTALLATIONS
- Insert the post pipe into a post bracket.
- Insert and fasten the display assembly screws.

9
DISPLAY
■ Front
■ Rear

10
Table 1 : Symbols on Display
SYMBOLS
DESCRIPTION
StableIndicator
Toadjustthe weighttozero.
Tare on
Inthesubtotalmode
Discountprice
Toadjustthe weighttozero.
ACPowerOn
Lowbatterywarning whenit is below residual20%
KEYPAD

11
■Function keys
KEYS
FUNCTIONS
SALES MODE
PROGRAMMODE
~
Toinputallnumerical data
Toinputdoublezero
Toclearallof numbers input on
thedisplay
Toset zero
Toset orcleartare value
To gotoprogram mode
Tocallup aPLUwith numeric
key
Toinputnon-weighed item
SHIFT:Toselectalternatekey
functions
Toshowsubtotal /total/
paymentsum
~
DirectPLUkeys
*PLUs#1~30 maybe used forboth
thedirectand indirect PLUs.Most
commonlyused30 itemsare
recommendedtobeusedfor
directPLUsforusers'convenience.
AlphabetKey(A~Zkey)
Tochangekeymap

12
REMOVE THE SCREW
Remove the crew
NOTICE：Make sure to remove thescrew before useat the first time.
COLUMN INSTALLATION
Column Installation

13

14
2. PROGRAMMING
ProgramModeMenuTree
Sale
PLU
Inventory
Tax
Tare
Delete
PLU
Tax
Tare
All
Print
Printlist
PLUlist
Taxlist
Tarelist
PrintReport
PLUreport
TaxReport
MonthlyReport
WeeklyReport
HourlyReport
PrintTotalReport
DeleteReport
TotalReport
MonthlyReport
WeeklyReport
HourlyReport
AllReport
Scale
Settings
DATE/TIME
UsePLUtare
Useinventory
Suspend
Definespeedkey
Set
Reset
Printer
Set
Header/Footer
Message
Settings
ImagePrint
UseImagePrint
TestImage
Linefeed
PrintPLUdetailsafterMakePLU
Printbill
Printintensity
Barcode
UsePLUBarcode
PLUBarcodeformat
UseTotalBarcode
TotalBarcodeformat
Test
AD
Display
Key
Printer
Battery
Memory

15
Rs232
2.1 SALE Programming
2.1.1 Create/Edit PLU
You can set 8items fora PLU asbelow table and if you do notwantto usesome
items
No
Item
Description
1
PLU No
PLU No. 1to300
2
PLUType
SelectPLUtypeamongByWeight,By Count
3
(Unit)Price
This valuecanbefrom 1to999999.
4
Item Code
Item Codecanbefrom 0to99999.(optional)
5
Tax No.
Entertaxindexnumber.Thisvaluecan befrom 0to9(optional)
6
TareNo.*
Entertareindexnumber.Thisvaluecanbefrom0to9
(optional,onlyBy-weightPLU)
7
Inventory
(optional)
8
Name
Entername1ofitem.Maximum32characters.(optional)
*Theseitemsare shown on the displaywhenyouselect ByWeightPLU.

16
Sample Create/Edit PLU Operation
Operation
Key
Display
Remark
Weight
Unit
Total
MENU
[MENU]



Enter Menu
Sale
Menu
[*]



Enter Sale Menu
PLU
menu
[*]



Enter PLU menu
PLU no.
[0]
[*]






Enter PLU No.
PLU type
[1]
[0]
[*]








.
Press [0]or[1]Key
canchangePLU type
WeighttoNon-weight.
PLU
Unit Price
[1][2][5][0]
[*]




.

Input unit price.
(Critical Item
Must be not 0)
PLU
Itemcode
[2][0][3][4]
[*]






Input Item-code for
Barcode(optional)
PLU
NAME
[A/PLU01]
[P/PLU16]
[P/PLU16]
[L/PLU12]
[E/PLU05]
[*]























When create a
PLU, PLU name is
filled with space(32)
Enter the PLU
name by Alphabet
key
PLU TAX
[1]
[2]
[*]






.
.

Input tax index
No.(optional)
#1 4.00% exclude
#2 5.00% include
PLU
TARE
[1]
[2]
[*]






.
.
.
Input tare index
No.(optional)*
PLU
Inventory
[1][0][0][0]


.
Input PLU inventory
(optional)**
PLU
menu
[*]



Move back to SALE
menu
*) Settings:USE PLUTare가NO일경우 보이지 않음
**) Settings:USE Inventory가NO일경우 보이지 않음

17

18
2.1.2 Edit Inventory
설명 추가할 것Sample Edit Inventory Operation
Operation
Key
Display
Remark
Weight
Unit
Total
MENU
[MENU]



Enter Menu
Sale Menu
[*]



Enter Sale Menu
Inventory
menu
[VOID/→]
[*]






Enter Inventory
menu*
Input PLU
No.
[1]
[*]





.
Enter PLU No.**
Edit
Inventory
value
[5][0][0][0]


.
Inputinventoryvalue
Tax Menu
[*]



Move back to
SALE menu
*)Parameter: USE Inventory가NO일경우 Dontuse 라고 표시됨
**) if PLU doesm’t exist, Display “PLU empty”

19
2.1.3 Create Tax
설명 추가 : exclude, include
SAMPLE Create/Edit Tax Operation
Operation
Key
Display
Remark
Weight
Unit
Total
MENU
[MENU]



Enter Menu
Sale Menu
[*]



Enter Sale Menu
Tax menu
[VOID/→]
[VOID/→]
[*]









Enter Tax menu
Tax No.
[1]
[*]





.
Enter tax No.
Tax value
Tax Type
[1][0][0][0]
[VOID/→]




.
.
InputTaxvalue
Press[VOID/→],[ADD]/[ ←]
key to change tax type
(‘I’ include/’E’ excluse)
Tax Menu
[*]



Move back to SALE menu
2.1.4 Create PLU Tare index
SAMPLE Create/Edit Tare Operation
Operation
Key
(e.g)
Display
Remark
Weight
Unit
Total
MENU
[MENU]



Enter Menu
Sale Menu
[*]



Enter Sale Menu
Tare menu
[VOID/→]
[VOID/→]
[VOID/→]
[*]












Enter Tare menu
Tare No.
[1]
[*]





.
Enter Tare No.
Tare
weight
[3][0][0][0]
[*]


.
InputTareweight
Tare Menu



Move back to SALE menu
Parameter: USE PLU TARE가NO일Dontuse 라고 표시

20
2.1.5 Delete sale items
SAMPLE Delete sale item Operation
Operation
Key
(e.g)
Display
Remark
Weight
Unit
Total
MENU
[MENU]



Enter Menu
Sale
Menu
[*]



Enter Sale Menu
Delete
item
menu
[VOID/→]
[VOID/→]
[VOID/→]
[VOID/→]
[*]















Enter delete item menu
Press[VOID/→],[ADD]/[ ←] key
to change items
1. PLU
2. Tax
3. Tare
4. All
[*]



Delete
item start
[1][0]
[*]






Input start PLUnumbertodelete
PLUlist
Delete
item list
No.
[2][2]



Input endPLU number todelete
PLUlist
Delete
item
[*]



Move back to Sale menu
2.2 List & Report
2.2.1 Print list
Operation
Key
(e.g)
Display
Remark
Weight
Unit
Total
MENU
[MENU]



Enter Menu
Print
Menu
[VOID/→]
[*]






Enter Print Menu
Print list
menu
[*]






Select items
1. PLU
2. Tax
3. Tare(*)
Select
Print item
no
[5]
[*]
[2][0][0]









Inputstartitem numbertoprint
list
Inputenditemnumbertoprint
list
Print
Item list
[*]



Print item list completely,
Move back to Print menu
