SERVICE MANUAL
ELECTRONIC CASH REGISTER
(without price)
130CR/PCR-262/CE-160
(EX-264)
JAN. 2005

CONTENTS
130CR/PCR-262/CE-160 Page
1. SPECIFICATIONS........................................................................................ 1
2. MACHINE INTIALIZATION .......................................................................... 3
3. BLOCK DIAGRAM....................................................................................... 4
4. DISASSEMBLY............................................................................................ 5
5. CIRCUIT EXPLANATION ............................................................................ 9
6. DIAGNOSTIC OPERATIONS .................................................................... 16
7. TROUBLESHOOTING ............................................................................... 20
8. IC DATA ..................................................................................................... 21
9. PCB LAYPUT............................................................................................. 22
10. CIRCUIT DIAGRAM ................................................................................... 23
11. PARTS LIST............................................................................................... 27

— 1 —
• CPU Name UPD780058BGC124-8BTA
Number of control bit 8 bit
Mask ROM (Built-in) 60 Kbytes
RAM (Built-in) 1024 bytes
• Printer Name M-42V-009-040
Print method Print wheel selecting type serial printer
MCBF 700,000 lines
• Roll paper Type Fine-quality paper
Size Width 57.5 ±0.5 mm
Roll diameter 80 mm or less
1. SPECIFICATIONS
1-1. Electrical specifications
120 V 220 V 230 V 240 V
• Power consumption In operation Max. 0.1 A 0.05 A 0.05 A 0.05 A
• Memory protection Back-up battery Mangan Battery (UM-3 ×3 pcs)
Back-up period 1 year (25 °C)
Battery life Replace the battery every 1 years.
• Clock & Calendar Accuracy Within ±30 sec. per month
Auto calendar Effective until 2099 A.D.
1-2. Environmental specifications
• Operating temperature 0 °C ~ 40 °C
• Operating humidity 10 % ~ 90 %
• Storage temperature -25 °C ~ 65 °C
• Storage humidity 10 % ~ 95 %
• Vibration strength 1.5 G (The machine must be in the carton box)
1-3. Main components
1-4. Drawer List
DRAWER NAME Specification NOTE
• DL-1329A (S type) D-21G2M-D54RM-16A U.S.A
• DL-1841A (S type) D-21G2M-D53RM-16A UK/Germany, Europe, Other countries
• DL-2794A (M type) D-18G2C-B84RM-13A Europe, Other countries
• DL-2796A (M type) D-18G2C-A84RM-13A Canada

— 2 —
DEVICE NAME MODEL NOTE
• Wet cover WT-80
• Roll paper P-5860 58 x 12 x 60D
1-5. Option List
CAUTION
Danger of explosion if battery is incorrectly replaced.
Replace only with the same or equivalent type
recommended by the manufacturer.
Dispose of used batteries according
to the manufacture’s instructions.
VORSICHT !
Explosionsgefahr bei unsachgemäßem Austausch der Batterie.
Ersatz nur durch denselben oder einen vom
Hersteller empfohlenen gleichwertigen Typ.
Entsorgung gebrauchter Batterien nach
Angaben des Herstellers.
ADVARSEL !
Lithiumbatteri - Eksplosionsfare ved fejlagtig hándtering.
Udskiftning má kun ske med batteri
af samme fabrikat og type.
Levér det brugte batteri tilbage til leverandØren.

— 3 —
2. MACHINE INTIALIZATION
2-1. Initialization and loading memory protection battery
Note: You must initialize the cash register and install the memory protection batteries before you can
program the cash register.
To initialize the cash register
1. Set the mode switch to OFF.
2. Plug the power cord of the cash register into an AC outlet.
3. Load the memory protection batteries.
4. Set the mode switch to REG.
To load the memory protection batteries
1. Remove the printer cover.
2. Open the battery compartment cover.
3. Load 3 new UM-3, R6P (SUM-3) or LR6 (AM-3) type batteries into the compartment.
Be sure that the plus (+) and minus (–) ends of each battery are facing in the directions indicated by
the illustrations inside the battery compartment.
4. Slide the memory protection battery compartment cover back into place.
5. Replace the printer paper and printer cover.
REPLACE MEMORY PROTECTION BATTERIES AT LEAST ONCE EVERY YEAR.
2-2. To select the date format and monetary mode (130CR only)
You can select the date format and the monetary mode after initialization depending on the requirements in your
area.
Default date format is Day/Month/Year.
Default Monetary Mode is Add 2.
Example: Change the date format to Month/Day/Year, and the monetary mode to Add 0.
1. Set the mode switch to PGM.
2. Press the following keys.
A
Date format selections
Year/Month/Day 0
Month/Day/Year 1
3
Day/Month/Year 2
B
Monetary mode selections
Add 0 (0. ) 0
Add 1 (0.0 ) 1
Add 2 (0.00 ) 2
P3 appears in mode display
SUB
TOTAL
0122 Program set code number
SUB
TOTAL
1 0 Select numbers from
lists A and B.
(To end the setting)
SUB
TOTAL
CA AMT
= TEND

— 4 —
3. BLOCK DIAGRAM
2P
2P
2P
21P
8P
8P 12P
DRAWER
PARALLEL CABLE PARALLEL CABLE
WINDER
MOTOR
TRANSFORMER
TE-264-***
E-264-1
PRINTER
M-42V
DISPLAY
KEY BOARD
BATTERY
UM-3(PZ) X3
MODE SWITCH
2P
8P

— 5 —
4. DISASSEMBLY
■ Removing the register
1. Remove the journal cover and then the WINDING PULLY and ROLL PAPER.
5. Remove the connector (CNDRW1) and then separate the main unit from the drawer.
2. Remove the battery cover and then the battery.
3. Remove the two screws.
4. Separate the main unit as shown below.
Screws
Connector
(CNDRW1)

— 6 —
■ Removing the printer unit
9. Remove one screw and then the printer unit.
■ Removing the Main PCB and Display PCB
6. Remove the three connectors (CNKEY1, CNBAT1, CNPR1) and the four screws.
7. Remove the two hooks and then Main PCB.
Connector
(CNKEY1)
Connector
(CNBAT1)
Screws
Connector
(CNPR1)
Hook
Hook
8. Remove the two hooks and then Display PCB.
Hooks
Screw

— 7 —
FPC
Hooks
Screws Screws
Spacer
Common sheet
Chassis
FPC
■ Disassembling the keyboard unit
10.Remove the FPC as well as the four screws, and then the keyboard unit.
11. Remove the two screws and then disassemble the keyboard unit.

— 8 —
Screws
Screws
■ Disassembling the drawer
1. Pull the lever and remove the coin case and bill case.
2. Remove the three screws and then the top plate.
3. Remove the three screws and the solenoid.

— 9 —
5. CIRCUIT EXPLANATION
5-1. CPU (IC3: uPD780058BGC124-8BTA)
5-1-1. Pin Assignment
P15/ANI5 1 60 RESET
P16/ANI6 2
59 P127/RTP7
P17/ANI7 3
58 P126/RTP6
AVSS 4
57 P125/RTP5
P130/ANO0 5
56 P124/RTP4
P131/ANO1 6
55 P123/RTP3
AVREF1 7
54 P122/RTP2
P70/SI2/RxD0 8
53 P121/RTP1
P71/SO2/TxD0 9
52 P120/RTP0
10 51 P37
P20/SI1
11 50 P36/BUZ
P21/SO1
12 49 P35/PCL
P22/SCK1
13 48 P34/TI2
P23/STB/TxD1
14 47 P33/TI1
P24/BUSY/RxD1
15 46 P32/TO2
P25/SI0/SB0
16 45 P31/TO1
P26/SO0/SB1
17 44 P30/TO0
P27/SCK0
18 43 P67/ASTB
P40/AD0
19 42 P66/WAIT
P41/AD1
20 41 P65/WR
P72/SCK2/ASCK
P42/ AD2
21
P14/ ANI4
P43/ AD3
22
P13/ ANI3
P44/ AD4
23
P12/ ANI2
P45/ AD5
24
P11/ ANI1
P46/ AD6
25
P10/ ANI0
P47/ AD7
26
AV REF0
P50/ A8
27
V DD0
P51/ A9
28
XT1/ P07
P52/ A10
29
XT2
30
IC (V PP )
P54/ A12
31
X1
P55/ A13
32
X2
VSS1
33
V DD1
P56/ A14
34
VSS0
P57/ A15
35
P05/ INTP5
P60
36
P04/ INTP4
P61
37
P03/ INTP3
P62
38
P02/ INTP2
P63
39
P01/ INTP1/ TI01
P64/ RD
40
80 79 78 77 76 75 74 73 72 71 70 69 68 67 66 65 64 63 62 61
P00/ INTP0/ TI00
P53/ A11

—10 —
TO0/P30 P00
P01 to P05
P07
P10 to P17
P20 to P27
P30 to P37
P40 to P47
P50 to P57
P60 to P67
P70 to P72
P120 to P127
P130, P131
RTP0/P120 to
RTP7/P127
AD0/P40 to
AD7/P47
A8/P50 to
A15/P57
Port 0
Port 1
Port 2
Port 3
Port 4
Port 5
Port 6
Port 7
Port 12
Port 13
Real-time output port
RD/P64
External access
WR/P65
WAIT/P66
ASTB/P67
RESET
X1
X2System control XT1/P07
XT2
TI00/P00 16-bit timer/
event counter
8-bit timer/
event counter 1
8-bit timer/
event counter 2
Watchdog timer
Watch timer
Serial interface 0
Serial interface 1
RAM
VDD0,
VDD1 IC (VPP)
VSS0,
VSS1
ROM
(flash
memory)
78K/0
CPU core
Serial interface 2
A/D converter
D/A converter
Interrupt control
Buzzer output
Clock output control
TO1/P31
TI1/P33
TO2/P32
TI2/P34
SI0/SB0/P25
SO0/SB1/P26
SCK0/P27
SI1/P20
SO1/P21
SCK1/P22
STB/TxD1/P23
BUSY/RxD1/P24
BUSY/RxD1/P24
STB/TxD1/P23
SI2/RxD0/P70
SO2/TxD0/P71
SCK2/ASCK/P72
ANI0/P10 to
ANI7/P17
AVSS
AVREF0
ANO0/P130,
ANO1/P131
INTP0/P00 to
INTP5/P05
AVSS
AVREF1
BUZ/P36
PCL/P35
TI01/P01
5-1-2. Block Diagram

—11 —
5-1-3. Pin Function
(1) Port pins (1/2)
Pin Name
P00
P01
P02
P03
P04
P05
P07Note 1
P10 to P17
P20
P21
P22
P23
P24
P25
P26
P27
P30
P31
P32
P33
P34
P35
P36
P37
I/O
Input
I/O
Input
I/O
I/O
I/O
Function
Port 0
7-bit I/O port
Port 1
8-bit I/O port
Input/output can be specified in 1-bit units.
If used as an input port, an on-chip pull-up resistor can
be connected by setting software.Note 2
Port 2
8-bit I/O port
Input/output can be specified in 1-bit units.
If used as an input port, an on-chip pull-up resistor can
be connected by setting software.
Port 3
8-bit I/O port
Input/output can be specified in 1-it units.
If used as an input port, an on-chip pull-up resistor can
be connected by setting software.
After Reset
Input
Input
Input
Input
Input
Input
Alternate Function
INTP0/TI00
INTP1/TI01
INTP2
INTP3
INTP4
INTP5
XT1
ANI0 to ANI7
SI1
SO1
SCK1
STB/TxD1
BUSY/RxD1
SI0/SB0
SO0/SB1
SCK0
TO0
TO1
TO2
TI1
TI2
PCL
BUZ
—
Input only
Input/output can be specified in 1-bit
units.
If used as an input port, an on-chip
pull-up resistor can be connected by
setting software.
Input only
Notes
1. When the P07/XT1 pin is used as an input port, set bit 6 (FRC) of the processor clock control register
(PCC) to 1 (do not use the feedback resistor incorporated in the subsystem clock oscillator).
2. When pins P10/ANI0 to P17/ANI7 are used as an analog input of the A/D converter, set port 1 to the
input mode. In this case, any connected on-chip pull-up resistors are automatically disabled.

—12 —
(1) Port pins (2/2)
Pin Name
P40 to P47
P50 to P57
P60
P61
P62
P63
P64
P65
P66
P67
P70
P71
P72
P120 to P127
P130 to P131
I/O
I/O
I/O
I/O
I/O
I/O
I/O
Function
Port 4
8-bit I/O port
Input/output can be specified in 8-bit units.
If used as an input port, an on-chip pull-up resistor can
be connected by setting software.
The test input flag (KRIF) is set to 1 by falling edge
detection.
Port 5
8-bit I/O port
LEDs can be driven directly.
Input/output can be specified in 1-bit units.
If used as an input port, an on-chip pull-up resistor can
be connected by setting software.
Port 6
8-bit I/O port
Input/output can be
specified in 1-bit units.
Port 7
3-bit I/O port
Input/output can be specified in 1-bit units.
If used as an input port, an on-chip pull-up resistor can
be connected by setting software.
Port 12
8-bit I/O port
Input/output can be specified in 1-bit units.
If used as an input port, an on-chip pull-up resistor can
be connected by setting software.
Port 13
2-bit I/O port
Input/output can be specified in 1-bit units.
If used as an input port, an on-chip pull-up resistor can
be connected by setting software.
After Reset
Input
Input
Input
Input
Input
Input
Alternate Function
AD0 to AD7
A8 to A15
—
RD
WR
WAIT
ASTB
SI2/RxD0
SO2/TxD0
SCK2/ASCK
RTP0 to RTP7
ANO0 to ANO1
N-ch open-drain I/O port
On-chip pull-up resistors can
be specified by mask option.
(Mask ROM version only).
LEDs can be driven directly.
If used as an input port, an on-
chip pull-up resistor can be
connected by setting software.

—13 —
(2) Non-port pins (1/2)
Pin Name
INTP0
INTP1
INTP2
INTP3
INTP4
INTP5
SI0
SI1
SI2
SO0
SO1
SO2
SB0
SB1
SCK0
SCK1
SCK2
STB
BUSY
RxD0
RxD1
TxD0
TxD1
ASCK
TI00
TI01
TI1
TI2
TO0
TO1
TO2
PCL
BUZ
RTP0 to RTP7
I/O
I/O
I/O
Output
I/O
I/O
Output
Input
Input
Output
Input
Input
Output
Output
Output
Outpu
Function
External interrupt request inputs with specifiable
valid edges (rising edge, falling edge, both rising and
falling edges).
Serial interface serial data input
Serial interface serial data output
Serial interface serial data input/output
Serial interface serial clock input/output
Serial interface automatic transmit/receive strobe
output
Serial interface automatic transmit/receive busy input
Asynchronous serial interface serial data input
Asynchronous serial interface serial data output
Asynchronous serial interface serial clock input
External count clock input to 16-bit timer (TM0)
Capture trigger signal input to capture register (CR00)
External count clock input to 8-bit timer (TM1)
External count clock input to 8-bit timer (TM2)
16-bit timer (TM0) output (also used for 14-bit PWM
output)
8-bit timer (TM1) output
8-bit timer (TM2) output
Clock output (for main system clock and subsystem
clock trimming)
Buzzer output
Real-time output port outputting data in
synchronization with trigger
After Reset
Input
Input
Input
Input
Input
Input
Input
Input
Input
Input
Input
Input
Input
Input
Alternate Function
P00/TI00
P01/TI01
P02
P03
P04
P05
P25/SB0
P20
P70/RxD
P26/SB1
P21
P71/TxD
P25/SI0
P26/SO0
P27
P22
P72/ASCK
P23/TxD1
P24/RxD1
P70/SI2
P24/BUSY
P71/SO2
P23/STB
P72/SCK2
P00/INTP0
P01/INTP1
P33
P34
P30
P31
P32
P35
P36
P120 to P127

—14 —
(2) Non-port pins (2/2)
Pin Name
AD0 to AD7
A8 to A15
RD
WR
WAIT
ASTB
ANI0 to ANI7
ANO0, ANO1
AVREF0
AVREF1
AVSS
RESET
X1
X2
XT1
XT2
VDD0
VSS0
VDD1
VSS1
VPP
IC
I/O
I/O
Output
Output
Input
Output
Input
Output
Input
Input
—
Input
Input
—
Input
—
—
—
—
—
—
—
Function
Lower address/data bus when expanding memory
externally
Higher address bus when expanding memory
externally
Strobe signal output for read operation from external
memory
Strobe signal output for write operation to external
memory
Wait insertion when accessing external memory
Strobe output externally latching address information
output to ports 4 and 5 to access external memory
A/D converter analog input
D/A converter analog output
A/D converter reference voltage input (also functions
as analog power supply)
D/A converter reference voltage input
A/D converter, D/A converter ground potential. Use
the same potential as VSS0.
System reset input
Crystal connection for main system clock oscillation
Crystal connection for subsystem clock oscillation
Positive power supply for ports
Ground potential for ports
Positive power supply (except ports and analog
block)
Ground potential (except ports and analog block)
High-voltage application for program write/verify.
Internally connected. Connect directly to VSS0.
After Reset
Input
Input
Input
Input
Input
Input
Input
—
—
—
—
—
—
Input
—
—
—
—
—
—
—
Alternate Function
P40 to P47
P50 to P57
P64
P65
P66
P67
P10 to P17
P130, P131
—
—
—
—
—
—
P07
—
—
—
—
—
—
—

—15 —
5-2. Reset circuit/Printer circuit/Power circuit
IC1
BA05CC0T
C28
HE60TKYB222K
IC3:uPD780058BGC124-8BTA
Q2
2SC1740S
C1
TE12TKYB103K
C30 330u/10V
ZD1
MTZJ6.8A
R60 ERG-1SJ100
R73 100K
D5
RB441Q-40
C24
DSTC50TKYR103K
C8 ECQ-B1H103-KF
R26
100K
5298T
R74 1K
D3
1SR139-400
TDW
C5
ECQ-B1H103-KF
R13
560
CNWIN1
2P-SAN
TVP
R72 100K
C2
4700u/25V
C25
DSTC50TKYR103K
ZD2
MTZJ4.7A
R76 1K
TRES
C4
330u/25V
C27
HE60TKYB222K
C7
100u/10V
D1
1SR139-400
F1
630/800mA
L1CM05RB03
C29 HE60TKYB222K
Q1
2SD2396
TVD
CNPR1
52011-0810
R75 1K
5298T
C3
100u/10V
R11 470K
T1
TE-264-E1U/TE-264-E1D
NC
NC
C6
HE40TKYB221K
IC2
S-80828CNY
CNAC1
7P-SDN
5298T R14 150
IC4
LB1268
R71 100K
D2
1SR139-400
TLED
D4
1SR139-400
C26
ECQ-B1H103-KF
R1
ERG-12SJ681P
VDD
VDD
VLED
VDD
VP
VDW
VP
VP
VP
VDD
IN
1OUT 3
G
2
P02
63
P01(INTP1)
62
P00
61
P03
64
/RESET
60
P20
11
P21
12
P22
13
P25
16
3
1 2
PN1 1
PN2 2
1 2
1 3
2 4
1
32
MAG- 8
MAG+ 7
MOT+ 6
MOT- 5
TIM 4
RES 3
COM 2
TS 1
6
1
2
4
5
3
7
9
10
(8)
Vout 1
Vin
2
Vss 3
S1 1
S2 2
S3 3
S4 4
S5 5
S6 6
S7 7
IN1 1
IN2 2
IN3 3
GND 4
VCC
5OUT3
6OUT2
7OUT1
8
AC IN
AC IN
AC IN
N100V
N
L
Reset circuit
Power circuit
Printer circuit

— 16 —
6. DIAGNOSTIC OPERATION
To start the diagnostic program
ECR enters the diagnostic mode by the following operation.
1Turn the mode key to PGM.
2Input “99990000” and “ST(SUB TOTAL)”.
Upon the above operation ECR prints the following and issues a receipt.
* Note that the test mode will not boot if once a receipt has been issued in the REG/RF/X/Z mode.
In this case, remove the battery and perform the above operation again.
FEED 029 C
7 8 9
4 5 6
1 2 3
0 011 012
028 023
027 022 021 017 020 016
019 015
018 014
013 013
026
025
024
d1d2d3d4: Version No.
d5: Destination PAD
0: domestic
1: general export (ADD2)
2: US/Canada
d6: 0: tax spec
1: no tax spec
“-”: overseas
07: 0: domestic
“-”: overseas
* “#” is not printed for US and Canada.
6-1. Content of the Test
1Displaying the Key Code ......................... Press any key other than the ten keys and clear key.
2Displaying the Switch Condition .............. Press the clear key, or change the status of switches.
3Printing, Display and Drawer test ............One digit number + “ST(SUB TOTAL)”key
6-2. Displaying the Key Code
Press any key other than the ten keys and clear key to dipslay the hard key code as shown below.
(Display) 019
2000-00-00
00-00#0001
-d1d2d3d4--d5d6d7

—17 —
[DISPLAY]
Mode SW
1:PGM, 2:RF, 4:REG,
5:CAL, 6:X, 7:Z, 0:no contact
FEED key
1:ON, 0:OFF
No tax PAD (film)
1: tax (default)
0: no tax (cut)
PAD2
1:SHORT
0:OPEN
PAD1
1:SHORT
0:OPEN
No display
No display
0:Fixed
6-3. Displaying the Switch Condition
Press the clear key, or change the status of switches to display the current conditions.

—18 —
6-4. Operations
■ Bulk test
Operation : 1 ST (SUB TOTAL)
All lit in the display, time and date setting, drawer open.
•All lit
(display) : 88888888=
↑(transaction)
•Waits for key input
•Time and date setting
Set the time and date at 23:59 on 31 December, 1994.
•Drawer open
•Test print US: 123456789012ST#
Other than US: 1234567890ST#
•Test display
(display) : 12345678
■ Switching the Receipt / Journal
Operation : 2 ST (SUB TOTAL)
This test switches the printing between the receipt and the journal.
■ Battery test
Operation : 7 ST (SUB TOTAL)
This test displays the battery voltage value.
The battery voltage is displayed until a power down occurs.
(display) : BBB BBB: battery voltage
Ex) when the voltage is 2.56V, “BBS=256”is displayed.
