CASIO Electronic Dictionary
Quick Guide (XD-N Series)
The contents of this Quick Guide apply to the
CASIO XD-N Series Electronic Dictionaries. Most
illustrations and screen shots show the XD-N8500.
•Hangul, Russian, Simplified Chinese, and accented
characters cannot be input on a model that does not
include a dictionary that requires such characters.
Installing optional content automatically enables
input of characters that match the installed content.
•The screen shots and product illustrations shown in
this manual may be different from those of the actual
product. Also note that some keys and icons are
shown in simplified form.
Example: →, →【音声 】
Loading Batteries for the First Time
Load the two AA-size batteries that come with the
electronic dictionary before trying to use it.
1Remove the battery cover.
While pressing down on the
two locations shown in the
illustration, slide the battery
cover in the direction indicated
by the arrows.
2Load two batteries.
Push against the spring
with the (–) end of the
battery.
With the battery on top of
the ribbon, press the (+)
end down.
Make sure the (+) and (–)
ends are facing correctly
and that the spring is
pressed straight down.
3Replace the battery cover.
4Remove the stylus
from the back of the
electronic dictionary
and then press the
RESET button on the
bottom.
Do not use a toothpick,
lead pencil, or other
object with a breakable
tip.
5Unfold the electronic dictionary.
Main panel
Keyboard
Sub panel
Arrow keys
This causes the 電池設定 (Battery Setting) screen
to appear.
If the message メインパネルの表示保護フィルムが...
(Main panel protective film may be...) or サブパ
ネルの表示保護フィルムが ... (Sub panel protective
film may be...) appears, remove the protective
film (option) from the indicated panel.
6
After confirming that
アルカリ電池 (Alkaline
Batteries) is selected for
電池設定 (Battery Setting),
press .
If you have commercially available eneloop
batteries or rechargeable EVOLTA batteries
loaded, use and to select the battery
type and then press .
If you have commercially available EVOLTA
alkaline batteries loaded, select ●アルカリ電池
(Alkaline Batteries).
•
•
•
•
•
•
•
•
•
Stylus
RESET button
Stylus
RESET button
7 Use the time setting
screen to configure
time settings.
Use the , , , and
or the stylus to select
the setting you want to
change, and then use the
on-screen number keys to change the setting.
Touch【12/24】to toggle between 12-hour and
24-hour format timekeeping.
When you are using 12-hour format
timekeeping, you need to touch
【AM】(a.m.) or
【PM】(p.m.) before setting the time.
8 Press .
Alternatively, you
also could touch
【保存】(Save) on the
time setting screen.
This displays the
メニュー (Menu)
screen.
To display the menu screen without changing
time settings, touch
【中止】(Cancel).
To avoid misplacing the stylus, always be sure
to return it to its storage slot in the back of the
electronic dictionary whenever you are not using it.
Turning Power On and Off
Power turns on and off
automatically whenever
you open or close the
electronic dictionary’s
panels.
•You also can use the following
key operation to turn power on
or off.
1Press the key to turn on power.
Power also turns on when you press a
dictionary/mode key.
2Press again to turn off power.
General Guide
Main Panel
You can touch the main panel to
select an on-screen item, swipe it
to scroll to another screen, or input
characters by handwriting them on
the panel.
Sub Panel
You can use this panel to hand-
write characters for input. Also,
touching buttons that appear
here performs certain operations.
④
⑤
⑩
③
②
①
⑫
⑬
⑥
⑨
⑭
⑧⑦⑪
⑳
⑱
⑮
⑯
⑰⑲
㉑
㉒
㉓
㉔
㉕
㉖
You can use the stylus for instant access to a variety of
different operations. (Quick Palette icons that appear
along the left side of the screen depend on what is
currently displayed.)
Quick Palette
buttons
Main Panel
Quick Palette
icons
•
•
•
•
•
•
•
•
Number keysNumber keys
Dictionary/
mode keys
Dictionary/
mode keys
①Dictionary/mode keys
Toggle between the initial screens of the two
dictionaries/modes assigned to each key.
②(Power) Key
Toggles power on and off.
③(Shift) Key
Shifts the keyboard. To use , press and
release it and then press the next key.
④さらに検 索
ヒストリー
(History) (Additional Search) Key
Accesses history data.
Press after to perform additional search ( さ
らに検索 ).
⑤(Text Size) Key
Cycles through available screen text sizes.
⑥
ガイド
ジャンプ
(Jump) (Guide) Key
Enables look up of a term on the currently
displayed definition or explanation screen.
Press after to view guide information.
⑦(Layout) Key
Changes the screen layout.
⑧(Scroll) Keys
These keys scroll screen contents up and down.
Press after to jump back or forward between
terms.
⑨読み上げ
音声
(Audio) (Read) Key
Press when you want to hear something
pronounced by a native speaker.
Press after to hear a reading by a
synthesized voice.
⑩(Back/List) Key
Back-steps through previous operations.
Press while a dictionary’s initial screen is
displayed to return to the メニュー screen.
Press while a definition screen is on the display
to switch to the list of terms, which includes the
term whose definition you were viewing.
⑪(Translate/Select) Key
Executes a function or selects an on-screen item.
⑫Arrow Keys
These keys move the selection highlighting or
cursor up, down, left, or right.
Used during volume adjustment to raise and
lower the volume level.
⑬(Setup/Delete) Key
Deletes the character at the current cursor
location.
Press after to display a screen for changing
the setup of the electronic dictionary.
⑭Letter Keys
Enter letters and numbers.
⑮【前見出し】・【次見出し】(Previous Headword/
Next Headword)
Jump from the current term to the previous or next
term.
The same result can be achieved by pressing
and then or .
⑯【熟語】(Compound Terms)
Displays compound terms that use kanji you are
currently viewing.
⑰【ズーム】(Zoom)
Enlarges the characters of a definition or
explanation screen.
⑱【成句複合語】(Phrases and Compound
Expressions)
Displays phrases and compound expressions that
use the term you are currently viewing.
⑲【暗記カード作成】(Create Flash Card)
Creates a flash card.
⑳【用例解説】(Examples and Explanations)
Displays examples and explanations in dictionaries
that include such information.
㉑【メニュー】(Menu)
Displays the menu screen.
㉒【ジャンプ】(Jump)
Performs the same functions as the ⑥
ガイド
ジャンプ
(Jump/Guide) key.
㉓【音声 】(Audio)
Performs the same functions as the ⑨読み上げ
音声
(Audio/Read) key.
㉔【戻る／リスト】(Back/List)
Performs the same functions as the ⑩
(Back/List) key.
㉕【訳／決定】(Translate/Select)
Performs the same functions as the ⑪
(Translate/Select) key.
㉖ (Scroll)
Perform the same functions as the ⑧keys.
•
•
•
•
•
•
•
Display Indicators
The following explains the meanings of display
indicators.
This indicator: Means this:
A definition or explanation
continues off the top, bottom, left,
or right of the screen. Use the arrow
keys to scroll the screen.
(Explanation)
There is an explanation for the word
where the indicator is located.
(Compound Term)
There is a compound term that
uses kanji you are looking up.
( Phrases/Compound
Expression
)
(Phrase)
There is a phrase or compound
term that uses the term you are
looking up.
With some electronic dictionary
models, will appear if optional
content is installed.
(Example)
There is an example that uses the
term you are looking up.
Native speaker pronunciation is
available for the contents to the
right or below this indicator.
(True Voice)
Native speaker pronunciation is
available.
(Reading)
Synthetic voice reading is available.
(Pronunciation
Search)
Pronunciations are available for the
English term on the screen.
(English)
The language whose pronunciation
is applied for pronunciations and
readings
There is related information for
the term you are looking up in the
current dictionary.
(Jump)
Jump function in use
(History)
History function in use
(Zoom)
Display zoom in use
(Guide)
Guide function in use
(Display All)
(Word Order)
(Continuous)
Indicates the display method when
using 例文検索 (Example Search) or
成句検索 (Phrase Search).
Panel Touch Operation Tips
•Strong pressure is not required when performing
main panel and sub panel touch operations.
•Avoid applying excessive pressure during touch
operations and input. Strong pressure can cause
cracking or breaking of the panels.
•When performing a main panel touch operation,
be sure to support the back of the panel with your
hand.
Main panel
Sub Panel
•For stylus character input, be sure to use only the
stylus that comes with your electronic dictionary.
•When using your finger for input, do not tap with
your fingernail.
Keyboard Input
•Alphabetic and Russian characters are input using
lower case.
•Except for certain models, Hangul, Chinese pinyin,
and Russian characters are not printed on the keys.
Inputting Japanese Characters
•Use alphabetic characters to input Japanese.
To input this: Type this:
いんかん
さんぽ or
きょう
らっこ or
とぅーるーず
Inputting Alphabetic Characters
•Use English input for unaccented alphabetic
characters.
To input this: Type this:
internet
?
~
Accented Characters
All alphabetic characters are input in lower-case,
regardless of their normal capitalization.
•For the German “ß”, input “ss”.
•For other characters that normally include a
diacritic, input the character without the diacritic.
Example: “à” →“a”, “ê” →“e”, etc.
•For the French “ç” input “c”, and for “œ”, input “oe”.
•Input hyphenated terms as single words, without a
hyphen. To look up “heaven-sent”, for example, input
“heavensent”.
•When inputting a term that consists of multiple
words, input the words without any spaces. To
look up “in orario”, for example, input “inorario”.
•When entering a noun that is normally accompanied
by an article, enter the noun only without the article.
To look up “die Elbe” for example, input “elbe”.
Inputting Hangul Characters
To input this: Type this:
G
G
G
Inputting Chinese Characters (Pinyin)
1234 0
To input this: Type this:
ming2tian1
(míng tiān・明天 )
W
TIAN
Q
•To specify one of the four Chinese tones ( , , ,
) or the “toneless” tone ( ), press and release
, and then press the key that corresponds
to the tone you want to specify. The four Chinese
tones and the “toneless” tone are indicated by
numbers on the display.
•You can also specify the four Chinese tones and the
“toneless” tone by touching one of the buttons on
the sub panel.
•To input “ü”, press V.
Inputting Russian Characters
To input this: Type this:
хобби
•To input a character marked in the upper right
corner of a key, press (and immediately release)
and then press the key.
Inputting with the Soft Keyboard
You can use the soft keyboard that appears on the
main panel for character input.
•The type of keyboard that appears depends on the
dictionary search method you are using.
■
Example: 明鏡国語辞典 (Japanese Dictionary)
When the Quick Palette
【入力】(Input)
icon is on the
display, touch
it to display
the input
screen.
•Touching will display a Japanese syllabary
keyboard, touching will display an alphabetic
keyboard, and touching will switch to
handwritten input.
•While the soft keyboard is displayed, touch the
character keys to input characters.
•To delete a character, use and to move the
cursor to the character and then touch
【削除】(Delete).
•To input a small character while the Japanese
syllabary screen is displayed, input the desired
character and then touch
【小文字】(Small).
•To exit the input screen, touch
【入力】or .
Handwritten Input
Use the stylus to write characters on the sub panel
or main panel, and then touch【認識】(Recognize).
•To handwrite characters on the main panel, touch
【入力】(Input) and then . This displays input cells
on the main panel.
•
With some search methods, like 単漢字 /熟語を手書き入
力から探す (Kanji/Compound Term Handwritten Input
Search) ( 新漢語林 (Japanese Kanji Dictionary)), you
can enter search terms using handwriting input only.
Character Input Mode
The indicators
described below
appear on the main
panel to show the
current input mode.
Indicator
Supported
Input
Characters
Hiragana
Katakana
Kanji
Simplified
Chinese
Hangul
Indicator
Supported
Input
Characters
Alphabetic
Alphabetic
and accented
alphabetic
Russian
Numbers
Main panelSub panel
【書き直し】
Scroll buttons
Character cells 【認識】
【認識】【削除】
【書き直し】
•
The number of cells that appear on the panel
depends on the type of characters that can be input.
Correcting Character Input
•The example here show how to use the sub panel,
but you can also use the same procedure when
inputting on the main panel.
Example: After mistakenly inputting 喜怒衰楽 instead of
喜怒哀楽
Sub panel Main panel
Input field
Character cells
Scroll buttons
(When there are too many characters to fit in the display area between
the buttons, touch these buttons to scroll the screen contents.)
1On the sub panel
or in the input
field on the main
panel, touch a
character ( 衰).
This displays up to 10 possible candidates for
the character.
•
Input ScreenInput Screen
IndicatorIndicator
(Continued on other side.)
QuickGuideEXD-N.indd1QuickGuideEXD-N.indd1 2012/11/309:59:442012/11/309:59:44

6Use ,,, and to select 志, and
then press .
This displays an explanation of the term.
【パターン 5】(Pattern 5): Touching a screen
item
You can perform a search simply by touching some
screen items on the main panel screen with the stylus.
Example: To look up 白川郷 ( ブリタニカ国際大百科事典)
After displaying the ブリ
タニカ国際大百科事典
initial screen, touch the
following items on the
screen: 地図から検索
(Map Search) (twice) →
おもな世界遺産 (Main World
Heritage Sites) (twice) →
日本 (Japan) →白川郷
(Shirakawagoh)
•This will cause an
explanation of 白川
郷(Shirakawagoh) to
appear on the sub
panel. (Depending on
the dictionary or search
method, the explanation
screen may not appear
on the sub panel.)
•Pressing will cause an explanation of 白川
郷(Shirakawagoh) to appear in the main panel.
•The number of times you need to touch an item
before the explanation appears on the sub panel
depends on the headword.
Other Searches
Jump Search
You can use jump search to jump to another
location in the same dictionary or to another
dictionary.
To jump within the same dictionary
1
When search
results show items
with a large arrow
( ) or small
arrow ( ) jump
symbol, press
ガイド
ジャンプ
.
appears and the first character that is the
jump target is selected.
The selected jump target is one character for
Japanese and a word for English.
2
Use the arrow keys to move the highlighting to
an item to the right of a jump symbol
(or ), and then press to jump.
Instead of the above procedure, you also can
perform the jump by touching the term to the
right of the arrow symbol.
For some dictionaries only red text is displayed
without or .
To jump to another dictionary
1While the results of a search are displayed,
press
ガイド
ジャンプ
.
2After using the
arrow keys to move
the highlighting to
the term you want
to look up, touch
the sub panel
【選択】(Select)
button or the Quick
Palette【選択】icon.
This displays the dictionary menu screen.
3Use and to select a dictionary, and
then press .
This displays a list of candidates.
4Use and to move the highlighting to
the item you want, and then press
to jump.
After pressing
ガイド
ジャンプ
in step 1, tapping a single
character or term or dragging the stylus across
multiple characters or terms will search for the
headwords that match the select character(s)
or word(s). If you select multiple English words
for an example/idiom search jump, only the first
words you select will be searched for.
•
■
•
•
•
•
■
•
•
•
•Note the following precautions concerning English
terms.
If there is more than one possible pronunciation,
a list of candidates will appear. Select the one you
want to hear and then press .
If a native speaker pronunciation is not available,
a screen will appear asking if you want to hear
a synthesized voice pronunciation. Select the
option you want and then press .
Proper pronunciation will not be produced for
language other than English.
The pronunciation produced by the electronic
dictionary may not be correct if there is more than
one pronunciation for a term.
Synthesized Voice Readings
Synthesized voice readings of terms and examples
are available in seven languages: English, Spanish,
German, French, Italian, Chinese, and Korean.
•
Some dictionaries/modes do not support synthetic
voice readings.
•Chinese reading can be selected for a Chinese
model electronic dictionary and Korean for a
Korean model electronic dictionary only. For other
models, these languages can be selected after the
applicable optional content is installed.
•Pronunciation is not available for pinyin and
alphabetic notation Chinese, and for some kanji.
•For Korean, only hangul terms can be read.
To play readings on a definition and
explanation screen
1Press and
then 読み上げ
音声
.
The first term or
example on the
screen for which
a pronunciation is
available will be
selected.
2Use and to select the term or
example whose pronunciation you want to
hear.
You can also select a term or example by
touching it.
3Press .
This will play the pronunciation of the term or
example.
4To exit pronunciation, press .
Configuring Audio Settings
Use the procedures below to configure audio settings.
1Press and then
.
2Use the arrow keys to
select 音声設定 (Audio
Settings), and then
press
.
This displays the settings screen. Use and
to select the setting you want to change,
and then press . This displays the
applicable setting screen.
Setting Description
音声速度設定
(Reading
Speed)
Select the speed you want and then press
.
You can select one of the five speeds
shown below. The percent values
indicate the speed relative to normal
speed (100%).
最高速モード (130%), 高速モード
(120%), 標準モード (100%), 低速モード
(85%), 最低速モード (75%)
•
音声言語設定
(Reading
Language)
Select the language you want and then
press .
This will change the pronunciation
language setting of only the dictionary
that was selected before the 音声設定
screen was displayed.
•
音量設定
(Volume)
Select the volume level you want and then
press .
-
-
-
-
■
•
•
•
•
2If you find the
correct character
among the
candidates, touch
it.
3
If you do not find the correct character, touch
【書き直し】(Rewrite), rewrite the character on the
sub panel and then touch【認識】(Recognize).
Touching【書き直し】(Rewrite) while the character
cells of the sub panel are blank (nothing input)
will delete the character currently in the input
field of the main panel. (In the case of the main
panel, touch
【削除】(Delete).)
Touch Panel Screen Operations
To select a dictionary
1Touch the Quick Palette【メニュー】(Menu)
button to display the menu screen.
2Touch a category.
Touching a
category selects it.
3Touch a
dictionary (icon).
This displays the
initial screen of the
dictionary.
Touching a
dictionary that
has a icon next to it displays a sub-list of
dictionaries. Touch the dictionary you want to
select.
If the menu screen has a【次ページへ】(Next page)
or
【前ページへ】(Previous page) icon, you can
touch these icons to scroll between menu pages.
To select a headword or screen item
1Enter characters. On the list that appears,
touch the term or screen item you want.
This highlights the term or item.
2Touch the highlighted term or item again.
This displays the definition or explanation in the
case of a term, or the next screen in the case of
a screen item.
Scrolling the Screen
•If there are pages following the currently displayed
page, you can scroll to them by swiping the panel.
•Swiping quickly will scroll at high speed. Touch the
panel to stop the scrolling.
Finding Information in a Dictionary
There are five basic patterns for term searches.
【パターン 1】(Pattern 1): Entering the initial
characters of the term you want to find
【パターン 2】(Pattern 2): Entering all of the terms
you want to find
【パターン 3】(Pattern 3): Searching step-by-step
through a series of titles
【パターン 4】(Pattern 4): Narrowing down the
search using multiple conditions
【パターン 5】(Pattern 5): Touching a screen item
•For details about the search patterns of each
dictionary, see the 収録辞典 (Dictionary) chapter in
the 取扱説明書 (User’s Guide).
【パターン 1】(Pattern 1): Entering the initial
characters of the term you want to find
The displayed list of search results changes as you
enter characters of the term you want to find.
Example: To look up the meaning offine( ジーニ
アス英和辞典 )
1Use and to select 見出し語検索
(Headword Search).
2Enter the term you
want.
As you enter each
character, the list of
terms on the main
panel is updated
accordingly.
•
■
•
•
•
•
■
•
•
■
•
When entering a headword, you can use the
following wildcard characters.
Character Represents
? A single unknown character
~
A series of multiple unknown characters of
unknown length
3Use and to move the highlighting to
a term, and then press .
This displays the definition screen.
【パターン 2】(Pattern 2): Entering all of the
terms you want to find
Enter the entire term you want to find and then
press .
Example: To find the phrases that use the words
“get” and “to” ( ジーニアス英和辞典 )
1
Use and to select 成句検索 (Phrase Search).
Select 例文検索 (Example Search) to search for
an example.
2Enter the term.
When inputting multiple words, separate them
using the ampersand character (&), not spaces.
Example: get to ➡get&to
3Press .
This displays a list
of all phrases that
contain the terms.
4Use and to move the highlighting to
a phrase, and then press .
This displays the detailed information screen.
【パターン 3】(Pattern 3): Searching
step-by-step through a series of titles
With some dictionaries, you need to perform
successive select and execute (by pressing
) operations until you arrive at the
information you need.
Example: To look up an English conversation
expression ( 英会話とっさのひとこと辞典 )
After displaying the
initial 英会話とっさのひと
こと辞典 screen, select
the following:［A］場
面から探す (Search by
Circumstance) →［A］毎
日の生活でつかうひとこと
(Daily Life Expressions) →［A］家のなかで (At home)
→［A］起きてから出かけるまで (Morning).
This will bring you to a screen that displays the English
expression for the Japanese おはよう (Good Morning).
【パターン 4】(Pattern 4): Narrowing down
the search using multiple conditions
With this type of search, you can input multiple
keywords, terms, or other conditions.
Example: Looking up the kanji 志in 新漢語林
(Japanese Kanji Dictionary)
The kanji 志has the radical 心( こころ ), and a total
of 7 strokes. This information can be used to look
up the kanji.
1Select 単漢字
を読み /画数から探
す(Single Kanji
Reading/Number
of Stroke Search)
and then press
.
If a selection item has a letter at the beginning,
you can press the corresponding letter key to
execute the selection directly. In case of the
above, for example, you could simply press .
2Use , , , and to select the 部首
読み (Radical Reading) column, input こころ
(heart), and then press .
This displays a list of applicable radicals.
3Use , , , and to select 心, and
then press .
4Use , , , and to select 総画数
(Total Strokes), and then enter 7.
Use the top row of keyboard keys to enter numbers.
5Press .
This displays a list of kanji characters that
satisfy the conditions.
•
•
•
•
•
•
•
•
•
•
•
To use the Mini Dictionary to look up a term
1While a search result screen is displayed,
press
ガイド
ジャンプ
.
2After using the arrow keys to move the
highlighting to the term you want to look
up, touch the sub panel 【ミニ辞書】 (Mini
Dictionary) button or Quick Palette 【ミニ辞書】
(Mini Dictionary) icon.
The Mini Dictionary appears on the sub panel (or
main panel).
While the Mini Dictionary is displayed, tapping
a single character or term or dragging the stylus
across multiple characters or terms on the main
panel will search for the headwords that match
the select character(s) or word(s).
To close the Mini Dictionary, press .
Simple Search
Simple Search lets you input hiragana or alphabetic
text to search multiple dictionaries for terms.
•In the case of models that use special characters,
tabs for those characters appear on the search
screen in addition to 日本語 (Hiragana) and アル
ファベット (Alphabet). For example, the German-
language model (XD-N7100), has a ドイツ語
(German) tab and the Chinese-language model
(XD-N7300) has 中国語 (ﾋﾟﾝｲﾝ ) (Chinese (Pinyin))
and 中国語 (漢字 ) (Chinese (Kanji)) tabs. You can
select the tab for the type of text you want to input.
1Press twice.
On some electronic
dictionary models,
you need to press
only once.
2
Use to select日本語 (Japanese) to search
using hiragana or アルファベット (alphabet) to
search using alphabetic characters.
3On the search screen that appears, enter a
term.
Terms starting with the characters you have
entered appear in a list on the display.
Each term also includes an indicator showing
its dictionary.
4Use and to move the highlighting to a
dictionary and term combination, and then
press .
Displaying Detailed Information
Use the operations described here to view detailed
explanations and other information about looked
up words and terms.
Viewing Phrases, Compound
Expressions, and Compound Terms
If there is a
(or ・)
or symbol on
the screen, it means
that there is phrase,
compound expression,
or compound term
information available
for the term you are
viewing.
1Touch the on-screen symbol.
This displays a list of applicable candidates.
You can also display the list of candidates by
touching
【成句複合語】(Phrases/Compound
Expressions) or
【熟語】(Compound Terms) on
the sub panel.
2Touch the item you want to view to select
it, and then .
This displays the applicable details.
Viewing Examples and Explanations
The symbols and
on the display
indicate that there is
example, illustration,
explanation, or other
information available.
■
•
•
•
•
•
•
•
•
•
1On the sub panel, touch【用例解説】(Example/
Explanation).
This will cause the or symbol
to become highlighted, and display partial
information at the bottom of the screen.
If there are multiple symbols on the screen, use
the arrow keys to move the highlighting to the
symbol you want to select.
2Press .
This displays the applicable details.
•Applicable details will also appear if you touch a
symbol.
Pronunciation
Your electronic dictionary can produce native
speaker pronunciations and simulated voice
readings of terms and examples.
To use the built-in speaker
On the side of the electronic
dictionary, slide the
pronunciation output switch
to SPEAKER.
To use earphones
1On the side of the
electronic dictionary,
slide the pronunciation
output switch to
PHONES.
2Connect the supplied
earphones to the
terminal on the left
side of the electronic
dictionary.
Use only the supplied
earphones.
To adjust the volume
1While any screen is
displayed, press
.
This causes the 音量設定
(Volume Setting) screen
to appear.
2Use the 音量（大） (increase volume) and
音量（小） (decrease volume) arrow keys
to adjust the volume level.
3Press .
While the icon is highlighted or while the
term you want to have read is selected, you can
adjust the audio volume by touching【+】or【–】
on the sub panel.
While audio output is in progress, you can
adjust its volume by pressing or .
Native Speaker Pronunciation
When or an English term is on the display, it
means that native speaker pronunciation (TRUE
VOICE®) is available.
1Press
読み上げ
音声
.
This causes
to become
highlighted.
When an English
term is displayed,
the first term for
which pronunciation is available becomes
selected.
2Press .
This will play the pronunciation of the term or
example sentence next to or under , or of
the currently selected English term.
If there are multiple symbols or English
terms, use the arrow keys to select the one you
want and then press .
3To exit pronunciation, press .
•You also can play a pronunciation by touching
.
•
•
•
■
■
•
■
•
•
•
•
•
•
•
Pronunciation
output switch
Pronunciation
output switch
•eneloop is a registered trademark of SANYO
Electric Co., Ltd.
•EVOLTA is a registered trademark of Panasonic
Corporation.
Printed in China
© 2013 CASIO COMPUTER CO., LTD.
QuickGuideEXD-N.indd2QuickGuideEXD-N.indd2 2012/11/309:59:462012/11/309:59:46
