Welcome
Welcome to CASPR COMPACT.
CASPR COMPACT is designed to provide years of trouble-free
service when it is properly maintained. Even when properly cared
for, some parts of your CASPR COMPACT will need to be
replaced periodically. Replacement parts can be purchased from
your authorized distributor or directly from CASPR Group.
(www.casprgroup.com)

3
Quickstart 4
Warnings 5
Setup & Operation 6
Diagrams 8
Routine Maintenance 12
Troubleshooting 15
Limited Warranty 17
Records/Specications 18
Contents

4
Quickstart
1
Place CASPR COMPACT on a counter top or shelf
the f oor. Ensure there is room
in front and back of the unit for air to flow through.
2Plug the unit in with the included power cable.
3
Insert the batter inside the remote control.
4 Power on with the remote or by pressing the display screen
then set the fan to a comfortable sound level. Leave the
CASPR COMPACT in NORMAL Mode - Screen will read PCO
This is the standard mode for occupied rooms. High mode is
used for high burst of disinfection and it should not be used
for more than one hour in any space
2
1
4
3
5
e the AWAY MODE for a higher
level of disinfection when space is
occupied. Pressing the Away Mode key
will start a timer (2 to 8 hours). The
CASPR COMPACT will go back to
Standard Mode when the timer ends or
when you push NORMAL Mode again.
NEVER USE AWAY MODE
WHEN ROOM IS OCCUPIED
Fan
speed level
Size of the room
(only set in HIGH mode)

5
Warnings
Review this list before using or performing any maintenance or cleaning of your unit.
WARNING: Never operate unit near a heat source, open ame or ammable/combustible uids.
WARNING: Do not operate unit unless all parts (including Cell, Purication Plate, Rear Filter Assembly and Rear Cover) are
properly installed.
CAUTION: Directly viewing the lamp inside unit for an extended period (longer than 20 min.) may result in eye damage.
CAUTION: When using AWAY Mode, never adjust setting to exceed square footage of ventilated space being treated. To use this
mode, the ventilation system from the room should provide a minimum of three air exchanges per hour.
CAUTION: Do not use AWAY MODE in occupied spaces. Short term exposure to ozone levels exceeding 0.5 ppm can
cause temporary adverse reactions, including irritation in the eyes, nose and throat, shortness of breath, chest pain, and
wheezing. Pets, children, the elderly, and individuals with preexisting conditions such as asthma, heart conditions, or high
blood pressure are especially at risk.
CAUTION: Unit should be powered OFF and Power Cord should be disconnected when Cleaning/Disassembling/
Reassembling/Servicing.
WARNING
CAUTION
CAUTION
WARNING
CAUTION
CAUTION

6
Ideal Placement
• Make sure the location you choose is as close to an air
supply duct as possible and as far away from the HVAC air
return duct as possible. This will ensure that the oxidizing
molecules produced by the CASPR COMPACT are
optimally circulated.
• Each CASPR COMPACT can effectively treat 1,500 sq feet
of space as long as there is air circulation in the space. Be
sure doors are open in areas that you wish to treat.
•To ensure the unit works properly, there should be as much
space as possible in front of your CASPR COMPACT so that
It can efficiently process the air in the area.
• Place CASPR COMPACT on a shelf or counter top.
Never place an operating unit on the floor.
Operating CASPR COMPACT
1. Connect the Power Cord to the Power Adapter and the
Power Adapter Plug into the unit. (Check to be sure your
power supply is properly assembled. The Power Cord should
be inserted far enough into the Power Adapter so that a
space of only about 1/8 in. is left between the widest part of
the power cord and the edge of the Power Adapter).
2. Insert the Power Plug into the wall outlet.
3. Turn on the unit by pressing the POWER button and set
it to NORMAL mode. The screen will read PCO. This is the
optimal setting for running CASPR COMPACT continuously
in your office or home. Adjust the fan to a comfortable
sound level using the up and down buttons next to the
display.
4. CASPR COMPACT comes with a remote control,and one
CR2025 battery, for easier operation when the unit is placed
on a high shelf, approximately 6-feet or higher.
Set up and Operation
(Initial Setup)
6

7
When to use NORMAL Mode
•NORMAL mode is the default mode for continually
running your CASPR COMPACT.
When to use HIGH Mode
•High mode is used for burst purification, removing
pollutants like smoke or other significant odors. Do not run
HIGH mode for more than one hour with occupants in the
room.
• When CASPR COMPACT is set to HIGH Mode the display
will ask you to set the square footage. Press the PURIFIER
button up or down to set the square footage of the room
for the most effective treatment.
When to use SLEEP Mode
• Access SLEEP mode on your remote control. Activating
this setting will dim the display screen settings.
When to use AWAY Mode
•AWAY Mode generates ozone for deep cleaning an area.
This mode can be used for removing smoke, cooking odors,
mold spores, viruses and bacteria. AWAY mode runs on a
timer and once it completes the cycle, it returns to Normal
Mode.
•Set AWAY Mode by pressing the AWAY Mode button. Each
time you press the button it will increase the time of the
cycle from 2:00, 4:00, 6:00 or 8:00 hours.
• If AWAY Mode is running when you enter the room, push
the NORMAL/HIGH button once to return to NORMAL
Mode.
NEVER USE AWAY MODE IN OCCUPIED SPACES
INCLUDING SPACES OCCUPIED BY PETS.
Operating Modes
Normal: Continual Usage: 24/7; High: Set Accurate Square
Footage; Away: Limit to Unoccupied Spaces ONLY

8
Ionization Needle
1
Front Grille2
Control Panel
3
Rear Cover Screw
1
Rear Cover Grooves2
Power Adapter Inlet
3
Rear Cover
1
Unit Rear2
Unit Front
3
1
2 3
Front of Unit Rear of unit Side of Unit
Diagrams (Unit)
1
2
3 1
2
3
2

9
Brass Thumbscrews
1
Filter Assembly2
Filter Assembly Clasps
3
Cell
1
Cell Nuts2
Cell Connector
3
Power Cord
1
Power Cord Plug2
Power Adapter
3
Power Adapter Plug
4
Purication Plate
4
Rear of Unit
(Rear Cover Removed)
Rear of Unit
(Filter Assembly Removed)
Power Supply
1
2
3 4
1
3
4
2
2
1
3
(Unit)

10
1
2
3
6
5
4
Power Button
1
2
Unit control (whether in ft2or m2)
Must be in high mode first
3
Away Mode Control4
Fan Level Control
5
LED Display Control (lighting)6
Diagrams (Controls)
1
2 4
5
3
Remote Control Panel
Power Button
1
Fan Speed Control
2
3
4
Power Button
1
Fan Speed Control
2
Purifier Level Control
3
Away Mode Toggle
4
55 Normal/High Toggle
10

11
Control Panel Screen
(Controls)
1
2
3
4
5
6
Fan Speed Indicator
1
2
Mode Indicator
3
4
Maintenance Reminders
5
Away Mode Warning
6
Mode Specific Display
Normal - Technology Indicator (
High - Square Footage Indicator
Away - Mode Duration Indicator
(hours:minutes)
3
Away Mode High Mode Normal Mode

12
Routine Maintenance
To run efficiently, your CASPR COMPACT requires cleaning on
a 60 to 90 day cycle. Every month the display will remind you
to clean the unit. The best way to tell if the Filter Assembly
needs to be cleaned is to check the front grill for dust. If the
front grill is dusty, you should remove and clean the Filter
Assembly. If the front grill is not dusty, you can press the
Reminder Reset button and you will be reminded again in 30
days.
Removing the Rear Cover
1. Turn off the unit with the Power button.
2. Unplug the unit from the power source and then remove
the power cord from the back of the unit.
3. Unscrew and remove the Rear Cover screw located
above the Power Cord Port.
4. With two hands, slide the back cover up and lift it away
from the machine.
5. Wipe the rear cover with a damp cloth and set to the
side.
Removing and Cleaning the Filter Assembly
1. Unit should be powered OFF and Power Cord should
be disconnected when Cleaning/Disassembling/
Reassembling/Servicing.
2. Grasp the top of the Filter, lift slightly and pull it away
from the unit.
3. Thoroughly rinse the filter with warm water. Shake
excess water from the filter and let it dry for an hour
before reattaching it.

13
Reattaching the Filter
1. Gently lay the filter back onto the machine with the
diamond pattern facing the interior of the unit and the
honeycomb pattern facing out.
2. Replace the rear cover to secure the filter in place.
Reattaching the Rear Cover
1. Slide the rear cover back into place. You will hear a click.
2. Insert the Rear Cover Screw into the hole above the Power
Cord Port and tighten.
Removing and Cleaning the Front Grille
1. Locate the Front Grille Screw on the front of the machine
above the CASPR logo.
2. Using your screwdriver, carefully remove the Front Grille
Screw and place where you will easily find it later.
3. Remove the Front Grille by pushing up from the bottom
of the Front Grille with your fingers. Be careful to ensure
the Ionization Needle (in the top center of the front of the
unit) is not damaged.
4. Clean the Front Grille using (compressed air, vacuum
cleaner, damp cloth or warm soapy water) and set the
Front Grille aside.
5. If the Ionization Needle is visibly dusty, gently clean it
with a cotton swab and clear alcohol-based cleaner or
rubbing alcohol
Reattaching the Front Grille
1. Align the Front Grille to the front of the unit, being careful
not to damage the Ionization Needle at the top center of
the unit.
2. Insert the screw and tighten it.
13

14
LCD Reminders
When your CASPR COMPACT unit is in need of maintenance,
a message will display on the LCD screen.
• Perform Cleaning – this message will display every 30 days.
Check to see if the front grill of the unit is dusty. If so, you
will need to clean the filter as described in the Routine
Maintenance section on page 12. If the front grill is not
dusty, simply press the Reminder Reset button and CASPR
COMPACT will remind you again in 30 days.
• Replace Plate – This message displays when the Purification
Plate has reached the end of its useful life and needs to be
replaced. To order a replacement, contact your distributor
or CASPR Group (www.casprgroup.com). Follow the
instructions included with your replacement part to replace
your Purification Plate.
• Replace Cell - This message displays when the Cell has
reached the end of its useful life and needs to be replaced.
To order a replacement, contact your distributor or CASPR
Group (www.casprgroup.com). Follow the instructions
included with your replacement part to replace your
Purification Plate.
A message will
display on the LCD
screen when your
CASPR COMPACT
units needs
maintenance.

1515
Troubleshooting
The Unit Fails to Turn on
1. Verify that the Power Plug is plugged into an operational
wall outlet.
2. Ensure that the Power Cord is fully inserted (leaving less
than an 1/8”) to the Power Adapter.
3. Ensure that the Power Adapter Plug is fully seated in the
receptacle on the back of the unit.
4. Verify the Power Button has been activated on the Control
Panel.
5. If the Power Button on the Control Panel fails, use the
Power Button on the Remote Control. If the Control Panel
fails, contact your distributor or CASPR Group
(www.casprgroup.com).
The Unit is Operating in High Mode or Away Mode, but
No Noticeable Purication is Being Produced
1. Ensure that the Purification Plate is clean (See Next Page.)
2. The Purification Plate may not be working because it needs
to be replaced. Try installing a new Purification Plate.
3. Check the electrical contact arms which touch the plate to
ensure that they are making proper contact with the metal
weave on the Purification Plate.
4. Ensure the electrical contact arms which touch the plate
are clean. Clean them with a soft cloth and rubbing alcohol.

16
Removing and Cleaning the Purication Plate
1. Follow the instructions for removing the Rear Cover and
Filter Assembly on Page 12.
2. Grasp the Purication Plate on the ceramic surface and
gently pull it out of the grooves on the sides.
3. Using a 50/50 mix of warm water and clear ammonia, or in
place of the water and ammonia mixture use 100% white
vinegar, soak the Purication Plate for 8 to 10 hours. Do
not exceed 10 hours. Using a soft bristled tooth brush,
scrub the wire mesh to remove debris lodged inside the
mesh. Rinse thoroughly. Allow the Purication Plate to dry
completely before reinstalling.
4. Use a soft cloth and rubbing alcohol to clean the metal
contacts that touch the Purication Plate.
5. Holding the Purication Plate by the ceramic, align it with
the grooves on either side and slowly insert it into the
Purication Plate Slot.
The Purication Plate Generates an Electrical Arc, an
Arcing Noise or a Burning Odor
This means the Purication Plate is damaged and must be
replaced. The unit may or may not display the Replace Plate
LCD reminder. To order a replacement, contact your distributor
or CASPR Group (www.casprgroup.com).
The Cell Does Not Light Up
1. Ensure the Cell Power Connector is properly seated in the
Cell Power Connector Outlet.
a. Follow the instructions for removing the Rear Cover
and Filter Assembly on Page 12.
b. Check to see if the Cell Power Connector is properly
inserted in the Cell Power Connector Outlet. To ensure
the proper connection, gently push until the tabs at
the top and bottom of the Cell Power Connector snap
into place, securing it to the Cell Power Connector
Outlet.
2. If the Cell still fails to operate, it needs to be replaced.
Contact your distributor or CASPR (www.casprgroup.com).

17
Limited Warranty
Your CASPR COMPACT is warranted to be free from all defects
in material and workmanship in normal household use for a
period of one (l) year from date of purchase. The warranty is
granted only to the original purchaser and is subject to the
following provisions. This warranty does not cover parts of the
CASPR COMPACT that require replacement under normal use.
This includes the purifier plate and rear filter assembly.
Although the Cell requires periodic replacement, the cell is
warranted for the same 1 year period as the purifier. Any
damages or malfunctions caused by negligence, abuse, or use
not in accordance with the Owner’s Manual are not covered by
this warranty. Likewise, any defects or damages caused by
unauthorized service or the use of other than Genuine CASPR
parts are not covered. CASPR Group will, at its option, repair or
replace a defective CASPR COMPACT or part(s) for the CASPR
COMPACT that is covered by this warranty As a matter of
warranty policy, CASPR Group will not refund the customer’s
purchase price.
To obtain warranty service you must return the defective
CASPR COMPACT unit or parts along with proof of purchase to
your CASPR distributor. All transportation charges on parts, or
units, submitted under this Warranty shall be borne by
purchaser. Unless this Warranty is expressly renewed or
extended by CASPR Group, any repaired or replaced part of
unit shall be warranted to the original purchaser only for the
length of the unexpired portion of the original warranty. For
additional service information, please visit us online at:
www.casprgroup.com
Further Limitations And Exclusions Are as Follows
Any warranty that may be implied in connection with your
purchase or use of the CASPR COMPACT including any
warranty of merchantability or any warranty for Fitness For A
Particular Purpose is limited to the duration of this warranty.
Some states do not allow limitations on how long an implied
warranty lasts, so the above limitations may not apply to you.
Your relief for breach of this warranty is limited to the relief
expressly provided above. In no event shall CASPR Group be
liable for any consequential or incidental damages you may
incur in connection with your purchase or use of the CASPR
COMPACT. Some states do not allow limitations on how long an
implied warranty lasts, so the above limitations may not apply
to you.
This Warranty gives you specific legal rights, and you may also
have other rights which vary from state to state.
17

18
Specications
Unit
Size: 13” high x 8.75” wide x 10.75” deep
Weight: 10.2 lb.
Coverage: 1500 ft2
Power Cord
Fuyuang Switching Power Supply
Model Number: FY3803000
Input: 100-240VAC 50/60Hz 2.5A Output: 38VDC 3A
See the power supply label for certications and warnings.
Cell
Normal Mode Output
Purication Plate
High Mode Output: 25-360mg ozone per hour
Ionization Needle
24 to 30 KV, 20-30 Khz Ion Generation Pulsator
6 KV DC Needle Ion Generator

19
Records
Purchase Date:
Model Number: CASPR COMPACT
Serial Number:
Distributor Name:
Distributor Phone:
Consumer Information
CASPR Group declines all responsibility for all damages
arising from improper use of the unit or in case of
tampering with the unit.

19
www.CASPRGROUP.COM
