CASPR TILE User manual

TILE Owner’s Manual
CAUTION: Read manual carefully for proper procedures and operation.

2
IMPORTANT SAFETY INSTRUCTIONS
When using an electrical appliance, basic precautions should always be taken.
READ ALL INSTRUCTIONS BEFORE USING THIS PRODUCT
WARNING!
To reduce the risk of re, electrical shock, or injury:
• Use only as described in this manual.
• Do not attempt to repair or adjust any of the electrical or mechanical functions.
Contact Customer Service for service information.
• Do not use outdoors or on wet surfaces.
• Do not allow to be used as a toy. Do not allow children around the unit.
• Do not handle appliance with wet hands.
• Do not allow foreign objects to enter the ventilation openings.
• Keep hair, clothing, ngers, and all parts of body away from openings.
SAVE THESE INSTRUCTIONS
WARNING
UV Light in operation.
Disconnect unit from power supply before servicing.
Failure to follow warnings may result in severe eye
damage and electrical shock.
Please record the name and phone number of your CASPR Distributor.
Name:
Phone#:
Please record the name and phone number of your Independent Contractor.
Name:
Phone#:
Please record the serial number of your product:
Serial #:

3
Congratulations
on your purchase of a TILE by CASPR air purication enhancement system. This
unit is designed to be mounted into a ceiling. Please read and follow all safety
warnings and service procedures outlined in this manual. Use only genuine CASPR
replacement parts available from your Independent HVAC Contractor.
If you have any questions concerning this or any CASPR product, contact your
Independent HVAC Contractor or CASPR Distributor.
Principles of Operation
Nature cleanses the air with lightning and rain. Lightning bolts produce positive
and negative ions which cleanse the air naturally. Rain helps bring ions close to
the earth’s surface. They are then attracted to atmospheric contaminants and
either removed from the air or attached to grounded objects. The TILE with
NCC® Technology mimics nature for indoor air purication using UV light and our
proprietary photocatalytic process to remove harmful contaminants from your
indoor environment. To learn more about this and other CASPR products and
technologies, please visit our website at www.CASPRgroup.com.
Table of Contents
Principles of Operation ................................................................................. 3
Specications.............................................................................................. 4
Install the Cell Assembly .............................................................................. 5
TILE Installation .......................................................................................... 6
Service and Maintenance .............................................................................. 6
Replacement parts (purchased separately): .................................................... 7
Cell Disposal ............................................................................................... 7
Warranty Information................................................................................... 8

4
Specications
Electrical:
110-240 VAC 50/60 Hz 1.8A
277 VAC 50/60 Hz 0.9A (North America only)
Dimensions:
23.9 in. x 23.9 in. x 5.4 in.
60.71 cm x 60.71 cm x 13.72 cm
Mechanical:
88 CFM
149 m3/h (2 fans)
Weight:
10.5 lbs
4.76 kg

5
WARNING
Risk of property damage, injury, or death.
Installation, adjustments, alterations, and service must be
performed by a qualied electrician.
WARNING
Electrical Shock Hazard.
Can cause injury or death. Disconnect all electrical
power supplies before servicing.
Install the Cell Assembly
1. Open the front door of the TILE unit.
2. Remove the Bracket Assembly by
unscrewing the top thumb screw.
3. Remove the 2 additional screws
from the Bracket Assembly.
4. Remove the Cell Assembly from the packaging box.
5. Carefully remove bulb from cell housing.
DO NOT touch the bulb with bare hands.
6. Connect Bulb
to socket in the
Bracket Assembly.
7. Attach Cell Housing to
bracket with previously
removed thumb screws (2).
8. Install Assembly on
TILE unit and secure
with top thumb screw.

6
TILE Installation
The TILE is designed to be mounted in place of a standard 2 ft x 2 ft ceiling tile.
Installation is only to be performed by a qualied electrician. A power switch turns
the unit ON and OFF.
1. Remove the ceiling tile where the TILE unit will be placed.
Be mindful not to place by a return duct.
2. Place TILE unit into the open ceiling square.
3. Hardwire TILE unit into an available power source. This is to be performed by a
licensed professional.
Service and Maintenance
Service should only be performed by a qualied technician. Make sure the power
switch is turned OFF and the unit is unplugged prior to handling.
It is recommended maintenance to vacuum o the vent openings and clean the
under side of the unit if any dust build-up has accumulated.
A face mask should be worn to prevent inhalation of any particles released into the
air during the process. Eye protection may be necessary when cleaning the unit
from below while it is mounted in the ceiling.
1. Open the front door of the TILE unit.
2. Remove the Bracket Assembly by
unscrewing the top thumb screw.
3. Remove the 2 additional screws
from the Bracket Assembly.
4. Remove the Cell Assembly from the packaging box.

7
5. Carefully remove bulb from cell housing.
DO NOT touch the bulb with bare hands.
6. Connect Bulb
to socket in the
Bracket Assembly.
7. Attach Cell Housing to
bracket with previously
removed thumb screws (2).
8. Install Assembly on
TILE unit and secure
with top thumb screw.
Replacement parts (purchased separately):
NCC Cell (Ozone-Free) CELL-VV-14-001-AP
Cell Disposal
Do not throw a used NCC Cell in the garbage. The special germicidal UVC bulb
used in the unit contains a very small amount of mercury. Dispose of the spent
NCC Cell and UV Lamp at your local recycling center or by local regulations. To
learn more, visit www.lamprecycle.org.

8
LIMITED 1 YEAR WARRANTY
Customer should not repackage and ship the TILE unit
due to possibility of irreparable damage. For warranty
service, please contact your CASPR Distributor for the
address of the nearest service center, email
warrant[email protected] call Customer Service at
844-717-8819.
WHAT IS COVERED BY THIS WARRANTY
We warrant the TILE to the Customer, subject to the
conditions below, against defects in workmanship or
material, provided that the products are returned to a
service location within one (1) years of date of purchase.
INSTALLATION AND MAINTENANCE REQUIREMENTS
This warranty is expressly conditioned upon proper
installation, operation, cleaning and maintenance, all in
accordance with the Owner’s Manual. Failure to meet any
of these requirements will void this warranty. Servicing
of your TILE by parties other than our authorized
representatives and/or using parts other than genuine
parts will also void this warranty.
HOW TO OBTAIN WARRANTY SERVICE
Customer must contact their CASPR Distributor and
provide proof of purchase within the above time periods.
We will repair or replace and return the product, without
charge and within a reasonable period of time, subject
to the conditions herein, if its examination shall disclose
any part to be defective in workmanship or material. If
we, in our discretion, are unable to repair the product
after a reasonable number of attempts, we will provide
either a refund of the purchase price or a replacement
unit, at the company’s option.
WHAT IS NOT COVERED BY THIS WARRANTY
Ordinary wear and tear shall not be considered a defect
in workman- ship or material. These warranties do
not apply to lters nor for loss or damage caused by
accident, re, abuse, misuse, improper installation,
leaking, modication, misapplication, or by any repairs
other than those provided by our authorized Service
Center. This warranty is non-transferable.
MISSING SERIAL NUMBERS AND UNAUTHORIZED
CHANNELS
If a valid serial number is missing from the product, the
warranty will be voided. CASPR products are authorized
for sale through CASPR Distributors only. Warranties are
voided if a product is purchased through unauthorized
channels; this includes websites that are not authorized
to use CASPR’s trademarked names, images and logos as
well as Internet auction sites (e.g. eBay and craigslist).
To conrm warranty coverage prior to purchasing a
product, contact CASPR at 844-717-8819 with the serial
number located on the back of the unit.
EXCLUSION OF OTHER WARRANTIES AND
CONDITIONS EXCEPT AS PROVIDED HEREIN, WE
MAKE NO REPRESENTATION OR WARRANTY OF
ANY KIND. ALL OTHER WARRANTIES OF ANY KIND,
EXPRESS OR IMPLIED, ARE HEREBY EXPRESSLY
DISCLAIMED, INCLUDING ANY IMPLIED WARRANTY OF
MERCHANTABILITY OR FITNESS FOR A PARTICULAR
PURPOSE.
LIMITATION OF LIABILITY FOR SPECIAL, INCIDENTAL,
OR CONSEQUENTIAL DAMAGES
WE SHALL NOT IN ANY CASE BE LIABLE FOR
SPECIAL, INCIDENTAL OR CONSEQUENTIAL
DAMAGES ARISING FROM BREACH OF EXPRESSED OR
IMPLIED WARRANTIES, CONDITIONS, GUARANTEES
OR REPRESENTATIONS, BREACH OF CONTRACT,
NEGLIGENCE OR ANY OTHER LEGAL THEORY. Such
excluded damages include, but are not limited to, loss of
prots or revenue, and loss of the use of the products,
and any loss caused by leaks or other water damage.
FOR U.S. APPLICATION ONLY
This warranty gives you specic legal rights, and you
may also have other rights which vary from state
to state. Some states do not allow limitations on
warranties, or on remedies for breach. In such states,
the above limitations may not apply to you.
FOR CANADIAN APPLICATION ONLY
Exclusion of Subsequent Owners: Except as otherwise
required by applicable legislation, this warranty is not
transferable. This warranty gives you specic legal rights
and you may also have other rights which vary from
province to province. Some provinces and territories
do not allow limitations on warranties, or on remedies
for breach. In such provinces or territories, the above
limitations may not apply to you. If any provision of this
warranty or part thereof is held by a court of competent
jurisdiction to be invalid, illegal, or unenforceable, the
validity, legality and enforceability of the remaining
provisions or parts thereof will not in any way be
aected or impaired within the jurisdiction of that
court. This entire warranty shall continue to be valid,
legal and enforceable in any jurisdiction where a similar
determination has not been made.
This warranty is provided by:
CASPR Group, Inc.
4505 Excel Parkway, #600
Addison, TX 75001
SERVICE
Every eort is made to ensure customers receive
an up-to-date instructions manual on the use of our
products; however, from time to time, modications to
our products may without notice make the information
contained herein subject to alteration. For the latest
information, please visit our website.
Warranty Information

9
This equipment has been tested and
found to comply with the limits for
Industrial, Scientic, and Medical
Equipment (ISM), pursuant to
Part 18 of the FCC Rules. These
limits are designed to provide
reasonable protection against
harmful interference in a residential
installation. This equipment
generates, uses, and can radiate
radio frequency energy, and if not
installed and used in accordance
with the instructions, may cause
harmful interference to radio
communications. However, there is
no guarantee that interference will
not occur in a particular installation.
If this equipment does cause harmful
interference to radio or television,
which can be determined by turning
the equipment o and on, the user
is encouraged to try to correct the
interference by one or more of the
following measures:
• Reorient or relocate the receiving
antenna.
• Increase the separation between
the equipment and receiver.
• Connect the equipment into an
outlet on a circuit dierent from
that to which the receiver is
connected.
• Consult the Independent HVAC
Contractor or an experienced
radio/TV technician for help.
FCC DECLARATION OF CONFORMITY
Name: CASPR Group
Model: CATILE21
Manufacturer: CASPR Group.
This device complies with Part 18 of the
FCC Rules.
RESPONSIBLE PARTY
CASPR Group, Inc
4505 Excel Parkway, #600
Addison, TX 75001
Ph: [phone]
Date: May 2021
V. 01052021
