NewTom 5G series –Patient Table Service Procedures 1-1
1 Target and Application Field
This document provide informations and instructions regarding the service functions of the NewTom 5G
series Patient Table.
For more details about NewTom 5G series scanner unit, please refer to the “Service Manual” document.
This manual is intended for trained personnel recognized by the manufacturer of the NewTom 5G series
devices.
Prior to operating or servicing this device, this manual must be read and understood.
Keep this and other associated manuals for future reference and for new operators or qualified service
personnel.
1.1 Attached documents
- 5G - Patient Table Block Schematic
- 5G series - Patient Table with Stretcher Block Schematic

NewTom 5G series –Patient Table Service Procedures 2-1
2 Patient Table
2.1 Service Level Procedures
Special keys combination of the table console, allow to enable SERVICE level (“support modality”)
DANGER:
The usage of the SERVICE level by not authorized
personnel can result in mechanical damages of the
table and/or the scanner and injury of the user.
The SERVICE level must be used without any patient on
the table.
Every movement can be stopped by pressing the
emergency button located under the console keypad.
WARNING:
Pay attention while moving the patient's table
in order to avoid possible collision with object
and/or person.
2.1.1 Service Level Access
From the INFO page hold the button and press the button. The SERVICE Level modality will be
enabled.
In order to disable the SERVICE Level modality repeat the same sequence or turn off and on the device.
INFO page
Once the SERVICE Level is enabled on the POS page the TOOLS page and DATA DEBUG page will appear.
Each page can be selected by pressing the corresponding F1 or F2 buttons.
POS page with SERVICE Level
While in the POS PAGE it is possible to show some additional informations:
-the “X” position will toggle to the “ K ” position when pressing “ + ” on the console
-the “Pantograph Encoder” position will toggle to the “Pantograph Potentiometer” position when
pressing “ - ” on the consolle
X or K
Y
Z
LEGREST ENCODER
BACKREST ENCODER
PHANTOGRAPH ENCODER or
POTENTIOMETER VALUE

NewTom 5G series –Patient Table Service Procedures 2-2
2.1.2 TOOLS page
In the TOOLS page is possible to select the
- “ACTIONS” page by pressing F1 button
- “LIMIT SWITCH” page by pressing the F2 button.
- “POS” page by pressing MODE button.
TOOL page
2.1.2.1 ACTIONS page
The ACTIONS page contain a scroll menu with a list of possible action to perform.
The F1 and F2 buttons allow to move among the list of actions that can be seleted pressing the MODE
button.
ACTIONS page
Some actions require a password in order to be selected. In that case besides the description of the
specific action a 4 digit value will appear.
It possible to modify the value using the “+” and “-” buttons. The value will be incremented/decremented
by 1, 10 or 100 units depending on the pressure duration. The value is reset every time the user scroll
among different actions and if necessary the correct password must be typed again.
The PASSWORD value is 9469.
ACTIONS page showing action with password request
Pressing the MODE button with a wrong password will result in showing for a few seconds a “ACCESS
DENIED!” message.
The provided actions are:
- MOVE ALL ON: Allow to enable the single movement of all axis. After the command has been
enabled the XY axis can be manually moved. Other movements (back rest plate, leg rest plate and
pantograph) could required the corresponding "referencing" signal, before to be manually moved.
- REF. LEGREST: Search for the minimum leg rest plate limit switch; move the leg rest plate to 90°.

NewTom 5G series –Patient Table Service Procedures 2-3
To be used in case, despite the activation of "MOVE ALL ON", the leg rest doesn't move.
- REF. BACKREST: Search for the minimum back rest plate limit switch; move the back rest plate to
90°. To be used in case, despite the activation of "MOVE ALL ON", the back rest doesn't move.
- REF.LIFT MOTOR: Search for the minimum pantograph limit switch; low down the pantograph to
the minimum height. To be used in case, despite the activation of "MOVE ALL ON", the pantograph
rest doesn't move.
- CONSOLLE RIGHT: Store the console position as at the patient's right.
- CONSOLLE LEFT: Store the console position as at the patient's left.
- DAILY REFER.: Perform the daily reset procedure (same as the first movement sequence required
after the device has been turned on)
- FULL REFER.: Perform the complete reset procedure.
- REF.UP-DOWN ALL [PW]: Search for the minimum and maximum limit switch of back rest plate,
leg rest plate, pantograph. Can be run only with the table in the seat position and chair all out of
the gantry
(X = 0mm). ATTENTION: risk of collision between mechanical parts!
- LOAD DEFAULT [PW]: Restore the original manufacturer settings (without resetting the
calibrations)
- GO PACKAGING [PW]: Bring the table to the position for the packaging.
- SET HORIZ POS [PW]: Store in the EEPROM the current position of the back rest plate and consider
it as the "Horizontal Headrest" position (position in which the the back rest plate is moved at the
end of the “P1” button corresponding procedure).
- SET SERIAL NUM [PW]: Set the table serial number. The serial number can be adjusted by pressing
the “+” and “-” buttons.
- XY CALIBRATION [PW]: XY axis board potentiometer calibration. To be performed only after
replacement of the XY motor board and/or potentiometer. Can be run only with the table in the
seat position. (ATTENTION: risk of collision between mechanical parts!)
- POTENT.CALIB. [PW]: Pantograph potentiometer calibration: to be run only after replacement of
pantograph motor/potentiometer. Can be run only with the table in the seat position.
(ATTENTION: risk of collision between mechanical parts!)
- XY LIMITS OFF [PW]: Disable the software limit switches for the XY motor (only the electric limit
switches are enabled)
- EXIT: Exit from the ACTIONS page e return to the TOOLS page.
Once the desired action has been selected the monitor will prompt for the user confirmation.
CONFIRM page

NewTom 5G series –Patient Table Service Procedures 2-4
Pressing the F1 button will confirm the request, pressing the F2 button will cancel the request and will
return to the ACTIONS page, pressing the MODE button will cancel the request and will return to the
HOME page.
After confirming the selected action, in case the action required movements or a sequence that takes a
few seconds, at the end will automatically return to the HOME page, while if the action task can be
carried out instantly the “DONE” message will appear for a few seconds before returning to the TOOLS
page.
2.1.2.2 LIMIT SWITCH page
In the LIMIT SWITCH page are shown the status of the Hardware limit switch for the X,Y,Z,L,B of the anti-
pitch safety switches and of the hand crashing security and of the emergency button. An X sign shows the
active signals. In the bottom right corner the software version is shown.
By pressing the MODE button is possible to return to the TOOLS page.
LIMIT SWITCH page
X = X Axis (gantry in / out)
Y = Patient's left / right
Z = Pantograph
L = Legrest
B = Backrest
A = Anti-pitch safety switch status
E = Emergency button switch status
2.1.3 DATA DEBUG page
In the DATA DEBUG page appear data about the system status.
DATA DEBUG page
St represents the CPU status. It is 0 if OK.
Trepresents the elapsed seconds from the device start up.
E0, E1 and E2 contains the last three error codes and T0, T1 and T2 are the time corresponding
to each error.
The D0..D3 value can assume different meaning depending on the firmware. For version equal or more
recent than 0.8 they represents:
- D0: pantograph potentiometer value corresponding to minimum limit switch.
- D1: 0 if the CAN communication is OK.
- D2: pantograph potentiometer value corresponding to maximum limit switch.
- D3: pantograph potentiometer current value
Pressing the MODE button is possible to return to the POS page.

NewTom 5G series –Patient Table Service Procedures 3-1
3 Patient Table with stretcher
3.1 Service Level Procedures
Special keys combination of the table console, allow to enable SERVICE level (“support modality”)
DANGER:
The usage of the SERVICE level by not authorized
personnel can result in mechanical damages of the
table and/or the scanner and injury of the user.
The SERVICE level must be used without any patient on
the table.
WARNING:
Pay attention while moving the patient's table
in order to avoid possible collision with object
and/or person.
WARNING:
Every movement can be stopped by pressing the
emergency button located under the console keypad
only if the patient table is powered through the 5G
series gantry
3.1.1 Service Level Access
From the INFO page hold the button and press the button. The SERVICE Level modality will be
enabled.
In order to disable the SERVICE Level modality repeat the same sequence or turn off and on the device.
INFO page
WARNING:
If the service mode is enabled, all buttons are available
in the console including longitudinal movements
(FORWARD/BACK)
Once the SERVICE Level is enabled on the POS page, press:
- F1 to enter in the “TOOLS” page
- F2 to enter in the “DATA DEBUG” page
- MODE to return in the “INFO” page.
POS page

NewTom 5G series –Patient Table Service Procedures 3-2
While in the POS PAGE it is possible to show some additional informations:
Stretcher insertion longitudinal absolute quota [mm]
Stretcher transversal movement absolute quota [mm]
Stretcher vertical movement absolute quota [mm]
Stretcher potentiometer relative quota [mm]
Longitudinal pantograph movement relative quota [mm]
Vertical pantograph movement relative quota [internal units]
3.1.2 TOOLS page
In the TOOLS page it is possible to select:
- “ACTIONS” page by pressing F1 button
- “LIMIT SWITCH” page by pressing the F2 button.
- “POS” page by pressing MODE button.
3.1.2.1 ACTION page
The ACTIONS page contain a scroll menu with a list of possible action to perform.
The F1 and F2 buttons allow to move among the list of actions that can be seleted pressing the MODE
button.
Some actions require a password in order to be selected. In that case besides the description of the
specific action a 4 digit value will appear.
It possible to modify the value using the “+” and “-” buttons and change digit by using “F1” and “F2”.
The value is reset every time the user scroll among different actions and if necessary the correct password
must be typed again.
The PASSWORD value is 9753.
If you press MODE button after entering a wrong password, you will return automatically to the ACTION
page

NewTom 5G series –Patient Table Service Procedures 3-3
The provided actions are:
DISABLE COLLISION DETECTION
(ATTENTION: risk of collision between mechanical parts!)
Disable the anticollision security. This settings stays enabled until the device is turned off. To restore the
functionality refer to the command enable collision detection.
ENABLE COLLISION DETECTION
Enable the anticollision security (always enabled by default after device has been turned on).
COMPLETE BURNIN:
(ATTENTION: risk of collision between mechanical parts!)
Perform 40 cycles of predefined movements. To stop the process keep pressed any button for a few
seconds until the DONE.
BURNIN W/O TABLE:
(ATTENTION: risk of collision between mechanical parts!)
Perform 20 cycles of predefined longitudinal and vertical pantograph movements.
To stop the process keep pressed any button for a few seconds until the DONE.
CONSOLLE RIGHT:
Store the console position as at the patient's right.
CONSOLLE LEFT:
Store the console position as at the patient's left.
SET SERIAL NUMBER:
Set the table serial number. The serial number can be adjusted by pressing the “+” and “-” buttons.
Change digit by the arrows keys.
NEW TABLE POT. TYPE:
To setup only in case the small potentiometer cod. 97643500 is mounted (enabled by default).
Perform only for patient table with S/N: 0005 , 0012 and subsequent
OLD TABLE POT. TYPE:
To setup only in case the big potentiometer 97643400 is mounted.
Perform only for patient table with S/N: 0001 ÷ 0004 , 0006 ÷ 0011 (included)
TABLE POT. CALIB:
Perform the stretcher potentiometer calibration.
Slide all the way out the stretcher and press the MODE button. Once the procedure is succesfully carried
out the sign DONE sould appear.
XY CALIBRATION:
(ATTENTION: risk of collision between mechanical parts!)
XY axis board potentiometer calibration. To be performed only after replacement of the XY motor board
and/or potentiometer. To perform also during the table installation
X CALIBRATION:
(ATTENTION: risk of collision between mechanical parts!)
X axis potentiometer calibration. To be performed only after replacement of the X axis potentiometer.
It is part of the XY CALIBRATION process
PANT. FC BOTTOM
(ATTENTION: risk of collision between mechanical parts!)
Search for the minimum limit switch of the pantograph. Procedure performed during device
manufacturing. It is part of the PANT FC BOTH procedure.
PANT. FC TOP
(ATTENTION: risk of collision between mechanical parts!)

NewTom 5G series –Patient Table Service Procedures 3-4
Search for the maximun limit switch of the pantograph.
It is part of the PANT FC BOTH procedure.
PANT. FC BOTH
(ATTENTION: risk of collision between mechanical parts!)
Pantograph potentiometer calibration: to be run only after replacement of pantograph
motor/potentiometer.
This procedure includes both the PANT FC BOTTOM and PANT FC TOP processes.
SET 1177 PANTOGRAPH:
This procedure set the firmware installed on the Hanning 97661177 pantograph board.
To set the board:
1) Disconnect C6 connector (5G - patient table).
2) Disconnect X207 connector located on 97661178 board.
3) Disconnect J8 connector located on 97660897 board.
4) Select “SET 1177 PANTOGRAPH” command from the service menu and press OK to confirm.
5) Turn off the machine.
6) Connect C6 connector (5G - patient table), J8 connector and X207 connector.
7) Turn on the machine and perform the “Pantograph potentiometer calibration”by select PANT. FC
BOTH command from Service menu.
NOTE: It is possible to set only “not setted” boards.
SET 1178 TABLE:
This procedure set the firmware installed on the Hanning 97661178 table board (located on the upper
structure).
To set the board:
1) Disconnect C6 connector (5G - patient table).
2) Disconnect X207 connector located on 97661177 board.
3) Disconnect J8 connector located on 97660897 board.
4) Select “SET 1178 TABLE” command from the service menu and press OK to confirm.
5) Turn off the machine.
6) Connect C6 connector (5G - patient table), J8 connector and X207 connector.
7) Turn on the machine and perform the “Stretcher potentiometer calibration”by select TABLE POT.
CALIB. command from Service menu.
NOTE: It is possible to set only “not setted” boards.

NewTom 5G series –Patient Table Service Procedures 3-5
RESET HANNING BOARDS:
This procedure delete the firmware installed on the Hanning boards (97661177 pantograph board and
97661178 table board).
To reset the boards:
8) Disconnect C6 connector (5G - patient table)
9) Disconnect J8 connector located on 97660897 board.
10) Disconnect X207 connector located on 97661178 board if you want to reset 97661177 board OR
Disconnect X207 connector located on 97661177 board if you want to reset 97661178 board.
11) Select “RESET HANNING BOARDS” command from the service menu, insert the password and press
OK to confirm.
12) Turn off the machine.
13) Connect C6 connector (5G - patient table), J8 connector and X207 connector.
14) Turn on the machine.
EXIT:
Exit from the ACTIONS page and return to the TOOLS page.
If the action task is carried out, “DONE” message will appear for a few seconds before returning to the
ACTIONS page.
3.1.2.2 LIMIT SWITCH page
In the LIMIT SWITCH page are shown the status of the hardware limit switch for the X,Y,Z,LT,UT, A (anti-
pitch safety switches and of the hand crashing security) and E (emergency button).
A white / black small circle shows the active signals. By pressing the MODE button is possible to return to
the TOOLS page.
LIMIT SWITCH page

NewTom 5G series –Patient Table Service Procedures 3-6
The following table shows the meaning of each limit switch
Limit switch
L status
H status
Description
X
Stretcher Longitudinal
movement switches
○
Pantograph all the way out of the gantry
○
Pantograph all the way toward the gantry
Y
Stretcher Transversal
movement switches
○
Stretcher completely on the left
○
Stretcher completely on the right
Z
Pantograpg vertical
movement switches
○
Pantograph in the lowest position
○
Pantograph in the highest position
LT
Stretcher completely out
of the gantry switch
○
Stretcher all the way out of the gantry
UT
Unlock table switch
○
Stretcher lock
A
Anti-pitch safety switch
●
AntiPinch activated
E
Emergency button switch
●
Emergency button activated
3.1.3 DATA DEBUG page
In the DATA DEBUG page appear data about the system status.
DATA DEBUG page
REC= N°of received data packets with errors
TEC= N°of trasmitted data packets with errors
CAN CA0= CAN tree status: if “Ok” connection is good, if “NOk”connection failed
CAN CA1= CAN tree status: if “Ok” connection is good, if “NOk” connection failed
CAN CA2= CAN tree status: if “Ok” connection is good, if “NOk” connection failed
E0,E1,E2,E3= Contains the last four error codes
Press any button to return to the POS page.

NewTom 5G series –Patient Table Service Procedures 3-7
3.1.4 Calibration sequence
WARNING:
In case of it is necessary to perform PANT. FC BOTH
calibration, if the patient table is mechanical connected with
the 5G series gantry, exit from TOOLS page, slide the
stretcher completely out of the gantry and completely draw
back the pantograph by using BACK button.
In case of table installation, console replacement or firmware update, perform the following
calibrations:
1) Insert the device serial number (following procedure SET SERIAL NUMBER)
2) Set the console position (following procedure CONSOLLE RIGHT/ LEFT)
Consolle
right
Consolle
left
3) Select the right type of mounted potentiometer (following procedure NEW TABLE POT. TYPE /
OLD TABLE POT. TYPE)
OLD TYPE potentiometer (cod. 97643400)
mounted on patient table with S/N: 0001 ÷ 0004 , 0006 ÷ 0011 (included)

NewTom 5G series –Patient Table Service Procedures 3-8
NEW TYPE potentiometer (cod. 97643500)
mounted on patient table with S/N: 0005 , 0012 and subsequent
4) Calibration of the stretcher potentiometer (following procedure TABLE POT. CALIB)
5) Calibration of the pantograph potentiometer (following procedure PANT. FC BOTH)
6) XY Calibration (following procedure XY CALIBRATION)
Once all the calibration steps has been carried out restart the device and verify the correct functionality.
In case of potentiometer replacement or after adjustment of the limit switch position follow the next
steps:
1) Select the type of mounted potentiometer (following procedure NEW TABLE POT. TYPE / OLD
TABLE POT. TYPE)
2) Calibration of the stretcher potentiometer (following procedure TABLE POT. CALIB)
3) Calibration of the pantograph potentiometer (following procedure PANT. FC BOTH)
4) XY Calibration (following procedure XY CALIBRATION)
Once all the calibration steps has been carried out restart the device and verify the correct functionality.
In case of replacement of boards responsible for the pantograph movement or for the strectcher position
reading please contact service support.

NewTom 5G series –Patient Table Service Procedures 3-9
3.1.5 Troubleshooting
The following table shows the stretcher / pantograph the correct ranges verificabili from the "POS" page
(by pressing P1 button and with the stretcher completely extracted from the gantry)
Stretcher insertion longitudinal absolute quota 310 ÷ 320 [mm]
Stretcher transversal movement absolute quota -5 ÷ 5 [mm]
Stretcher vertical movement absolute quota 735 ÷ 745 [mm]
Stretcher potentiometer relative quota ≤ 2[mm]
Longitudinal pantograph movement relative quota 200 ÷ 210 [mm]
Vertical pantograph movement relative quota 300 ÷ 315 [internal units]
The following table shows the stretcher / pantograph the correct ranges verificabili from the "POS" page
(by pressing P2 button and with the stretcher completely extracted from the gantry)
Stretcher insertion longitudinal absolute quota 220 ÷ 230 [mm]
Stretcher transversal movement absolute quota -5 ÷ 5 [mm]
Stretcher vertical movement absolute quota 515 ÷ 525 [mm]
Stretcher potentiometer relative quota ≤ 2[mm]
Longitudinal pantograph movement relative quota 260 ÷ 270 [mm]
Vertical pantograph movement relative quota 47 ÷ 57 [internal units]

NewTom 5G series –Patient Table Service Procedures 3-10
The following table includes error codes that could appear on the console display and possible causes /
solutions.
Err. Code
Description
Possible causes / Solutions
1
Power supply of Hanning boards < 26VDC
40VDC power supply of Hanning boards may be
missing or may not be connected properly
2
Power supply of Hanning boards > 43VDC
40VDC power supply of Hanning boards not be
connected properly.
5
Motor or Hanning pantograph board overheating
Wait 2 minutes and try again the movement. If the
error persists, there may be a malfunction of the
pantograph motor or the pantograph is not free to
move.
9
Overcurrent peak output to Hanning pantograph
board
There may be a malfunction of the pantograph motor
13
Short-curcuit output to Hanning boards
The pantograph motor may be faulty, or incorrect
wiring of the motor power supply: X102, X103, X104
on one of the Hanning boards.
16
Enable external command not present on Hanning
boards
May be missing the enable jumper between pins 3 and
2 of X208.
17
Hanning pantograph board movement sequence time
out
The Hanning board may be faulty or not programmed
properly or the pantograph motor is locked
18
Error on the start of the movement of the Hanning
pantograph board.
The Hanning board may be faulty or not programmed
properly
128
Internal timing error on one of the Hanning boards.
The Hanning board may be faulty or not programmed
properly
129
System error of Hanning boards
The Hanning board may be faulty or not programmed
properly
131
Reset for Hanning boards error
The Hanning board may be faulty or not programmed
properly
132
Reset for power supply change in Hanning boards
40VDC power supply of Hanning boards may have
undergone rapid > 5 VDC
133
Software reset of Hanning boards
The Hanning board may be faulty or not programmed
properly
140
CRC error on parameters reading of hanning boards
The Hanning board may be faulty or not programmed
properly
141
Read error of Hanning board table
The Hanning board may be faulty or not programmed
properly
142
Read error on parameters of Hanning boards
The Hanning board may be faulty or not programmed
properly
150
XY axes controller board doesn’t send regularly the
status message.
The board may be turned off, faulty or CANBUS is not
working properly.
151
Hanning pantograph board doesn’t respond correctly
if cyclically interrogated
The board may be faulty, not powered or with wrong
address. CAN may be faulty
152
The Hanning board that control the stretcher position
and handle release doesn't respond properly if
cyclically interrogated
The board may be faulty, not powered or with wrong
address. CAN may be faulty
210 ÷ 213
Error during motion started by remote control
The system can not reach the required positions or
the movement is stopped before its completition
253
There is a position mismatch between the
potentiometer and pantograph encoder
It may not have been carried out a correct
calibration, the Hanning board may have lost some
encoder count or may be an hardware problem to
encoder, potentiometer or wiring.
254
Calibration data stored in the console are not
compatible with the new firmware version just
installed and consequently restored
The console board may have been replaced or
updated with new firmware without calibrations

NewTom 5G series –Patient Table Service Procedures 3-11
3.1.6 Hanning boards connections and interfaces (97661177 / 97661178)

NewTom 5G series –Patient Table Service Procedures 3-12
3.1.7 List of patient table electronic boards
UPPER STRUCTURE BOARDS
1) 97661178 (97660848) –TABLE BOARD
2) 97660897 - XY MOTORS CONTROL BOARD
3) 97660888 –MANAGEMENT BOARD
PANTOGRAPH BOARDS
1) 97660905 –POWER SUPPLY BOARD
2) 97661177 (97661071) –PANTOGRAPH MOTOR BOARD
