Chamberlain TriCode Systems User manual

TriCode LiftMaster Four Button Garage Door Opener Remote Control
Transmitter Coding Instructions
TC4 Four Channel Transmitter Coding Instructions
This device complies with FCC Rules Part 15 and IC Canada Rules and Regulations.
Operation is subject to the following two conditions: (1) This device may not cause harmful
interference and (2) this device must accept any interference received, including
interference that my cause undesired operation. F.C.C. rules prohibit adjustments to or
modification of receiver and/or remote control transmitter circuitry except for changing the
code setting and replacing remote control transmitter battery. THERE ARE NO OTHER
SERVICEABLE PARTS.
CAUTION
ACTIVATE THE TRANSMITTER ONLY WHEN THE DOOR/GATE IS IN FULL VIEW,
FREE OF OBSTRUCTION AND PROPERLY ADJUSTED. NO ONE SHOULD ENTER OR
LEAVE THE DOOR/GATE WHILE IN MOTION. DO NOT ALLOW CHILDREN TO
OPERATE THE REMOTE(S) OR THE DOOR/GATE CONTROL BUTTONS. DO NOT
ALLOW CHILDREN TO PLAY NEAR THE DOOR/GATE.
The TriCode™ digital TC4 transmitter is a four-channel wireless radio control designed for
use with automatic garage/gate operators and access control systems. All TriCode™
products can be used with Linear/Delta 3™, Stanley™ and Multi-Code™ receivers. Two
configuration switches allow the four buttons to be configured to interface with two different
receiver types in the same transmitter. The TriCode™ radio format provides a potential of
2048 different digital codes. Two 10-posistion DIP switches, each capable of 1024 different
digital codes provide these codes. For Delta-3™ products, 512 (256x2) different digitals
codes are available.
SWITCH SETTINGS
CAUTION: To avoid possibility of duplicating codes in adjacent systems, all
transmitters should be recoded prior to operation. Unless using the maximum
number of codes four codes should not be used:
All DIP Switches ON
All DIP Switches Off
DIP Switches alternating ON/OFF
DIP Switches alternating OFF/ON
STEP 1: LOCATE SWITCHES AND CONNECT BATTERY
Locate the DIP switches, configuration switches and battery by sliding down access cover on
front of the transmitter case. DIP switches are numbered 1 through 10. The configuration
switches are located to the right of the DIP switches. The battery is located below the
switches. Connect the battery connector to the 9V battery before programming transmitter

STEP 2: SET TRANSMITTER CONFIGURATION SWITCH(S)
The TriCode™ Transmitter is factory set to Linear/Delta-3™ position. Using a pointed object
set transmitter configuration switches to desired setting..
STEP 3: SET TRANSMITTER DIP SWITCH(S)
The TriCode™ Transmitter DIP switch(s) are factory set, CH1 OFF (1-10) and CH2 ON (1-
10).
Using a pointed object set transmitter DIP switches to desired setting. For Linear/Delta-3™
compatibility, set codes on switches 1 through 8. Switches 9 and 10 are not used for
Linear/Delta-3™ products.
Note: Switches in receiver must match the switches in all transmitters used to
operate the receiver. Some older radios use toggle switches and it may be difficult
to determine 'ON' & 'OFF'. If so, try reverse settings on the TriCode™.
STEP 4: RECODE RECEIVER CODES
Once the transmitter codes have been set, verify the receiver codes are set to the following
settings:
Linear/Delta-3™ Receiver Type Detail
When the TC4 is set to the Linear/Delta-3™ transmitter type, set the receiver DIP switches
as follows.
Receiver 1 - Set switch 1-8 to match switch 1, activates from Button 1.
Receiver 2 - Set switches 1 and 2 OFF, match switches 3-8 on switch 2, activates from
Button 2.
Receiver 3 - Set switch 1 ON, switch 2 OFF, match switches 3-8 on switch 2, activates from
Button 3.
Receiver 4 - Set switch 1 Off, switch 2 ON, match switches 3-8 on switch 2, activates from
Button 4.
Multi-Code™ Receiver Type Detail
When the TC4 is set to the Multi-Code™ transmitter type, set the receiver DIP switches as
follows.
Receiver 1 - Set switch 10 OFF, match switches 1-9 on switch 1, activates from Button 1.
Receiver 2 - Set switch 10 ON, match switches 1-9 on switch 1, activates from Button 2.
Receiver 3 - Set switch 10 OFF. match switches 1-9 on switch 2, activates from Button 3.

Receiver 4 - Set switch 10 ON, match switches 1-9 on switch 2, activates from Button 4.
Stanley™ Radio Receiver Type Detail
When the TC4 is set to the Stanley™ radio transmitter type, set the DIP switches as follows.
Receiver 1 - Set switch 10 OFF, match switches 1-9 on switch 1, activates from Button 1.
Receiver 2 - Set switch 10 ON, match switches 1-9 on switch 1, activates from Button 2.
Receiver 3 - Set switch 10 OFF, match switches 1-9 on switch 2, activates from Button 3.
Receiver 4 - Set the switch 10 ON, match switches 1-9 on code switch 2, activates from
Button 4.
NOTE: The DIP switches in the receiver must match the DIP switches in all transmitters
used to operate the receiver.
STEP 5: TEST THE EQUIPMENT
If not already installed, connect the receivers to the operators as described in their
installation instructions. Be sure the door/gate is clear of people and obstructions.
Activated each transmitter button and verify that each receiver triggers its operator.
Battery Replacement: The 9 volt battery should last 12 to 18 months of normal use. The
red LED on the face of the transmitter will light dimly or not at all when the battery needs
replacing. The battery is located under the access cover.
