Charge Amps Aura User manual

Charge Amps Aura
User Manual

© 2021 Charge Amps AB (publ)
Doc. Nr: 130
629-EN
Rev 01
Charge Amps
Frösundaleden 2B
SE
-169 75 Solna
Sweden
www.chargeamps.com
Org. No. 556897-
7192
Registered office: Solna
2
Care for the environment! Must not be discarded with household waste! This
product contains electrical or electronic components that should be
recycled. Leave the product for recycling at the designated station e.g. the
local authority's recycling station.
Disposal of the product must comply to the local environmental laws and
guidelines. The product consists of recycled aluminium, plastic, and
electronics, and should be recycled as specified for these materials.
Approved in accordance with the relevant EU directives.
Neglecting to follow and carry out the directions, instructions and safety precautions of
this user manual implies that any warranty provisions will be cancelled and that Charge
Amps AB can reject any and all claims for compensation in connection with any
injuries/damage or incidents – direct or indirect – that are a result of such negligence.
The manufacturer does not give any warranties as to the accuracy or completeness of
this document and shall have no liability for the consequences of use of such information.
The manufacturer reserves the right to make changes to information published in this
document without notice. Visit www.chargeamps.com for the latest document releases.
© Copyright Charge-Amps AB 2021. All rights reserved. Copying, amending and
translating are strictly forbidden without prior written approval from Charge-Amps AB.

© 2021 Charge Amps AB (publ)
Doc. Nr: 130
629-EN
Rev 01
Charge Amps
Frösundaleden 2B
SE
-169 75 Solna
Sweden
www.chargeamps.com
Org. No. 556897-
7192
Registered office: Solna
3
1. Safety
WARNING! Read all instructions before use.
•Improper use may create a risk of personal injury.
•The product must only be installed by a qualified electrician in accordance with
the Installation Manual.
•National installation requirements and restrictions apply.
•Only use this product for charging compatible electric vehicles.
•Inspect the product for visible damage before use.
•Never attempt to repair or use the product if it is damaged.
•Do not immerse the product in water, subject it to physical abuse or insert foreign
objects in any part of the product.
•Never attempt to disassemble the product in any way.
2. Technical Data
Article number
101010 / 101010-LTE*
Charging standard
Mode 3
EV power supply identifier
Identification
RFID( i/a) HF, 13.56 MHz
Internet connection
WiFi 802.11b/g/n, 2.4 GHz
Metering
3-phase voltage, current and power
External RCD needed
No
Operating temperatures
-30 °C to +45 °C
Voltage
230/400 V
Sockets
2 x 22 kW Type 2
IK-rating
IK10
IP-rating
IP55
Dimensions (B x D x H)
367 x 159 x 405 mm

© 2021 Charge Amps AB (publ)
Doc. Nr: 130
629-EN
Rev 01
Charge Amps
Frösundaleden 2B
SE
-169 75 Solna
Sweden
www.chargeamps.com
Org. No. 556897-
7192
Registered office: Solna
4
Weight
10 kg
RFID Frequency Range
13.553 – 13.567 MHz
RFID Output
31 dBm
WiFi Frequency Range
2412 - 2484 MHz
WiFi Output
802.11 b/g/n: 20/17/14 dBm
*Specification of 101010-LTE
RF Technology
GSM, GPRS, EDGE, UMTS/HSPA+, LTE
Max RF output
32 dBm@GSM, 24 dBm@WCDMA, 23 dBm@LTE
RF Range
698 - 868 / 1650 – 2690 MHz
SIM card
Standard SIM

© 2021 Charge Amps AB (publ)
Doc. Nr: 130
629-EN
Rev 01
Charge Amps
Frösundaleden 2B
SE
-169 75 Solna
Sweden
www.chargeamps.com
Org. No. 556897-
7192
Registered office: Solna
5
3. Product Overview
3.1. Parts
A. RFID reader
B. RFID light
C. EV socket
D. Socket light
E. Cylinder lock
3.2. Contents of the package
•Charge Amps Aura
•Cable slide with fittings, plugs and screw
•Two keys for the cylinder lock (Only to be opened by a qualified installer during
installation)
•Two RFID cards
•Quick Guide User
D
C
A
B
E
C
C
B
D

© 2021 Charge Amps AB (publ)
Doc. Nr: 130
629-EN
Rev 01
Charge Amps
Frösundaleden 2B
SE
-169 75 Solna
Sweden
www.chargeamps.com
Org. No. 556897-
7192
Registered office: Solna
6
4. Use
4.1. Cloud service & App
Charge Amps Cloud and Charge Amps App are available for Charge Amps Aura
connected to Charge Amps as cloud provider.
For Charge Amps Auras connected to other cloud providers, please refer to your cloud
provider for inquiries about portals and apps.
Charge Amps App
Charge Amps Cloud
https://my.charge.space/
Visit link to find full product documentation.
https://www.chargeamps.com/product/charge-amps-aura/

© 2021 Charge Amps AB (publ)
Doc. Nr: 130
629-EN
Rev 01
Charge Amps
Frösundaleden 2B
SE
-169 75 Solna
Sweden
www.chargeamps.com
Org. No. 556897-
7192
Registered office: Solna
7
4.2. Add RFID card
Add RFID cards using the cloud service.
4.3. Charging without RFID identification
1. Connect the EV connector to the car. Lift the socket cover and connect the EV
plug to the EV socket.
2. Disconnect the EV connector from the car and disconnect the EV plug from the
EV socket.
4.4. Charging with RFID identification
1. Connect the EV connector to the car. Lift the socket cover and connect the EV
plug to the EV socket.
2. Briefly hold the RFID card in front of the RFID reader to initiate charging.
If the other socket is not in use, it will turn dark and be unavailable for use
during the 5 minutes RFID verification time window.
If no RFID card has been verified during the 5 minutes time window,
charging needs to be initiated remotely or reactivated by unplugging and
reconnecting the EV connector.
3. Disconnect the EV connector from the car and disconnect the EV plug from the
EV socket.
4.5. Cable lock
During charging the cable lock is automatically activated.
To lock the EV charging cable to Charge Amps Aura while not charging, use Charge Amps
App or Cloud Service.

© 2021 Charge Amps AB (publ)
Doc. Nr: 130
629-EN
Rev 01
Charge Amps
Frösundaleden 2B
SE
-169 75 Solna
Sweden
www.chargeamps.com
Org. No. 556897-
7192
Registered office: Solna
8
4.6. Status Indications
Status
Socket Light
RFID Light
Ready for charging
Green light
No light
Charging
Blue light
Green light
Waiting for load balancing
Flashing blue light
No light
Waiting for RFID verification
Yellow light
Flashing blue light
Charging complete
Yellow light
No light
RFID card not approved
Yellow light
Red/Flashing
Blue light *
RFID verification timeout
Yellow light
Red light
Error
Red light
Red light
EV socket not available for
use
No light
No light
* Auto return to Waiting for RFID verification
5. Maintenance
WARNING! Never spray water or any other liquid directly on the product.
5.1. Regular maintenance
•Visually check that the EV connector is free from damage.
•The outside of the product must be regularly wiped with a clean, dry cloth to
remove dirt and dust.
•Do not use detergent to clean any of the product components.

© 2021 Charge Amps AB (publ)
Doc. Nr: 130
629-EN
Rev 01
Charge Amps
Frösundaleden 2B
SE
-169 75 Solna
Sweden
www.chargeamps.com
Org. No. 556897-
7192
Registered office: Solna
9
6. Product support and service
If you have any questions or problems with the product, support is always available.
To find answers to your questions most quickly:
Read through the user manual to check whether your questions are answered there.
1. If your question is not answered in the manual, please contact your supplier or
cloud provider.
2. If you need service or repair, start by contacting the supplier from whom you
purchased the product.
3. For additional information, see chargeamps.com/support.
7. Warranty
As warranty terms may differ from market to market, we recommend that you contact
your supplier regarding the warranty terms.
