Chauvet COLORband PiX Mini User manual

User Manual

Page 2 of 20 COLORband PiX™ Mini User Manual (Rev. 02)
TABLE OF CONTENTS
1. Before You Begin................................................................................3
What Is Included ...........................................................................................3
Unpacking Instructions..................................................................................3
Claims...................................................................................................................3
Text Conventions ..........................................................................................3
Icons.............................................................................................................3
Document Information...................................................................................3
Product at a Glance.......................................................................................4
Safety Notes .................................................................................................4
2. Introduction.........................................................................................5
Product Overview..........................................................................................5
Product Dimensions......................................................................................6
3. Setup...................................................................................................7
AC Power......................................................................................................7
Fuse Replacement.................................................................................................7
Power Linking........................................................................................................8
Mounting.......................................................................................................9
Orientation.............................................................................................................9
Rigging..................................................................................................................9
4. Operation ..........................................................................................10
Control Panel Operation..............................................................................10
Menu Map...................................................................................................10
Configuration (DMX)....................................................................................11
DMX Personalities and Starting Address..............................................................11
Sectional Control..................................................................................................11
DMX Channel Assignments and Values.......................................................12
7-CH....................................................................................................................12
3-CH....................................................................................................................12
4-CH....................................................................................................................12
6-CH....................................................................................................................13
9-CH....................................................................................................................13
18CH...................................................................................................................14
Configuration (Standalone)..........................................................................15
Static Color Mode ................................................................................................15
Automatic Mode...................................................................................................15
Custom Static Color Mode....................................................................................15
Master/Slave Mode..............................................................................................16
5. Technical Information ......................................................................17
Product Maintenance ..................................................................................17
General Troubleshooting.............................................................................18
Contact Procedure ......................................................................................19
CHAUVET® Contact Information.................................................................19
Returning Products to CHAUVET®..............................................................19
6. Technical Specifications..................................................................20

COLORband PiX™ Mini User Manual (Rev. 02) Page 3 of 20
1.BEFORE YOU BEGIN
What Is
Included
•1 x COLORband PiX™ Mini
•1 x Power Cord
•2 x L-Brackets
•1 x Warranty Card
•1 x Quick Reference Guide
Unpacking
Instructions
Immediately upon receipt, carefully unpack the product and check the container to make
sure you have received all the parts indicated above in good condition.
Claims
If the container or the material inside the container (the product and
included
accessories) appear damaged from shipping, or show signs of mishandling,
upon receipt
notify the carrier immediately, not CHAUVET®.
Failure to do so in a timely manner may
invalidate your claim with the carrier. In addition, keep the container and all the pa
cking
material for inspection.
For other issues
such as missing components or parts, damage not related to shipping,
or concealed damage, file a claim with CHAUVET®
within seven (7) days of receiving
the merchandise.
Text
Conventions
Convention Meaning
1~512
A range of values
50/60
A set of values of which only one can be chosen
Settings
A menu option not to be modified
Menu > Settings
A sequence of menu options to be followed
<ENTER>
A key to be pressed on the product’s control panel
ON
A value to be entered or selected
Icons
Icon
Meaning
Critical installation, configuration, or operation information. Failure
to comply with this information may render the product partially or
completely inoperative, cause damage to the product, or cause
harm to the user.
Important installation or configuration information. Failure to
comply with this information may prevent the product from
functioning correctly.
Useful non-critical information.
Document
Information
The information and specifications contained in this document are subject to change
without notice. CHAUVET® assumes no responsibility or liability for any errors or
omissions that may appear in this manual.
CHAUVET® reserves the right to update the
existing document or to create a new document to correct any errors or omissions.
You can download the latest version of this document from www.chauvetlighting.com.
© Copyright 2012 CHAUVET®. All rights reserved.
Electronically published by CHAUVET® in the United States of America
Author
Date
Editor
Date
A. Diaz 1/11/12 S. Graham 1/12/12

Page 4 of 20 COLORband PiX™ Mini User Manual (Rev. 02)
Product at a
Glance
Use on Dimmer

Auto Programs

Outdoor Use

Auto-ranging Power Supply

Sound Activated

Replaceable Fuse

DMX

User Serviceable

Master/Slave

Duty Cycle

Safety Notes
Please read the following Safety Notes carefully before working with the product. The
Notes include important safety information about installation, usage, and maintenance.
•Always connect the product to a grounded circuit to avoid the risk of electrocution.
•Always disconnect the product from the power source before cleaning or replacing
the fuse.
•Avoid direct eye exposure to the light source while the product is on.
•Make sure the power cord is not crimped or damaged.
•Never disconnect the product from power cord by pulling or tugging on the cord.
•If mounting the product overhead, always secure to a fastening device using a
safety cable.
•Make sure there are no flammable materials close to the product when operating.
•Do not touch the product’s housing when operating because it may be very hot.
•Always make sure that the voltage of the outlet to which you are connecting the
product is within the range stated on the decal or rear panel of the product.
•The product is for indoor use only! (IP20) To prevent risk of fire or shock, do not
expose the product to rain or moisture.
•Always install the product in a location with adequate ventilation, at least 20 in (50
cm) from adjacent surfaces.
•Be sure that no ventilation slots on the product’s housing are blocked.
•Never connect the product to a dimmer.
•Make sure to replace the fuse with another of the same type and rating.
•Never carry the product from the power cord or any moving part. Always use the
hanging/mounting bracket or the handles.
•The maximum ambient temperature (Ta) is 104° F (40° C). Do not operate the
product at higher temperatures.
•In the event of a serious operating problem, stop using the product immediately.
•Never try to repair the product. Repairs carried out by unskilled people can lead to
damage or malfunction. Please contact the nearest authorized technical assistance
center.
•Keep this User Manual for future consultation. If you sell the product to another
user, be sure that they also receive this document.

COLORband PiX™ Mini User Manual (Rev. 02) Page 5 of 20
2.INTRODUCTION
Product Overview
Power Out
Power In
Sound Sensitivity Knob
Microphone
LED Display
Bracket Adjustment Knob
5-pin DMX Connectors
3-pin DMX Connectors

Page 6 of 20 COLORband PiX™ Mini User Manual (Rev. 02)
Product Dimensions

COLORband PiX™ Mini User Manual (Rev. 02) Page 7 of 20
3.SETUP
AC Power
The COLORband PiX™ Mini has an auto-
ranging power supply and it can work with an
input voltage range of 100~240 VAC, 50/60 Hz.
To determine the product’s power requirements (circuit breaker, power
outlet, and
wiring), use the current value listed on the label affixed to the product’s back panel, or
refer to the product’s specifications chart. The listed current rating indicates the
product’s average current draw under normal conditions.
Always connect the product to a protected circuit
(circuit breaker or fuse). Make
sure the product has
an appropriate electrical ground to avoid the risk of
electrocution or fire.
Never connect the product to
a rheostat (variable resistor) or dimmer circuit, even
if the rheostat or dimmer channel serves only as a 0% to 100% switch.
Fuse
Replacement Follow the instructions below to change the fuse, if necessary.
Disconnect the product from the power outlet before replacing the fuse.
1. Wedge the tip of a flat-head screwdriver into the slot of the fuse holder.
2. Pry the fuse holder out of the housing.
3. Remove the blown fuse from the holder and replace with a fuse of the exact same
type and rating.
4. Insert the fuse holder back in place and reconnect power.
The product does not ship with a spare fuse; however, the safety cap has room
for a spare.
Installed fuse
(held by plastic clip)
Spare fuse holder
(inside safety cap)
Safety cap

Page 8 of 20 COLORband PiX™ Mini User Manual (Rev. 02)
Power Linking
The product provides power linking via the IEC outlet located in the back of the unit (see
diagram below).
Power Linking
Diagram
You can power link up to 20 COLORband PiX™ Mini units on 120 VAC or up to 35
COLORband PiX™ Mini units on 230 VAC.
The power linking diagram shown above corresponds to the North American
version of the product ONLY! If using the product
in other markets, you must
consult with the local CHAUVET® distributor because
power linking connectors
and requirements may differ in your country or region.
1st Product
2nd Product
3rd Product
Other products

COLORband PiX™ Mini User Manual (Rev. 02) Page 9 of 20
Mounting
Before mounting the product
, read and follow the safety recommendations indicated in
the Safety Notes.
Orientation
The COLORband PiX™ Mini
may be mounted in any position; however, make sure
adequate ventilation is provided around the product.
Rigging
•Before deciding on a location for the product, always make sure there is easy
access to the product for maintenance and programming purposes.
•Make sure that the structure or surface onto which you are mounting the
product
can support the product’s weight. Please see the Technical Specifications for weight
information.
•When mounting the product
overhead, always use a safety cable. Mount the
product securely to a rigging point, whether an elevated platform or a truss.
•When rigging the
product onto a truss, you should use a mounting clamp of
appropriate weight capacity. Thebracket has a 13-mm hol
e, which is appropriate for
this purpose.
•
When power linking multiple products, you must always consider the length of the
power linking cable and mount the products close enough for the cable to reach.
•The bracket adjustment knobs allow for directional ad
justment when aiming the
product to the desired angle. Only loosen or tighten the bracket knobs manually.
Using tools could damage the knobs.
•
The mounting brackets also serve as floor supports/allow for surface mounting.
When mounting the product on the fl
oor, make sure that the product and cables are
away from people and vehicles.
Mounting Diagram
Bracket
Adjustment Knob
Mounting Bracket
L-Bracket (x2)

Page 10 of 20 COLORband PiX™ Mini User Manual (Rev. 02)
4.OPERATION
Control Panel
Operation
To access the control panel functions, use the four buttons located underneath the
display. Please refer to the Product Overview to see the button locations
on the control
panel.
Button Function
<MENU> Press to find an operation mode or to back out of the current menu
option
<UP> Press to scroll up the list of options or to find a higher value
<DOWN> Press to scroll down the list of options or to find a lower value
<ENTER>
Press to activate a menu option or a selected value
Menu Map
Mode Programming Steps Description
Static Colors C--
C1 Red
C2
Green
C3
Blue
C4 Cyan
C5 Magenta
C6 Yellow
C7
White
Auto Programs P--
P1 7-Color Switching
P2 7-Color Fading
P3 3-Color Switching
P4 3-Color Fading
P5 Chase Program
P6
7-Color Sound Active
P7 7-Color Sound Active Chase + Strobe
Program Speed S-- S001-S100 Selects auto program speed
Slave Mode
SLA
Sets Slave Mode
Custom Color
Mixing U--
r--
Red
g-- Green
b--
Blue
DMX
Personalities
3-CH
d001-d512 Selects DMX starting address
4-CH
6-CH
7-CH
9-CH
18-CH

COLORband PiX™ Mini User Manual (Rev. 02) Page 11 of 20
Configuration
(DMX)
Set the product in DMX mode to control with a DMX controller.
1. Connect the product to a suitable power outlet.
2. Turn the product on.
3. Connect a DMX cable from the DMX output of the DMX controller to the DMX input
socket on the product.
DMX
Personalities
and
Starting
Address
The COLORband PiX™ Mini has six DMX personalities, from a 3-channel mode for basic
control to an 18-channel mode with more advanced control over the lights.
The COLORband PiX™ Mini uses up to 18 DMX channels in its 18-
channel DMX mode,
which defines the highest configurable address to 495.
When selecting a starti
ng DMX address, always consider the number of DMX channels
the selected DMX mode uses. If you choose a starting address that is too high, you could
restrict the access to some of the product’s channels.
If you are not familiar with the DMX protocol, download the DMX Primer from
www.chauvetlighting.com.
To select the DMX personality, do the following:
1. Press <MENU> repeatedly until 3-CH, 4-CH, 6-CH, 7-CH, 9-CH, or 18CH shows on
the display.
2. Press <ENTER> to choose your DMX personality when it appears on the display.
To then choose your starting address:
1. The display should show d1once you’ve selected your DMX personality using the
steps above.
2. Use <UP> or <DOWN> to select the starting address.
3. Press <ENTER>.
Sectional
Control
The COLORband PiX™ Mini offers section control of the lights, anywhere from 2 through
6 sections. To access this, simply choose the DMX personality as shown above. The
diagrams for what each DMX personality controls are below.
Note: not all DMX personalities offer sectional control.

Page 12 of 20 COLORband PiX™ Mini User Manual (Rev. 02)
DMX Channel Assignments and Values
7-CH
Channel Function Value Setting
1
Red
000 255
0~100%
2
Green
000 255
0~100%
3
Blue
000

255
0~100%
4 Color Macros
000 015
No function
016 255
Color Macros
5 Speed 000 255
Speed (slow to fast)
(when CH.6 is from 032~233)
Strobe
(CH.1-CH.4 only)
000 015
No function
016 255
0~30 Hz
6 Auto Programs
000 031
No function
032 063
Pulse effect 0%~100%
064 095
Pulse effect 100%~0%
096 114
Pulse effect 100%~0%~100%
115 127
Chase program
128 159
Auto fade transition
160 191
Auto snap transition (3 colors)
192 223
Auto snap transition (7 colors)
224 255
Sound active mode
7
Dimmer
000 255
0~100%
3-CH
Channel Function Value Setting
1
Red
000 255
0~100%
2
Green
000 255
0~100%
3
Blue
000 255
0~100%
4-CH
Channel
Function
Value
Setting
1
Red
000 255
0~100%
2
Green
000 255
0~100%
3
Blue
000 255
0~100%
4
Dimmer
000 255
0~100%

COLORband PiX™ Mini User Manual (Rev. 02) Page 13 of 20
6-CH
Channel Function Value Setting Section
1
Red
000 255
0~100%
1
2
Green
000 255
0~100%
3
Blue
000 255
0~100%
4
Red
000 255
0~100%
2
5
Green
000 255
0~100%
6
Blue
000 255
0~100%
9-CH
Channel Function Value Setting Section
1
Red
000 255
0~100%
1
2
Green
000 255
0~100%
3
Blue
000 255
0~100%
4
Red
000 255
0~100%
2
5
Green
000 255
0~100%
6
Blue
000 255
0~100%
7
Red
000

255
0~100%
3
8
Green
000 255
0~100%
9
Blue
000 255
0~100%

Page 14 of 20 COLORband PiX™ Mini User Manual (Rev. 02)
18CH
Channel
Function
Value
Setting
Section
1
Red
000 255
0~100%
1
2
Green
000 255
0~100%
3
Blue
000 255
0~100%
4
Red
000 255
0~100%
2
5
Green
000 255
0~100%
6
Blue
000 255
0~100%
7
Red
000 255
0~100%
3
8
Green
000 255
0~100%
9
Blue
000 255
0~100%
10
Red
000 255
0~100%
4
11
Green
000 255
0~100%
12
Blue
000 255
0~100%
13
Red
000 255
0~100%
5
14
Green
000 255
0~100%
15
Blue
000 255
0~100%
16
Red
000 255
0~100%
6
17
Green
000 255
0~100%
18
Blue
000 255
0~100%

COLORband PiX™ Mini User Manual (Rev. 02) Page 15 of 20
Configuration
(Standalone)
Set the product in one of the standalone modes to control without a DMX controller.
1. Connect the product to a suitable power outlet.
2. Turn the product on.
Never connect a product that is operating in any standalone mode (either Static,
Automatic, or Sound) to a DMX string connected to a DMX controller. Products in
standalone mode may transmit DMX signals that could interfere with the DMX
signals from the controller.
Static Color Mode
To enable the Static Color Mode, do the following:
1. Press <MENU> repeatedly until C-- shows on the display.
2. Press <ENTER>.
3. Use <UP> or <DOWN> to choose a color (C1-C7).
4. Press <ENTER>.
Automatic Mode
To enable the Automatic Mode, follow the instructions below:
1. Press <MENU> repeatedly until P-- shows on the display.
2. Press <ENTER>.
3. Use <UP> or <DOWN> to choose your auto program (P1-P7).
4. Press <ENTER>.
You can adjust the speed of the automatic program as well.
1. Press <MENU> repeatedly until S-- shows on the display.
2. Press <ENTER>.
3. Use <UP> or <DOWN>
to adjust the duration of each step of the automatic program
from S001(slow) to S100 (fast).
4. Press <ENTER>.
Custom Static
Color Mode
To enable the Custom Static Color Mode, follow the instructions below:
1. Press <MENU> repeatedly until U-- shows on the display.
2. Press <ENTER>.
3. Press <UP> or <DOWN> to choose between colors (r--, g--, b--).
4. Press <ENTER>.
5. Press <UP> or <DOWN> to choose the intensity of the color (000-100).
6. Repeat the steps to mix additional colors to create the color you need.
7. Press <ENTER>.

Page 16 of 20 COLORband PiX™ Mini User Manual (Rev. 02)
Master/Slave
Mode
The Master/Slave mode allows a single COLORband PiX™ Mini unit (the “master”) to
control the actions of one or more COLORband PiX™ Mini
units (the “slaves”) without
the need of a DMX controller. The master unit will be set to operate in either Automatic
or Sound Active mode, while the slave units will be set to operate in Slave Mode. Once
set and connected, the slave units will operate in unison with the master unit.
Configure the units as indicated below.
Slave units:
1. Press <MODE> repeatedly until SLA shows on the display.
2. Press <ENTER> to accept.
3. Set the DMX address to 001.
4. Connect the DMX input of the first slave unit to the DMX output of the master unit.
5. Connect the DMX input of the subsequent slave units to the DMX output of the
previous slave unit.
6. Finish setting and connecting all the slave units.
Master unit:
1. Set the master unit to operate in either Automatic or Sound mode.
2. Make the master unit the first unit in the DMX daisy chain.
•Configure
all the slave units before connecting the master unit to the DMX
daisy chain.
•
Never connect a DMX controller to a DMX string configured for Master/Slave
operation because the controller
may interfere with the signals from the
master unit.
•Do not connect more than 31 slave units to the master unit.

COLORband PiX™ Mini User Manual (Rev. 02) Page 17 of 20
5.TECHNICAL INFORMATION
Product
Maintenance
Dust build-
up reduces light output performance and can cause overheating. This can
lead to reduction of the light source’s life.
To maintain optimum performance and
minimize wear, you should clean your lighting products at least twice a month. However,
be aware that usage and environmental conditions could be contributing factors to
increase the cleaning frequency.
To clean the product, follow the instructions below:
•Unplug the product from power.
•Wait until the product is cold.
•Use a vacuum (or dry compressed air) and a soft brush to remove dust collected on
the external surface/vents.
•Clean all transparent surfaces with a mild soap solution, ammonia-free glass
cleaner, or isopropyl alcohol.
•Apply the solution directly to a soft, lint-free cotton cloth or a lens cleaning tissue.
•Carefully wipe any dirt or grime to the outside edge of the transparent surface.
•Gently polish the transparent surfaces until they are free of haze and lint.
Always dry the transparent surfaces carefully after cleaning them.

Page 18 of 20 COLORband PiX™ Mini User Manual (Rev. 02)
General Troubleshooting
Symptom Possible Cause Possible Action
Circuit breaker or fuse
keeps blowing
Excessive load on the circuit
Make sure that the total load does not
exceed 80% of the breaker or fuse nominal
current
Short circuit along the power lines
Check the power lines and power cords
Product does not power
up
No energy on power outlet
Check power outlet
Change to another outlet
Loose or damaged power cord
Check the power cord
Blown fuse
Replace blown fuse with a good one of the
same type and rating
Internal problem
Send product for repair
Product does not
respond to DMX
Wrong starting address on the product
Set the correct starting address on the
product
Use the right fader(s) on the controller
Wrong DMX personality on the product
Set the correct DMX product’s personality
Assign the faders accordingly
Wrong polarity setting on the DMX
controller
Change the signal polarity on the controller
Loose or damaged DMX cable
Check the DMX cable before the faulty unit
Internal problem
Send product for repair
Intermittent DMX
problems
Signal cables are not DMX compatible
Replace non-DMX cables with true DMX
cables
Interference with AC or radio signals
Keep DMX cables away from AC wires or
radio equipment
DMX cable too long
Install an optically coupled DMX amplifier
right before the product with intermittent
problems
Too many products connected
Install an optically coupled DMX amplifier
after unit #32
Terminator not connected
Install a terminator as indicated in the DMX
Primer
If you still experience problems after trying the above solutions, contact
CHAUVET® Technical Support.

COLORband PiX™ Mini User Manual (Rev. 02) Page 19 of 20
Contact
Procedure
In case you need to return a product or request support, follow the procedure below:
•If you live in the U.S., contact CHAUVET® World Headquarters (see below).
•If you live in the UK or Ireland, contact CHAUVET® Europe Ltd.(see below).
•If you live in any other country, DO NOT contact CHAUVET®. Instead, contact your
distributor of record. Refer to our Web site for contact details of distributors outside
the U.S., United Kingdom, or Ireland.
CHAUVET®
Contact
Information
World Headquarters
CHAUVET®
General Information
Address: 5200 NW 108th Avenue
Sunrise, FL 33351
Voice: [phone]
Fax: [phone]
Toll free: [phone]
United Kingdom & Ireland
CHAUVET® Europe Ltd.
General Information
Address: Unit 1C
Brookhill Road Industrial Estate
Pinxton, Nottingham, UK
NG16 6NT
Voice: [phone]
Fax: [phone]
Technical Support
Voice: [phone] (Press 4)
Fax: [phone]
Email: [e-mail]
Technical Support
Email: [e-mail]
World Wide Web
www.chauvetlighting.com
World Wide Web
www.chauvetlighting.co.uk
If you live outside the U.S., United Kingdom, or Ireland, contact your distributor of
record and follow their instructions on how to return CHAUVET® product
s to
them. Visit our website for contact details.
Returning
Products
to
CHAUVET®
Call the corresponding CHAUVET®
Tech Support office and request a Return
Merchandise Authorization (RMA) number before shipping the product
. Be prepared to
provide the model number, serial number, and a brief description of the cause f
or the
return.
You must send the merchandise prepaid, in its original box, and with its original packing
and accessories. CHAUVET® will not issue call tags.
Clearly label the package with the RMA number. CHAUVET® will refuse any product
returned without an RMA number.
Write the RMA number on a properly affixed label. DO NOT write the RMA number
directly on the box.
Before sending the product, clearly write
the following information on a piece of paper
and place it inside the box:
•Your name
•Your address
•Your phone number
•The RMA number
•A brief description of the problem
Be sure to pack the product
properly. Any shipping damage resulting from inadequate
packaging will be your responsibility. As a suggestion, proper FedEx
packing or
double-boxing are recommended methods of packaging.
CHAUVET®
reserves the right to use its own discretion to repair or replace
returned product(s).

Page 20 of 20 COLORband PiX™ Mini User Manual (Rev. 02)
6.TECHNICAL SPECIFICATIONS
Dimensions and
Weight
Length
Width
Height
Weight
21.8 in (554 mm)
6.1 in (154 mm)
2.5 in (64 mm)
4.9 lbs (2.2 kg)
Note: Dimensions in inches rounded to the nearest decimal digit.
Power
Power Supply Type
Range
Voltage Selection
Switching (internal)
100~240 V, 50/60 Hz
Auto-ranging
Parameter
120 V, 60 Hz
230 V, 50 Hz
Consumption
47 W
51 W
Operating
0.4 A
0.2 A
Power linking current (units)
8 A (20 units)
8 A (35 units)
Fuse
F 1 A, 250 V
F 1 A, 250 V
Power I/O
US/Worldwide
UK/Europe
Power input connector
IEC
IEC
Power output connector
Edison
IEC
Power Cord plug
Edison (US)
Local plug
Light Source
Type
Power
Lifespan
LED
3 W
50,000 hours
Color
Quantity
Current
Tri-color
6
350 mA
Photo Optic
Parameter
Strobe Rate
0~30 Hz
Illuminance @ 2 m
1,300 lux
Beam angle
19º
Field angle
35°
Thermal
Maximum External Temp.
Cooling System
104° F (40° C)
Convection
DMX
I/O Connectors
Connector Type
Channel Range
3-pin and 5-pin XLR
Sockets
3, 4, 6, 7, 9, 18
Ordering
Product Name
Item Code
Item Number
COLORband PiX™ Mini
03020470
COLORBANDPIXMINI
