Chauvet Scorpion GBC User manual

User Manual
LASER LIGHT
AVOID DIRECT EYE EXPOSURE
CLASS IIIa LASER PRODUCT
CLASSIFIED PER 21 CFR 1040.10 & .11
Complies with US FDA CDRH laser safety
standards 21 CFR 1040.10 & 1040.11

Page 2 of 52 Scorpion™ GBC 2.0/RGY User Manual (Rev. 2 ML)
TABLE OF CONTENTS
1. Before you Begin............................................................................................4
Laser Safety Labels...................................................................................................7
Laser Emission Data..................................................................................................8
Scorpion™ GBC 2.0........................................................................................................8
Scorpion™ RGY..............................................................................................................8
Laser Compliance Statement ...........................................................................................8
2. Introduction.....................................................................................................9
Overview...................................................................................................................9
Dimensions ...............................................................................................................9
3. Setup .............................................................................................................10
Power Linking................................................................................................................10
Mounting.................................................................................................................11
Orientation.....................................................................................................................11
Rigging..........................................................................................................................11
4. Operation.......................................................................................................12
Changing Options on the Current Menu Branch..............................................................12
Changing Options on a Different Menu Branch...............................................................12
Configuration...........................................................................................................14
Starting Address............................................................................................................14
Sound Mode..................................................................................................................14
Automatic Mode.............................................................................................................15
Laser Sky Color Mode ...................................................................................................15
Laser Sky Effect Mode...................................................................................................15
Reverse Motion .............................................................................................................15
DMX Channel Assignments and Values..........................................................................16
DMX Ch. 2 Pattern Selection..........................................................................................17
5. Technical Information...................................................................................18
6. Technical Specifications..............................................................................19
1. Antes de Empezar.........................................................................................20
Etiquetas de Seguridad del Láser............................................................................23
Datos de Emisión Láser...........................................................................................24
Scorpion™ GBC 2.0......................................................................................................24
Scorpion™ RGY............................................................................................................24
Declaración de Conformidad Láser.................................................................................24
2. Introducción..................................................................................................25
Vista General...........................................................................................................25
Dimensiones ...........................................................................................................25
3. Instalación.....................................................................................................26
Alimentación en Cadena................................................................................................26
Montaje ..................................................................................................................27
Orientación....................................................................................................................27
Colocación ....................................................................................................................27
4. Funcionamiento............................................................................................28
Modificar Opciones en la Rama de Menú Actual.............................................................28
Modificar Opciones en la Rama de Menú Actual.............................................................28
Configuración........................................................................................................30
Dirección de Inicio .........................................................................................................30
Modo Sonido.................................................................................................................30
Modo Automático...........................................................................................................31
Modo Color Cielo Láser .................................................................................................31
Modo Efecto Cielo Láser................................................................................................31

Scorpion™ GBC 2.0/RGY User Manual (Rev. 2 ML) Page 3 of 52
Asignaciones de Canal y Valores DMX.......................................................................32
Selección Patrón C. 2 DMX ...........................................................................................33
6. Especificaciones Técnicas...........................................................................35
1. Avant de Commencer ...................................................................................36
Étiquettes de Sécurité du Laser...............................................................................39
Scorpion™ GBC 2.0 ....................................................................................................40
Scorpion™ RGY..........................................................................................................40
2. Introduction...................................................................................................41
Aperçu.....................................................................................................................41
Dimensions .............................................................................................................41
3. Configuration.................................................................................................42
Installation...............................................................................................................43
Orientation....................................................................................................................43
Suspension...................................................................................................................43
4. Fonctionnement............................................................................................44
Modifier les Options sur l'Arborescence de Menu Actuelle ..............................................44
Modifier les Options sur une Arborescence de Menu Différente ......................................44
Configuration.........................................................................................................46
Adresse de Départ........................................................................................................46
Mode Musical................................................................................................................46
Mode Automatique........................................................................................................47
Mode Laser Couleur du Ciel ..........................................................................................47
Effet de Mode Ciel au Laser ..........................................................................................47
Mouvement Reverse (Inversé).......................................................................................47
Valeurs et Assignations de Canaux DMX ...................................................................48
Sélection de Motif pour le Canal DMX n°2......................................................................49
5. Informations Techniques..............................................................................50
6. Spécificités Techniques ...............................................................................51

Page 4 of 52 Scorpion™ GBC 2.0/RGY User Manual (Rev. 2 ML)
1. Before You Begin
What is
Included
•Scorpion™ GBC or RGY
•Power Cord
•Warranty Card
•User Manual
Unpacking
Instructions
Immediately unpack and check the box. Make sure all the parts are present and in good
condition. If the material inside the box appears damaged from shipping,
notify the shipper
immediately, not CHAUVET®. In addition, retain the container and all the packing material
for inspection.
Text
Conventions
Convention
Meaning
<Menu>
A key to be pressed on the product’s control panel
1~512
A range of values
50/60 A set of values of which only one can be chosen
Settings
A menu option not to be modified (for example, showing the operating
mode/current status)
Menu > Settings
A sequence of menu options to be followed
ON
A value to be entered or selected
Symbols
Symbol Meaning
Critical installation, configuration, or operation information. Failure to
comply can make the laser not work, or not work correctly; damage it, or
harm to the user.
Important installation or configuration information. The laser may not work
correctly if this advice is not followed.
Useful information.
Disclaimer
The information and specifications contained in this document are subject to change without
notice. CHAUVET® assumes no responsibility or liability for any errors or omissions that may
appear in this manual. © Copyright 2012 CHAUVET®. All rights reserved.
Printed in P.R.C. Electronically published by CHAUVET® in the U.S.A.
Author Date
S. Diaz 8/7/12

Scorpion™ GBC 2.0/RGY User Manual (Rev. 2 ML) Page 5 of 52
Safety Notes CAUTION! The use of optical instruments with this product will increase eye
hazard.
The following notes include important safety information about the
installation, usage, and maintenance of this product.
•Keep this User Manual for future consultation. If you sell this product to another user,
be sure that they also receive this document.
•Always make sure that the voltage of the outlet to which you are connecting this
product is within the range stated on the decal or rear panel of the product.
•This product is for indoor use only! To prevent risk of fire or shock, do not expose this
product to rain or moisture.
•Make sure there are no flammable materials close to the unit while operating.
•Always install this product in a location with adequate ventilation, at least 20in (50
cm) from adjacent surfaces. Be sure that no ventilation slots are blocked.
•Always disconnect this product from the power source before cleaning it or replacing
fuse.
•Make sure to replace the fuse with another of the same type and rating.
•If mounting it overhead, always secure this product to a fastening device using a
safety chain.
•The maximum ambient temperature (Ta) is 104° F (40° C). Do not operate this
product at higher temperatures.
•In the event of a serious operating problem, stop using the unit immediately. Never try
to repair the unit. Repairs carried out by unskilled people can lead to damage or
malfunction. Please contact the nearest authorized technical assistance center.
•Never connect this product to a dimmer pack.
•Make sure the power cord is not crimped or damaged.
•Never disconnect the power cord by pulling or tugging on the cord.
•Never carry a product from the power cord or any moving part. Always use the
hanging/mounting bracket or the handles.
•Always avoid direct eye exposure to the light source when this product is on.
•Lasers can be hazardous and have unique safety considerations. Permanent eye
injury and blindness is possible if lasers are used incorrectly. Pay close attention to
each safety REMARK and WARNING statement in this user manual. Read all
instructions carefully BEFORE operating this device.
•Avoid direct eye contact with laser light. Never intentionally expose your eyes or others
to direct laser light.
•This laser product can potentially cause instant eye injury or blindness if laser light
directly strikes the eyes.
•It is illegal and dangerous to shine this laser into audience areas, where the audience or
other personnel could get direct laser beams or bright reflections into their eyes.
•It is a U.S. federal offense to shine any laser at aircraft.
•Use of controls or adjustments or performance of procedures other than those specified
herein may result in hazardous radiation exposure.
•There are no user serviceable parts inside the unit. Do not open the housing or attempt
any repairs yourself. In the unlikely event your unit may require service, please contact
the dealer nearest to you.

Page 6 of 52 Scorpion™ GBC 2.0/RGY User Manual (Rev. 2 ML)
Non-
Interlocked
Housing
Warning
•This unit contains high power laser devices internally.
•Do not open the laser housing, due to potential exposure to unsafe levels of laser
radiation.
•The laser power levels, accessible if the unit is opened, can cause instant blindness,
skin burns, and fires.
Laser Safety
Notes
STOP AND READ ALL THE LASER SAFETY NOTES BELOW
Laser Light is different from any other light sources with which you may be familiar. The
light from this product can potentially cause eye injury if not set up and used properly.
Laser light is thousands of times more concentrated than light from any other kind of light
source. This concentration of light can cause instant eye injuries, primarily by burning the
retina (the light sensitive portion at the back of the eye). Even if you cannot feel “heat”
from a laser beam, it can still potentially injure or blind you or your audience. Even very
small amounts of laser light are potentially hazardous even at long distances. Laser eye
injuries can happen quicker than you can blink.
It is incorrect to think that because these laser entertainment products use high speed
scanned laser beams, that an individual laser beam is safe for eye exposure.
It is also incorrect to assume that because the laser light is moving, it is safe. This is not
true. Nor, do the laser beams always move. Since eye injuries can occur instantly, it is
critical to prevent the possibility of any direct eye exposure. In the laser safety regulation,
it is not legal to aim Class IIIa lasers in areas where people can be exposed. This is true
even if it is aimed below people’s faces, such as on a dance floor.
•Do not operate the laser without first reading and understanding all safety and
technical data in this manual.
•Always set up and install all laser effects so that all laser light is at least 3 meters (9.8
feet) above the floor on which people can stand. See the “Proper Usage” section later
in this manual.
•After set up, and prior to public use, test the laser to ensure proper function. Do not
use if any defect is detected.
•Laser Light - Avoid Direct Eye Exposure.
•Do not point lasers at people or animals.
•Never look into the laser aperture or laser beams.
•Do not point lasers in areas where people can potentially be exposed, such as
uncontrolled balconies, etc.
•Do not point lasers at highly reflective surfaces, such as windows, mirrors and shiny
metal. Even laser reflections can be hazardous.
•Never point a laser at aircraft, as this is a US Federal offense.
•Never point un-terminated laser beams into the sky.
•Do not expose the output optic (aperture) to cleaning chemicals.
•Do not use laser if the laser appears to be emitting only one or two beams.
•Do not use the laser if the housing is damaged, open, or if the optics appear damaged
in any way.
•Never open the laser housing. The high laser power levels inside of the protective
housing can start fires, burn skin and will cause instant eye injury.
•Never leave this device running unattended.
•The operation of a Class IIIa laser show is only allowed if the show is controlled by a
skilled and well-trained operator, familiar with the data included in this manual.
•The legal requirements for using laser entertainment products vary from country to
country. The user is responsible for the legal requirements at the location/country of
use.
•Always use appropriate lighting safety cables when hanging lights and effects
overhead.

Scorpion™ GBC 2.0/RGY User Manual (Rev. 2 ML) Page 7 of 52
Laser Safety Labels
NOTICE
Scorpion™ GBC 2.0
sticker shown.
The sticker on your unit will
reflect the actual Scorpion™
product model, whether
GBC 2.0 or RGY.

Page 8 of 52 Scorpion™ GBC 2.0/RGY User Manual (Rev. 2 ML)
Laser Emission Data
Laser light — Avoid direct eye contact!
Further guidelines and safety programs for safe use of lasers can be found in the ANSI
Z136.1 Standard “For Safe Use of Lasers”, available from the Laser Institute of
America: www.laserinstitute.org. Many local governments, corporations, agencies,
military and others, require all lasers to be used under the guidelines of ANSI Z136.1.
Laser Display guidance can be obtained via the International Laser Display Association:
www.laserist.org.
Scorpion™ GBC 2.0
Laser Classification
Class IIIa
Green Laser Medium
DPSS Nd: YVO4, 532 nm
Blue Laser Medium
450 nm, GaN
Beam Diameter
<15 mm at aperture
Pulse Data
All pulses < 4 Hz (>0.25 sec)
Divergence (each beam)
<2 mrad
Laser Power for Classification via 7mm
aperture*
<5 mW
Scorpion™ RGY
Laser Classification
Class IIIa
Red Laser Medium
GaAlAs, 650nm
Green Laser Medium
532 nm, DPSS Nd: YV04
Beam Diameter
<15 mm at aperture
Pulse Data
All pulses < 4 Hz (>0.25 sec)
Divergence (each beam)
<2 mrad
Laser Power for Classification via 7 mm
aperture*
<5 mW
*As measured under IEC measurement conditions for classification.
Laser
Compliance
Statement
This laser product complies with U.S. FDA CDRH Laser Safety Standards 21 CFR
1040.10 and 1040.11. This laser device is Classified IIIa. (Class 3R is the international
equivalent of U.S. Class IIIa). No maintenance is required to keep this product in
compliance with laser performance standards.
LASER EXPOSURE WARNING

Scorpion™ GBC 2.0/RGY User Manual (Rev. 2 ML) Page 9 of 52
2. Introduction
Overview
Dimensions
Control Panel
(LED display)
DMX Out
DMX In
Power Switch
Fuse holder
Power In
Power Out
Safety Eye Bolt
Back Panel

Page 10 of 52 Scorpion™ GBC 2.0/RGY User Manual (Rev. 2 ML)
3. Setup
AC Power
This product has an auto-ranging power supply and can work with an input voltage
range of 100~240 VAC, 50/60 Hz. See the label affixed to the back plate of the product
or refer to the specifications chart. The listed current rating indicates its average current
draw under normal conditions.
Always connect this product to a protected circuit (circuit breaker or fuse). Make
sure that it has an appropriate electrical ground to avoid the risk of electrocution
or fire.
Never connect this product to a rheostat (variable resistor) or dimmer circuit,
even if the rheostat or dimmer channel serves only as a 0 to 100% switch.
Power Linking
This product provides power linking via the Edison outlet located in the back of the unit.
Power Linking
Diagram
You can power link up to 37 Scorpion™ GBC 2.0 products on 120 VAC or up to
74 Scorpion™ GBC 2.0 products on 230 VAC.
You can power link up to 39 Scorpion™ RGY products on 120 VAC or up to 63
Scorpion™ RGY products on 230 VAC.
The power linking diagram shown above corresponds to the North American
version of this product ONLY! If using this product in other parts of the world,
consult with your
local CHAUVET® distributor, as power linking connectors and
requirements may differ in your country or region.
1st Product
2nd
Product
3rd Product
To other
products

Scorpion™ GBC 2.0/RGY User Manual (Rev. 2 ML) Page 11 of 52
Mounting
Orientation
The Scorpion™ GBC 2.0 and RGY units may be mounted in any position, provided
there is adequate ventilation.
Rigging
Be sure that the structure onto which you are mounting this product can support its
weight. See the Technical Specifications section of this manual for weight information.
Mount the product securely. You can do this with a screw, a nut, and a bolt. You could
also use a mounting clamp if rigging this product onto a truss. A
lways use a safety
cable. Consider ease of access to the unit for maintenance and programming purposes
before deciding on a location for this product
When power linking multiple products,
always consider the length of the power linking
cable and mount the products close enough together for cables to reach.
The bracket adjustment knobs allow for aiming the product to a desired angle. Do not
use tools to loosen or tighten the bracket knobs because tools can damage them.
Mounting Diagram
Proper Use
This product is for overhead mounting only. For safety purposes, CHAUVET®
recommends mounting your lighting effect products on steady elevated platforms or
sturdy overhead supports using suitable hanging clamps. In all cases, you must use
safety cables. You can obtain appropriate mounting hardware from your distributor.
International laser safety regulations require that laser products must be operated in the
fashion illustrated below, with a minimum of 3 meters (9.8 ft) of vertical separation
between the floor and the lowest laser light vertically. Additionally, 3 meters of horizontal
separation is required between laser light and audience or other public spaces.
Hanging Bracket
Bracket Adjustment
Knob (1 of 2)
Safety Loop
CAUTION: USE OF CONTROLS OR ADJUSTMENTS OR PERFORMANCE OF
PROCEDURES OTHER THA
N THOSE SPECIFIED HEREIN MAY RESULT IN
HAZARDOUS RADIATION EXPOSURE.

Page 12 of 52 Scorpion™ GBC 2.0/RGY User Manual (Rev. 2 ML)
4. Operation
Control
Panel
Operation
To access the control panel functions, use the four buttons located underneath the
display.
Button Function
<MENU>
Press to find an operation mode or
to back out of the current menu
option
<DOWN>
Press to scroll down the list of
options or to find a lower value
<UP>
Press to scroll up the list of options
or to find a higher value
<ENT>
Press to activate a menu option or a
selected value
Menu
Branches
The menu structures of the Scorpion™ GBC 2.0/RGY products have seven branches,
as follows:
•Auto/Sound (13 option)
•Laser Sky Color (4 options)
•Laser Sky Effect (1 option)
•Sound Sensitivity (10 options)
•DMX address (503 options)
•Slave (1 option)
•Reverse (2 options with two values each)
•The control panel will remember the last setting you programmed, even after you
have turned the product off.
•In addition, the control panel will remember the last selected option from each menu
branch.
Changing
Options on the
Current Menu
Branch
To change an option on the same menu branch, do the following:
1. Press <MENU> once (the LED display will blink).
2. Press <UP> or <DOWN> until the desired menu option shows on the LED
display.
3. Press <ENT> to accept the new option (the new option will show solid on the
LED display).
Changing
Options on a
Different Menu
Branch
To change an option on a different menu branch, you must exit the current branch.
1. Press <MENU> once (the LED display will blink).
2. Press <MENU> repeatedly until seeing the active option of the desired menu
branch.
3. Press <UP> or <DOWN> until the desired menu option within the new menu
branch shows on the LED display.
4. Press <ENT> to accept the new option (the new option will show solid on the
LED display).

Scorpion™ GBC 2.0/RGY User Manual (Rev. 2 ML) Page 13 of 52
Menu
Options
This menu refers to two different CMY products, GBC 2.0 and RGY, each
with a different set of colors.
Model Color 1 Color 2 Color 3
GBC 2.0
Green
Blue
Cyan
RGY
Red
Green
Yellow
Branch Programming Steps Description
Auto/Sound
AF1
Fast program shows color 1
AS1
Slow program shows color 1
AF2
Fast program shows color 2
AS2
Slow program shows color 2
AF3
Fast program shows color 3
AS3
Slow program shows color 3
AFM
Fast program alternates colors 1 through 3
ASM
Slow program alternates colors 1 through 3
So1
Sound-activated program shows color 1
So2
Sound-activated program shows color 2
So3
Sound-activated program shows color 3
SoM
Sound-activated program alternates colors 1
through 3
rdM
Randomly selects an operation mode
Laser Sky
Color
LS1
Laser sky effect shows the product’s first color
LS2
Laser sky effect shows the product’s second color
LS3
Laser sky effect shows the product’s third color
LSS
Sound triggered laser sky effect alternates colors
Laser Sky
Effect
LSU Laser sky effect position setting
Sound
sensitivity
S 0~S 9 Adjusts the internal microphone’s sensitivity
DMX
001~503
Selects the DMX starting address (1~503)
Slave SLA
Sets the product as “Slave” for master/slave
operation
Reverse rEv
P-y/P-n
Reverses pan movement direction
t-y/t-n
Reverses tilt movement direction

Page 14 of 52 Scorpion™ GBC 2.0/RGY User Manual (Rev. 2 ML)
Configuration
DMX Mode
Setting this product to operate in DMX mode will allow you to control it with a DMX
controller.
1. Connect this product to a suitable power outlet.
2. Turn this product on.
3. Connect a DMX cable from the DMX output of the DMX controller to the DMX
input socket of this product.
Starting Address
When selecting a starting DMX address, you must always consider the number of DMX
channels assigned to the selected DMX mode. If you choose a starting address that is
too high, you could restrict the access to some of the channels of the DMX mode in use.
The Scorpion™ GBC 2.0/RGY products use ten
DMX channels, which defines the
highest configurable address to 503.
If you are not familiar with the DMX protocol, you may refer to the “DMX Primer” section
in the “Technical Information” chapter.
To select the starting address, do the following:
1. Press <MENU> repeatedly until the current starting address (001 to 503)
shows blinking on the display.
2. Use <UP> or <DOWN> to select a different starting address (001~503).
3. Press <ENT> (the new starting address will show solid on the display).
Standalone
Modes
Never connect a product that is operating in any standalone mode,
whether Static, Automatic, or Sound to a DMX string connected to a
DMX controller. This is because products in standalone mode may
transmit DMX signals that could interfere with the DMX signals from the
controller.
Setting this product to operate in DMX mode will allow you to control it without a DMX
controller.
1. Connect this product to a suitable power outlet.
2. Turn this product on.
Sound Mode
To enable the Sound mode, do the following:
1. Press <MENU> repeatedly until the active option of the Auto/Sound branch
(AF1 to rdM) appears on the display.
2. Use <UP> or <DOWN> to select a sound-triggered program (So1~SoM).
3. Press <ENT> (the new sound program will show solid on the display).
4. Turn the music on.
5. Press <MENU> repeatedly until the active option of the Sound Sensitivity
branch (S 0 to S 9) shows blinking on the display.
6. Use <UP> or <DOWN> to select the sensitivity level (S 0~S 9).
7. Press <ENT> (the new sound sensitivity will show solid on the display).
The product will only respond to the low frequencies of the music (bass and
drums).
NOTE: There are individual differences in responses to music between
Scorpions™ set to the same Sound-active mode (S0~S9). To ensure an in-unison
effect from multiple lasers, link them together in Master/Slave mode. The slave
products will operate according to the master unit’s Sound-active setting.

Scorpion™ GBC 2.0/RGY User Manual (Rev. 2 ML) Page 15 of 52
Automatic Mode
To enable the Automatic mode, follow the instructions below:
1. Press <MENU> repeatedly until the active option of the Auto/Sound branch
(AF1 to rdM) shows blinking on the display.
2. Use <UP> or <DOWN> to select an automatic program (AF1~ASM).
3. Press <ENT> (the new auto program will show solid on the display).
Laser Sky Color
Mode
To enable the Laser Sky Color mode, follow the instructions below:
1. Press <MENU> repeatedly until the active option of the Laser Sky Color
branch (LS1 to LSS) shows blinking on the display.
2. Use <UP> or <DOWN> to select a laser sky color option (LS1~LSS).
3. Press <ENT> (the new laser sky color will show solid on the display).
Laser Sky Effect
Mode
To enable the Laser Sky Effect mode, follow the instructions below:
1. Press <MENU> repeatedly until LSU shows blinking on the display.
2. Use <UP> or <DOWN> to change the angle of the laser sky effect.
3. Press <ENT> (LSU will show solid on the display).
Reverse Motion
To reverse the direction of the pan and tilt motion, follow the instructions below:
1. Press <MENU> repeatedly until rEv shows blinking on the display.
2. Press <ENT> (the current option for pan direction will show (P-n or P-Y).
a) To change the setting, use <UP> or <DOWN> and continue to step “3”.
b) To keep the setting, continue to step “3”.
3. Press <ENT> (the current option for tilt direction will show (t-n or t-Y).
a) To change the setting, use <UP> or <DOWN> and continue to step “4”.
b) To keep the setting, continue to step “4”.
4. Press <ENT> (the current software version will show briefly on the display,
followed by rEv).
Master/Slave
Mode
This mode allows a single Scorpion™ GBC 2.0/RGY product (the “master”) to control
the actions of one or more Scorpion™ GBC 2.0/RGY units (the “slaves”) without the
need of a DMX controller. The master unit will be set to operate in either Automatic,
Sound, or Laser Sky mode, while the slave units will be set to operate in Slave Mode.
Once set and connected, the slave units will operate in unison with the master unit.
Configure the units as indicated below.
Slave units:
1. Press <MENU> repeatedly until SLA shows blinking on the display.
2. Press <ENT> (SLA will show solid on the display).
3. Connect the DMX input of the first slave unit to the DMX output of the
master unit
4. Connect the DMX input of the subsequent slave units to the DMX
output of the previous slave unit.
5. Finish setting and connecting all the slave units.
Master unit:
1. Set the master unit to operate in either, Automatic, Laser Sky, or Sound
mode, as previously indicated.
2. Make the master unit the first unit in the DMX daisy chain.
•Wait until all the slave units are configured and connected before connecting the
master unit to the DMX daisy chain.
•Never connect a DMX controller to a DMX string configured for Master/Slave
operation because it may interfere with the signals from the master unit.
Do not connect more than 31 slave units to the master unit.

Page 16 of 52 Scorpion™ GBC 2.0/RGY User Manual (Rev. 2 ML)
DMX Channel Assignments and Values
Channel Function Value Setting
1 Control Mode (Use channels 2~10 in this
mode)
000

017
018 035
036 053
054 071
072 089
090 107
108 125
126 143
144 161
162 179
180 197
198 215
216 233
234 255
Manual Mode
Automatic fast color 1
Automatic slow color 1
Automatic fast color 2
Automatic slow color 2
Automatic fast color 3
Automatic slow color 3
Automatic fast mixed colors
Automatic slow mixed colors
Sound color 1
Sound color 2
Sound color 3
Sound mixed colors
Random (Auto)
2
Pattern selection
(Only when CH1 is
between 000~017)
000 255 32 patterns
3 Color selection
000

024
025 049
050 074
075 099
100 124
125 149
150 174
175 199
200 224
225

255
Blackout
Preprogrammed Color
Color 1
Color 2
Color 3
Alternate Color 1/2
Alternate Color 2/3
Alternate Color 1/3
Alternate Color 1/2/3
Color Roll
4 Color Changing Speed
000 004
005 255
Stop
Slow fast
5 Zoom
000 127
128 169
170 209
210

255
100%~5%
Zoom In Macro
Zoom Out Macro
Zoom In and Out Macro
6 X-Axis Move (Pan)
000

127
128 191
192 255
128 different positions on Y-Axis
Move Left to right to Left (slow fast)
Move Left to right to Left (fast slow)
7 Y-Axis Move (Tilt)
000 127
128 191
192 255
128 different positions on X-Axis
Move Up to down to Up (slow fast)
Move Up to down to Up (fast slow)
8 X-Axis Roll
000

127
128 191
192 255
Y-Axis Roll
Roll (slow fast)
Roll (fast slow)
9 Y-Axis Roll
000 127
128 191
192 255
Y-Axis Roll
Roll (slow fast)
Roll (fast slow)
10 Rotate
000

127
128 191
192 255
Z-Axis Roll
Clockwise Rotate
Counterclockwise Rotate

Scorpion™ GBC 2.0/RGY User Manual (Rev. 2 ML) Page 17 of 52
DMX Ch. 2 Pattern Selection
DMX VALUE
PATTERN
DMX VALUE
PATTERN
DMX VALUE
PATTERN
000~007 096~103 192~199
008~015 104~111 200~207
016~023 112~119 208~215
024~031 120~127 216~223
032~039 128~135 224~231
040~047 136~143 232~235
048~055
144~151 236~247
056~063
152~159 248~255
064~071
160~167
072~079
168~175
080~087 176~183
088~095 184~191

Page 18 of 52 Scorpion™ GBC 2.0/RGY User Manual (Rev. 2 ML)
5. Technical Information
Product
Maintenance
Dust build-up reduces light output performance and can cause overheating. This can
lead to reduction of the light source’s life and mechanical wear. To maintain optimum
performance and minimize wear, clean your lighting products at least twice a month.
(Use and environmental conditions may require increased cleaning frequency.)
•Unplug the product from power.
•Wait until the product is cold.
•Use a vacuum (or dry compressed air) and a soft brush to remove dust collected
on the external surface and fan vents.
•Clean the glass panel (laser aperture) with a mild solution of glass cleaner or
isopropyl alcohol.
•Apply the solution directly to a soft, lint-free cotton cloth or a lens cleaning tissue,
and drag any dirt or grime to the outside of the glass.
•Gently polish the glass surface until it is free of haze and lint.
Always dry the glass surface carefully after cleaning them.
DO NOT spin the fan using compressed air because you could damage
it.
DO NOT open this product for cleaning or servicing.
Returns
The user must send the merchandise prepaid, in the original box, and with its original
packing and accessories. CHAUVET® will not issue call tags.
Call CHAUVET® and request a Return Merchandise Authorization (R
MA) number
before shipping the product. Be prepared to provide the model number, serial number,
and a brief description of the cause for the return.
The user must clearly label the package with a Return Merchandise Authorization
(RMA) number. CHAUVET® will refuse any product returned without an RMA number.
DO NOT write the RMA number directly on the box. Instead, write it on a
properly affixed label.
Once you have received the RMA number, please include the following information on a
piece of paper inside the box:
•Your name
•Your address
•Your phone number
•The RMA number
•A brief description of the problem
Be sure to pack the product properly. Any shipping damage resulting from inadequate
packaging will be the customer’s responsibility. FedEx packing or double-boxing are
recommended.
CHAUVET® reserves the right to use its own discretion to repair or
replace returned product(s).
Claims
The carrier is responsible for any damage incurred during shipping to this product or
any part that shipped with it. Therefore, if the received merchandise appears to have
damages caused during shipping, the customer must submit the damage report and
any related claims with the carrier, not CHAUVET®. The customer must submit the
report upon reception of the damaged merchandise. Failure to do so in a timely manner
may invalidate the customer’s claim with the carrier.
For other issues such as missing components or parts, damage not related to shipping,
or concealed damage, the customer must make claims to CHAUVET® within 7 days of
receiving the product.

Scorpion™ GBC 2.0/RGY User Manual (Rev. 2 ML) Page 19 of 52
6. Technical Specifications
Dimensions and
Weight
Length
Width
Height
Weight
11 in (276 mm)
8.5 in (215 mm)
7.4 in (187 mm)
5.6 lbs (2.7 kg)
Note: Dimensions in inches rounded to the nearest decimal digit
Power
Power Supply Type
Range
Voltage Selection
Switching (internal)
100~240 V, 50/60 Hz
Auto-ranging
Parameter
120 V, 60 Hz
230 V, 50 Hz
Energy consumption
16 W
16 W
Operating current (units)
0.2 A
0.1 A
Power linking (units)
37 units
74 units
Fuse
T 1 A, 250 V
T 1 A, 250 V
Power I/O
Input
Output
Connectors
IEC
Edison (USA)
Cord plug
Edison (USA)
N/A
Light Source
Scorpion™ GBC 2.0
Type
Power
Wavelength
Laser (green)
10 mW
532 nm
Laser (blue)
20 mW
450 nm
Scorpion™ RGY
Type
Power
Wavelength
Laser (red)
20 mW
650 nm
Laser (green)
10 mW
532 nm
Photo Optic
Parameter
Value
Zoom range
1º~36º
Pan positioning
43º
Tilt positioning
39º
Thermal
Maximum External Temp.
Cooling System
104° F (40° C)
Fan cooled
DMX
I/O Connectors
Connector Type
Channel Range
3-pin XLR
Sockets
10
Ordering
Scorpion™ GBC 2.0
Scorpion™ RGY
10060591
10060264
