Chauvet Nexus 4x4 User manual

User Manual

Edition Notes
Trademarks
Copyright Notice
Manual Use
Document Printing
Intended Audience
Disclaimer
This User Manual covers the description, safety precautions, installation, programming,
operation, and maintenance of the Nexus™ 4x4.
Chauvet released this edition of the Nexus™ 4x4 User Manual in November 2014.
CHAUVET® is a registered trademark of CHAUVET & Sons Inc. (d/b/a CHAUVET® or
Chauvet). The CHAUVET® logo in its entirety including the CHAUVET® name and the dotted
triangle, and all other trademarks in this manual pertaining to services, products, or marketing
statements (for example: It’s Green Thinking™) are owned or licensed by Chauvet.
Art-Net™ is designed and copyrighted by Artistic Licence Holdings Ltd.
Any other product names, logos, brands, company names, and other trademarks featured or
referred to within this document are the property of their respective trademark holders.
Chauvet owns the content of this User Manual in its entirety, including but not limited to
pictures, logos, trademarks, and resources.
© Copyright 2014 Chauvet. All rights reserved.
Electronically published by Chauvet in the United States of America.
Chauvet authorizes its customers to download and print this manual for professional
information purposes only. Chauvet expressly prohibits the usage, copy, storage, distribution,
modification, or printing of this manual or its content for any other purpose without written
consent from Chauvet.
For better results, print this document in color, on letter size paper (8.5 x 11 in), double-sided.
If using A4 paper (210 x 297 mm), configure your printer to scale the content accordingly.
Any person in charge of installing, operating, and/or maintaining this product should
completely read through the guide that shipped with the product, as well as this manual,
before installing, operating, or maintaining this product.
Chauvet believes that the information contained in this manual is accurate in all respects.
However, Chauvet assumes no responsibility for any errors or omissions in this document.
Chauvet reserves the right to revise and make changes to the content of this document
without obligation that Chauvet notify any person or company of such revision or changes. In
any way, this does not constitute a commitment by Chauvet to make such changes. Chauvet
may issue a revision of this manual or a new edition to incorporate such changes.
Author
Date
Editor
Date
L. Henry
7/23/14
D. Couppe
1/27/15

Nexus™ 4x4 User Manual Rev. 4
Table of Contents
1.Before You Begin...............................................................................................................................3
What Is Included..................................................................................................................................3
Claims..................................................................................................................................................3
Manual Conventions............................................................................................................................3
Symbols...............................................................................................................................................3
Safety Notes........................................................................................................................................4
Expected LED Lifespan.......................................................................................................................4
2.Introduction........................................................................................................................................5
Description...........................................................................................................................................5
Features...............................................................................................................................................5
Overview..............................................................................................................................................6
Dimensions..........................................................................................................................................7
Pixel Layout.........................................................................................................................................7
3.Setup...................................................................................................................................................8
AC Power.............................................................................................................................................8
AC Plug ............................................................................................................................................8
Fuse Replacement...........................................................................................................................8
Power Linking......................................................................................................................................9
Power Linking Diagram....................................................................................................................9
DMX Linking ......................................................................................................................................10
DMX Linking Diagram ....................................................................................................................10
DMX Mode .....................................................................................................................................10
Master/Slave Mode ........................................................................................................................11
Ethernet Connections........................................................................................................................11
Ethernet Connections Diagram......................................................................................................11
Kling-Net Mode...............................................................................................................................12
Art-Net™ Mode ..............................................................................................................................12
Setting Modes And Protocols............................................................................................................12
Mounting............................................................................................................................................13
Orientation......................................................................................................................................13
Rigging ...........................................................................................................................................13
Mounting Diagram..........................................................................................................................14
4.Operation..........................................................................................................................................15
Control Panel.....................................................................................................................................15
Menu Map..........................................................................................................................................16
Menu Operations...............................................................................................................................17
Auto Show......................................................................................................................................17
Exiting Auto Show Mode.............................................................................................................17
Static Color.....................................................................................................................................17
Dimmer Mode.................................................................................................................................17
Display Backlight............................................................................................................................17
Product...........................................................................................................................................18
Information .....................................................................................................................................18
DMX Channel.................................................................................................................................18
DMX Address.................................................................................................................................18
Master/Slave ..................................................................................................................................18
White Calibration............................................................................................................................19
Fan Control.....................................................................................................................................19
Temperature...................................................................................................................................19
Reset to Factory Default ................................................................................................................19
Setting Ethernet Protocols .............................................................................................................19

Nexus™ 4x4 User Manual Rev. 4
Kling-Net .....................................................................................................................................19
Art-Net™ .....................................................................................................................................20
Kling-Net Mapper...............................................................................................................................21
Part 1: Confirm Network Connectivity............................................................................................21
The Connected Devices Window................................................................................................22
Part 2: Test Network Connectivity..................................................................................................22
Part 3: Map The Products For ArKaos...........................................................................................23
Nexus Software Upgrade Instructions...............................................................................................24
DMX Channel Assignments And Values...........................................................................................28
53-Channel.....................................................................................................................................28
48-Channel.....................................................................................................................................31
9-Channel.......................................................................................................................................32
5-Channel.......................................................................................................................................33
3-Channel.......................................................................................................................................33
5.Technical Information .....................................................................................................................34
Product Maintenance.........................................................................................................................34
Returns ..............................................................................................................................................34
6.Technical Specifications.................................................................................................................35
Contact Us...........................................................................................................................................36

Before You Begin
Nexus™ 4x4 User Manual Rev. 4 -3-
1.Before You Begin
What Is
Included
Claims
Manual
Conventions
Symbols
•Nexus™ 4x4
•Neutrik® powerCON® power cord
•#5 Allen key with handle
•Warranty Card
•Quick Reference Guide
Carefully unpack the product immediately, and check the box to make sure all the parts are in
the package and are in good condition.
If the box or the product and included accessories appear damaged from shipping or show
signs of mishandling, notify the carrier immediately, not Chauvet. Failure to report damage to
the carrier immediately may invalidate your claim. In addition, keep the box and contents for
inspection.
For other issues, such as missing components or parts, damage not related to shipping, or
concealed damage, file a claim with Chauvet within 7 days of delivery.
Convention
Meaning
1–512
A range of values in the text
50/60
A set of mutually exclusive values in the text
<SET>
A button on the product’s control panel
Settings
A product function or a menu option
MENU>Settings
A sequence of menu options
1–10
A range of menu values from which to choose in a menu
Yes/No
A set of two mutually exclusive menu options in a menu
ON
A unique value to be entered or selected in a menu
Symbols
Meaning
Critical installation, configuration, or operation information. Failure to comply
with this information may cause the product not to work, damage third-
party
equipment, or cause harm to the operator.
Important installation or configuration information.
Failure to comply with this
information may keep the product from working.
Useful information.

Before You Begin
-4- Nexus™ 4x4 User Manual Rev. 4
Safety Notes
Read all the following Safety Notes before working with this product. These notes include
important information about the installation, usage, and maintenance of this product.
This product contains no user-serviceable parts. Any reference to servicing in this U
ser
Manual will only apply to properly trained Chauvet
certified technicians. Do not open the
housing or attempt any repairs.
All applicable local codes and regulations apply to proper installation of this product.
Personal Safety
•Avoid direct eye exposure to the light source while the product is on.
•Always disconnect this product from its power source before servicing.
•Always connect this product to a grounded circuit to avoid the risk of electrocution.
•Do not touch this product’s housing during operation because it may be very hot.
Mounting and
Rigging
•This product is for indoor use only! To prevent risk of fire or shock, do not expose this
product to rain or moisture.
•Make sure there are no flammable materials close to this product while it is operating.
•When hanging this product, always secure to a fastening device using a safety cable.
Power and Wiring
•Always make sure you are connecting this product to the proper voltage in accordance with
the specifications in this manual or on the product’s specification label.
•Never connect this product to a dimmer pack or rheostat.
•Never disconnect this product by pulling or tugging on the power cable.
Operation
•Do not operate this product if you see damage on the housing, lenses, or cables. Have the
damaged parts replaced by an authorized technician at once.
•Do not cover the ventilation slots when operating to avoid internal overheating.
•The maximum ambient temperature is 113 °F (45 °C). Do not operate this product at a
higher temperature.
•In case of a serious operating problem, stop using this product immediately!
•To eliminate unnecessary wear and improve its lifespan, during periods of non-use
completely disconnect the product from power via breaker or by unplugging it.
Expected LED
Lifespan
In the unlikely event that your CHAUVET® product requires service, contact Chauvet
Technical Support.
LEDs gradually decline in brightness over time, mostly because of heat. LEDs packaged in
clusters exhibit higher operating temperatures than single LEDs. Using clustered LEDs at their
fullest intensity significantly reduces the LEDs’ lifespan, which under normal circumstances
40,000 to 50,000 hours. If extending this lifespan is vital, lower the operating temperature by
improving the ventilation around the product and reducing the ambient temperature to an
optimal operating range. In addition, limiting the overall projection intensity may also help to
extend the LEDs’ lifespan.

Introduction
Nexus™ 4x4 User Manual Rev. 4 -5-
2.Introduction
Description
Features
Nexus™ 4x4 is a tour-ready wash light with a pixel mappable display of sixteen 27 watt RGB
COB LEDs. The combination of circuit on board (COB) emitters and a clever reflector design
create a soft, bright light with saturated hues. The Nexus™ 4x4 operates in Standalone mode
or with the Art-Net™, Kling-Net, or DMX protocols. The Nexus™ 4x4s have coffin locks so
they can be connected into large arrays.
•Sixteen 27 watt RBG COB LEDs
•Pixel mapping capability
•Operates in Standalone and Master/Slave modes
•Operates with Art-Net™, Kling-Net, or DMX protocols using 3-, 5-, 9-, 48- or 53-channel
DMX personalities
•Coffin locks for connecting into arrays
•Works seamlessly with Nexus™ 4x1 and Nexus™ 2x2
•Universal power and control cabling with Neutrik® powerCON®, Neutrik® etherCON®, and
both 3- and 5-pin DMX ports

Introduction
-6- Nexus™ 4x4 User Manual Rev. 4
Overview
Front View Side View
Rear View Top View
COB LED (x16)
Control Panel
Power
Sockets
5-Pin DMX Ports
3-Pin DMX Ports
Neutrik
®
etherCON
® I/O
Coffin Locks
Bracket
Adjustment
Knob
Mounting
Bracket
Fuse
Holder

Introduction
Nexus™ 4x4 User Manual Rev. 4 -7-
Dimensions
Pixel Layout
1
2
3
4
5
6
7
8
9
10
11
12
14
15
16
13

Setup
-8- Nexus™ 4x4 User Manual Rev. 4
3.Setup
AC Power
AC Plug
Fuse
Replacement
The Nexus™ 4x4 has an auto-ranging power supply that works with an input voltage range of
100 to 240 VAC, 50/60 Hz. To determine the power requirements for the Nexus™ 4x4, refer to
the label on the product or Technical Specifications in this manual.
The listed current rating indicates the maximum current draw during normal operation. For
more information, download Sizing Circuit Breakers from the Chauvet website at
www.chauvetprofessional.com.
•Always connect this product to a protected circuit with an appropriate electrical
ground.
•Never connect this product to a rheostat (variable resistor) or dimmer circuit, even if
the rheostat or dimmer channel serves only as a 0 to 100% switch.
The Nexus™ 4x4 comes with a power input cord terminated with a Neutrik® powerCON®
connector on one end and an Edison plug on the other end (U.S. market). If the power input
cord that came with the Nexus™ 4x4 product has no plug or there is the need to change the
plug, use the table below to wire a new plug.
Connection
Wire (U.S.)
Wire (Europe)
Screw Color
AC Live
Black
Brown
Yellow or Brass
AC Neutral
White
Blue
Silver
AC Ground
Green/Yellow
Green/Yellow
Green
The fuse is a T 5 A, 250 V and it is located in a fuse holder next to the Neutrik® powerCON®
power socket. To replace the fuse, do the following:
1. Disconnect the product from power.
2. Using a flat-head screwdriver, unscrew the fuse holder cap.
3. Remove the blown fuse and replace it with a good fuse of the same type and rating.
4. Screw the fuse holder cap back in place.
5. Reconnect the product to power.
•Make sure to disconnect the power before replacing a blown fuse.
•Always replace the blown fuse with a fuse of the same type and rating.

Setup
Nexus™ 4x4 User Manual Rev. 4 -9-
Power
Linking
Power Linking
Diagram
The Nexus™ 4x4 supports power linking of up to:
•4 products at 120 V,
•7 products at 208 V, or
•8 products at 230 V.
A power cord is included but power-linking cables are not included. For power-linking cables,
see the Chauvet website at www.chauvetlighting.com.
Other Products

Setup
-10- Nexus™ 4x4 User Manual Rev. 4
DMX Linking
DMX Linking
Diagram
DMX Mode
DMX linking connects Nexus™ 4x4 products through their DMX In and Out ports.
Nexus™ 4x4 has both 3- and 5-pin DMX ports, so either 3- or 5-pin cables, or a combination
of both, can be used. DMX linking is for DMX control and for Master/Slave control.
In DMX mode, Nexus™ 4x4 products are controlled by a DMX controller, and the DMX
address and DMX personality must be set through the control panel.
The Nexus™ 4x4 automatically senses its control source. When there is a DMX cable plugged
in, the Nexus™ 4x4 responds to DMX control. When there is a Neutrik® etherCON® cable
plugged in, it responds to an IP protocol, such as Art-Net™ or Kling-Net.
The Nexus™ 4x4 has 5 DMX personalities, each with different capabilities. The table below
lists the capabilities of each personality. For more information, see DMX Address and DMX
Personality.
Personality
Capabilities
3-channel
RGB control
5-channel
RGB control with dimmer and strobe
9-channel
R, G, B, WW, CW control with dimmer and dimmer speed, strobe, color
macros, auto programs and program speed
48-channel
RGB with individual pixel control
53-channel
R, G, B, control with 8 WW and 8 CW controls, dimmer and dimmer speed,
strobe, color macros, auto programs and program speed
DMX Controller or Master
Other DMX Products

Setup
Nexus™ 4x4 User Manual Rev. 4 -11-
Master/Slave
Mode
Ethernet
Connections
Ethernet
Connections
Diagram
In Master/Slave mode one Nexus™ 4x4 product (the master) controls one or more Nexus™
4x4 products (the slaves) without a DMX controller. The master Nexus™ 4x4 is set to an auto
program, static color, or color macro and sends DMX signals to the slaves. During
Master/Slave operation, the slave products operate in unison with the master. For more
information, see Master/Slave.
•Do not connect a DMX controller to the DMX chain when operating Nexus™ 4x4
products in Master/Slave mode, because signals from the master and the DMX
controller will conflict and cause erratic behavior in all the products.
•Master/Slave operates via DMX ports only. The Neutrik® etherCON® ports cannot be
used for Master/Slave mode.
For more information about DMX, see the CHAUVET® DMX primer, available at
www.chauvetlighting.com.
Ethernet connections link Nexus™ 4x4 to routers and each other through their Neutrik®
etherCON® ports. Ethernet connections are for running TCP/IP-based control system, such as
Art-Net™ and Kling-Net. All Neutrik® etherCON® ports can be either input or output ports,
and panels can be linked together, but the start of each chain must be a router port.
Do not connect Nexus™ 4x4 to the WAN port of the router.
NOTE: Do Not Use WAN Port On Router!
Router
Nexus™ 4x4 Panels
More
Products
Computer or Controller
Running TCP/IP-based
protocol, such as
Kling-Net or Art-Net™

Setup
-12- Nexus™ 4x4 User Manual Rev. 4
Kling-Net Mode
Art-Net™ Mode
Setting
Modes And
Protocols
Kling-Net is a network protocol that uses TCP/IP to send DMX over a network and into the
Neutrik® etherCON® connection ports of the Nexus™ 4x4 panels. Kling-Net works
seamlessly with Kling-Net-supported ArKaos software for configuring and mapping display
devices. For more information, see Kling-Net Configuration.
Kling-Net requires a gigabit per second (1,000 Mbps) Ethernet card and network router.
Art-Net™ is an Ethernet protocol that uses TCP/IP to send DMX signals over a network and
into the Neutrik® etherCON® connection ports of the Nexus™ 4x4 panels. Art-Net™ requires
configuration through the control panel. For more information, see Setting Ethernet Protocols
and Art-Net™.
For more information about Art-Net™, see the Art-Net™ protocol document available on the
Chauvet website at www.chauvetlighting.com.
Nexus™ 4x4 panels do not work with Art-Net™ controllers sending in Broadcast mode.
For information about the controller’s mode, see the controller’s User Manual.
The Nexus™ 4x4 automatically senses whether control is coming from a DMX source or a
Network source. When there is a Neutrik® etherCON® cable plugged into it, the Nexus™ 4x4
responds to a TCP/IP protocol, such as Art-Net™ or Kling-Net, depending on the setting in the
control panel. If there is a DMX cable plugged into it, the Nexus™ 4x4 responds to a DMX
controller or Master/Slave control, depending on the settings in the control panel.
The Nexus™ 4x4 can receive control from only one set of ports, either the DMX ports or the
Neutrik® etherCON® ports. The Nexus™ 4x4 senses which ports are used on power-up, so
the panel cannot be changed from DMX to TCP/IP, or from TCP/IP to DMX while it is turned
on.
To switch from one set of ports to another (one control type to another):
1. Disconnect the Nexus™ 4x4 from power.
2. Switch the control cables.
3. Reconnect the Nexus™ 4x4 to power.
A DMX personality must be set for all control modes – DMX, Art-Net™, or Kling-Net. For more
information, see DMX Personality.
Kling-Net has no settings to configure, but it must be selected through the control panel. For
more information, see Setting Ethernet Protocols and Kling-Net.
Art-Net™ has a number of settings that must be configured through the control panel. For
more information, see Setting Ethernet Protocols and Art-Net™.

Setup
Nexus™ 4x4 User Manual Rev. 4 -13-
Mounting
Orientation
Rigging
Before mounting the Nexus™ 4x4, review the Safety Notes section. Read and follow the
guidelines below for mounting the Nexus™ 4x4.
•When selecting a desired location and before installation, consider easy access to this
product for operation, programming adjustments, and routine maintenance.
•Mount in a way that allows adequate ventilation around the product.
•Do not mount near flammable materials as indicated in the Safety Notes section.
•Do not mount where there is rain, high humidity, or extreme temperature change.
•Make sure that the mounting structure can support the weight of the Nexus™ 4x4. See
Technical Specifications for information on weight.
•Always secure product to a fastening device using a safety cable.
The Nexus™ 4x4 can be mounted in any orientation as long as each individual product is
secured through the mounting bracket. Always mount the Nexus™ 4x4 securely and use
safety cables.
The Nexus™ 4x4 includes a hanging bracket with holes for M12-compatible bolts. There are
coffin locks on all four edges of the Nexus™ 4x4 that are used for aligning the products in an
array. The coffin locks should not carry the weight of the Nexus™ 4x4. Each Nexus™ 4x4
must be rigged to hold its own weight using its hanging bracket and at least one rigging point
per panel.
The coffin locks of the Nexus™ 4x4 panels are not load-bearing connectors.
The hanging bracket can be bolted directly onto a surface or can be connected to truss with
clamps. For the complete line of CHAUVET® clamps, see the Chauvet website at
www.trusst.com/productcategory/accessories-clamps/.

Setup
-14- Nexus™ 4x4 User Manual Rev. 4
Mounting
Diagram
\
Top Mount To Structure
Side Mount To Pipe Or Truss
Only use the coffin locks to align the Nexus™ 4x4s. The coffin locks are not
load-bearing connectors. Do not hang the product by the coffin locks.
Align Panels Using Coffin
Locks And A #5 Allen Key

Operation
Nexus™ 4x4 User Manual Rev. 4 -15-
4.Operation
Control Panel
Button
Function
<MENU>
Scrolls through the main menu or exits from the current menu or function
<ENTER>
Enables the currently displayed menu or sets the currently selected value in to
the current function
<UP>
Navigates upward through the menu list or increases the numeric value when
in a function
<DOWN>
Navigates downward through the menu list or decreases the numeric value
when in a function
To access a main level menu press <MENU> repeatedly, or press <MENU> once and then
<UP> or <DOWN>, until the desired menu level shows on the control panel display. Press
<ENTER> to go into that menu level.
To select a programming value in the selected main level menu, press <UP> or <DOWN> until
the desired option shows on the control panel display. Press <ENTER> to select the option.
To exit back to the home screen, press and hold <MENU> for 10 seconds.
The home screen on the control panel display shows <Master> if the Nexus™ 4x4 is in a
standalone or Master mode.
The following Menu Map shows the main levels and the programming levels for each option.
•For Ethernet Settings, <MENU> must be pressed twice to change between Art-Net™
and Kling-Net.
•Changes to the settings are activated when the control panel display returns to the
home screen. To return the control panel display to the home screen, press and
hold <MENU> for 10 seconds.
After pressing <MENU> once, use <UP> or <DOWN> to cycle through main level options.

Operation
-16- Nexus™ 4x4 User Manual Rev. 4
Menu Map
Main Level
Programming Levels
Description
Auto Show
Auto 1–9
Show Speed 000–100
Selects auto programs and speed control
Fade 1–2
Selects color fades 1–2 and speed control
Static
Fixture Color
R
Selects a preset color
G
B
GB
RB
RG
RGB
Manual Color
R
000–255 Sets color levels for manual color mixing
G
B
Dimmer Mode
Off
Sets dimming curve
Dimmer 1–3
Back Lite
On
Sets control panel backlight on time
10S
20S
30S
Info
Fixture Hours
Shows total operating time
Version
Shows software version
IP Address
Shows IP address
Device ID
Shows ID number
DMX Address
001–512
Sets DMX starting address
DMX Channel
3Ch
Sets DMX personality for DMX, Art-
Net™ mode, and
Kling-Net mode.
5Ch
9Ch
48Ch
53Ch
Master/Slave
Master
Sets Master mode
Slave
Sets Slave mode
White
R
125–255 Sets the color mix that will be white
G
B
Fan Speed
Auto
Sets fan to slow down when product is cool
High
Sets fan to run continuously at high speed
Temperature
Shows product’s internal temperature
Ethernet Settings Protocol
Kling-Net
Sets Kling-Net protocol
Art-Net
IP Mode
Manual
Sets product to use a manually set IP address
DHCP
Sets product to use dynamic IP addressing
Static
Sets product to use its internal IP address
Net
000–127
Sets the net address of the product
Subnet
00–15
Sets the subnet number of the product
Universe
Sets the universe number of the product

Operation
Nexus™ 4x4 User Manual Rev. 4 -17-
Menu
Operations
Auto Show
Exiting Auto Show
Mode
Static Color
Dimmer Mode
Display
Backlight
The menu operations set configurations for the Nexus™ 4x4, including built-in programs to
operate the Nexus™ 4x4 without a DMX controller. The menu operations are accessed via the
control panel. See Control Panel.
Changes to settings are not activated until the control panel display returns to the
home screen. To return the control panel display to the home screen, press and hold
<MENU> for 10 seconds.
Auto Show mode allows for dynamic RGB color mixing without a DMX controller. To activate
Auto Show mode do the following:
1. Go to the Auto Show main level.
2. Select the Auto (1–12) or Fade program.
3. Select the Show Speed (000–100).
4. Press <MENU> to return to the home screen.
Auto Show mode does not stop when a different operating mode, such as DMX, Art-Net™, or
Kling-Net is selected. To exit from Show mode, put the Nexus™ 4x4 into Slave mode. For
more information see Master/Slave Mode. Slave mode does stop when a different operating
mode is selected through the control panel.
Static mode selects preset colors or color mixing. To set Static mode do the following:
1. Go to the Static main level.
2. Select Fixture Color or Manual Color.
For Fixture Color:
1. Select desired color (R, G, B, GB, RB, RG, or RGB).
2. Press <MENU> to return to the home screen.
For Manual Color:
1. Select the desired color (R, G, or B).
2. Select the desired color value (000–255).
3. Repeat the steps for each color.
4. Press <MENU> to return to the home screen.
Dimmer Mode configures the rate of change in light intensity. There are 3 different dimmer
modes with 1being the slowest and 3being the fastest. When Dimmer Mode is set to OFF,
the Nexus™ 4x4 fades in direct proportion to the DMX values. To configure Dimmer Mode, do
the following: Go to Dimmer Mode in the main level.
1. Select a dimmer mode (OFF, Dimmer 1, Dimmer 2, or Dimmer 3).
2. Press <MENU> to return to the home screen.
Back Lite option determines how long the control panel display stays on during inactivity. To
set the display backlight time, do the following:
1. Go to Back Lite in the main level.
2. Select the desired amount of time (in seconds) the backlight display will stay on after
pressing the last menu button (On, 10S, 20S, or 30S).
3. Press <MENU> to return to the home screen.

Operation
-18- Nexus™ 4x4 User Manual Rev. 4
Product
Information
DMX Channel
DMX Address
Master/Slave
Product Information shows information about the Nexus™ 4x4. To display product information,
do the following:
Go to the I nfo mai nl evel .
1. Select the desired program level based on the information required.
•Fixture Hours – The amount of time the product has been in use
•Version – The software version installed on the product
•IP Address - The product’s IP address
•Device ID - The product’s ID number (used with Kling-Net only)
2. Press <MENU> to return to the home screen.
DMX Channel sets the Nexus™ 4x4 DMX personality for use in all modes: DMX, Art-Net™,
and Kling-Net. Each DMX personality has different capabilities. For more information, see
DMX Mode. To select a DMX personality, do the following:
1. Go to the DMX Channel main level.
2. Select the desired personality (3Ch, 5Ch, 9Ch, 48Ch, or 53Ch).
3. Press <MENU> to return to the home screen.
DMX Address sets the Nexus™ 4x4 DMX starting address for DMX mode and Art-Net™
mode. To select a DMX address, do the following:
1. Go to DMX Address main level.
2. Select the starting address (001–512).
3. Press <MENU> to return to the home screen.
The highest recommended DMX address for each DMX personality is listed in the table below.
DMX Personality
Highest DMX Address
DMX Personality
Highest DMX Address
3Ch
510
48Ch
465
5Ch
508
53Ch
460
9Ch
504
Master/Slave mode configures the Nexus™ 4x4 panels so that a group of panels (the slaves)
duplicates the actions of a single panel (the master). Master/Save mode does not need a DMX
controller. To configure the Nexus™ 4x4s for Master/Slave mode, do the following:
First, set each of the slave panels:
1. Go to the Master/Slave main level.
2. Select Slave.
3. Press <MENU> to return to the home screen.
Second, set the master panel:
1. Go to the Master/Slave main level.
2. Select Master.
3. Select a standalone mode (an automatic program or a static mode). For more information,
see Auto Show and Static Colors.
4. Press <MENU> to return to the home screen.
•Set the slaves before setting the master.
•Do not connect a DMX controller to Nexus™ 4x4 products configured for
Master/Slave operation. The DMX controller may interfere with signals from the
master.
•The master must be the first product in the DMX daisy chain.
•The master must be set to a standalone mode for Master/Slave to work.
