Chauvet SlimPANEL TRI 12 IP User manual

User Manual

Page 2 of 18 SlimPANEL™ TRI 12 IP User Manual (Rev. 4)
TABLE OF CONTENTS
1. Before You Begin .............................................................................. 3
What Is Included ...............................................................................................3
Unpacking Instructions......................................................................................3
Claims........................................................................................................................ 3
Text Conventions ..............................................................................................3
Icons..................................................................................................................3
Disclaimer .........................................................................................................3
Product at a Glance ..........................................................................................4
Safety Notes......................................................................................................4
2. Introduction ....................................................................................... 5
Product Overview..............................................................................................5
Product Dimensions..........................................................................................6
3. Setup .................................................................................................. 7
AC Power..........................................................................................................7
Power Linking............................................................................................................. 7
Mounting ...........................................................................................................8
Orientation ................................................................................................................. 8
Rigging....................................................................................................................... 8
4. Operation ........................................................................................... 9
Control Panel Operation....................................................................................9
Menu Map.........................................................................................................9
Configuration (DMX) .......................................................................................10
DMX Personalities and Starting Address................................................................ 10
DMX Channel Assignments and Values.........................................................11
3-CH......................................................................................................................... 11
4-CH......................................................................................................................... 11
5-CH......................................................................................................................... 11
9-CH......................................................................................................................... 12
Configuration (Standalone).............................................................................13
Automatic Mode....................................................................................................... 13
Static Color Mode..................................................................................................... 13
Custom Static Color Mode....................................................................................... 13
Dimmer Adjustment.................................................................................................. 13
Touch Control Panel Lock........................................................................................ 14
Master/Slave Mode.................................................................................................. 14
5. Technical Information ......................................................................15
Product Maintenance......................................................................................15
6. Technical Specifications..................................................................16
Returns............................................................................................................17
Contact Us ............................................................................................18

SlimPANEL™ TRI 12 IP User Manual (Rev. 4) Page 3 of 18
1.BEFORE YOU BEGIN
What Is
Included
•SlimPANEL™ TRI 12 IP
•DMX In Adapter
•DMX Out Adapter
•Power Cord
•Warranty Card
•Quick Reference Guide
Unpacking
Instructions
Immediately upon receipt, carefully unpack the product and check the container to make
sure you have received all the parts indicated above in good condition.
Claims
If the container or the material inside the container (the product and included
accessories) appear damaged from shipping, or show signs of mishandling,
upon receipt
notify the carrier immediately, not Chauvet.
Failure to do so in a timely manner may
invalidate your claim with the carrier. In addition, keep the container and all the packing
material for inspection.
For other issues such as missing components or parts, damage not related to shipping,
or concealed damage, file a claim with Chauvet
within 7 days of receiving the
merchandise.
Text
Conventions
Convention Meaning
1–512
A range of values
50/60
A set of values of which only one can be chosen
Settings
A menu option not to be modified
Menu > Settings
A sequence of menu options to be followed
<ENTER>
A key to be pressed on the product’s control panel
ON
A value to be entered or selected
Icons
Icon Meaning
Critical installation, configuration, or operation information. Failure
to comply with this information may render the product partially or
completely inoperative, cause damage to the product, or cause
harm to the user.
Important installation or configuration information. Failure to
comply with this information may prevent the product from
functioning correctly.
Useful information.
Disclaimer
The information and specifications contained in this document are subject to change
without notice. Chauvet
assumes no responsibility or liability for any errors or omissions
that may appear in this manual. Chauvet reserves the right to update the existing
document or to create a new document to correct any errors or omissions.
You can download the latest version of this document from www.chauvetlighting.com.
© Copyright 2015 Chauvet. All rights reserved.
Electronically published by Chauvet in the United States of America.
Author Date Editor Updated
M. Trouard 05/07/15 R. Isenstadt 05/07/15

Page 4 of 18 SlimPANEL™ TRI 12 IP User Manual (Rev. 4)
Product at a
Glance
Use on Dimmer
x
Auto Programs
P
Outdoor Use
P
Auto-ranging Power Supply
P
Sound Activated
x
Replaceable Fuse
x
DMX
P
User Serviceable
x
Master/Slave
P
Duty Cycle
x
Safety Notes
Please read the following Safety Notes carefully before working with the product. The
Notes include important safety information about installation, usage, and maintenance.
•Always connect the product to a GFI (ground fault interrupter) circuit to avoid the
risk of electrocution.
•To eliminate wear and improve its lifespan, during periods of non-use completely
disconnect from power via breaker or by unplugging it.
•Always disconnect the product from the power source before cleaning or replacing
the fuse.
•Avoid direct eye exposure to the light source while the product is on.
•Make sure the power cord is not crimped or damaged.
•Never disconnect the product from power cord by pulling or tugging on the cord.
•If mounting the product overhead, always secure to a fastening device using a
safety cable.
•Make sure there are no flammable materials close to the product when operating.
•
Do not touch the product’s housing when operating because it may be very hot.
•Always make sure that the voltage of the outlet to which you are connecting the
product is within the range stated on the decal or rear panel of the product.
•This product is for indoor or temporary outdoor use (IP65). Do not expose to harsh
or excessively corrosive environmental conditions (whether indoors or outdoors),
including, but not limited to, extreme temperatures, humidity, atmospheric
conditions (including salinity or pressure), radiation (UV, infrared or nuclear), shock
and conditions which exceed the product’s Ingress Protection (“IP”) rating. Do not
submerge this product.
•Always install the product in a location with adequate ventilation, at least 20 in (50
cm) from adjacent surfaces.
•Be sure that no ventilation slots on the product’s housing are blocked.
•Never connect the product to a dimmer.
•Make sure to replace the fuse with another of the same type and rating.
•Never carry the product from the power cord or any moving part. Always use the
hanging/mounting bracket or the handles.
•The maximum ambient temperature (Ta) is 104 °F (40 °C). Do not operate the
product at higher temperatures.
•In the event of a serious operating problem, stop using the product immediately.
•Never try to repair the product. Repairs carried out by unskilled people can lead to
damage or malfunction. Please contact the nearest authorized technical assistance
center.
Keep this User Manual for future consultation. If you sell the product to another
user, be sure that they also receive this document.

SlimPANEL™ TRI 12 IP User Manual (Rev. 4) Page 5 of 18
2.INTRODUCTION
Product Overview
DMX Out
DMX In
Mounting Bracket
Power In
Power Out
Touch Display

Page 6 of 18 SlimPANEL™ TRI 12 IP User Manual (Rev. 4)
Product Dimensions

SlimPANEL™ TRI 12 IP User Manual (Rev. 4) Page 7 of 18
3.SETUP
AC Power
The SlimPANEL™ TRI 12 IP has an auto-
ranging power supply and it can work with an
input voltage range of 100–240 VAC, 50/60 Hz.
To determine the product’s power requirements (
circuit breaker, power outlet, and
wiring), use the current value listed on the label affixed to the product’s back panel, or
refer to the product’s specifications chart. The listed current rating indicates the
product’s average current draw under normal conditions.
•Always connect the product to a protected circuit
(circuit breaker or fuse).
Make sure the product has
an appropriate electrical ground to avoid the risk of
electrocution or fire.
•To eliminate wear and improve its lifespan, during periods of non-use
completely disconnect from power via breaker or by unplugging it.
Never connect the product to
a rheostat (variable resistor) or dimmer circuit, even
if the rheostat or dimmer channel serves only as a 0 to 100% switch.
Power Linking The product provides a power linking option via the pigtails located on the back
of the
unit.
You can daisy chain up to 19 units on 120 VAC or up to 39 units on 230 VAC.
If you choose not to use the power linking feature, be sure to use the included screw on
cap to prevent any water from getting into the power cords.
The power linking information
above corresponds to the North American version
of the product ONLY! If using the product
in other markets, you must consult with
the local Chauvet
distributor as power linking connectors and requirements may
differ in your country or region.

Page 8 of 18 SlimPANEL™ TRI 12 IP User Manual (Rev. 4)
Mounting
Before mounting the product
, read and follow the safety recommendations indicated in
the Safety Notes.
Orientation
The SlimPANEL™ TRI 12 IP
may be mounted in any position; however, make sure
adequate ventilation is provided around the product.
Rigging
•Before deciding on a location for the product, always make sure there is easy
access to the product for maintenance and programming purposes.
•Make sure that the structure onto which you are mounting the product
can support
the product’s weight. See the Technical Specifications for weight information.
•When mounting the product overhead, always use a safety cable.
Mount the
product securely to a rigging point, whether an elevated platform or a truss.
•When rigging the product onto a truss, you should use a mounting clamp of
appropriate weight capacity. The bracket has a 13 mm hole
, which is appropriate for
this purpose.
•When power linking multiple products, you must
always consider the length of the
power linking cable and mount the products close enough for the cable to reach.
•
This product is for indoor or outdoor use (IP65). Do not expose to harsh or
excessively corrosive environmental conditions (whether indoors or outdoors),
including, but not limited to, extreme temperatures, humidity, atmospheric
conditions (including salinity or pressure), radiation (UV, infrared or nuclear), shock
and conditions
which exceed the product’s Ingress Protection (“IP”) rating. Do not
submerge this product.
Mounting Diagram
Mounting Bracket

SlimPANEL™ TRI 12 IP User Manual (Rev. 4) Page 9 of 18
4.OPERATION
Control Panel
Operation
To access the control panel
functions, use the four buttons located underneath the
display. Please refer to the Product Overview to see the button locations
on the control
panel.
Button Function
<MENU> Press to find an operation mode or to back out of the current menu
option
<UP> Press to scroll up the list of options or to find a higher value
<DOWN> Press to scroll down the list of options or to find a lower value
<ENTER> Press to activate a menu option or a selected value
Menu Map
Mode Programming Steps Description
DMX Address Addr d__1-d512 Selects the DMX starting address
DMX
Personalities PRES
3CH
Selects DMX personality
4CH
5CH
9CH
Dimmer DIM
OFF
Change dimmer speed
DIM1
DIM2
DIM3
Static Colors C--
C1
Red
C2 Green
C3 Blue
C4
Cyan
C5 Magenta
C6 Yellow
C7 White
Touch Control
Panel Lock PASS
ON
Locks touch control panel
Passcode is UP,DOWN,UP,DOWN,ENTER
OFF
Custom Color
Mixing U--
r-- Red
g-- Green
b-- Blue
S-- Strobe rate
Auto Programs P--
P1
S__1-
S100 Auto program selection and speed
selection
P2
P3
P4
P5

Page 10 of 18 SlimPANEL™ TRI 12 IP User Manual (Rev. 4)
Configuration
(DMX)
Set the product in DMX mode to control with a DMX controller.
1. Connect the product to a suitable power outlet.
2. Turn the product on.
3. Connect a DMX cable from the DMX output of the DMX controller to the DMX input
socket on the product.
DMX
Personalities
and Starting
Address
The SlimPANEL™ TRI 12 IP has 4 DMX personalities, from a 3-
channel mode for basic
control to a 9-channel mode with more advanced control over the lights.
The SlimPANEL™ TRI 12 IP uses up to 9 DMX channels in its 9-
channel DMX mode,
which defines the highest configurable address to 504.
When selecting a starting DMX address, always consider the number of DMX channels
the selected DMX mode uses. If you choose a starting address that is too high, you could
restrict the access to some of the product’s channels.
If you are not familiar with the DMX protocol, you may refer to the DMX Primer at
www.chauvetlighting.com.
To select the DMX personality, do the following:
1. Press <MENU> repeatedly until PERS shows on the display.
2. Use <UP> or <DOWN> to select 3CH, 4CH, 5CH or 9CH.
3. Press <ENTER> to choose your DMX personality when it appears on the display.
To then choose your starting address:
1. Press <MENU> repeatedly until Addr shows on the display.
2. Use <UP> or <DOWN> to select the starting address.
3. Press <ENTER>.

SlimPANEL™ TRI 12 IP User Manual (Rev. 4) Page 11 of 18
DMX Channel Assignments and Values
3-CH
Channel Function Value Setting
1
Red
000 ó255
0–100%
2
Green
000 ó255
0–100%
3
Blue
000 ó255
0–100%
4-CH
Channel Function Value Setting
1
Dimmer
000 ó255
0–100%
2
Red
000 ó255
0–100%
3
Green
000 ó255
0–100%
4
Blue
000
ó
255
0–100%
5-CH
Channel Function Value Setting
1
Red
000
ó
255
0–100%
2
Green
000 ó255
0–100%
3
Blue
000 ó255
0–100%
4
Dimmer
000 ó255
0–100%
5 Strobe
000 ó010
No function
011 ó255
Slow to fast

Page 12 of 18 SlimPANEL™ TRI 12 IP User Manual (Rev. 4)
9-CH
Channel Function Value Setting
1
Dimmer
000 ó255
0–100%
2
Red
000 ó255
0–100%
3
Green
000 ó255
0–100%
4
Blue
000 ó255
0–100%
5 Color Macros
000 ó010
No function
011 ó200
Color Macros
201 ó205
White 1: 3200K
206 ó210
White 2: 3400K
211
ó
215
White 3: 4200K
216 ó220
White 4: 4900K
221 ó225
White 5: 5600K
226 ó230
White 6: 5900K
231 ó235
White 7: 6500K
236 ó240
White 8: 7200K
241 ó245
White 9: 8000K
246 ó250
White 10: 8500K
251 ó255
White 11: 10000K
6 Strobe
000 ó009
No function
010 ó255
0–100% (slow to fast)
7 Auto Programs
000 ó051
No function
052 ó101
Auto Program 1
102 ó152
Auto Program 2
153 ó203
Auto Program 3
204
ó
254
Auto Program 4
255
Auto Program 5
8
Auto Program Speed
000 ó255
Slow to fast (when Ch. 7 is between 052-255)
9 Dimmer Curve
000 ó051
Default speed
052 ó101
Linear dimmer
102
ó
152
Nonlinear dimmer 1
153 ó203
Nonlinear dimmer 2
204 ó255
Nonlinear dimmer 3

SlimPANEL™ TRI 12 IP User Manual (Rev. 4) Page 13 of 18
Configuration
(Standalone)
Set the product in one of the standalone modes to control without a DMX controller.
1. Connect the product to a suitable power outlet.
2. Turn the product on.
Never connect a product that is operating in any standalone mode (
Static,
Automatic, or Sound) to a DMX string connected to a DMX controller. Product
s in
standalone mode may transmit DMX signals that could interfere with the DMX
signals from the controller.
Automatic Mode
To enable the Automatic Mode, follow the instructions below:
1. Press <MENU> repeatedly until P-- shows on the display.
2. Press <ENTER>.
3. Use <UP> or <DOWN> to choose an auto program (P1-P5).
4. Press <ENTER> to adjust the speed of the program.
5. Use <UP> or <DOWN>
to adjust the duration of each step of the automatic program
from S__1 (fast) to S100 (slow).
6. Press <ENTER>.
Static Color Mode
To enable the Static Color Mode, follow the instructions below:
1. Press <MENU> repeatedly until C-- shows on the display.
2. Press <ENTER>.
3. Use <UP> or <DOWN> to choose a color (C1-C7).
4. Press <ENTER>.
Custom Static
Color Mode
To enable the Custom Static Color Mode, follow the instructions below:
1. Press <MENU> repeatedly until U-- shows on the display.
2. Press <ENTER> to choose between colors (r--, g--, b--).
3. Press <UP> or <DOWN> to choose the intensity of the color (000-100).
4. Repeat the steps to mix additional colors to create the color you need.
5. Press <ENTER>.
You can also manually adjust the strobe rate. To do so, do the following:
1. Press <MENU> repeatedly until U-- shows on the display.
2. Press <ENTER> until S-- shows on the display.
3. Press <UP> or <DOWN> to choose the strobe rate (S 0-S 20).
4. Press <ENTER> once you have chosen your desired strobe rate.
Dimmer
Adjustment
You can manually control the dimmer speed to suit any need. To set up your preferred
dimmer speed, do the following:
1. Press <MENU> repeatedly until DIM shows on the display.
2. Press <ENTER>.
3. Use <UP> or <DOWN> to choose between the dimming types (OFF-DIM3).
4. Press <ENTER>.

Page 14 of 18 SlimPANEL™ TRI 12 IP User Manual (Rev. 4)
Touch Control
Panel Lock
To enable the touch panel lock, follow the instructions below:
1. Press <MENU> repeatedly until PASS shows on the display.
2. Press <ENTER>.
3. Press <UP> or <DOWN> until ON
shows on the display to enable the touch panel
lock.
To disable the touch panel lock so you can resume functionality, follow the steps below:
1. Press <UP>, <DOWN>, <UP>, <DOWN>, <ENTER>
to disable the touch panel
lock.
2. Press <MENU> to move through the menus as normal.
In situations where water may flow onto the touch display, use the Touch Panel
Control Lock so that the water does not reset the product’s settings.
Master/Slave
Mode
The Master/Slave mode allows a single SlimPANEL™ TRI 12 IP
unit (the “master”) to
control the actions of one or more SlimPANEL™ TRI 12 IP
units (the “slaves”) without
the need of a DMX controller. The master unit will be set to operate in either Automatic
or Sound Active mode, while the slave units will be set to
operate in Slave Mode. Once
set and connected, the slave units will operate in unison with the master unit.
Configure the units as indicated below.
Slave units:
1. Press <MENU>repeatedly until Addr shows on the display.
2. Press <ENTER> to accept.
3. Set the DMX address to 001.
4. Connect the DMX input of the first slave unit to the DMX output of the master unit.
5. Connect the DMX input of the subsequent slave units to the DMX output of the
previous slave unit.
6. Finish setting and connecting all the slave units.
Master unit:
1. Set the master unit to operate in Static Color Mode, Automatic, or Custom Static
Color mode.
2. Make the master unit the first unit in the daisy chain.
•Configure
all the slave units before connecting the master unit to the daisy
chain.
•
Never connect a DMX controller to a DMX string configured for Master/Slave
operation because the controller
may interfere with the signals from the
master unit.
•Do not connect more than 31 slave units to the master unit.

SlimPANEL™ TRI 12 IP User Manual (Rev. 4) Page 15 of 18
5.TECHNICAL INFORMATION
Product
Maintenance
Dust build up reduces light output performance and can cause overheating. This can
lead to reduction of the light source’s life and mechanical wear.
To maintain optimum
performance and minimize wear, you should clean your lighting products
at least twice a
month. However, use and environmental conditions could be contributing factors to
increased cleaning.
To clean the product, follow the instructions below:
1. Unplug the product from power.
2. Wait until the product is at room temperature.
3.
Use a vacuum (or dry compressed air) and a soft brush to remove dust collected on
the external surface/vents.
4. Clean all external optics and glass/transparent surfaces with a mild soap solution,
ammonia-free glass cleaner, or isopropyl alcohol.
5. Apply the solution directly to a soft, lint free cotton cloth or a lens cleaning tissue.
6. Softly drag any dirt or grime to the outside of the external optics or
glass/transparent surface.
7. Gently polish the external optics and glass/transparent surfaces until they are free
of haze and lint.
Always dry the external optics and glass/transparent
surfaces carefully after
cleaning them.

Page 16 of 18 SlimPANEL™ TRI 12 IP User Manual (Rev. 4)
6.TECHNICAL SPECIFICATIONS
Dimensions and
Weight
Length
Width
Height
Weight
14 in (358 mm)
7 in (180 mm)
3.5 in (90 mm)
10.5 lbs (4.8 kg)
Note: Dimensions in inches rounded to the nearest decimal digit.
Power
Power Supply Type
Range
Voltage Selection
Switching (internal)
100–240 V, 50/60 Hz
Auto-ranging
Parameter
120 V, 60 Hz
230 V, 50 Hz
Consumption
46 W
46 W
Operating
0.4 A
0.2 A
Power linking current (units)
8 A (19 units)
8 A (39 units)
Power I/O
U.S./Worldwide
UK/Europe
Power input connector
Proprietary
Proprietary
Power output connector
Proprietary
Proprietary
Power Cord plug
Edison (U.S.)
Local plug
Light Source
Type
Power
Lifespan
LED
3 W
50,000 hours
Color
Quantity
Current
Tri-color
12
350 mA (x3)
Photometrics
Parameter
Strobe Rate
0 to 27 Hz
Illuminance @ 2 m
3,576 lux
Beam angle
20º
Field angle
34º
Thermal
Maximum External Temp.
Minimum Startup Temp.
Cooling System
113° F (45° C)
-4° F (-20° C)
Convection
DMX
I/O Connectors
Connector Type
Channel Range
3-pin XLR
Proprietary
3, 4, 5 or 9
Ordering
Product Name
Item Code
UPC Number
SlimPANEL™ TRI 12 IP
03030525
781462208738

SlimPANEL™ TRI 12 IP User Manual (Rev. 4) Page 17 of 18
In case you need to get support or return a product:
•If you are located in the U.S., contact Chauvet World Headquarters.
•If you are located in the UK or Ireland, contact Chauvet Europe Ltd.
•If you are located in Mexico, contact Chauvet Mexico.
•If you are located in Benelux, contact Chauvet Europe BVBA.
•If you are located in any other country, DO NOT contact Chauvet. Instead, contact
your local distributor. See www.chauvetlighting.com for distributors outside the U.S.,
UK, Ireland, Mexico, or Benelux.
If you are located outside the U.S., UK, Ireland, Mexico, or Benelux, contact your
distributor of record and follow their instructions on how to return Chauvet
products to them. Visit our website www.chauvetlighting.com for contact details.
Returns
Call the corresponding Chauvet
Tech Support office and request a Return Merchandise
Authorization (RMA) number before shipping the product
. Be prepared to provide the
model number, serial number, and a brief description of the cause for the return.
You must send the merchandise prepaid, in its original box, and with its original packing
and accessories. Chauvet will not issue call tags.
Clearly label the package with the RMA number. Chauvet will refuse any product
returned without an RMA number.
Write the RMA number on a properly affixed label. DO NOT write the RMA number
directly on the box.
Before sending the product, clearly write
the following information on a piece of paper
and place it inside the box:
•Your name
•Your address
•Your phone number
•The RMA number
•A brief description of the problem
Be sure to pack the product
properly. Any shipping damage resulting from inadequate
packaging will be your responsibility. As a suggestion, proper UPS packing or double-
boxing is always a safe method to use.
Chauvet
reserves the right to use its own discretion to repair or replace returned
product(s).

Page 18 of 18 SlimPANEL™ TRI 12 IP User Manual (Rev. 4)
C
ONTACT
U
S
WORLD HEADQUARTERS - Chauvet
General Information
Address: 5200 NW 108th Avenue
Sunrise, FL 33351
Voice: [phone]
Fax: [phone]
Toll free: [phone]
Technical Support
Voice: [phone] (Press 4)
Fax: [phone]
Email: tec[email protected]
World Wide Web www.chauvetlighting.com
UNITED KINGDOM AND IRELAND - Chauvet Europe Ltd.
General Information
Address: Unit 1C
Brookhill Road Industrial Estate
Pinxton, Nottingham, UK
NG16 6NT
Voice: [phone]
Fax: [phone]
Technical Support
Email: ukt[email protected]om
World Wide Web
www.chauvetlighting.co.uk
MEXICO - Chauvet Mexico
General Information
Address: Av. Santa Ana 30
Parque Industrial Lerma
Lerma, Mexico C.P. 52000
Voice: [phone]
Technical Support
Email: servic[email protected]
World Wide Web www.chauvet.com.mx
CHAUVET EUROPE - Chauvet Europe BVBA
General Information
Address:Stokstraat 18
9770 Kruishoutem
Belgium
Voice: [phone]
Technical Support
Email: [e-mail]
World Wide Web www.chauvetlighting.eu
Outside the U.S., United Kingdom, Ireland, Mexico, or Benelux
contact your dealer. Follow their
instructions to request support or to return a product. Visit our website for contact details.
