Chauvet Vue 6.1 User manual

Snapshot
Ok on Dimmer
Outdoor OK
Sound Activated
DMX512
Master/Slave
Autoswitching
Transformer
Replaceable Fuse
User Serviceable
Duty Cycle
Vue™ 6.1
USER MANUAL
Chauvet, 3000 N 29th Ct, Hollywood, FL 33020 U.S.A.
[phone] – [phone]
FAX [phone]
www.chauvetlighting.com

TABLE OF CONTENTS
1. Before You Begin...................................................................................................................................... 3
What is included.............................................................................................................................................. 3
Unpacking Instructions.................................................................................................................................... 3
AC Power........................................................................................................................................................ 3
Safety Instructions .......................................................................................................................................... 4
2. Introduction............................................................................................................................................... 5
Features.......................................................................................................................................................... 5
DMX Channel Summary ................................................................................................................................. 5
Product Overview............................................................................................................................................ 6
3. Setup.......................................................................................................................................................... 7
Fuse Replacement.......................................................................................................................................... 7
Fixture Linking................................................................................................................................................. 7
Data Cabling................................................................................................................................................... 7
DMX Data Cable............................................................................................................................................. 7
Cable Connectors ........................................................................................................................................... 8
3-Pin to 5-Pin Conversion Chart ..................................................................................................................... 8
Setting up a DMX Serial Data Link.................................................................................................................. 8
Stand-Alone/Master/Slave Fixture Linking...................................................................................................... 9
Mounting......................................................................................................................................................... 9
Orientation ...................................................................................................................................................... 9
Rigging............................................................................................................................................................ 9
4. Operating Instructions............................................................................................................................ 10
Menu Functions ............................................................................................................................................ 10
Operation...................................................................................................................................................... 11
Stand-Alone Mode (Sound-Active, Auto Mode): ........................................................................................... 11
Master/Slave Mode (Master Sound, Master Auto):....................................................................................... 11
DMX Mode.................................................................................................................................................... 11
DMX Channel Values.................................................................................................................................... 12
DMX Quick Reference Chart......................................................................................................................... 14
Vue™ 6.1 Maintenance Guide.................................................................................................................... 15
Contact Us.................................................................................................................................................... 16
General Information ...................................................................................................................................... 16
Technical Support......................................................................................................................................... 16
5. Appendix.................................................................................................................................................. 16
DMX Primer .................................................................................................................................................. 16
General Maintenance.................................................................................................................................... 16
Returns Procedure........................................................................................................................................ 17
Claims........................................................................................................................................................... 17
Blow-out Diagram ......................................................................................................................................... 18
Technical Specifications ............................................................................................................................... 20
Vue™ 6.1 User Manual 2 2008-12-03/14:33

1. BEFORE YOU BEGIN
What is included
¾1 x Vue™ 6.1
¾Power Cord
¾Warranty Card
¾User Manual
Unpacking Instructions
Immediately upon receiving a fixture, carefully unpack the carton, check the contents to ensure that
all parts are present, and have been received in good condition. Notify the shipper immediately and
retain packing material for inspection if any parts appear damaged from shipping or the carton itself
shows signs of mishandling. Save the carton and all packing materials. In the event that a fixture
must be returned to the factory, it is important that the fixture be returned in the original factory box
and packing.
AC Power
This fixture has an auto-switching power supply that can accommodate a wide range of input
voltages. The only thing necessary to do before powering on the unit is to make sure the line voltage
you are applying is within the range of accepted voltages. This fixture will accommodate between
100V and 240V AC. All fixtures must be powered directly off a switched circuit and cannot be run off a
rheostat (variable resistor) or dimmer circuit, even if the rheostat or dimmer channel is used solely for
a 0% to 100% switch.
Vue™ 6.1 User Manual 3 2008-12-03/14:33

Safety Instructions
Please read these instructions carefully, which includes important
information about the installation, usage and maintenance of this
product.
•Please keep this User Guide for future consultation. If you sell the unit to another user, be sure that
they also receive this instruction booklet.
•Always make sure that you are connecting to the proper voltage, and that the line voltage you are
connecting to is not higher than that stated on the decal or rear panel of the fixture.
•This product is intended for indoor use only!
•To prevent risk of fire or shock, do not expose fixture to rain or moisture. Make sure there are no
flammable materials close to the unit while operating.
•The unit must be installed in a location with adequate ventilation, at least 50cm (20in) from adjacent
surfaces. Be sure that no ventilation slots are blocked.
•Always disconnect from power source before servicing or replacing lamp or fuse and be sure to
replace with same lamp source.
•Secure fixture to fastening device using a safety chain. Never carry the fixture solely by its head. Use
its carrying handles.
•Maximum ambient temperature (Ta) is 104°F (40°C). Do not operate fixture at temperatures higher
than this.
•In the event of a serious operating problem, stop using the unit immediately. Never try to repair the
unit by yourself. Repairs carried out by unskilled people can lead to damage or malfunction. Please
contact the nearest authorized technical assistance center. Always use the same type spare parts.
•Don’t connect the device to a dimmer pack.
•Make sure the power cord is never crimped or damaged.
•Never disconnect the power cord by pulling or tugging on the cord.
•Avoid direct eye exposure to the light source while it is on.
•Do not link more than 20 @120V and 35@230V
Caution! There are no user serviceable parts inside the unit. Do not open the housing or
attempt any repairs yourself. In the unlikely event your unit may require service,
please contact CHAUVET at: 954-929-1115.
Vue™ 6.1 User Manual 4 2008-12-03/14:33

2. INTRODUCTION
Features
•6-channel DMX-512 rotating LED moonflower
•Blackout/static/strobe
•Individual control of red, green and blue LEDs within each cluster (3 total)
•Built-in automated programs via master/slave or DMX
•Built-in sound activated programs via master/slave or DMX
Additional Features
•Linkable with Vue™ I, Vue™ 1.1 and Vue™ II
•Adjustable hanging bracket with slide rail
•Additional power output: max 20 units @ 120V (see manual for details)
DMX Channel Summary
CHANNEL FUNCTION
1 Mode
2 Pod 1
3 Pod 2
4 Pod 3
5 Strobe Speed
6 Motor Speed
Vue™ 6.1 User Manual 5 2008-12-03/14:33

Product Overview
Bracket
Adjustment
Knob
Hanging
Bracket
Digital
Display
Microphone
Sound
Sensitivity
Knob
Power
Output
Connector
Vue™ 6.1 User Manual 6 2008-12-03/14:33
DMX
Output
Connector
DMX Input
Connector
AC Power Input
& Fuse

3.SETUP
Disconnect the power cord before replacing a fuse and always
replace with the same type fuse.
Fuse Replacement
With a flat head screwdriver wedge the fuse
holder out of its housing. Remove the damaged
fuse from its holder and replace with exact
same type fuse. Insert the fuse holder back in
its place and reconnect power.
The fuse is located
inside this
compartment.
Remove using a flat
head screwdriver.
Fixture Linking
You will need a serial data link to run light shows of one or more fixtures using a DMX-512 controller
or to run synchronized shows on two or more fixtures set to a master/slave operating mode. The
combined number of channels required by all the fixtures on a serial data link determines the number
of fixtures the data link can support.
This fixture uses 9 channels of DMX control.
Important: Fixtures on a serial data link must be daisy chained in one single line. To comply with the EIA-485
standard no more than 32 devices should be connected on one data link. Connecting more than 32
fixtures on one serial data link without the use of a DMX optically-isolated splitter may result in
deterioration of the digital DMX signal.
Maximum recommended serial data link distance: 500 meters (1640 ft.)
Maximum recommended number of fixtures on a serial data link: 32 fixtures
Data Cabling
To link fixtures together you must obtain data cables. You can purchase CHAUVET-certified DMX
cables directly from a dealer/distributor or construct your own cable. If you choose to create your own
cable please use data-grade cables that can carry a high quality signal and are less prone to
electromagnetic interference.
DMX DATA CABLE
Use a Belden© 9841 or equivalent cable which meets the specifications for EIA RS-485 applications.
Standard microphone cables cannot transmit DMX data reliably over long distances. The cable will
have the following characteristics:
2-conductor twisted pair plus a shield
Maximum capacitance between conductors – 30 pF/ft.
Maximum capacitance between conductor and shield – 55 pF/ft.
Maximum resistance of 20 ohms / 1000 ft.
Nominal impedance 100 – 140 ohms
Vue™ 6.1 User Manual 7 2008-12-03/14:33

CABLE CONNECTORS
Cabling must have a male XLR connector on one end and a female XLR connector on the other end.
Vue™ 6.1 User Manual 8 2008-12-03/14:33
CAUTION Do not allow contact between the common and the fixture’s chassis ground. Grounding the common
can cause a ground loop, and your fixture may perform erratically. Test cables with an ohm meter to
verify correct polarity and to make sure the pins are not grounded or shorted to the shield or each other.
3-PIN TO 5-PIN CONVERSION CHART
Note! If you use a controller with a 5 pin DMX output connector, you will need to use a 5 pin to 3 pin adapter.
CHAUVET Model No: DMX5M, or DMX5F.
The chart below details a proper cable conversion:
3PIN TO 5PIN CONVERSION CHART
Conductor 3 Pin Female (output) 5 Pin Male (Input)
Ground/Shield Pin 1 Pin 1
Data ( - ) signal Pin 2 Pin 2
Data ( + ) signal Pin 3 Pin 3
Do not use Do not use
Do not use Do not use
Setting up a DMX Serial Data Link
1. Connect the (male) 3 pin connector side of the DMX cable to the output (female) 3 pin connector
of the controller.
2. Connect the end of the cable coming from the controller which will have a (female) 3 pin connector
to the input connector of the next fixture consisting of a (male) 3 pin connector.
3. Then, proceed to connect from the output as stated above to the input of the following fixture and
so on.
CHAUVET Certified DMX Data Cables
Order Code Description
DMX1.5 DMX Cable 1.5m/4.9ft
DMX4.5 DMX Cable 4.5m/14.8ft
DMX10 DMX Cable 10m/32.8ft
COMMON
DMX
+
DMX -
INPUT OUTPUT
1
3
2
1
3
2
1
3
2
Resistance 120
ohm 1/4w between
pin 2 (DMX -) and
pin 3 (DMX +) of
the last fixture.
Termination reduces signal errors and
to avoid signal transmission problems
and interference, it is always
advisable to connect a DMX signal
terminator.
DMX connector configuration
This drawing provides a
general illustration of the
DMX Input/Output panel of
a lighting fixture.
Universal DMX Controller
Continue the link

Stand-Alone/Master/Slave Fixture Linking
1. Connect the (male) 3 pin connector side of the DMX cable to the output (female) 3 pin connector
of the first fixture.
2. Connect the end of the cable coming from the first fixture which will have a (female) 3 pin
connector to the input connector of the next fixture consisting of a (male) 3 pin connector. Then,
proceed to connect from the output as stated above to the input of the following fixture and so on.
Often, the setup for Master-Slave
and Standalone operation requires
that the first fixture in the chain be
initialized for this purpose via either
settings in the control panel or DIP-
switches. Secondarily, the fixtures
that follow may also require a slave
setting. Please consult the
“Operating Instructions” section in
this manual for complete instructions
for this type of setup and
configuration.
Mounting
ORIENTATION
This fixture may be mounted in any safe position provided there is adequate room for ventilation.
RIGGING
Hanging Clamp
Note!
Clamp is sold separatel
y
.
It is important never to obstruct the fan or vents pathway. Mount the
fixture using, a suitable “C” or “O” type clamp. Adjust the angle of the
fixture by loosening both knobs and tilting the fixture. After finding the
desired position, retighten both knobs.
•When selecting installation location, take into consideration lamp
replacement access and routine maintenance.
•Safety cables should always be used.
•Never mount in places where the fixture will be exposed to rain, high
humidity, extreme temperature changes or restricted ventilation.
Vue™ 6.1 User Manual 9 2008-12-03/14:33

4. OPERATING INSTRUCTIONS
Display Options
M/S
DMX
Menu Functions
MAIN FUNCTION SELECTION INSTRUCTION
SET.d d:001-d:512
Sets the DMX starting address
SET.S S:001-S:100
Sets the speed of the current program
SET.
f
F:000-F:100
Sets the flash rate of the current program
SET.
A
A:000-
A
:035 Selects the current program in standalone
SUND This is displaying that the fixture is
operating in sound activation mode
AUTO This is displaying that the fixture is
operating in auto activation mode
Navigating the menu
1. Press Mode to scroll through the menu options.
2. Press Enter to select a function to modify.
3. Use the Up and Down buttons to modify the selected menu function.
Vue™ 6.1 User Manual 10 2008-12-03/14:33

Operation
Stand-Alone Mode (Sound-Active, Auto Mode):
This mode allows a single unit to run to the beat of the music, or the unit will auto change in Auto
Mode. There is an LED indicator on the rear of the fixture which will indicate this mode.
1. Use
SET.A to choose the desired program.
2. Use
SET.S to set the speed of the current program
3. Use
SET.f to set the flash rate of the current program.
Note: when there is no sound available, then the unit will automatically switch to auto
mode. To change it into auto mode when there is sound present, then simply turn the
sound adjustment knob fully counter-clockwise.
Note: In the absence of DMX signal, the fixture will automatically revert to standalone
mode. Plugging in a DMX cable that is connected to a DMX controller will automatically
disable standalone mode and put the fixture into DMX mode.
Note: In sound-active mode, the display will read SUND.
•The unit will react to the low frequencies of music via the internal microphone in Sound
Active mode, or the unit will auto change in Auto Mode.
•Use the audio sensitivity knob on the back of the unit to make the unit more or less
sensitive in Sound-Active mode. Turning the knob counterclockwise decreases the
sensitivity; turning the knob clockwise increases the sensitivity.
Master/Slave Mode (Master Sound, Master Auto):
This mode will allow you to link up to 32 units together without a controller. The first fixture in the
daisy chain will automatically be assigned as the master, and each fixture following will be assigned
as slave fixtures.
Note: for this mode, you must not connect a DMX controller to the fixtures.
Note: In sound-active mode, the display will read SUND.
1) Use standard DMX cables to daisy chain your units together via the DMX connector on the rear
of the units. For longer cable runs we suggest a terminator at the last fixture. For more
information about terminators, see page 14.
DMX Mode This mode allows the unit to be controlled by any universal DMX controller. If you are unfamiliar with
DMX, please read the DMX Primer section in the appendix. The fixture will automatically switch to
DMX mode when it sees the signal from a DMX controller.
Note: In the absence of DMX signal, the fixture will automatically revert to standalone
mode. Plugging in a DMX cable that is connected to a DMX controller will automatically
disable standalone mode and put the fixture into DMX mode.
1. Plug in your DMX controller to the fixture to put in into DMX mode.
2. Set your address by SET.d.
3. Press Enter.
4. Use the Up and Down buttons to scroll to the desired DMX starting address.
5. Press Enter.
Vue™ 6.1 User Manual 11 2008-12-03/14:33

DMX Channel Values
CHANNEL VALUE FUNCTION
1
000 Ù024
025 Ù049
050 Ù074
075 Ù099
100 Ù124
125 Ù149
150 Ù174
175 Ù199
200 Ù224
225 Ù249
250 Ù255
Control/Operating Mode
Dimmer mode
Stand-alone mode 1 (automatic)
Stand-alone mode 2 (automatic)
Stand-alone mode 3 (automatic)
Stand-alone mode 4 (automatic)
Stand-alone mode 5 (automatic)
Stand-alone mode 6 (automatic)
Stand-alone mode 7 (automatic)
Stand-alone mode 8 (automatic)
Stand-alone mode 9 (automatic)
Stand-alone (sound active)
2-4
000 Ù004
005 Ù009
010 Ù014
015 Ù019
020 Ù024
025 Ù029
030 Ù034
035 Ù039
040 Ù044
045 Ù049
050 Ù054
055 Ù059
060 Ù064
065 Ù069
070 Ù074
075 Ù079
080 Ù084
085 Ù089
090 Ù094
095 Ù099
100 Ù104
105 Ù109
110 Ù114
115 Ù119
120 Ù124
125 Ù129
130 Ù134
135 Ù139
140 Ù144
145 Ù149
150 Ù154
155 Ù159
160 Ù164
165 Ù169
170 Ù255
Pod 1/2/3
Blackout
Red
Yellow
Green
Blue
Purple
Cyan
White
Auto 1
Auto 2
Auto 3
Auto 4
Auto 5
Auto 6
Auto 7
Auto 8
Auto 9
Auto 10
Auto 11
Auto 12
Auto 13
Auto 14
Auto 15
Auto 16
Auto 17
Auto 18
Auto 19
Auto 20
Auto 21
Auto 22
Auto 23
Auto 24
Auto 25
Auto 26
Auto 27
5
000 Ù005
006 Ù255
Strobing Speed (Dimmer Mode)
Blackout
Slow →Fast
6
000 Ù005
006 Ù255
Motor Speed
Stop
Slow →Fast
Vue™ 6.1 User Manual 12 2008-12-03/14:33

SETTING THE STARTING ADDRESS
This DMX mode enables the use of a universal DMX controller device. Each fixture requires a "start address"
from 1 to 512. A fixture requiring one or more channels for control begins to read the data on the channel
indicated by the start address. For example, a fixture that uses 6 DMX channels and was addressed to start on
DMX channel 100, would read data from channels: 100, 101, 102, 103, 104, and 105. Choose start addresses
so that the channels used do not overlap, and note the start address selected for future reference.
If this is your first time addressing a fixture using the DMX-512 control protocol, we suggest jumping to the
Appendix Section and reading the heading “DMX Primer”. It contains very useful information that will help you
understand its use.
Set the start address using the group of DIP switches located usually on bottom of the fixture. Each dip switch
has an associated value. Adding the value of each switch in the ON position will provide the start address.
Figuring out which switches to toggle ON given a specific start address can be accomplished by determining
which switch values will add up to the address value and turning these switches on. Do so by doing the
following:
1) Determine the largest value switch that is less than the start address. Turn this switch on.
2) Subtract the value of the switch you just turned on from the starting address number.
3) Determine the largest value switch that is less than the remainder from the previous subtraction. Turn this
switch on.
4) Subtract the value of the switch you just turned on from the remainder of the previous subtraction.
5) Repeat steps three and four until you have a remainder of zero.
EXAMPLE STARTING ADDRESS
Address 10
Switch # 4 = 8
Switch # 2 = 2
Total = 10
13456789 ON
OFF
1 2 4 8
16 32 64
128 256
13456789 ON
OFF
1 2 4 8
16 32 64
128 256
13456789 ON
OFF
1 2 4 8
16 32 64
128 256
13456789 ON
OFF
1 2 4 8
16 32 64
128 256
13456789 ON
OFF
1 2 4 8
16 32 64
128 256
12222223456789 ON
OFF
1 2 4 8
16 32 64
128 256
Address 24
Switch # 5 = 16
Switch # 4 = 8
Total = 24
123456789 ON
OFF
1 2 4 8
16 32 64
128 256
123456789 ON
OFF
1 2 4 8
16 32 64
128 256
123456789 ON
OFF
1 2 4 8
16 32 64
128 256
123456789 ON
OFF
1 2 4 8
16 32 64
128 256
123456789 ON
OFF
1 2 4 8
16 32 64
128 256
123456789 ON
OFF
1 2 4 8
16 32 64
128 256
Resolving address
using simple math.
Address 233
233 – (128) = 105, Turn ON Dip # 8
105 – (64) = 41, Turn ON Dip # 7
41 – (32) = 9, Turn ON Dip # 6
9 – (8) = 1, Turn ON Dip # 4
1 – (1) = 0, Turn ON Dip # 1
DIPSWITCH

(DMXVALUE)

1
2
3
4
5
6
7
8
9
1
2
4
8
16
32
64
128
256
Vue™ 6.1 User Manual 13 2008-12-03/14:33

DMX QUICK REFERENCE CHART
DMX Address Quick Reference Chart
Dip Switch Position
DMX DIP
SWITCH SET #9 0 0 0 0 0 0 0 0 1 1 1 1 1 1 1 1
0=OFF #8 0 0 0 0 1 1 1 1 0 0 0 0 1 1 1 1
1=ON #7 0 0 1 1 0 0 1 1 0 0 1 1 0 0 1 1
X=OFF or ON #6 0 1 0 1 0 1 0 1 0 1 01 0 1 0 1
#1 #2 #3 #4 #5
0 0 0 0 0 32 64 96 128 160 192 224 256 288 320 352 384 416 448 480
1 0 0 0 0 1 33 65 97 129 161 193 225 257 289 321 353 385 417 449 481
0 1 0 0 0 2 34 66 98 130 162 194 226 258 290 322 354 386 418 450 482
1 1 0 0 0 3 35 67 99 131 163 195 227 259 291 323 355 387 419 451 483
0 0 1 0 0 4 36 68 100 132 164 196 228 260 292 324 356 388 420 452 484
1 0 1 0 0 5 37 69 101 133 165 197 229 261 293 325 357 389 421 453 485
0 1 1 0 0 6 38 70 102 134 166 198 230 262 294 326 358 390 422 454 486
1 1 1 0 0 7 39 71 103 135 167 199 231 263 295 327 359 391 423 455 487
0 0 0 1 0 8 40 72 104 136 168 200 232 264 296 328 360 392 424 456 488
1 0 0 1 0 9 41 73 105 137 169 201 233 265 297 329 361 393 425 457 489
0 1 0 1 0 10 42 74 106 138 170 202 234 266 298 330 362 394 426 458 490
1 1 0 1 0 11 43 75 107 139 171 203 235 267 299 331 363 395 427 459 491
0 0 1 1 0 12 44 76 108 140 172 204 236 268 300 332 364 396 428 460 492
1 0 1 1 0 13 45 77 109 141 173 205 237 269 301 333 365 397 429 461 493
0 1 1 1 0 14 46 78 110 142 174 206 238 270 302 334 366 398 430 462 494
1 1 1 1 0 15 47 79 111 143 175 207 239 271 303 335 367 399 431 463 495
0 0 0 0 1 16 48 80 112 144 176 208 240 272 304 336 368 400 432 464 496
1 0 0 0 1 17 49 81 113 145 177 209 241 273 305 337 369 401 433 465 497
0 1 0 0 1 18 50 82 114 146 178 210 242 274 306 338 370 402 434 466 498
1 1 0 0 1 19 51 83 115 147 179 211 243 275 307 339 371 403 435 467 499
0 0 1 0 1 20 52 84 116 148 180 212 244 276 308 340 372 404 436 468 500
1 0 1 0 1 21 53 85 117 149 181 213 245 277 309 341 373 405 437 469 501
0 1 1 0 1 22 54 86 118 150 182 214 246 278 310 342 374 406 438 470 502
1 1 1 0 1 23 55 87 119 151 183 215 247 279 311 343 375 407 439 471 503
0 0 0 1 1 24 56 88 120 152 184 216 248 280 312 344 376 408 440 472 504
1 0 0 1 1 25 57 89 121 153 185 217 249 281 313 345 377 409 441 473 505
0 1 0 1 1 26 58 90 122 154 186 218 250 282 314 346 378 410 442 474 506
1 1 0 1 1 27 59 91 123 155 187 219 251 283 315 347 379 411 443 475 507
0 0 1 1 1 28 60 92 124 156 188 220 252 284 316 348 380 412 444 476 508
1 0 1 1 1 29 61 93 125 157 189 221 253 285 317 349 381 413 445 477 509
0 1 1 1 1 30 62 94 126 158 190 222 254 286 318 350 382 414 446 478 510
1 1 1 1 1 31 63 95 127 159 191 223 255 287 319 351 383 415 447 479 511
Dip Switch Position DMX Address
Vue™ 6.1 User Manual 14 2008-12-03/14:33

Vue™ 6.1 Maintenance Guide
Symptom(s) Possible Solution(s)
1 or more LED’s are not
illuminating
Clean the fixture regularly to avoid any such failure. This fixture is convection
cooled, which means that if the surface is kept clean and free of debris, then
proper cooling will be allowed to occur
An LED may have failed, resulting in an open circuit. In this event, all of the
red, green, or blue in a single module will no longer illuminate. This does not
mean that all of the LEDs have failed, but the circuit is wired in series.
An LED may have failed, resulting in a short circuit. In this event, only the
single LED which has failed will no longer function. This does not mean that all
of the LEDs have failed, but the circuit is wired in series.
-Note: In the event of LED failure, a replacement LED PCB assembly may be
purchased directly from CHAUVET Part#: P222-VIVDLED
1 or more LED’s are producing
very low output
Check that the lens assembly is installed properly. If the lens assembly is not
aligned properly over the LEDs, then they will not project fully
-See section on Lens Assembly Installation
-Note: In the event of LED failure, a replacement LED PCB assembly may be
purchased directly from CHAUVET Part#: P222-VIVDLED
Breaker/Fuse keeps blowing Check total load placed on the electrical circuit
Check for a short in the electrical wiring: internal and/or external
Device has no power Check device’s fuse (internal)
Check for power on Mains
-Note: In the event of autoswitching transformer failure, the unit can be sent in
for repair; however, a replacement part can be ordered directly from
CHAUVET Part#: P140-VIELTR
Fixture is not responding to DMX Check Control Panel settings for correct addressing
Check DMX cables
Check polarity switch settings on the controller
Check cable connections
Call service technician
See page #11 for proper settings for DMX operation
-Note: In the event of Master PCB failure, a replacement PCB can be ordered
directly from CHAUVET Part#: P170-VUEIVMP
Loss of signal Use only DMX cables
Install terminator
Note: Keep DMX cables separated from power cables or black lights
Stand alone operation problem See page #11 for proper settings for standalone operation
The motor is not rotating This fixture uses a separate channel to operate the motor rotation. Try
operating the fixture in standalone mode to determine if the problem is DMX
related. If the motor still does not rotate, then it may need to be replaced, or
the motor driver IC or the Master PCB may need to be replaced.
-Note: In the event of motor failure, a replacement motor can be ordered
directly from CHAUVET Part#: P110-VUEMTR
-Note: In the event of Master PCB failure, a replacement PCB can be ordered
directly from CHAUVET Part#: P170-VUEIVMP
If you still have a problem after trying the above solutions, please contact CHAUVET Technical
Support at the location on the next page.
Vue™ 6.1 User Manual 15 2008-12-03/14:33

Contact Us
General Information
Chauvet Lighting
3000 N 29th Ct,
Hollywood, FL 33020 (U.S.A.)
voice: [phone]
fax: [phone]
toll free: 800-762-1084
Technical Support
Address: Service Dept.
3000 N 29th Ct, Hollywood, FL 33020 (U.S.A.)
Support (Email): [email protected]om
Telephone: [phone] - (Press 4)
Fax: [phone] - (Attention: Service)
Website: http://www.chauvetlighting.com
5.APPENDIX
DMX Primer
There are 512 channels in a DMX-512 connection. Channels may be assigned in any manner. A
fixture capable of receiving DMX 512 will require one or a number of sequential channels. The user
must assign a starting address on the fixture that indicates the first channel reserved in the controller.
There are many different types of DMX controllable fixtures and they all may vary in the total number
of channels required. Choosing a start address should be planned in advance. Channels should
never overlap. If they do, this will result in erratic operation of the fixtures whose starting address is
set incorrectly. You can however, control multiple fixtures of the same type using the same starting
address as long as the intended result is that of unison movement or operation. In other words, the
fixtures will be slaved together and all respond exactly the same.
DMX fixtures are designed to receive data through a serial Daisy Chain. A Daisy Chain connection is
where the DATA OUT of one fixture connects to the DATA IN of the next fixture. The order in which
the fixtures are connected is not important and has no effect on how a controller communicates to
each fixture. Use an order that provides for the easiest and most direct cabling. Connect fixtures
using shielded two conductor twisted pair cable with three pin XLR male to female connectors. The
shield connection is pin 1, while pin 2 is Data Negative (S-) and pin 3 is Data positive (S+). CHAUVET
carries 3-pin XLR DMX compliant cables, DMX-10 (33’), DMX-4.5 (15’) and DMX-1.5 (5’)
General Maintenance
To maintain optimum performance and minimize wear fixtures should be cleaned frequently. Usage
and environment are contributing factors in determining frequency. As a general rule, fixtures should
Vue™ 6.1 User Manual 16 2008-12-03/14:33

be cleaned at least twice a month. Dust build up reduces light output performance and can cause
overheating. This can lead to reduced lamp life and increased mechanical wear. Be sure to power off
fixture before conducting maintenance.
Unplug fixture from power. Use a vacuum or air compressor and a soft brush to remove dust
collected on external vents and internal components. Clean all glass when the fixture is cold with a
mild solution of glass cleaner or Isopropyl Alcohol and a soft lint free cotton cloth or lens tissue. Apply
solution to the cloth or tissue and drag dirt and grime to the outside of the lens. Gently polish optical
surfaces until they are free of haze and lint.
The cleaning of internal and external optical lenses and/or mirrors must be carried out periodically to
optimize light output. Cleaning frequency depends on the environment in which the fixture operates:
damp, smoky or particularly dirty surrounding can cause greater accumulation of dirt on the unit’s
optics. Clean with soft cloth using normal glass cleaning fluid. - Always dry the parts carefully. - Clean
the external optics at least every 20 days. Clean the internal optics at least every 30/60 days.
Returns Procedure
Returned merchandise must be sent prepaid and in the original packing, call tags will not be issued.
Package must be clearly labeled with a Return Merchandise Authorization Number (RMA #).
Products returned without an RMA # will be refused. Call CHAUVET and request RMA # prior to
shipping the fixture. Be prepared to provide the model number, serial number and a brief description
of the cause for the return. Be sure to properly pack fixture, any shipping damage resulting from
inadequate packaging is the customer’s responsibility. CHAUVET reserves the right to use its own
discretion to repair or replace product(s). As a suggestion, proper UPS packing or double-boxing is
always a safe method to use.
Note: If you are given an RMA #, please include the following information on a piece of paper inside the box:
1) Your name
2) Your address
3) Your phone number
4) The RMA #
5) A brief description of the symptoms
Claims
Damage incurred in shipping is the responsibility of the shipper; therefore the damage must be
reported to the carrier upon receipt of merchandise. It is the customer's responsibility to notify and
submit claims with the shipper in the event that a fixture is damaged due to shipping. Any other claim
for items such as missing component/part, damage not related to shipping, and concealed damage,
must be made within seven (7) days of receiving merchandise.
Vue™ 6.1 User Manual 17 2008-12-03/14:33

Blow-out Diagram
2
5
1
4
3
6
7
DescriptionPartNumber
1FrontFresnelLensP150‐V6LENS
2LEDPCBAssemblyP222‐VIVDLED
3ElectronicTransformerP140‐VIELTR
41.8°StepperMotorP110‐VUEMTR
5DisplayPCBP172‐VUEVIDP
6MasterPCBP170-VUEIVMP
7MountingBracket/YokeP110-VUEVIBK
8BracketAdjustmentknobP111-VUEVINB
9IECPowerinputP170-FUSEIEC
10EdisonPoweroutputP170-IECMALE
11MasterChipP177-VUEVIIC(notshown)
Vue™ 6.1 User Manual 18 2008-12-03/14:33

Electrical Connections Diagram
Vue™ 6.1 User Manual 19 2008-12-03/14:33

Vue™ 6.1 User Manual 20 2008-12-03/14:33
Technical Specifications
WEIGHT & DIMENSIONS
Length.............................................................................................................................. 13 in (330 mm)
Width ............................................................................................................................... 13 in (330 mm)
Height.............................................................................................................................. 13 in (330 mm)
Weight ..............................................................................................................................7.1 lbs (3.2 kg)
Light Source
Light Source ........................................................... 252 (108 red, 72 green, 72 blue) LED’s 100,000hrs
PHOTO OPTIC
Coverage Angle................................................................................................................................110°
POWER
Auto-switching power supply.......................................................................... 100V – 240V 50/60Hz AC
Fuse............................................................................................................................................2A 250V
Power Consumption..............................................................................................40W (0.3A) Operating
Inrush Power .......................................................................................................................(0.4A) Inrush
THERMAL
Maximum ambient temperature..........................................................................................104° F (40°C)
CONTROL & PROGRAMMING
Data input................................................................................................locking 3-pin XLR male socket
Data output...........................................................................................locking 3-pin XLR female socket
Data pin configuration ..............................................................................pin 1 shield, pin 2 (-), pin 3 (+)
Protocols........................................................................................................................DMX-512 USITT
DMX Channels .......................................................................................................................................6
ORDERING INFORMATION
Vue™ 6.1..................................................................................................................................... VUE6.1
WARRANTY INFORMATION
Warranty.............................................................................................................. 2-year limited warranty
