Chauvin Arnoux CA 8345 User manual

Three-phase electrical network analyser
EN - User’s manual
CA 8345

2
Thank you for purchasing this CA 8345 (Qualistar 2) three-phase power quality analyser.
For best results from your instrument:
read these operating instructions carefully,
comply with the precautions for use.

Measurement category IV corresponds to measurements taken at the source of low-voltage installations.
Example: power feeders, counters and protection devices.
Measurement category III corresponds to measurements on building installations.

Measurement category II corresponds to measurements taken on circuits directly connected to low-voltage installations.
Example: power supply to electro-domestic devices and portable tools.
WARNING, risk of DANGER! The operator must refer to these instructions whenever this danger symbol
appears.
WARNING, risk of electric shock. The voltage applied to parts marked with this symbol may be hazardous.
USB connector / USB drive.
Kensington anti-theft lock.
Ethernet connector (RJ45).
Earth.
Useful information or tip.
SD card.
Chauvin Arnoux has designed this instrument in the context of a global Eco-Design approach. A life cycle analysis
was carried out to master and optimize the impact of this product on the environment. More precisely, the product
exceeds the requirements of regulations as regards recycling and valuation.
The product is declared recyclable following an analysis of the life cycle in accordance with standard ISO 14040.

in particular as regards Low Voltage Directive 2014/35/EU, Electromagnetic Compatibility Directive 2014/30/EU,
Radio Equipment Directive 2014/53/EU, and Restriction of Hazardous Substances Directives 2011/65/EU and
2015/863/EU.

as regards Low Voltage, Electromagnetic Compatibility, and Restriction of Hazardous Substances.
The rubbish bin with a line through it means that in the European Union, the product must undergo selective disposal
in compliance with Directive WEEE 2012/19/UE.
GND

3
PRECAUTIONS FOR USE
This instrument is compliant with safety standard IEC/EN 61010-2-030 or BS EN 61010-2-030, the leads are compliant with IEC/
EN 61010-031 or BS EN 61010-031, and the current sensors are compliant with IEC/EN 61010-2-032 or BS EN 61010-2-032, for
voltages up to 600V in category IV.

and of the installations.
The operator and/or the responsible authority must carefully read and clearly understand the various precautions to be taken
in use. Sound knowledge and a keen awareness of electrical hazards are essential when using this instrument.

Do not use the instrument on networks of which the voltage or category exceeds those mentioned.
Do not use the instrument if it seems to be damaged, incomplete, or poorly closed.
Do not use the instrument without its battery.
Before each use, check the condition of the insulation on the leads, housing, and accessories.Any item of which the insulation
is deteriorated (even partially) must be set aside for repair or scrapping.
Before using your instrument, check that it is perfectly dry. If it is wet, it must be thoroughly dried before it can be connected
or used.
Use only the leads and accessories supplied. The use of leads (or accessories) of a lower voltage or category limits the voltage
or category of the combined instrument and leads (or accessories) to that of the leads (or accessories).
Use personal protection equipment systematically.
Keep your hands away from the terminals of the instrument.


Some current sensors must not be placed on or removed from bare conductors at hazardous voltages: refer to the data sheet
of the sensor and comply with the handling instructions.
All troubleshooting and metrological checks must be performed by competent and accredited personnel.

4
CONTENTS
1. COMMISSIONING..........................................................5
1.1. Delivery condition..................................................5
1.2. Accessories ...........................................................6
1.3. Spare.....................................................................6
1.4. Charging the battery..............................................7
1.5. Choice of language................................................7
2. DESCRIPTION OF THE INSTRUMENT.......................8
2.1. Functions...............................................................8
2.2. Overall view.........................................................10
2.3. Measurement terminals ......................................10
2.4. Connectors on side .............................................11
2.5. Battery ................................................................11
2.6. Display unit .........................................................12
󰀨 ......................................................12
2.8. Keypad ................................................................13
2.9. Installation of the colour codes............................14
2.10. Memory card......................................................15
2.11. Prop...................................................................16
2.12. Magnetised hook (optional)...............................16
3. CONFIGURATION........................................................17
3.1. Navigation............................................................17
3.2. Users...................................................................17
 ...........................18
 ....................24
4. USERS ..........................................................................39
4.1. Starting up...........................................................39
4.2. Navigation............................................................39
 .......................................................42
4.4. Connections.........................................................42
4.5. Functions of the instrument.................................44
󰀨 ........................................................44
4.7. Safety status of the instrument............................45
5. FORM OF THE SIGNAL..............................................46
.........................................................46
5.2. RMS function.......................................................46
5.3. THD function........................................................48
5.4. CF function..........................................................48
5.5. Min-Max function.................................................48
5.6. Summary function................................................49
5.7. Fresnel function...................................................51
6. HARMONIC...................................................................53
.........................................................54
6.2. Examples of screens...........................................54
7. POWER.........................................................................57
.........................................................57
7.2. Examples of screens...........................................57
8. ENERGY........................................................................59
.........................................................59
8.2. Examples of screens...........................................59
9. TREND MODE..............................................................61
9.1. Start of a recording..............................................61
9.2. List of recordings.................................................62
9.3. Reading a recording............................................62
10. TRANSIENT MODE ...................................................65
10.1. Start of a recording............................................65
10.2. List of recordings...............................................66
10.3. Reading a recording..........................................66
11. INRUSH CURRENT MODE .......................................69
11.1. Start of a capture...............................................69
11.2. List of captures ..................................................70
11.3. Reading a capture .............................................70
12. ALARM MODE............................................................74
12.1. Start of an alarm campaign ...............................74
12.2. List of alarm campaigns.....................................75
12.3. Start of an alarm campaign ...............................76
13. MONITORING MODE.................................................77
13.1. Start of a monitoring campaign..........................77
13.2. List of monitoring campaigns.............................79
13.3. Reading a monitoring campaigns......................80
14. SCREENSHOT...........................................................81
14.1. Screenshot ........................................................81
14.2. Management of screenshots.............................81
15. HELP ..........................................................................83
16. APPLICATION SOFTWARE......................................84
16.1. Obtain the PAT3 software..................................84
17. TECHNICAL CHARACTERISTICS .........................85
17.1. Reference conditions.........................................85
17.2. Electrical characteristics ...................................86
17.3. Memory card......................................................97
17.4. Power supply.....................................................98
17.5. Display unit........................................................99
17.6. Environmental conditions ..................................99
17.7. Mechanical characteristics ................................99
17.8. Compliance with international standards.........100
17.9. Electromagnetic compatibility (EMC)...............102
17.10. Radio emissions............................................102
17.11. GPL code.......................................................102
18. MAINTENANCE .......................................................103
18.1. Cleaning the housing.......................................103
18.2. Maintenance of the sensors ............................103
18.3. Replacement of the battery .............................103
18.4. Memory card....................................................105
 .....................................106
19. WARRANTY..............................................................108
20. APPENDICES...........................................................109
20.1. Notation...........................................................109
20.2. Formulas .........................................................109
20.3. Flicker..............................................................114
20.4. Sources of distribution supported by the
instrument........................................................114
20.5. Hysteresis........................................................114
20.6. Minimum scale values of waveforms and
minimum RMS values .....................................115
20.7. Four-quadrant diagram ...................................116
20.8. Transient capture triggering mechanism .........116
20.9. Conditions of capture in inrush current mode..117
20.10. Glossary ........................................................118
20.11. Abbreviations .................................................121

5
Figure 1
1
25 black straight-straight banana-banana safety leads attached with a Velcro tie.
35 black crocodile clips.
45 cable reels
5One hand strap.
6One USB A-B cord.
7
812 sets of inserts and rings to mark the current leads and sensors according to their phases.
9One carrying bag.
10 One carrying bag for the instrument.
11 One multilingual safety data sheet
12 One test report.
13 One multilingual quick start guide
1. COMMISSIONING
1.1. DELIVERY CONDITION
➀➅
➄
➃
➁➂
➆
➇
➈
➉
11 12
13
x 5
x 5
x 5

6
1.3. SPARE
Li-ion battery, 10.8V, 5800mAh
USB-A USB-B cord

One PA32ER power supply unit per phase
SDHC card, 16 GB
No. 22 carrying case
No. 21 carrying case
Set of 5 black straight-straight banana-banana safety cables, 5 crocodile clips, and
12 inserts and rings to identify the phases, the voltage leads, and the current sensors
Set of inserts and rings to identify the phases, the voltage leads, and the current sensors
Adapter, C8 jack to 2 banana jacks
5 cable reels
For accessories and spares, check out our Web site:
www.chauvin-arnoux.com
L1/AL2/B
L3/C
N/D
1.2. ACCESSORIES
Three-phase 5 A adapter
Essailec®5A three-phase adapter MN93 clamp
MN93A clamp
PAC93 clamp C193 clamp
AmpFlex®A193 450 mm
AmpFlex®A193 800 mm MiniFlex®MA194 250 mm
MiniFlex®MA194 350 mm
MiniFlex®MA194 1000 mm
E3N clamp
E3N/E27 clamp BNC adapter
Mains adapter for E3N clamp
E27 clamp
Charging dock for the battery
Hand strap for the instrument
Data View Software
J93 clamp
Magnetized hook
E3N MINI94 E94 clamp

7
1.4. CHARGING THE BATTERY


remove the battery from the instrument.
Connect the mains cord to the power supply unit and to mains.
Open the elastomer hatch protecting the mains power socket and connect the special 4-point connector of the power supply
unit to the instrument.
The 󰀨
1.5. CHOICE OF LANGUAGE
Before using the instrument, start by choosing the display language.
󰀨

Press the second yellow function key , then , to open the language menu. More than 20 languages are available, choose
yours.


Figure 3
120 V ± 15 %, 60 Hz
230 V ± 15 %, 50 Hz
Figure 2
When the battery is completely dis-
charged, the charging time is approx-
imately 6 hours.

8
2. DESCRIPTION OF THE INSTRUMENT
2.1. FUNCTIONS
The CA 8345 (Qualistar 2) is a portable three-phase power quality analyser with built-in rechargeable battery. It is in compliance
with the standard governing the methods of measurement of power quality, IEC 61000-4-30, class A.
The CA 8345 is used:
to measure the RMS values, powers, and disturbances of power distribution networks.
to take a snapshot of the main characteristics of a three-phase network.
󰀨
The measurement uncertainty of the instrument is better than 0.1% for voltage measurements and 1% for current measurements.
The instrument provides a large choice of current sensors, for measurements from a few milliamperes up to several kiloamperes.
The instrument is compact and impact-resistant.
The ergonomics and simplicity of its user interface make it a pleasure to use. The CA8345 has a large colour touch screen graphic

The SD card can store a large quantity of measurements and photographs, which can be read directly on a PC. It is also possible
to use a USB drive (optional).

The instrument has a remote user interface (VNC) allowing remote control from a PC, a tablet, or a smartphone.
The PAT3 application software processes the recorded data and generates reports.
2.1.1. MEASUREMENT FUNCTIONS
These serve to make the following measurements and calculations:
Measurement of the RMS values of AC voltages up to 1000 V between terminals. Using ratios, the instrument can reach
hundreds of gigavolts.
Measurement of the RMS values of AC currents up to 10,000 A (neutral included). Using ratios, the instrument can reach
hundreds of kiloamperes.
Automatic detection of the type of current sensor and powering of the sensor if necessary.
Measurement of the DC component of voltages and currents (neutral included).
Measurement of RMS voltage and current (without neutral) over minimum and maximum half-cycles.
Calculation of forward, reverse, and zero sequence voltage/ current unbalances.
Measurement of inrush current, application to motor start-up.
Measurement of peak values of voltages and currents (neutral included).
Measurement of the frequency of 50-Hz and 60-Hz networks.
Measurement of the current and voltage crest factors (neutral included).
Calculation of the harmonic loss factor (FHL), application to transformers in the presence of harmonic currents.
Calculation of the K factor (FK), application to transformers in the presence of harmonic currents.

Log of events such as voltage dips, overvoltages, interruptions, transients, rapid voltage changes (RVC), and synchronisation.
Measurementofthetotal harmonic distortion of currentsand ofvoltages (without neutral)referred to the fundamental(THD in%f).
Measurement of the total harmonic distortion of currents and of voltages (neutral included) referred to the AC RMS value
(THD in %r)
Measurement of active, reactive (capacitive and inductive), non-active, distorting, and apparent power, per phase and total
(without neutral).

Measurement of the distorting RMS value (d) for currents and voltages (without neutral).
st) (without neutral).
lt) (without neutral).

9
Measurement of active, reactive (capacitive and inductive), non-active, distorting, and apparent energy, per phase and total
(without neutral).
Valuation of the energy directly in currency (€, $, £, etc.), with a basic rate and 8 special rates.
Measurement of current and voltage harmonics (neutral included) up to order 63: RMS value, percentages referred to
the fundamental (%f) (without neutral) or to the total RMS value (%r), minimum and maximum and harmonic sequence level.
Measurement of apparent harmonic power (without neutral) up to order 63: percentages referred to the fundamental apparent
power (%f) or to the total apparent power (%r), minimum and maximum of the level of one order.
Measurement of current and voltage inter-harmonics (neutral included) up to order 62.
Synchronisation with UTC time, with a choice of time zone.
Monitoring mode, used to check the compliance of the voltages.
Measurement of information signals on the CPL (MSV).
2.1.2. DISPLAY FUNCTIONS
Display of waveforms (voltages and currents).
Bargraphs of voltage and current harmonics.
Screenshots.

Display of recordings: trend, alarm, transients, and inrush current.
2.1.3. MEASUREMENT FUNCTIONS
Trendrecording(datalogging)functionwithtime-stampingandprogrammingofthebeginningandendofarecord.Representation,
in the form of barcharts or curves, of the mean values of many parameters as a function of time, with or without the MIN-MAX.

Transients function. Detection and transient recording (up to 1000 per record) for a chosen duration and on a chosen date
(programming of the beginning and end of the transient recording). Recording of 4 complete cycles (one before the event
triggering the transient and three after) in the 8 acquisition channels.
Possibility of capturing shock waves up to 12kV over a duration of 1ms.


Inrush current function: display of parameters useful for studying motor start-up
Instantaneous value of the current and voltage at the instant designated by the cursor.
Absolute maximum instantaneous current and voltage (over the entire starting event).
RMS current and voltage (without neutral) of the half-cycle (or lobe) on which the cursor is placed.
Maximum half-cycle RMS current and voltage (over the entire starting event).
Instantaneous network frequency at the instant designated by the cursor.
Maximum, mean, and minimum instantaneous network frequency (over the entire starting event).
Time at which motor start-up begins.
2.1.4. CONFIGURATION FUNCTIONS
Setting the date and time
Brightness adjustment.
Choice of colours of the curves.
󰀨
Choice of night mode display.
Choice of language.
󰀩
the calculation of the K factor, choice of reference for levels of harmonics, calculation of PLT (moving window or not).
Choice of distribution system (single-phase, two-phase, three-phase with or without measurement of neutral) and connection
method (standard, 2 elements or 2½ elements).

Erasure of the data (total or partial).
Display of current sensors: detected, not detected, not managed, simulated, or impossible to simulate (2-element connection
method ). Adjustment of voltage and current ratios, transduction ratios, and sensitivity.


10
NL1 L2 L3 NL1 L2 L3
POWER & QUALITY ANALYSER
CA 8345
Class
QUALI ST R
Figure 4
2.3. MEASUREMENT TERMINALS
Measurement terminals
Colour touch screen
Function keys
(yellow keys)

Screenshot key
Help key
󰀨
Connector
for USB drive.
Mode keys
(violet keys)
Validation key
Navigation keys
Return key
2.2. OVERALL VIEW
SD card slot.
1000V CAT IV
L2L1N L3
L2L1N L3
GND
4 current input terminals (for current sensors). 5 voltage input terminals.
Figure 5

11
2.4. CONNECTORS ON SIDE
Strap attachment point.

RJ45 connector for Ethernet connection.
Special 4-point connector for the mains power supply. This is used to charge the battery
or operate the instrument on mains power.
Figure 6
USB type B connector for connection to a PC.
2.5. BATTERY
The instrument can operate either on its own battery or on mains power. It can operate on the battery while the latter is being
recharged. It must never be used without its battery, which contributes to the user’s safety.
Battery charge level check light
Battery fully charged, or a new battery whose level is unknown.
, , , Battery charge level check light
Battery discharged. Charge completely in this case.
Battery charging: one bar blinks.
When the remaining charge of the battery is too low to ensure correct operation of the instrument, a message is displayed.
󰀨

12
2.6. DISPLAY UNIT
The CA 8345 has a large colour touch-screen display unit (WVGA).
Below, a typical screen.
The status bar at the top of the screen reports the status of the instrument.
Screenshot.
Help.
Mode.
To return to
the main screen.
Frequency measured.
Date and time.
Connection.
USB drive.
USB link.
Ethernet link.
Battery charge level.
Display corresponding
to the chosen mode
and function.
Functions that
depend on the mode. Figure 7
2.7. ON/OFF BUTTON
Pressing the button switches the instrument on. The button blinks orange during starting up.
When the battery is charging, the button blinks green. When it is lit steadily, the battery is fully charged.
󰀨
an information message is displayed when it is next switched on.
Pressing the     󰀨          

󰀨󰀨-
ically the next time the instrument is switched on.
󰀨
󰀨 button, you can
󰀨 button pressed for 10 seconds. This may cause a loss of the recordings in progress on the
SD card.

13
2.8. KEYPAD
2.8.1. MODE KEYS (PURPLE KEYS)

Key Function See
Waveform mode 
Harmonic mode 
Power mode 
Energy mode 
Trend mode 
Transient mode 
Inrush current mode 
Alarm mode 
Monitoring mode 
2.8.2. NAVIGATION KEYS
Key Function
4 directional arrows.
Validation key.
Return key.
2.8.3. THE OTHER KEYS
The functions of the other keys on the keypad are as follows:
Key Function See
 
Screenshot. 
Help key. 
2.8.4. THE FUNCTION KEYS (8 YELLOW KEYS)
The functions of the yellow keys change according to the mode and the context.

14
2.9. INSTALLATION OF THE COLOUR CODES
To identify the cords and the input terminals, you can mark them using the coloured markers provided with the instrument.
󰀨
terminal and the small one for the voltage terminal).
Large sectors
for current terminals. Small sectors
for voltage terminals.
Rings the same colour
as the terminal.
Figure 8
Clip a ring of the same colour onto each end of the cord you are going to connect to the terminal.
󰀨

15
NL1 L2 L3 NL1 L2 L3
POWER & QUALITY ANALYSER
Class
QUALI ST R
CA 8345
2.10. MEMORY CARD
The instrument accepts SD (SDSC), SDHC, and SDXC memory cards in FAT16, FAT32 or exFAT format as required.
The instrument is delivered with a formatted SD card. The memory card is essential for recording measurements.
If you want to install a new SD card:
Open the elastomer cap marked SD.
󰀨
Press on the memory card to remove it from its slot.
Slide the new SD card all the way home in its slot. The red indicator lights.
Then close the elastomer cap.
Figure 9
Write-protect the memory card when you remove it from the instrument. Unprotect the write-protected card before inserting
it in the instrument.
SD card present indicator.
LOCK
LOCK
Unprotected memory card. Protected memory card.

16
Figure 10
2.12. MAGNETISED HOOK (OPTIONAL)
The magnetised hook can be used to suspend the instrument from the top of a door or attach it to a metallic surface.
2.11. PROP
There is a retractable prop on the back of the instrument to hold it at an angle of 60°.
Magnet.
Hand strap.

17
3. CONFIGURATION


 ,
 .
Press the key.
Figure 11
3.1. NAVIGATION

are wearing gloves, or you can use the touch screen.
The key is used to validate.
The key is used to abort or to return to the previous screen.
3.2. USERS
󰀨
Select and choose your user number.
Select the user name and change it.
Figure 12
The entry screen lets you enter:
upper-case letters from Ato Z,
lower-case letters from a to z,
digits from 0 to 9,
special characters: . _ - @.
Use to erase the previous character.
Use to erase the selected character and all following characters.



To change users.
User.

18
Figure 13
-
ing, metering energy, recording transients or alarms, or capturing an inrush current.
3.3.1. LANGUAGE
To choose the language of your instrument, select .
Choose your language, then validate using the key.
3.3.2. DATE AND TIME.
To set the date and time, select .
Figure 14
The time can be set automatically
(GPS or NTP) or by hand.
3.3. CONFIGURATION OF THE INSTRUMENT
Choice of time zone.
Figure 15
Choose one of the
73 time zones proposed.

19
Figure 16
The satellite reception status is indicated by an icon in the status bar, with the following meanings:
GPS synchronisation Not synchronised Synchronised
Satellite No satellite
in view At least one satellite in view No satellite in view At least one satellite in view
No recording
Recording in progress
At the end of 40 days without exposure to a GPS satellite, the synchronisation icon ( ) changes over to unsynchronised status
().
3.3.2.2. NTP MODE
If you choose time synchronisation by NTP, enter the address of the NTP server in the NTP server

Status of time synchronisation
by GPS.
Figure 17
Status of time synchronisation
by NTP:
Not synchronised
Synchronised
Synchronised and recording
in progress.
3.3.2.1. GPS MODE
The GPS mode is necessary to guarantee that your instrument is classA (per IEC 61000-4-30). The instrument must be exposed
at least once to the GPS satellites, so that the receiver can recover the date and time. Correct synchronisation may take up to 15
minutes. Accuracy is then maintained, even if the satellites are no longer accessible, in the following situations:
Satellite reception  
No satellite in view ±1s / 24h ± 24ms / 24h
At least one satellite in view ±16.7ms vs UTC, at all times ±60ns / s, corrected at all times
To avoid time discontinuities, automatic setting of the time is blocked when recording is in progress.

20
Figure 18
3.3.3.1. COLOURS OF THE VOLTAGE CURVES
To choose the colours of the voltage curves, select .
Choose one colour for each of the 3 phases and for the neutral. You can choose from among about thirty colours.
In night mode, the white background turns black and the colours are reversed.
3.3.3.2. COLOURS OF THE CURRENT CURVES
To choose the colours of the current curves, select .
Choose one colour for each of the 4 current inputs. You can choose from among about thirty colours.
In night mode, the white background turns black.
3.3.3.3. SCREEN BRIGHTNESS AND AUTO-OFF
󰀨 .
󰀨󰀨
󰀨
To switch the screen back on, press any key.
3.3.4. MEMORY
Select to manage the content of the external memory.
3.3.3. DISPLAY
Select 
Indication of the SD card
occupancy rate.
Figure 19
Indication of the total size
of the SD card.
