KeyFit®Caddy
Owner's Manual
www.chiccousa.com
IS0202E_01 ©2020 Artsana USA, INC. 09/20
Read all instructions BEFORE
assembly and USE of product.
KEEP INSTRUCTIONS FOR
FUTURE USE.

2 3
Using Chicco Infant Car Seat
with stroller:
• ONLY USE this product with a
Chicco infant car seat. Do not use
any other manufacturer's infant car
seat.
• Only use this product to transport
infants that are within the size and
weight limitations of the infant car
seat.
• FALL HAZARD: Always check that
infant car seat is securely attached
to stroller frame by pulling up on
the infant car seat.
• ALWAYS SECURE your child with
the car seat harness. Always make
sure child is properly harnessed in
the car seat.
• Refer to your Chicco infant car
seat owner's manual for additional
warnings and use instructions
before using this product.
• PLEASE SAVE OWNER'S MANUAL
FOR FUTURE USE.
• ADULT ASSEMBLY REQUIRED.
• NEVER LEAVE CHILD
UNATTENDED. Always keep child
in view while in the caddy.
• AVOID SERIOUS INJURY from
falling or sliding out. Always
use the infant car seat harness
and make sure that it is properly
adjusted to provide a secure fit
around your child.
• AVOID FINGER ENTRAPMENT: Use
care when folding and unfolding
the caddy. Be certain the caddy
is fully opened and latched before
allowing your child near the caddy.
• CADDY TO BE USED only at
walking speed. Product not
intended for use while jogging,
skating, etc.
• TO PREVENT TIPPING, do not place
more than 2 lbs (0.9 kg) on the
parent's tray.
• TO AVOID BURNS, never put hot
liquids in the parent's tray.
• TO PREVENT A HAZARDOUS,
UNSTABLE CONDITION, never
place purses, shopping bags,
parcels or accessory items on the
parent tray or handle. Do not place
more than 10 lbs (4.5 kg) in the
storage basket.
• DO NOT use storage basket as a
child carrier.
• NEVER ALLOW YOUR CADDY to be
used as a toy.
• DISCONTINUE USING YOUR
CADDY should it become damaged
or broken.
• AVOID STRANGULATION. DO
NOT place items with a string
around your child's neck, suspend
strings from this product, or attach
strings to toys.
• NEVER USE CADDY ON STAIRS or
escalators. You may suddenly lose
control of the product and your
child may fall out. Also, use extra
care when going up or down a step
or curb.
• Do not attempt to attach any
infant car seat to the stroller other
than a Chicco infant car seat.
Injury or death may result when
attempting to use this stroller in
conjunction with infant car seats
from other manufacturers.
• Before use, remove and dispose
of all plastic bags and packaging
materials and keep them out of
reach of children.
• Before assembly, check that the
product and all of its components
have not been damaged during
transportation.
• Do not use accessories, spare parts,
or any component not supplied or
approved by Chicco as they may
make the stroller unsafe.
Failure to follow all warnings and instructions may result in serious injury or
death. For your child's safety, read the labels and owner's manual before using the
product.
Failure to follow all warnings and instructions may result in serious injury or
death. For your child's safety, read the labels and owner's manual before using the
product.
WARNING WARNING

4 5
A. - Caddy Frame
B. - Front Swivel Wheels
C. - Rear Axle Assembly
D. - Bumper Bar
A.
B.
C.
D.
E. - ParentTray
F. - Basket Brace
E.
F.
Parts List Parts List

6 7
1. Insert Basket Brace (F) through Basket
Brace sleeve and snap securely onto rear
frame tube.
2. Attach Rear Axle Assembly (C) to the
Caddy Frame as shown. The assembly
will click into place. Pull on each Wheel
to make sure the axle assembly is
securely attached to the frame.
“SNAP!”
1
How To Attach Basket Brace
2
Attach Rear Wheels
*
*
Note: Basket Brace
flat end is to the top.

8 9
3A. Locate the Storage Basket frame
(painted metal bar) on the Caddy Frame
(A) and flip it open as shown.
3A3B
3B. Locate the Storage Basket Brace. Flip
the Brace over and snap it into position,
attaching it onto the Basket frame.
“CLICK!”
How to Attach Basket Brace How to Attach Basket Brace

10 11
3C
3C. Locate the Caddy Handle. Pull up on
the Caddy Handle to lock it into the first
position.
4. Using the Caddy Handle, stand the
Caddy up so that it is resting on the
Caddy Basket frame.
4
How to Open Caddy How to Open Caddy

12 13
5B
5A
5A. With the Caddy in an upright
position, rotate the Release Handle
towards the Caddy Handle. Push on the
Release Handle (5B) until you hear an
audible click.
Note: It is necessary for this Release
Handle to be locked into this position for
the Caddy to open and close properly -
Once this handle is locked into this
position it is not intended to be unlocked.
“CLICK!”
How to Open Caddy
6. Locate the tabs on both ends of the
ParentTray (E) and slide the tabs through
the channels on the inside of the Caddy
handle. The tabs and grooves must be
lined up. Then slide the ParentTray into
place. You will hear an audible click on
both sides when the ParentTray is secured
to the Caddy handles. Pull up on each
side of the ParentTray to make sure the
tray is securely attached.
“CLICK!”
“CLICK!”
6
Assemble Parent Tray
WARNING
To prevent tipping, do not place more than 2 lbs (0.9 kg) in the parent's tray. Never put
hot liquids in the cup holders. Never place purses, shopping bags, parcels or accessory
items on the handle.

14 15
8. Attach Bumper Bar (D) to the frame
as shown. You will hear an audible click
when Bumper Bar is in place. Gently lift
up on both sides of Bumper Bar to make
sure it is secure.
Note: Once the Bumper Bar is installed it
is not intended to be removed.
8
“CLICK!”
“CLICK!”
Attach Bumper Bar
7A. Stand behind the Caddy. Place one
hand on the Caddy Handle and one hand
on the Release Handle. Lean the Caddy
forward and pull up on the Release
Handle to open the Caddy. You will
hear an audible click on both sides when
Caddy is completely open and locked
(7B).
“CLICK!”
“CLICK!”
7A
7B
How to Open Caddy

16 17
10A. Pull both sides of Storage Basket
fabric up and wrap it around the Basket
frame.
10A
Snap button
Assemble Storage Basket
9. Attach Front Swivel Wheels (B) to the
Caddy frame as shown. The Wheels will
click into place. Pull down on each Wheel
to make sure the Wheel assembly is
securely attached to the frame.
“CLICK!”
“CLICK!”
9
Attach Front Swivel Wheels

18 19
11. To access the Storage Basket from the
front, unzip both zippers located on each
side of the front of the Basket.
11
Storage Basket Access
6X
10B. Snap the 6 buttons into place as
shown.
10B
“CLICK!”
Assemble Storage Basket

20 21
13
13. The Caddy Handle height can be
adjusted for comfort. To adjust the
Caddy Handle position, push in on
both buttons (as shown) and rotate the
Caddy Handle up or down. Make sure
the Caddy Handle is securely latched
before using.
“CLICK!”
“CLICK!”
Adjust Caddy Handle
12. Extend the storage capacity of the
Basket from the rear. Locate the edge of
the extension flap, which is tucked inside
the rear Basket edge. Flip the extension
flap up.
12
Storage Basket Access

22 23
How to Attach Chicco Infant Car Seat
WARNING
ONLY use this product with a Chicco infant car seat. Use of this product with other
manufacturer's infant car seats may result in injury or death. Only use this product to
transport infants that are within the size and weight limitations of the infant car seat.
Refer to your Chicco infant car seat owner's manual for additional warnings and use
instructions before using this product. Always secure your child with the harness when
using the infant car seat with this product.
14. To lock the rear wheel brakes, push
down on the brake lock levers located
on each side of the rear wheel assembly
(14A). To unlock pull up (14B). Always
apply both brakes.
14B
14A
How to Use Brakes
WARNING
Always apply both brakes whenever the caddy is stationary. Never leave the caddy on
a sloped surface, with a child on board, even with the brakes applied.

24 25
16. To remove the infant car seat, squeeze
the Release Handle on the back of the
infant car seat and lift up on the carrying
handle.
16
How to Remove Chicco Infant Car Seat
15A15. Place the Chicco infant car seat into
the caddy frame (15A). The infant car
seat will click into the attachment points
(15B).
Note: Pull up on the infant car seat to
make sure it is securely attached to the
Caddy frame (15C).
“CLICK!”
2X
15B
How to Attach Chicco Infant Car Seat
15C
1
CLICK! CHECK!
2

26 27
17B. While pulling up on the Release
Handle, push down on the Storage Basket
with your foot. The Caddy will
automatically fold, latch and stand on its
own. To make the Caddy more compact,
fold the Caddy Handle by pushing in on
both buttons (as shown) and rotating the
Caddy Handle down into the storage
position (17C).
17B
17C
How to Fold Caddy
17A. To fold Caddy: Make sure to remove
the infant car seat. Lift the Release
Handle on the parent tray.
17A
How to Fold Caddy
WARNING
When folding the caddy, make sure that your child and other children are at a safe
distance. Ensure that during the operations, the movable parts of the caddy do not
come in contact with your child.

2928
For USA customers :
If you have any questions or comments about this product, or are missing any of the
parts. Please do not return this product to the store. Contact us in one of the
following ways:
@
(877)-424-4226
[email protected]
1826 William Penn Way
Lancaster, PA 17601
www.chiccousa.com
For More Information
This product requires regular maintenance. The cleaning and maintenance of the caddy must
only be carried out by an adult.
CLEANING
Please refer to the care label for instructions on cleaning the fabric parts of the caddy.
Periodically wipe clean plastic parts with a soft damp cloth. Always dry the metal parts to
prevent the formation of rust if the caddy has come into contact with water.
MAINTENANCE
Lubricate the moving parts only if necessary, with
a light application of a silicone based lubricant. If
wheel squeaks, use a light oil (e.g., WD-40, 3-in-1,
or sewing machine oil). It is important to get the
oil in the axle and wheel assembly as illustrated.
Periodically check the caddy for loose screws,
worn parts, torn material or stitching. Replace or
repair the parts as needed. Use only Chicco replacement parts. To avoid
friction that may prevent the correct operation of the caddy, ensure that all the movable
plastic parts placed along the metal frame are clean of dust, dirt or sand. Keep the caddy in a
dry place. If caddy becomes wet open and allow caddy to dry completely. Prolonged
exposure to direct sunlight may cause the fabric to fade and plastic parts to warp.
Cleaning and Maintenance
