Christie CoreIII Series Assembly instructions

Product Name
1
020-001930-01 Rev. 1 (01-2024)
LED Display System
Christie CoreIII Series
Installation and Setup Guide
020-002147-01

NOTICES
COPYRIGHT AND TRADEMARKS
Copyright © 2024 Christie Digital Systems USA, Inc. All rights reserved.
All brand names and product names are trademarks, registered trademarks or trade names of their respective holders.
GENERAL
Every effort has been made to ensure accuracy, however in some cases changes in the products or availability could occur which may not be reflected
in this document. Christie reserves the right to make changes to specifications at any time without notice. Performance specifications are typical, but
may vary depending on conditions beyond Christie's control such as maintenance of the product in proper working conditions. Performance
specifications are based on information available at the time of printing. Christie makes no warranty of any kind with regard to this material, including,
but not limited to, implied warranties of fitness for a particular purpose. Christie will not be liable for errors contained herein or for incidental or
consequential damages in connection with the performance or use of this material. Our centers of excellence for manufacturing in Kitchener, Ontario,
Canada and in Shenzhen, China are ISO 9001:2015 Quality Management System-certified.
Christie is committed to making our documents free from language bias; however, we are not responsible for the language used on any linked or third-
party documentation.
For the most current technical documentation and office contact information, visit HYPERLINK "https://www.christiedigital.com/"www.christiedigital.com.
WARRANTY
Products are warranted under Christie’s standard limited warranty, the details of which are available at https://www.christiedigital.com/help-
center/warranties/ or by contacting your Christie dealer or Christie.
PREVENTATIVE MAINTENANCE
Preventative maintenance is an important part of the continued and proper operation of your product. Failure to perform maintenance as required, and
in accordance with the maintenance schedule specified by Christie, voids the warranty for preventative maintenance schedules, refer to HYPERLINK
"https://www.christiedigital.com/"www.christiedigital.com.
REGULATORY (if applicable)
The product has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference when the product is operated in a commercial environment. The product
generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful
interference to radio communications. Operation of the product in a residential area is likely to cause harmful interference in which case the user will be
required to correct the interference at the user’s own expense.
CAN ICES-3 (A) / NMB-3 (A)
이 기기는 업무용(A급)으로 전자파적합등록을 한 기기이오니 판매자 또는 사용자는 이점을 주의하시기 바라며, 가정 외의 지역에서 사용하는 것을
목적으로 합니다.
ENVIRONMENTAL
The product is designed and manufactured with high-quality materials and components that can be recycled and reused. This symbol means that
electrical and electronic equipment, at their end-of-life, should be disposed of separately from regular waste. Please dispose of the product
appropriately and according to local regulations. In the European Union, there are separate collection systems for used electrical and electronic
products.
If printing this document, consider printing only the pages you need and select the double-sided option.
Please help us to conserve the environment we live in!
NOTATION
Learn the hazard and information symbols used in the product documentation.
Danger! If not avoided, the following could result in death or serious injury.
Warning! If not avoided, the following could result in death or serious injury.
Caution! If not avoided, the following could result in minor or moderate injury.
Notice. If not avoided, the following could result in property damage.

020-002147-01 Rev. 1 (01-2024)
Copyright ©2024 Christie Digital Systems USA, Inc. All rights reserved.
If printed, please recycle this document after use.
Velvet LED Display System Installation and Setup Guide–Christie CoreIII Series 3
Content
Important safeguards................................................................................................................. 5
General safety precautions....................................................................................................... 5
Power precautions .................................................................................................................. 6
Terminology .............................................................................................................................. 6
Product documentation............................................................................................................... 7
Related documentation............................................................................................................ 7
Required tools ........................................................................................................................... 7
Typical LED solution ................................................................................................................... 8
Cable and controller layout and design.......................................................................................... 9
Controller limitations .................................................................................................................. 9
E510 controller interface and ports..............................................................................................10
E600 controller interface and ports..............................................................................................14
FE600 controller extender interface and ports...............................................................................17
Installing the mounting poles......................................................................................................20
Mounting the tiles .....................................................................................................................25
Connecting the data source cables ..............................................................................................26
Connecting the power cables ......................................................................................................27
Installing the LED modules.........................................................................................................28
Powering on the array ...............................................................................................................30
Powering off the array............................................................................................................30
Connecting to video sources.......................................................................................................30
Installing the Christie controller software .....................................................................................31
Logging into the controller software.............................................................................................31
Setting the output mode ............................................................................................................31
Adjusting the initial picture coordinates........................................................................................31
Testing the communication between the controller and tiles ...........................................................32
Reviewing the tile configuration ..................................................................................................32
Setting the input resolution ........................................................................................................33
Locking and unlocking the controller............................................................................................33

Content
020-002147-01 Rev. 1 (01-2024)
Copyright ©2024 Christie Digital Systems USA, Inc. All rights reserved.
If printed, please recycle this document after use.
Velvet LED Display System Installation and Setup Guide–Christie CoreIII Series 4
Upgrading the firmware on the E510 controller .............................................................................33
Installing/Accessing the E600 controller software..........................................................................35
Logging into the controller software.............................................................................................35
Adjusting the initial picture coordinates........................................................................................35
Testing the communication between the controller and tiles ...........................................................36
Reviewing the tile configuration ..................................................................................................36
Setting the input resolution ........................................................................................................36
Locking and unlocking the controller............................................................................................37
Upgrading the firmware on the E600 controller .............................................................................37
Cleaning the LED panels.............................................................................................................39
Taking out of an LED Module ......................................................................................................39
Safety......................................................................................................................................41
Electro-magnetic compatibility....................................................................................................41
Emissions .............................................................................................................................41
Immunity .............................................................................................................................41

Velvet LED Display System Installation and Setup Guide–CoreIII Series
020-002147-01Rev. 1 (01-2024)
Copyright ©2024Christie Digital Systems USA, Inc. All rights reserved.
If printed, please recycle this document after use.
5
Product overview
Christie® CoreIII have been fully upgraded on the previous basis. Featuring UHD resolution, high fill-factor,
and advanced monitoring capabilities, the CoreIII is a certified LED display wall solution providing 24/7
operation for critical viewing environments. With front-access serviceability, remote, and redundant power
supply and a slim ADA-compliant design, the CoreIII delivers performance possible for LED displays.
Important safeguards
To prevent personal injury and to protect the device from damage, read and follow these safety precautions.
General safety precautions
To prevent personal injury and to protect the device from damage, read and follow these safety precautions.
Warning! If not avoided, the following could result in death or serious injury.
•Observe all electrostatic precautions. Use a grounded wrist strap and insulated tools when handling,
servicing, or cleaning electronic assemblies.
•A certified electrician must be present during installation to ensure the installation meets the local
electrical code.
•Motors and fans may start without warning.
SIDE VIEW
TOP VIEW
REAR VIEW

Product overview
Velvet LED Display System Installation and Setup Guide–CoreIII Series
020-002147-01Rev. 1 (01-2024)
Copyright ©2024Christie Digital Systems USA, Inc. All rights reserved.
If printed, please recycle this document after use.
6
Notice. If not avoided, the following could result in property damage.
•Always wear clean, lint-free gloves when handling the product.
Power precautions
Ensure all power precautions are understood before installing the product.
Warning! If not avoided, the following could result in death or serious injury.
•After the replacement of the power supply, hi-pot and ground/earth bond tests must be performed. Only
Christie qualified technicians who are familiar with the necessary precautions can perform these tests.
•A certified electrician must be present during installation to ensure the installation meets the local
electrical code.
•Always connect the ground or earth first to reduce shock hazard.
•Do not return the current through the ground or earth.
•SHOCK HAZARD! The line cord has a maximum power carrying capability. For the maximum number of
tiles that may be connected per daisy chain when connecting to the power supply, refer to the product
specifications.
•SHOCK HAZARD! A permanent single-phase connection must be installed between the LED tile system
and the AC power supply.
•FIRE AND SHOCK HAZARD! Do not operate the system unless certified power connections, providing the
recommended voltage, are used.
•HIGH TOUCH CURRENT HAZARD! To ensure reliable grounding, the power connection must be made by
using an industrial plug (pluggable type B), or be provided by a permanent connection.
•A 13-20 A double pole mains circuit breaker, certified for the applicable local regulations, is required. It
must be part of the building installation and easily accessible.
•Do not use a wall breaker greater than 20 A. This could result in severe damage to the tile system in the
event of a failure.
Caution! If not avoided, the following could result in minor or moderate injury.
•SHOCK HAZARD! The line cord has a maximum power carrying capability. For the maximum number of
tiles that may be connected per daisy chain when connecting to the power supply, refer to the product
specifications.
•SHOCK HAZARD! Only use the AC power cord provided with the product or recommended by Christie.
•TRIP OR FIRE HAZARD! Position all cables where they cannot contact hot surfaces, be pulled, be tripped
over, or damaged by persons walking on or objects rolling over the cables.
•FIRE HAZARD! Do not use a power cord, harness, or cable that appears damaged.
•FIRE OR SHOCK HAZARD! Do not overload power outlets and extension cords.
•Only Christie qualified technicians are permitted to open product enclosures.
Terminology
Learn about the components of the LED display system.
Term
Definition
Tile
A cabinet that contains several LED modules.

Product overview
Velvet LED Display System Installation and Setup Guide–CoreIII Series
020-002147-01Rev. 1 (01-2024)
Copyright ©2024Christie Digital Systems USA, Inc. All rights reserved.
If printed, please recycle this document after use.
7
Array
A group of connected tiles that from a larger display.
Controller
Controls the LED display system array and video input source. Sometimes referred to as the control
unit.
Pixel
A group of one red, one green, and one blue dot.
Subpixel
A pixel is comprised of three subpixels, one for each color: red, green, and blue. Each subpixel in LED
display technology is and LED chip.
Pixel pitch
Specified the distance from the center of one pixel to the center of the next pixel.
SMD package size
A technical supplier specification related to the pixel size, and denotes the size of the surface-mounted
diode (SMD) itself.
Fill factor
Indicates the ratio between the area covered by pixels and the area not covered by pixels.
Product documentation
For installation, setup, and user information, see the product documentation available on the Christie
Digital Systems USA Inc. website. Read all instructions before using or servicing this product.
1. Access the documentation from the Christie website:
•Go to this URL: http://bit.ly/2qXBAdX or
https://www.christiedigital.com/en-us/digital-signage/products/led-tiles/coreplus-series.
•Scan the QR code using a QR code reader app on a smartphone or tablet.
2. On the product page, select the model and switch to the Download tab.
Related documentation
Additional information on the Core LED Display System is available in the following documents.
•E600 User Guide (P/N: 020-102717- XX)
•E510 User Guide (P/N: 020-102222- XX)
Required tools
Make sure the following tools are available during the installation.
•Rubber hammer
•Utility knife

Product overview
Velvet LED Display System Installation and Setup Guide–CoreIII Series
020-002147-01Rev. 1 (01-2024)
Copyright ©2024Christie Digital Systems USA, Inc. All rights reserved.
If printed, please recycle this document after use.
8
•Allen key
•Spirit level
•Tape measure
•Anti-static glove
•socket wrench
•Torque driver
•Torque wrench
•Philips screwdriver, with magnetic tip
•Slotted screwdriver, with magnetic tip
•LED module removal tool for CoreIII (P/N: 003-007099-XX)
•Attachment Block Template for CoreIII (P/N: 003-007100-XX)
Typical LED solution
A
Media sources
B
E600/E510 LED display controller
C
Receiving card A8s-N
D
LED display

Product overview
Velvet LED Display System Installation and Setup Guide–CoreIII Series
020-002147-01Rev. 1 (01-2024)
Copyright ©2024Christie Digital Systems USA, Inc. All rights reserved.
If printed, please recycle this document after use.
9
Cable and controller layout and design
Before an array is constructed, you must plan the design layout of the tiles to make sure the controller
placement and the cabling layout support the overall tile design objectives.
The LED display system offers flexibility in terms of the number of media sources displayed and the overall
resolution. Color and brightness matching, as well as other functions, can be performed across an entire
array.
The video source connections between the cabinets are represented by the blue line. The power connections
between the cabinets are represented by the red line.
Controller limitations
Each controller can support a maximum number of tiles, which varies depending on the pixel pitch of the tiles
in the array. The configuration to achieve an HD display differs by the pixel pitch of the tile, as outlined in the
table below.

Product overview
Velvet LED Display System Installation and Setup Guide–CoreIII Series
020-002147-01Rev. 1 (01-2024)
Copyright ©2024Christie Digital Systems USA, Inc. All rights reserved.
If printed, please recycle this document after use.
10
E510 controller
Tile
Pixel pitch
1080p array
size
4K array size
8K array size
Maximum
number of tiles
per controller
LED009
0.9 mm
3x3
6x6
12x12
9
LED012
1.25 mm
4x4
8x8
16x16
16
LED015
1.5625 mm
5x5
10x10
20x20
25
LED018
1.875 mm
6x6
12x12
24x24
36
LED025
2.5 mm
8x8
16x16
32x32
64
E600 controller
Tile
Pixel pitch
1080p array
size
4K array size
8K array size
Maximum
number of tiles
per controller
LED009
0.9 mm
3x3
6x6
12x12
36
LED012
1.25 mm
4x4
8x8
16x16
64
LED015
1.5625 mm
5x5
10x10
20x20
100
LED018
1.875 mm
6x6
12x12
24x24
144
LED025
2.5 mm
8x8
16x16
32x32
256
E510 controller interface and ports
Learn about the interface and physical ports on the E510 controller.
Front
1
Operating indicator
•Green: The device is running normally.
•Red: The device is in standby mode.

Product overview
Velvet LED Display System Installation and Setup Guide–CoreIII Series
020-002147-01Rev. 1 (01-2024)
Copyright ©2024Christie Digital Systems USA, Inc. All rights reserved.
If printed, please recycle this document after use.
11
2
Power switch
3
OLED operation screen
4
Function knob
5
BACK button—Select to return to the previous menu.
6
INPUT button—Select to choose a video source.
7
USB port—Updates firmware
Rear
Inputs/Outputs
Description
Inputs
DVI IN
•Single-link DVI connector
•Custom resolutions supported:
Maximum width: 3840 pixels
Maximum height: 2560 pixels
•Supported standard resolutions:
1024×768@(24/30/48/50/60/72/75/85/100/120) Hz
1280×1024@(24/30/48/50/60/72/75/85) Hz
1366×768@(24/30/48/50/60/72/75/85/100) Hz
1440×900@(24/30/48/50/60/72/75/85) Hz
1600×1200@(24/30/48/50/60) Hz
1920×1080@(24/30/48/50/60) Hz
1920×1200@(24/30/48/50/60) Hz
2560×960@(24/30/48/50) Hz
2560×1600@(24/30) Hz

Product overview
Velvet LED Display System Installation and Setup Guide–CoreIII Series
020-002147-01Rev. 1 (01-2024)
Copyright ©2024Christie Digital Systems USA, Inc. All rights reserved.
If printed, please recycle this document after use.
12
HDMI IN
•HDMI 1.4a compliant
•HDCP 1.4 compliant
•Custom resolutions supported:
Maximum width: 3840 pixels
Maximum height: 2560 pixels
•Supported standard resolutions:
1024×768@(24/30/48/50/60/72/75/85/100/120) Hz
1280×1024@(24/30/48/50/60/72/75/85) Hz
1366×768@(24/30/48/50/60/72/75/85/100) Hz
1440×900@(24/30/48/50/60/72/75/85) Hz
1600×1200@(24/30/48/50/60) Hz
1920×1080@(24/30/48/50/60) Hz
1920×1200@(24/30/48/50/60) Hz
2560×960@(24/30/48/50) Hz
2560×1600@(24/30) Hz
3G-SDI IN
•SMPTE ST 425-1 Level A and B, SMPTE ST 274, ST 296, ST 295 compliant
•Maximum supported input resolution: 1920×1080@60 Hz
Note: 3G-SDI input sources do not support input resolution and color depth settings.
Outputs
RJ45 × 6
•6 Gigabit Ethernet ports
•Maximum loading capacity of a single Ethernet port:
For 8-bit input sources: 650,000 pixels
For 10-bit/12-bit input sources: 320,000 pixels
•Support redundancy between Ethernet ports.
OPT1
OPT2
•10G optical ports
Single-mode twin-core fiber: Support LC optical connectors; wavelength: 1310 nm;
transmission distance: 10 km; OS1/OS2 recommended
Dual-mode twin-core fiber: Support LC optical connectors; wavelength: 850 nm;
transmission distance: 300 m; OM3/OM4 recommended

Product overview
Velvet LED Display System Installation and Setup Guide–CoreIII Series
020-002147-01Rev. 1 (01-2024)
Copyright ©2024Christie Digital Systems USA, Inc. All rights reserved.
If printed, please recycle this document after use.
13
•The maximum loading capacity of a single optical port equals to that of all the six Ethernet
ports.
•Two OPT inputs/outputs:
The OPT1 works as the primary input or output port, and the six Gigabit Ethernet ports.
The OPT2 works as the backup input or output port of OPT1.
•In the sending card mode, both OPT ports and 6 Gigabit Ethernet ports can work as output
ports to output the same image.
•In the fiber converter mode, when the OPT ports work as the input ports, the 6 Gigabit
Ethernet ports work as output ports. When the 6 Gigabit Ethernet ports work as input
ports, the OPT ports work as output ports.
DVI LOOP
DVI loop output
HDMI LOOP
HDMI loop output
Support HDCP 1.3 loop output encryption.
3G-SDI LOOP
SDI loop output
MONITOR
HDMI
Connect to a monitor to monitor the inputs. The output resolution of this connector is
1920×1080@60 Hz (fixed output with a width of 1920 pixels and height of 1080 pixels).
If the input resolution exceeds the monitor resolution, the input is automatically scaled in
proportion and then displayed on the monitor starting from its top left.
Control
GENLOCK IN
GENLOCK input connector
•Genlock type: Blackburst
•Input Genlock sync signal to ensure synchronization and same refresh rate between the
output signals of cascaded E510 units and the external Genlock input signal.
GENLOCK LOOP
Genlock loop output connector. Up to eight E510 units can be cascaded.
ETHERNET
Fast Ethernet port, which connects to PC and supports TCP/IP
USB IN
Input port for cascading devices, or connecting to PC
USB OUT
Output port for cascading devices. Up to eight E510 units can be cascaded.
Power supply
100 V–240 VAC
Power switch
ON/OFF

Product overview
Velvet LED Display System Installation and Setup Guide–CoreIII Series
020-002147-01Rev. 1 (01-2024)
Copyright ©2024Christie Digital Systems USA, Inc. All rights reserved.
If printed, please recycle this document after use.
14
E600 controller interface and ports
Learn about the interface and physical ports on the E600 controller.
The E600 controller behaves as two independent controllers, displaying 3840x2160 pixels at 30 Hz
with each virtual controller. The images of both DVI1 and DVI2 input sources can be displayed on the
tiles simultaneously, but the inputs must be configured independently.
DVI1 corresponds to Ethernet ports 1 to 8, and DVI2 corresponds to Ethernet ports 9 to 16.
Front
A
Power button
B
USB interface for communication with a UDISK
C
LCD screen
D
Menu dial for interacting with the menu
E
Menu dial for interacting with the menu
F
Back button for exiting from the current operation or option in the menu

Product overview
Velvet LED Display System Installation and Setup Guide–CoreIII Series
020-002147-01Rev. 1 (01-2024)
Copyright ©2024Christie Digital Systems USA, Inc. All rights reserved.
If printed, please recycle this document after use.
15
Rear
Inputs/outputs
Description
A
Outputs
BNC (Quantity 16)
16-channel Gigabit Ethernet interface, with each channel
supporting up to 1G bandwidth
Total loading capacity: 8.8 million pixels
Low latency is not supported
B
Control
Ethernet
USB, RJ45 (with SNMP support), and USB cascading
C
USB Out
D
USB In
E
Genlock
BNC (Quantity 2)
Support Genlock IN & LOOP
F
Inputs
DisplayPort
Standard DisplayPort 1.2 input
The maximum user-definable resolution is 7680x1080 @
60Hz or 1080x6000 @ 60 Hz.
G
HDMI
Standard HDMI 2.0 input
Supports 8-bit, 10-bit, and 12-bit; refer to the table
below.
H
DVI (Quantity 2)
Dual-link DVI, user-definable resolution
•Horizontal resolution maximum: 3840 pixels
•Vertical resolution maximum 3840 pixels
I
OPT Output
Fiber optic ports for connecting to the FE600 fiber optic
extender
J
Power
Power supply port: AC 100-240V~ 50/60hz
K
Power switch

Product overview
Velvet LED Display System Installation and Setup Guide–CoreIII Series
020-002147-01Rev. 1 (01-2024)
Copyright ©2024Christie Digital Systems USA, Inc. All rights reserved.
If printed, please recycle this document after use.
16
HDMI 8 bit, 10 bit, and 12 bit support
Color depth
Input source
3840x2160 @
60 Hz (HDCP)
3840x1080 @
60 Hz (HDCP)
1920x1080 @
60 Hz (HDCP)
8-bit
RGB444
Yes
Yes
Yes
Y'C'BC'R444
Yes
Yes
Yes
Y'C'BC'R422
Yes
Yes
Yes
Y'C'BC'R420
Yes
Yes
Yes
10-bit
RGB444
Yes
Yes
Yes
Y'C'BC'R444
Yes
Yes
Yes
Y'C'BC'R422
Yes
Yes
Yes
Y'C'BC'R420
Yes
Yes
Yes
12-bit
RGB444
Yes
Yes
Yes
Y'C'BC'R444
Yes
Yes
Yes
Y'C'BC'R422
Yes
Yes
Yes
Y'C'BC'R420
Yes
Yes
Yes

Product overview
Velvet LED Display System Installation and Setup Guide–CoreIII Series
020-002147-01Rev. 1 (01-2024)
Copyright ©2024Christie Digital Systems USA, Inc. All rights reserved.
If printed, please recycle this document after use.
17
FE600 controller extender interface and ports
Learn about the interface and physical ports on the E600 controller.
Front
A
Status display
Rear
Inputs/Outputs
Description
A
Outputs
BNC (Quantity 16)
16-channel Gigabit Ethernet interface, with each channel
supporting up to 1G bandwidth
Total loading capacity: 8.8 million pixels
Low latency is not supported
B
Control
Ethernet
USB, RJ45 (with SNMP support), and USB cascading
C
USB In
D
OPT Output (Quantity 4)
Fiber optic ports for connecting to the E600 controller

Product overview
Velvet LED Display System Installation and Setup Guide–CoreIII Series
020-002147-01Rev. 1 (01-2024)
Copyright ©2024Christie Digital Systems USA, Inc. All rights reserved.
If printed, please recycle this document after use.
18
•OPT1 is used for transferring the data of port 1 to 8
•OPT2 is used for transferring the data of port 9 to 16
•OPT3 is the backup channel of OPT1
•OPT4 is the backup channel of OPT2
Either Gigabit Ethernet port or optical fiber port can be used at
the same time, but cannot be used to connect devices
simultaneously.
E
Power
Power supply port: AC 100-240V~ 50/60hz
F
Power switch
G
Power supply port: AC 100-240V~ 50/60hz

Velvet LED Display System Installation and Setup Guide–CoreIII Series
020-002147-01Rev. 1 (01-2024)
Copyright ©2024Christie Digital Systems USA, Inc. All rights reserved.
If printed, please recycle this document after use.
19
Installation and setup
The configuration of an array depends on the installation. Use the following instructions as a guideline only.
Before you install an LED array, fully understand all site requirements and characteristics.
Installing an LED array from the front
Perform the following steps when you install an LED array while facing the LED modules.
Chassis (A)
4 x LED modules (B)
8 x LED modules (B)
Chassis (A)

Installation and setup
Velvet LED Display System Installation and Setup Guide–CoreIII Series
020-002147-01Rev. 1 (01-2024)
Copyright ©2024Christie Digital Systems USA, Inc. All rights reserved.
If printed, please recycle this document after use.
20
1. Install the mounting poles (on page 20).
2. Mount the tiles (A) (on page 25).
3. Connect the data cables (on page 26).
4. Connect the power cables between tiles (on page 27).
5. Install the LED modules (B) (on page 28).
6. Power on the array (on page 30).
7. Install the E510 controller software (on page 31) or install the E600 controller software (on page 35).
8. Configure the E510 controller (on page 31) or configure the E600 controller (on page 35).
The controller can be configured at any time. Before connecting the controller to the wall, Christie
recommends updating the firmware and configuring the controller.
Installing the mounting poles
If the tiles are being installed onto a flat wall surface, determine where the mounting pads should be
installed, and attach them to the support structure.
Warning! If not avoided, the following could result in death or serious injury.
•External support for a display wall must be designed and implemented by a Christie qualified installer
and must comply with local area regulations and safety standards.
•All display walls must have permanent external supports. The amount of external support required
depends on the size of the display wall.
•A minimum of two people or appropriately rated lift equipment is required to safely lift, install, or move
the product.
The mounting blocks are available in five different configurations:
For 3x3 array
