Cisco DPC2202 User manual

Cisco Model DPC2202 and EPC2202
VoIP Cable Modem
User Guide
In This Document
IMPORTANT SAFETY INSTRUCTIONS ...............................................................2
Introduction...............................................................................................................10
What's In the Carton?............................................................................................... 12
Front Panel Description ...........................................................................................13
Back Panel Description ............................................................................................14
What Are the System Requirements for Internet Service?..................................15
How Do I Subscribe to High-Speed Internet and Telephone Service? .............16
Where Is the Best Location for My Cable Modem?..............................................18
How Do I Mount the Modem on a Wall? (Optional)...........................................19
What Are the Requirements for Telephone Service?...........................................21
How Do I Connect the Cable Modem for Internet and Telephone Service?....22
Installing USB Drivers..............................................................................................25
Frequently Asked Questions...................................................................................27
Having Difficulty? ....................................................................................................30
Tips for Improved Performance .............................................................................31
Front Panel LED Status Indicator Functions.........................................................32
Notices........................................................................................................................34

2 4028518 Rev B
IMPORTANT SAFETY INSTRUCTIONS
IMPORTANT SAFETY INSTRUCTIONS
Notice to Installers
The servicing instructions in this notice are for use by qualified service personnel only. To reduce the
risk of electric shock, do not perform any servicing other than that contained in the operating
instructions, unless you are qualified to do so.
Notice à l’attention des installateurs de réseaux câblés
Les instructions relatives aux interventions d’entretien, fournies dans la présente notice, s’adressent
exclusivement au personnel technique qualifié. Pour réduire les risques de chocs électriques, n’effectuer
aucune intervention autre que celles décrites dans le mode d'emploi et les instructions relatives au
fonctionnement, à moins que vous ne soyez qualifié pour ce faire.

4028518 Rev B 3
IMPORTANT SAFETY INSTRUCTIONS
Mitteilung für CATV-Techniker
Die in dieser Mitteilung aufgeführten Wartungsanweisungen sind ausschließlich für qualifiziertes
Fachpersonal bestimmt. Um die Gefahr eines elektrischen Schlags zu reduzieren, sollten Sie keine
Wartungsarbeiten durchführen, die nicht ausdrücklich in der Bedienungsanleitung aufgeführt sind,
außer Sie sind zur Durchführung solcher Arbeiten qualifiziert.
Aviso a los instaladores de sistemas CATV
Las instrucciones de reparación contenidas en el presente aviso son para uso exclusivo por parte de
personal de mantenimiento cualificado. Con el fin de reducir el riesgo de descarga eléctrica, no realice
ninguna otra operación de reparación distinta a las contenidas en las instrucciones de funcionamiento, a
menos que posea la cualificación necesaria para hacerlo.
20080814_Installer820_Intl

4 4028518 Rev B
IMPORTANT SAFETY INSTRUCTIONS
IMPORTANT SAFETY INSTRUCTIONS
1)
Read these instructions.
2)
Keep these instructions.
3)
Heed all warnings.
4)
Follow all instructions.
5)
Do not use this apparatus near water.
6)
Clean only with dry cloth.
7)
Do not block any ventilation openings. Install in accordance with the manufacturer's
instructions.
8)
Do not install near any heat sources such as radiators, heat registers, stoves, or other
apparatus (including amplifiers) that produce heat.
9)
Do not defeat the safety purpose of the polarized or grounding-type plug. A
polarized plug has two blades with one wider than the other. A grounding-type
plug has two blades and a third grounding prong. The wide blade or the third
prong are provided for your safety. If the provided plug does not fit into your
outlet, consult an electrician for replacement of the obsolete outlet.
10)
Protect the power cord from being walked on or pinched particularly at plugs,
convenience receptacles, and the point where they exit from the apparatus.
11)
Only use attachments/accessories specified by the manufacturer.
12)
Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer,
or sold with the apparatus. When a cart is used, use caution when moving the
cart/apparatus combination to avoid injury from tip-over.
13)
Unplug this apparatus during lightning storms or when unused for long periods of
time.
14)
Refer all servicing to qualified service personnel. Servicing is required when the
apparatus has been damaged in any way, such as a power-supply cord or plug is
damaged, liquid has been spilled or objects have fallen into the apparatus, the
apparatus has been exposed to rain or moisture, does not operate normally, or has
been dropped.
Power Source Warning
A label on this product indicates the correct power source for this product. Operate this product only
from an electrical outlet with the voltage and frequency indicated on the product label. If you are
uncertain of the type of power supply to your home or business, consult your service provider or your
local power company.
The AC inlet on the unit must remain accessible and operable at all times.
Ground the Product
WARNING: Avoid electric shock and fire hazard! If this product connects to coaxial
cable wiring, be sure the cable system is grounded (earthed). Grounding provides some
protection against voltage surges and built-up static charges.

4028518 Rev B 5
IMPORTANT SAFETY INSTRUCTIONS
Protect the Product from Lightning
In addition to disconnecting the AC power from the wall outlet, disconnect the signal inputs.
Verify the Power Source from the On/Off Power Light
When the on/off power light is not illuminated, the apparatus may still be connected to the power
source. The light may go out when the apparatus is turned off, regardless of whether it is still plugged
into an AC power source.
Eliminate AC Mains Overloads
WARNING: Avoid electric shock and fire hazard! Do not overload AC mains, outlets,
extension cords, or integral convenience receptacles. For products that require battery
power or other power sources to operate them, refer to the operating instructions for
those products.
Provide Ventilation and Select a Location
Remove all packaging material before applying power to the product.
Do not place this apparatus on a bed, sofa, rug, or similar surface.
Do not place this apparatus on an unstable surface.
Do not install this apparatus in an enclosure, such as a bookcase or rack, unless the installation
provides proper ventilation.
Do not place entertainment devices (such as VCRs or DVDs), lamps, books, vases with liquids, or
other objects on top of this product.
Do not block ventilation openings.
Protect from Exposure to Moisture and Foreign Objects
WARNING: Avoid electric shock and fire hazard! Do not expose this product to
dripping or splashing liquids, rain, or moisture. Objects filled with liquids, such as
vases, should not be placed on this apparatus.
WARNING: Avoid electric shock and fire hazard! Unplug this product before cleaning.
Do not use a liquid cleaner or an aerosol cleaner. Do not use a magnetic/static cleaning
device (dust remover) to clean this product.
WARNING: Avoid electric shock and fire hazard! Never push objects through the
openings in this product. Foreign objects can cause electrical shorts that can result in
electric shock or fire.
Service Warnings
WARNING: Avoid electric shock! Do not open the cover of this product. Opening or
removing the cover may expose you to dangerous voltages. If you open the cover, your
warranty will be void. This product contains no user-serviceable parts.

6 4028518 Rev B
IMPORTANT SAFETY INSTRUCTIONS
Check Product Safety
Upon completion of any service or repairs to this product, the service technician must perform safety
checks to determine that this product is in proper operating condition.
Protect the Product When Moving It
Always disconnect the power source when moving the apparatus or connecting or disconnecting
cables.
Telephone Equipment Notice
When using your telephone equipment, basic safety precautions should always be followed to reduce
the risk of fire, electric stock and injury to persons, including the following:
1. Do not use this product near water, for example, near a bath tub, wash bowl, kitchen sink or laundry
tub, in a wet basement or near a swimming pool.
2. Avoid using a telephone (other than a cordless type) during an electrical storm. There may be a
remote risk of electric shock from lightning.
3. Do not use the telephone to report a gas leak in the vicinity of the leak.
CAUTION: To reduce the risk of fire, use only No. 26 AWG or larger
telecommunication line cord.
SAVE THESE INSTRUCTIONS
20090326_Modem No Battery_Safety

4028518 Rev B vii
United States FCC Compliance
This device has been tested and found to comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against such interference in a residential installation. This equipment generates,
uses, and can radiate radio frequency energy. If not installed and used in accordance with the
instructions, it may cause harmful interference to radio communications. However, there is
no guarantee that interference will not occur in a particular installation. If this equipment
does cause harmful interference to radio or television reception, which can be determined by
turning the equipment OFF and ON, the user is encouraged to try to correct the interference
by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
Consult the service provider or an experienced radio/television technician for help.
Any changes or modifications not expressly approved by Cisco Systems, Inc., could void the
user's authority to operate the equipment.
The information shown in the FCC Declaration of Conformity paragraph below is a
requirement of the FCC and is intended to supply you with information regarding the FCC
approval of this device. The phone numbers listed are for FCC-related questions only and not
intended for questions regarding the connection or operation for this device. Please contact your
service provider for any questions you may have regarding the operation or installation of this device.
Declaration of Conformity
This device complies with Part 15 of FCC
Rules. Operation is subject to the following two
conditions: 1) the device may not cause
harmful interference, and 2) the device must
accept any interference received, including
interference that may cause undesired
operation.
DPC2202 or EPC2202 VoIP Cable Modem
Model: DPC2202/EPC2202
Manufactured by:
Cisco Systems, Inc.
5030 Sugarloaf Parkway
Lawrenceville, Georgia 30044 USA
Telephone: [phone]
Canada EMI Regulation
This Class B digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la class B est conforme à la norme NMB-003 du Canada.
20081121 FCC Standard

viii 4028518 Rev B
CE Compliance
Declaration of Conformity with Regard to the EU Directive 1999/5/EC
(R&TTE Directive)
This declaration is only valid for configurations (combinations of software, firmware and
hardware) supported or provided by Cisco Systems for use within the EU. The use of
software or firmware not supported or provided by Cisco Systems may result in the
equipment no longer being compliant with the regulatory requirements.

4028518 Rev B ix
Note: The full declaration of conformity for this product can be found in the Declarations of
Conformity and Regulatory Information section of the appropriate product hardware
installation guide, which is available on Cisco.com.
The following standards were applied during the assessment of the product against the
requirements of the Directive 1999/5/EC:
EMC: EN 55022 and EN 55024
EN 61000-3-2 and EN 61000-3-3
Safety: EN 60950-1
This product conforms to the following European directives:
-1999/5/EC
20090724 CE_Modem/EMTA

10 4028518 Rev B
Introduction
Introduction
Welcome to the exciting world of high-speed Internet and high-quality digital
telephone service. Your new DPC2202 or EPC2202 Voice-over-Internet Protocol
(VoIP) Cable Modem is a modem that meets industry standards for high-speed data
connectivity along with reliable digital telephone service. With cable modem, your
Internet enjoyment, home and business communications, and personal productivity
will surely soar.
This guide provides procedures and recommendations for placing, installing,
configuring, operating, and troubleshooting your DPC2202 or EPC2202 cable
modem for high-speed Internet or digital telephone service for your home or office.
Refer to the appropriate section in this guide for the specific information you need
for your situation. Contact your service provider for more information about
subscribing to these services.
Benefits and Features
Your new cable modem offers the following outstanding benefits and features:
Includes an embedded media terminal adapter (EMTA) supporting two-line
voice services
Provides a high-speed broadband Internet connection that energizes your online
experience, which makes downloading and sharing files and photos with your
family and friends hassle free
Includes 10/100BASE-T Ethernet and USB ports to provide connectivity for high-
speed data services or to other Internet devices
Ensures interoperability with most service providers by complying with the
following specifications:
-DPC2202—DOCSIS 2.0 and backward compatibility for operation in DOCSIS
1.1 and DOCSIS 1.0 networks
-EPC2202—EuroDOCSIS 2.0 and backward compatibility for operation in
EuroDOCSIS 1.1 and EuroDOCSIS 1.0 networks
Includes two RJ-11 telephony ports for connecting conventional telephones or
fax machines
Allows you to attach multiple devices in your home or office to the cable modem
for high-speed networking and sharing of files and folders without first copying
them onto a CD or diskette
Features Plug and Play operation for easy set up and installation
Provides parental control and advanced firewall technology

4028518 Rev B 11
Introduction
Uses an attractive compact design that allows for horizontal tabletop or wall-
mount placement
Allows automatic software upgrades by your service provider

12 Error! No text of specified style in document.
What's In the Carton?
What's In the Carton?
When you receive your cable modem, you should check the equipment and
accessories to verify that each item is in the carton and that each item is undamaged.
The carton contains the following items:
One DPC2202 or EPC2202 VoIP Cable
Modem
One AC power adapter with power cord
One Ethernet cable (CAT5/RJ-45)
One USB cable
One CD-ROM containing the user guide
and the USB drivers
If any of these items are missing or damaged, please contact your service provider
for assistance.
Notes:
You need a cable signal splitter and additional standard RF coaxial cables if you
want to connect a VCR, a Digital Home Communications Terminal (DHCT) or a
set-top converter, or a TV to the same cable connection as your wireless home
gateway.
Cables and other equipment needed for telephone service must be purchased
separately. Contact your service provider to inquire about the equipment and
cables you need for telephone service.

Error! No text of specified style in document. 13
Front Panel Description
Front Panel Description
The front panel of your cable modem provides status LEDs that indicate how well
and at what state your cable modem is operating. See Front Panel LED Status
Indicator Functions (on page 32) for more information on front-panel LED status
indicator functions.
1POWER –Illuminates solid green to indicate that AC power is being applied to
the cable modem.
2DS (Downstream) –Indicates the status of the connection for receiving data.
Illuminates during normal operation
3US (Upstream) –Indicates the status of the connection for sending data.
Illuminates during normal operation
4ONLINE –Illuminates solid green when the cable modem is registered on the
network and fully operational. This indicator blinks to indicate one of the
following conditions:
The cable modem is booting up and not ready for data
The cable modem is scanning the network and attempting to register
The cable modem has lost registration on the network and will continue
blinking until it registers again
5LINK –Illuminates solid green to indicate that an Ethernet/USB carrier is
present and blinks to indicate that Ethernet/USB data is being transferred
between the PC and the cable modem
6TEL 1 –Illuminates solid green when telephony service is enabled. Blinks when
line 1 is in use
7TEL 2 –Illuminates solid green when telephony service is enabled. Blinks when
line 2 is in use
Note: After the cable modem is successfully registered on the network, the
POWER (LED 1), DS (LED 2), US (LED 3), and ONLINE (LED 4) LEDs
illuminate continuously to indicate that the cable mode is active and fully
operational

14 Error! No text of specified style in document.
Back Panel Description
Back Panel Description
The following illustration shows the description and function of the back panel
components on the DPC2202 and EPC2202.
Important: Do not connect your PC to both the Ethernet and USB ports at the same
time. Your modem will not function properly if both the Ethernet and USB ports are
connected to your PC at the same time.
1POWER –Connects the cable modem to the AC power supply that is provided
with your cable modem
CAUTION:
Avoid damage to your equipment. Only use the AC power adapter that is
provided with your cable modem.
2TEL 1/TEL 2 –RJ-11 telephone ports connect to home telephone wiring to
conventional telephones or fax machines
3ETHERNET –RJ-45 Ethernet port connects to the 10/100BASE-T Ethernet port
on your PC or your home network
4USB –12 Mbps USB 1.1 port connects to the USB port on your PC
5REBOOT EMTA –Pressing this switch reboots the EMTA. Pressing this switch
for more than three seconds resets the device to factory default values and
reboots the EMTA
CAUTION:
The Reboot EMTA button is for maintenance purposes only. Do not use
unless instructed to do so by your service provider. Doing so may cause
you to lose any cable modem settings you have selected.
6CABLE –F-Connector connects to an active signal from your service provider

Error! No text of specified style in document. 15
What Are the System Requirements for Internet Service?
What Are the System Requirements for Internet Service?
To ensure that your cable modem operates efficiently for high-speed Internet service,
verify that all of the Internet devices on your system meet or exceed the following
minimum hardware and software requirements.
Note: You will also need an active cable input line and an Internet connection.
Minimum System Requirements for a PC
A PC with a Pentium MMX 133 processor or greater
32 MB of RAM
Web browsing software
CD-ROM drive
Minimum System Requirements for Macintosh
MAC OS 7.5 or later
32 MB of RAM
System Requirements for an Ethernet Connection
A PC with Microsoft Windows 95 operating system (or later) with TCP/IP
protocol installed, or an Apple Macintosh computer with TCP/IP protocol
installed
An active 10/100BASE-T Ethernet network interface card (NIC) installed
System Requirements for a USB Connection
A PC with Microsoft Windows 98SE, ME, 2000, XP, or Vista operating system
A master USB port installed in your PC

16 4028518 Rev B
How Do I Subscribe to High-Speed Internet and Telephone Service?
How Do I Subscribe to High-Speed Internet and Telephone
Service?
Before you can use your cable modem, you need to have a high-speed Internet
access account. If you do not have a high-speed Internet access account, you need to
set up an account with your local service provider. Choose one of the options in this
section.
I Do Not Have a High-Speed Internet Access Account
If you do not have a high-speed Internet access account, your service provider will
set up your account and become your Internet Service Provider (ISP). Internet access
enables you to send and receive e-mail, access the World Wide Web, and receive
other Internet services.
You will need to give your service provider the following information:
The serial number of the modem
The Media Access Control (MAC) address of the modem (CM MAC)
These numbers appear on a bar code label located on the cable modem. The serial
number consists of a series of alphanumeric characters preceded by S/N. The MAC
address consists of a series of alphanumeric characters preceded by CM MAC. The
following illustration shows a sample bar code label.
Write down these numbers in the space provided here.
Serial Number _______________________
MAC Address ________________________
I Already Have an Existing High-Speed Internet Access Account
If you have an existing high-speed Internet access account, you must give your
service provider the serial number and the MAC address of the cable modem. Refer
to the serial number and MAC address information listed previously in this section.

4028518 Rev B 17
How Do I Subscribe to High-Speed Internet and Telephone Service?
I Want to Use the Cable Modem for Telephone Service
You will also need to set up a telephone account with your local service provider to
use your cable modem for telephone service. When you contact your service
provider, you may be able to transfer your existing telephone numbers, or your cable
telephony service provider will assign a new telephone number for each current or
additional active telephone line. Discuss these options with your telephony service
provider.

18 Error! No text of specified style in document.
Where Is the Best Location for My Cable Modem?
Where Is the Best Location for My Cable Modem?
The ideal location for your cable modem is where it has access to outlets and other
devices. Think about the layout of your home or office, and consult with your
service provider to select the best location for your cable modem. Read this user
guide thoroughly before you decide where to place your cable modem.
Consider these recommendations:
Position your PC and cable modem so that they are located near an AC power
outlet.
Position your PC and cable modem so that they are located near an existing cable
input connection to eliminate the need for an additional cable outlet. There
should be plenty of room to guide the cables away from the modem and the PC
without straining or crimping them.
Airflow around the cable modem should not be restricted.
Choose a location that protects the cable modem from accidental disturbance or
harm.

4028518 Rev B 19
How Do I Mount the Modem on a Wall? (Optional)
How Do I Mount the Modem on a Wall? (Optional)
You can mount the cable modem on a wall using two wall anchors, two screws, and
the mounting slots located on the unit. The modem can be horizontally mounted.
Before You Begin
Before you begin, choose an appropriate mounting place. The wall can be made of
cement, wood, or drywall. The mounting location should be free of obstructions on
all sides, and the cables should be able to easily reach the cable modem without
strain. Leave sufficient clearance between the bottom of the cable modem and any
flooring or shelving underneath to allow access to cabling. In addition, leave enough
slack in all cables so that the cable modem can be removed for any required
maintenance without disconnecting the cables. Also, verify that you have the
following items:
Two wall anchors for #8 x 1-inch screws
Two #8 x 1-inch pan head sheet metal screws
Drill with a 3/16-in. wood or masonry bit, as appropriate for the wall
composition
A copy of the wall-mounting illustrations shown on the following pages
Mount the modem as shown in the following illustration.

20 4028518 Rev B
How Do I Mount the Modem on a Wall? (Optional)
Location and Dimensions of the Wall-Mounting Slots
The following illustration shows the location and dimensions of the wall-mounting
slots on the bottom of the modem. Use the information on this page as a guide for
mounting your modem to the wall.
