Cisco ISA 3000 Operator's manual

Cisco Systems, Inc.
www.cisco.com
Product Documentation and Compliance Informa-
tion for the Cisco ISA 3000 Industrial Security
Appliance
•Cisco Information
•Related Documentation
•Installing the ISA 3000
•Hazardous Locations Standards and Marking Strings
•EMC Information
IMPORTANT! READ ALL THE SAFETY INFORMATION
BEFORE INSTALLING THE HARDWARE

2
Product Documentation and Compliance Information for the Cisco ISA 3000 Industrial Security Appliance
78-100733-01B0
Cisco Information
Related Documentation
For basic installation and configuration information, refer to the installation and configuration guide:
•ISA 3000 product page
http://www.cisco.com/c/en/us/support/security/industrial-security-appliance-3000/model.html
•ASDM documentation
http://www.cisco.com/c/en/us/td/docs/security/asa/compatibility/asamatrx.html
http://www.cisco.com/c/en/us/td/docs/security/asa/roadmap/asaroadmap.html
•CSM Documentation
http://www.cisco.com/c/en/us/support/security/security-manager/products-docum
entation-roadmaps-list.html
•FireSIGHT Documentation
•http://www.cisco.com/c/en/us/td/docs/security/firesight/roadmap/firesight-roadmap.
html
•Cisco.com: www.cisco.com
•Warranty Information: www.cisco-warrantyfinder.com
•Cisco Information Packet, consisting of Cisco Limited Warranty, Disclaimer of Warranty, End User
License Agreement, and United States Federal Communications Commission Notice:
www.cisco.com/en/US/docs/general/warranty/English/SL3DEN__.html
•Cisco Marketplace: www.cisco.com/pcgi-bin/marketplace/welcome.pl
•Cisco Product Documentation: www.cisco.com/go/techdocs
•Cisco Support: www.cisco.com/cisco/web/support/index.html
Installing the ISA 3000
These sections explain how to install the device. See the Cisco ISA 3000 Hardware Installation Guide
for more information.
Items Shipped with your Cisco ISA 3000
Unpack the box and verify that all items listed on the invoice were shipped with the Cisco ISA 3000.
The following items are shipped with your device:
•This document, Part Number 78-100733-01
Table 1 Cisco Company Name and Address Details
Company Name Cisco Address
Cisco Systems, Inc. 170 West Tasman Drive, San Jose, CA 95134-1706, United States.

3
Product Documentation and Compliance Information for the Cisco ISA 3000 Industrial Security Appliance
78-100733-01B0
Equipment that You Supply
•For power and alarm connections, use UL- and CSA-rated style 1007 or 1569 twisted-pair copper
appliance wiring material (AWM) wire
•ESD-preventive cord and wrist strap.
•Wire crimper for chassis grounding.
•Wire for connecting the chassis to an earth ground.
•Ethernet cables for connecting to the Gigabit Ethernet ports.
•Ratcheting torque flathead screwdriver that exerts up to 15 in-lb (1.69 N-m) of pressure.
•A number-2 Phillips screwdriver.
•Wire-stripping tool
Installation Warning and Caution Statements
Warning IMPORTANT SAFETY INSTRUCTIONS
This warning symbol means danger. You are in a situation that could cause bodily injury. Before you
work on any equipment, be aware of the hazards involved with electrical circuitry and be familiar
with standard practices for preventing accidents. Use the statement number provided at the end of
each warning to locate its translation in the translated safety warnings that accompanied this device.
Statement 1071
Warning Read the installation instructions before connecting the system to the power source. Statement 1004
Warning Exposure to some chemicals could degrade the sealing properties of materials used in the sealed
relay device. Statement 381
Warning This product relies on the building’s installation for short-circuit (over-current) protection. Ensure
that the protective device is rated not greater than: 2 A Statement 1005
Warning This unit is intended for installation in restricted access areas. A restricted access area can be
accessed only through the use of a special tool, lock and key, or other means of security.
Statement 1017
Warning This equipment must be grounded. Never defeat the ground conductor or operate the equipment in the
absence of a suitably installed ground conductor. Contact the appropriate electrical inspection
authority or an electrician if you are uncertain that suitable grounding is available. Statement 1024
Warning Only trained and qualified personnel should be allowed to install, replace, or service this equipment.
Statement 1030
Warning Ultimate disposal of this product should be handled according to all national laws and regulations.
Statement 1040

4
Product Documentation and Compliance Information for the Cisco ISA 3000 Industrial Security Appliance
78-100733-01B0
Warning To prevent the system from overheating, do not operate it in an area that exceeds the maximum
recommended ambient temperature of:
158°F (60°C) Statement 1047
Warning Installation of the equipment must comply with local and national electric codes. Statement 1074
Warning Explosion Hazard—The area must be known to be nonhazardous before installing, servicing, or
replacing the unit. Statement 1082
Warning Use twisted-pair supply wires suitable for 86°F (30°C) above surrounding ambient temperature
outside the enclosure. Statement 1067
Warning Avoid using or servicing any equipment that has outdoor connections during an electrical storm.
There may be a risk of electric shock from lightning. Statement 1088
Caution Airflow around the device must be unrestricted. To prevent the device from overheating, ensure these
minimum clearances:
– Top and bottom: 1.0 inches (25 mm)
– Exposed side (not connected to the module): 1.0 inches (25 mm)
– Front: 1.0 inches (25 mm)
Contact your Cisco Technical Assistance Centre (TAC) if tighter spacings are required.
Caution This equipment is suitable for use in Class I, Division 2, Groups A, B, C, D, or only nonhazardous
locations.
Caution The equipment shall only be used in an area of not more than pollution degree 2 as defined by EN
60664-1. In addition, the equipment shall be installed in an ATEX certified enclosure that provides a
degree of protection not less than IP 54 in accordance with EN 60079-15.
Note This equipment is rated as follows:
- DC Input Voltage: Maximum Operating Range: 9.6VDC to 60VDC; Nominal: 12VDC to 48VDC
Note The maximum ambient operating temperature range is –40 to 140°F (–40 to 60°C).

5
Product Documentation and Compliance Information for the Cisco ISA 3000 Industrial Security Appliance
78-100733-01B0
Grounding the ISA 3000
Make sure to follow any grounding requirements at your site. The device must be connected to a reliable
earth ground. Install the ground wire in accordance with local electrical safety standards.
Note The ground lug is not supplied with the device. You can use either a single ring terminal, two single ring
terminals, or a double ring terminal.
Warning This equipment must be grounded. Never defeat the ground conductor or operate the equipment in the
absence of a suitably installed ground conductor. Contact the appropriate electrical inspection
authority or an electrician if you are uncertain that suitable grounding is available. Statement 1024
Warning This equipment is intended to be grounded to comply with emission and immunity requirements.
Ensure that the device functional ground lug is connected to earth ground during normal use.
Statement 1064
Warning This equipment needs to be grounded. Use a green and yellow 14 to 16 AWG ground wire to connect
the host to earth ground during normal use. Statement 242
Warning This equipment must be grounded. Never defeat the ground conductor or operate the equipment in the
absence of a suitably installed ground conductor. Contact the appropriate electrical inspection
authority or an electrician if you are uncertain that suitable grounding is available. Statement 1024
Warning When installing or replacing the unit, the ground connection must always be made first and
disconnected last. Statement 1046
To ground the ISA 3000 to earth ground, follow these steps:
Step 1 Use a standard Phillips screwdriver or a ratcheting torque screwdriver with a Phillips head to remove the ground
screw from the front panel of the device.
Step 2 Use a wire stripping tool to strip the 14-to-16 AWG grounding wire to 0.22 in. (5.56 mm).
Step 3 Insert the ground wire into the ring terminal lug, and using a crimping
tool, crimp the terminal to the wire.
Step 4 Slide the ground screw through the terminal.
332163

6
Product Documentation and Compliance Information for the Cisco ISA 3000 Industrial Security Appliance
78-100733-01B0
Connecting DC Power
Warning When you connect or disconnect the power and/or alarm connector with power applied, an electrical
arc can occur. This could cause an explosion in hazardous area installations. Be sure that all power
is removed from the device and any other circuits. Be sure that power cannot be accidentally turned
on or verify that the area is nonhazardous before proceeding. Statement 1058
Warning Explosion Hazard—Substitution of components may impair suitability for Class I, Division 2/Zone 2.
Statement 1083
Warning In device installations in a hazardous location, the DC power source could be located away from the
vicinity of the device. Before performing any of the following procedures, locate the DC circuit to
ensure that the power is removed and cannot be turned on accidentally, or verify that the area is
nonhazardous before proceeding. Statement 1059
Warning Installation of the equipment must comply with local and national electrical codes. Statement 1074
Warning Before performing any of the following procedures, ensure that power is removed from the DC circuit.
Statement 1003
Warning Only trained and qualified personnel should be allowed to install, replace, or service this equipment.
Statement 1030
Warning A readily accessible two-poled disconnect device must be incorporated in the fixed wiring.
Statement 1022
Step 5 Insert the ground screw into the functional ground screw opening on the
front panel.
Attach the ring terminal to the chassis using the screw set aside in step 1.
The graphic to the right shows the proper ground connection points.
Step 6 Use a ratcheting torque screwdriver to tighten the ground screw and ring terminal to the ISA 3000 front panel to 3.5
in-lb (0.4 N-m). The torque should not exceed 3.5 in-lb (0.4 N-m).
Step 7 Attach the other end of the ground wire to a grounded bare metal surface, such as a ground bus, a grounded DIN
rail, or a grounded bare rack.

7
Product Documentation and Compliance Information for the Cisco ISA 3000 Industrial Security Appliance
78-100733-01B0
To connect DC power:
Step 1 Locate the power connector on the ISA 3000 front panel.
Step 2 Identify the connector positive and return DC power connections. The connections are:
•+ — Positive DC power connection
•- —Return DC power connection
Step 3 Measure two strands of twisted-pair copper wire (18-to-20 AWG) (2.6mm) long enough to connect to the DC power
source.
Step 4 Using an 18-gauge (1.02mm) wire-stripping tool, strip each of the two
twisted pair wires coming from each DC-input power source to 0.25 inch
(6.3 mm) ± 0.02 inch (0.5 mm). Do not strip more than 0.27 inch (6.8 mm)
of insulation from the wire. Stripping more than the recommended
amount of wire can leave exposed wire from the power connector after
installation.
Step 5 Remove the two captive screws that attach the power connector to the ISA 3000, and remove the connector.
Step 6 On the power connector, insert the exposed part of the positive wire into
the connection labeled “+” and the exposed part of the return wire into the
connection labeled “–”. Make sure that you cannot see any wire lead. Only
wire with insulation should extend from the connector.
1 - Power source positive connection.
2 - Power source return connection.
331209
333084
406053
2 1

8
Product Documentation and Compliance Information for the Cisco ISA 3000 Industrial Security Appliance
78-100733-01B0
Attaching the DC Power Connectors
Warning This product relies on the building’s installation for short-circuit (over-current) protection. Ensure
that the protective device is rated not greater than: 2 A
Statement 1005
To attach the power connectors:
Warning Failure to securely tighten the captive screws can result in an electrical arc if the connector is
accidentally removed. Statement 397
Step 7 Use a ratcheting torque flathead screwdriver to torque the power
connector captive screws (above the installed wire leads) to 2 in-lb (0.23
N-m).
1- Power connector captive screws
Step 8 Connect the other end of the positive wire to the positive terminal on the DC power source, and connect the other
end of the return wire to the return terminal on the DC power source.
When you are testing the device, one power connection is sufficient. If you are installing the device and are using a
second power source, repeat steps 4 through 8 using the second power connector.
1
Step 1 Insert the power connector into the receptacle on the ISA 3000 front panel.
Step 2 Use a ratcheting torque flathead screwdriver to tighten the captive screws on both sides of the power connector to
2 in-lb (0.23 N-m).
When you are testing the device, one power source is sufficient. If you are installing the device and are using a
second power source, repeat this procedure for the second power connector (DC-B), which installs just below the
primary power connector (DC-A).
When you are installing the device, secure the wires coming from the power connector so that they cannot be
disturbed by casual contact. For example, use tie wraps to secure the wires to the rack.

9
Product Documentation and Compliance Information for the Cisco ISA 3000 Industrial Security Appliance
78-100733-01B0
Warning When you connect or disconnect the power and/or alarm connector with power applied, an electrical
arc can occur. This could cause an explosion in hazardous area installations. Be sure that all power
is removed from the device and any other circuits. Be sure that power cannot be accidentally turned
on or verify that the area is nonhazardous before proceeding. Statement 1058
Connecting to the ISA 3000 Ports
For hazardous location environments, follow these warnings when connecting to the destination ports
(Gigabit Ethernet and console ports).
Warning If you connect or disconnect the console cable with power applied to the device or any device on the
network, an electrical arc can occur. This could cause an explosion in hazardous location
installations. Be sure that power is removed or the area is nonhazardous before proceeding.
Statement 1080
Warning Do not connect or disconnect cables to the ports while power is applied to the device or any device
on the network because an electrical arc can occur. This could cause an explosion in hazardous
location installations. Be sure that power is removed from the device and cannot be accidentally be
turned on, or verify that the area is nonhazardous before proceeding.
Statement 1070
Connecting to the USB Ports
Note If you are connecting to the USB ports:
- a connection (to the USB ports) can only be made in a non-hazardous environment
- the USB port covers must be reinstalled before the ISA 3000 can be deployed in a hazardous
environment
For more information about connecting to the USB port, see the Cisco ISA 3000 Hardware Installation
Guide on Cisco.com.
Optional Procedures
For detailed instructions on installing the device in a hazardous environment, see the Cisco ISA 3000
Hardware Installation Guide on Cisco.com.
For hazardous locations environments, if you are installing or removing the flash card or alarm wiring,
follow these warnings:
Caution Use a ratcheting torque flathead screwdriver to torque the power connector captive screws to 2in-lb (0.226
N-m), the maximum recommended torque.
Warning When you connect or disconnect the power and/or alarm connector with power applied, an electrical
arc can occur. This could cause an explosion in hazardous area installations. Be sure that all power
is removed from the device and any other circuits. Be sure that power cannot be accidentally turned
on or verify that the area is nonhazardous before proceeding. Statement 1058

10
Product Documentation and Compliance Information for the Cisco ISA 3000 Industrial Security Appliance
78-100733-01B0
Warning Do not insert or remove the flash card while power is on; an electrical arc can occur. This could cause
an explosion in hazardous location installations. Be sure that power is removed or the area is
nonhazardous before proceeding. Statement 379
Hazardous Locations Standards and Marking Strings
EMC Information
EMC Class A Notices and Warnings
Statement 340—Class A Warning for CISPR22
The following standards were used for the
hazardous locations approvals and certifications:
ANSI/ASA 12.12.01-2013
CAN/CSA C22.2 No. 60079-0-11 Ed. 2
CAN/CSA C22.2 No. 60079-15-12 Ed. 1
CSA C22.2 No. 213-M1987
EN 60079-0:2012+A11:2013
EN 60079-15:2010
IEC 60079-0 6th Edition
IEC 60079-15 4th Edition
UL 60079-0, 5th Ed, 2009-10-21
UL 60079-15, 3rd Ed, 2009-7-17
The following hazardous locations strings are
provided on the ISA 3000:
Class 1, Div 2, Groups A B C D
Class I, Zone 2, Ex nA nC IIC T4 Gc X
II 3G, Ex nA nC IIC T4 Gc
DEMKO 15ATEX 1523X
Class I, Zone 2, AEx nA nC IIC T4 Gc
Warnung
Dies ist ein Produkt der Klasse A. Bei der Verwendung dieses Produkts im Haus- oder Wohnungsbereich kann es zu
Funkstörungen kommen. In diesem Fall muss der Benutzer u. U. angemessene Maßnahmen ergreifen.

11
Product Documentation and Compliance Information for the Cisco ISA 3000 Industrial Security Appliance
78-100733-01B0
This page intentionally left blank.

12
Product Documentation and Compliance Information for the Cisco ISA 3000 Industrial Security Appliance
78-100733-01B0
Note This Table is a regulatory document required for products shipped to the People’s Republic of China.
Cisco and the Cisco logo are trademarks or registered trademarks of Cisco and/or its affiliates in the U.S. and other countries. To view a list of
Cisco trademarks, go to this URL: www.cisco.com/go/trademarks. Third-party trademarks mentioned are the property of their respective owners. The
use of the word partner does not imply a partnership relationship between Cisco and any other company. (1110R)
© 2015 Cisco Systems, Inc. All rights reserved.
Printed in the USA on recycled paper containing 10% postconsumer waste.
