Clear-Com Tempest 2400 MasterBelt User manual

2-Channel Wireless Intercom Reference Manual
Tempest®2400 MasterBelt™
399G114 Rev A

Document Reference
Tempest®2400 MasterBelt™ Reference Manual
Part Number 399G114 Rev A
T2400MasterBelt_RefMan_D0000109_RevA
Legal Disclaimers
Clear-Com, LLC
1301 Marina Village Parkway
Suite 105
Alameda, CA 94501
www.clear-com.com
© 2014 HM Electronics All rights reserved
Clear-Com and the Clear-Com logo are trademarks or registered trademarks of HM Electronics, Inc.
Tempest is manufactured by CoachComm, LLC and is distributed by Clear-Com, LLC.
®Tempest and MasterBelt™ are registered trademarks of CoachComm, LLC.
The soware described in this document is furnished under a license agreement and may be used only in accordance with
the terms of the agreement.
The product described in this document is distributed under licenses restricng its use, copying, distribuon, and
decompilaon/reverse engineering. No part of this document may be reproduced in any form by any means without prior
wrien authorizaon of Clear-Com, an HME Company.
Clear-Com Oces are located in California, USA; Cambridge, UK; Montreal, Canada; and Beijing, China. Specic addresses and
contact informaon can be found on Clear-Com’s corporate web site:
Web site: www.clearcom.com
Clear-Com Contacts
Americas and Asia-Pacic Headquarters
California, United States
Tel: [phone]
E-mail: Cust[email protected]
Europe, Middle East, and Africa Headquarters
Cambridge, United Kingdom
Tel: [phone]
E-mail: [e-mail]
Canada Oce
Quebec , Canada
Tel: [phone]
China Oce
Beijing Representave Oce
Beijing, P.R.China
Tel: [phone]

Table of Contents
Thank you from Tempest Wireless.......................................................................................................... 1
Important Safety Instrucons ................................................................................................................. 2
A/C Power Warning .................................................................................................................................. 3
Baery Safety ........................................................................................................................................... 3
Baery Transportaon ..................................................................................................................... 3
Baery Storage................................................................................................................................. 4
Maintenance and Care ............................................................................................................................. 4
Cleaning ........................................................................................................................................... 4
Temperature and Humidity .............................................................................................................. 4
MasterBelt Overview.............................................................................................................................. 5
1- Volume- CH A and CH B................................................................................................................ 5
2- Base Buon.................................................................................................................................. 5
3- MENU Buon............................................................................................................................... 5
4- ENTER Buon............................................................................................................................... 5
5- LCD ............................................................................................................................................... 6
6- CALL Buon ................................................................................................................................. 6
1- Rubberized Access Cover ............................................................................................................. 6
2- USB Mini B Connector.................................................................................................................. 6
3- BeltStaon Pairing Connector...................................................................................................... 6
1- Belt Clip........................................................................................................................................ 6
2- Power ON/OFF Buon ................................................................................................................. 6
3- Baery Compartment.................................................................................................................. 6
4- Headset Connector ...................................................................................................................... 6
Talk Buon A and B .......................................................................................................................... 7
Channel Indicator LEDs A and B ....................................................................................................... 7
MasterBelt Display Overview........................................................................................................... 7
BeltStaon Overview.............................................................................................................................. 8
1- Volume- CH A and CH B................................................................................................................ 8
2- STAGE Buon ............................................................................................................................... 8
3- MENU Buon............................................................................................................................... 8
4- ENTER Buon............................................................................................................................... 8
5- LCD ............................................................................................................................................... 8
6- CALL Buon ................................................................................................................................. 8
1- Rubberized Access Cover ............................................................................................................. 9
2- USB Mini B Connector.................................................................................................................. 9
3- BeltStaon Pairing Connector...................................................................................................... 9
1- Belt Clip........................................................................................................................................ 9
2- Power ON/OFF Buon ................................................................................................................. 9
3- Baery Compartment.................................................................................................................. 9
4- Headset Connector ...................................................................................................................... 9
Talk Buon A and B ........................................................................................................................ 10
Channel Indicator LEDs A and B ..................................................................................................... 10
BeltStaon Display Overview ......................................................................................................... 10
MasterBelt Set-up ................................................................................................................................11
Selecng MasterBelt Locaon ................................................................................................................ 11
Fixed Locaon ................................................................................................................................ 11
Mobile Operaon........................................................................................................................... 11
Baery Charging and Installaon ...........................................................................................................12
MasterBelt Power ON/OFF.............................................................................................................13
Selecng a Frequency Band.................................................................................................................... 13
Set Network Number and Lockout Key...................................................................................................14
Pairing BeltStaons to MasterBelt..........................................................................................................15
Pair BeltStaon to MasterBelt:.......................................................................................................15
Name MasterBelt....................................................................................................................................15

Congure BeltStaon Sengs ..............................................................................................................16
Name BeltStaons ..................................................................................................................................16
Adjust Mic Gain ...................................................................................................................................... 16
Adjust Sidetone.......................................................................................................................................16
Adjust BeltStaon Slot ............................................................................................................................16
Addional Sengs and Features ............................................................................................................17
Modes of Operaon .............................................................................................................................19
Normal Mode ......................................................................................................................................... 19
Shared Mode ..........................................................................................................................................19
Split Mode ..............................................................................................................................................20
MasterBelt Menu.................................................................................................................................... 26
BeltStaon Menu ...................................................................................................................................26

1Tempest®2400 MasterBelt™
Thank you from Clear-Com
We at Clear-Com want to thank you for purchasing a Tempest MasterBelt Wireless Intercom System. We have made every
eort to build a reliable, intuive wireless intercom system that provides the same funconality that you expect from your
hard-wired intercom equipment.
One of our goals in the design of Tempest was that it should work the way you think it should work – that is, it should
be intuive and similar to other equipment that you may already use. You will be able to begin using your new Tempest
Wireless Intercom System with nothing more than the Quick Start Guide. However, to fully benet from the available
features, please read this manual carefully.
We want Tempest to make your job easier and your experience to be posive. To successfully familiarize yourself with the
many diverse and powerful features Tempest oers, it is crucial that you acquaint yourself with the manual. Your me spent
will help you get the most from your Tempest Wireless Intercom by making setup easier .
We are commied to providing you with a high quality product that will deliver years of trouble-free service. Should you
experience any problem with your Tempest Wireless equipment, whether it is a warranted problem or service aer you
have owned the system for several years, we will be there to take care of you.
Thank you for choosing Clear-Com for your wireless intercom needs.

2Tempest®2400 MasterBelt™
Important Safety Instrucons
The word “Cauon” is the lowest of the three signal words (Cauon, Warning and Danger), with “Danger” being the
highest. Therefore, whenever the word “Cauon” is used, it may be replaced with either of the higher rated signal words:
“Warning” or “Danger.”
a) DANGER – indicates a situaon which, when not avoided, results in death or severe injury;
b) WARNING – indicates a situaon which, when not avoided, has the potenal to result in death or severe injury;
c) CAUTION – indicates a situaon which, when not avoided, results or has the potenal to result in minor injury.
1. Read these instrucons.
2. Follow all instrucons.
3. Heed all warnings.
4. Keep these instrucons.
WARNING – To reduce the risk of re or electric shock, do not expose this apparatus to rain or moisture.
Do not use this apparatus near water.
Do not expose the apparatus to dripping or splashing. Do not place objects lled with liquids, such as vases, on the apparatus.
The MasterBelt shall be connected to a main socket outlet having a protecve earthing connecon.
Install the MasterBelt so that the appliance coupler (AC power inlet) is readily accessible and operable. Clean only with a
dry cloth.
Install in accordance with manufacturer’s instrucons.
Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including ampliers) that
produce heat.
Do not defeat the safety purpose of the polarizing or grounding type plug. A polarized plug has two blades with one
wider than the other. A grounding type plug has two blades and a third grounding prong. The wide blade or third prong is
provided for your safety. When the provided plug does not t into your outlet, consult an electrician for replacement of
the obsolete outlet.
Protect the power cord from being walked on or pinched, parcularly at plugs, convenience receptacles, and the point
where they exit the apparatus.
Only use aachments/accessories specied by the manufacturer.
Unplug this apparatus during lightning storms or when unused for long periods of me.
Refer all servicing to qualied service personnel. Servicing is required when the apparatus has been damaged in any way,
for example if the power-supply cord has been damaged, liquid has been spilled or objects have fallen into the apparatus,
or if the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped.

3Tempest®2400 MasterBelt™
A/C Power Warning
Users should exercise extreme care when working with electricity. Addional care should be
used when working with electricity outdoors in inclement weather. When working outdoors or
near water, always connect the system into a ground-fault interrupng circuit.
There are no user-serviceable parts inside the Tempest MasterBelt. Opening the case may expose dangerous electrical
components, and will void the warranty.
ALERT SYMBOL – Indicates important informaon.
CAUTION SYMBOL – Indicates a potenal to damage equipment.
DANGER SYMBOL – indicates a potenal safety hazard.
Baery Safety
Baery Transportaon
Rechargeable lithium baeries are subject to special regulaon by U.S. and
Internaonal laws, parcularly regarding transportaon on passenger aircra.
However, individual baeries installed in consumer electronics are not restricted,
provided there are only the correct numbers and types of baeries as may be needed
to operate the electronic equipment.
Your Tempest MasterBelt Wireless Intercom System includes rechargeable lithium-polymer baeries that power the
MasterBelt and BeltStaons. To ensure that there is no violaon of U.S. or Internaonal laws, and to ensure your own
safety, always:
• Transport rechargeable lithium baeries installed in the equipment they are intended to power.
• Transport spare baeries in a padded case, separated from one another.
• Never transport your rechargeable lithium baeries bundled together.
• Never transport more than 12 lithium baeries in a single package.
Lithium-polymer baeries include a chemistry that is intended to overcome the dangers associated with lithium ion
baeries. In addion, the baeries that accompany your Tempest Wireless system include protecve circuits to further
reduce the possibility of a dangerous reacon associated with charging or discharging beyond safe limits. With reasonable
care you can expect many years of safe and reliable power from your baeries.

4Tempest®2400 MasterBelt™
Tempest baeries are not subject to transport regulaons of dangerous goods because they fulll the following regulatory
provisions:
»ADR 188
»IATA A45
»IMDG 188
Baery Storage
Long-term storage of baeries at maximum charge can result in permanent loss of capacity.
For long term storage of baeries, charge/discharge the baeries to approximately 60% of capacity. Baeries stored for
longer than one year should be recharged to 60% annually. Trickle charging is not recommended due to the very low self
discharge rate of the baeries.
As with all baeries:
• Do not burn.
• Do not expose baeries to excessive heat such as sunshine, re or other heat sources.
• CAUTION – Danger of explosion if baery is incorrectly replaced. Replace only with the same or equivalent type.
• Properly dispose of used baeries promptly.
• Keep away from children.
Maintenance and Care
Cleaning
Generally, the Tempest Wireless hardware should be cleaned only with a dry cloth. A so cloth with rubbing alcohol may
be used to wipe the units if needed. Never spray solvents or chemicals onto the units.
Because of Tempest’s weather resistant design, it is not highly suscepble to dust or airborne contaminants. However, all
electronic devices can be suscepble to parculate contaminaon. If exposed to an extremely dusty environment, contact
an authorized Tempest service center for internal cleaning.
Temperature and Humidity
Ideally, all electronics should be stored and used in a controlled environment with moderate temperature and humidity.
Tempest components are designed to be very durable, and can tolerate a wide range of environmental condions.
Install the MasterBelt in a locaon where it will not be exposed to extreme weather condions. Protect the unit against
dust or moisture. Always protect any AC power connecons from the elements with safety in mind.
The MasterBelt and BeltStaons are designed to work wherever people work. While the design is weather resistant, the
headset XLR connector on the boom is not waterght. MasterBelts or BeltStaons should not be submerged in liquids.
Protect the baery compartment from water when changing baeries. The baery compartment oers a route to the
electronic circuitry.

5Tempest®2400 MasterBelt™
MasterBelt Overview
The Tempest MasterBelt is a 2-Channel Tempest BeltStaon that serves as a Tempest BaseStaon. The MasterBelt is
compable with exisng 2-Channel Tempest BeltStaons. Like a Tempest BaseStaon, the MasterBelt is capable of hosng
and supporng up to ve standard BeltStaons in full duplex communicaon when operang in Normal mode. When
operang in Shared or Split mode, the MasterBelt can support an unlimited number of standard BeltStaons in a listen/
push-to-talk capacity.
The MasterBelt can be situated in a xed locaon (like a BaseStaon) or worn in a mobile capacity (like a BeltStaon).
This type of exibility and mobility enables users to overcome challenges associated with AC power needs, xed antenna
placement and limited coverage area. With a MasterBelt, groups of Tempest users can eecvely move together and
maintain wireless communicaon with one another without the need of a tradional BaseStaon or xed antenna.
A MasterBelt has many of the same funconal and cosmec characteriscs of a standard BeltStaon. Talk buons, channel
buons, volume knobs, and many other features remain the same.
1- Volume- CH A and CH B
In Operaonal Mode, turning the Volume control adjusts the volume of the
audio. Volume indicators appear on the display during adjustment and are
expressed in Decibels (dB).
The Volume control has an opon to be set to “Volume Press” where it requires
a “press and turn” to adjust the volume level. The “Volume Press” opon can be
adjusted under the “Set Controls” secon of the MasterBelt menu.
Pressing the Volume control in “Dual-listen” mode does nothing. In “Single-
listen” mode, pressing “CH A” enables channel A, and pressing “CH B” enables
channel B . The Volume control has a channel “Delay Switch” opon which
requires the knob to be pressed and held slightly longer in order to switch from
one channel to the other. This feature can be enabled under the “Set Controls”
secon of the MasterBelt menu.
In Menu Mode, turning either Volume control allows the user to scroll the
opons of the current menu screen. Pressing the Volume control selects the
opon.
2- Base Buon
The BASE buon (when pressed) changes the MasterBelt’s display to show the telemetry status
of all current BeltStaons logged into the MasterBelt. Once on this screen, pressing the BASE
buon will cycle through each BeltStaon’s telemetry based on their assigned slot posion.
3- MENU Buon
Pressing MENU while the MasterBelt is in Operaonal mode will select Menu Mode, and the Main Menu screen will be
displayed. Once in Menu Mode, pressing MENU again will act as an escape key and will back out of the current menu screen
moving the user up one level. Pressing the MENU buon while at the Main Menu screen will exit Menu Mode and return
to Operaonal mode. The menu can be locked via a “Menu Lock” feature per MasterBelt.
4- ENTER Buon
The ENTER buon operates dierently depending on the mode of the MasterBelt. In Menu Mode, pressing the ENTER
buon selects the current menu opon and is the same as pressing a Volume control. A menu item is not selected unl the
ENTER buon (or Volume control) is pressed.
The ENTER buon can also acvate Wireless ISO (wireless talk around).
BASE Buon Display

6Tempest®2400 MasterBelt™
5- LCD
While in Operaonal Mode, the LCD displays the number of BeltStaons currently in use with
the MasterBelt. In addion, it includes the name of the MasterBelt, baery life remaining,
channel indicators and other data. The LCD backlight and contrast can be adjusted from the LCD
Adjustments menu screen under the LCD/LED secon of the MasterBelt menu.
6- CALL Buon
The CALL Buon sends a call signal to any wireless BeltStaon on the same intercom channel. The Call signal will be routed
to intercom channels indicated by the user’s acve Talk buon(s). Note: The TALK buon must be enabled to send a call signal.
1- Rubberized Access Cover
The Rubberized Access Cover helps prevent dust, dirt and liquid from entering the MasterBelt
through the USB or the BeltStaon pairing connector. Keep this cover securely closed at all mes
to ensure the best possible seal.
2- USB Mini B Connector
The USB Connector is used to charge the MasterBelt with the supplied wall charger. In addion,
the USB connect is used to update the rmware of the MasterBelt.
3- Pairing Connector
The Pairing Connector is used to pair the MasterBelt to BeltStaons using the supplied 3.5mm
stereo mini connector.
1- Belt Clip
The Belt Clip enables the MasterBelt to be worn on the user’s belt or other clothing
item.
2- Power ON/OFF Buon
The Power ON/OFF buon is used to turn the MasterBelt ON or OFF. Press and hold
the Power ON/OFF buon for two seconds to turn the MasterBelt ON. Press for
four seconds to turn the MasterBelt OFF.
3- Baery Compartment
The Baery Compartment holds either one Tempest Lithium-Polymer rechargeable
baery or (3) standard alkaline AA cells. To remove the baery door, press down on
the thumb markings and pull the baery door toward the boom of the MasterBelt.
To remove baeries from the baery compartment turn the MasterBelt baery
side down and tap the boom of the MasterBelt on the palm of your other hand.
Please be careful to insert alkaline AA baeries according to the marked polarity. All of the alkaline AA cells face the same
direcon. If the baery cover does not t or close properly, the baery may not be inserted correctly.
4- Headset Connector
The 4-pin XLR male headset connector mates with most Dynamic or Electret headsets that have 4-pin XLR female connectors.
This Headset connector allows a user to communicate in “Dual-listen” or “Single-listen” mode on either intercom channel.
Operaonal Display

7Tempest®2400 MasterBelt™
The mic detect circuit (dynamic/electret) will indicate dynamic when it sees a load of 600Ω or less. It will indicate an
electret when it sees 1kΩ or greater. Between 600Ω and 1kΩ is not recommended as it may not accurately detect mic type.
Talk Buon A and B
There are two TALK buons on each MasterBelt, one for
channel A and the other for channel B. The Talk buon
enables the microphone signal for the assigned intercom
channels.
Tempest uses an intelligent latching method for TALK
buons. Pressing the TALK buon momentarily will cause
the TALK buon to latch. Pressing and holding the TALK
buon will cause the buon to act as a momentary switch.
Talk tones can be enabled or disabled per MasterBelt. If
enabled, users will here a tone each me the TALK buon
is pressed.
Channel Indicator LEDs A and B
Each Talk buon has two individual LED indicators. Together they surround the
Talk buon. The LEDs will ash blue to indicate which intercom channel, A or
B, has been selected and will illuminate connuously to indicate that “Talk” is
enabled on that channel.
The Channel Indicator LEDs will ash red when the microphone signal is reaching a peak level and is entering into liming.
MasterBelt Display Overview
1. Mode Setting - indicates the mode the MasterBelt is currently
operang in (NORM, SHARE, or SPLIT.)
2. Battery Alert - indicates that the baery alert is enabled or
disabled (shown as enabled).
3. Battery Status - visual indicator of baery level.
4. Battery Time - the operaonal me remaining on the baery.
5. MasterBelt Name - the name assigned to the MasterBelt.
6. Belt Slot/Status - surrounding box indicates a BeltStaon is
logged into that slot.
7. Channel Indicators - available channels and acve channel
shown with surrounding box.
8. Talk Status - TALK is displayed when latched/pressed.
1
2 3 4
5
6
8
7

8Tempest®2400 MasterBelt™
BeltStaon Overview
1- Volume- CH A and CH B
In Operaonal Mode, turning the Volume control adjusts the volume of the
audio. Volume indicators appear on the display during adjustment and are
expressed in Decibels (dB).
The Volume control has an opon to be set to “Volume Press” where it requires
a “press and turn” to adjust the volume level. The “Volume Press” opon can
be adjusted under the “Set Controls” secon of the BeltStaon menu.
Pressing the Volume control in “Dual-listen” mode does nothing. In “Single-
listen” mode, pressing “CH A” enables channel A, and pressing “CH B” enables
channel B . The Volume control has a channel “Delay Switch” opon which
requires the knob to be pressed and held slightly longer in order to switch from
one channel to the other. This feature can be enabled under the “Set Controls”
secon of the BeltStaon menu.
In Menu Mode, turning either Volume control allows the user to scroll the
opons of the current menu screen. Pressing the Volume control selects the
opon.
2- STAGE Buon
The Stage Announce (STAGE) buon has no funconality when a BeltStaon is operang with a MasterBelt.
3- MENU Buon
Pressing MENU while the BeltStaon is in Operaonal mode will select Menu Mode, and the Main Menu screen will be
displayed. Once in Menu Mode, pressing MENU again will act as an escape key and will back out of the current menu screen
moving the user up one level. Pressing the MENU buon while at the Main Menu screen will exit Menu Mode and return
to Operaonal mode. The menu can be locked via a “Menu Lock” feature per BeltStaon.
4- ENTER Buon
The ENTER buon operates dierently depending on the mode of the BeltStaon. In Menu Mode, pressing the ENTER
buon selects the current menu opon and is the same as pressing a Volume control. A menu item is not selected unl the
ENTER buon (or Volume control) is pressed.
The ENTER buon can also acvate Wireless ISO (wireless talk around), providing wireless communicaon isolated from
any connected wired intercom system.
5- LCD
While in Operaonal Mode, the LCD displays the status of the BeltStaon including the name of
the currently communicang MasterBelt, radio strength, baery level, and other data. The LCD
backlight and contrast can be adjusted from the LCD Adjustments menu screen under the LCD/
LED secon of the BeltStaon menu.
6- CALL Buon
The CALL Buon sends call signal to any wireless BeltStaon on the same intercom channel. The Call signal will be routed to
intercom channels indicated by the user’s acve Talk buon(s). Note: The TALK buon must be enabled to send a call signal.
Operaonal Display

9Tempest®2400 MasterBelt™
1- Rubberized Access Cover
The Rubberized Access Cover helps prevent dust, dirt and liquid from entering the BeltStaon
through the USB or the BeltStaon pairing connector. Keep this cover securely closed at all mes
to ensure the best possible seal.
2- USB Mini B Connector
The USB Connector is used to charge the BeltStaon with the supplied wall charger. In addion,
the USB connect is used to update the rmware of the BeltStaon.
3- Pairing Connector
The Pairing Connector is used to pair the MasterBelt to BeltStaons using the supplied 3.5mm
stereo mini connector.
1- Belt Clip
The Belt Clip enables the BeltStaon to be worn on the user’s belt or other clothing
item.
2- Power ON/OFF Buon
The Power ON/OFF buon is used to turn the BeltStaon ON or OFF. Press and
hold the Power ON/OFF buon for two seconds to turn the BeltStaon ON. Press
for four seconds to turn the BeltStaon OFF.
3- Baery Compartment
The Baery Compartment holds either one Tempest Lithium-Polymer rechargeable
baery or (3) standard alkaline AA cells. To remove the baery door, press down on
the thumb markings and pull the baery door toward the boom of the BeltStaon.
To remove baeries from the baery compartment turn the BeltStaon baery
side down and tap the boom of the BeltStaon on the palm of your other hand.
Please be careful to insert alkaline AA baeries according to the marked polarity.
All of the alkaline AA cells face the same direcon. If the baery cover does not t
or close properly, the baery may not be inserted correctly.
4- Headset Connector
The 4-pin XLR male headset connector mates with most Dynamic or Electret headsets that have 4-pin XLR female connectors.
This Headset connector allows a user to communicate in “Dual-listen” or “Single-listen” mode on either intercom channel.
The mic detect circuit (dynamic/electret) will indicate dynamic when it sees a load of 600Ω or less. It will indicate an
electret when it sees 1kΩ or greater. Between 600Ω and 1kΩ is not recommended as it may not accurately detect mic type.

10 Tempest®2400 MasterBelt™
Talk Buon A and B
There are two TALK buons on each BeltStaon, one for
channel A and the other for channel B. The Talk buon
enables the microphone signal for the assigned intercom
channels.
Tempest uses an intelligent latching method for TALK
buons. Pressing the TALK buon momentarily will cause
the TALK buon to latch. Pressing and holding the TALK
buon will cause the buon to act as a momentary switch.
Talk tones can be enabled or disabled per BeltStaon. If
enabled, users will here a tone each me the TALK buon
is pressed.
Channel Indicator LEDs A and B
Each Talk buon has two individual LED indicators. Together they surround the
Talk buon. The LEDs will ash blue to indicate which intercom channel, A or
B, has been selected and will illuminate connuously to indicate that “Talk” is
enabled on that channel.
The Channel Indicator LEDs will ash red when the microphone signal is reaching a peak level and is entering into liming.
BeltStaon Display Overview
1. RSS Indicator - indicates the Radio Signal Strength of the
BeltStaon’s internal radio.
2. Battery Alert - indicates that the baery alert is enabled or
disabled (shown as enabled).
3. Battery Status - visual indicator of baery level.
4. Battery Time - the operaonal me remaining on the baery.
5. MasterBelt Name - the name assigned to the MasterBelt.
6. BeltStation Name - the name assigned to the BeltStaon.
7. Channel Indicators - available channels and acve channel
shown with surrounding box.
8. Talk Status - TALK is displayed when latched/pressed.
1
2 3 4
5
6
8
7

11 Tempest®2400 MasterBelt™
MasterBelt Set-up
Selecng MasterBelt Locaon
Antenna Paern
The Tempest MasterBelt and BeltStaon have the same internal patch antenna located
at the top-end of the unit. It is important to understand the antenna propagaon when
determining the locaon of the MasterBelt during operaon. The MasterBelt and
BeltStaon antenna is a linear polarized omnidireconal antenna. However, due to its
posioning at the top of the BeltStaon, the antenna is aenuated at it’s boom thus
creang a direconal paern.
Fixed Locaon
Despite having no external antenna, the
Tempest MasterBelt can be used in the same
manner as tradional Tempest BaseStaons.
However, there could be an impact on the
system’s range depending on the chosen
locaon and orientaon.
When determining a locaon to place the
MasterBelt, use the same approach used
with Tempest BaseStaons and/or Remote
Transceivers. Be sure that line-of-sight
from MasterBelt to standard BeltStaons is
maintained for opmal performance. Any
obstrucons can cause the RF signal to
become aenuated and diminish range and
performance.
Mobile Operaon
When using the MasterBelt in a mobile applicaon, system range will be less due to body shielding.
Antenna Propagaon
MasterBelt
BeltStaons
MasterBelt
BeltStaons

12 Tempest®2400 MasterBelt™
Baery Charging and Installaon
With the Lithium-Polymer baeries installed in the baery compartment, plug the AC
end of the supplied 5VDC Charger/Power Supply into a standard AC wall outlet. Open the
rubberized access cover on the side of the MasterBelt or BeltStaon and plug the USB end
of the Charger/Power Supply into the USB connector. The Lithium-Polymer baeries will take
approximately 2¾ hours to charge from completely empty to completely full. This me is the
same with the unit turned ON or OFF. A new, fully charged baery should power a Tempest
MasterBelt or BeltStaon for approximately nine hours. Fast charging with the supplied fast
charger requires a temperature range of 32° – 113° F.
Baeries can receive more than 500 charge cycles, and
connue to maintain more than 70% of their power rang. The
Tempest baery indicator will maintain its accuracy as baery
life decreases.
Alternavely, remove the Lithium-Polymer rechargeable baery from the unit and insert it into
the oponal 5-Bay Baery Charger. The Lithium-Polymer baeries will take approximately 2½
hours to charge from completely empty to completely full. See the baery charger manual
for addional details.
The Tempest MasterBelt and BeltStaon Baery Compartment holds either one
Tempest Lithium-Polymer rechargeable baery or three standard alkaline AA cells.
Lithium-Polymer baeries are the primary power source. High quality alkaline AA
cells may be used in situaons where Lithium-Polymer baeries are not available or
are not charged. One Lithium-Polymer baery comes standard with each Tempest
MasterBelt or BeltStaon. Addional Lithium-Polymer baeries may be purchased.
Contact your dealer or distributor to purchase addional baeries. The Lithium-
Polymer baeries supplied with your Tempest Wireless system are warranted for 90
days from the date of purchase.
Lithium-Polymer baeries oer 7+ hours of baery life in a MasterBelt and up to
9 hours of baery life in a BeltStaon. The baeries recharge in approximately 2¾
hours.
Lithium-Polymer baeries ship from the factory with approximately 50% charge. It will not damage the Lithium-Polymer
baeries to use them without charging them rst. This will, however result in shorter run me unl the Lithium-Polymer
baery is fully charged. When possible, charge Lithium-Polymer baeries to full capacity to ensure full baery life prior to
use.
Using (3) alkaline AA baeries can provide up to four hours of baery life. Use only high quality alkaline AA cells. This will
provide enough me to fully charge the Lithium-Polymer baery.
To remove the baery door, press down on the thumb markings and pull the baery door toward the boom of the unit.
To remove baeries from the baery compartment, turn the MasterBelt baery side down and tap the boom of the unit
on the palm of your other hand.
Please be careful to insert alkaline AA baeries according to the marked polarity. All of the alkaline AA cells must be
oriented the same direcon. If the baery cover does not close properly, the baery may not be inserted correctly.

13 Tempest®2400 MasterBelt™
MasterBelt Power ON/OFF
• The Power ON/OFF buon is used to turn the MasterBelt ON or
OFF.
• Press and hold the Power ON/OFF buon for two seconds to turn
the MasterBelt ON.
• Press and hold for four seconds to turn the MasterBelt OFF.
Selecng a Frequency Band
The Tempest MasterBelt 2.4GHz model is approved for license free use in most countries. However, due to dierences
in radio spectrum regulaons, a few countries require that 2.4GHz equipment limit or adjust its RF spectrum operaon.
Always determine if there are country specic frequency restricons that apply and select the required frequency band as
described below. Tempest performs RF frequency adjustment automacally when you select the appropriate frequency
band from the “Tech Menu.” It is only necessary to use this feature if you use Tempest in one of the countries with special
frequency requirements. Otherwise, Band 1 should be used for maximum RF performance.
If the Tempest Wireless system is transported to a country with special requirements, navigate to the Radio Conguraon
screen in the “Tech Menu” to select the appropriate frequency band from the “Set Band” menu screen of the MasterBelt.
Aer changing the frequency band selecon it is necessary to “pair” each BeltStaon with the MasterBelt so the informaon
can be transmied from the MasterBelt to the BeltStaon. See the “Pairing BeltStaons with MasterBelt” secon of this
manual for more informaon on pairing.
MHz MHz Avoid 802.11 b/g
Band Start End Width
1 2400 2480 80 None
2 2400 2450 50 11
3 2423 2473 50 1
4 2431 2480 49 1, 2,
5 2400 2428 28 7, 8, 9, 10, 11
6 2423 2450 27 1, 11
7 2453 2480 27 1, 2, 3, 4, 5, 6, 7

14 Tempest®2400 MasterBelt™
Set Network Number and Lockout Key
The Network Number determines the frequency hopping paern for the MasterBelt and its respecve BeltStaons. This is
a key operaonal parameter and is represented by a number between 0 and 63.
Using dierent conguraons or systems in close proximity can cause interference and diminish performance. Mulple
MasterBelt conguraons within the same proximity should maintain a respectable distance from one another and always
ulize dierent network numbers.
The Lockout Key prevents systems with the same Network Number from trying to communicate with each other and is
represented by a number between 0 and 255. Together, the Network Number and Lockout Key represent more than 16,000
possible combinaons to minimize the possibility of inter-system interference.
The Network Numbers and Lockout Keys for Tempest Wireless are set to factory defaults before leaving the factory. Always
adjust the Network Number and Lockout Key of any Tempest Wireless that are known to operate in close proximity to one
another as described below. Users should conrm these sengs to minimize the opportunity for improper performance
issues.
Failure to set a unique Network Number and Lockout Key may result in poor system performance caused by interference
from another Tempest Wireless system using the same Network Number and Lockout Key. Tempest BeltStaons received
their Network Number and Lockout Key’s from their respecve MasterBelt, therefore it is not possible to manipulate
Network Numbers and Lockout Keys to gain unauthorized access to a communicaon channel.

15 Tempest®2400 MasterBelt™
Pairing BeltStaons to MasterBelt
Pair BeltStaon to MasterBelt:
Conrm that the MasterBelt is powered ON and in Operaonal Mode (not
in Menu Mode) and that the BeltStaon is powered OFF. Conrm that the
MasterBelt’s Network Number and Lockout Key are adjusted as needed. See the
secon on Set Network Number and Lockout Key.
Plug one end of the pairing cable into the MasterBelt and the other end into the
BeltStaon.
The pairing cable is a standard 3.5mm
(1/8 in.) Male to Male stereo patch cord.
Turn the BeltStaon power ON by pressing and holding the BeltStaon Power ON/OFF buon for two seconds. The pairing
process will begin automacally. Watch for the message “Pairing Complete” to appear briey on the BeltStaon display.
The BeltStaon will automacally re-inialize.
Name MasterBelt
Name the MasterBelt with a descripve name. The MasterBelt name can include up to 14 characters. Prior to a name being
assigned, a hexadecimal serial number is displayed as a default.
The MasterBelt name will appear on the LCD Display, on the BeltStaon LCD display, and in the BeltStaon’s menu under
“Select Base.”
To name each MasterBelt:
1. On the MasterBelt press MENU and select “Belt Sengs,” then “Name BeltStaon.”
2. Rotate the Volume control to move the underscore “_” to select the character to be changed.
3. Press ENT and noce the underscore changes to a pointer “Λ” under the selected character.
4. Rotate the Volume control to scroll through the character list. Press ENT to select the new character. Characters always
replace and never insert. Repeat as needed.
5. Press ENT to save the new name aer all characters are complete. Failure to press ENT to save will clear all changes.
6. Press MENU to escape to the Operaon Mode screen.
Naming the BeltStaon works the same as naming the MasterBelt.

16 Tempest®2400 MasterBelt™
Congure BeltStaon Sengs
Name BeltStaons
Naming BeltStaons is the same as naming a MasterBelt. See the “Name MasterBelt” for more informaon on naming BeltStaons.
Adjust Mic Gain
Set the Mic Gain properly to ensure the best audio quality. To set the Mic Gain for the BeltStaon Headset:
1. Press MENU to enter Menu Mode. From the Main Menu, select “Set Controls,” then “Mic Gain.”
2. While at the Mic Gain screen, talk into the headset microphone at a louder than normal level and adjust the Volume control
unl the PEAK LEDs just start to light at the loudest parts of the audio. Press ENT to accept the changes.
Mic Gain can be set in the BeltStaon without acvang the Talk buon. This allows private mic gain adjustment during
live events.
When the Mic Gain is set too high, it is possible to induce feedback or echo. When set too low, words can be clipped by
the low level noise gate or sound too quiet to other listeners. Headsets by dierent manufacturers or dierent models
of headsets will require widely varying Mic Gain sengs. When seng microphone gain, it is best to err toward a seng
that is too low, rather than too high. This will help reduce unwanted echo in the system when that microphone is enabled.
Adjust Sidetone
1. Press MENU to enter Menu Mode. From the Main Menu, select “Set Controls,” then “Mic Gain.”
2. Rotate the Volume knob and scroll to “Belt Sengs” on the display
3. Press ENT
4. Scroll to “Sidetone” and press ENT (or the Volume knob) to select
Sidetone value is expressed in Decibels (dB). You will see a level indicator with a numeric value between -30 dB to -6 dB.
Speak into the headset microphone at a typical speaking level and adjust the sound of your own voice in your headset. Pay
close aenon to the TALK buon LED when speaking into the mic. The LED will light red when clipping is occurring. Once
you’ve determined a proper level, press ENT to accept the changes.
Press MENU to move up one level in the menu tree. Press MENU repeatedly to exit Menu Mode and return to Operaonal
Mode. If no other items are selected, Menu Mode automacally exits and returns to Operaonal Mode aer about three
minutes.
Adjust BeltStaon Slot
The MasterBelt Slot Assignment only aects the order that the MasterBelt Operaonal screen displays the BeltStaon
informaon when the MasterBelt is in the Stac display mode. If the MasterBelt is rounely used as a communicaon port
or for monitoring BeltStaons, it may be more convenient to always have the same user appear in the same posion on the
MasterBelt display. This is a personal preference seng.
In the MasterBelt “Tech Menu,” choose Stac or Dynamic from the “Slot Assignment” screen. Dynamic,the default, will
work without any adjustment, and always displays BeltStaons in alpha-numeric order by name.
Stac will be the preferred choice for users who are using only one MasterBelt and want to ensure that a BeltStaon that is
logged in will always appear in the same locaon (slot) on the MasterBelt display. When selecng Stac slot assignments,
you must also enter the Tech Menu for each BeltStaon and assign each BeltStaon a dierent slot (1 – 5).
