Cocoon HE180040 User manual

Follow these steps to connect your DVR to the internet and view on your smartphone. Note: a broadband
internet connection is required.
A tutorial video of these steps can be found on the Winplus Website www.winplus.com.au
1.Connect your DVR to the Internet
a. Connect all cameras to your DVR as per instructions in user
manual
b. Connect your DVR to your TV or Monitor using an HDMI or
VGA Cable
c. Connect your DVR to your Modem Router using the
Ethernet Cable
d. Turn on your DVR
2.Accessing Main Menu
a. Right click on the Screen to access the Main Menu.
NOTE: The default Login is ‘admin’ and the default password is left blank. You can change the default
settings under Main Menu - Set Up - Users
b. In the Main Menu, go to Set Up and select Network
c. Ensure that ‘Obtain an IP Address Automatically’ is ticked.
d. Click on the ‘Test’ button on the bottom of the screen to check if your DVR is connected to the internet.
e. A message ‘Please Wait’ and ‘OK’ will appear on the screen indicating successful connection.
3.Install and Register the
Cocoon DVR App
a. Download the Cocoon DVR APP from the Apple or Google Play Store and
install on your smartphone
b. Enter a User ID and Password to register in the APP and re-enter the
password providing a valid email address.
NOTE: For User ID and Password, use any letters and numbers to create a unique
6-digit (or above) combination
NOTE: The User ID and Password for the Cocoon DVR App is different to the Login
and Password for your DVR
c. Once you are registered, log into the Cocoon DVR APP
Network Setup Guide
Ethernet LAN Cable Input
HE180040
02/2018
Scan this QR Code on your Android or iOS
phone to nd the Cocoon DVR App

4.Add Your Cocoon DVR to the Cocoon DVR App
a. In the Cocoon DVR APP Main Menu, go to ‘Device Manage’
b. On the bottom Left Hand bar, press and select ‘Add Device’. This will
prompt you to add your DVR’s unique settings
c. Name/Alias: Provide a name for your DVR (e.g. Home, Ofce, etc.)
Connection Mode/Link Mode: Select Cloud (iOS) or P2P (Android)
Cloud ID/UMID Code: Your DVR’s unique ID (see below)
User ID: is the Login for your DVR (Default is ‘admin’)
Password: is the password for your DVR (Default is left blank)
Max Channel/Channels: is 4 for 4 Camera Systems and 8 for 8 Camera
Systems
Stream Type: Select Main
d. Select the ‘+’ button to add your DVR
5.Remote Viewing
a. Return to Main Menu in the Cocoon DVR App.
b. Select Live View (iOS)/ Real Time Monitoring (Android).
c. Select the alias that you have chosen for the DVR to view
d. Select ‘All Device’ to view all cameras.
NOTE: Double tap on the desired camera for a full screen view. Please refer to the included instruction
manual for more viewing options
Adding Cloud ID/UMID to your Smartphone
You can nd your Cocoon DVR’s DEVICE ID by using the mouse
on your DVR and selecting MAIN MENU > INFORMATION >
SYSTEM. This will display two QR Codes. Select the second QR
Code labelled Device ID
a. On your smartphone, add your Cloud ID (Android) or UMID
Code (iOS) by selecting QR thumbnail
b. Your smartphone’s camera will activate
c. Scan the second QR Code on your DVR screen using your
smartphone. NOTE: Your smartphone will beep once QR
Code is scanned successfully
d. Press OK. This will enter the Device ID into the eld
Network Setup Guide HE180040
02/2018
