Code Blue CB 1 Series Service manual

800.205.7186 •www.codeblue.com
Administrator Guide
Installation | Configuration | Operation | Troubleshooting
CB 1 Series
CB 1-e
CB 1-s
CB 1 Series with Public Address
CB 1-w with Solar/GSM/Wireless

Code Blue •259 Hedcor Street •Holland, MI 49423 USA •800.205.7186 •www.codeblue.com GU-157-AApage 2 of 76
CB 1 Series
Administrator Guide
WARNING
ONLY QUALIFIED PERSONNEL SHOULD INSTALL THESE UNITS. THE INSTALLATION
SHOULD CONFORM TO ALL LOCAL CODES. IN SOME COUNTRIES, A CERTIFIED ELECTRI-
CIAN MAY BE REQUIRED.
NOTICE TO USERS
Copyright © Code Blue Corporation. All rights reserved. This guide or software described herein, in
whole or part, shall not be reproduced, translated or reduced to any machine-readable form without
prior written approval from Code Blue Corporation.
CODE BLUE CORPORATION PROVIDES NO WARRANTY WITH REGARD TO THIS GUIDE, THE
SOFTWARE OR OTHER INFORMATION CONTAINED HEREIN AND HEREBY EXPRESSLY DIS-
CLAIMS ANY IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR ANY PARTICU-
LAR PURPOSE WITH REGARD TO THIS GUIDE, THE SOFTWARE OR SUCH OTHER INFORMA-
TION. IN NO EVENT SHALL CODE BLUE CORPORATION BE LIABLE FOR ANY INCIDENTAL,
CONSEQUENTIAL, OR SPECIAL DAMAGES, WHETHER BASED ON TORT, CONTRACT, OR
OTHERWISE, ARISING OUT OF OR IN CONNECTIONS WITH THIS GUIDE, THE SOFTWARE
OR OTHER INFORMATION CONTAINED HEREIN OR THE USE THEREOF.
Code Blue Corporation reserves the right to make any modications to this guide or the information
contained herein at any time without notice. The software described herein may also be governed
by the terms of a separate user license agreement.
Code Blue®is a registered trademark of Code Blue Corporation.

Code Blue •259 Hedcor Street •Holland, MI 49423 USA •800.205.7186 •www.codeblue.com GU-157-AApage 3 of 76
CB 1 Series
Administrator Guide
Table of Contents
(NOTE: Phone programming instructions can be found in the IP5000 and IA4100 Guides.)
Section Page
2 Introduction.................................................................................... 5
3 Getting Started............................................................................... 7
4 Spare Parts..................................................................................... 9
5 Power Requirements.....................................................................12
6 Software Conguration.................................................................14
7 CB 1-e Low Voltage Exploded View.............................................15
8 CB 1-e High Voltage Exploded View............................................16
9 CB 1-s Low Voltage Exploded View.............................................17
10 CB 1-s High Voltage Exploded View............................................18
11 CB 1-s with Dual Faceplates Low Voltage Exploded View.........19
12 CB 1-s with Dual Faceplates High Voltage Exploded View.......20
13 CB 1-w Exploded View..................................................................21
14 CB 1-e and CB 1-s Installation Instructions................................22
15 CB 1 Series Tower Base Gasket Installation Instructions.........24
16 CB 1-s with AED Housing Installation Instructions....................26
17 CB 1-w Installation Instructions...................................................28
18 Cellular Retro Instructions............................................................31
19 CB 1 Series Anchor Bolt Installation Instructions......................36
20 Overhead Camera Mount Installation Instructions.....................37
21 Line Power Installation Instructions............................................39
22 CB 1 Series Public Address Installation Instructions................40
23 NightCharge®Installation Instructions........................................42
24 Solar and WindAssist™ Installation Instructions.......................44
25 AED Access Instructions..............................................................48
26 S-1000/S-1050 Installation Instructions.......................................49
27 LED Retro Area Light Installation Instructions...........................51
28 PoE Installation Instructions........................................................55
29 Blank Ring Installation Instructions............................................56
30 CB 1 Series Deck Mount Installation Instructions......................57
31 CB 1-e and CB 1-s 24V or Multi-Tap Power Brick Wiring (prior 2015)..58

Code Blue •259 Hedcor Street •Holland, MI 49423 USA •800.205.7186 •www.codeblue.com GU-157-AApage 4 of 76
CB 1 Series
Administrator Guide
32 CB 1-e and CB 1-s 24V or Multi-Tap Power Brick Wiring (current).....59
33 CB 1-e and CB 1-s Standard Wiring (with 24V Fuse Block)........................60
34 CB 1-e and CB 1-s Standard Wiring (with Hammond Transformer)...............61
35 CB 1-e 120V Standard Wiring Diagram (with Triad Transformer)................62
36 CB 1 Series NightCharge Wiring......................................................63
37 CB 1 Series with Public Address Wiring.........................................64
38 CB 1-w Standard Wiring....................................................................66
39 GSM Wireless Wiring Diagram.........................................................67
40 CB 1-s with AED, Public Address and IP Wireless.........................68
41 CB 1-s with AED Wiring....................................................................69
42 Multi Tap Transformer Wiring...........................................................70
43 Maintenance Schedule......................................................................71
44 CB 1-s with AED Access and Maintenance.....................................73
45 Locating Unit Serial Numbers..........................................................74
46 Warranty.............................................................................................75
47 Download Information......................................................................76

Code Blue •259 Hedcor Street •Holland, MI 49423 USA •800.205.7186 •www.codeblue.com GU-157-AApage 5 of 76
CB 1 Series
Administrator Guide
2 Introduction
Thank you for choosing the CB 1 Series for your Code Blue application.
The CB 1 Series of products are the original Code Blue pedestal units that set the industry
standard for rugged construction, full feature availability and high visibility. The CB 1 Series is easily
recognized throughout a full 360-degree area. The user friendly lighted faceplate and the integral
area light ensure rapid location in an open environment. The high output strobe is easily identiable
by security when activated.
The CB 1 Series is an excellent choice for walkways, parks, college and commercial campus areas,
open landscape areas and anywhere a freestanding pedestal unit is required.
The exclusive analog InterAct and VoIP speakerphones are designed for maximum reliability,
vandal resistance, auxiliary functions, mass notication control, and fault monitoring and reporting
capability. (See IA4100 or IP5000 guides for more information.)
Our unmistakable craftsmanship makes our Help Points®the most rugged on the market,
withstanding the punishment of natural and man-made disasters. With durable construction, our
pedestal units can meet any requirement or purpose. CB 1 Series units have a rugged steel
construction, shatterproof Lexan Lens, industrial engineering grade reective graphics and weather,
UV and grafti resistant paint. They are illuminated by a high-powered, 270 lumens/92 candela LED
blue beacon/strobe.
Other options include:
• IP and analog phones
• Long-life LED area light
• Low power consumption LED faceplate light
• Camera and card reader openings
• Temperature controlled automated external debrillator (AED) housing
• 360° Public Address Speaker (PAS)
• Color IP camera
• Custom cut-out stainless steel plates
• Mounting rings
• Overhead Camera Mount
• Second opening

Code Blue •259 Hedcor Street •Holland, MI 49423 USA •800.205.7186 •www.codeblue.com GU-157-AApage 6 of 76
CB 1 Series
Administrator Guide
This guide contains all of the CB 1 Series information for the CB 1-e, CB 1-s and the CB 1-w with
WindAssist™. This guide contains a general overview of the CB 1 Series options and its application,
installation and wiring.
CB 1-s with
Public Address
CB 1-s with
AED Housing
CB 1-w with
WindAssist
CB 1-e
CB 1-s
CB 1-s with
Dual Faceplates

Code Blue •259 Hedcor Street •Holland, MI 49423 USA •800.205.7186 •www.codeblue.com GU-157-AApage 7 of 76
CB 1 Series
Administrator Guide
3 Getting Started
Basic Install Instructions
1. EIA/TIA, ANSI, CSA and BICSI cabling or similar standards shall be adhered to for proper
operation of Code Blue communication devices connected to copper or ber infrastructures.
Communications cable and electrical cable in the same conduit is not an acceptable instal-
lation and shall not be supported. Analog phones require a minimum of 23mA for proper
operation (26-29mA recommended).
2. Each analog speakerphone requires its own phone line or PBX extension. Multiple units
shall not be supported.
3. Speakerphones require programming before operation. Consult the User Guide or Admin-
istrator Guide enclosed with the unit or visit www.codeblue.com > Support > Downloads to
read or download manuals.
4. If you are installing IP speakerphones, please read the appropriate manuals and consult
with your Network Administrator.
5. Size electrical wiring based on length of run.
6. Consult the enclosed document packet for internal wiring instructions.
What’s Included
Quantity Part Description
1 Anchor Bolt Kit (4 L-Bolts, 8 Washers, 4 Hex Nuts, 1 Cardboard Template)
1 Security Bit
1 Enclosure (CB 1-s, CB 1-w (Solar), CB 1-e)
2Access Door Screws
2 Key fobs – CB1-s w/AED only
1 URL listing sheet of Installation, Programming, Wiring & Warranty locations
255AMP Batteries (Solar Only)
1 55AMP Battery (NightCharge®Only)
1 PAS Top (PAS Option Only)
1 Dome Top Assembly (Solar not Included)
1 WindAssist™ (Solar Option Only)

Code Blue •259 Hedcor Street •Holland, MI 49423 USA •800.205.7186 •www.codeblue.com GU-157-AApage 8 of 76
CB 1 Series
Administrator Guide
CB 1-e and CB 1-s Tools Required
1. Ladder to reach the top of the units
2. Drill and security bit for removing and inserting security screws on phone, dome top and
access door
3. 11/8 socket set and extension for installing anchor bolts or Deck Mount Kits
4. 3/8 socket set to mount the mounting plate containing the new toroid transformer (PAS only)
5. Phillips head screwdriver and at head screwdriver
6. 1/2-inch wrench for NightCharge®batteries, if required
CB 1-s with AED Tools Required
1. Ladder to reach the top of the units
2. Drill and security bit for removing and inserting security screws on phone, dome top and
access door
3. 11/8 socket set and extension for installing anchor bolts
4. Phillips head screwdriver and at head screwdriver
CB 1-w with WindAssist™ Tools Required
1. Ladder to reach the top of the units
2. Drill and security bit for removing and inserting security screws on phone, dome top and
access door
3. 11/8 socket set and extension for installing anchor bolts
4. Phillips head screwdriver and at head screwdriver
5. 1/2-inch wrench for solar batteries

Code Blue •259 Hedcor Street •Holland, MI 49423 USA •800.205.7186 •www.codeblue.com GU-157-AApage 9 of 76
CB 1 Series
Administrator Guide
4 Spare Parts
CB 1-e
Part Part Number
LED Strobe Light 40159
Dome Top Lens 41402
LED Faceplate Light 40196
Faceplate Screws 41544 (6pk)
Dome Top Screws 41500 (3pk)
Access Door Screws 41545 (2pk)
Manifold R/B 5-way 40101
Analog Surge Suppressor 41471
IP Surge Suppressor 41421
CB 1-s with Dual Faceplates
Part Part Number
LED Strobe Light 40159
LED Area Light 41539
Dome Top Lens 41402
LED Faceplate Light 40196
Faceplate Screws 41544 (6pk)
Dome Top Screws 41500 (3pk)
Access Door Screws 41545 (2pk)
Blank Lexan Plate 40067
Manifold R/B 5-way 40101
Analog Surge Suppressor 41471
IP Surge Suppressor 41421

Code Blue •259 Hedcor Street •Holland, MI 49423 USA •800.205.7186 •www.codeblue.com GU-157-AApage 10 of 76
CB 1 Series
Administrator Guide
CB 1-s
Part Part Number
LED Strobe Light 40159
Dome Top Lens 41402
LED Area Light 41539
LED Faceplate Light 40196
Faceplate Screws 41544 (6pk)
Dome Top Screws 41500 (3pk)
Access Door Screws 41545 (2pk)
Manifold R/B 5-way 40101
Analog Surge Suppressor 41471
IP Surge Suppressor 41421
CB 1-s with AED Housing
Part Part Number
LED Strobe Light 40159
LED Area Light 41539
Dome Top Lens 41402
LED Faceplate Light 40196
Faceplate Screws 41544 (6pk)
Dome Top Screws 41500 (3pk)
Access Door Screws 41545 (2pk)
Manifold R/B 5-way 40101
Analog Surge Suppressor 41471
IP Surge Suppressor 41421
AED Housing Door Release Mechanism 41104
AED Housing Heater 41105
AED Housing Thermostat 41106
AED Housing Door Controller 41107
AED Housing Retro Fit Kit 40012

Code Blue •259 Hedcor Street •Holland, MI 49423 USA •800.205.7186 •www.codeblue.com GU-157-AApage 11 of 76
CB 1 Series
Administrator Guide
CB 1-w
Part Part Number
LED Strobe Light 40159
Dome Top Lens 41402
LED Faceplate Light 40196
Faceplate Screws 41544 (6pk)
Dome Top Screws 41500 (3pk)
Access Door Screws 41545 (2pk)
Solar Batteries (2) 41537
GSM 40023
CB 1-e and CB 1-s Additional Options
Part Part Number
GSM 40022
NightCharge®45005
NightCharge Batteries (1) 41537
Public Address Top Need Color for Part#
Overhead Camera Mount Need Color for Part#
Multi Tap Transformer (powers accessories) 120V, 240V, 277V, 347V 40104
120V Triad Transformer (will not power accessories) 41247
Directory Plate Assembly 40056
Color IP Camera with Mounting Plate 41420
Blank Lexan Plate Assembly 40067
Service Plate - Lexan w/graphics (This Location Being Serviced) 40208
Blank Mounting Rings – 5.25 in, 5.25 in with Antenna post, 16.5 in Need Color for Part#
Deck Mount Kit 40215

Code Blue •259 Hedcor Street •Holland, MI 49423 USA •800.205.7186 •www.codeblue.com GU-157-AApage 12 of 76
CB 1 Series
Administrator Guide
5 Power Requirements
(The following power requirements include the 9 Series and also ALL OTHER Code Blue units.)

Code Blue •259 Hedcor Street •Holland, MI 49423 USA •800.205.7186 •www.codeblue.com GU-157-AApage 13 of 76
CB 1 Series
Administrator Guide

Code Blue •259 Hedcor Street •Holland, MI 49423 USA •800.205.7186 •www.codeblue.com GU-157-AApage 14 of 76
CB 1 Series
Administrator Guide
6 Software Configuration
Blue Alert® MNS Software
Blue Alert MNS (Mass Notication Software) lls a need in the marketplace for an incident response
solution that is both comprehensive and cost-effective, while also providing an efcient way to detect
and respond. The advanced mass notication system allows responders to deliver multi-layered
emergency notications via a wide range of platforms, including email, text message (SMS), emer-
gency phones, public address speakers, social media, desktop alerts and more, quickly informing
and directing people in emergency situations.
Blue Alert® EMS
Blue Alert EMS is an advanced software solution that handles all incoming events effectively by re-
motely controlling emergency communication devices with an easy-to-use Graphical User Interface
(GUI). You also will have the ability to open gates and AED access doors, turn LED beacon/strobes
on or off, transfer calls to Public Address Systems to make area wide announcements and incor-
porate other ancillary devices and applications while the system securely archives data for future
reference.
ToolVox®
A sophisticated emergency management platform for your blue light phone network, ToolVox offers
unique real-time monitoring and provisioning options for emergency phones and public address
speakers, effectively acting as a hub for connecting Help Points®and other Code Blue devices. Us-
ing our proprietary incident response software, Blue Alert®MNS and EMS, you can send alerts via
outdoor platforms, such as blue light phones and public address speakers. It also provides connec-
tions to PBX, public telephone (PSTN) and Internet (ISP) networks, in addition to third party security
platforms.

Code Blue •259 Hedcor Street •Holland, MI 49423 USA •800.205.7186 •www.codeblue.com GU-157-AApage 15 of 76
CB 1 Series
Administrator Guide
7 CB 1-e Low Voltage Exploded View
DISCLAIMER: Product design and component use subject to change without notice. Product shown reasonably represents current offering and
is intended to assist in component identication. Reference the model and serial number from the unit ID tag and contact manufacturer to conrm
replacement part version and availability.
BALL # PART # DESCRIPTION
1a 40260 Dome Top Kit with Strobe
1b 40165 Dome Top Kit w/o Strobe
1c 40166 Dome Top Kit w/o Strobe & Active Vent
2 41402 Dome Top Lens
3 40159 LED Blue Beacon Strobe
4 41500 Button Head Security Screws (3 pk)
5 CALL Standard / Custom Graphic
6 41471 Analog Surge Suppressor
6 41421 IP Surge Suppressor
7 41548 LED Faceplate Light
8 50001 Single Button IA4100 Analog Phone – PUSH FOR HELP
8 50002 Double Button IA4100 Analog Phone – PUSH FOR HELP
8 50003 Keypad IA4100 Analog Phone – PUSH FOR HELP
8 50004 Single Button IA4100 Analog Phone – EMERGENCY
8 50005 Double Button IA4100 Analog Phone – EMERGENCY
8 50006 Keypad IA4100 Analog Phone – EMERGENCY
8 50007 Single Button IA4100 Analog Phone – EMERGENCY/EMERGENCIA
8 50008 Double Button IA4100 Analog Phone – EMERGENCY/EMERGENCIA
8 50009 Keypad IA4100 Analog Phone – EMERGENCY/EMERGENCIA
8 50101 Single Button IP5000 VoIP Phone – PUSH FOR HELP
8 50102 Double Button IP5000 VoIP Phone – PUSH FOR HELP
8 50103 Keypad IP5000 VoIP Phone – PUSH FOR HELP
8 50104 Single Button IP5000 VoIP Phone – EMERGENCY
8 50105 Double Button IP5000 VoIP Phone – EMERGENCY
8 50106 Keypad IP5000 VoIP Phone – EMERGENCY
8 50107 Single Button IP5000 VoIP Phone – EMERGENCY/EMERGENCIA
8 50108 Double Button IP5000 VoIP Phone – EMERGENCY/EMERGENCIA
8 50109 Keypad IP5000 VoIP Phone – EMERGENCY/EMERGENCIA
9 41544 Faceplate Security Screw 10x24 (6 pk)
10 41700 24V Fuse Block
11 41545 Access Door Security Screws (2 pk)
12 40357 Bezel Assembly IA4100 Analog Phone – PUSH FOR HELP
12 40407 Bezel Assembly IA4100 Analog Phone – EMERGENCY
12 40408 Bezel Assembly IA4100 Analog Phone – EMERGENCY/EMERGENCIA
12 40313 Bezel Assembly IP5000 VoIP Phone – PUSH FOR HELP
12 40405 Bezel Assembly IP5000 VoIP Phone – EMERGENCY
12 40406 Bezel Assembly IP5000 VoIP Phone – EMERGENCY/EMERGENCIA
2
4
1a
3
5
7
8
9
12
6
10
11
1b
1c

Code Blue •259 Hedcor Street •Holland, MI 49423 USA •800.205.7186 •www.codeblue.com GU-157-AApage 16 of 76
CB 1 Series
Administrator Guide
8 CB 1-e High Voltage Exploded View
DISCLAIMER: Product design and component use subject to change without notice. Product shown reasonably represents current offering and
is intended to assist in component identication. Reference the model and serial number from the unit ID tag and contact manufacturer to conrm
replacement part version and availability.
BALL # PART # DESCRIPTION
1a 40260 Dome Top Kit with Strobe
1b 40165 Dome Top Kit w/o Strobe
1c 40166 Dome Top Kit w/o Strobe & Active Vent
2 41402 Dome Top Lens
3 40159 LED Blue Beacon Strobe
4 41500 Button Head Security Screws (3 pk)
5 CALL Standard / Custom Graphic
6 41471 Analog Surge Suppressor
6 41421 IP Surge Suppressor
7 41548 LED Faceplate Light
8 50001 Single Button IA4100 Analog Phone – PUSH FOR HELP
8 50002 Double Button IA4100 Analog Phone – PUSH FOR HELP
8 50003 Keypad IA4100 Analog Phone – PUSH FOR HELP
8 50004 Single Button IA4100 Analog Phone – EMERGENCY
8 50005 Double Button IA4100 Analog Phone – EMERGENCY
8 50006 Keypad IA4100 Analog Phone – EMERGENCY
8 50007 Single Button IA4100 Analog Phone – EMERGENCY/EMERGENCIA
8 50008 Double Button IA4100 Analog Phone – EMERGENCY/EMERGENCIA
8 50009 Keypad IA4100 Analog Phone – EMERGENCY/EMERGENCIA
8 50101 Single Button IP5000 VoIP Phone – PUSH FOR HELP
8 50102 Double Button IP5000 VoIP Phone – PUSH FOR HELP
8 50103 Keypad IP5000 VoIP Phone – PUSH FOR HELP
8 50104 Single Button IP5000 VoIP Phone – EMERGENCY
8 50105 Double Button IP5000 VoIP Phone – EMERGENCY
8 50106 Keypad IP5000 VoIP Phone – EMERGENCY
8 50107 Single Button IP5000 VoIP Phone – EMERGENCY/EMERGENCIA
8 50108 Double Button IP5000 VoIP Phone – EMERGENCY/EMERGENCIA
8 50109 Keypad IP5000 VoIP Phone – EMERGENCY/EMERGENCIA
9 41544 Faceplate Security Screw 10x24 (6 pk)
10 40104 Power Brick 120V, 240V, 277V, 347V Option
10 45003 NightCharge®Option
11 41545 Access Door Security Screws (2 pk)
12 40357 Bezel Assembly IA4100 Analog Phone – PUSH FOR HELP
12 40407 Bezel Assembly IA4100 Analog Phone – EMERGENCY
12 40408 Bezel Assembly IA4100 Analog Phone – EMERGENCY/EMERGENCIA
12 40313 Bezel Assembly IP5000 VoIP Phone – PUSH FOR HELP
12 40405 Bezel Assembly IP5000 VoIP Phone – EMERGENCY
12 40406 Bezel Assembly IP5000 VoIP Phone – EMERGENCY/EMERGENCIA
2
4
1a
3
7
8
9
12
11
5
1b
1c
10
6
10

Code Blue •259 Hedcor Street •Holland, MI 49423 USA •800.205.7186 •www.codeblue.com GU-157-AApage 17 of 76
CB 1 Series
Administrator Guide
9 CB 1-s Low Voltage Exploded View
DISCLAIMER: Product design and component use subject to change without notice. Product shown reasonably represents current offering and
is intended to assist in component identication. Reference the model and serial number from the unit ID tag and contact manufacturer to conrm
replacement part version and availability.
BALL # PART # DESCRIPTION
1a 40260 Dome Top Kit with Strobe
1b 40165 Dome Top Kit w/o Strobe
1c 40166 Dome Top Kit w/o Strobe & Active Vent
2 41402 Dome Top Lens
3 40159 LED Blue Beacon Strobe
4 41500 Button Head Security Screws (3 pk)
5 40393 Reective Disk
6 41539 LED Area Light
7 41410 HID Lens
8 CALL Standard / Custom Graphic
9 41471 Analog Surge Suppressor
9 41421 IP Surge Suppressor
10 41548 LED Faceplate Light
11 50001 Single Button IA4100 Analog Phone – PUSH FOR HELP
11 50002 Double Button IA4100 Analog Phone – PUSH FOR HELP
11 50003 Keypad IA4100 Analog Phone – PUSH FOR HELP
11 50004 Single Button IA4100 Analog Phone – EMERGENCY
11 50005 Double Button IA4100 Analog Phone – EMERGENCY
11 50006 Keypad IA4100 Analog Phone – EMERGENCY
11 50007 Single Button IA4100 Analog Phone – EMERGENCY/EMERGENCIA
11 50008 Double Button IA4100 Analog Phone – EMERGENCY/EMERGENCIA
11 50009 Keypad IA4100 Analog Phone – EMERGENCY/EMERGENCIA
11 50101 Single Button IP5000 VoIP Phone – PUSH FOR HELP
11 50102 Double Button IP5000 VoIP Phone – PUSH FOR HELP
11 50103 Keypad IP5000 VoIP Phone – PUSH FOR HELP
11 50104 Single Button IP5000 VoIP Phone – EMERGENCY
11 50105 Double Button IP5000 VoIP Phone – EMERGENCY
11 50106 Keypad IP5000 VoIP Phone – EMERGENCY
11 50107 Single Button IP5000 VoIP Phone – EMERGENCY/EMERGENCIA
11 50108 Double Button IP5000 VoIP Phone – EMERGENCY/EMERGENCIA
11 50109 Keypad IP5000 VoIP Phone – EMERGENCY/EMERGENCIA
12 41544 Faceplate Security Screw 10x24 (6 pk)
13 41700 24V Fuse Block
14 41545 Access Door Security Screws (2 pk)
15 40357 Bezel Assembly IA4100 Analog Phone – PUSH FOR HELP
15 40407 Bezel Assembly IA4100 Analog Phone – EMERGENCY
15 40408 Bezel Assembly IA4100 Analog Phone – EMERGENCY/EMERGENCIA
15 40313 Bezel Assembly IP5000 VoIP Phone – PUSH FOR HELP
15 40405 Bezel Assembly IP5000 VoIP Phone – EMERGENCY
15 40406 Bezel Assembly IP5000 VoIP Phone – EMERGENCY/EMERGENCIA
2
4
1a
3
7
9
5
6
7
8
10
11
12
15
9
13
14
1b
1c

Code Blue •259 Hedcor Street •Holland, MI 49423 USA •800.205.7186 •www.codeblue.com GU-157-AApage 18 of 76
CB 1 Series
Administrator Guide
10 CB 1-s High Voltage Exploded View
DISCLAIMER: Product design and component use subject to change without notice. Product shown reasonably represents current offering and
is intended to assist in component identication. Reference the model and serial number from the unit ID tag and contact manufacturer to conrm
replacement part version and availability.
BALL # PART # DESCRIPTION
1a 40260 Dome Top Kit with Strobe
1b 40165 Dome Top Kit w/o Strobe
1c 40166 Dome Top Kit w/o Strobe & Active Vent
2 41402 Dome Top Lens
3 40159 LED Blue Beacon Strobe
4 41500 Button Head Security Screws (3 pk)
5 40393 Reective Disk
6 41539 LED Area Light
7 41410 HID Lens
8 CALL Standard / Custom Graphic
9 41471 Analog Surge Suppressor
9 41421 IP Surge Suppressor
10 41548 LED Faceplate Light
11 50001 Single Button IA4100 Analog Phone – PUSH FOR HELP
11 50002 Double Button IA4100 Analog Phone – PUSH FOR HELP
11 50003 Keypad IA4100 Analog Phone – PUSH FOR HELP
11 50004 Single Button IA4100 Analog Phone – EMERGENCY
11 50005 Double Button IA4100 Analog Phone – EMERGENCY
11 50006 Keypad IA4100 Analog Phone – EMERGENCY
11 50007 Single Button IA4100 Analog Phone – EMERGENCY/EMERGENCIA
11 50008 Double Button IA4100 Analog Phone – EMERGENCY/EMERGENCIA
11 50009 Keypad IA4100 Analog Phone – EMERGENCY/EMERGENCIA
11 50101 Single Button IP5000 VoIP Phone – PUSH FOR HELP
11 50102 Double Button IP5000 VoIP Phone – PUSH FOR HELP
11 50103 Keypad IP5000 VoIP Phone – PUSH FOR HELP
11 50104 Single Button IP5000 VoIP Phone – EMERGENCY
11 50105 Double Button IP5000 VoIP Phone – EMERGENCY
11 50106 Keypad IP5000 VoIP Phone – EMERGENCY
11 50107 Single Button IP5000 VoIP Phone – EMERGENCY/EMERGENCIA
11 50108 Double Button IP5000 VoIP Phone – EMERGENCY/EMERGENCIA
11 50109 Keypad IP5000 VoIP Phone – EMERGENCY/EMERGENCIA
12 41544 Faceplate Security Screw 10x24 (6 pk)
13 40104 Power Brick 120V, 240V, 277V, 347V Option
13 45005 NightCharge®Option
14 41545 Access Door Security Screws (2 pk)
15 40357 Bezel Assembly IA4100 Analog Phone – PUSH FOR HELP
15 40407 Bezel Assembly IA4100 Analog Phone – EMERGENCY
15 40408 Bezel Assembly IA4100 Analog Phone – EMERGENCY/EMERGENCIA
15 40313 Bezel Assembly IP5000 VoIP Phone – PUSH FOR HELP
15 40405 Bezel Assembly IP5000 VoIP Phone – EMERGENCY
15 40406 Bezel Assembly IP5000 VoIP Phone – EMERGENCY/EMERGENCIA
2
4
5
6
7
10
11
3
15
12
14
9
13
8
1c 1a
1b
13

Code Blue •259 Hedcor Street •Holland, MI 49423 USA •800.205.7186 •www.codeblue.com GU-157-AApage 19 of 76
CB 1 Series
Administrator Guide
11 CB 1-s with Dual Faceplates Low Voltage Exploded View
DISCLAIMER: Product design and component use subject to change without notice. Product shown reasonably represents current offering and
is intended to assist in component identication. Reference the model and serial number from the unit ID tag and contact manufacturer to conrm
replacement part version and availability.
BALL # PART # DESCRIPTION
1a 40260 Dome Top Kit with Strobe
1b 40165 Dome Top Kit w/o Strobe
1c 40166 Dome Top Kit w/o Strobe & Active Vent
2 41402 Dome Top Lens
3 40159 LED Blue Beacon Strobe
4 41500 Button Head Security Screws (3 pk)
5 40393 Reective Disk
6 41539 LED Area Light
7 41410 HID Lens
8 CALL Standard / Custom Graphic
9 41471 Analog Surge Suppressor
9 41421 IP Surge Suppressor
10 41548 LED Faceplate Light
11 50001 Single Button IA4100 Analog Phone – PUSH FOR HELP
11 50002 Double Button IA4100 Analog Phone – PUSH FOR HELP
11 50003 Keypad IA4100 Analog Phone – PUSH FOR HELP
11 50004 Single Button IA4100 Analog Phone – EMERGENCY
11 50005 Double Button IA4100 Analog Phone – EMERGENCY
11 50006 Keypad IA4100 Analog Phone – EMERGENCY
11 50007 Single Button IA4100 Analog Phone – EMERGENCY/EMERGENCIA
11 50008 Double Button IA4100 Analog Phone – EMERGENCY/EMERGENCIA
11 50009 Keypad IA4100 Analog Phone – EMERGENCY/EMERGENCIA
11 50101 Single Button IP5000 VoIP Phone – PUSH FOR HELP
11 50102 Double Button IP5000 VoIP Phone – PUSH FOR HELP
11 50103 Keypad IP5000 VoIP Phone – PUSH FOR HELP
11 50104 Single Button IP5000 VoIP Phone – EMERGENCY
11 50105 Double Button IP5000 VoIP Phone – EMERGENCY
11 50106 Keypad IP5000 VoIP Phone – EMERGENCY
11 50107 Single Button IP5000 VoIP Phone – EMERGENCY/EMERGENCIA
11 50108 Double Button IP5000 VoIP Phone – EMERGENCY/EMERGENCIA
11 50109 Keypad IP5000 VoIP Phone – EMERGENCY/EMERGENCIA
12 41544 Faceplate Security Screw 10x24 (6 pk)
13 41700 24V Fuse Block
14 41545 Access Door Security Screws (2 pk)
15 40357 Bezel Assembly IA4100 Analog Phone – PUSH FOR HELP
15 40407 Bezel Assembly IA4100 Analog Phone – EMERGENCY
15 40408 Bezel Assembly IA4100 Analog Phone – EMERGENCY/EMERGENCIA
15 40313 Bezel Assembly IP5000 VoIP Phone – PUSH FOR HELP
15 40405 Bezel Assembly IP5000 VoIP Phone – EMERGENCY
15 40406 Bezel Assembly IP5000 VoIP Phone – EMERGENCY/EMERGENCIA
2
4
5
6
7
8
10
11
3
15
12
14
9
1c 1a
1b
7
13

Code Blue •259 Hedcor Street •Holland, MI 49423 USA •800.205.7186 •www.codeblue.com GU-157-AApage 20 of 76
CB 1 Series
Administrator Guide
12 CB 1-s with Dual Faceplates High Voltage Exploded View
DISCLAIMER: Product design and component use subject to change without notice. Product shown reasonably represents current offering and
is intended to assist in component identication. Reference the model and serial number from the unit ID tag and contact manufacturer to conrm
replacement part version and availability.
BALL # PART # DESCRIPTION
1a 40260 Dome Top Kit with Strobe
1b 40165 Dome Top Kit w/o Strobe
1c 40166 Dome Top Kit w/o Strobe & Active Vent
2 41402 Dome Top Lens
3 40159 LED Blue Beacon Strobe
4 41500 Button Head Security Screws (3 pk)
5 40393 Reective Disk
6 41539 LED Area Light
7 41410 HID Lens
8 CALL Standard / Custom Graphic
9 41471 Analog Surge Suppressor
9 41421 IP Surge Suppressor
10 41548 LED Faceplate Light
11 50001 Single Button IA4100 Analog Phone – PUSH FOR HELP
11 50002 Double Button IA4100 Analog Phone – PUSH FOR HELP
11 50003 Keypad IA4100 Analog Phone – PUSH FOR HELP
11 50004 Single Button IA4100 Analog Phone – EMERGENCY
11 50005 Double Button IA4100 Analog Phone – EMERGENCY
11 50006 Keypad IA4100 Analog Phone – EMERGENCY
11 50007 Single Button IA4100 Analog Phone – EMERGENCY/EMERGENCIA
11 50008 Double Button IA4100 Analog Phone – EMERGENCY/EMERGENCIA
11 50009 Keypad IA4100 Analog Phone – EMERGENCY/EMERGENCIA
11 50101 Single Button IP5000 VoIP Phone – PUSH FOR HELP
11 50102 Double Button IP5000 VoIP Phone – PUSH FOR HELP
11 50103 Keypad IP5000 VoIP Phone – PUSH FOR HELP
11 50104 Single Button IP5000 VoIP Phone – EMERGENCY
11 50105 Double Button IP5000 VoIP Phone – EMERGENCY
11 50106 Keypad IP5000 VoIP Phone – EMERGENCY
11 50107 Single Button IP5000 VoIP Phone – EMERGENCY/EMERGENCIA
11 50108 Double Button IP5000 VoIP Phone – EMERGENCY/EMERGENCIA
11 50109 Keypad IP5000 VoIP Phone – EMERGENCY/EMERGENCIA
12 41544 Faceplate Security Screw 10x24 (6 pk)
13 40104 Power Brick 120V, 240V, 277V, 347V Option
13 45005 NightCharge®Option
14 41545 Access Door Security Screws (2 pk)
15 40357 Bezel Assembly IA4100 Analog Phone – PUSH FOR HELP
15 40407 Bezel Assembly IA4100 Analog Phone – EMERGENCY
15 40408 Bezel Assembly IA4100 Analog Phone – EMERGENCY/EMERGENCIA
15 40313 Bezel Assembly IP5000 VoIP Phone – PUSH FOR HELP
15 40405 Bezel Assembly IP5000 VoIP Phone – EMERGENCY
15 40406 Bezel Assembly IP5000 VoIP Phone – EMERGENCY/EMERGENCIA
2
4
5
6
7
10
11
3
15
12
14
9
13
8
1c 1a
1b
13
