Code Blue CB 2 Series Service manual

800.205.7186 •www.codeblue.com
Administrator Guide
Installation & Setup
CB 2 Series
CB 2-e
CB 2-e with AED Housing
CB 2-e with Public Address
CB 2-s

Code Blue •259 Hedcor Street •Holland, MI 49423 USA •800.205.7186 •www.codeblue.com GU-149-Bpage 2 of 33
CB 2 Series
Administrator Guide
Table of Contents
Section Page
2 Introduction....................................................................................3
3 Getting Started...............................................................................4
3.1 CB 2-e Replacement Parts List............................................5
3.2 CB 2-e with Public Address Replacement Parts List............6
3.3 Cb 2-e with AED Housing Replacement Parts List...............7
3.4 CB 2-s Replacement Parts List.............................................8
4 Installation Instructions.................................................................9
4.1 CB 2-e Installation Instructions.............................................9
4.2 CB 2-e with Public Address Installation Instructions...........13
4.3 Cb 2-e with AED Housing Installation Instructions..............16
4.4 CB 2-s Installation Instructions...........................................19
4.5 Pole Mount Bracket Installation Instructions.......................22
5 Wiring Diagrams...........................................................................23
5.1 CB 2-e Wiring Diagram.......................................................23
5.2 CB 2-e with Public Address Wiring Diagram.......................24
5.3 Cb 2-e with AED Housing Wiring Diagram..........................25
5.4 CB 2-s Wiring Diagram........................................................26
5.5 CB 2-e and CB 2-s PoE Wiring Diagram.............................27
6 Maintenance Schedule..................................................................28
6.1 CB 2-e with AED Housing Access and Maintenance...........30
7 Locating Unit Serial Numbers......................................................31
8 Warranty.........................................................................................32
9 Download Information...................................................................33

Code Blue •259 Hedcor Street •Holland, MI 49423 USA •800.205.7186 •www.codeblue.com GU-149-Bpage 3 of 33
CB 2 Series
Administrator Guide
2 Introduction
The 2 Series Wall Mount Help Points
This popular line is a good t for any indoor or outdoor application including parking facilities. Our
unmistakable craftsmanship makes our Help Points®the most rugged on the market, withstanding
the punishment of natural and man-made disasters. With durable construction, our wall mount units
can meet any requirement or purpose. All 2 Series units have a rugged steel construction, shat-
terproof Lexan Lens, industrial engineering grade reective graphics and weather, UV and grafti
resistant paint. Lighting with a high-powered, 270 lumens / 92 candela LED blue beacon/strobe.
Other options include:
• IP and analog phones
• Long-life LED area light
• Low powered consumption LED faceplate light
• Camera and card reader openings
• Temperature controlled automated external debrillator (AED) housing
• Public address speakers (PAS) housing
CB 2-e CB 2-e with Public Address CB 2-e with AED Housing CB 2-s

Code Blue •259 Hedcor Street •Holland, MI 49423 USA •800.205.7186 •www.codeblue.com GU-149-Bpage 4 of 33
CB 2 Series
Administrator Guide
3 Getting Started
Basic Install Instructions
1. EIA/TIA, ANSI, CSA and BICSI cabling or similar standards shall be adhered to for proper
operation of Code Blue communication devices connected to copper or ber infrastructures.
Communications cable and electrical cable in the same conduit is not an acceptable instal-
lation and shall not be supported. Analog phones require a minimum of 23mA for proper
operation (26-29mA recommended).
2. Each analog speakerphone requires its own phone line or PBX extension. Multiple units
shall not be supported.
3. Speakerphones require programming before operation. Consult the User Guide or
Administrator Guide enclosed with the unit or go to www.codeblue.com > Support >
Downloads to read or download manuals.
4. If you are installing IP speakerphones, please read the appropriate manuals and consult
with your Network
Administrator.
5. Size electrical wiring based on length of run.
6. Consult the enclosed document packet for internal wiring instructions.
What’s Included
Quantity Part Description
1Document packet (Installation and Setup)
1 Hardware packet
4 Lag screw sleeves
4 Metal washers
4 Rubber washers
1Security bit
1Enclosure (CB 2-e, CB 2-e with PAS, CB 2-e with AED or CB 2-s)
2Faceplate screws – CB 2-s only
2Key fobs – CB 2-e with AED only

Code Blue •259 Hedcor Street •Holland, MI 49423 USA •800.205.7186 •www.codeblue.com GU-149-Bpage 5 of 33
CB 2 Series
Administrator Guide
3.1 CB 2-e Replacement Parts List
Part Part Number
LED Strobe Light 40159
Button Head Security Screws (3 pack) 41418
Analog Phone Line Surge Suppressor 41471
IP Phone Line Surge Suppressor 41421
Manifold R/B 5-way 40101
Power Brick 120V, 240V, 277V, & 347V 40104
CB 2-e

Code Blue •259 Hedcor Street •Holland, MI 49423 USA •800.205.7186 •www.codeblue.com GU-149-Bpage 6 of 33
CB 2 Series
Administrator Guide
3.2 CB 2-e with Public Address Replacement Parts List
Part Part Number
LED Strobe Light 40159
Button Head Security Screws (3 pack) 41418
Analog Phone Line Surge Suppressor 41471
IP Phone Line Surge Suppressor 41421
Manifold R/B 5-way 40101
PAS AMP Kit 24V 40009
Power Brick 120V, 240V, 277V, & 347V 40104
PAS Speaker 40080
CB 2-e with
Public Address

Code Blue •259 Hedcor Street •Holland, MI 49423 USA •800.205.7186 •www.codeblue.com GU-149-Bpage 7 of 33
CB 2 Series
Administrator Guide
3.3 CB 2-e with AED Housing Replacement Parts List
Part Part Number
LED Strobe Light 40159
Button Head Security Screws (3 pack) 41418
Analog Phone Line Surge Suppressor 41471
IP Phone Line Surge Suppressor 41421
Manifold R/B 5-way 40101
Power Brick 120V, 240V, 277V, & 347V 40104
AED Housing Door Release Mechanism 41104
AED Housing Heater 41105
AED Housing Thermostat 41106
AED Housing Door Controller 41107
AED Housing Retrot kit 40012
CB 2-e with
AED Housing

Code Blue •259 Hedcor Street •Holland, MI 49423 USA •800.205.7186 •www.codeblue.com GU-149-Bpage 8 of 33
CB 2 Series
Administrator Guide
3.4 CB 2-s Replacement Parts List
Part Part Number
LED Strobe Light 40159
Button Head Security Screws (3 pack) 41418
Analog Phone Line Surge Suppressor 41471
IP Phone Line Surge Suppressor 41421
Manifold R/B 5-way 40101
Power Brick 120V, 240V, 277V, & 347V 40104
LED Area Light 41539
CB 2-s

Code Blue •259 Hedcor Street •Holland, MI 49423 USA •800.205.7186 •www.codeblue.com GU-149-Bpage 9 of 33
CB 2 Series
Administrator Guide
4 Installation Instructions
4.1 CB 2-e Installation Instructions
Pre-Installation
Electrical preparation – The unit may have supply wires run either behind the unit through the wall
or below the unit by using an external conduit through the bottom of the unit. Holes in the back and
the bottom of the unit have been provided for this purpose.
Installation Procedures
1. Remove the top of the unit.
2. Mark the mounting holes – In order to comply with the Americans with Disabilities Act
(ADA) of 1990, the speakerphone button(s) should be positioned between 34 and 48 inches
from grade level. (Consult an ADA specialist in your area to verify local and federal
guidelines.)
3. Drill all marked holes.
4. Install the housing – Four anchors of appropriate size and type should be used to
fasten the housing to the wall.
IMPORTANT: If wiring is being supplied from the back, ensure that the conduit is aligned at
this time.
5. Reattach the top.
Wiring
1. Ground – The ground (green) wire should be stripped and fastened to the supplied
grounding lug.
2. 12-24V AC / DC - The enclosure comes pre-wired, except for incoming power. Bring
incoming power to the harness or pigtails. A Certied Electrician should do any wiring.
120V AC – The enclosure comes pre-wired except for incoming power. If you are using a
Code Blue Power Supply/Transformer, please look at the wiring diagram on top of the Step-
Down Transformer to verify how to step down the voltage that you are bringing to the
enclosure. A Certied Electrician should do any wiring.

Code Blue •259 Hedcor Street •Holland, MI 49423 USA •800.205.7186 •www.codeblue.com GU-149-Bpage 10 of 33
CB 2 Series
Administrator Guide
CB 2-e Additional Options
HIKVISION Network Mini Dome Camera
The HIKVISION Mini Dome Network IP Camera installed in this unit is a Code Blue 3rd Party
Partner product. Model # DS-2CD7153-E.
The network camera is set with the following factory default settings:
1. IP Address: 192.0.0.64
2. Camera is accessed on IP Port 8000
3. User Name: admin
4. Password: 12345
For additional support, contact HIKVISION at:
1. Website: http://www.hikvision-usa.com/support.html
2. Phone: [phone], 6 a.m. to 6 p.m. PST
3. Email: [email protected]
Note: Please contact Code Blue Customer Service if a custom cutout is needed in the CB 2-e
for third party products, such as a card reader or a custom camera to mount inside the CB 2-e
enclosure.
Contact Code Blue Customer Service at 1-800-205-7186 or [email protected].

Code Blue •259 Hedcor Street •Holland, MI 49423 USA •800.205.7186 •www.codeblue.com GU-149-Bpage 11 of 33
CB 2 Series
Administrator Guide
CB 2-e Installation Instructions (continued)

Code Blue •259 Hedcor Street •Holland, MI 49423 USA •800.205.7186 •www.codeblue.com GU-149-Bpage 12 of 33
CB 2 Series
Administrator Guide
CB 2-e Installation Instructions (continued)
Suggested installation dimensions shown from ground to lower right mounting hole are for single
button faceplates.
• For dual button faceplate, deduct 3.25 inches.
• For keypad faceplate, deduct 4.5 inches.
• For wheelchair direct facing access only, deduct 6 inches.
DISCLAIMER: The dimensions above are intended as guidelines only. For specic installation
requirements reference your local codes.
All wiring must be installed and connected by experienced and certied personnel to meet local and
national electrical codes, and will include a service disconnect.

Code Blue •259 Hedcor Street •Holland, MI 49423 USA •800.205.7186 •www.codeblue.com GU-149-Bpage 13 of 33
CB 2 Series
Administrator Guide
4.2 CB 2-e with Public Address Installation Instructions
Pre-Installation
Electrical preparation – The unit may have supply wires run either behind the unit through the wall
or below the unit by using an external conduit through the bottom of the unit. Holes in the back and
the bottom of the unit have been provided for this purpose.
Installation Procedures
1. Remove the top of the unit.
2. Mark the mounting holes – In order to comply with the Americans with Disabilities Act
(ADA) of 1990, the speakerphone button(s) should be positioned between 34 and 48 inches
from grade level. (Consult an ADA specialist in your area to verify local and federal
guidelines.)
3. Drill all marked holes.
4. Install the housing – Four anchors of appropriate size and type should be used to
fasten the housing to the wall.
IMPORTANT: If wiring is being supplied from the back, ensure that the conduit is aligned at
this time.
5. Reattach the top.
Wiring
1. Ground – The ground (green) wire should be stripped and fastened to the supplied
grounding lug.
2. 12-24V AC / DC - The enclosure comes pre-wired, except for incoming power. Bring
incoming power to the harness or pigtails. A Certied Electrician should do any wiring.
120V AC – The enclosure comes pre-wired except for incoming power. If you are using a
Code Blue Power Supply/Transformer please look at the wiring diagram on top of
the Step-Down Transformer to verify how to step down the voltage that you are bringing
to the enclosure. A Certied Electrician should do any wiring.
Communications Wiring
Have category 3 or higher 4 pair cable terminated to a RJ45 applying TIA/EIA T568-B specications.

Code Blue •259 Hedcor Street •Holland, MI 49423 USA •800.205.7186 •www.codeblue.com GU-149-Bpage 14 of 33
CB 2 Series
Administrator Guide
CB 2-e with Public Address Installation Instructions (continued)

Code Blue •259 Hedcor Street •Holland, MI 49423 USA •800.205.7186 •www.codeblue.com GU-149-Bpage 15 of 33
CB 2 Series
Administrator Guide
CB 2-e with Public Address Installation Instructions (continued)
Suggested installation dimensions shown from ground to lower right mounting hole are for single
button faceplates.
• For dual button faceplate, deduct 3.25 inches.
• For keypad faceplate, deduct 4.5 inches.
• For wheelchair direct facing access only, deduct 6 inches.
DISCLAIMER: The dimensions above are intended as guidelines only. For specic installation
requirements reference your local codes.
All wiring must be installed and connected by experienced and certied personnel to meet local and
national electrical codes, and will include a service disconnect.

Code Blue •259 Hedcor Street •Holland, MI 49423 USA •800.205.7186 •www.codeblue.com GU-149-Bpage 16 of 33
CB 2 Series
Administrator Guide
4.3 CB 2-e with AED Housing Installation Instructions
Pre-Installation
Electrical preparation – The unit may have supply wires run either behind the unit through the wall
or below the unit by using an external conduit through the bottom of the unit. Holes in the back and
bottom of the unit have been provided for this purpose.
Installation Procedures
1. Remove the top of the unit.
2. Mark the mounting holes – In order to comply with the Americans with Disabilities Act
(ADA) of 1990, the speakerphone button(s) should be positioned between 34 and
48 inches from grade level. (Consult an ADA specialist in your area to verify local and
federal guidelines.)
3. Drill all marked holes.
4. Install the housing – Four anchors of appropriate size and type should be used to
fasten the housing to the wall.
IMPORTANT: If wiring is being supplied from the back, ensure that the conduit is aligned at
this time.
5. Reattach the top.
Wiring
120/240V AC supply – Feed the incoming power leads into the supplied J-Box. Connect the ground
to the supplied grounding lug. Connect the neutral to the orange lead for fusing the unit. Connect the
load to the black wires. After completing the wire connections, install the supplied J-Box cover and
ensure all cord grips are secure.

Code Blue •259 Hedcor Street •Holland, MI 49423 USA •800.205.7186 •www.codeblue.com GU-149-Bpage 17 of 33
CB 2 Series
Administrator Guide
CB 2-e with AED Housing Installation Instructions (continued)
11
23.06
15.5
12.53
9.00
3.00
36.00
21.00
8.00
46.72

Code Blue •259 Hedcor Street •Holland, MI 49423 USA •800.205.7186 •www.codeblue.com GU-149-Bpage 18 of 33
CB 2 Series
Administrator Guide
CB 2-e with AED Housing Installation Instructions (continued)
Suggested installation dimensions shown from ground to lower right mounting hole are for single
button faceplates.
• For dual button faceplate, deduct 3.25 inches.
• For keypad faceplate, deduct 4.5 inches.
• For wheelchair direct facing access only, deduct 6 inches.
DISCLAIMER: The dimensions above are intended as guidelines only. For specic installation
requirements reference your local codes.
All wiring must be installed and connected by experienced and certied personnel to meet local and
national electrical codes, and will include a service disconnect.
28.00
BOTTOM
GROUND LEVEL
3.00
36.00
21.00
9.00
8.00
12.40
Ø .44 MOUNTING HOLES
4 PLCS
Ø 1.13
KNOCKOUTS FOR Ø3/4 CONDUIT
2 PLCS
45.22
Ø 1.13
THRU BOTTOM PLATE FOR Ø3/4 CONDUIT
2 PLCS
8.00
2.20
REF
1.62
MOUNTING SURFACE

Code Blue •259 Hedcor Street •Holland, MI 49423 USA •800.205.7186 •www.codeblue.com GU-149-Bpage 19 of 33
CB 2 Series
Administrator Guide
4.4 CB 2-s Installation Instructions
Pre-Installation
Electrical preparation – The unit may have supply wires run either behind the unit through the wall
or below the unit by using an external conduit through the bottom of the unit. Holes in the back and
the bottom of the unit have been provided for this purpose.
Installation Procedures
1. Remove the light bracket and outer shell from the back plate.
2. Mark the mounting holes – In order to comply with the Americans with Disabilities Act
(ADA) of 1990, the speakerphone button(s) should be positioned between 34 and 48 inches
from grade level. (Consult an ADA specialist in your area to verify local and federal
guidelines.)
3. Install the back plate – Four anchors should securely fasten the back plate to the wall.
IMPORTANT: If wiring is coming in from the back, ensure that the conduit is aligned at
this time.
4. Reattach the light bracket.
5. Reattach the outer shell – Holding the shell horizontal, hook the bottom hinge into the
bottom of the back plate. Swing the shell up and fasten the safety cable to the eyehook.
6. Connect electrical and communications wiring (see wiring instructions).
7. Close the unit – Fasten the outer shell to the back plate using two #10
countersunk security screws.
Wiring
1. Ground – The ground (green) wire should be stripped and fastened to the supplied
grounding lug.
2. 12-24V AC / DC - The enclosure comes pre-wired, except for incoming power. Bring
incoming power to the harness or pigtails. A Certied Electrician should do any wiring.
120V AC – The enclosure comes pre-wired, except for incoming power. If you are using a
Code Blue Power Supply/Transformer, please look at the wiring diagram on the top of
the Step-Down Transformer to verify how to step down the voltage that you are bringing
to the enclosure. A Certied Electrician should do any wiring.

Code Blue •259 Hedcor Street •Holland, MI 49423 USA •800.205.7186 •www.codeblue.com GU-149-Bpage 20 of 33
CB 2 Series
Administrator Guide
CB 2-s Installation Instructions (continued)
