Coffee Queen CAFE ELITE User manual

User manual
CAFÉ ELITE
Your retail dealer
Rev. 110119
U_EN

1. Table of contents.
1. Contents sid. 2
2. General; Warning and safety/ Function descriptions 3-4
3. Overview components, front 5
3. Overview components, inside 6
3. Overview components, membrane switch 7
3. Overview, user card 8
4. SERVICE; Installation and start up 9
Place machine 9
Connecting electrical, water 9
First start up 10
Fill ingredients containers 11
5. Operation
Dispensing drinks 12
Brewing of jug 13
6. Cleaning Daily cleaning
Automatic cleaning of mixer system 14
Automatic cleaning of valves 15
7. Cleaning Weekly
Disassemble mixer system 16
Wash parts 17
Re-install mixer system 18
8. Failure messages 19
9. Storage and transport 19
10. Cleaning and maintenance 19
11. PROGRAMMING Activate with user card 20
Programming Main menu 21
Clean Machine 22
Counters 23-24
2.

2. General. CAFÉ ELITE
Congratulations on choosing a Café Elite Instant coffee machine .
 Readthismanualbeforeusingthecoffeemachineforthersttime.
  Onlyqualiedpersonnelshouldinstallthemachine.
Check that all parts are free of defects. If they are not, stop the installation and contact
your dealer.
Keep this manual in a safe place.
 CremInternationalABiscertiedinaccordancewithISO9001andISO14001,
  ensuringthatitsproductshavethelowestpossibleenvironmentalimpact.
Warningsandsafetyregulations:
The manufacturer is not liable for personal injuries or damages caused by the machine
when is used in a way other than the manner described in the manual.
Likewise, the manufacturer cannot be held liable if maintenance or safety regulations
are neglected.
The warranty will become void if the machine is used in a way other than the manner
described in the manual. The machine may only be operated by an adult.
- The user must be an adult. The machine may not be used by children or other
unsuitable individuals.
- The user must observe the safety regulations applicable in the user’s country.
- The user must also use common sense.
- The user, installer or service technician must inform the manufacturer of any defects or
wear that may jeopardise the machine’s original safety.
- The installer must check the conditions at the place of use, to ensure hygienic and safe
use for the user and customers.
- The manufacturer is responsible for the machine components, and the buyer for
ensuring that trained personnel use the machine.
3.

2. General. CAFÉ ELITE
Functiondescription:
Café Elite has three nozzles, one for hot water and two for a choice of other drinks.
Café Elite has eight buttons, one of which is generally reserved for hot water only and
the others are programmable for dispensing a choice of other drinks.
Café Elite can be programmed to dispense a set volume.
Café Elite canbeprogrammedtodispensecontinuousowfromdispensernozzleor
self-closing faucet.
Firststartup
Turn ON the main switch behind the door, display will show: “water level low”
  “PressEnter”PresstheEbuttontoconrm.
EnergySavingMode:
Hold the stop button for 5 seconds. Display will show standby.
When the machine goes into standby mode, drinks cannot be dispensed and the
water temperature falls to the block ambient temperature.
To return to operation mode, press the stop button for 5 seconds.
Fact:  
Height 735 mm
Width 310 mm
Depth 515 mm
Electrical connection. 1-phase 230V/2200W
Coldwaterconnection: ½” Radius external thread
Ambient temperatures for correct operation +5ºC - +50ºC
Note:Alloptionsmustbeconnectedandinstalledbyaqualiedelectrician.
4.
4 Canisters
Canister: Width Depth Height volume/litre;
coffee 67 225 335 2,7
espresso 67 225 335 2,7
chocolate 67 225 335 2,7
topping 67 225 335 2,7
3 Canisters
Canister: Width Depth Height volume/litre;
coffee 137 225 335 2,7
chocolate 67 225 335 2,7
topping 67 225 335 2,7

5.
3.Viewofcomponents,front    CAFÉELITE
Strength of drinks
++ or - -
Card reader
Key switch
(cup and jug)
Door
lock
Drinks
outlet
Drip tray
insert
Drip tray
Display

6.
3.Viewofcomponents,inside    CAFÉELITE
ON/OFF
mainswitch
Canisters
Chute
Canister
 lids
Mixingbowl
 Servicelid
(for emptying
water tank)
Drinks
outlet

7.
3.Overviewofcomponents,membraneswitch  CAFÉELITE
Membraneswitch,functionbuttons
Press the + button if you wish to increase the
strength of the drink or go forwards in menu.
Press the - button if you wish to decrease the
strength of the drink or go backwards in menu.
Press the Back button if you want to leave the
submenu and go back to the main menu.
Press the Enter button if you want to enter the
menu, change a value or a setting.
Conrmthenewsettingbypressingthebutton.
Press the STOP button to go back to the start
position in service menu. Press the STOP
button if you want to return to the start menu.
ENERGYSAVINGMODE button. Keep the
STOP button pressed down for c. 5 seconds.
The display shows; Energy Saving Mode. To
return to normal setting, keep the Stop button
pressed down for 5 sec.
E
E
ENERGY SAVING MODE, the machine switches off the front display and
decreases the temperature in the water tank to c. 65°C.

5. Overviewofcomponents, function buttons AC12
8.
3.Overviewofcomponents,UserCard   CAFÉELITE
USERCARD.
Insert the user card, according to the illustration.
USER CARD Item number: 1602693.is used for adjusting drinks and counters.
The user card is supplied by your dealer.
To use the machine again. Remove the card and keep it in a safe place.

4.Service.  Installationandstarting  CAFÉELITE
4.1.Placethemachineonaat Connect the electrical plug to a separate
waterproof surface. grounded wall socket
         Groundedwallsocket
          230V10A
Attention!
Make sure there is a space behind the
        machineforfreeowofair.(minimum10cm).
4.2. Water connection
Connect to a coldwatersupplyinlet1/2”Radius using the tube supplied.
Inareaswithhighlevelsoflime,awaterltershouldbeinstalled.
Make sure that the water tube does not have any kinks anywhere when the machine is
moved into place. Pleaseushthewatertubebeforeconnectingtothemachine,this
  istoushoutanyparticleswhichmightotherwisedamagetheinletvalve.
4.3. Open the water inlet.
9.
90º

4.Service.  Installationandstart   CAFÉELITE
Firststartup
4.4. Open the door.
 4.5. Turn ON the main switch behind the door.
4.6. Close the door.
4.7. The display will show: “water level low”
“Press Enter”
4.8. Press the button to start up machine.
 4.9.Displayenshows:“llingwater”
 4.10. Thetankisnowlledautomaticallywith5,0litresofwater.
Heating will not start until the water level reaches the level sensor.
Defaulttemperatureisapprox.85ºC.
  4.11. Machineisreadytouse when ”Select product”, ”Temp” shows in display.
10.
ON/OFF
mainswitch
Selectproduct
Temp 85ºC

11.
4.Service.  Installationandstart   CAFÉELITE
4.12. Fillcanisterswithingredients. 
Takeoutingredientcanisters(toavoidanyspillageinthemachine)andll
them with ingredients.
4.12.1. Loosen ingredients canister.
4.12.2.Removelidandllwith ingredients.
4.12.3. Reassemble canisters.
Whenplacingtheingredientcanisters;
Make sure that the outlet pipes on the ingredient canisters are touching
the steam traps (A).
(A).
(A).

5.1. Placeacupinthecentreofthedriptray.
5.2. The strength has a standard setting,
if you wish to increase or decrease it, do as
follows.
For a stronger drink increase by pushing button.
or alternatively
For a weaker drink decrease by pushing button.
5.3. Choose drink.
12.
5.Operation; Dispensingdrinks   CAFÉELITE
E

 Brewingcoffeeinjug.
1. Place a jug in the centre of drip tray.
Serving pot 1,2L art.no. 1103091
2. Turn on the key with jug symbole clockwise.
3. 6 cups of brewing is standard settings,
Change amount of cups by pushing + or - button.
Optional up to 12 cups or down to 1 cup brewing.
4. Push the button for drink 1.
Wait until the light and message
”Please wait” has been turned off before you
take out the jug.
Serve a jug with good coffee.
Serving pot 1,8L art.no. 110001
Serving pot 1,2L art.no. 1103091
13.
5.Operation.Brewingcoffeeinajug.   CAFÉELITE
E
2

14.
 6.CLEANING: DailyCleaning   CAFÉ ELITE
Automaticcleaningofmixingsystem.
E
1. Put a container that takes c. 0.5 litres under the dispenser
2. Insert the user card in the card reader.
3. Display shows ServiceMenu,CleanMachine.
4. Press the E button.
5. Move through the menu until the display shows
SelectCleaning,CleanMixer.
6. Press the E button.
7. The machine will no clean the mixing bowls for c. 5 seconds.
Note: Repeat the cleaning procedures 2-3 times.
8. Remove the user card..
Cleaningmeansrinsingwithwaterandrotatingthe
whippermotor.

15.
 6.CLEANING: DailyCleaning   CAFÉ ELITE
Automaticcleaningofvalves.
E
1. Put a container that takes c. 0.5 litres under the dispenser.
2. Insert the user card in the card reader.
3. Display shows ServiceMenu,CleanMachine.
4. Press the E button.
5. Move through the menu until the display shows
SelectCleaning,CleanValves.
6. Press the E button.
7. Dispenser valves will not start to open and close with
3 pulses/second for a max of 6 seconds.
Repeat the procedure 2 - 3 times.
8. Remove the user card.
Cleaningentailsthatthevalves"knock"offanylime
      scaleandotherparticlesthatmaygetstuckinthe
      cylindersandushingthemwithwater.

7. CLEANING:  Weeklycleaning   CAFÉELITE
16.
Disassemble:themixersystem
1. Loosencanisterandoutputhose.seeg.1.
  2. Turntheleveranticlockwise.seeg.2.
  3. Loosenthemixingbowlbypullstraightout.seeg.3.
(C)
Fig 1. Fig 2. Fig 3.
4. Loosenwhipperbypullingitstraightout.seeg.4
  5. Loosenthemountingplate.Turntheleveranticlockwise,untilitstops.seeg.5.
  Fig4.  Fig5.
Reassembly
mixingsystem.
Seenextpage.

7. CLEANING:   Weeklycleaning  CAFÉELITE
17.
Washtheseparts.
Mixing bowl Condensation trap Mounting plate Whipper
Fig 6. Fig 7. Fig 8.
Clean with a moist
cloth and wipe dry.
Reassemblymixersystemreversed.
6. CHECKallsealsbeforereassemblyofparts.seeg.6.
7. The plane side of the whipper motor shaft must correspond with the marking
onthewhipper.seeg.7.
8. Fit the whipper, push until a slight clicking sound can be heard. Follow the
instructionsofthemixer,arrow.Itisonlypossibletotthewhipperinoneway.
  seeg.8.
Allpartsmustbedrybeforereassembly.
CHECK all
seals
      Fig9.
9. Fix the mixing bowl and
condensation trap.
  Push-tthemixerbowlandx
with lever. Connect the output
hose.
OBS! ensure that all water hoses
  havebeenconnectedandtted.
  seeg.9.

18.
8. Failure messages.
 9.Storage/Transport.
1. Display shows: ”water level low” ”Press enter”.
Check if water tap is open.
Press button.
2. Display shows normal: but no drink is coming.
Possible cause of failure:
Mechanical stop in the ingredients canisters
or whipper unit.
 Action:Trytondthecauseoffailure.
Clean the mixer system and try again.
  Transportandnotinuseforalongperiod.
1. Turn off the switch, pull out the electric plug and close
incoming water tube.
2. Long machine storage at temperatures below 0ºC can
cause damage of the machine.
It is recommended to empty all the water in the machine.
 Failuremessageswhichcanmostlybecorrectedwithoutanyhelpfrom
 servicecompany
”water level low”
”press enter”

Cleaningtheoutside;
Use a soft rag and liquid cleaning
agent to prevent scratches.
19.
10.Cleaningandmaintenance.  CAFÉ ELITE
TOBEWASHEDASNEEDED
Driptrayanddriptrayinsertshouldbewashedbyhandinordinarydishwater.
Donotwashinadishwashingmachine!
NB:Allpartsmustbedrybeforebeingre-inserted.
NOTE!
Themachinemustnotbecovered
withorimmersedinwater.

20.
11.PROGRAMMING      CAFÉ ELITE
  Activateprogrammingwiththeusercard.
1.  Inserttheusercardinthecardreader.
  2. Displayenshows:Service Menu, Clean Machine
Press this button if you wish to increase a value
or step forward in the menu.
Press this button if you want to reduce a value
or go back in the menu.
Press this button if you wish to leave the submenu and
return to the main menu.
Press the enter button if you want to enter a menu, alter the value or a setting.
Alter a value by pressing the button or the button.
ConrmthenewsettingbypressingtheE-button.
  Functionbuttonsprogramming
Press the STOP button if you wish to return to the service menu.
