Compak K3 TOUCH User manual

PROFESSIONAL ESPRESSO
K3
K3 ELITE
K6
K6 SILENZIO
K6 PB
K8 SILENZIO
K10 CONIC
K10 CONIC PB
K10 MASTER CONIC
K10 MASTER CONIC PB
coffee grinders
instructions manual

index
1. SAFETY MEASURES 1
2. DESCRIPTION 2
3. INSTRUCTIONS 3
4. IDENTIFICATION 3
5. TECHNICAL CARACTERISTICS 4
6. INSTALLATION 6
7. REGULATION 8
8. OPERATION 10
9. CONFIGURATION 13
10. CLEANING 14
11. MAINTENANCE 16
12. EC CONFORMITY 21

K01068 | v. 22/09/2014 | Ref. quality process 002/03 | ORIGINAL INSTRUCTIONS 1
1. SECURITY
NOTE: The manufacturer will not be held responsible for any damages resulting from
improper use of the equipment, or for not following the safety measures as outlined
below.
Safety measures incorporated into our grinders:
• Specialscrewtomaintainthehopperxedinplace.
• Accessrestrictorinthegrindgroup.
Owners: Please pay careful attention with the following instructions:
• The grinder should be used exclusively for the function for which it was
designed:grindingwholebeancoffee.
• Donotusethisgrindertogrindothertypesoffoodproductssuchasdryfruit,
sugarorspices.
• The grinder should not be used by children or individuals with physical, or
mentallimitationsthatcouldresultinriskofinjuryormisuse.
• Anyotheruseofthemachinewillbeconsideredimproperanddangerous.
• Donotputliquidsincontactwithinternalorexternalpartsofthisgrinderwhile
ON or OFF,withtheexceptionofpartsexpresslyoutlinedinthe“CLEANING”
section of this manual. If liquids do come in contact with the grinder,
immediatelydisconnectelectricalconnectionandcarefullycleantheaffected
areas.Ifitisnecessarytoaccesstheinteriorpartsofthegrinder,contactyour
localserviceprofessional.
• Incaseofanydamagetopartsorcomponents,werecommendcontactingyour
local service professional to help with repair or replacement of such parts,
therebyguaranteeingthemaintenanceofthesecuritystandardsofthegrinder.
• Only an authorized distributor should replace the main power cable of the
grinder.

ORIGINAL INSTRUCTIONS | Ref. quality process 002/03 | v. 22/09/2014 | K01068
2
SOUNDDECIBELLEVEL
The level of sound emitted in different models is:
Sounddecibellevel With coffee
K3, K3 ELITE 75,3 dB
K6, K6 PB 73,2 dB
K6 SILENZIO 68,7 dB
K8 SILENZIO 70,2 dB
K10 CONIC, K10 CONIC PB 68,4 dB
K10 MASTER CONIC, K10 MASTER CONIC PB 67,8 dB
2. DESCRIPTION
Your new grinder has been designed using the most sophisticated technologies in
existence. The result is a product of high quality that offers the assurance of the best
results possible. Our products are manufactured by hand, one by one, following the
strictest quality requirements. In the manufacturing process, we use only the highest
quality materials (aluminum, stainless steel, etc.) especially designated for being in
contact with food stuff.
For the optimum functionality of the grinder models described in this user manual,
the maximum work cycles are as follows:
Model
Workingcycle
ON OFF
K3, K3 ELITE 2 minutes 10 minutes
K6, K6 SILENZIO, K6 PB 5 minutes 10 minutes
K8 SILENZIO, K10 CONIC, K10 CONIC PB 2 minutes 10 minutes
K10 MASTER CONIC, K10 MASTER CONIC PB 2 minutes 10 minutes

K01068 | v. 22/09/2014 | Ref. quality process 002/03 | ORIGINAL INSTRUCTIONS 3
3. INSTRUCTIONS
3.1. This manual is designed to provide the necessary information to correctly
install, use and maintain the grinder, as well as to highlight precautions for users to
keep in mind. To ensure the best operation of the coffee grinder, please follow the
instructions as outlined in this manual. This manual should be saved for the life of the
grinder, and should always be at the disposal of the operator.
3.2. This manual contains special terminology such as:
• Words in BOLD indicate important points or terminology.
• Numbers in parenthese after a word, indicate the location of this item in a parts
diagram.
Example: ( ) - Hopper lid
• Icons:
Information Atention
4. IDENTIFICATION
In the grinder information plaque is the following manufacturing/product information.
NOTE: Themanufacturerreservestherighttochangecomponents/congurationsof
any model, according to the different geographic market demands.

ORIGINAL INSTRUCTIONS | Ref. quality process 002/03 | v. 22/09/2014 | K01068
4
5. TECHNICAL CARACTERISITICS
5.1.Usage
The coffee grinders are intended for use on commercial premises and facilities where
ground coffee is required, or in small stores that sell coffee. The grinder must only be
used to grind coffee beans. Any use other than this will be considered improper and
dangerous.
NOTE: The manufacturer will not be held responsible for any damages resulting from
improper use of the equipment, or for not following the safety measures as outlined
below.
5.2.Technicaldata
Model 100V
50Hz
100V
60Hz
110V
60Hz
220V
60Hz
230V
50Hz
240V
50Hz
400Vψ
50Hz
208V
60Hz
K3,
K3 ELITE
Electric
power 200 200 230 210 210 225 (W)
Spin
speed 1,320 1,620 1,650 1,640 1,340 1,345 rpm
K6,
K6 SILENZIO,
K6 PB
Electric
power 230 230 250 265 240 240 (W)
Spin
speed 1,320 1,600 1,650 1,700 1,395 1,400 rpm
K8
SILENZIO
Electric
power 380 400 440 420 400 440 (W)
Spin
speed 1,300 1,450 1,140 1,600 1,325 1,330 rpm
K10 CONIC,
K10 CONIC
PB
Electric
power 890 960 825 825 800 850 780 840 (W)
Spin
speed 1,340 1,550 1,600 1,500 1,300 1,325 1,400 1,600 rpm
K10 MASTER
CONIC,
K10 MASTER
CONIC PB
Electric
power 850 1,000 935 930 950 975 780 840 (W)
Spin
speed 326 378 325 388 340 345 350 390 rpm

K01068 | v. 22/09/2014 | Ref. quality process 002/03 | ORIGINAL INSTRUCTIONS 5
Model
K3,
K3 ELITE
K6,
K6 SILENZIO,
K6 PB
K8 SILENZIO
K10 CONIC,
K10 CONIC
PB
K10 MASTER
CONIC,
K10 MASTER
CONIC PB
ØBurrs 2.3
58
2.5
64
3.3
83
2.65
Conic 68
2.65
Conic 68
in
mm
Production*
50Hz
8.2
3,7
13
6
33
15
33
15
37
17
lb/h
Kg/h
Production*
60Hz
9.5
4,3
15
7
38.5
17,5
38.5
17,5
44
20
lb/h
Kg/h
Hopper
capacity
1.76
38.5
3.74
1700
3.74
1700
3.74
1700
3.74
1700
lb
gr
Mini-hopper
capacity
(optional)
0.6
275
0.6
275
0.6
275
0.6
275
0.6
275
lb
gr
Doser
capacity
0.66
300
0.66
300
0.66
300
0.66
300
0.66
300
lb
gr
Doserlever
position
right
left
right
left
right
left
right
left
right
left
Net weight 15.07
6,85
25.47
11,58
28.6
13
7.25
16,93
7.25
16,93
lb
Kg
Height
Width
Depth
19.5
6.7
14.37
495
170
365
25
8.46
15.74
635
215
400
25
8.46
15.74
635
215
400
25
8.46
15.74
635
215
400
28.14
8.46
15.74
715
215
400
in mm in mm in mm in mm in mm
Mini-hopper
Height Widht
Depth
16.5
6.7
14.37
420
170
365
22
8.46
15.74
560
215
400
22
8.46
15.74
560
215
400
22
8.46
15.74
560
215
400
25.14
8.46
15.74
640
215
400
in mm in mm in mm in mm in mm
* Production is based on a medium-roasted coffee and an Espresso grind.

ORIGINAL INSTRUCTIONS | Ref. quality process 002/03 | v. 22/09/2014 | K01068
6
6. EXTERNAL COMPONENTS
K10 MASTER CONIC

K01068 | v. 22/09/2014 | Ref. quality process 002/03 | ORIGINAL INSTRUCTIONS 7
K3 ELITE

ORIGINAL INSTRUCTIONS | Ref. quality process 002/03 | v. 22/09/2014 | K01068
8
7. INSTALLATION
7.1.GeneralWarnings
The person installing the grinder should carefully read this instruction manual
before installation. The installation of this machine should be completed by
qualiedandauthorizedpersonnel,andallnormsofsafetyandsanitationshouldbe
followed.
7.2.ImportantWarnings
The operator of the grinder should be a responsible adult, and a never a minor
or person incapable of safely using such equipment. Whenusingthegrinder,
the following precautions should be followed:
• Nobarefeet.
• Nowethandsorfeet.
• Donotsubmergeinwater.
• Donotexposethegrindertosunorotheratmosphericconditions.
• Donotplaceanytypeofobjectinthecoffeeentranceorexitwhilethegrinder
isrunning.(Itshouldbekeptinmindthatthecuttingburrscontinueturningfor
acouplerevolutionsafterthegrinderispoweredoff).
• To disconnect the grinder, use the main power switch and never the power
cable,toavoidapossibleshortcircuit.

K01068 | v. 22/09/2014 | Ref. quality process 002/03 | ORIGINAL INSTRUCTIONS 9
7.3.Wheretouse
The grinder should be installed on a at, stable surface. The minimum
dimensions of the work space should be as follows:
Model Height Width Depth
K3, K3 ELITE 20.27 515 7.28 185 15.15 385
K3, K3 ELITE
Mini-hopper (optional)17.32 440 7.28 185 15.15 385
K6, K6 SILENZIO, K6 PB 25.78 655 9.25 235 16.53 420
K8 SILENZIO 25 655 9.25 235 16.53 420
K10 CONIC, K10 CONIC PB 25 655 9.25 235 16.53 420
K10 MASTER CONIC,
K10 MASTER CONIC PB 28.1 735 9.25 235 16.53 420
in mm in mm in mm
7.4.GrinderInstallation
Before grinder installation, the following should be considered:
• The grinder information plaque data coincides with the electrical system on
site.
• Theelectricaloutletcoincideswiththegrinderplug.
• The electric power at the location of installation should meet the minimum
requiredtoproperlyrunthegrinder.
• Theinstallationsiteshouldhavetheproperelectricaloverloadprotections.
• Thegrindershouldbeproperlygroundedasspeciedbylocalcode.
NOTE: The grinder should be used in environments with mínimum temperature
of 77-86F and should not be installed in places (such as industrial kitchens) where
cleaning is done with direct water spray cleaning.

ORIGINAL INSTRUCTIONS | Ref. quality process 002/03 | v. 22/09/2014 | K01068
10
8. REGULATION
8.1.Grindersetup
Place the hopper ( ) on the grind regulator ( ) and make sure the bean trap ( )
is in the closed position. Lock the hopper ( )inplaceusingaatheadscrewdriver
to gently tighten the hopper security screw making it match to the hole at the bean
hopper collar ( ) (Fig. 1).
Remove the hopper lid ( ),llthehopperwithcoffee( ), and replace the lid on the
hopper ( ) (Fig. 2).
Plug in the grinder, and place the main power switch ( ) ON-OFF to position ON and
open the bean trap ( ) to allow coffee to pass into the grind chamber.

K01068 | v. 22/09/2014 | Ref. quality process 002/03 | ORIGINAL INSTRUCTIONS 11
8.2.Grindadjustmentsystem
8.2.1.Micrometricalsystem/Parallelmicrometricalsystem
Rotate the grind regulator ( ) until reaching the grind level desired. Rotating the
grind regulator counterclockwise will result in a courser grind; turning the regulator
clockwisewillresultinanergrinder*(Fig. 3).
Onceyoureachthedesiredgrindingpoint,youcanxthegrindingregulation( )
using the regulation break ( ) (Fig. 4). Except K3 and K3 ELITE models.
*NOTE: Changing grind settings must be done when the grinder is on and burrs are in motion.
Not doing this suposes that the burrs will gunk up and cleaning will be required.
8.2.2.Steppedgrindadjustment
In the stepped adjustment versions, the positions on the grind regulator are limited
by“steps”thataredenedbytheholeandpinpoints(Fig. 5).
The instructions detailed in section 8.2.1. on adjusting the regulator should be
followed, while at the same time, pulling the brake post ( ) (Fig. 5) up to release the
locking action of the post.

ORIGINAL INSTRUCTIONS | Ref. quality process 002/03 | v. 22/09/2014 | K01068
12
NOTE: If the output is very slow, it could mean that the coffee is being ground too
ne.Iftheoutputisveryfast,itcouldmeanthatthecoffeeisbeinggroundtoo
coarse. A perfect espresso grind is found when the grind point gives an infusion of
25 ml of coffee in 25 seconds using 7 grams of ground coffee.
8.3.Regulatingthecoffeeserving
The dispensers are factory adjusted to serve an amount of approximately 7 gr of
ground coffee, but this quantity can be regulated between 6 and 10 gr, as follows:
1. Remove the ground coffee dispenser lid ( ) and turn the dispensing regulation
screw ( ) clockwise to obtain a smaller amount of coffee, and counterclockwise
to obtain a larger amount (Fig. 6).
2. Once the quantity of eachserving has been regulated, replace the ground coffee
dispenser lid ( ).

K01068 | v. 22/09/2014 | Ref. quality process 002/03 | ORIGINAL INSTRUCTIONS 13
9. OPERATION
9.1.Mainswitch
The main swith ( ) has 2 positions of use, ON–OFF
ON: Working
OFF: Not working
9.2.Use
To turn the machine on and off use the ON–OFF switch ( ). The machine will start
to grind the coffee. If the automatic stop option is incorporated, the grinder will stop
grinding when the dispenser reaches the maximum level, and will restart after 8
portions of coffee have been served, grinding again to the maximum level.
If the machine does not incorporate the automatic stop option, we recommend that
youllthedoser75%ofitscapacityinordertoguaranteeconsistentdosing.
Toservethecoffeeservings,placetheportalteronthefork( ) as far in as possible
so that it is positioned under the ground coffee discharge tube. Pull the dispensing
lever ( ) to obtain one coffee serving (one serving is equal to one cup of coffee), and
release it so it returns to its normal position (Fig. 7).
9.3.Staticpress
Taketheportalterandplaceitunderthecoffeetamper( ), pressing upwards to
pack the coffee (Fig. 7).

ORIGINAL INSTRUCTIONS | Ref. quality process 002/03 | v. 22/09/2014 | K01068
14
9.4.Telescopicpress
Whenusingthetelescopiccoffeepressoption,placetheportalter
on the fork ( ) and push the coffee tamper downwards (Fig. 8).
10. CLEANING
10.1.Generalcleaning
To ensure that the grinder functions properly, and produces the highest quality grind
possible, the parts that come into contact with coffee should cleaned periodically.
General Cleaning guidelines as follows:
• Always turn the main power switch to the OFF position ( ).
• Unplug the machine from the power source.
• Do not submerge the grinder in water or use power washing devises.
10.2.Beanhoppercleaning
It is recommended that the grind chamber be cleaned monthly with a cleaner as
recommended by Compak. This process will eliminate smelly residues from the
coffee remains, which can negatively affect the quality of the brewed coffee.

K01068 | v. 22/09/2014 | Ref. quality process 002/03 | ORIGINAL INSTRUCTIONS 15
The steps to follow are:
• Inordertoproperlycleanthebeanhopper,rstemptyoutallremainingbeans
and fragments.
• Close the bean trap on the hopper ( ) and grind out the remaining coffee in the
grind chamber.
• Remove any remaining coffee beans from the bean hopper ( ).
• Pour the recommended grinder cleaning product into the bean hopper ( ) and
open the bean trap ( ), allowing the cleaning product to pass into the grind
chamber.
• Grindthecleaningproductatamediumcoursegrindsettinguntiltherecommended
amount is passed through the system and nothing remains in the grind chamber.
• Clean the hopper ( )andrellwithcoffeebeans.
• Discardtherst2-3dosesofcoffeetoassurethattheresidualcleaningproduct
is removed from the grind chamber and set the grind regulator to the desired
setting ( ).
Following these steps will ensure that the grinder is clean and ready for use.
We do not recommend the taking apart of the grind assembly unless changing burrs,
or removing a blockage/obstruction in the grind chamber. Removal of the grind
assemblyshouldbeperformedbyaqualiedservicetechnician.
10.3.Cleaningdegroundcoffeedeposit
To clean the ground coffee holder, rst empty all the coffee insideit.Remove the
ground coffee dispenser lid ( ) and clean the inside, using a small brush.
10.4.Cleaningtheoutsideofthegrinder
Tocleantheexteriorofthegrinder,rstwipewithadrysoftcloth,andthengently
wipe with a damp soapy cloth.

ORIGINAL INSTRUCTIONS | Ref. quality process 002/03 | v. 22/09/2014 | K01068
16
11. MAINTENANCE
11.1.Generalwarning
Before performing any type of maintenance you should:
• Always turn OFF the main power switch to the OFF position ( ).
• If the grinder is jammed, unplug it from the power source and contact an
authorizedservicetechnician.
Not following these warnings can compromise the safety of the grinder as well as
the user.
11.2.Generalmaintenanceofthegrindchamber
To guarantee the efciency and correct operation of the grinder, it is essential to
follow manufacturer instructions and ensure that all maintenance work is carried
outbyqualiedstaff.
Dull burrs will result in; a lower quality grind, greater heat generation in the coffee
andgrinder,increasedelectricalconsumption,andnallyitputsadditionalstresson
the grinder motor.
NOTE: Based on extensive experience and a medium-hard coffee blend, we
recommend replacing the burrs after grinding 350 Kg/770 lb of coffee.
Burrschange RedSpeedLucidate
K3, K3 ELITE 300 Kg
K6, K6 PB 400 Kg
K6 SILENZIO 400 Kg
K8 SILENZIO 800 Kg 3500 Kg
K10 CONIC, K10 CONIC PB 1200 Kg 7500 Kg
K10 MASTER CONIC, K10 MASTER CONIC PB 1200 Kg 7500 Kg

K01068 | v. 22/09/2014 | Ref. quality process 002/03 | ORIGINAL INSTRUCTIONS 17
11.3.Grindinggroupmaintenance
Not following the recommended burr life guidelines can compromise the safety of
the grinder.
Theseoperationsshouldbedonebyaqualiedservicetecnician.
To perform grind chamber maintenance please observe the following steps:
Turn off the grinder by making sure the main power switch ( )is on the OFF position.
Disconnect the plug from the power source. Loosen the hopper security screw ( )
usingaatheadscrewdriverasseeninFig.1. and remove the hopper ( ) from the
grind regulator ( ). Loosen the screws on the grind regulator ( ) using an Allen key
A3 series for the K3 models following Fig.9. or a Torx T20 screw driver for the rest of
the models as seen in Fig. 10.
For the models with micrometric Parallel system, before removing the grinding
adjustment collar ( ) rotate the grind point lock screw ( ) counterclockwise to
release it from a locked position (Fig. 11).

ORIGINAL INSTRUCTIONS | Ref. quality process 002/03 | v. 22/09/2014 | K01068
18
Rotate the grind regulator clockwise until it is completely unscrewed (Fig. 11) until
the upper and lower burrs touch and can not be turned further. Clean the grind
chamber and threads of the housing using a soft cloth and vacuum cleaner until all of
the oils and residue has been removed.
Make sure to put new food grade lubricant on the clean threading of the housing and
upper assembly. Insert the upper burr assembly into the grind chamber, and turn
counter clockwise.
For positioning and mounting the grinding adjustment ( ) distinguish between
modelswithatburrs,K3, K6 and K8, and the conical burr models K10.
